Behringer LPS 60-T - Vertical Metal Band Saw
- Servo feed with cutting pressure control
- Robust cast iron belt guide
- Quick saw blade change
- Saw drive operating hours: 32441 h
- Year of construction 2017
Technical data
- Working area LxWxH: 1260 x 720 x 600 mm
- Smallest material height: 10 mm
- Smallest section width: 5 mm
- Inner table support surface: approx. 1260 x 680 mm
- Indoor table max. load: 3000 kg
- Outdoor table support surface: approx. 1260 x 680 mm
- Outdoor table max. load: 3000 kg
- Material support height approx.: 1050mm (incl. bottom tray)
- Cutting speed: 10 - 110 m/min
- Saw blade dimensions: 5400 x 54 x 1.6 mm
- System or belt tensioning pressure: 85 bar
- Quantity of cooling lubricant: approx. 100 l
- Motor power - Saw drive: 5.5 kW
- Motor power' hydraulic pump: 2.2 kW
- Engine power - Coolant pump: 0.15 kW
- Motor power - chip conveyor: approx. 0.26 kW
- Connected load: approx. 10.5 kW
- Voltage: 400 V, 50 HZ
- Control voltage / hydraulic vent voltage: 24 V = (DC)
- Current consumption: approx. 31 A
- Fuse: 35 A
- Cable cross-section: min. 10 mm2
- Machine dimensions WxHxD: 3150 x 2970 x 2500 mm
- Weight (net): approx. 3200 kg
