121,997 used machines on RESALE, but how to find them? Machine Search
used
Balancing machine for balancing tool holders in 1 level. Accesories: 80.213.01 Software for balancing by drilling (axial) 80.245.10 Software for calculating alternative compensation positions (TDC 4.0) 80.207.10 Tool scale up to 30kg (for balancing machine) 80.230.00 Calibrator for calibrating the balancing machine TD 1002/2002/2009 80.201.E50.00 Adapter for HSK E50 with clamping system (May only be used in original Haimer Tool Dynamic!), max. tool length: 360 mm, Max. Workpiece diameter: 340 mm, max. tool weight: 15 kg, measurement accuracy: < 0.5mm, Measurement accuracy: < 1 gmm, compressed air: 6 bar, Power consumption: 0,4 kW, Power supply: 230 V / 50-60 Hz, Dimensions W x D x H =: 500 x 680 x 820 mm, mass: 200 kg, colour: black-and-white
used
- Vibration measurement - Balancing in one level - Balancing in two levels - Iterations Method - Trans-red method - Machine weight: 15 kg - Condition: very good Details well-maintained vibration measuring device
used
Balancing machine Capacity: 30 kg Max rotor diameter: 600 mm Balancing speed: 900 rpm Power: 1.5 kW
used
The CIMAT CMT 30 V2 balancing machine was manufactured in 2015 in Poland. Bvcilkrj7m Basic technical data: - software: ROTOTEST - component weight: 0.2 to 30 kg - maximum rotor diameter: 400 mm - maximum rotor height: up to 200 mm - compressed air pressure: 0.6 MPa - balancing machine dimensions: 1200 x 1200 x 1500 mm - control panel dimensions: 600 x 600 x 1800 mm - weight: 500 kg
used
Built-in balancing head DITTEL NS F21378 (for Junkers Jumat 50) Motoren i.O. Balancing weights have play! used, tested ! Dimensions: 160 x 90 x 90 mm
used
Balancing machine CEMB ZE-300 / GV - new in1992 - machine weight 1.8 t, power input 1.8 kW - revolutions 200 - 2000 rpm - length of part for balancing up to 3000 mm
used
workpiece weight: 4 kg workpiece length: 200 mm dia. on complete length: 200 mm Control: Schenck-Lauer electrics - voltage/frequency: 400 / 50 V/Hz dimensions: 4,1 x 4,2 x 2,5 m connected load: 12 kVA flange diameter: 250 mm weight: 4,5 t Balancing machine for rotors - Turbocharger fuselage groups - hydraulic measuring station - Compensation station - Pulsation measuring table - Chip extraction - Measuring instrument CAB 950T - feeding device - Schenck/Lauer Control on Dase of Windows The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Tire balancing machine make HAWEKA type BALCO 9460Fabr. -No: 0507.602.8007.16Technical specifications:max.wheel diameter: 950 mmmax.wheel width: 530 mmmax.wheel weight: 70 kgRim width: 76 - 510/3 - 20 mm / Measurement time:> 6 sec.Measurement speed:
used
Tire balancing machine make HAWEKA type BALCO 9460Fabr. -No: 0507.602.8007.13Technical specifications:max.wheel diameter: 950 mmmax.wheel width: 530 mmmax.wheel weight: 70 kgRim width: 76 - 510/3 - 20 mm / Measurement time:> 6 sec.Measurement speed:
used
Force-measuring dynamic balancing machine make Dr. REUTLINGER type HK 12 LBMachine -No: 5.212.070 built in 1985Technical data:Workpiece weight: 1-100 kgDG 2 and 2.3 x 10 to the power of 6Center height: 340 mmhorizontal adjustment of the recording: 800 mmExternal dimensions approx.: 1800 x 1000 x 1450 mmwith- Measuring device K 2700- Computer MC 100 with screen- removable coverlittle used, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools
used
Balancing valve with bypass TACONOVA TACO - SETTER 223.2461.000 10 - 40 l/min PN 10, 10 bar DN 25, 1 tmax: 100 °C New ! Dimensions: 160 x 80 x 70 mm
used
Description: Maximum rotor weight per bearing 750 kg Largest rotor diameter over balancing machine bed 1600 mm Bearing journal diameter 12- 100 mm Minimum bearing center distance 50 mm Bearing center distance with belt drive min. 140 mm recessed guide rails can be deformed during disassembly, or cannot be dismantled  , rotor weight max.: 1,500 kg, rotor dia. max.: 1,600 mm, weight approx.: 500 kg, Approx. Onsite Dimension. (l x w x h): 4,800 x 1,700 x 1,600 mm
used
Description: SPECIFICATIONS Brand: JP Type: PHQ-1000H Year of construction: 2016 Balancing machine Capacity: 1,000 kg Table length: 2,500 mm Table width: 660 mm Electrically driven Machine dimensions (L×W×H): 2,500 x 1,300 x 1,700 mm weight approx.: 3,000 kg, Approx. Onsite Dimension. (l x w x h): 2,500 x 1,300 x 1,700 mm
used
Power consumption 140 W Pneumatic tension for tool holders SK 10 - SK 40 and HSK 32 - HSK 63 rotor diameter 270 mm rotor length 350 mm Rotor weight 0.1 – 35 kg Accessories: Adapter SK 40, HSK 50, HSK 63
used
The machine is in good general condition and is equipped with the following accessories. 1 set of racks with castors 1 set of bearing stands with prisms 1 piece test rotor Various spare parts Operating instructions with spare parts list Price on request
used
Industrial robots, robots, counterbalancing -Manufacturer: KUKA, counterweight from robot KR125/3 -Type: GA2-D2 -Location hole: Ø 54 mm, distance 620 mm -Technical data: see photos -Dimension: 760/220/H290 mm -Weight: 41 kg
used
Balancer, wheel balancer, tire balancer, balancer -Manufacturer: MPM Micro Precision Marx, Balancer AB100 -Type: 3.AB100T.C.M4 -Dimensions: 300/315/H130 mm -Weight: 5.4 kg
used
We offer you here a used Balancing plate of the manufacturer Polypal for purchase. Included in delivery are: 01x Balancing plate, used Manufacturer: Polypal Type: SKPU Material color: sendzimir galvanized Dimensions: approx. 130 x 85 mm Thickness: approx. 1.25 mm Weight/pcs.: 0,119 kg
used
workpiece weight: 100 - 3.000 kg workpiece length: 5.000 mm diameter: 1.260 - 1.600 mm Control: CAP920 total power requirement: 11 kW weight of the machine ca.: 20 t dimensions of the machine ca.: 20 Container m Mobile balancing system SCHENCK for use anywhere in the world The balancing system is permanently installed in a 20 open-top container. The container is equipped with everything you need for balancing • Lighting • Metal base plate 12,000 kg as a base plate for accuracy • Compressor for working air supply distributed in the container • Compressed air connections. • A circumferential power strip • A tool cabinet equipped with tools • A hydraulic lifting device for aligning the container from the outside • In addition to a tarpaulin for the roof, the container also comes with movable roof segments made of sheet metal. • The container has a central plug through whic ...
used
Magnetic table with electromagnet Magnetic table size 300x1000 mm Longitudinal feed rate 7-23 mm / min Transversal advance -working 0.1 - 8 mm - fast 990 mm / min - manual 0.02 mm / gradation Vertical advance -working 0.005 / 0.01 / 0.02 / 0.03 / 0.04 / 0.05 mm - fast 460 mm / min - manual 0.005 mm / gradation Abrasive disc speeds 1450min-1 The dimensions of the abrasive disc 350x40x127mm Electric motor power 5.5 kW motor Electric motor power vertical feed 0.5 kW Transverse feed electric motor power 0.04 kW Maximum load on the table 400 kg The height of the car is 1890 mm Disc balancing device yes Weight - mass 3500 kg Packaging - box dimensions (L x W x H) 2950x2220x2200 mm Standard equipment ⢠Two-axis digital display ⢠Grinding stones ⢠Balancing wheel ⢠Balancing stand ⢠Magnetic plate for fixing ⢠System for demagnetization ⢠Cooling system ⢠...
used
Manufacturer: Wagner (SMS MEER) Type: SP 1ZO 1000 YOM: Revamped 2006 and 2019 REVAMP REPORT 2019 3.2. Mechanical works 3.2.1. Supplies and Achievements Supply and machining of 4 guiding columns • Material 42CD4V + CPCU 3.1, 0330 x length 6300 from raw forged, treated, dress and owned • Central threads and external thread • The centering bearings will be pre-machined to a rough dimension and finished according to diameters obtained aer retouching on the lower windchest and the upper yoke. Refurbishment of the lower bedstead: • Cast steel • Weight of 10,600 Kg and dimensions of 3500 x 3174 • 1050 Mounng on boring machine with balancing and geometric and dimensional checks • Retouching of the 4 lines of bores with 0330/332 (Rework of a maximum of 1mm/rays) • Dressage of inferiors and superiors • Retouching of 2 sides with 0340H7 and Ø330H7 (mini) • Retouchin ...
used
Naxos CNC Multi-Axis Cylindrical Grinder Year: 1987/2013 Max. swing: 630mm Max. distance workhead face to tailstock face: 4850mm Max. travel for Z axis: 5000mm Max. grinding distance for main wheel: 4520mm X axis infeed travel for both headstocks: 720mm Approx. weight between centers: 4000kg Power requirements: 460/3/60 This machine was completely remanufactured to new specifications in 2013 and installed in 2014. It was stripped down to the bare casting, table/base/wheel heads/work head and tailstock and the second z axis ways were fit and rescrapped. New electrical cabinet with all new wiring to the machine and new all components, hydraulic lines, air lines and new cable carriers were added. New Marathon 60HP motors for both grinding wheel heads. (The drives in the cabinet are set for 40 Hp) The spindle drives in the cabinet are Yakawa built in the USA along with the workh ...
new
Figure shows precision flat grinding machine: FSM 2550 AH Table size: 300 x 600 mm Installation height: 500 mm Max table load: 300 kg Engine power: 4.6 kW Connection: 400 V Dimensions: 2300 x 1790 x 2200 mm Weight, approx.: 2000 kg Equipment and scope of delivery: - All castings, such as machine stand, table, etc. made of MEEHANITE® quality casting - Automatic cross and longitudinal feed - Permanent lubrication - Automatic cross-stroke device - Rear splash protection - Grinding wheel - Grinding wheel flange - Pulling device - Balancing mandrel - Balancing scales - Dressing diamond - Machine light - Nivilier elements - Operating tool - Operating instructions - CE Special equipment of our storage machine: - Electric magnetic clamping plate 300 x 600 mm (fine pole) - 2-axis digital display, accuracy 0.001 mm, X 450 / Y 500 mm - Automatic verti ...
used
-Load capacity: adjustable from 600 – 3000 kg -Effective height : from 1300 – 2000 mm -Tine length : 1000 mm Fvmfedlvq -Tine cross-section : 120 x 50 mm -Total height: 1720 – 2420 mm -Net weight : 260 kg These crane forks are equipped with adjustable tines, height adjustment and automatic weight compensation. In the case of self-balancing forks, the support tines tilt upwards when the load is lifted. This prevents the load from slipping out unintentionally. The suspension eyelet is movably mounted via a subframe. The automatic self-balancing is carried out by a gas pressure spring when the fork is loaded. This ensures that the suspension point is always in the centre of gravity of the fork and that the load picked up is transported absolutely safely.
used
ELB SHLIFF SWBD-30 VA II surface grinding machine was manufactured in 1970 in Germany. The machine is equipped with an electromagnetic table consisting of three electromagnetic clamping plates, each 3000 mm long and 450 mm wide. It is possible to process workpieces on the work table of the magnetic grinder with a length of up to 3000 mm, width of up to 500 mm and maximum weight of 2000 kg. The grinding height depends on the grinding wheel wear – with a new grinding wheel it is possible to grind the workpiece with a maximum height of 450 mm, while with the used grinding wheel the grinding height is 540 mm. Grinding machine ELB SHLIFF SWBD 30 has also a mandrel for balancing grinding wheels, holders for grinding wheels and electro-automatic magnetic pole switch in electromagnetic plates. The machine underwent a complete overhaul carried out in 2002 by the Polish company JOTES. Tech ...
used
COMPOSED OF: 1 x Rotor Remanufactured + balanced+ equipped 2 x Rotor (need to be refurbished) 1 x Clamping device for balancing 9 x Impact strips (Large) 6 x Impact bar (small) 2 x Enema cone 3 x tear-off edge various rotor protection plates CONSISTING OF: 1 x Rotor newly reconditioned + balanced+ fitted 2 x Rotor (must be reconditioned) 1 x Clamping device for balancing 9 x Blow bars (large) 6 x Blow bars (small) 2 x Inlet cone 3 x Tear-off edge Various rotor protection plates
used
The NEW CNC grinding VERECO RG 700/8500 is designed for the batch production of bench pins and connecting rod pins of crankshafts in a fully automatic cycle, or, for the production of individual parts in manual. It operates by means of a mobile grinding wheel unit both on the X axis and on the Z axis: this allows the grinding of different diameters in a single positioning of the piece. MAIN TECHNICAL FEATURES: Distance between tips: 8500 mm Drill height: 800 mm Maximum rotating Ø: 1600 mm Maximum weight of the balance piece: 10,000 kg Maximum grinding wheel dimensions (with recesses): 1600x900x160 mm Approximate machine weight: 98.000 kg NB: The aforementioned technical data, collected from the technical data sheet of the manufacturer, are to be considered non-binding and subject to change without notice. NUMERICAL CONTROL The Siemens 840 D electronic numerical contro ...
used
grinding length: 1.000 mm grinding width: 600 mm workpiece height: 400 mm control: SINUMERK 840 D Grinding Area: : grinding range: max. 1.000 x 600 mm travel cross (z-axis): 540 mm distance table surface - grinding spindle centre: max. 600 mm Travel vertical (Y-axis): 500 mm Max. working height on new grinding wheel: 400 mm workpiece table: : Electro permanent magnetic plate: 800 x 500 mm pole pitch: 18 mm clamping force in 8 levels: - Table drive (X-axis): : Incremental encoder in the longitudinal axis X axi: - table speeds: 2-35.000 mm/min Electromechanical longitudinal movement: - by means of digital servo motor,: - toothed belt and ball screw: - Preloaded precision rolling guide size 35: - Central grease lubrication: - Automatic vertical feed (Y-axis): : min. feed size: 0,001 mm measuring system: Galsmaßstab Max. distance spindle centre - table: 700 Grinding head vertical: 550 mm El ...
used
Double Column Machining Center TOSHIBA MPC-3180B Table mm.8000 x 2700 Distance between columns mm.3100 X mm.9000 Y mm.3900 Z Verticaal RAM stroke mm.900 W Vertical Crossrail stroke mm.1600 Automatic indexed every 5 degrees 5 face head Distance table to spindle nose mm.2440 Table load Kg. 20.000 Spindle speed 5-3000 rpm 2 ranges Spindle taper BT 50 Ram section 380 x 380 Machine dimensions mm.29110 x 9900 x 7260 Machine weight Kg. 151.000 Year 2007 Standard options : 5-face cutter head Automatic attachment (5-face cutter head or other attachments)index (AAI) (4-position index by 90.) Automatic tool loading/unloading device for vertical spindle and horizontal spindle) CNC controller including standard and pack specifications Pendant operation box with electrically-driven free arm Hydraulic unit Oil cooling unit (AKZ 908) Hydraulic crossrail servo balancing s ...
used
Crane fork, loading fork, load fork, pallet fork, pallet crane fork -Manufacturer: REMA, pallet hook with manual balancing -Load capacity: 3000 kg -Tine length: 980 mm -manual weight balancing -Fork: adjustable, 430 to 880 mm -Useable height: 1320 to 2020 mm -Dimension: 1185/930/H1640 mm -Total weight: 270 kg
used
grinding length: 1.000 mm grinding width: 600 mm workpiece height: 400 mm Control: SINUMERK 840 D Grinding Area: : grinding range: max. 1.000 x 600 mm travel cross (z-axis): 540 mm distance table surface - grinding spindle centre: max. 600 mm Travel vertical (Y-axis): 500 mm Max. working height on new grinding wheel: 400 mm workpiece table: : Electro permanent magnetic plate: 800 x 500 mm pole pitch: 18 mm clamping force in 8 levels: - Table drive (X-axis): : Incremental encoder in the longitudinal axis X axi: - table speeds: 2-35.000 mm/min Electromechanical longitudinal movement: - by means of digital servo motor,: - toothed belt and ball screw: - Preloaded precision rolling guide size 35: - Central grease lubrication: - Automatic vertical feed (Y-axis): : min. feed size: 0,001 mm measuring system: Galsmaßstab Max. distance spindle centre - table: 700 Grinding head vertical: 550 mm El ...
technical data: Track gauge: 980 mm Support height: 420 mm reinforced execution circulating chain Drive by worm gear motor with built-in slip clutch Kippstool adjustable stem holder Cable and cable balancing
used
Steelyard with tare balancing device Manufacturer: Pfister scales GmbH Augsburg Type: N 300 Minimum load: 50 kg Maximum load: 2000 kg Mass Bridge: 1.5 m x 1.25 m In good condition!
used
Hydraulic safety lock from an overload: 125-250 tons Number of idle slide strokes per minute: -For the head press: 20 -For the subsequent press: 25 Number of microdrive strokes per minute: 0,45 Electric motor for the press table: 45 kW Electric motor for the microdrive: 17 kW Max. balancing weight of the upper part of die on the slide: 3,5 tons Distance between columns: 2550 mm Slide stroke: 400 mm Max. extract depth: 160 mm Slide adjustment: 250 mm Adjustment range of the extract depth: 0-160 mm Max. closed height: 800 mm Height of the pull-out table: 500 mm Table dimensions: 2500x1250 mm Table bore dimensions: 2100x850 mm Slide dimensions: 2500x250 mm Weight: 74500 kg
new
We sell a complete package from bearing resolution. Mounting material for photovoltaic systems open space The following positions are included in the package: Central Terminal profiles, end clamp profiles, potential balancing ropes, Checker Advancende DC70A cabinets (GAK passing element, fully assembled), connection profiles (profiles), solar cables. It's new product. We will send you a detailed statement you request. Price on request.
new
Swing boom crane boom crane with ZYBA-MAT Manufacturer: Strödter Type: ZP 60 / SAZ 60 D1 Built: 2014 New and unused Load capacity permissible load weight max: 25 kg Working radius approx.: 3,000 mm Stroke max: 800 mm Lifting speed max. : approx. 800mm/sec. Energy supply: pneumatic Mounting: Swing boom with stand column Net weight device (with load-carrying equipment): 287 kg Pneumatic working pressure: 6 bar Air quality required for maximum load-bearing capacity: clean, dry and filtered (5 microns) Air consumption max.: approx. 17 Nl/ double stroke ZYBA-MAT on the swivel boom Pneumatic balancing control with automatic scale
used
Grinding diameter: 0 mm Grinding length: 0 mm Workpiece weight: 0 kg CNC Brand: 0 CNC Model: 0 Operating hours: 31677 Technical data Centre height: 175 mm Distance between centres: 650 mm Grinding wheel right and left hand Max. Longitudinal travel: 700 mm Grinding weehl left side: Diameter: 400 mm Width: 80 mm Bore: 127 mm grinding wheel width: 80 mm Grinding wheel right side: Diameter: 400 mm Width: 40 mm Bore: 127 mm Workpiece weight on centres max.: 130 kg Grinding wheel speeds: number (steps): 6 from: 1500 rpm up to: 2400 rpm Peripheral speed: 35 m/s Hydraulic cross travel: 300 mm Angular displacement: 180 ° Work piece spindle head: speeds: stepless from: 60 rpm up to: 600 rpm rotatable: 0-90 ° Spindle taper:: 5 MT Taper in tailstock:: 3 MT Table angular displacement: 12 ° Table speed: from: 0.05 m/min up to: 9.0 m/min Voltage 50 Hz 3x: 400 Volt External Grinding wheel motor ...
used
Grinding diameter: 0 mm Grinding length: 0 mm Workpiece weight: 0 kg CNC Brand: 0 CNC Model: 0 Control: GE FANUC Series 16-GC Operating hours: 34900 Technical data Centre height: 175 mm Distance between centres: 1000 mm Workpiece weight on centres max.: 130 kg Grinding weehl left side: Diameter: 400 mm Width: 40 mm Bore: 127 mm Grinding wheel right side: Diameter: 400 mm Width: 63 mm Bore: 127 mm B axis resolution max.: 0.001 ° B axis swivelling range (automatic): 15° + 205 ° Peripheral speed: 35 m/s Max. travel: 275 mm Max. grinding length: 1050 mm Transversal slide: Work piece spindle head: speeds: from: 30 rpm up to: 675 rpm rotatable: 90 ° taper in spindle: MT: 5 Tailstock: Hydraulic return Taper in tailstock:: 3 MT Voltage 50 Hz 3x: 400 Volt Workpiece spindle motor: 7.5 kW Machine´s weight about: 5100 kg Overall dimensions machine: Length: 3750 mm Width: 1200 mm Height: 2 ...
used
Zero point clamping system Manufacturer: Vischer & Bolli VB tools Built: 2018 Condition: unused System consisting of: 1 piece Dock Lock steel closure plate Dimensions: 600x200x85/95 mm with 2 pieces DockLock SAFE20 built-in cylinder up to 12.5 KN per cylinder 10 Mounting holes for M16-Inbus 1 piece special base plate made of steel Dimensions: 800x250x76 mm 1 piece DEUX-MILL tensioner 1 piece special base plate made of aluminium Dimensions: 600x600x40 mm 5 pieces clamping bolt SAFE20 long with centering 10 pieces clamping bolt SAFE20 long without centering 5 pieces balancing clamping bolt SAFE20 long 1 piece hydraulic pump
used
Grinding diameter: 0 mm Grinding length: 0 mm Workpiece weight: 0 kg CNC Brand: 0 CNC Model: 0 Operating hours: 39970 Technical data Centre height: 175 mm Distance between centres: 650 mm Grinding wheel right and left hand Max. Longitudinal travel: 700 mm Grinding weehl left side: Diameter: 400 mm Width: 80 mm Bore: 127 mm grinding wheel width: 80 mm Grinding wheel right side: Diameter: 400 mm Width: 40 mm Bore: 127 mm Workpiece weight on centres max.: 130 kg Grinding wheel speeds: number (steps): 6 from: 1500 rpm up to: 2400 rpm Peripheral speed: 35 m/s Hydraulic cross travel: 300 mm Angular displacement: 180 ° Work piece spindle head: speeds: stepless from: 60 rpm up to: 600 rpm rotatable: 0-90 ° Spindle taper:: 5 MT Taper in tailstock:: 3 MT Table angular displacement: 12 ° Table speed: from: 0.05 m/min up to: 9.0 m/min Voltage 50 Hz 3x: 400 Volt External Grinding wheel motor ...
used
Very well preserved crankshaft grinding machine RTM 260. Machine was newly scraped, spindles of eccentric adjustment replaced. Lots of accessories, 10 grinding wheels, user manual, balancing jack, tape filter system, etc.
used
grinding diameter: 250 mm grinding length: 1000 mm centre height: 125 mm grinding wheel diameter: 500 mm grinding wheel width: 80 (100) mm bore: 203,2 mm : MK5 work piece spindle speed: 20-400 U/min workpiece spindle - bore: mm workpiece spindle swivable +/-: 360 ° grinding head swivellable +/-: 0 ° grinding spindle speed: U/min : 0-9,99 mm/Ø : 0-9,99 mm/Ø table swivelabel +/-: 10 ° longitudinal feed of the table: mm table speeds: 0,02-6 m/min : 130 kg max. workpiece weight -without tailstock: 130 inkl. Spannung kg cross travel: 270 mm tailstock quill taper MT: 3 quill travel: 30 mm total power requirement: 5,5-7,5 kW weight of the machine ca.: 2,7 t dimensions of the machine ca.: m As the world’s leading company in Kellenberger overhaul and retrofit we are not only able to deliver machines in a quality similar to a new machine and with warranty, but we can also offer you the serv ...
used
Grinding diameter: 0 mm Grinding length: 0 mm Workpiece weight: 0 kg CNC Brand: 0 CNC Model: 0 Technical data Centre height: 100 mm Distance between centres: 400 mm Grinding wheel: Diameter: 300 mm Width: 50 mm Bore: 127.0 mm grinding wheel width: 60 mm Grinding wheel speeds: number (steps): 3 from: 1500 rpm up to: 1900 rpm Work piece spindle head: speeds: stepless from: 65 rpm up to: 500 rpm rotatable: 360 ° Spindle hole: 23 mm Spindle taper:: 4 MT Taper in tailstock:: 3 MT Table angular displacement: 9 ° Table speed: stepless up to: 5.0 m/min Voltage 50 Hz 3x: 380 Volt External Grinding wheel motor: 2.5 HP Workhead spindle motor: 0.5 HP Total power required: 4.0 HP Machine´s weight about: 2100 kg Overall dimensions machine: Length: 1600 mm Width: 1200 mm Height: 1550 mm Various accessories: 3-jaw chuck diameter: 135 mm Macnetic chuck diameter: 150 mm Coolant system Paper filte ...
used
grinding diameter: 360 mm grinding length: 1600 mm centre height: 180 mm internal diameter: 0 mm grinding depth: 0 mm swing diameter: 0 mm total power requirement: 40 kW weight of the machine ca.: 10000 kg dimensions of the machine ca.: m K A R S T E N S (Germany) Universal CNC” - Cylindrical Internal and Face Grinding Machine also for grinding excentric and cam profiles and polygons and even suitable for Threadgrinding Model K 51 – 1500 Year 2000 Serial No. 99 093 Height of centres 180 mm Distance between centres / grinding length 1,700/1.600 mm Cylindrical Grinding: Grinding Ø, approx. 5 - 360 mm Grinding wheel: Ø x width x bore 500 x 100 x 127 mm Grinding spindle speeds (35 m/s / 50 m/s) 1.900 / 2.200 rpm Drives of cyl./int/face spindle units 7.5/4,0/7,5 kW Grinding Wheelhead: 3 ...
used
grinding diameter: 915 mm grinding length: 3200 mm swing diameter: 915 mm grinding diameter - min.: 0 mm centre height: 450 mm centre distance: 3200 mm grinding wheel size: 750 x 305 x 80 mm max. workpiece weight between centres: 8000 kg grinding wheel turining speeds: 40 - 1500 U/min number of turns of spindle head: 6- 45 U/min grinding motor: ca. 30 kW electrics - voltage/frequency: 380 / 50 V/Hz total power requirement: 60 kW weight of the machine ca.: 40 t dimensions of the machine ca.: 12,0 x 5,0 x 2,5 m Machine reconditioned and modernised to Siemens Sinumerik S7 in 1998, including reconditioning of grinding wheel motor. Machine raised from 750mm dia. to 915mm dia in 2016. - Various Steadies - Coolant & Clarifier - Balancing Stand - Sony DRO The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Key data: 630 Siemens, 3000 840 D
Grinding diameter: 630 mm Grinding length: 3000 mm Workpiece weight: 0 kg CNC Brand: Siemens CNC Model: 840 D CNC Dresser EMAG with Siemens 840D new in 2008 HeidenHain measuring scales Siemens Servo engines MARPOS E9 balancing system 0,2 Mu Crankshaft and External grinding Large steady rest package Large stone and flanch package Centre height: 316mm Grinding Ø: 632mm Grinding length: 3.000mm Grinding stone dimensions:800 x 305 x 105 mm Grinding stone speeds: 1000Rpm Table inclasement: 9,1 ° Length: 10.100 mm Width: 2.610 mm Height: ...
used
Hydraulic balancing act with cooling and tank (0.70 cbm) Motor 37 kW, filter, pressure vessel, etc...
new
grinding wheel diameter: 200 mm no. of working stations: 2 Stück grinding wheel width: 20 mm bore: 16 mm grinding wheel diameter - width-internal grin: 200 x 25 x 20 mm grinding wheel speeds: 2850 U/min voltage: 230 V total power requirement: 0,45 kW weight of the machine ca.: 19 kg dimensions of the machine ca.: 525 x 335 x 295 m Industrial quality machine. Powerful motor, no vibration through clever balancing. Heavy duty tool rests and protection covers. Low noise, tool rests adjustable. With high quality eye shield. emergency stop with no-load switch adjustable tool rest with eye shield with dust extractor connection The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
new
grinding wheel diameter: 200 mm no. of working stations: 1 Stück grinding wheel width: 19 mm grinding band dimension: 100 x 1150 mm turning speeds: 2850 U/min saw band speed: 30 m/s grinding wheel size: 200 x 19 x 20 mm grinding wheel speeds: 2850 U/min grinding band dimension: 100 x 1000 mm total power requirement: 0,75 kW weight of the machine ca.: 31 kg Heavy duty universal grinding and sanding machine in industrial quality. Powerful motor, no vibration through clever balancing. Heavy duty tool rests and protection covers. Low noise, tool rests adjustable. With high quality eye shield. Supplied with additional polishing disc and steel brush. emergency stop with no-load switch adjustable tool rest with eye shield with dust extractor connection steel brush grinding belt polishing disc The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Grinding diameter: 350 mm Grinding length: 540 mm Workpiece weight: 0 kg made of GRANITAN STONE Dittel autamatic balancing unit Hydraulic tailstock retraction External measuring head CR 100/23A diameter 4 – 100 mm Studer S15 Favorit Handwheel connection X and Z axis Centre height: 175mm Grinding Ø: 350mm Grinding length: 540mm Grinding stone dimensions:500 x 80 x 203 mm Grinding stone speeds: 2800Rpm Table inclasement: 8.5° Tailstock: 3Mk Length: 2.200 mm Width: 1.500 mm Height: &nb ...
