Tool holder, milling holder, milling tool -Adjustment: SK50 -Tool holder: MK4 -Brill chucks: flat chucks, reducing sleeves, cutter head, shell end mill, spindle tool -suitable for tool changers -Number: 6x recordings available -Price: per piece -Dimensions: 240/95/H95 mm -Weight: 3.0 kg/piece

Tool holder, milling holder, milling tool -Adjustment: SK50 -Tool holder: Ø with groove -Brill chucks: flat chucks, reducing sleeves, cutter head, shell end mill, spindle tool -suitable for tool changers -Number: 8x recordings available -Price: per piece -Dimensions: 270/95/H95 mm -Weight: 3.2 kg/piece

Tool holder, milling holder, milling tool -Adjustment: SK50 -Tool holder: MK3 -Brill chucks: flat chucks, reducing sleeves, cutter head, shell end mill, spindle tool -suitable for tool changers -Number: 12x recordings available -Price: per piece -Dimensions: 235/95/H95 mm -Weight: 3.0 kg/piece

Tool holder, milling holder, milling tool -Adjustment: SK50 -Tool holder: Ø with groove -Brill chucks: flat chucks, reducing sleeves, cutter head, shell end mill, spindle tool -suitable for tool changers -Number: 28x recordings available -Price: per piece -Dimensions: 270/95/H95 mm -Weight: 3.2 kg/piece

IV Bag in line test system is used for automatic container closure integrity test. The IV bag test measurement method is based on mass extraction technology. At deeper vacuum liquid will boil off the surface and become gas vapor. The intelligent molecular flow sensor will measure the amount of gas extracted from the IV bag while the IV bag is placed inside the sealed vacuum chamber. the leak flow rate is then compared to the maximum allowed leakage which is the flow rate generated from a known defect size at similar test conditions and a pass fail decision is made.

- Arbeitsbereich X - Achse 1300 mm - Arbeitsbereich Y - Achse 2500 mm - Arbeitsbereich Z - Achse 300 mm - Frässpindel luftgekühlt HITECO / Italy 9.5 kw, HSK 63F - Spindel Drehzahl stufenlos 24.000 rpm - Werkzeugwechsler 8-fach, seitlich - Verfahrsystem (X & Y Achse) Zahnstangen-Ritzelantrieb - Verfahrsystem (Z Achse) Kugelrollspindel - Verfahrmotoren AC Servo Motoren Delta / YASKAWA - SHIMPO Getriebe Antrieb - max. Verfahrgeschwindigkeit 40 m/min - max. Arbeitsgeschwindigkeit 20 m/min - Arbeitsgenauigkeit 0.05 mm - Vakuum - Rastertisch mit 4 Sektionen und T-Nuten - BECKER Vakuumpumpe trockenlaufend, luftgekühlt, Leistung 129 m3/h - Werkstückpositionierung, pneumatisch absenkbare Anschläge je 2 Stück in X und Y - Werkzeuglängen Sensor - CAD/CAM Software VECTRIC CUT 2D PRO (NESTING Inclusive) - Steuerung OSAI/ Italy - Schnittstelle Ethernet/USB/CompactFlash Card - Elektroanschluss 3 ...

- Arbeitsbereich X - Achse 2100 mm - Arbeitsbereich Y - Achse 3000 mm - Arbeitsbereich Z - Achse 300 mm - Frässpindel luftgekühlt HITECO/ Italy 9.5 kw, HSK 63 F - Spindel Drehzahl stufenlos 24.000 rpm - Werkzeugwechsler,Karusell 8-fach, mitfahrend - Verfahrsystem (X & Y Achse) Zahnstangen-Ritzelantrieb - Verfahrsystem (Z Achse) Kugelrollspindel - Verfahrmotoren AC Servo Motoren Delta / YASKAWA - SHIMPO Getriebe Antrieb - max. Verfahrgeschwindigkeit 40 m/min - max. Arbeitsgeschwindigkeit 20 m/min - Arbeitsgenauigkeit 0.05 mm - Vakuum - Rastertisch mit 4 Sektionen - BECKER Vakuumpumpe trockenlaufend, luftgekühlt, Leistung 2 x 129 m3/h = 258 m3/h - Werkstückpositionierung, pneumatisch absenkbare Anschläge je 2 Stück in X und Y - Werkzeuglängen Sensor - CAD/CAM Software VECTRIC CUT 2D PRO (NESTING Inclusive) - Steuerung OSAI / Italy - Schnittstelle Ethernet/USB/CompactFlash Card - Ele ...

- Arbeitsbereich X - Achse 1500 mm - Arbeitsbereich Y - Achse 3000 mm - Arbeitsbereich Z - Achse 300 mm - Frässpindel luftgekühlt HITECO / Italy 9.5 kw, HSK 63F - Spindel Drehzahl stufenlos 24.000 rpm - Werkzeugwechsler 8-fach, seitlich - Verfahrsystem (X & Y Achse) Zahnstangen-Ritzelantrieb - Verfahrsystem (Z Achse) Kugelrollspindel - Verfahrmotoren AC Servo Motoren Delta / YASKAWA - SHIMPO Getriebe Antrieb - max. Verfahrgeschwindigkeit 40 m/min - max. Arbeitsgeschwindigkeit 20 m/min - Arbeitsgenauigkeit 0.05 mm - Vakuum - Rastertisch mit 4 Sektionen und T-Nuten - BECKER Vakuumpumpe trockenlaufend, luftgekühlt, Leistung 129 m3/h - Werkstückpositionierung, pneumatisch absenkbare Anschläge je 2 Stück in X und Y - Werkzeuglängen Sensor - CAD/CAM Software VECTRIC 2D PRO (NESTING Inclusive) - Sicherheitslichtschranke Vorschrift nach EN 848-3 (Optional einseitig, zweiseitig oder dreise ...

- Working range X - Axis 1300 mm- Working area Y - Axis 1300 mm- Working area Z - Axis 200 mm- Working accuracy -+0.04/300 mm- Vacuum - Scanning table with 4 sections and T-slots including vacuum pump- Max. Travel speed 10000 mm/min- Max. Working speed 6000 mm/min- milling spindle motor 2.2 kW / ISO 20, water-cooled tool changer 6-fold, side-collet tool holder diameter 3, 6, 8,10,12 mm- speed Milling spindle 6000-18000 rpm- Drive motors stepper motors- Voltage 400 V/50Hz guide in X,Y Direction linear guide + rack guide in X, Z-direction linear guide + ball roller spindle- command language G-code- DSP control NK 105 (option: Mach3 control, PC and Monitor)- CAD/CAM Software Vectric CUT2D PRO (NESTING Inclusive)- Workpiece positioning, pneumatically lowerable stops 1 x pieces in X ,2 pieces in Y- tool lengths Sensor safety light barrier regulation according to EN 848-3 (optional one-sided,  ...

Technische Daten: - schwingungsfreier Marmor-Granit Ständer garantiert für höchste Präzision - Arbeitsbereich X - Achse 2500 mm - Arbeitsbereich Y - Achse 1300 mm - Arbeitsbereich Z - Achse  200 mm - Frässpindel luftgekühlt HSD / Italy 9.5 kw, ISO 30 - Spindel Drehzahl stufenlos 24.000 rpm - Werkzeugwechsler 8-fach, seitlich - Verfahrsystem (X & Y Achse) Kugelrollspindel - Verfahrsystem (Z Achse) Kugelrollspindel - Verfahrmotoren AC Servo Motoren YASKAWA - Linearführungen in X, Y und Z Achse 30 mm - max. Verfahrgeschwindigkeit 40 m/min - max. Arbeitsgeschwindigkeit 20 m/min - Arbeitsgenauigkeit 0.05 mm - Vakuum - Rastertisch mit 4 Sektionen und T-Nuten - Vakuumpumpe trockenlaufend,Leistung 5,5 kW - Werkzeuglängen Sensor - CAD/CAM Software VECTRIC CUT 2D PRO (NESTING Inclusive) - Steuerung WEIHONG inklusive CNC Handrad - Schnittstelle Ethernet/USB/CompactFlash Card - Elektroansch ...

- Arbeitsbereich X - Achse 1300 mm - Arbeitsbereich Y - Achse 1300 mm - Arbeitsbereich Z - Achse 200 mm - Arbeitsgenauigkeit -+0,04/300 mm - Vakuum - Rastertisch mit 4 Sektionen und T-Nuten inklusive Vakuumpumpe - Max. Verfahrgeschwindigkeit 10000 mm/min - Max. Arbeitsgeschwindigkeit 6000 mm/min - Frässpindel Motor 2,2 kW / ISO 20, Wassergekühlt - Werkzeugwechsler 6-fach, seitlich - Spannzangen Werkzeugaufnahme Durchmesser 3, 6, 8,10,12 mm - Drehzahl Frässpindel 6000-18000 U/min. - Antriebsmotoren Schrittmotoren - Spannung 400 V/50Hz - Führung in X,Y Richtung Linearführung + Zahnstange - Führung in X, Z-Richtung Linearführung + Kugelrollspindel - Befehlssprache G-code - DSP Steuerung NK 105 (Option: Mach3 Steuerung, PC und Monitor) - CAD/CAM Software Vectric CUT2D PRO (NESTING Inclusive) - Werkstückpositionierung, pneumatisch absenkbare Anschläge 1 x Stück in X ,2 Stück in Y  ...

Broadband vacuum gauge VACOM ATMION ATC25KLE Dimensions: 185 x 105 x 75 mm

CONTROLS   CNC controls SIEMENS SINUMERIK 840 C TABLE   table surface (left-right): 4000 mm   table surface (front-back): 1250 mm TOOL MAGAZINE   magazin type: cartridge magazine   number of positions: 300 ELECTRICAL SPECIFICATIONS   mains power supply: 80 kVA   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   total weight approx.: 50000 kg

Table Surface 3.000 X 1.250 mm Longitudinal Traverse (X Axis) 2.500 mm Cross Traverse (Y Axis) 2.500 mm Vertical Traverse (Z Axis) 1.000 mm Distance Between Columns 2.000 mm. Rapid Traverse (X Axis ) 15 m/min. Rapid Traverse (Y ,Z Axis) 12 m/min. Max. Working Feed 5 m/min. Head Type ORTOGONAL UDG-40 Orthogonal Milling Head indexing every C Axis Indexing 2.5º B Axis Indexing 2.5º Taper ISO-50 / DIN 69871 A Spindle Speed 50- 2.000 r.p.m. Range Speeds 2 Ranges ATC INCLUDED Nº Positions ATC 10 TOOLS Coolant Through Tools 15 BAR INCLUDED Spindle Motor 30 KW. Total Power Requirement 44 kW Year 1997 CNC Heidenhain TNC 426 Carrying Load Table 10.000 Kg. Machine Weight 24.000 Kg. Portable Handwheel HEIDENHAIN HR 410

CNC carousel lathe with tool changer.You Ji GTH-35/45 ATC-I. Built 2012.Fanuc 0i-TD CNC Control.Planchime diameter 3,500 mm.Hydrostatic table - Max load 50 t.swing diameter max. 4,500 mm.Turning diameter max. 4,000 mm.turning height max. 2,200 mm.Stoesselplanweg X -1.750/+2.160 mm.Stoesselsenkrechtweg Z 1.500 mm.Table drive 60/75 kW.Speed 2 x 75 mm.Torque at the table 67,330 Nm.Tool magazine with 16 places.Tool holder 7/24 BT 60.Place requirement 12,375 x 8,210 mm.Machine height 7,920 mm.Full cladding.3-colors Signal lamp.NEW - 200 operating hours ! Immediately available;; As good as new

CNC Vertical Lathe VTL with Tool Changer.You Ji GTH-35/45 ATC-I.Year of manufacture 2012.Fanuc 0i-TD CNC Control.Face plate diameter 3500 mm.Hydrostatic table - Load max. 50 t.Swing diameter max. 4500 mm.Turning diameter max. 4000 mm.Turning height max. 2200 mm.Ram cross travel X -1750/+2160 mm.Ram vertical travel Z 1500 mm.Table drive 60/75 KW.Table turning speeds 2 ~ 75 mm.Torque at the table 67330 Nm.Tool magazine with 16 positions.Tool taper 7/24 BT 60.Floor space required 12375 x 8210 mm.Machine height 7920 mm.Full guarding.3-colour signal lamp (tower).AS NEW - 200 run hours !Available immediately.; As new

DYNAJET 500th HELI ATC RC INTRODUCTORY OFFER: If you want to be sure that this device is right for you, then we have a special offer for you: Crediting of rents for up to 6 months at 100% of the purchase price! The mobile and universally applicable dynaJET cold and hot water high-pressure cleaner In addition to its user-friendliness, 500th with up to 500 bar working pressure is characterized in particular by its low weight, compact dimensions and high level of performance and safety. Construction 1-axle chassis with pneumatic tyres for easy manoeuvring on site Self-supporting and indestructible framework for weight optimization Crane eyelet for easy transport and handling Underrun protection for additional safety Frame in dip painting technology for high corrosion protection and highest surface quality Targa concept with separation between unit side and operating side f ...

DYNAJET 500th HELI ATC RC INTRODUCTORY OFFER: If you want to be sure that this device is right for you, then we have a special offer for you: Crediting of rents for up to 6 months at 100% of the purchase price! For purchase: Including 1st UVV WITH arrival and maintenance (plus spare parts) on the same date (value approx. 1,500 net). The mobile and universally applicable dynaJET cold and hot water high-pressure cleaner In addition to its user-friendliness, 500th with up to 500 bar working pressure is characterized in particular by its low weight, compact dimensions and high level of performance and safety. Construction 1-axle chassis with pneumatic tyres for easy manoeuvring on site Self-supporting and indestructible framework for weight optimization Crane eyelet for easy transport and handling Underrun protection for additional safety Frame in dip painting technology  ...

Key data: 2100 , 9

CNC milling machine 2132 OPTIMAT 2100x3200 ATC 100% European product New for 2022! CNC milling machine 2132 with a weight of approx. 4100 KG and a working table area of 2100x3200mm, equipped with an automatic 12th tool linear magazine cooperating with the HSD / HITECO 9kW 24000rpm electrospindle (ceramic bearing, HSK F63 interface) enabling the use of tools with a diameter up to 26mm inclusive! Technical parameters: Effective working size: 2100x3200mm - Trouble-free processing of the entire size of the furniture board - Vacuum workbench made of HPL Machine weight: approx. 4100KG - The frame of the machine made of the highest quality alloy is welded in its entirety, then subjected to the stress relieving process in a special chamber with special conditions, and then milled. This process ensures that excellent results of structural rigidity and stability are achieved Z-axis stro ...

Processing Manufacturer: Biesse Model: Rover 335 ATC Working range: approx. 3200mm x 950 mm Drilling spindles vertical: 24 pcs. Drilling spindles horizontal: 10 pcs. Milling unit: 7.5 KW

Brige Type Milling Machine Manufacturer NICOLÁS CORREA Model FP 30/30 ATC Year 2000 CNC HEIDENHAIN TNC-426 Table surface 3.000 X 1.250 mm Max weight allowed on table 10.000 kg. Longitudinal Traverse (X Axis) 2.500 mm Transversal Traverse (Y Axis 2.000 mm Vertical Traverse (Z Axis) 800 mm Distance Between Columns 1.740 mm. Rapid Traverse X Axis 15.000 mm/min Rapid Traverse Y , Z Axis 12.000 mm/min Max. Working Feed 7.500 mm/min Taper ISO-50 Direct Output Head Speed 5.000 r.p.m. Main Motor Power 22 kW Speed Ranges 2 Internal coolant (12 Bar) INCLUDED Automatic tool changer INCLUDED Positions at tool magazine 30 Soluble Oil Lubricant Tank With Filter Paper + Magnetic INCLUDED External Electrospindle 18.000 rpm + Coolant INCLUDED 90º angle head MIMATIC INCLUDED Double rear chip conveyor INCLUDED Portable handwheel HEIDENHAIN HR-410 Machine Weight 25.500 kg. Large ...

Description: FRAMA ATC Lathe Cutter Sharpener no. 131 weight approx.: 50 kg, Approx. Onsite Dimension. (l x w x h): 600 x 400 x 1,200 mm

Technical information Swing over bed 420 mm Distance centre tot centre 1000 mm Max longitudinal travel Z-axis 1028 mm Max cross travel X-axis 335 mm Spindle coneA2-6 Dia of spindle bore 56 mm Power on the spindle20/25 hp Number of speeds16 - 4000 rpm CommandMazatrol Cam T3 Total power needed18,5 kW - 32,9 kVa Length 3734 mm Width 1893 mm Height 2401 mm Weight 4400 kg Toolchanger yes Number of tools 16x - rotating yes milling tools C-axis Robo flex automatic loading system tooling included Measuring arm included MAZATROL CAM T-3 CNC Accessories Tailstock, Evoquator, Tool Attachments, Presetting Machine weight 4700 kg Axis C Yes

5-axis digital wood cutting centre. Good condition with a 2m50 by 1m50 carpet

Machining center in continuous flow Usable width 1300 mm Working Dimensions X:4200 mm / Y: 1300mm / Z: 60 mm HSD Boring Unit 10 Vertical Drill - 3x2 Horizontal - 1Saw Blade) Working Speeds X: 100m/min / Y: 100m/min - Z: 20m/min 5.5 Kw I 7.50 HP ISO 30 HSD Spindle Motor Panel Handling with Double Clamping System (Independent Servo Control) Double Sided Air Flotation Working Table AES WOP CAD/CAM Program Piece Verification System with Laser Weight (Approx.) 3.500 kg

faceplate diameter:1250 mm swing diameter:1600 mm turning height:1350 mm max. turning diameter:1350 mm weight of the machine ca.:32 t Chip Conveyor Coolant Tank Oil/Water Separator Machine Cover (High guarding) Heat exchanger For Electrical Cabinet Auto Lubrication for Guide way 4 Jaw Manual Chuck 1600mm Hydraulic Unit BT50 Tool Connection in RAM Metal frame and case in machine shipment packing(Wooden packing with metal base) 3 colors Warning Light Chamber light Anti- Dropping in Z axis -- Auto Motor Brake System Options Installed Air Conditioner For cabinet Coolant Through Spindle Filter for Coolant Water CE Mark Transformer

MazaK M Plus X Axis Strokes: 1150 Y Axis Strokes: 1000 Z Axis Strokes: 1000 Board length: 630 Deck Board Width: 630 Max Piece Dimensions Length X Width X Height Table: D.1050XH.1100 Spindle Table Surface: Tapped holes Max Spindle Piece Weight: 1500 Spindle Spindle: 8000 Spindle holder: ISO 50 Torque Cont 10 Min Spindle: 600 Nm Rapid Displacement X Axis Rapid Displacement: 30000 Rapid Move Y Axis Rapid Move: 30000 Rapid Displacement Z Axis Rapid Displacement: 30000 Number of Atc Warehouse Tools: 120 Max Atc Magazine Tool Diameter: 225 Max Tool Length from the Atc Warehouse Reference Line: 630 ATC magazine tool selection method: fixed Max Tool Weight Atc Warehouse: 30 Kg Atc Warehouse Tool Change Time: 5 SEC. Refrigerant pressure: 50 BAR Machine Dimensions Height: 21350 Machine Dimensions Width: 3480 Depth Machine Dimensions: 6750 Machine Dimensions Weight: 20900  ...

Mazak Hcn 5000 Fusion Used Horizontal Machining Center Machine In Good Condition. Table 4th Continuous Axis Tecnoforme 20 Bar System With Coonsep Lateral Rotofilter Government Unit: FUSION X-axis Strokes: 730 Y axis Strokes: 730 Z axis Strokes: 800 Table Length: 500 Deck Width: 500 Max Piece Dimensions L X W X H Table: D.800x1000 Spindle Table Surface: Tapped Holes Max Piece Weight Spindle: 500 kg Spindle Spindle: 18000 Spindle Shank: ISO 40 Torque Cont 10 Min Spindle: 168 NM X-Axis Rapid Movement Rapid Movement: 60.000 Y-Axis Rapid Movement Rapid Movement: 60.000 Z Axis Rapid Movement Rapid Movement: 60.000 Number of Atc Warehouse Tools: 80 Atc Warehouse Max Tool Diameter: D. 95 D.170 Max Tool Length From Atc Warehouse Reference Line: 170 Atc Warehouse Tool Selection Method: FIXED Max Tool Weight Atc Warehouse: 12 Atc Warehouse Tool Change Time: 2.8 Refrigerant ...

Dn Solution Nhp 5100 - Continuously controlled 4-axis horizontal CNC machining center Fanuc 31i-model B -apc 2 Stations - racing X730 -60 Random Tool Places - Iso 50 electrospindle with double contact flange, oil cooled, 15000 rpm - Pallet capacity: 500 kg -External air blow Adjustable m” function -Internal refrigerant supply at 70 Bar - preparation of measuring probe for zeroing of piece with Renishaw Rmp60 cycles (radio transmission) -data Server 2gb, Fanuc Aicc 2 Software (High Speed ​​For 3D Molds And Figures, 1ooo Blocks Ahead) -communication with ports and USB + Ethernet - Carpet Chip Conveyor Belt Steering Unit: FANUC 31I-MODEL B X Axis Runs: 730 Y Axis Strokes: 730 Z Axis Strokes: 880 Board length: 500 Board width: 500 Max Piece Dimensions Length x Width x Height Table: D.800x10900 Spindle Table Surface: Tapped Holes Max Piece Spindle Weight: 500 kg  ...

Used Mazak Fh 8800 Machining Center Complete With Fms Line Composed Of 8 Pallets At 2 Levels + 2 Loading And Unloading Stations Machine In Excellent Visible Condition Government unit: FUSION 640 M X axis Strokes: 1300 Y axis Strokes: 1100 Z axis Strokes: 1000 Table Length Table: 800 Deck Width Deck: 800 Max Piece Dimensions L X W X H Table: D.1250 X H.1250 Spindle Table Surface: T-SLOTS Max Spindle Piece Weight: 2,200 Spindle Spindle: 8000 Spindle attachment: ISO 50 Torque Cont 10 Min Spindle: 1280 NM X-Axis Rapid Movement Rapid Movement: 48.000 Y-Axis Rapid Movement Rapid Movement: 48.000 Z Axis Rapid Movement Rapid Movement: 48.000 Number of Atc Warehouse Tools: 240 Atc Warehouse Max Tool Diameter: 360 Max Tool Length From Atc Warehouse Reference Line: 630 Atc Warehouse Tool Selection Method: FIXED Max Tool Weight Atc Warehouse: 30 Kg Atc Warehouse Tool Change Ti ...

CNC milling machine 2100x4000mm 9kW HEAVY DUTY TechnologieCNC CNC Industry 2.0 2140 ATC The INDUSTRY 2.0 ATC series differs from the standard series by using the best and most precise motors in its class and the power transmission, which significantly increase the machine's machining capabilities, making it the most industrialized series in this price range. ✔The INDUSTRY 2.0 ATC series CNC milling machine with a working surface of 2100x4000mm and a clearance in the Z axis equal to 300mm is equipped with an electrospindle with a power of 9kW and 24000 rpm. on a ceramic bearing. The working table of the machine is made in hybrid technology - it has vacuum sections and subsections for automatic, non-invasive clamping of the processed material, as well as t-groove slots for manual clamping of irregular shapes. ✔ATC - The machine is equipped with an automatic linear magazine wi ...

General- Compound slides with turning/milling spindle as integrated spindle motor, with hydr. locking at turning acceptance HSK-63A DIN 69893 - Y-axis ± 100 mm - B-axis ±110° with pneumatic locking - Tools magazin disc with 1x24 positions - Absolute direct gauging system in the X, Y, Z linear axes - Coolant pump 5 bar; 20l/min - Cooling system for spindle motor, turning/milling spindle, B-axis torque motor - USB interface, Ethernet interface; Control: CELOS with Siemens 840D sl Operate Working areaSwing diameter over guide ways500 mmTurning diameter500 mmMax. Turning Length750 mmBar diameter max.65 mmWork spindle (left)Spindle noseFlat flange Diametre of spindle nose170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmMain drive 1Drive power (100% DC)25 kWDrive power (40% DC)32 kWSpeed range- 5000 rpmTorque (100% DC)280 NmMax. torque (40% DC)360 NmC-Axis Speed-5000 rp ...

Description, subject to prior sale. CNC 4-axis horizontal machining center Make: Matsuura Type: H.Plus-300/PC-5 Y.o.m.: 2003 Control: Fanuc/Matsuura i30 G-Tech X 500 mm Y 500 mm Z 500 mm Spindle revolutions 15000 rpm 240 ATC Pallets 300 x 300 mm Number of pallets 5 SK40 IKZ 25-50 bar Measuring Probe Tool breakage monitoring KSS Cooling New spindle in 7/2022. Spindle hours 4800 April 2021 - tool spindle spindle motor renewed May 2021 - changer arm of ATC repaired July 2022 - tool spindle + motor renewed November 2022 - ATC drive repaired. The ATC, automatic tool changer, has been completely retrofitted. The housing is the original, the wear parts like e.g. bearing, lever, cam discs etc. have been renewed. Machine is in very good working condition and partly retrofitted. It can be inspected working under power. Technical indications, s ...

Key data: 500 Mazatrol, 500 640 M, 730

Pallet length: 500 mm Pallet width: 500 mm Longitudinal X: 730 mm Cross Y: 730 mm Vertical Z: 740 mm Number of pallets: 20   Positions ATC: 325   CNC Brand: Mazatrol CNC Model: 640 M Make: MAZAK Type: PFH 5800 Control: MAZATROl 640M YOP: 2005 20 x Pallet stations ATC with 325 positions Tooling package ca 150 pieces Granit clamping towers 18 x X – Travel:               730mm Y – Travel:               730mm Z – Travel:               740mm B-Axis indexing:          360000° Table Length:             500mm Table Width:              500mm Table load:               500Kg Number of pallets:      &n ...

Table length: 2200 mm Table width: 850 mm Longitudinal X: 2000 mm Cross Y: 1000 mm Vertical Z: 1000 mm Positions ATC: 10   CNC Brand: Heidenhain CNC Model: TNC410 MAKE   CME Spain TYPE     BF 03 YEAR    1999 SPECIFICATIONS X - Travel     2000 mm Y - Travel     1000 mm Z - Travel      1000 mm bed / plano / portal / moving column bed milling machine          Controll      HeidenHain TNC 410 Table Length x Width    2200 x 850 mm Table load in kG      4000 Kg Spindle Taper      Bt 50 kW power on spindle    22 kW Spindle speeds / ranges    3000 ? Rpm ATC tool changer   ATC 10 Coolant true spindle / Bar    10 Bar Number off controlled axis      & ...

Table diameter: 2000 mm Turning diameter: 2500 mm Turning height: 1600 mm Motor power: 0 HP/kW Positions ATC: 12   Positions APC: 0   CNC Brand: Fanuc CNC Model: 18 iM Make You Ji 2 Type ATC 2000 - 2 Year Aug 2007 Fanuc 18 iM Centre height (mm)Table = 2.000 Center distance (mm)Swing = 2.500 Spindle bore Height = 1.600 Load = 10.000 ATC 12 positions Bt 50 Chip conveyor

SERON 1315 EXPERT CNC milling machine built in Poland in 2017 is new and has never been used. The machine designed and manufactured with attention to the smallest details, is used for precision machining of a wide range of materials such as mild metals, plastics, carbon, wood, wood-like panels and glass. All vibrations and deformations during the milling process are eliminated by the high-quality ribbed steel construction with a T-slot table made of aluminium profiles, with a length of 1500 mm and a width of 1300 mm. The workspace is additionally equipped with a special PVC overlay to protect the table cover while cutting the workpieces through. At the end of the table there is a six-position linear magazine with an automatic tool correction sensor. The 1315 EXPERT machine axes are driven by highly dynamic and precise brushless AC servo drives with back pressure, equipped with serv ...

GeneralTwo spindle turning/milling centre with - Main and counter spindle; Control: CELOS with Siemens 840D sl Operate Tool holder 2Number of tool stations12 Shank diametre according to DIN 6988040 mmNumber of driven tools12 Speed max.4000 rpmPower max. (40% DC)10 kWTool magazineNumber of tools24 Max. tool length230 mmMax. tool diameter80 mmMax. tool weight7 KgTurning-milling spindleSpindle taperHSK-A 63 Spindle speed-12000 rpmDrive power (100% DC)19 kWDrive power (40% DC)22,5 kWTorque (100% DC)85 NmTorque (40% DC)120 Nmlocking moment1000 NmSwivelling range+/-110 degreeSlide 2Longitudinal stroke1200 mmTransverse stroke195 mmSlide 3Longitudinal stroke1200 mmSlide 1Longitudinal stroke1200 mmTransverse stroke490 mmY axis, vertical+/- 100 mmHeadstock, rightClamping chuck Ø315 mmSpindle nose diameter170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmDrive power (100% DC)25 kWDri ...

GeneralTwo spindle turning/milling centre with - Main and counter spindle; Control: CELOS with Siemens 840D sl Operate Tool holder 2Number of tool stations12 Shank diametre according to DIN 6988040 mmNumber of driven tools12 Speed max.4000 rpmPower max. (40% DC)10 kWTurning-milling spindleSpindle taperHSK-A 63 Spindle speed-12000 rpmDrive power (100% DC)19 kWDrive power (40% DC)22,5 kWTorque (100% DC)85 NmTorque (40% DC)120 Nmlocking moment1000 NmSwivelling range+/-110 degreeTool magazineNumber of tools24 Max. tool length230 mmMax. tool diameter80 mmMax. tool weight7 KgSlide 3Longitudinal stroke1200 mmSlide 2Longitudinal stroke1200 mmTransverse stroke195 mmSlide 1Longitudinal stroke1200 mmTransverse stroke490 mmY axis, vertical+/- 100 mmHeadstock, rightClamping chuck Ø315 mmSpindle nose diameter170h5 mmSpindle bore87 mmSpindle diametre on front bearing130 mmDrive power (100% DC)25 kWDri ...

Manufacturer QUASER Model MV204IIU / 10 Year 12/2002 CNC HEIDENHAIN ITNC530 3 Working Tables / Pallets Table 1 Size Ø280 mm. Table 2 Size Ø 500 mm. Table 3 Size 600×400 mm. Max weight allowed on table 265 kg Min-max distance over table 150-760 mm. Axis Longitudinal Traverse (X Axis) 700 mm Cross Traverse (Y Axis 590 mm Vertical Traverse (Z Axis) 480 mm Titling spindle head range (A Axis) ±110º A Axis positioning 0.001º Table turning (C Axis) 360º C Axis positioning 0.001º Rapid Feed (X/Y/Z Axis) 32.000 mm/min Working Feed (X/Y/Z Axis) 15.000 mm./min. Spindle Spindle Speed 10.000 r.p.m. Taper BT-40 Power 15/33 kW Torque 192/189 Nm. ATC ATC Positions 32 ATC system RANDOM Max Tool length 280 mm. Max Tool weight 7 kg Other Equipment Chip Conveyor INCLUDED Internal Coolant 20 Bar INCLUDED Coolnat tank capacity 280 l. Electrical cabinet coolant IN ...

Spindle diameter: 130 mm Cross X: 3500 mm Vertical Y: 2000 mm Table length: 2200 mm Table width: 1800 mm Positions ATC: 60   Number of pallets: 0   CNC Brand: Heidenhain CNC Model: TNC 430 Make TOS WHQ13 CNC Type WHQ 13 CNC Year 2004 TNC 430 in 5 Axis Spindle diameter (mm) 130/3000/37kW Table length (mm) L = 2.200 Table width (mm) W = 1.800 Longitudinal X (mm) X = 3.500 Cross Y (mm) Y = 2.000 Pos ATC Z = 1.250 Number APC .W = 800 ATC 60 position 20 bar high pressure coolant

x-travel: 800 mm y-travel: 700 mm z-travel: 610 mm Control: Siemens 828 D total power requirement: kW weight of the machine ca.: 8,7 t dimensions of the machine ca.: m ONLY 2800 HOURS SPINDLE WORKS Description The QUASER MF vertical machining centres are highly versatile, offering high speed, high powered machining with 4+1 and full 5-axis machining capability along with large X-axis machines with a compact footprint. Superb build quality and stability for high volume production, toolroom and subcontract machining environments. Specification Table size 500mm diameter Travels – X/Y/Z axes 800 x 700 x 610 mm A Axis + 30 deg ~ -120 deg C Axis 360 deg continous Maximum swing 630 mm Table surface to spindle nose -25mm ~ 585mm Spindle nose to tilting centre at 90 deg -25mm ~ 585mm Maximum work piece of size 630mm dia x 300mm Table load capacity 300kg Spindle taper BT40 Spindle options 10,00 ...

Spindle diameter: 50 mm Cross X: 2500 mm Vertical Y: 2500 mm Table length: 2200 mm Table width: 2200 mm Positions ATC: 60   Number of pallets: 1   CNC Brand: Heidenhain CNC Model: HeidenHain TNC640 Orthogonal Milling head Tooling package Sk50 3D measuring probe Clamping equipment PEISSLER Rotary index table 1200 mm ATC 60 Positions Safety housing with 2 big front doors Retrofitted in 2019 by Primoteq X - Travel:               2500mm Y - Travel:               2500mm Z - Travel:               800mm W - Travel:               1000mm Table Length:             2200mm Table Width:              2200mm Table load:          &n ...

Table length: 920 mm Table width: 380 mm Longitudinal X: 505 mm Cross Y: 355 mm Vertical Z: 610 mm Positions ATC: 24   Positions APC: 0   CNC Brand: Heidenhain CNC Model: HeidenHain TNC 430 Tooling package SK-30 Documentation included Some clamping equippment Max. tool length ATC 260 mm  X - Travel:              505mm Y - Travel:              355mm Z - Travel:              610mm Table Length:            920mm Table Width:             380mm Table load:              250 Feed rate X-Axis:        20000mm/min. Feed rate Y-Axis:        20000mm/min. Feed rate Z-Axis:        20000mm/min. Spindle Taper:  ...

Table length: 630 mm Table width: 500 mm Longitudinal X: 730 mm Cross Y: 850 mm Vertical Z: 560 mm Positions ATC: 80   Positions APC: 2   CNC Brand: Mazatrol Renishaw OMP 60 3D Taster ikz 15 Bar Double chip conveyor EUCHNER toolmanagment prepared Pallet changer 2 position Extended 80 Position ATC Synchronized threat cutting EIA Dynamic 5 Axis compensation Directl availebel X - Travel:               730mm Y - Travel:               850mm Z - Travel:               560mm A - Axis:                 -120 to +30° B - Axis:                 360000° Table Length:             630mm Table Width:             ...

Spindle diameter: 110 mm Cross X: 2500 mm Vertical Y: 2000 mm Table length: 1600 mm Table width: 1250 mm Positions ATC: 60   Number of pallets: 0   CNC Brand: Heidenhain Spindle SK-50 with 2000 Nm torq 60 Position Chian ATC ( Optional toling package) Backlash free ball screws in all linear axes with absolute valvue High pressure coolant and paper filtration 40 bar Fully enclosre housing guarding area Chip conveyor X - Travel:              2500mm Y - Travel:              2000mm Z - Travel:              1500mm W - Travel:              550mm Table Length:            1600mm Table Width:             1250mm Table load:              6000 S ...

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0   Number of pallets: 0   CNC Brand: 0 CNC Model: 0 Control: GE FANUC 0i - MD 7 512 kB / Touch screen Technical data Table length: 300 mm Table width: 260 mm Longitudinal travel (X-axis): 150 mm Transversal travel (y axis): 225+50 ATC mm Vertical travel (z axis): 200 mm Table load max.: 80 kg Distance from vertical spindle to table: 140 ~ 340 mm Taper in spindle: HSK-E32 Spindle speeds: stepless vertical from: 100 rpm up to: 30000 rpm Tool changer: number of tools: 17 Rapid traverse:: 30 m/min Milling spindle motor: 3.0 / 4.5 kW Total power required: 12 kVA Machine´s weight about: 2000 kg Overall dimensions machine: Length: 1750 mm Width: 600 mm Height: 1800 mm Various accessories: Handwheel electroinic Full splash cabin Coolant system: 120 ltr. Tool changer: (number of tools): ...

Table length: 0 mm Table width: 0 mm Longitudinal X: 0 mm Cross Y: 0 mm Vertical Z: 0 mm Positions ATC: 0   Number of pallets: 0   CNC Brand: 0 CNC Model: 0 Technical data Table length: 300 mm Table width: 260 mm Longitudinal travel (X-axis): 150 mm Transversal travel (y axis): 225+50 ATC mm Vertical travel (z axis): 200 mm Table load max.: 80 kg Distance from vertical spindle to table: 140 ~ 340 mm Taper in spindle: HSK-E32 Spindle speeds: stepless vertical from: 100 rpm up to: 30000 rpm Tool changer: number of tools: 17 Rapid traverse:: 30 m/min Milling spindle motor: 3.0 / 4.5 kW Total power required: 12 kVA Machine´s weight about: 2000 kg Overall dimensions machine: Length: 1750 mm Width: 600 mm Height: 1800 mm Various accessories: Handwheel electroinic Full splash cabin Coolant system: 120 ltr. Tool changer: (number of tools): 17 Automatic setting tool: BLUM Z-Pico Interface: ...

FMS SYSTEM: Machining Cell consisting of: Two 5-Axis machining Centres 8-Pool Pallet System(1250 x 1250mm x 3.000kg) Pallet Storage System X= 3.000 mm, Y= 2.000H/1.720V, Z= 2.000mm; A= 175°, B=0,001°; 640 Pos. ATC ; Spindle Taper HSK-A100; Spindle n= 3.000; Motor 50kW; Feeds: X,Y= 40m/min, Z= 30m/min Siemens 840D, Chip-conveyor; Serial No. 1450-03 and 1451-3, both from 2003 FR: À VENDRE MAINTENANTFMS SYSTEME ; 8 Pos. Piscine à palettes (1250 x 1250mm x3.000kg). 2x MCM Jet Five Mirror 5 axes CENTRE D'USINAGE/BEARBEITUNGSZENTREN/MACHINE CENTERS, X= 3.000, Y= 2.000H/1.720V, Z= 2.000mm ; A= 175°, B=0,001° ; 640 Pos. ATC ; Cône de broche HSK-A100 ; Broche n= 3.000 ; Moteur 50kW ; Alimentation : X,Y= 40m/min, Z= 30m/minSiemens 840D, convoyeur à copeaux ; numéros de série 1450-03 et 1451-3, à partir de 2003

FMS SYSTEM; Machining Cell consisting of: Two 5-Axis Machining Centres 12-Pool Pallet System (630 mm X 630 mm); Pallet Storage System X= 750 mm, Y= 860 mm, Z= 850mm; B= 0,001°; 334 Pos. ATC Spindle Taper HSK-A100; Spindle n= 11.000; Spindle 25 kW; Feeds 32.000mm/min; Chip-conveyor; Coolant System Serial No. 1283-01 (2001) Siemens 840D; and Coolant System Serial No. 1024-98 (1999) Siemens 840C FR: À VENDRE MAINTENANTFMS SYSTEME ; 12 Pos. Piscine à palettes (630 X 630mm) ; 2x horloge MCM 5 axes CENTRE D'USINAGE/BEARBEITUNGSZENTREN/MACHINE CENTERS ; X= 750, Y= 860, Z= 850.mm ; A= .. ? ? B= 0,001° ; 334 Pos. ATC ; cône de broche HSK-A100 ; broche n= 11.000 ; broche 25 kW ; avance 32.000mm/min ; convoyeur à copeaux ; système de refroidissement n° 1283-01 (2001)Siemens 840D ; et système de refroidissement n° 1024-98 (1999)Siemens 840C
