alignment used for sale

band width: 200 mm band length: 1490 mm table-size: 540 x 280 mm engine output: 1,1 kW voltage: 400 V weight of the machine ca.: 72 kg dimensions: 750 x 600 x 320 mm Equipment: - with 2 belt speeds - Table model - 1 grinding belt - Steel sanding table with planed surface - Belt alignment via two threaded rods with star grip The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

width of the strips: 100 mm band length: 920 mm engine output: 0,35 kW saw band speed: 7 m/sec. Table surface: 300 x 150 mm roll diameter: 58 mm dimensions: 460 x 400 x 210 mm voltage: 380 V weight of the machine ca.: 15 kg Equipment: - Table model - 1 grinding belt - Steel grinding table with planed surface - Belt alignment via two Threaded rods with star grip The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Machine type Machining center universal BAZ Manufacturer Heller Model MCS-H / U 300 Year of construction 2002 Condition good (used) Specifications Bright MCS-H/U 300 Year of construction: 2002 Control: Siemens 840 D Workspace: Longitudinal stroke X-axis 1000 mm Vertical stroke Y-axis 800 mm Transverse stroke Z-axis 1100 mm Lifting position longitudinally to the center of the table MCS-H X-axis +500 to -500 mm Lifting position vertically over. Palettes. MCS-H Y-axis +120 to +920 mm Lifting position transverse to the center of the table MCS-H Z-axis +200 to +1300 mm Guidance system: Linear compact roller guide version Size 55 Transfer elements: Accuracy Ball Screws Diameter x Slope Diameter 50 x 20 mm Feed drive system: Three-phase servo motors Closed design Feed forces: X-axis at ED S3-40% 15000 N Y-axis at ED S3-40% 15000 N Z-axis at ED S3-40% 20000 N Positio ...

GeneralHorizontal universal machining center; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal650 mmCross700 mmVertical950 mmTechnical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minCabineFull protection cabinMotor spindle 20,000 rpmMotor spindle speedMASTER® HSK-A 63 Spindle speed 20 - 20,000 min-1 Output 35 kW / 25 kW (47 hp / 33 hp) Torque 130 Nm / 86 Nm (96 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)Taper cleaning brushesTaper cleaning unit with rotating brushes for spindle taper HSKNC swivel rotary table DirectDriveNC swivel rotary table direct drive Table plate: d 650 mm / 25.6 in 1 x T-slot 14 H7 / 0.55 H7 (alignment groove, table centre) 8 x T-slot 14 H12 / 0.55 H7 (clamping grooves) Permissible load: 600 kg / 1,323 lbs Rotary-axis: 80 min-1 direct drive Swivel-aKinematics a ...

Code: 0068 Brand: GIBEN Model: STARMATIC 850 - CE Standard CNC Horizontal panel saw with clamps for cutting wood panels, plywood, furniture, composite materials, sandwich panels, plastics and various materials - CE Standard Technical data: Useful cutting length 4500 mm Automatic pusher with lateral upper guides, electronically controlled, complete with 6 pneumatic clamps- Clamps opening 117 mm - Pusher stroke 4550 mm Max blade projection 85 mm Max main blade diameter 360 mm Main blade motor 7,5 kW - Rpm 3827 Max scoring blade diameter 160 mm Scoring blade motor 1,1 kW - Rpm 8290 Scoring exclusion with choiceor Quick tool removal (Pneumatic) Automatic adjustment of main blade overhang according to stack height Adjustment (lateral and in height) of outside scoring unit Blade carriage translation by brushless servomotor Blade carriage feed speed 1-80 m/min Blade car ...

Aluminium riser conveyor belt incl. substructure increasing range starting from 50mm (customizable) Discharge range 1500mm (customizable) Conveyor belt width 500mm (adjustable) We supply our conveyor belts in PVC, PU or rubber. PVC conveyor belt incl. carrier and shaft edge Drive: Motor 0.25KW ( adjustable ), speed 0.3m/sec Connection 220/240V, 50Hz protection class IP54 Drive etc. ready for connection, motor control optional 6x adjustable machine feet for alignment Shaft edge: 40x35mm (adjustable) T-20 studs - 400mm pitch (customizable) 2-layer particularly transversely stable Our core competence lies in providing the customer with exactly what he really needs. Together with our customers, we develop customer-specific, individual solutions and supply corresponding systems from our own production. Feel free to contact us by phone to find a suitable solution for your  ...

Aluminium angle conveyor belt incl. mobile substructure horizontal range 1500mm (adjustable) Rising range 2500mm (customizable) Angle in the kink freely selectable: 30, 35, 40 or 45° Polyamide swivel castors with parking brakes Conveyor belt width 400mm (adjustable) We supply our conveyor belts in PVC, PU or rubber. PVC conveyor belt incl. carrier and shaft edge Drive: Motor 0.25KW ( adjustable ), speed 0.3m/sec Connection 220/240V, 50Hz protection class IP54 Drive etc. ready for connection, motor control optional 6x adjustable machine feet for alignment Shaft edge: 40x35mm (adjustable) T-20 studs - 400mm pitch (customizable) 2-layer particularly transversely stable Our core competence lies in providing the customer with exactly what he really needs. Together with our customers, we develop customer-specific, individual solutions and supply corresponding systems f ...

Format range: max. 1000 mm, min. 126 mm Equipment: Longitudinal seam, folding bottom, double edge, electronic top gluing unit HHS X-tend, 4 channel with 2 application heads, Disc gluing unit left, feeder with vibrator, folding floor module A2 Primary crusher right and left, kicker, counter, Bobst CUBE control, additional middle transport at the top/bottom in folding, cutting alignment on the press belt, pneumatic, intermittent press belt. Overhaul 2023: cleaned, tested, painted and fitted with new feeders and Transport belts, as well as equipped with new press belts. Other: The machine can be viewed while running by appointment.

Aluminium angle conveyor belt incl. mobile substructure horizontal range 1500mm (adjustable) Rising range 2500mm (customizable) Angle in the kink freely selectable: 30, 35, 40 or 45° Polyamide swivel castors with parking brakes Conveyor belt width 400mm (adjustable) We supply our conveyor belts in PVC, PU or rubber. PVC conveyor belt incl. carrier and shaft edge Drive: Motor 0.25KW ( adjustable ), speed 0.3m/sec Connection 220/240V, 50Hz protection class IP54 Drive etc. ready for connection, motor control optional 6x adjustable machine feet for alignment Shaft edge: 40x35mm (adjustable) T-20 studs - 400mm pitch (customizable) 2-layer particularly transversely stable Our core competence lies in providing the customer with exactly what he really needs. Together with our customers, we develop customer-specific, individual solutions and supply appropriate systems. Fee ...

Aluminium angle conveyor belt incl. substructure horizontal range 2000mm (adjustable) Rising range 2200mm (customizable) Angle in the kink freely selectable: 30, 35, 40 or 45° Conveyor belt width 500mm (adjustable) We supply our conveyor belts in PVC, PU or rubber. PVC conveyor belt incl. carrier and shaft edge Drive: Motor 1.1KW ( adjustable ), speed 0.3m/sec Connection 220/240V, 50Hz protection class IP54 Drive etc. ready for connection, motor control optional 6x adjustable machine feet for alignment Shaft edge: 40x35mm (adjustable) T-20 studs - 400mm pitch (customizable) 2-layer particularly transversely stable Our core competence lies in providing the customer with exactly what he really needs. Together with our customers, we develop customer-specific, individual solutions and supply corresponding systems from our own production. Feel free to contact us by phone  ...

Complete solution for the transport of bulk materials and demetalization of magnetic metal impurities. Aluminium angle conveyor belt incl. substructure horizontal range 2000mm (adjustable) Rising range 4500mm (customizable) Angle in the kink freely selectable: 30, 35, 40 or 45° Construction: height-adjustable Construction for suspension of the DMPM1200 overbelt magnetic separator included Conveyor belt width 600mm (adjustable) We supply our conveyor belts in PVC, PU or rubber. PVC conveyor belt incl. carrier and shaft edge Drive: Motor 0.25KW ( adjustable ), speed 0.3m/sec Connection 220/240V, 50Hz protection class IP54 Drive etc. ready for connection, motor control optional 6x adjustable machine feet for alignment Shaft edge: 40x35mm T-20 tunnels - 400mm pitch 2-layer particularly transversely stable Our core competence lies in providing the customer with e ...

Complete solution for the transport of bulk materials and demetalization of magnetic metal impurities. Aluminium riser conveyor belt incl. substructure Slope beginning area level ground (adjustable) Discharge height 1800mm (adjustable) Construction: height-adjustable Construction for suspension of the DMPM1200 overbelt magnetic separator included Conveyor belt width 500mm (adjustable) We supply our conveyor belts in PVC, PU or rubber. PVC conveyor belt incl. carrier and shaft edge Drive: Motor 0.25KW ( adjustable ), speed 0.3m/sec Connection 220/240V, 50Hz protection class IP54 Drive etc. ready for connection, motor control optional 6x adjustable machine feet for alignment Shaft edge: 40x35mm T-20 tunnels - 400mm pitch 2-layer particularly transversely stable Our core competence lies in providing the customer with exactly what he really needs. Together with our c ...

Laser cutting machine Trumpf TruLaser 3030 with TruStore 1030 and SortMaster - Laser power 5000 watts. - Year of construction 2010 - Thin Sheet Productivity Package - Nozzle changer - Cross conveyor belt - Tilting container for transverse conveyors - LiftMaster Store - Extension Sort (1000 x 600) - Extended partial removal from 600 x 600 - Integrated sheet metal alignment - Separating thin sheet - Sliding gate bifly - SortMaster - Rotary unit + extended partial removal 1000 x 600 infinitely variable - Additional gripper long parts - Extension of magnetic suction - TruStore 1030 - Storage/retrieval station with trolley - 10 layer compartment 90mm + pallet - 5 pallet bottoms - Saulenverkleidung - Warehouse interface Available from the end of the year or at the beginning of next year. Errors in the technical data and prior sale excepted.

Brand new machine designed for screwing reinforcements in PVC profiles. - simultaneous operation of the screwing unit - adjustable distance between screwdrivers 42-110 mm - Automatic screw connection - automatic automatic movement alignment - the ability to work as a screwdriver - screw depth sensor - powerless steering control - Specific feed account Additional equipment: - machine base - pick-up rollers - pneumatic impulse to the feeder (13mm), preventing jamming of the screws in the feeder at the entrance and exit - screw depth sensor - horizontal pressure

Year of manufacture: 2008, Machine No.: 670 - Working range X 300, Y 280, Z 250 mm - Feed speed 0.01 - 16,000 mm/min - Acceleration 8 m/s2 Resolution: 0.1 μm Position spread Ps: ±0.5 μm CNC precision dividing head (4th and 5th axis) - System 3R Macro Chuck - Brushless servo drive, fully digital - Feed speed C/B 7000 / 3000 °/min - Swivel range B from -10 to +120 degrees - Heidenhain iTNC 530 smarT.NC - High frequency coil HSK E25 500 -50'000 rpm - Tool changer 95-fold - Prepared for external workpiece changer - Minimum quantity lubrication -Suction - CO2 extinguishing system - Laser for tool measurement (Blum) - Infrared 3D probe - External dry cooler - External spindle cooling unit - External coolant device with cooling - Vorma machine light Accessories - Shrink device Haimer Power Clamp Nano - HSK E25 mounts (CORE) ø 2 - 6mm (Total 115 pcs; Shri ...

Specifications: Drill diameter: 3 - 32 mm Center angle: 90° - 140° Speed grinding wheel: 4800 1/min Connection: 230 V Motor power: 0.25 kW Weight, approx.: 32 kg Dimensions LxWxH, approx.: 360 x 250 x 310 mm Characteristics: - Ideal for grinding HSS/carbide twist drills - Easy to use - Safe operation due to forced grinding process - Peak angle adjustable from 90° - 140° - Compact design, with collet storage in the machine and handle for quick storage - Including spout alignment for flawless centering of the drill on the workpiece and to reduce the feed force during drilling - Device for back grinding the drill edges to reduce friction between drill and workpiece - Rotor with precision ball bearing - Vibration-free running due to high dead weight - CE Scope of delivery: - Grinding wheel CBN - 30 ER collets ER 40, 13 - 32 mm (suitable for intermediate sizes) - ...

FARO EDGE 2.7 M coordinate measuring arm was built in 2014. The efficient and productive portable measuring arm verifies the quality of workpieces of any shape by measuring components in 2D and 3D with an accuracy of ± 0.017 mm. The mounted measuring head and the non-contact laser scanning function also allow for comparative analysis of individual components and assemblies with CAD files. The machine has been designed with convenience and ease of use in mind, as evidenced by the excellent weight distribution and balance maintained. The FARO EDGE measuring machine consists of: – a 2.7 metre long measuring machine with base plate and probe, – battery and cables, – a removable handle, – a non-standard case (hard case). Applications of the FARO EDGE 2.7 M machine - measuring and verifying the dimensions of machine parts of any shape - measurement of shape deviation and c ...

Specifications: Drill diameter: 3 - 20 mm Center angle: 90° - 140° Speed: 4800 1/min Connection: 230 V Motor power: 0.12kW Weight, approx.: 8.6 kg Dimensions, approx.: 290 x 150 x 180 cm Characteristics: - Ideal for grinding HSS/carbide twist drills - Safe operation due to forced grinding process - Peak angle adjustable from 90° - 140° - Compact design, with collet storage in the machine and handle for quick storage - Including propping alignment to reduce feed force - Device for back grinding the drill edges to reduce friction between drill and workpiece - Rotor with precision ball bearing - CE Scope of delivery: - Grinding wheel CBN - 11 collets ER 20, 3 - 13 mm - 7 collets ER 24, 4 - 20 mm - Collet holder ER 20, ER 25

Format range: 1400 x 1400 mm stack height 1300 mm Equipment: motorized format setting via remote control, pneumatic lateral alignment, Siemens control, Non-stop setup. Overhaul 2022: cleaned, tested, painted. Other: Stackers can be viewed in operation by arrangement.

SNK CMV-100/5 5-Axis CNC Horizontal Machining Center New 2016 - Installed 2017 CNC Control: yes CNC Control: Fanuc 31i-B5 Main Specifications - See Below: See Below Table Size:: 1000mm x 1000mm (39.3 x 39.3 in) Distance from Pallet surface to spindle center: 0-1,300mm (0 -51.1 in) Distance from pallet surface to spindle end (when spindle is in vertical position): 0-1,000 mm (0-39.3 in) Max Table Load: 1,500 kg / table (3,300 lbs.) Spindle:: See Below Spindle Speed: 40 to 8,000 RPM Spindle Nose Taper: CT-50V (Dual face contact type) Coolant Thru Spindle: yes Spindle motor drive: VAC 30/22 kW (40/29.5 HP) Torque N-m: 26 to 653 Nm Travels: See Below Table Longitudinal (X-Axis): 1,500 mm (59.0 in) Column transverse (y-Axis): 1,330 (52.3 in) Spindlehead vertical (Z-Axis): 1,300 mm (51.1 in) Spindlehead tilt (A-Axis): +30 to -120 deg. Table rotation (C- ...

Ultrasonic tube filling and sealing machine with the following equipment: - Basic machine - Blank tube magazine incl. tube feeding chute for autm. Entering the blank tubes - automatic tube alignment according to the typeface or identification mark - Ultrasonic capping unit for closing PE and laminate tubes - Coding device on the tube fold, one-sided, incl. 4 set of coding numbers (0-9) - Cutting device on the tube fold - 1 format set for PE tube size D.35 mm - Format range 19mm - 50mm tube diameter - Cycle rate 15 - 30 tubes/min. Depending on product Please also note our current machine offers ( NEW + USED ) on Resale under : abc://abc.resale.de/angebotelinkd-user.php?myid=35837&dealer=1&order=1 & abc://abc.resale.de/angebotelinkd-user.php?myid=35846&dealer=1&order=1 & Visit us also on : cbv-pack

Ultrasonic tube filling and sealing machine with the following equipment: - Basic machine - automatic tube alignment according to the typeface or identification mark - Ultrasonic capping unit for closing PE and laminate tubes - Coding device on the tube fold, one-sided, incl. 4 set of coding numbers (0-9) - Cutting device on the tube fold - 1 format set for PE tube size D.35 mm - Format range 13mm - 50mm tube diameter - Cycle rate 10 - 15 tubes/min. Depending on product and operator Please also note our current machine offers ( NEW + USED ) on Resale under : abc://abc.resale.de/angebotelinkd-user.php?myid=35837&dealer=1&order=1 & abc://abc.resale.de/angebotelinkd-user.php?myid=35846&dealer=1&order=1 & Visit us also on : cbv-pack

Machine for the completion of insulation strip assembly Manufacturer: Aluro Type: BTM 100908-190 Year of construction: 2005 Location: Zweibrücken - Roll-in below 90° in 1 pass - Separately adjustable retaining castors - 4x2 horizontal retaining castors at the top and bottom with Vulkollan coated surfaces - Correction for the straight alignment of the profiles - Stop with safety switch - Display of position and pressure with display, correction of mechanical deformation after roll-in We will be happy to send you further information on request.

sheet width: 2050 mm plate thickness: 6,0 mm pre-bending: 4,0 mm diameter of upper rolls: 160 mm diameter of lower rolls: 140 mm total power requirement: 2,2 kW weight of the machine ca.: 3.000 kg dimensions of the machine ca.: 3500 x 1500 x 1300 mm New price ~ 48.000 euros from a repair workshop - good condition (!) Furnishing: - hydraulic 4-roller bending machine - with conical bending device Inclination of the bottom roller and the side rollers Alignment in parallelism in each side roller position Hardened stop roller Workpiece limitation for a cone with a 45° pitch: Working length max: 60% Bending capacity max: 50% - pivoting operation - Digital displays (2 pieces) for the side roller position - Adjustable contact pressure of the bottom roller with manometer - hardened rollers SAE 1050 CK 45 - Conical bending device - Hydraulic folding store for removing closed pipes - Direc ...

sheet width: 2050 mm plate thickness: 6,0 mm pre-bending: 4,0 mm diameter of upper rolls: 160 mm diameter of lower rolls: 140 mm total power requirement: 2,2 kW weight of the machine ca.: 3,0 t dimensions of the machine ca.: 3,5 x 1,5 x 1,3 m New price ~ 45.000 euros from a maintenance workshop rarely used () Furnishing: - hydraulic 4-roller bending machine - with conical bending device Inclination of the bottom roller and the side rollers Alignment in parallelism in each side roller position Hardened stop roller Workpiece limitation for a cone with a 45° pitch: Working length max: 60% Bending capacity max: 50% - pivoting operation - Digital displays (2 pieces) for the side roller position - Adjustable contact pressure of the bottom roller with manometer - hardened rollers SAE 1050 CK 45 - Conical bending device - Hydraulic folding store for removing closed pipes - Direct drive ...

Sample filling system of a disinfection liquid bottle filling line for smaller bottles with a filling volume of up to 100ml. The fully automatic filling process includes: Aligning and feeding of the bottles | filling with 2 to 8 filling heads and with high accuracy by anti-drip device | automatic alignment, feeding and capping of the lids / spray caps, single or double sided labeling of the bottles | outfeed and collection of the bottles to a collection table or to the next production station. -Specifications: number of filling nozzles: 4 (can be customized for a surcharge) | number of heads for lid positioning and capping: 1, each (can be customized for a surcharge) | filling range: 30-100ml | dosing method: by piston pump | accuracy: +/- 1% | speed: max. 2000 bottles/hour, at 100ml max. 500 bottles/hour | label size: L10-350mm, W10-200mm | product contact parts are made from corrosion- ...

Format Range: max. 1650 mm min. 275 mm Equipment: Longitudinal seam, folding bottom, double edge, 4-point gluing, electronic gluing unit HHS X-tend 8 channel with 4 nozzles, Disc gluing unit link with re-pumping device, electronic Overtaking fold with servos, feeder with vacuum, primary crusher left, Kickers, counters, digital position indicators, pressing device after folding, motorized threading station, Jagenberg DBS 01 control, Fully automatic format setting Jagset II, corrugated cardboard package , 3 x alignment with the press belt, pneumatic, clocked press belt. Press belt extension, video surveillance tray, cleaned, tested, new conveyor belts, new press belts at the top / bottom Other: The machine can be viewed while it is running, by arrangement.

Mechanical high-pressure machine vice ALLMATIC type HD 160 high-pressure clamp jaw width 160 mm jaw height 50 mm wingspan max. 302 mm clamping pressure max. 3.2 ton. Guideway height 85 mm - integrated turntable - clamping force preselectable in 4 steps, clamping pressure max 3.2 ton. - High-pressure clamp with mechanical power amplifier - span adjustable in 2 steps- lateral threads for workpiece stop- precise straightening grooves in the base surface for alignment on the machine table Dimensions: 600 x 160 x 140 mm Weight 58 Kg good condition; used

Hydro-mechanical high-pressure machine vice hydraulics high-pressure clamp SAFEWAY type PHV 160 Year of construction approx. 2010 jaw width 160 mm jaw height 58 mm clamping range: 0 to 315 mm Guideway height: 83 mm - clamping pressure max 6 ton. - 3 clamping ranges adjustable via plug-in bolts, 0 to 116mm, 95 to 215 mm and 195 to 315 mm- High-pressure clamp with hydraulic power amplifier - precise straightening grooves in the base surface for alignment on the machine table Text suggestion ready Ralf Dimension: 650 x 240 x 140 mm Weight 55 Kg good condition 4 pieces available, price per piece; used

State of the machine: Excellent, after a full renovation Device characteristics: Capacity: about 300 kg of dough per hour, Dough up to 80% water content, Moving speed of the dough ribbon max. 1.5 m/min., Dough ribbon width up to 170 mm, Quick row alignment with easy-to-move rotary blades, Possibility to supply double-sided grain sprinkler (optional), Machine made of stainless steel. Warranty: 6 months of parts warranty - worldwide

Machine Type: SK50 Mandrel Manufacturer: KYUSHUKOGU Type: SK50 Condition: used / very good Offer will only be sent if a complete imprint is provided! Price 178,50 Euro incl. VAT and shipping within Germany. Location Warstein , Germany Reference MZ-WER-1223-1 DESCRIPTION We offer you a used alignment mandrel, see pictures. Technical data will follow. Availability: immediately Our offer is aimed at tradespeople who are registered within the meaning of the Trade Regulation Act according to §14 GewO. The offer is subject to change, subject to prior sale. Please provide your full contact details to receive a quote with our terms and conditions and payment terms. Errors in the descriptions and offers are excepted!

HIGH SPEED MULTIFORMAT POUCH MACHINE MATERIAL WIDTH :1200MM (MAX) MATERIAL DIA : 1000 MM (MAX) POUCH WIDTH : 50-650 MM POUCH LENGTH : 30-300 MM - (250 MM X 6 =1500 MM) MACHINE SPEED :180CPM /45 meters POWER : 220V, 3 PHASE, 50/60 HZ COLOR: : STAINLESS STEEL/White COMPLETE WITH: - SHAFTED UNWIND ST AND X 1 SET - UNWIND DIA. 800 MM WITH ROLL - 3" AIR SHAFT - 2.5 KW POWDER BRAKE WITH ROTARY ENCODER AND DANCER FOR TENSION CONTROL - .55KW DRIVE MOTOR NIP WITH INVERTER CONTROL FOR UNWIND UNIT FOR CONTINUOUS MOTI ON UNWINDING - LPC SENSOR FOR UNWIND MATERIAL FOR EDGE/LINE GUIDING - PHOTO SENSOR (NT-6) FOR PUNCHING AND ELECTRONIC TOUCHSCREEN CONTROL FOR POSITIONING X 1 SET - DANCER ROLLER DEVICE X 1 SETS - UNWIND STAND CAN BE MOVED LEFT/ RIGHT BY MANUAL - ADJUSTMENT FOR QUICK SETUPS Material folding device for gussets x 1 set. Material ...

Format range: max. 740 mm (can be extended to 1040 mm) min. 50 mm Equipment: Longitudinal seam, disc gluing unit on the left, vibrator, cutting alignment according to the feeder, Primary crusher right and left, kicker, counter, digital position indicators, motorized, extended transfer station, Press belt with pneumatic pressure adjustment, main drive with Frequency. Overhaul 2023: cleaned, checked, painted and with new feeder and transport belts, as well as new press belts. Other: The machine can be viewed while running by appointment.

Pos.1 Buffer conveyor belts for layer formation for 4 frieze lengths Pos.2 Gantry stacking system Pos.3 Parcel roller conveyors in the area of gantry systems Pos.4 Security technology Pos.5 Machine control Pos.6 Intermediate strip automatic The mechanization is designed for the following workpiece dimensions: Length: 320 - 1000 mm Width: 56 - 120 mm Thickness: 20 - 40 mm Stack Dimensions: Length: 400 - 1000 mm (double lengths up to 2 x 520mm) Width up to: 1200 mm Height up to: 1200 mm Stacking is carried out on Euro pallets Max. output: max 40 parts/min or max 4 layers/min (board or batten layer!) Pos.1 Buffer conveyor belts for layer formation for 4 frieze lengths Quantity: 4 pieces Length: 2600 mm each Usable width: 800 mm each Propulsion: Spur gear motor Conveying speed: 15 m/min Incl. side guide rulers and layer alignment (One layer is formed,  ...

Foldingmachine 24P Make MBO Model K800.S 4SKTZ - FP Year 2008 Size Min: 150 x 210 mm / Max: 780 x 1200 mm Feeder MBO FP120 pallet feeder - with MBO Vaculift sheet seperation head and MBO Vacubelt suction belt VIVAS suction alignment belt, slitter shafts prior to entering buckle station, exit to left or right by turning the section Folding configuration 4 platebuckles + 2 knives + 1 buckles after the first knife Delivery OMG Economic P700 pright delivery with pressing Number of pages 16-24 pages for signatures Details Vacuum pump, noise hoods, MBO Navigator controls Available direct

Mast attachment, for street, path, square lighting ELSPRO SCOOPLED ESL/M842 Material: stainless steel Pipe dimension ( outside): 88.9 mm / 140 mm, material thickness: 3 mm Mast diameter: Ø 67-80 mm / 117 - 130 mm 2 Carrying port: horizontal ( 0° version ) Diameter: Ø 50 mm, length: 220 mm, material thickness: 2 mm with recess for cable outlet and plate: 90 x 30 mm, for straight alignment of the lamp suitable lamps - see EL3238 and EL3239 ! New ! Dimensions: 540 x 150 x 460 mm

Machine foot set with side alignment, wedge feet, leveling shoe PAGUS Support height: 84 - 90 mm side orientation: 10 mm Support surface: 170 x 110 mm Weight: 14.25 kg each 2 pieces each Dimensions: 260 x 165 x 125 mm

Magnetic holder, alignment aid for taps HELD Ø 3.5 - 4.5 - 6 - 7 - 9 - 11 mm ( Ø3.5-4.5-6-7-9-11mm ) DIN 352, 371, 376 in wooden box used, tested ! Dimensions: 195 x 100 x 70 mm

GeneralUniversal Milling Machine; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal650 mmCross520 mmVertical475 mmTechnical DataType of main driveAC Drive power (100% DC)16 kWDrive power (40% DC)21 kWSpeed range20 - 15000 rpmSpindle taperSK40 Tool holder DIN ISO 7388-1-A Clamping SystemDIN ISO 7388-3-A, AD Feed rate longitudinal/transverse/vertical-42000/-42000/-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minFloor space/WeightDimensions (L x W x H)2,85 x 2,35 x 2,75 mWeight approx.7500 KgDirect measuring systemDirect path measuring systemSpindle speed 15,000 rpmMotor spindle speedMASTER® HSK-A63 Spindle speed 20 - 15,000 min-1 Output 21 kW / 16 kW (28 hp / 21.5 hp) Torque 111 Nm / 85 Nm (82 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)NC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 630 x 500mm / 24.8 ...

Reference ID: PP-35200 Category Flatbed Die Cutter Manufacturer: Heidelberg Model Promatrix 106 CS Year Built 2021 Speed 8000 sheets/h Max. Size 760×1,060 mm Min. Size 300×350 mm Condition Very Good Location Europe Availability December 2023 Machine Description Processing of cardboard up to 2,000 g/m² Stripping Station 1. Register system 2. Integrated quick release systems for everyone ools (top, middle, bottom) 3. Fine adjustment of the tools Position indicators 4. Test sheet removal 5. Electronic sheet monitoring 6. Preparation table (option) Tray (CS only) 1. Non-stop roll cloth 2. Pneumatic flap for 3. Test sheet removal 4. Sheet format setting with 5. Position indicators 6. Motorized brake brush 7. Braking force adjustment 8. Strip insertion device (option) 9. Gripper edge separation (option) Non-stop investor 1. Suction head for paper, cardboard  ...

KÄRCHER ROBO 30 pipe boring machine for pipes, flat material and profiles With this machine, tubes, flat material or profiles can be cut very quickly and accurately in a single pass. can be drilled or milled at an angle or at an angle up to  50° in such a way that filling rods or filling tubes up to 1" can be drilled or milled can be plugged through. With the standard additional clamp for the jaw chuck, you can not only cut pipes, but also transport flat material or other profiles with the feed and at the desired angle up to over Make 50° single-sided holes or through holes. The clamping jaws in the self-centering vice have a recess at the top for flat material. We are unrivalled when it comes to converting to another material! The feed is positioned at 0.1 mm with the counter with absolute or chain gauge. With the ROBO 30, you don't need to set limit switches or cams for ...

Label dispenser Macro SP12 right side RA1956 Manufacturer: Schwinn Model: Macro SP 12 Year of manufacture: 2018 Alignment: right Label passage: up to 115 mm Label speed: 1-18 m/min Maximum diameter label roll: 300 mm Core diameter 40 mm expandable with adapter Power supply: Euro plug 230/50Hz Integrated control with control parameters, controllable inputs and outputs, fault messages,... Additional equipment: Start triggering external AP 010-500 Vacuum Applicator Module Maintenance - equipment - combination Core adapter AP 031 Prewarning - label supply Mounting frame Control box Warning light, 3-stage Features: nominal voltage: 50Hz, 230 maximale Etikettengröße: 115 Etikettengeschwindigkeit: 1-18 m/min Kerndurchmesser Rolle: 40 mm maximale Größe Etikettenrolle: 300 Etikettendrucker enthalten?: NEIN Etikettenaplikator?: Stempel Vorwarnung Etikettenvorrat: JA Hub Aufklebestempel: 500 m ...

TRUMPF TruPunch 3000-1300 (S11) punching machine was built in Germany in 2013. The reliable machine with extensive equipment and modern components offers its user unparalleled precision and accuracy in machining both thick and thin sheet metal. In addition to standard punching and marking, the punching machine also allows fast grooving, surface embossing, forming and chipless threading in stainless steel, structural steel and aluminium. On the machine’s sturdy and welded C” shaped structure, sits a specially designed brush table with integrated balls, designed to facilitate the loading and unloading of workpieces. The use of this type of table prevents scratches and nicks from appearing on the surface of the sheet, which results in a significant increase in the quality of the machining. During the entire production process, the sheet is held rigidly by hydraulic clamps fixed to th ...

Manufacturer: Fischer Rückle, Type: AFD, Year: 2007, Control: Programm, Double knife: yes, Cutting lenght mm: 4200, Working hight mm: 40, Alignment light: yes, Digital readout lineal guide: yes, Motorische Anschlagverstellung mm: automatisch, Hydraulically driven kinfe beam: yes, Pressure beam: yes, Wight approx. kg: 10000, machine ready for demonstration: yes, Year :2007

STROJARNE PIESOK XZMP 3150/6.3C 3-roll plate rolling machine built in Czechoslovakia in 1983 is designed for pre-bending and rolling sheet metal into cylindrical or conical covers and segments. The machine is distinguished by a fully welded structure with increased rigidity and three high-quality 300 mm diameter rollers with longitudinal grooves for easy alignment of the sheet. The bottom rollers, driven by a high-performance motor with two stages of rotation, allow for vertical repositioning during pre-bending and coiling, and also allow for an offset to an inclined position when the claw couplings are opened. As a result, each of the four lower roll bearings can be freely adjusted in the pitch range. The XZMP plate rolling machine has a control panel with a function to monitor the position of the lower rollers directly on the numerical indicators. The total weight of the STROJARNE  ...

wheel alignment scissor lift 5t, galvanized, Specifications: Stroke underfloor 1,800mm, stroke above-ground 2,160 mm Overall length 5,200 mm, overall width 2,300 mm, ramp height 360 mm, platform length 5,200 mm, Platform width 729 mm, motor power 3 kW, electrical connection 230/400V, 50 Hz, compressed air connection 6-8 bar, Lifting time 45 sec., lowering time 45 sec. Characteristics: Electro-hydraulic drive,2 maintenance-free hydraulic cylinders, No mechanical connections between the rails,Maintenance-free roller lafers, HD unit integrated in the control panel, operation via push buttons with integrated storage option, Integrated hand pump and emergency lowering in case of power failure, Hydraulic synchronization system with automatic level compensation (master-slave system)Pneumatic set-down device with automatic pressure system. Unlocking, non-contact inductive proximity swit ...

Manufacturer: Jsting , Type: PFS 1800, Year: 1964, Longitudinal cutting guillotine: yes, Pressbalkenöffung mm: ca.80, Cutting lenght mm: 1800, Schnittbreite min-max mm: 850, Working hight mm: ca.40, Alignment light: yes, Digital readout lineal guide: yes, Motor-driven kinfe beam: yes, Motorized stop adjustment mm: yes, Year :1964

DIRECTLY FROM THE PRINT SHOP We sell this machine on behalf of our customer and try to realize his asking price. However, we are open to offers from you. Offer consists of: - High-performance finisher DocuCutter DC-645 Duplo DocuCutter DC-645 High-Performance Finisher for Digital Color Printing: -Investor: Suction/blowing air feeder with alignment section - Operation: via LCD display - Control: Barcode control - PC included - Business Card Module BCM-54 54mm - Longitudinal perforation PFM-01 - Job memory: 80 memory locations for repeat jobs - Error prevention: Ultrasonic Double-Blade Control Dowry compartment Test Run Program Print Mark Reading - Built-in blades: 6 longitudinal knives + 1 cross-blade -Format: max. 650x370mm min. 210x210mm - Paper weight: 110-350g/sqm - Loading capacity: 100mm - Grooves per sheet: max. 10 -Vel ...

Manufacturer: Josting , Type: EFS, Year: 1968, Control: hand, Longitudinal cutting guillotine: yes, Pressbalkenöffung mm: 60, Cutting lenght mm: 2800, Schnittbreite min-max mm: 500, Working hight mm: 30, Alignment light: yes, Digital readout lineal guide: yes, Motor-driven kinfe beam: yes, Motorized stop adjustment mm: yes, Knife drive: Elektro, Year :1968

• Labeller for two-sided labelling of rectangular, conical, oval and semicircular products • Output max. 80 labels/min • Basic conveyor belt width 80 mm • Interchangeable separator at the infeed • Chain alignment for centred positioning of the products • Head band for product stabilisation • 2 lateral label dispensers Bluhm Weber Alpha Compact Plus RH+LH in the wipe-on procedure, can also be used individually • Label dispenser height/cross/length adjustable and inclinable • Label format min. 10 x 10 mm, max. 200 x 200 mm • Label roll diam. 300 mm, core diam. 76 mm • One-sided inkjet printing unit for labels Bluhm Weber Markoprint X1 Jet with cartridge • Press-on device • Product delivery on Bluhm Weber turntable, diam. 1,000 mm, white plastic plate, speed adjustable, mobile • PLC Siemens S7-1200 CPU 1214C • HMI Siemens Simatic • Drive 400V/5 ...
