adam used for sale

Manufacturer: Adam Bodenabsetzer, Type: Aufrichter, Year: ca.1998, Control: keine, Corpus length max mm: 1200, Working hight mm: 950, Hydraulical: Motorisch, Belt width: 600/1300, Total power kW: ca.5, Year :ca.1998

Adam weighing scale, type: FK 150, number: 17250, maximum weight: 150 kg, minimum weight: 10 gram, scale dimensions: 500 mm x 400 mm, total dimensions: 650 mm x 400 mm x 800 mm.

Exhaust silencer type KRNS 45 DN 250 according to the reflection and absorption principle in vertical design Outer diameter: 600 mm x height 14000 mm Nominal entry distance DN 250 (Ø 273.0 mm), radial in height of 2500 mm (?) with flange and counter flange, Flange hole circuit according to EN 1092-1/02/PN10 Material flanges St 37 galvanized Flanging made of V4A, screws and seal Nominal outlet diameter DN 250 (Ø 273.0 mm), axially with pipe end made of stainless steel sheet V4A (W.Nr. 1.4571) static calculation basis DIN 4133, Wind load zone 3

1 x Adamson 96in wide x 32in dia 4 roll Z Calender line, peripherally drilled rolls with oil heating, motorised nip adjustment to rolls 1,2 and 3 (roll 4 fixed). Cross axis roll 4. Hydraulic pre-load to all rolls, Adjustable stock guides, rubber coated pressure roller with hydraulic adjustment and v/s motor to roll 4, with Adamson unidrive gearbox on universal couplings, with 500HP, 850/1300rpm, 785A, 500V, 3ph, 60Hz Reliance DC variable speed motor to rolls 1, 2 and 3. 200HP, 850/1400rpm DC variable speed motor to roll 4. 1 x Embossing station 1 x set of 8 x 96in wide x 24in dia stainless steel cooling drums. 1 x Dual turret winder. Full drawings available. We can supply the upstream equipment I.e. internal mixers that fed the calenders, along with the batching and material handling/dosage equipment. Complete line available in very good condition previously us ...

Pressing force: 350t, stroke: 30-200mm, stroke adjustment: 130mm, stroke speed: 30/min, table dimensions: 1700x1250mm, including Roller Feeder Straightening Machine ALBA VhyRia 600S and uncoiler.

Stroke adjustment: 29-160mm, ram adjustment: 130mm, stroke speed: 48/min, connected load: 14kW.

AGFA ADAMAS 125 COU ( Clean out unit ) Washer for Adamas printing plates. Excellent condition, little used. online version without tables. Stock! AGFA ADAMAS 125 COU ( Clean out unit ) washer for Adamas processing. Excellent condition, was very rare in use. Online version without infeed and outlet. Processor is on stock and can be inspected on appointment.

thread dia.: M5 - M10 mm Tools speed: 320 - 1600 U/min table-size: 330 x 290 mm throat: 215 mm voltage: 380 V threading length: mm total power requirement: 0,55 kW weight of the machine ca.: 300 Kg dimensions of the machine ca.: 1,2 x 0,8 x 2,0 m Tapping machine including: machine base footswitch vice different tools see pictures The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Description: Tapping machine included: Machine base frame Footswitch vice different tools see pictures Thread diameter M5 - M10 mm Tool speed 320 - 1600 rpm Table size 330 x 290 mm Projection 215 mm Operating voltage 380 V Total power requirement 0.55 kW Machine weight approx. 300 kg Space requirement approx. 1.2 x 0.8 x 2.0 m Approx. Onsite Dimension. (l x w x h): 1,200 x 800 x 2,000 mm, weight approx.: 300 kg

Machine number: 2023-578 Adam Power Systems GmbH Thank you for your interest in our machines, please also check out our other offers Specifications: Emergency generator + + NEW - Year of construction 2023 + + producenter:Geen Power Model : GP88 S/I-N-A Engine : Perkins 4 cylinder turbo diesel water-cooled. Generator: MECCALTE Rated Power: 88 KVA Continuous Power: 80KVA RPM : 1500 U/Min. Frequency : 50 Hz Voltage : 230/400 volts L:Operating hours : approx. NEW Year built:2023 Consumption: 14-16./h (75%) Sr: 254865 L2260xW1000x1420/1325 kg Incl. sockets Complete with control Incl. diesel tank in the base frame Immediately ready for use Delivery nationwide possible for an extra charge Adam Power Systems GmbH Power generator of all kinds Werkstraße 16, 24848 Kropp

Machine number: 2022-558 Adam Power Systems GmbH Thank you for your interest in our machines, please also check out our other offers Manufacturer :Caterpillar -Olympian Model-GEP400-2 Serial No: OLY00000K23000227 Power : /350KW/400KVA Engine: Caterpillar 6cylinder turbo diesel Year of construction :2007 Operating hours:19000h RPM : 1500 U/Min. Frequency : 50 Hz Voltage : 230/400 volts Complete with control Incl. diesel tank in the base frame Incl. new battery Power generator possesses: oil filter, water filter, fan belt. L:460/W:160/H:220/KG4800 Immediately ready for use Delivery available nationwide at an additional cost. Adam Power Systems GmbH Power generator of all kinds

Machine number: 2022-521 Adam Power Systems GmbH Thank you for your interest in our machines, please also have a look at our other offers Specifications: Condition: Like new ! Manufacturer :FG Wilson Model : P605E2 Power : KW484/605KVA Engine: Perkins 6Cylinder Turbo Diesel Operating hours: 85 h RPM : 1500 U/Min. Frequency : 50 Hz Year built:2010 Complete with controls Cifhwhjrez Incl. diesel tank in the base frame Ready to use Delivery against 1500, - € is possible. Adam Power Systems GmbH Generator set of all kinds

Machine number: 2023-578 Adam Power Systems GmbH Thank you for your interest in our machines, please also check out our other offers Specifications: Emergency generator + + NEW - Year of construction 2023 + + producenter:Geen Power Model : GP88 S/I-N-A Engine : Perkins 4 cylinder turbo diesel water-cooled. Generator: MECCALTE Rated Power: 88 KVA Continuous Power: 80KVA RPM : 1500 U/Min. Frequency : 50 Hz Voltage : 230/400 volts L:Operating hours : approx. NEW Year built:2023 Consumption: 14-16./h (75%) Sr: 254865 L2260xW1000x1420/1325 kg Incl. sockets Complete with control Incl. diesel tank in the base frame Immediately ready for use Delivery nationwide possible for an extra charge Adam Power Systems GmbH Power generator of all kinds Werkstraße 16, 24848 Kropp

Machine number: 2022-522 Adam Power Systems GmbH Thank you for your interest in our machines, please also have a look at our other offers Condition: very good, fully functional Engine: Caterpillar 3516B, 1800KW Generator: AvK Power: 2230 kva each Frequency : 50 Hz Year of construction: 2000 Voltage: 10000V RPM : 1500 U/min. Hours: Price on request Adam Power Systems GmbH Generator set of all kinds Werkstraße 16, 24848 Kropp, Germany

Machine number: 2023-578 Adam Power Systems GmbH Thank you for your interest in our machines, please also check out our other offers Specifications: Emergency generator + + NEW - Year of construction 2023 + + producenter:Geen Power Model : GP88 S/I-N-A Engine : Perkins 4 cylinder turbo diesel water-cooled. Generator: MECCALTE Rated Power: 88 KVA Continuous Power: 80KVA RPM : 1500 U/Min. Frequency : 50 Hz Voltage : 230/400 volts L:Operating hours : approx. NEW Year built:2023 Consumption: 14-16./h (75%) Sr: 254865 L2260xW1000x1420/1325 kg Incl. sockets Complete with control Incl. diesel tank in the base frame Immediately ready for use Delivery nationwide possible for an extra charge Adam Power Systems GmbH Power generator of all kinds Werkstraße 16, 24848 Kropp

Machine number: 2022-526 Adam Power Systems GmbH Thank you for your interest in our machines, please also have a look at our other offers Cusqhfl Specifications: Manufacturer: Olympian Power Systems Model : GEP65 - 9 Condition: ( Very good ) Engine: Perkins 3Cylinder Turbo Diesel water-cooled. Power : 65KVA / 52KW RPM : 1500 U/Min. Frequency : 50 Hz Voltage : 230/400 volts Operating hours : approx. 13350h Year built:2012 Incl. sockets Complete with controls Incl. diesel tank in the base frame Ready to use Delivery possible nationwide for an extra charge Adam Power Systems GmbH Generator set of all kinds Werkstraße 16, 24848 Kropp, Germany

Machine number: 2022-527 Adam Power Systems GmbH Thank you for your interest in our machines, please also have a look at our other offers Specifications: Manufacturer: Olympian Power Systems Model : GEP165-1 Condition: ( Very good ) Engine: Perkins 6Cylinder Turbo Diesel water-cooled. Power : 165KVA / 132KW RPM : 1500 U/Min. Frequency : 50 Hz Voltage : 230/400 volts Operating hours : approx. 5780h Year built:2011 Complete with controls Incl. diesel tank in the base frame Ready to use Delivery possible nationwide for an extra charge cir9wkqvr0 Adam Power Systems GmbH Generator set of all kinds Werkstraße 16, 24848 Kropp, Germany

Machine number: 2022-529 Adam Power Systems GmbH Thank you for your interest in our machines, please also have a look at our other offers Specifications: Condition: New Manufacturer :P ower generation Model : C110D5 Power : /88KW/110KVA Engine: Cummins 6Cylinder Turbo Diesel Year built in :2022 Operating hours:00h RPM : 1500 U/Min. Frequency : 50 Hz Voltage : 230/400 volts Complete with controls Incl. diesel tank in the base frame Iqkvfmr Ready to use Delivery against 800, - € is possible. Adam Power Systems GmbH Generator set of all kinds

Machine number: 2022-531 Adam Power Systems GmbH Thank you for your interest in our machines, please also have a look at our other offers Specifications: Condition: New Manufacturer :P ower generation Model : C170D5 Power : 170KVA Engine: Cummins 6Cylinder Turbo Diesel Year built in :2022 Operating hours:00h RPM : 1500 U/Min. Frequency : 50 Hz Voltage : 230/400 volts Complete with controls Incl. diesel tank in the base frame Ready to use Re2ob Delivery against 800, - € is possible. Adam Power Systems GmbH Generator set of all kinds

Machine number: 2022-530 Adam Power Systems GmbH Thank you for your interest in our machines, please also have a look at our other offers Specifications: Condition: New Manufacturer :P ower generation Model : C150D5 Power : 150KVA Engine: Cummins 6Cylinder Turbo Diesel Iziyofp Year built in :2022 Operating hours:00h RPM : 1500 U/Min. Frequency : 50 Hz Voltage : 230/400 volts Complete with controls Incl. diesel tank in the base frame Ready to use Delivery against 800, - € is possible. Adam Power Systems GmbH Generator set of all kinds

Machine number: 2022-532 Adam Power Systems GmbH Thank you for your interest in our machines, please also have a look at our other offers Specifications: Condition: New Manufacturer :P ower generation Model : C22D5 Power : 22KVA/17,6 KW Engine: Cummins 3Cylinder Diesel Year built in :2022 Operating hours:00h RPM : 1500 U/Min. Frequency : 50 Hz Voltage : 230/400 volts Complete with controls Incl. diesel tank in the base frame Ready to use Delivery against 500, - € is possible. Adam Power Systems GmbH Generator set of all kinds

Machine number: 2022-533 Adam Power Systems GmbH Thank you for your interest in our machines, please also have a look at our other offers Specifications: Condition: New Manufacturer :P ower generation Model : C33D5 Power : 33KVA/26,4 KW Engine: Cummins 4Cylinder Diesel Year built in :2022 Operating hours:00h RPM : 1500 U/Min. Frequency : 50 Hz Voltage : 230/400 volts Complete with controls Incl. diesel tank in the base frame Ready to use Delivery against 500, - € is possible. Adam Power Systems GmbH Generator set of all kinds

Machine number: 2022-548 Adam Power Systems GmbH Thank you for your interest in our machines, please also check out our other offers For sale we have new diesel generator sets with the following data: Condition: New Engine Cummins Model: 4BTA3.9-G11 Rated Power: 77KvA Continuous power: 70KvA Frequency : 50 Hz Voltage: 400/231 V RPM : 1500 rpm. Year of construction: 2023 Included: Diesel filter, air filter, oil filter High-quality sound hood made of galvanized steel Water preheater Diesel tank, approx. L234 Auto-start, Batteries Circuit breakers Diesel tank Sophisticated controls Battery Battery Charger Controller-DEEPSEA: Model: DSE6120 UK Protection: • Low oil pressure • High water temperature • High/low voltage • High engine temperature and overspeed. • Voltage regulator Frequency regulator • Emergency stop • Startup error  ...

Machine number: 2022-546 Adam Power Systems GmbH Thank you for your interest in our machines, please also check out our other offers For sale we have new diesel generator sets with the following data: Condition: New Engine Cummins Model: 4BTA3.9-G2 Rated Power: 55KvA Continuous power: 50KvA Frequency : 50 Hz Voltage: 400/231 V RPM : 1500 rpm. Year of construction: 2023 Included: Diesel filter, air filter, oil filter High-quality sound hood made of galvanized steel Water preheater Diesel tank, approx. 234L Auto-start, Batteries Circuit breakers Diesel tank Sophisticated controls Battery Battery Charger Controller-DEEPSEA: Model: DSE6120 UK Protection: • Low oil pressure • High water temperature • High/low voltage • High engine temperature and overspeed. • Voltage regulator Frequency regulator • Emergency stop • Startup error  ...

Machine number: 2022-549 Adam Power Systems GmbH Thank you for your interest in our machines, please also check out our other offers For sale we have new diesel generator sets with the following data: Condition: New Engine Cummins Model: 6BTAA5.9-G12 Rated Power: 165KvA Continuous power: 150KvA Frequency : 50 Hz Voltage: 400/231 V RPM : 1500 rpm. Year of construction: 2023 Included: Diesel filter, air filter, oil filter High-quality sound hood made of galvanized steel Water preheater Diesel tank, approx. L342 Auto-start, Batteries Circuit breakers Diesel tank Sophisticated controls Battery Battery Charger Controller-DEEPSEA: Model: DSE6120 UK Protection: • Low oil pressure • High water temperature • High/low voltage • High engine temperature and overspeed. • Voltage regulator Frequency regulator • Emergency stop • Startup err ...

Machine number: 2022-547 Adam Power Systems GmbH Thank you for your interest in our machines, please also check out our other offers For sale we have new diesel generator sets with the following data: Condition: New Engine Cummins Model: 4BTA3.9-G13 Rated Power: 110KvA Continuous power: 100KvA Frequency : 50 Hz Voltage: 400/231 V RPM : 1500 rpm. Year of construction: 2023 Included: Diesel filter, air filter, oil filter High-quality sound hood made of galvanized steel Water preheater Diesel tank, approx. L234 Auto-start, Batteries Circuit breakers Diesel tank Sophisticated controls Battery Battery Charger Controller-DEEPSEA: Model: DSE6120 UK Protection: • Low oil pressure • High water temperature • High/low voltage • High engine temperature and overspeed. • Voltage regulator Frequency regulator • Emergency stop • Startup erro ...

Machine number: 2022-545 Adam Power Systems GmbH Thank you for your interest in our machines, please also check out our other offers For sale we have new diesel generator sets with the following data: Condition: New Engine Cummins Model: 4B3.9-G12 Rated Power: 33KvA Continuous power: 30 KvA Frequency : 50 Hz Voltage: 400/231 V RPM : 1500 rpm. Year of construction: 2023 Included: Diesel filter, air filter, oil filter High-quality sound hood made of galvanized steel Water preheater Diesel tank, approx. 135L Auto-start, Batteries Circuit breakers Diesel tank Sophisticated controls Battery Battery Charger Controller-DEEPSEA: Model: DSE6120 UK Protection: • Low oil pressure • High water temperature • High/low voltage • High engine temperature and overspeed. • Voltage regulator Frequency regulator • Emergency stop • Startup error  ...

Machine number: 2022-564 Adam Power Systems GmbH Thank you for your interest in our machines, please also check out our other offers Specifications: Manafacture: Fogo Condition: ( very good ) Operating hours:7950h Engine:Iveco 6 cylinder turbo diesel Year built:2019 Frequency : 50 Hz Voltage: 400/231 V RPM : 1500 rpm. Delivery nationwide possible for an extra charge Adam Power Systems GmbH GW3C9QE Power generator of all kinds Werkstraße 16, 24848 Kropp

Machine number: 2022-565 Adam Power Systems GmbH Thank you for your interest in our machines, please also check out our other offers Specifications: producenter:Atlas Copco Condition: ( very good ) Model : QAS150 Condition: ( very good ) Engine : Volvo Penta 6cylinder Terbo diesel water-cooled. Power : kw/120/KVA 150 RPM : 1500 U/Min. Frequency : 50 Hz Voltage : 230/400 volts Operating hours : approx. 10400h Year built:2007 Shuro - CEE 16 A 1× 400 V - CEE 32 A 1× 400 V - CEE 63 A 1× 400 V - CEE 125A2 400v -Precaution - Length 3.35mm - Width 1.20 mm - Height 1,70 mm/2500Kg - Complete with control Incl. diesel tank in the base frame Immediately ready for use Delivery nationwide possible for an extra charge Adam Power Systems GmbH Power generator of all kinds Werkstraße 16, 24848 Kropp

Machine number: 2022-569 Adam Power Systems GmbH Thank you for your interest in our machines, please also check out our other offers Specifications: Iveco emergency generator 275 kVA + + NEW - Year of construction 2023 + + - - - - - Engine: - Iveco (Italy) - Model: N67TE8P - 6 cylinders -Diesel - 1500 rpm - Displacement: 6700 cc - - - - - Generator: - Manufacturer: LEROY SOMER (french) - 250 / 275 kVA - 230 / 400 volts - 50 Hertz - AVR controller - - - - - Control / Start Unit: - Digital ComAp Start Unit - Manual start at the touch of a button - Automatic start function - Generator monitoring: volts, amps, hertz, kW - Engine monitoring - Hour meter - Maintenance timer - - - - - Other data: - Dimensions: 4300 x 1300 x 2200 - Weight: 3800 - Tank volume: 170 litres - Sound level: approx. 67 dB (7m) - Fuel consumption: 41.2 l/h (75%)  ...

Machine number: 2023-574 Adam Power Systems GmbH Thank you for your interest in our machines, please also check out our other offers Specifications: Scania emergency generator 440 kVA + + NEW - Year of construction 2023 + + - - - - - Engine: -Scania - Model:DC13 072A - 6 cylinders -Diesel - 1500 rpm - Displacement: 6700 cc - - - - - Generator: - Manufacturer: LEROY SOMER (french) - 360/ 440 kVA - 230 / 400 volts - 50 Hertz - AVR controller - - - - - Control / Start Unit: - Digital ComAp Start Unit - Manual start at the touch of a button - Automatic start function - Generator monitoring: volts, amps, hertz, kW - Engine monitoring - Hour meter - Maintenance timer - - - - - Other data: - Dimensions: 4500×1450×2250 - Weight: 3800 - Tank volume: 320 litres - Sound level: approx. 67 dB (7m) - Fuel consumption: 61-69l/h (75%) Other: ...

Machine number: 2023-575 Adam Power Systems GmbH Thank you for your interest in our machines, please also check out our other offers Specifications: Emergency generator + + NEW - Year of construction 2023 + + Engine:Perkins UK Generator: MECCALTE GP-22 KVA GP-33 KVA GP-50 KVA GP-66KVA GP-88 KVA GP-110 KVA - All prices are net plus VAT. - Delivery at an additional cost is possible. Adam Power Systems GmbH Power generators of all kinds Werkstraße 16, 24848 Kropp

Machine number: 2023-576 Adam Power Systems GmbH Thank you for your interest in our machines, please also check out our other offers Specifications: Emergency generator + + NEW - Year of construction 2023 + + producenter:Geen Power Model : GP190 S/I-N-A Engine : iveco 6cylinder turbo diesel water-cooled. Generator: MECCALTE Rated Power:190 KVA Continuous Power:170 KVA RPM : 1500 U/Min. Frequency : 50 Hz Voltage : 230/400 volts Operating hours : approx. NEW Year built:2023 Fuel consumption: 29.4l/h (75%) Sr: 254879 L:280/W:100/H160/kg2090 Incl. sockets Complete with control Incl. diesel tank in the base frame Immediately ready for use Delivery nationwide possible for an extra charge Adam Power Systems GmbH Power generator of all kinds Werkstraße 16, 24848 Kropp

Machine number: 2023-578 Adam Power Systems GmbH Thank you for your interest in our machines, please also check out our other offers Specifications: Emergency generator + + NEW - Year of construction 2023 + + producenter:Geen Power Model : GP88 S/I-N-A Engine : Perkins 4 cylinder turbo diesel water-cooled. Generator: MECCALTE Rated Power: 88 KVA Continuous Power: 80KVA RPM : 1500 U/Min. Frequency : 50 Hz Voltage : 230/400 volts L:Operating hours : approx. NEW Year built:2023 Consumption: 14-16./h (75%) Sr: 254865 L2260xW1000x1420/1325 kg Incl. sockets Complete with control Incl. diesel tank in the base frame Immediately ready for use Delivery nationwide possible for an extra charge Adam Power Systems GmbH Power generator of all kinds Werkstraße 16, 24848 Kropp

Machine number: 2022-520 Adam Power Systems GmbH Thank you for your interest in our machines, please also have a look at our other offers For sale is a diesel engine in the good condition Engine:Caterpillar:C13 Year built:2011 HP:415 Kw:309 Operating hours:5500

Three-phase electric motor, two speeds ABM, ADAM BAUMÜLLER GmbH MARKTREDWITZ Type: 2.DF1/63 b-4/2 0,12 / 0,18 kW 1390 / 2770 rpm 380 V 3AC 50 Hz Design: B5 IP44 / 54 Shaft diameter: Ø 11 mm Wavelength: 18 mm Groove width: 4 mm Flange diameter: Ø 95 / 140 mm bolt circle diameter: Ø 115 mm 4x bore: Ø 10 mm used, tested ! Dimensions: 210 x 140 x 185 mm

Gear motor with brake ADAM BAUMÜLLER DF80b - 4S1947 ( DF80b-4S1947 ) 1,1 kW 28 rpm 200 / 380 V IP33 shaft diameter: 30 mm New ! Dimensions: 600 x 240 x 250 mm

GeneralHorizontal Machining Centre in travelling column construction; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical100000/100000/100000 mm/minRapid traverse longitudinal/transverse/vertical100/100/100 m/minWorking area 1Longitudinal630 mmCross800 mmVertical750 mmIntegrated motor spindle speedMASTER®Drive power (100% DC) 30 kWDrive power (40% DC) 46 kWTorque (100% DC) 130 NmTorque (40% DC) 200 NmSpeed range - 15000 rpmSpindle taper HSK-A 63CabineFull protection cabinDirect measuring systemDirect path measuring systemNC swivel rotary tableNC swivel rotary table with pallet carrier max. table load: 400 kg / 882 lbs rotation B axis: 360° swivel range A axis: 25° / -200° range X / Y / Z - axis 630 x 800 x 750 mm/24.8 x 31.5 x 29.5 in axis kinematics A / B (basic machine without NC rotaryClamping hydraulics 2/4 channels f. working tabl ...

Roller die line consisting of:- 1 x Troester 200mm pin barrel extruder Type QSM200K-16D power roller feed, 10 rows of 8 pins, L/D ratio 16:1 Serial no. 1816/88, year 1988, With temperature regulation unit, 282kW ASEA DC variable speed motor mounted on rails (moves away from calender to clean out etc) Hydraulic sheeting head linked directly to:- 1 x Adamson 24in dia x 68in wide two roll calender, peripherally drilled rolls cross axis, bush type bearings, motorised nip adjustment with unidrive gearbox 277kW ASEA DC variable speed motor Hydraulic clamping device for extruder Set of 4 x cooling drums Dual wind up and liner applicator Chalking Unit Siemens PLC control. Complete line in excellent condition. PRICE: On request.

GeneralUniversal Machining Centre Vertical headstock Tool change system double gripper NC-Swivel rotary table with pallet carrier 3 pallets 500 mm x 500 mm / 19.7 in x 19.7 in T-slots according to DIN 55201-A2 linear pallet changer coolant tank 500 l / 132 gallon chip conveyor with netting band filter integrated, coolant ring jet; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minWorking area 1Longitudinal735 mmCross650 mmVertical560 mmFloor space/WeightWeight approx.18300 KgDirect measuring systemDirect path measuring systemCabineFull protection cabinNC swivel rotary table with pallet carrierTable surface 500 x 500 mmCentre bore 50 mmMaximum load (table centre) 500 KgMotor spindle 20,000 rpmMotor spindle speedMASTER® HSK-A 63 Spindle speed 20 - 20,000  ...

GeneralUniversal milling and turning machining centre with duoBLOCK construction; Control: CELOS with Siemens 840D sl Operate Technical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minWorking area 1Longitudinal800 mmVertical850 mmCross1050 mmTool changerApplicationUniversal Type of magazineWheel Tool changer planehorizontal Type of gripperDouble gripper Number of tools123 NC mill-turn table with palletNC mill-turn table with pallet number of T-slots: - 1x cross slot 14 H7 / 0.55 H7 - 12x star slots 14 H12 / 0.55 H11 / 22.5° max. table speed milling operation: 30 rpm turning operation: 800 rpm integrated balancing sensor Pallet changer for 2 palletsType of Measuring system Direct measuring systemTable surface Ø 800 x 630 mmCentre bore 50 mmMaximum load (table centre) 1400 Kg4. Axes (swivelling range) 360  ...

GeneralUniversal Milling Machine; Control: CELOS with Siemens 840D sl Operate Working area 1Longitudinal650 mmCross520 mmVertical475 mmFloor space/WeightDimensions (L x W x H)2,85 x 2,35 x 2,75 mWeight approx.7500 KgTechnical DataType of main driveAC Drive power (100% DC)25 kWDrive power (40% DC)35 kWSpeed range20-20000 rpmSpindle taperHSK-63A DIN 69893 Clamping SystemDIN ISO 7388-3-A, AD Feed rate longitudinal/transverse/vertical-42000/-42000/-42000 mm/minRapid traverse longitudinal/transverse/vertical42/42/42 m/minDirect measuring systemDirect path measuring systemSpindle speed 20.000 rpmMotor spindle speedMASTER® HSK-A63 Spindle speed 20 - 20,000 min-1 Output 35 kW / 25 kW (47 hp / 33 hp) Torque 130 Nm / 86 Nm (96 ft lbs / 63 ft lbs) (40 / 100 % duty cycle)NC swivel rotary tableSwivel Rotary Table for simultaneous machining Clamping surface dia. 630 x 500mm / 24.8 x 19.6 in swivel ra ...

Technical DataSpindle taperHSK-E 50 Feed rate longitudinal/transverse/vertical1-80000/1-80000/1-80000 mm/minRapid traverse longitudinal/transverse/vertical80/80/80 m/minGeneralHSC-Precision Centre - Active chiller for main spindle and linear drives - Active chiller for electrical cabinet - Direct absolute measuring system with air purge - Coolant-airblast changeover - MPC (Machine Protection Control); Control: 3D-control Heidenhain iTNC 530 HSCI Working area 1Longitudinal450 mmCross580 mmVertical460 mmTool changerApplicationVertical Type of magazineChain Type of gripperDouble gripper Number of tools30 Rigid tableRigid table, clamping area 460 x 600 mm / 18,11 x 23,62 inch Loading weight max. 600 kg / 1322 lbsSpindle speed up to 40,000rpm with Shaft CoolingSpindle speed 20 up to 40,000 rpm within shaft cooling for tool taper HSK-E50 DIN 69893 AC-Main drive with 19,5/15 kW (100/40%DC) 14,5 ...

Technical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minGeneralUniversal Machining Centre Vertical headstock Tool change system double gripper NC-Swivel rotary table with pallet carrier 3 pallets 500 mm x 500 mm / 19.7 in x 19.7 in T-slots according to DIN 55201-A2 linear pallet changer coolant tank 500 l / 132 gallon chip conveyor with netting band filter integrated, coolant ring jet; Control: CELOS with Heidenhain TNC 640 Working area 1Longitudinal735 mmCross650 mmVertical560 mmFloor space/WeightWeight approx.16800 KgDirect measuring systemDirect path measuring systemCabineFull protection cabinPackage Mill / Turn HSK-A 63Package Milling / Turning: Upgrade NC-swivel rotary table to Milling - Turning / direct drive Pallet C-axis d 630 mm / 24.9 in Speed C-axis 1.000 rpm Integrated balancing sensor Motor ...

GeneralHigh dynamic Vertical Drill-Tap centre with best milling performance; Control: 3D-control Siemens 840D sl Operate Working area 1Longitudinal350 mmCross420 mmVertical380 mmTechnical DataFeed rate longitudinal/transverse/vertical60000/60000/60000 mm/minRapid traverse longitudinal/transverse/vertical60/60/60 m/minMain driveDrive power (100% DC) 6 kWDrive power (40% DC) 8,5 kWTorque (100% DC) 41 NmTorque (40% DC) 48 NmSpeed range 20 - 15000 rpmSpindle taper BT 30Clamping System ISO 7388-3 - JD30ToolchangertoolchangerType of magazine WheelNumber of tools 15TableTable surface 740 x 420 mmMaximum load (table centre) 400 KgPreparation NC-Devider EA510 indirectPreparation 4.th axis Lehmann EA 510.L indirect measuring System Attention: Customer specific optimisations and adjustments are not part of delivery!Chip removal package with chip conveyorChip removal package with chip conveyor conte ...

General2 spindles automatic lathe - 2 cross slides - Main and counter spindle - Y axis on slide 1 - Y axis on slide 2 - C axis on main spindle - C axis on counter spindle - Chip tank with coolant system and coolant pump - Part unloading chute; Control: Numeric control Fanuc 32i Working areaBar diameter max.20 mmCounter spindle collet cleaningCounter spindle collet cleaning with coolantChanging kit from steady to sliding headstockChanging kit from steady to sliding headstock including application bush type Dunner B260 and bush-spindle syncronismAdditional charge for belt type chip conveyorAdditional charge for belt type chip conveyor, compatible with shaft-unloading-device Specific chip removol systems (for example: scraping blades chip conveyors, with additional filtering systems) are recommended in case of short chip material machininOil mist filter for emulsion or oilOil mist filter fo ...

GeneralTwo-spindle turning centre with - 2 cross slides - 2 turrets with 12 positions each (all driven) - main spindle and counter-spindle - 2 C-axis - 2 tool drives - Y-axis on slide 1 - chip conveyor - workpiece-unloading; Control: Fanuc 31i Working areaBar diameter max.50 mmTransport beltTransport belt for finished workpieces outside the machineDMG MORI NETSERVICEDMG MORI NETSERVICE Qualified support by Internet-based remote diagnosticsIoT connectorDMG MORI IoTconnector The IoTconnector allows the use of online services of DMG MORI (e.g. NETSERVICE or MESSENGER on ADAMOS)Special equipmentAdditional bar capacity for main spindle from Ø 50 mm to Ø 65 mm (max. 5.500 RPM) Additional charge for cooling on turret (upgrade to) 50 bar instead of 25 bar

Working area 1Longitudinal735 mmCross650 mmVertical560 mmTechnical DataFeed rate longitudinal/transverse/vertical40000/40000/40000 mm/minRapid traverse longitudinal/transverse/vertical40/40/40 m/minGeneralUniversal Machining Centre in monoBLOCK construction; Control: CELOS with Siemens 840D sl Operate Tool changerTool changer planevertical Type of gripperDouble gripper Number of tools30 Max. tool length315 mmMax. tool diameter with occupied adjacent pockets80 mmMax. tool dia. with free neighbouring pockets160 mmFloor space/WeightWeight approx.12100 KgNC swivel rotary table integrated in rigid tableType of Measuring system Direct measuring systemTable surface 800 x 650 (Ø 650) mmCentre bore 50 mmMaximum load (table centre) 600 KgSlot width 14 mmRotation Speed 5. Axis 20 rpm5. Axes (swivelling range) +120/-120 x 0,001 degree4. Axes (swivelling range) 360 x 0,001 degreeRotation speed max.4 ...
