achs used for sale

New CNC working machine brand: Cosmec Type: Smart 30, 5 Achsen Configuration example: other equipment possible on request The smart serie: - Flexibility through cantilever construction - Best equipped for door processing - Protection by laser system (instead of step mats) - Especially good for machining light / small workpieces The controlling: OSAI CNC system control + Aspan CAD-CAM software: - Aspan uses simple commands to execute the machining process - By entering dimensions you can precisely position the machining operations - The machining operations are displayed on the virtual workpiece. - Diverse macros facilitate programming (of holes, slots, linear milling, arc milling...) Aspan Doors - Software module for easy creation of programs for door processing. - Different door types are already stored (doors with milled arches, round doors...) - Doors can ...

; NEW

New water jet cutting machine Make: aps Type: 3D 5-axis 301508 Little hours Conversion to pure water operation possible Year: new -Latest generation of control -Latest servo drives -Latest CAD-CAM software -Latest high pressure pump 22 kW -Latest Abrasivausrüstung with cutting head, Abrasivdosierer and storage containers Work area: L: 3000 mm x B: 1500 mm x H: 800 mm Dimensions: L: approx. 5000 mm, B: approx. 3500 mm, H: approx. 3200 mm Z-axis: optional with collision protection Cutting speed: up to 10 m / min. Positioning accuracy: ± 0.1 mm (500 mm travel) Repeatability: ± 0.05 mm Die heads: 1 x Abrasivschneiden or 1 x pure water cutting Electrical connection: 3 x 400 V, 50/60 Hz.; 35 A slow Compressed air connection: approx. 20 NL/min at 6 bar Water connection: depending on the used high pressure pump High pressure pump: 22 kW Pres ...

Ref.nr. 00887 Description of the system Used swap bodies vehicle Swopper 3 ACHSER Manufacturer: Fiege tec Model Swopper max 200 (3 axles) Year of manufacture 2014 (possibly also 2010) still to be clarified Self propelling chair Swopper max 200 with global viewing cab and the single-lever Masterpilot for all driving, lifting, steering and locking functions ergonomically mounted on the right side of the driver's seat. A powerful diesel engine serves as the drive. The hydrostatic drive allows the speed to be infinitely adjusted both forwards and backwards. The max. 200 is equipped with an articulated drive axle at the front and an air-sprung two-axle unit at the rear. Front tyres: two pieces 12.00-20 Industrial – Rear tyres: eight pieces 7.50-15 Industrial. Lighting according to STVZO consisting of 2 three-chamber lights, side spotlights and position lights, reversing lig ...

Tip width: 700 mm Tip height: 150 mm Circulation diameter over bed: 300 mm Bed width: 180 mm Spindle bore: 38 mm Mounting in the spindle bore: MK 5 Speed range, infinitely variable: 30 - 450 / 150 - 3000 rpm Range of longitudinal feeds: (14) 0.07 - 0.65 mm/U Area of plan feeds: (11) 0.03 - 0.12 mm/U Metric threads: (18) 0.2 - 3.5 mm Inch Thread: (21) 8 - 56 Gg/1" Pinole path: 85 mm Pinole holder: MK 3 Engine power S1 100%: 1.5 kW / 400 V Motor recording power S6 40%: 2.2 kW / 400 V Machine dimensions (W x D x H): 1380 x 640 x 500 mm Weight approx.: 235 kg without base Delivery: - Digital display - 3-jaw chuck PO3-160 mm steel version - Feed flange 160 mm - Solid grain tips - Interchangeable wheels - Quick-release steel holder size 20-2 with 2 straight inserts - Slip clutch - Micrometer longitudinal stop - Plan sled with top support - Frequency inverter ...

Used cutting machine Hundegger K2 machining width 1250mm Manufacturer: Hundegger, DE Type: K2i - 5 1250mm Built: 2009 Condition: used, in operation, very good Consisting of: 1. Fully automatic wood conveying with feed roller conveyor and feed and feeding cross conveyor Consisting of a roller conveyor with cross-over from the cross conveyor with 5 strands equipped with hinge tape chains, which ensure injury-free transport Length: 9.2 m, Width: 2.2 m 2. Lower table swivel crosscut saw with 4-axis control With a carbide saw blade of 900 mm (11.0 KW) max. saw cutting depth: 300mm at 90° infinitely adjustable machining stroke with positioning drive pivotable 0- 360°, inclination 0-65°, drive servo-hydraulic, With this aggregate, all saw cuts, such as angles and shitging sections, longitudinal sections for burring and lruning, hewing or stash sections) are executed.  ...

Ref.nr 00888 Designation of the system Swap bodies Vehicle Swopper 2-axle Manufacturer: Fiege Tec Model Swopper max 200 (2 axles) Year of manufacture 2004 Self-propelled Swopper max. 200 with global viewing cab and the single-lever Masterpilot for all driving, lifting, steering and locking functions ergonomically mounted on the right side of the driver's seat. A powerful diesel engine serves as the drive. The hydrostatic drive allows the speed to be infinitely adjusted forwards and backwards. The max. 200 is equipped with an articulated drive axle at the front and an air-driven single-axle unit at the rear. Front tyres: two pieces 12.00-20 Industrial a 50% - Rear tyres: four pieces 2.50-15 Industiral approx. 50% lighting according to StVZO consisting of 2x three-chamber lights, side spotlights and position lights, reversing lights, rotating beacon Technical details Hour ...

Table dimensions: 2500x 780 mm Motor output: 7,5 kW Spindle diameter: , mm reus: 1.500 - 10.000 U/min The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Laser welding machine with 200 watt laser power - incl. 4th axis (axis of rotation) - For cylindrical welding tasks - Lamp-pumped YAG laser - Point welding machine for the finest welding tasks - for jewelry, optics, precision engineering, etc. - Welding spot from 0.1 to 3mm - For practically all metals (steel, stainless steel, silver, gold, titanium, etc.) - incl. optical microscope (10x) - Additional CCD microscope with reticle - Current, pulse width, repetition rate, frequency at the controller adjustable - incl. inert gas connection - Nd3+:YAG laser (metal cavity with xenon flash lamp) - Lamp-pumped Nd:YAG laser with 200Watt power - External cooling - Power connection 230Volt / 32 Amp. Machine dimensions approx.: Width: 60cm Height: 120cm Depth: 110cm Weight: approx. 150kg . . . . . . --------------------------------------------------------- ...

x-travel: 3000 mm y-travel: 800 mm z-travel: 1100 mm total power requirement: kW weight of the machine ca.: 15 t required space: 4x6x3.5 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

table length: 2000 mm table width: 1500 mm burner heads: 0 total power requirement: kW weight of the machine ca.: t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

The technical data are manufacturer or operator information and are therefore non-binding for us. We reserve the right to sell the goods prior to the event, our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 12,000 m² of storage space, crane capacity 70 t More than 1,000 items of accessories for your workshop If you want to sell machines, production lines or your business, then contact us. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Manufacturer: Siemens Achsmotor für Ima Maschine, Type: 1FK6063-6AF71-1AG0, Motor with gear: yes, Maschinennummer: YF M110 5834 02 003, From machine: IMA BIMA, Motor with gear: yes,

x-travel 800 mm y-travel 500 mm z-travel 460 mm Table size 1000 x 500 mm Spindle holder ISO SK 40 Spindle speeds - infinitely variable 31.5 - 6150 rpm Operating voltage 380 V CNC control heidenhain 425 Rapid traverses 6000 mm/min Quill stroke 90 mm Coolant tank l Total power requirement 13.5 kW Machine weight approx. 3.1 t Dimensions approx. 2.20x2.70x2.35 m Hydraulic tool clamping full 4th axis + 5th axis +45° -20°

Manufacturer: Siemens Z Achsmotor IMA Bima 410, Type: Permanentmagnetmotor , Model: 1 FT5064-1AG71-4BB0, Serial number: NoEH063 7112 01 004 VDE 0530,

Manufacturer: Homag, Type: 2 Achser HC 010 o.Analogeingang, Model: 2-Achser F.mini-Controller Rev, Serial number: 2-083-02-8071,

new CNC working center Brand: Cosmec Type: Smart 30, 4 Axis example configuration: other equipment on request the smart serie: - Flexibility through cantilever construction - Best equipped for door processing - Protection by laser system (instead of step mats) - Especially good for machining light / small workpieces the controlling: OSAI CNC system controlling + Aspan CAD-CAM Software: - Aspan uses simple commands to perform machining - By entering dimensions you can precisely position the machining operations - The machining operations are displayed on the virtual workpiece. - Various macros facilitate programming (of holes, slots, linear milling, arc milling...) Aspan Doors - Software module for easy creation of programs for door processing - Different door types are already stored (doors with milled arches, round doors...) - Doors can be modified individ ...

Manufacturer: Homag, Type: Homatic Achskarte, Model: Servo 4 Achser, Serial number: 2-083-02-8075,

CNC processing centre Brand: TecnoTeam Type: Enjoy Basic 3 Achsen New machine Save your space: Standing upright means progress for human! - With a vertical CNC machine you save a lot of space: Wether for consuming material or a further machine, you have more space to use in your storage. Easy machine use: - TPA makes the use very easy, you find this software at several well-known machine brands - You see the programmed processings on a virtual display, no matter which process: if circle, bow, linear millings or drillings, - Create job lists in the CAM - Forget the calculator, the machine calculates for you. - For this software several genious tips and tricks are possible. With realiability to success: - Technoteam uses High-Quality components from well-established producers. - We modify the machine exactly to your needs: If you process massive wood, you get a stro ...

Manufacturer: Homatic, Type: Streckenprozessor 4 Achser, Model: Rev 5 , Serial number: 2-083-02-7013, Year: 10.10.1995, Year :10.10.1995

Manufacturer: Homag, Type: 2 Achser HC 010 o.Analogeingang, Model: 2-Achser F.mini-Controller Rev, Serial number: 2-083-02-8071,

Control: HEIDENHAIN iTNC-530 x-travel: 885 mm y-travel: 800 mm z-travel: 520 mm B-axis (table): +30/-120 ° c-axis: 360 ° table-size: 600x500 mm tool magazin:: 60 spindle taper ISO: 40 Big Plus spindle turning speed - stepless: 15000 U/min total power requirement: 25 kW rapid travel x/y/z: 36 mm/min rapid traverse (slewing motion): 60 U/min rapid traverse feeds rotary table: 100 U/min dimensions of the machine ca.: 3.8x3.6x3.0 m weight of the machine ca.: 12,1 t Coolant through spindle: pressure: 20 bar 3D measuring tracer: RENISHAW Chip conveyor: Coolant installation: The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Control: HEIDENHAIN iTNC-530 for axes: 5 x-travel: 712 mm y-travel: 508 mm z-travel: 515 mm -A-axis table swivelling: +30/-120 ° -C-axis table rotating: 360 ° rotary table dia.: 330 mm no. of tools in magazin: 60 max. tool diameter: 88 mm max. tool-dia with free toolbox: 125 mm max. tool length: 280 mm max. tool weight: 7 kg spindle taper: SK40 Big Plus spindle turning speed range: -15000 U/min power capacity - milling spindle: 25 kW weight of the machine ca.: 12.8 t dimensions of the machine ca.: 303x395x367 cm 3D measuring tracer: RENISHAW Zero point clamping system:: LANG TECHNIK Coolant through spindle: pressure: 20 bar The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Carpentry machine Hundegger k2 625 5 axis year 2003

Key data: 46 °, 3 mm, 1 mm

MARTIN T74 Automatic sliding table saw with 4-axis CNC control -Paratable integrated as 5th axis in the control and 3-axis scoring Mark: MARTIN Type: T74 AUTOMATIC - Radio Control Year of Make: 2008 M-No.: V484794 Table dimensions: 1,350 x 1500 mm. with table extension 600400 mm with tool storage Table height: 900mm Edging table: 3,300mm Main saw: 5.5 kW Saw blade shaft: ø 30 mm. with two drive pins 10 mm Saw blade change: "ProLock" quick-change system Saw blades: Ø 250 - 500 mm; up to Ø400 mm retractable under table; up to Ø400 mm can be combined with scoring Cutting height: CNC control up to max. 170 mm. (saw blade 500 mm) Saw blade swivel: CNC control 0 - 46° Cutting width: CNC control 1,350 mm Scoring machine: 3-axis controlled scoring machine Rip Fence: CNC Control Rip Fence; End position can be lowered automatically below table level Parallelogramtic:  ...

A Reichenbacher CNC multi-spindle woodworking center with automatic support table and vacuum pins is available. Traverse path X1/X2: 8540mm, traverse path Y1: 2500mm, traverse path Z1: 480mm, swivel B: 180°, swivel C: 360°, X3 axis: underfloor drilling unit, U2-U10: carrier movement 1-9 (gantry), axis speed X/Y/Z: 60m/60m/20m/min, turning speed B/C: 90°/s, table dimensions X/Y: approx. 8500mm/2600mm, max. workpiece weight: 150kg, max. workpiece dimensions X/Y: 8500mm/2600mm, number of carriers: 9. Workpiece dimensions X/Y: 8500mm/2600mm, number of carriers: 9, suction plates per carrier: 8, suction plate diameter: 100mm, carrier positioning: +/-1000mm, min. carrier distance: 300mm, total vacuum pump number: 72, vacuum pump stroke: 100mm, vacuum pump useful stroke: 25mm, tool positions: 24, max. tool weight: 6kg, max. tool length: 240mm, max. tool diameter: 300mm. Total system dimensio ...

x-travel: 620 mm y-travel: 520 mm z-travel: 460 mm c-axis: 360 ° b-axis: -50 / +110 ° distance spindle nose and table: 170 - 630 mm CNC-control: iTNC 640 HEIDENHAIN Table dimensions: Ø 650 mm max. table load: 500 kg spindle turning speed range: 12.000 U/min drive capacity - spindle motor: 15,5 / 33,0 kW rapid traverse: 48 m/min tool change unit: 48 Pos. SK 40 coolant: IKZ 30 bar voltage: 400 V total power requirement: 35 kVA weight of the machine ca.: 10,0 t dimensions of the machine ca.: 4,00 x 2,46 x 2,85 m chip conveyor: 2,90 x 0,50 x 1,30 m coolant tank: 2,30 x 1,70 x 0,45 m coolant pump: 0,60 x 0,50 x 0,90 m Oil cooler: 0,55 x 0,60 x 1,10 m 5-axis simultaneous machining center - Serial-No.: 9496-117 - Control ON: 10,137 h - Spindle ON: 3,380 h - Control: HEIDENHAIN iTNC 640 - electr. handwheel - IKZ 30 bar - chip conveyor The data for this ad was created with ModulMWS - the sof ...

Warneke aluminum tipping body, two axles with steering axle, - Year of construction: 1990, - Support load: 10 t, - Wheelbase: 220cm, - Dead weight: 10.6 t, - Maximum permissible total weight: 30 t

Heidenhain TNC 426/430 Year of construction 1998 Total Spindle Hours 17000 Travels X/Y/Z axis 500/380/380 mm Tool changer for 24 tools Tool holder SK40 Spindle speed 15000 rpm NC swivel rotary table 500 x 380 mm Feed speed max. 20000 mm/min Rapid traverse 30m/min Weight approx. 4000 kg Coolant Setup The machine is in very good condition. Milling spindle and axes run smoothly and very precisely.

Key data: 300 mm, 200 mm, 200 mm

Specifications: Manufacturer: Sodick Type: AQ 300 L (5 axles) Year of Make: 2005 Control: Sodick LN1W Travel distances X, Y, Z: X 300 mm, Y 200 mm, Z 200 mm Travel distances U, V: U 80 mm, V 80 mm Workbench Dimensions: 750 x 500 mm Max. workpiece height: 200 mm/180 mm Max. table load: 300 kg Dimensions and weight Dimensions L/W/H: 2,400 x 1,300 x 2,210 mm Weight: 2,700 kg Condition Condition: Used Functional: Tested and fully functional The machine is in very neat condition.

Knott single-axle trailer chassis

x-travel: 5000 mm y-travel: 2500 mm table-size: 2.000 x 2.500 mm table weight: 20.000 Kg B-axis (table): (0.001º) mm w-axis: 2000 mm z-axis: 800 mm rapid taverse: 10.000 mm taper ISO: ISO 50 turning speeds: 0-2.000 U/min spindle drive motor: 37 kW Torque: 12–183 U/min 0 internal coolant system feed: inkl. handwheel: HEIDENHAIN HR-410 total power requirement: 74 kW weight of the machine ca.: 35 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 700 mm y-travel: 590 mm z-travel: 480 mm Control: HEIDENHAIN ITNC 530 table weight: 265 Kg a-axis: ±110 ° c-axis: 360 ° rapid travel x/y/z: 32.000 mm/min feed: 15.000 m/min number of spindle speeds: 10.000 U/min/rpm spindle taper: BT - 40 spindle drive: 15/33 kW Torque: 192/189 Nm tool change unit: 32 pos. Working hours: 13.975 h Spindle hours: 6.258 h total power requirement: 30 kva weight of the machine ca.: 8,2 t dimensions of the machine ca.: 2.220 X 2.650 X 2.855 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 2134 mm y-travel: 1016 mm z-travel: 762 mm CNC-control: HAAS CNC Table dimensions: 2134 x 914 mm max. table load: 1814 kg spindle taper: SK 50 spindle turning speed range: 7500 U/min spindle motor: 22,4 kW feed range: 1270 mm/min rapid traverse: 15,2 m/min tool change unit: 30 Pos. coolant: IKZ voltage: 400 V total power requirement: kW weight of the machine ca.: 13,2 t dimensions of the machine ca.: 4,70 x 2,95 x 2,99 m chip conveyor: - Serial No.:1099476 - Year of manufacture 11/2012 - Through spindle coolant TSC - 5-Axis pivotable rotary table HAAS TR310 (as new condition) PRICE FOR MACHINE WITHOUT ROTARY TABLE TR310: 82.000,- EUR The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 1.050 mm y-travel: 610 mm z-travel: 610 mm control: HEIDENHAIN iTNC 530 Distance between table and spindle: 100-710 mm table-size: 1.200 x 600 mm table weight: 1.200 Kg rapid travel x/y/z: 30.000/20.000 mm/min feed: 12.000 m/min spindle taper: BT-40 spindle turning speed range: 60 - 10.000 U/min spindle drive: 7,5/11 kW Tools changer: 20 pos. Internal cooling system: 20 bar Chip coveyor: 2 handwheel: HEIDENHAIN HR-410 tool diameter: 100 mm tool length - max.: 320 mm weight of tools max.: 10 kg total power requirement: kW weight of the machine ca.: 7 t dimensions of the machine ca.: 2.900 x 3.420 x 2.888 m Complete installation 4th axis - Rotary table Golden Sun CNCT 321 (4th/5th axis)- Rotary table diameter 200 mm. - Rotary table tailstock - ZF box - Electrical cabinet air conditioning The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Hans Schreiner drilling,- & milling machine with 90° pivoting gear head and variable speed for the commercial demand. With halogenlamp and coolant system. Technical data: Spindle cone MT 4 Motor output power S1 1,5 kW, 400 V Weight 310 kg Table dimensions 800 x 240 mm max. workpiece height 400 mm Speeds 50 - 530 and 530 - 2600 rpm Max. drilling capacity in steel 45 mm Worktable travel x=500mm, Y= 175 mm Optional equipment: Underframe with coolant tub Drill chuck, quick release chuck, milling cutter and tools

x-travel: mm y-travel: mm z-travel: mm total power requirement: kW weight of the machine ca.: t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

TRAUB TNS 65 D / 5 - Axis CNC Lathe -For complete technical data, see data sheets -Control TX8 D -Built in 1994 -Rod passage 65 mm -Hydraulic bar loading magazine -Various driven tool holders -Tool holder -Three-jaw chuck -Complete documentation Hebkn Auovug Uls S Tel

Description Machine type: CNC-BAZ Vertical Model: M1 Pro with 4th axle incl. tailstock Manufacturer: DMGMORI Control: Siemens 828 D Year of Make: 2022 #001283 Location: Germany TECHNICAL DATA: Technical data Traversing range X-axis approx. 550 mm Y-axis approx. 550 mm Z-axis approx. 510 mm Table size approx. 850 x 650 mm Workpiece weight max. approx. 600 kg Speed max. approx. 12,000 rpm Spindle motor approx. 13/9 KW Number of tool positions approx. 24 Rapid traverse X / Y / Z approx. 24 m/min Pick-up taper approx. SK40 Footprint L x W x H approx. 3.1 x 2.7 x 2.9 m Machine weight approx. 5,600 kg Facilities Main spindle 12,000 rpm 13/9 kW - Separate electronic handwheel - 24 places chain magazine - SK40 - Coolant tank - IKZ pump 20bar - Filter for coolant - Bed flushing via M-function switchable - coolant spray gun - spindle blowing air switchable via M-funct ...

Used machine DMU40eVo with EROWA Magazine Machine type: CNC machining center 5-axis vertical Model: DMU40eVo with EROWA Manufacturer: DMGMORI Control: CELOS Heidenhain TNC640 Year of Make: 2019 Location: Germany #001371 Options: -Motor spindle speedMASTER® HSK-A63 -Spindle speed 20-20,000 min-1 -NC swivel rotary table -Tool magazine 210 places -Scraper chip conveyor -Internal coolant supply (IKZ) paper belt filter 20-80bar -Advanced chip flushing -Blowing air through the center of the spindle -Rotating lens -Oil and emulsion mist separator mechanical - Infrared touch probe -Tool breakage detection TRS2 -Preparation 3D quickSET -Signal light, four-color -DMG MORI automation interface -Pneumatic control of the PowerChuck 210 zero-point clamping system -EROWA Robot Compact (ERC80) -Magazine:15x rack level PC210 with 3 pos. each = total 45 pos. Changes, Thi ...

x-travel: 835 mm y-travel: 510 mm z-travel: 510 mm CNC-control: SIEMENS table-size: 1000 x 560 mm max. table load: 800 kg spindle taper: SK 40 spindle turning speed range: 20 - 8.000 U/min feed stepless: 1 - 20.000 mm/min rapid traverse: 20 m/min drive capacity - spindle motor: 13 / 9 kW tool change unit: 20 Pos coolant: voltage: 380 V total power requirement: 35 kVA weight of the machine ca.: 4,5 t dimensions of the machine ca.: 3,50 x 3,50 x 2,70 m - Serial No.: 15415027604 - machine as good as new - Machine ON: 2.599 h program ON: 1.027 h - tool measurement BLUM-MICRO incl. calibration tool - infrared probe HEIDENHAIN TS 640 - Tool changer 20 pos. with double gripper - chip tray (no chip conveyor) - div. tool holder - coolant unit The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Trailers, construction machinery trailers -Remark: Vehicle registration missing, electrical wiring missing / damaged -Trailer: Construction machinery trailer -Loading area: 2220/1085/H420 mm, border height 410 mm -Overrun device: HahnType ABV25. 1DZKE 2010 up to 2500 kg -Support load: 100 kg -Dimensions: 4175/2030/H980 mm -Own weight: 650 kg -Handover: in the current condition as viewed

for glass scale, scale, digital display, measuring rod, length measuring system, linear scale, fluorescent display, glass scale, scale, length measuring device, linear scale, positioning display, digital scales, digital scale -Manufacturer: RSF Elektronik, digital display from coordinate measuring machine Stiefelmayer C 100 413514 -Type: Z 735M -Dimensions: 275/120/H170 mm -Weight: 3.4 kg

Manufacturer: Biesse, Type: Rover 6.50 5-Achsmaschine conf.2, Year: 2006, Software: Editor 2.2.1.273, Working range X: 4600, Working range Y-axis: 1535, Working range Z: 230, C axis: yes, B-axis: yes, Programming station office: möglich, Number of milling spindles: 1, Milling engine 1 hours power: 12, rpm 1): 1500-2400, Kettenwechsler: yes, Number of tools per tool-magazine: 14, Mitfahrender Werkzeugwechsler: yes, Traverse table: yes, 4 station allocation: yes, Stops in the table front: yes, Stops in the table rear: yes, Vacuum pumps m³/h: 120, Rigging support table: yes, Tool clamping system: HSK-63 F, Saw unit: yes, Radial arm machine: yes, Werkstückspannsystem: Vakuum, Schnittstelle DXF: yes, machine ready for demonstration: yes, Zentralschnierung: yes, Presentation possible: yes, Year :2006

Manufacturer: Biesse 5 Achsmaschine, Type: Arrow FT-5 Achsmaschine, Year: 2007, Control: XP 600, Working range X: 2 X 1600 , Working range Y-axis: 2600, Working range Z: 300, C axis: yes, B-axis: yes, Pendulum processing: yes, Number of milling spindles: 1, Tool adaption system: HSK 63F, Milling engine 1 hours power: 12, rpm 1): ca. 24000, Number of tools per tool-magazine: 10, Vertical drills-X: 18, Horizontal drills-X: 3, Number of tables: 2, raster table: yes, 2 station allocation: yes, Stops in the table rear: yes, Vacuum pumps m³/h: 2 X 250, Drill vertical: 3, Saw unit: 120 mm, Portal machine: yes, Werkstückspannsystem: Vakuum, Schnittstelle DXF: yes, Zentralschnierung: yes, Available: sofort, FREE TEXT: Wassergekühlte Spindel, Year :2007

Table dimensions 1000 x 460 mm X Travel 762 mm Y travel 460 mm Z travel 460 mm Table load 700 kg Chip conveyor Weight 6500 kg Dimensions LxWxH = 2750 x 2160 x 2715 mm Spindle clearance: 0.05 - 0.10 mm Repair: approx. 9,000 € New: 12.000 €

Key data: 90 mm, 1000 mm, 1000 mm

Retrofit built in 2009 Spindle running time - control: 3093 h Switch-on hours: 10585 h - Control HdT TNC 320 - Displacement measurement system in all axes - New drives in all axles - New table, new clamping - New media aggregates Equipment: - Manual control unit - Coolant device - Hydraulic power unit Accessories: - 3D touch probe - Security fence

x-travel:1000 mm y-travel:1150 mm z-travel:700 mm table-size:900 mm table load:1500 kg spindle speeds:10.000 1/min spindle drive:Motorspindel von Cytec CS34-180-A 34&42KW/160&200 Nm spindle taper:A100 HSK T-slots:18mm/7/100 mm milling feed range:20.000 mm/min rapid traverse feeds:X/Y/Z: 24 m/min diameter of tools max.:150 mm workpiece length:300 mm weight of tools max.:20 kg weight of the machine ca.:15 t dimensions of the machine ca.:s. Katalog m CNC controller:Heidenhain iTNC-640 HSCI-Steuerung cnc rotary table:von Cytec; mit Ø900mm; 800 1/min Drehmomenttisch (AS3347) + HSK-T63/100 Spindel & ATC + TNC-640 Fräsdrehzahlregelung B-axis:Fräskopf, 0-180° c-axis:0,001° automatic tool changer:HSK-A/T100; 60 fach Scales:in X/Y/Z von Heidenhain mit Druckluft inner coolant:20

6-Achsenmessgelenkarmsystem Manufacturer: Zett-mess Type of machine: AMPG - 36 p Year of construction: 2003 2 same facilities are available. The price is for a plant. All information without guarantee
