Model
(Manufacturer: DOOSAN)
Turning Diameter 830 mm Turning lenght 750 mm Spindle speed 2000 rpm Controller FANUC-i Chuck size 24"
Inv. Num. : 7971 Type: Lynx 2100 LYB Producer: Doosan Created: 2022 Parameters: Control system: Siemens Sinumerik 828D Maximum turning length: 510 mm Max. turning diameter: 300 mm Maximum length of travel in the X-axis: 205 mm Maximum length of travel in the Y-axis: 105 mm Maximum feed in the Z-axis: 560 mm Maximum main spindle power: 15 kW Maximum spindle speed: 4500 1/min Length: 2880 mm Width: 1711 mm Height: 1921 mm Weight: 3900 kg
Control Fanuc ... i Series Turning diameter ... 600mm Turning length ... 330mm Inclined bed Spindle bore ... 61mm Turret Circumferential diameter over bed ... 600mm Circumferential diameter via support ... 400mm Axis X ... 205mm Axis Z ... 340mm Rapid traverse of the X axis ... 30m/min Rapid traverse of the Z axis ... 36m/min Spin speed... 0-6000 rpm. Max. spindle torque ... 127Nm Main engine power ... 11/15kW Doosan Robot Cell Assembly: 2x LYNX 2100A + ROBOTEC APC7 (Fanuc AM-100 iC6L) - The machines are supplied with chucks and pliers - High pressure cooling 20bar - Arm for picking up workpieces (Ø65 x L130 mm, weight 3 kg) - Automatic door opening - Spindle bladders for cleaning the clamping jaws - Oil separator - OIL SKIMMER - Tool Load Monitor (works with X-, Z-axis and S-spindle) - Workpiece conveyor The machine is in good condition, possible to test un ...
Key data: 760 mm, 1540 mm
CNC turning/milling center DOOSAN PUMA MX2600ST Year of construction 08-2012 Fanuc 31i-A with Manual Guide i Max. turning diameter: 760 mm Max. swing diameter over bed: 1,000 mm Max. turning length: 1,540 mm Max. bar passage: 76 mm Travel: X1 axis: 630 mm Y1 axle: 230 mm Z1 axle: 1,585 mm B-axis: -120° + 120° X2 axis: 220 mm Z2 axis: 1,515 mm A-axis: 1,550 mm Spindle motor main spindle 22/26 kW Spindle nose A2-8 Max. spindle speed 4,000 rpm Spindle motor sub-spindle 22/26 kW Max. spindle speed 4,000 rpm Spindle nose A2-8 Spindle motor milling spindle 22/18.5 kW Capto C6 Max. spindle speed 12,000 rpm B-axis, 0.001° Tool magazine with 40 tool positions Lower turret, 12-speed BMT65P Max. speed driven tools: 4,000 rpm Cooling by the spindle, 1.5 kW, 2.0 MPA, 21.6 l/min Coolant pump for lower turret, 2.2 kW, 1.0 MPA, 30l/min Coolant for powered tools Co ...
Listing ID: 22693 Brand Engine: Doosan Model: L126 TIM Power: 400 PS (294 kW) RPM: 2100 General condition: Very low hours only test hours Features: Flywheel housing: SAE-1 Flywheel: 14 inch Starter: 1 x 24V Governor: Mechanical Exhaust system: Water cooled Turbo: Water cooled Cooling system: H-E cooled Weight: 1060 kg Dimensions (cm) 150x90x130
CNC lathe LYNX 2100 B Manufacturer: DOOSAN Year: 2017 Control Fanuc ... i Series Turning diameter ... 350mm Rotation length ... 330mm inclined bed Spindle bore ... 76mm Turret Machine weight... 2750kg Axis X ... 300mm Axis Z ... 360mm Feed diameter ... 210mm Spindle speed ... 1-4500/min. L x W x H ... 2350x1595x1693mm The machine is in good condition, possible to test under electricity.
Doosan DNM 750 II Machining center - vertical - new in 2016 - control system: FANUC
Doosan G15S-2 Forklift truck Serial: DG01041 Runs on LP GAS, up to 1500Kgs lift capacity, max lift height 4730mm, treble masts, tilt forwards and backwards, with sideshift, comes with fork extensions
DOOSAN PU126TI 395 HP - 2100 RPM / 0 HOURS AFTER OVERHAUL / NEW PISTON RINGS / CONNECTING RODS / BEARINGS
MAX DIAMETER OF ROTATION: 750 MM MAX DIAMETER SWITCHABLE: 680 MM SWITCHABLE LENGTH: 1195 MM CNC: FANUC 18i-TB MAIN SPINDLE: MAX SPEED. OF ROTATION: 2800 RPM DIN 55026 8 ' ' CHUCK NOSE BAR PASS: 95 MM MOTOR POWER: 30 KW SELF-CENTRING DIAMETER: 315 MM Tailstock: POSITIONING STROKE: 1310 MM RACEWAY: 150 MM TUBE DIAMETER: 115 MM TORRETA TOOLHOLDER: MOTOR POWER: 10-17.5 KW TOOL DIMENSIONS: 25X25 MM BARENI DIA DIMENSIONS: 32-40 MM
X-AXIS STROKE MM 2,400 Y-AXIS STROKE MM 960 AXLE STROKE Z MM 800 TABLE SIZE MM 2600X900 ATTACK: BT50 SPEED ROTATION REVOLUTIONS/MIN 12,000 TOOLS N ° 30 FANUC 31I MODEL A CONTROL YEAR: 2012
Classification L136TI Cylinder L6 Aspiration TI Displacement (Liter) 8.1 Bore x Stroke (mm) 111 x 139 kW(ps)/rpm Heavy Duty 169(230) @ 2200 Dimension (L×W×H) (mm) 1364 x 911 x 937 Dry Weight (kg) 773 Emissions Tier 2 Power Range (kW) 169 Speed Range (rpm) 2200 The value is based on Output (ISO 3046, 8528).
Specifications Classification L136 Cylinder L6 Aspiration NA Displacement (Liter) 8.1 Bore x Stroke (mm) 111 x 139 kW(ps)/rpm Heavy Duty 118(160) @ 2200 kW(ps)/rpm Medium Duty - kW(ps)/rpm Light Duty - Dimension (L×W×H) (mm) 1266 x 875 x 937 Dry Weight (kg) 743 Emissions Tier 1 Power Range (kW) 118 Speed Range (rpm) 2200 The value is based on Output (ISO 3046, 8528).
Model L126TI No. of Cyl. L6 Aspiration TI Displacement (Liter) 11.1 Bore x Stroke (mm) 123x155 Output (ISO 3046, 8528 kW(ps)/rpm) 265(360) / 2000 - Dimension (L×W×H) 1235x855x1073 Dry Weight (kg) 1,060 Emission TIER-2
CONTROLS CNC controls FANUC 31I MODEL A BASIC FUNCTIONS number of spindles: 2 number of turrets: 2 live positions: yes number of c-axes: 2 number of y-axes: 1 WORKING RANGE TURNING turning diameter (max): 230 mm worpiece length max.: 700 mm MAIN SPINDLE spindle revolutions (min): 50 /min spindle revolutions (max): 5000 /min c-axis: yes COUNTER SPINDLE spindle revolutions (min): 50 /min spindle revolutions (max): 6000 /min c-axis: yes X/Z SLIDE tool fixture: Turret ELECTRICAL SPECIFICATIONS mains voltage: 400 V mains frequency: 50 Hz DIMENSIONS / WEIGHTS space requirements -left/right-: 2800 mm space requirements -front/back-: 1630 mm total height: 2200 mm total weight approx.: 9000 kg ATTACHMENTS (TURNING) chip conveyor: yes coolant unit: yes band filtration unit: yes coolant through ...
The Doosan Puma VT1100 is a powerful CNC vertical turning center designed for the economical machining of large workpieces. Its stable machine construction with a vertical main spindle ensures high process reliability and optimal chip removal. The machine is suitable for machining flanges, rings, housings, and other heavy, rotationally symmetrical components. The working area includes a maximum turning diameter of 1,100 mm, a maximum turning height of approximately 1,000 mm, and a maximum workpiece weight of approximately 2,000 kg. Spindle: Vertical main spindle, spindle motor 45 kW, hydraulic chuck, hydraulic workpiece clamping, 12-position tool turret Travel paths: X-axis approximately 650 mm, Z-axis approximately 800 mm Workpiece data: Max. workpiece diameter: 1,100 mm, max. workpiece height: approximately 1,000 mm, max. workpiece weight: approximately 2,000 kg. Equipment: hydraulic ...
The Doosan Puma VT1100 is a powerful CNC vertical turning center designed for the economical machining of large workpieces. Its stable machine construction with a vertical main spindle ensures high process reliability and optimal chip removal. The machine is suitable for machining flanges, rings, housings, and other heavy, rotationally symmetrical components. The working area includes a maximum turning diameter of 1,100 mm, a maximum turning height of approximately 1,000 mm, and a maximum workpiece weight of approximately 2,000 kg. Spindle: Vertical main spindle, spindle motor 45 kW, hydraulic chuck, hydraulic workpiece clamping, 12-position tool turret Travel paths: X-axis approximately 650 mm, Z-axis approximately 800 mm Workpiece data: Max. workpiece diameter: 1,100 mm, max. workpiece height: approximately 1,000 mm, max. workpiece weight: approximately 2,000 kg. Equipment: hydraulic ...
CNC lathe Type: PUMA 2000 SY Manufacturer: Doosan Year: 2005 Control: Fanuc Hours: 38000 Counter spindle Driven tools Collet chuck Spindle bore: 65 mm Max turning diameter: 330 mm Max turning length: 510 mm Swing over bed: 600 mm Swing over support: 550 mm X: 250 mm Z: 580 mm Turret: 12 positions Driven tools Chip conveyor Spindle overhaul in 2023 Machine in good condition, fully functional, under power Find more here - / Contact us at -
CNC lathe Type: LYNX 220 C Manufacturer: Doosan Year: 2008 Control: Fanuc Hours: 17100 Spindle overhaul in 2025 Max. turning diameter: 320 mm Max. turning length: 305 mm Swing diameter over bed: 510 mm Swing diameter over slide: 290 mm X: 175 mm Z: 330 mm Spindle speed: 4000 rpm Spindle passage: 76 mm Bar capacity: 65 mm Turret: 12 positions Machine in good condition, fully functional, under power Find more here - / Contact us at -
CNC turning center Type: Puma MX 1600 ST Manufacturer: Doosan Year: 2015 Highly productive multifunctional CNC turning-milling center designed for complete machining of parts in one clamping. The machine is equipped with a 16-position turret, milling spindle with 40-position Capto C5 tool magazine, counter spindle Y-axis and B-axis. The equipment includes Grundfos 25 bar high-pressure cooling Renishaw tool probe CNC Spacesaver 2500 bar feeder Sung Woo MX1600 chip conveyor Belt oil separator and belt workpiece ejector. Both the main and counter spindles have continuously adjustable clamping force and the possibility of using a hydraulic chuck or collet clamping Control: FANUC Series 31i Model A Hours: 17662 Max machining diameter: 330 mm Max machining length: 900 mm Main spindle: 6" chuck Speed up to 6,000 rpm Bar passage 51 mm Y-axis: ± 85 mm B-axis: ± 120° ...
CNC turning center Type: Puma MX 1600 ST Manufacturer: Doosan Year: 2014 Highly productive multifunctional CNC turning-milling center designed for complete machining of parts in one clamping. The machine is equipped with a 16-position turret, milling spindle with 40-position Capto C5 tool magazine, counter spindle Y-axis and B-axis. The equipment includes Grundfos 25 bar high-pressure cooling Renishaw tool probe CNC Spacesaver 2500 bar feeder Sung Woo MX1600 chip conveyor Belt oil separator and belt workpiece ejector. Both the main and counter spindles have continuously adjustable clamping force and the possibility of using a hydraulic chuck or collet clamping Control: FANUC Series 31i Model A Hours: 32371 Max machining diameter: 330 mm Max machining length: 900 mm Main spindle: 6" chuck Speed up to 6,000 rpm Bar passage 51 mm Y-axis: ± 85 mm B-axis: ± 120° ...
This 4-axis DOOSAN NHP6300 was manufactured in 2014. It features an impressive X-axis travel of 1,050 mm, Y-axis travel of 900 mm, and Z-axis travel of 1,000 mm. The machine includes a maximum pallet load of 1,500 kg and a tool capacity of 40 tools. If you are looking to get high-quality machining capabilities, consider the DOOSAN NHP6300 horizontal machining centre we have for sale. Contact us for further details.
control: FANUC 21i TB turning diameter: 355 mm turning length: 1330 mm c-axis: indexing: 0.001 ° turning speeds: -2800 U/min tool taper: BMT 65 Top turret tool hodler:: 12 rapid traverse X-axis: 16 m/min rapid traverse Z-axis: 24 m/min Overall size: 4000 x 2000 x 2100 mm weight of the machine ca.: 6700 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: 370 mm turning length: 712 mm control: Siemens Sinumerik 828D x-axis: 255 mm z-axis: 790 mm total power requirement: kW weight of the machine ca.: 3100 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: 420 mm turning length: 1350 mm spindle passage: 101 mm control: Siemens SL 828D ShopTurn number of controlled axis: 4 turning speed range: 3000 U/min power requirement: 22/18,5 kW rapid speed: 30 m/min number of tapers in turret head: 12/24 BMT 65 number of driven tools in turret: 12 BMT 65 Spindel speed of driven tools: 5000 U/min Spindelpower on driven tool: 7,5/5,5 kW y-axis: +/- 65 mm tail stock: MT-5 weight: 8,0 t dimensions: 5,7 x 2,3 x 2,32 m Heavy CNC- lathe with driven tools and Y- Axis in very good condition. First instalation: 03/2023 Appr. 5400 h Power on. - 2x 3-jaw chuck Ø 325 + 400 mm - some fixed tool holders - Tool pre- setter - chip conveyor - 4x driven tool holders - 2 + 2 driven toolholders with Capto C4 - oildust collector - band filter system with appr. 1000 ltr. - hydr. steady moveable wit turret SMW Autoblock SLU-X3.1 (Ø 20- 165 mm) - 3 colour ...
This 4-axis DOOSAN Lynx 220 LMS was manufactured in 2013. It features a Fanuc 31 i control unit and comes equipped with a short bar loader/bar feeder. If you are looking to get high-quality turning capabilities, consider the DOOSAN Lynx 220 LMS machine we have for sale. Contact us for further details.
x-travel: 1050 mm y-travel: 570 mm z-travel: 510 mm Control: Siemens 828D Main spindle:: turning speed range - main spindle: 12000 min/-1 power capacity - main spindel: 16,5 / 11 kW max. Torque: 141 Nm tool taper: BT 40 distance spindle /table: 150 - 775 mm work table:: table surface area: 1300 x 570 mm max. table load: 1000 kg tool magazin:: number of toolpositions: 40 pos. tool taper: BT 40 max. tool diameter: 80 mm max. tool length: 300 mm max. tool weight: 8,0 kg change-time tool to tool: 1,2 sec change-time chip to chip: 3,2 sec feeds:: rapid traverse ( X / Y / Z ): 36 / 36 / 30 m/min workpiece height max.: 590 mm total power requirement: 40,9 kVA weight of the machine ca.: 6,5 t dimensions of the machine ca.: 2,5 x 3,1 x 2,98 m 3-axis vertical CNC machining center - Siemens 828D CNC control and workshop-oriented programming support Shop Mill - 40-tool tool changer (BT 40) - Bas ...
Horizontal turning machine manufactured in 2006. This DOOSAN Puma 240 MB features driven tools and is equipped with a Fanuc 0iTC control unit. If you are looking to get high-quality turning capabilities, consider the DOOSAN Puma 240 MB machine we have for sale. Contact us for further details.
