used
bore capacity in steel (diameter): 32 mm arm length: 1230 mm table surface area: 1200 x 500 mm bore stroke: 180 mm feed - independent: 0,10 - 0,15 - 0,20 - 0,30 mm turning speeds: 45 - 1370 U/min taper MK: 4 total power requirement: 2,7 kW weight of the machine ca.: 1,8 t dimensions of the machine ca.: 2,2 x 1,8 x 2,3 m Quick radial with: - Feed - Thread cutting device The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Danube DR 32 High Speed Radial Drilling Machine High-precision and robust high-speed radial drilling machine, which is appreciated for its reliability in mechanical engineering and industrial production. Thanks to its swivelling boom, it allows the drill head to be positioned quickly and flexibly above the workpiece. Technical data Drilling capacity: Maximum 32 mm in steel. Tool holder: MK 4 (Morse taper). Speed range: Approx. 41 to 1,800 rpm Quill stroke: 190 mm to 200 mm. Projection: Flexibly adjustable from approx. 240 mm to 850 mm Table size: 1,200 x 600 mm Typical functions Tapping device: Integrated automatic for cutting threads (e.g. up to M26 in steel). Feeds: Automatic quill feed in several stages Coolant device: Integrated pump and coolant trough directly on the work table. "Everything from a single source: We will be happy to offer you suitable bank f ...
used
bore capacity in steel (diameter): 32 mm arm length: 1230 mm table surface area: 1200 x 500 mm bore stroke: 180 mm feed - independent: 0,10 - 0,15 - 0,20 - 0,30 mm turning speeds: 60 - 1800 U/min taper MK: 4 total power requirement: 2,7 kW weight of the machine ca.: 1,8 t dimensions of the machine ca.: 2,2 x 1,8 x 2,3 m Quick radial with: - Feed - Thread cutting device The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Code 220406 Description of fast radial MK-4 Brand DONAU Type DR – 32 Machine r. 686 – 3 Year of construction ± 19.. Capacity in steel 60 32 mm Capacity in GG 45 mm Tapping in steel 60 M 26 Thread cutting in GG M 36 Spindle holder 4 MK Projection 900 mm Table 1200 x 600 mm Vertical movement of the boom 400 mm Spindle stroke 190 mm Spindle table min. – max. 80 – 650 mm 18 spindle speeds 31 – 1370 rpm Spindle feeds 0.1 – 0.15 – 0.2 – 0.3 mm/rev Power 1.5 / 2.2 kW – 380 volts Accessories tapping device Dimensions Br. x D x H 1200 x 1600 x 1910 mm Weight 1700 kgs Condition machine is in normal condition
