used DEMAG ergotech 10

screw size:45 mm injection shot weight in Polysterol:149 g/PS closing pressure:100 kN

DEMAG ERGOTECH- EL-EXIS E 1000/420-310 (130) Built: 2003 specifications Screw diameter [mm]: 35 Spray weight [g]: 150 Spray pressure [bar]: 1865 Closing force [kN]: 1000 Tie bar distance [mm]: 420x420 Clamping plate size [mm]: 600x600 Tool installation height min. [mm]: 200 control Control: ERGOcontrol Monitor: Yes Control cabinet: Yes Language: Yes other Power [kW]: 46.7 Engine hours [h]: 67455 Dimensions [m]: 4.6x1.5x2.1 Weight [kg]: 6500 - KNIESCHLIESSEINHEIT - CORE TRAIN - EUROMAP - AIR VALVE

warehouse no.: 503174 manufacturer: DEMAG type: ERGOtech 1000-420-310 controller: NC 4 year of construction: 2002 clamping force: 1000 kN distance between tie-bars h x v: 420 x 420 mm size of mould plates h x v: 600 x 600 mm min. mould height: 250 mm max. open daylight: 750 mm opening stroke: 500 mm screw diameter: 35 mm swept volume: 168 ccm injection pressure: 2020 bar equipment included screen text german CEE-socket 16A complact flash drive core pulling hydraulically 1x air valve 1x machine incl. Handling machine incl. water flow regulator machine without material hopper Anti vibration mounts electric interface for handling units according to Euromap 12 Schuko-socket 10A Schuko-socket 10A measures of machine l x w x h: 4.2m x 1.4m x 1.8m total weight: 3700KG technical data robot-system handling type: Linear manufacture: Wittmann controller: W7 ...

Brand DEMAG Type ERGOtech system 1000-200 year of manufacture 1998 Clamping unit clamping force 100 ton opening stroke 500 mm beam dimension (h x v) 420 x 420 mm Installation height min. 250 mm Platen size (h x v) 600 x 600 mm Injection unit Screw diameter 25 mm Injection volume 61 cm³ Injection weight PS 54 gr Injection pressure 2752 bar Dimensions and weights Dimensions LxWxH 4,2 x 1,4 x 2,0 m Machine weight 4200 Kg Additional information & extras Core pull 1 pc.

Brand DEMAG type Ergotech system 100/500-430 year of manufacture 2006 Clamping unit clamping force 100 ton opening stroke 500 mm Beam dimension (h x v) 400 x 420 mm Installation height min. 200 mm Installation height max. 800 mm Platen size (h x v) 600 x 600 mm Injection unit Screw diameter 35 mm Injection volume 168 cm³ Injection weight PS 149 gr Injection pressure 2400 bar Dimensions and weights Dimensions LxWxH 5,2 x 1,6 x 2,1 m Machine weight 5700 kg Robot Brand Wittmann type W602 year of construction 2006

Molding machine of Mag Type: Ergotech 100-430, El Exis control: NC 4 year of construction: 2000 Clamping unit Clamping force t 100 Gap mm: 445 Holm dimension mm: min/max height of 420 x 420 mm: 460 / 560 Plate size: 690 x 660 injection unit Screw diameter mm: Gr 40 injection weight: 210 Injection volume cm m³: 231 Spray pressure bar: 1855 Dimensions and weights Dimensions Lxwxh m: 5 x 1.6 x 2 machine weight kg: 6900 Miscellaneous 1 Core pull of armored snail

Molding machine of Mag Type: Ergotech 100-310 compact control: NC 4 year of construction: 1997 Clamping unit Clamping force t 100 Gap mm: 500 Holm dimension mm: 420 x 420 min/max height mm: 250 Plate size: 590 x 590 Injection unit Screw diameter mm: 35 Injection weight gr: 149 Injection volume cm m³: 168.3 Spray pressure bar: 2640 Dimensions and weights Dimensions Lxwxh m: 4.4 x 1.4 x 1.8 machine weight kg: 4400 Miscellaneous EUROMAP 12,Pneumatikventil

Molding machine of Mag Type: Ergotech 100-400 Viva control: NC 4 year of construction: 1998 Clamping unit Clamping force t 100 Gap mm: 500 Holm dimension mm: 400 x 400 min/max height mm: 250 /. Plate size: 580 x 580 Injection unit Screw diameter mm: Gr 40 injection weight: 205 Injection volume cm m³: 231.1 Spray pressure bar: 1828 Dimensions and weights Dimensions Lxwxh m: 4.25 x 1.27 x 1.79

Molding machine of Mag Type: Ergotech 100-430 system control: NC 4 year of construction: 1999 Clamping unit Clamping force t 100 gap mm: 500 Holm dimension mm: 400 x 400 min/max height mm: 250 / 750 Plate size: 590 x 590 injection unit Screw diameter mm: Gr 40 injection weight: 205 Injection volume cm 3: 231 spray pressure bar: 2020 Dimensions and weights Dimensions Lxwxh m: 4.4 x 1.4 x 1.8 machine weight kg: 4400 Miscellaneous EUROMAP pull 12, 1 core

Key data: 1000 , 205 , 40

Manufacturer: Demag Type: 100/420 - 430 concept Built: 2004 Control: NC 4 Control Type of closure: Hydraulish Closing force: 1000 kN Tie bar ratio: 420 mm x 420 mm Plate size: 590 mm x 600 mm WZ Installation height: 250 mm Opening distance: 500 mm Plate spacing max: 750 mm Screw: 40 mm Lifting volume: 231 cc / 205 gram PS Spray pressure: 2020 bar General Engine: 18.5 kW Heater: 11.1 kW Dimensions: 4.9 m x 1.6 m x 2.1 m Weight: 4800 kg Screen text: German Optional extras Core train: x1 Air valve: x1 Robot interface

clamping force: 1.000 kN injection volume: 203 cm³ screw diameter: 40 mm platen size: 580 x 652 mm Condition: used, Specification: Horizontal 2K-injection moulding machine, injection unit 1: - Screw diameter: 40 mm - injection volume: 230 cm³ - weight: 205 g Clamping unit: - Clamping force: 1000 kN - Centring: 125 mm - Platen size: 580 x 652 mm - Mould size: 400 x 400 mm - Mould thickness min.: 250 mm - Mould thickness max.: 450 mm - 1x core pull - Voltage: 3x 400V, 50Hz, N, PE - Total power: 25 kW - Dimensions L/W/H: approx. 4,350 x 1,400 x 1,900 mm - Weight approx.: 4,750 kg Further DEMAG plastic injection moulding machines and a conveyor control/material station for 4 to 56 separators for granulate conveying on our homepage. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Ref. no.: 17516 Hersteller: DEMAG Year of construction: 1998 Clamping unit Clamping force: 100 ton Opening stroke: 500 mm Distance between tie bars: 420 x 420 mm Mould height min.: 250 mm Platen size (h x v): 600 x 600 mm Injection unit Screw diameter: 25 mm Injection volume: 61 cm³ Shot weight: 54 g Injection pressure: 2752 bar Measurements and weight Dimensions: 4,2 x 1,4 x 2,0 m Machine weight: 4200 kg Additional information & extras Core pull: 1 pcs

INJECTION UNIT Screw diameter: 40 mm Calculated injection volume: 231 cm³ Length / diameter ratio: 20 L / D Pressure on the material: 2020 bars CLOSING UNIT Closing force: 1000 kN Passage between columns: 460 x 460 mm Tray size: 580 x 470 mm GENERAL Heat output: 22 kW Total installed power: 31 kW Quantity of oil: 250 l.

Operational pressure: 210bar, weight: 4t, with documentation, without accessories.

Injection weight: 150 g Closing force of 1000 kN Screw diameter: 35 mm Injection pressure: 1865 bar Column spacing: 420 x 420 mm Plate size: 600 x 600 mm Min. mold height: 200 mm Control type: ERGOcontrol Language German Installed power: 46.7 kw Operating hours: 67455 h Weight: 6500 kg Dimensions: 4.6 x 1.5 m Core pull Yes Robot socket Yes Air valve Yes Heating control for molds Yes Elbow closing unit Yes

The machine has a Demag DR631-0399 robot built into it. Machine with CE standards. Type of material used: PC/ABS Service History: 3.2018 - Calibration - Ergocheck 1.2016 — Replacement of a faulty hydraulic system pressure sensor. scheme 1.2015 – repair of the nozzle rod. units 2.2014 — Replacement of the chamber, auger and tip 1.2013 — Replacement of the screw and tip 6.2012 – Repair, re-sealing of the injection cylinder. units 11.2010 — Repair of proportional valve 4.2008 — Replacing the control panel display 3.2008 — Replacing the proportional valve 3.2008 — Calibration — Ergocheck 12.2007 — Replacing the tip

screw size:30 mm injection shot weight in Polysterol:100 g clamping force:600 kN screw size:30 mm max. swept volumne:106 cm³ injection shot weight in Polysterol:100 g/PS injection pressure:2.750 bar closing pressure:60 t tie bar distance:370 x 370 mm mould hight - min.:160 mm opening stroke:350 mm microprocessor control:NC4 screen text:deutsch Manual:deutsch robot interface:Euromap 12 core pull:1 x without hopper / without water distributor:-/- pump drive power:5,5 kW total connection power:45,0 kW total weight:5.000 kg :4,6 x 1,5 x 2,0 m Electric dosing: 15 kW Electric clamping: 9,8 kW Payment: 100% prior to delivery

Clamping unit Clamping force350 ton Opening stroke675 mm Distance between tie bars630 x 630 mm Mould height min.330 mm Mould height max.710 mm Platen size (h x v)950 x950 mm Injection unit Screw diameter70 mm Injection volume1212 cm³ Shot weight1090 g Injection pressure1877 bar Measurements and weight Dimensions6,5 x 1,9 x 2,2 m Machine weight 16000 kg this extra information is standard for this model. Please always double-check the details during a visit The DEMAG Ergotech System 3500-2300 NC4 Injection Molding Machine, introduced in 2002, exemplifies precision and efficiency in plastic molding technology. Renowned for its advanced features and superior performance, this model has become a cornerstone in the injection molding industry. At its core, the Ergotech System 3500-2300 NC4 excels in injection molding operations with unparalleled accuracy and speed. ...

Demag Ergotech 160/520-600 Santosh and Demag Ergotech 120-320 System Injection Moulding Machine Prefer to sell both together Price for both machines

This used DEMAG Ergotech System 1500-440/120 injection moulding machine was manufactured in 1999, equipped with handling features for enhanced productivity and ease of use. As an injection moulding machine, it offers reliable performance and precision in moulding operations, making it a valuable asset for production lines requiring high-quality plastic components. The opportunity to buy this DEMAG Ergotech System 1500-440/120 injection moulding machine represents a strategic investment for businesses looking to upgrade or expand their manufacturing capabilities. For more details, please contact us.

Demag Ergotech Viva 800-400 (144) Description without funnel General Information SKU: 144 Availability: In stock Year of construction: 2001 Brand: Demag Specifications Injection weight: 205 g Clamping force: 800 kN Screw diameter: 40 mm Spray pressure: 1830 bar Tie bar spacing: 400 x 400 mm Clamping plate size: 590 x 580 mm Tool installation height min.: 250 mm Control: NC4 Language: German Power: 26.1 kW Operating hours: 70180 h Weight: 3600 kg Dimensions: 4.35 x 1.7 m Funnel: No Core train: Yes

clamping force: 6500 kN injection volume: 2011 / 323 cm³ screw diameter: 80 / 45 mm platen size: 1450 x 1350 mm Condition: used, Specification: Horizontal 2K-injection moulding machine, DEMAG ergotech 650-5200-610 incl. handling injection unit 1: - Screw diameter: 80 mm - injection volume: 2.011 cm³ - weight: 1810 g injection unit 2: - Screw diameter: 45 mm - injection volume: 323 cm³ - weight: 290 g Clamping unit: - Clamping force: 6500 kN - Centring: 200 mm - Platen size: 1450 x 1350 mm - Mould size: 1000 x 910 mm - Mould thickness min.: 450 mm - Mould thickness max.: 950 mm - 2x core pull - Handling: Yes - Voltage: 3x 400V, 50Hz, N, PE - Total power: 245 kW - Dimensions L/W/H: approx. 10,100 x 5,500 x 5,000 mm - Weight approx.: 36,000 kg Further DEMAG plastic injection mould ...

Key data: 500 kN

Demag Ergotech Compact 500-200 / Machine in very good technical condition Year of construction: 1997 Injection unit: Screw diameter: 30 mm Spray weight: 94 g Injection pressure: 1990 bar Dosing volume: 106 ccm Clamping unit : Clamping force: 50 t Tie bar spacing: 355x355 mm Size of clamping plates: 520x520 mm Ejector: hydraulic Clamping unit: hydraulic Control: NC4 Additional equipment: Hydraulic core pull x 1 Injection unit hardened - Bimetal Original Demag tool crane: chain, electrically controlled, 2 lifting speeds Metrics: Weight: 3100 kg Length/Width/Height: 3.60x1.40x1.80 m Drive: Pumps/motor: 15 kW Heating capacity: 7.5 kW Total power: 22.5 kW All offered machines are started by our service technicians before they are sold. It is possible to receive a video of the technical tests of the selected machine or to participate in live technical te ...

Key data: 250 kN

Demag Ergotech Compact 250-80 Year of construction: 1995 Injection unit: Screw diameter: 18 mm Injection weight: 20 g Injection pressure: 2400 bar Dosing volume: 22.8 ccm Clamping unit: Clamping force: 25 t Tie bar spacing: 280x280 mm Size of clamping plates: 410x410 mm Ejector: hydraulic Clamping unit: hydraulic Control: NC4 Additional equipment: Air valve x 2 Hydraulic core pull x 1 Injection unit hardened - Bimetal Original Demag tool crane: chain, electrically controlled, 2 lifting speeds Metrics: Weight: 2600 kg Length/Width/Height: 3.20x1.30x1.80 m Drive: Pumps/motor: 7.5 kW Heating capacity: 3.7 kW Total power: 11.2 kW All offered machines are started by our service technicians before they are sold. It is possible to receive a video of the technical tests of the selected machine or to participate in live technical tests at our company in � ...

This DEMAG Ergotech 150-610 Compact Injection Moulding Machine was built in the year 1998 and has 13860 pump hours. It is equipped with a Demag NC IV control unit. The machine has a clamping force of 1650 kN and a screw diameter of 40 mm.
