used DECKEL fp4

This DECKEL FP4 60 Milling machine was manufactured in the year 1994 in Germany.

DECKEL FP4 NC Fraesmaschine Dialog 4 Dialog 4 control, working range 560 x 500 x 450 mm, pinole stroke 80 mm, 18 spindle speeds 31.5 -6300 min, folding head, tool holder SK 40, feed speed 1-4000 mm/min, rapid traw 6000 mm/min, table load 800 kg, weight 2070 kg, total connection value 16 kVA.

!!! Needed! FP 4NC SK40 / dialog 4 contouring Control: CNC dialogue 4 - 3D contouring speed: 25-3150 RPM Feed: 1-3600 mm / min stepless Rapid traverse rate: 4 m / min Drive performance: 2,0 / 4,0 kW 1430 / 2830 RPM Travel: X/Y/Z 560/450/450 mm Angle table: Solid angle table 530 x 900 mm of maximum capacity 450 kg Version: Vertical & horizontal spindle; Vertical Quill 80 mm extendable Splash Guard cabin; Milling head manually swiveling options: machine light / E Handwheel / NC rotary table / dividing head, etc.

Spänewanne gebr. for lid FP4NC Newly painted Size (LxWxH): 120cm x 73cm x 32cm

Model: DECKEL FP 4 CCT with CNC control dialog 11 Condition: Used Technical data: Total power requirement: 7.5 kW Vertical / Horizontal CNC - Machining Center with Tool changer and with angular table Working range: Table longitudinal stroke X-axis 600 mm Table Vertical stroke Z-axis 500 mm Milling head cross stroke Y-axis 500 mm Clamping surface of the angular table 530 x 900 mm Table load approx. 450 kg Distance table ? V-spindle min / max. 120-620 mm Distance table ? H-spindle min/max. 156-656 mm Tool holder SK 40 Spindle speeds 0 - 6,300 rpm Pre-pane X / Y / Z-axis max. 2 - 8,000 mm/min Rapid response Y / X / Z-axis 10,000 mm/min Spindle drive power 8 kW Total drive approx. 15 kW - 400 V - 50 Hz Weight approx. 5,500 kg

!!! Used!!! FP 4MK SK40 / with 3- axles - ACTIVE - digital display Heidenhain Control: Digital display Heidenhain T NC111 Speed: 50 - 25000 rpm Feed: 8 - 630 mm/min continuous Rapid speed: 3 m/min Drive power: 6 kW 2830 rpm Travel: X/Y/Z 500/400/400 mm Angular table: Rigid angular table 700 x 400mm max load 450 kg Design: Vertical & horizontal spindle; Vertical pinole 80mm extendable Milling head can be swivelled manually Options: Machine Light

Lid FP4NC !!! Used!!! FP 4NC SK40 / with dialog 11 web control Built: 1991 Control: CNC Dialog 11- 3D web control Speed: 31 - 5000rpm Feed: 1 - 6000 mm/min infinitely variable Rapid speed: 6 m/min Drive power: 7.5 kW 1430/2830 rpm Travel: X/Y/Z 560/500/450 mm Angular table: Rigid angle table 530 x 900mm max. load 450 kg Design: Vertical & Horizontal Spindle; Vertical pinole 80mm extendable Milling head can be swivelled manually Options: Splash guard cabin/ machine light / E-handwheel / Universal round table / NC round table / sub-machine.

Milling machine lid FP 4 NC Built c. 1992 with controlled C-axis 2 pieces of screw sticks Various tool holders Machine is in top condition and was last serviced on 20.08.2020 for approx. 3.000,- € (net). documents available. The machine is sold only because of space requirements. Location of the machine: 76661 Philippsburg

Controls: DECKEL DIALOG 11.

Rapid traverse: 3000mm/min, connected load: 12.5kVA, length: 2300mm, width: 2500mm, weight: 1.83t, the display is defective and the z-axis needs overhauling.

X-travel: 560mm, y-travel: 500mm, z-travel: 390mm, table dimensions: 900x530mm, rotational speed: 4000/min, tool changer: SK 40, controls: DECKEL DIALOG 11, with documentation, the tool changer is defective and needs overhauling.

Controls: Deckel Dialog 11.

X-travel: 485mm, y-travel: 385mm, z-travel: 380mm, max. rotational speed: 3150/min, controls: DECKEL CONTOUR 2, with documentation, the machine has already been in storage for 18 months.

Controls: Deckel DIALOG 11E, tools are available, number of operational hours unknown, was maintained regularly, an inspection is possible.

X-travel: 560mm, y-travel: 500, z-travel: 450mm, rotational speed: 40-4000/min, connected load: 16.5VA, control: Contour 3, weight: 2.7t +295kg control cabinet, spindle y-axis defective, fourth axis defective, on-site inspection is possible.

Control system: Contour 2 lid, the machine has no operating hours counter, the control system parameters must be reloaded onto the machine, the buffer battery is empty, an on-site inspection is possible.

x-travel: 700 mm y-travel: 400 mm z-travel: 450 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m 3-axis digital read out horizontal and vertical milling spindle quill Technische Daten / technical details: Längsweg X / X-travel longitudinal 700 mm Querweg Y / Y-travel cross 400 mm Senkrechtweg Z / Z-travel vertical 450 mm Tischgröße / table size 1000x470 mm Spindelaufnahme / spindle taper SK40 Drehzahlbereich / spindle speed 31,5-1600 UpM /rpm Vorschubbereich X und Y-Achse / feed range X and Y axis 10-500 mm/min. Vorschubbereich Z-Achse / infeed Z-axis 5-250 mm/min Antriebsleistung/ power capacity 5 kW Gewicht der Maschine / weight 2400 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding. The data for this ad was cre ...

Lid FP4A Id No. 2284-0242 CNC 2301 control x 560 y 500 Z 450 Weight 2.2 t Hydraulic Data Machine has a malfunction in the startup procedure !!!!!

x-travel: 500 mm y-travel: 400 mm z-travel: 400 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m 3-axis digital read out horizontal and vertical milling spindle quill Technische Daten / technical details: Längsweg X / X-travel longitudinal 500 mm Querweg Y / Y-travel cross 400 mm Senkrechtweg Z / Z-travel vertical 400 mm Tischgröße / table size 800x460 mm Spindelaufnahme / spindle taper SK40 Drehzahlbereich / spindle speed 50-2500 UpM /rpm Vorschubbereich / feed range 8-630 mm/min. Antriebsleistung Frässpindel / power capacity milling spindle 4,4 kW Gewicht der Maschine / weight 1500 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding. The data for this ad was created with ModulMWS - the software solution of LogoTec ...

x-travel: 500 mm y-travel: 400 mm z-travel: 400 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m 3-axes digital read out horizontal and vertical milling spindle quill Technische Daten / technical details: Längsweg X / X-travel longitudinal 500 mm Querweg Y / Y-travel cross 400 mm Senkrechtweg Z / Z-travel vertical 400 mm Tischgröße / table size 800x460 mm Spindelaufnahme / spindle taper SK40 Drehzahlbereich / spindle speed 50-2500 UpM /rpm Vorschubbereich / feed range 8-630 mm/min. Antriebsleistung Frässpindel / power capacity milling spindle 4,4 kW Gewicht der Maschine / weight 1500 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich - Technical data, accessories and description of the machine are not binding. The data for this ad was created with ModulMWS - the software solution of LogoTec ...

Lid milling machine FP4MA-2204 Year of construction: 1987 Serial no.: 20965 Controls: Contour 2 Condition: fully functional

Deckel FP3 A Milling Machine Dialog 11 Year of construction 1990, Dialog 11 control, working range 400 x 400 x 450 mm, quill stroke 80 mm, spindle speeds 4000 min, tool holder SK 40, feed rate 2 - 6000 mm/min, working range 400 x 405 x 400 mm, angle table, weight approx. 2000 kg, dimensions without control panel 1700 x 2100 x 2000 mm. Accessories: Universal tilt and swivel table Electronic handwheel, Coolant equipment Manuals Very good technical condition. Unfortunately, the machine was poorly painted over. A viewing under power is possible by appointment. If you have any questions, please feel free to contact us by phone at any time! You can find information on this under Legal information of the seller. Thank you very much.

with digital read-out: Activ make: HEIDENHAIN for axes: 3 x-travel: 500 mm y-travel: 400 mm z-travel: 400 mm horizontal milling head:: tool taper: ISO 40 vertical head:: tool taper: ISO 40 vertical movement of the milling spindle: 90 mm spindle turning speed range: 50-2500 U/min number: 18 feed stepless: 6.3-630 mm/min rapid motion -longitudinal/cross/vertical: 1.3 m/min total power requirement: 3.7/4.4 kW dimensions of the machine ca.: 1.3x2.0x2.0 m weight of the machine ca.: 1.8 t fixed working table:surface area: 800x460 mm vice: jaw width: 125 mm collet chuck: 1 number of collets: 11 boring chuck: 1 milling arbors: 7 coolant: The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

BRAND: DECKEL YEAR: 1989 MODEL: FP4AT APPLICATION TYPE: MILLING LOCATION: AUSTRIA MACHINE TYPE: MILLING MACHINE AVAILABILITY: IMMEDIATELY Technical Information GENERAL DATA MACHINE WEIGHT: 2895 KG CONTROL UNIT BRAND: DECKEL MODEL: CONTOUR 3 MAIN DRIVE SPINDLE SPEED RANGE: 4000 1/MIN MOVEMENT X-AXIS MOVEMENT: 560 MM Y-AXIS MOVEMENT: 500 MM Z-AXIS MOVEMENT: 450 MM TABLE OUTER LENGTH: 900 MM OUTER WIDTH: 530 MM TOOLS SLOTS IN STORAGE: 20 TYPE OF TOOL HOLDER: SK 40

For sale is our DECKEL FP4NC with universal table Year of construction: 1985 Control Dialog 4 x-travel 485 mm y-travel 385 mm z-travel 380 mm Spindle holder SK 40 Spindle speeds 0 - 3150 rpm Table size 800 x 460 mm Feed rate 10 - 2000 mm/min Machine is connected and can be tested on site. Price VB 5.000 EUR net plus 19% VAT We also have vices that are sold separately Also, some SK40 tools.
