used
Travel X/Y/Z: 630mm/500mm/500mm, max. spindle feed X/Y/Z: 24m/min, max. cutting feed rate: 12m/min. Max. Spindle speed: 8000rpm, table dimensions X/Y: 800mm/500mm. Tool holder: ISO40, tool capacity: 24, max. tool weight: 6kg, max. tool diameter/length: 100mm/300mm, tool change time: 3.6s. Control: Heidenhain TNC 426M, operating hours: 12100h, dimensions X/Y/Z: approx. 2600mm/2400mm/2600mm, weight: approx. 4500kg. Documentation available.
used
Control: Heidenhain TNC 430M, connected load: 30kVA, operating hours: 27,879h, the machine is heavily used, X- and Y-axis need to be overhauled, the motor of the Z-axis is defective, an on-site inspection is possible.
used
Description: Technical details: Control type: CNC, control name: Siemens 810, x-travel 630 mm, y-travel 500 mm, z-travel 500 mm, spindle holder SK 40, table clamping area 800 x 500 mm, table load 500 kg, IKZ spindle speed: 6000 U/ min, total power requirement 30 kW, additional information: Including IKZ - internal spindle cooling, operating hours: 15545.34 h, table without vices: installation height with max. tool length max. 240 mm, distance spindle nose / table (min. 150 mm / max. 65 Approx. Onsite Dimension. (l x w x h): 4,100 x 2,400 x 2,700 mm, weight approx.: 4,500 kg
used
x-travel: 630 mm y-travel: 500 mm z-travel: 500 mm spindle taper: SK 40 table surface area: 800 x 500 mm table load capacity: 500 kg control: Siemens 810 IKZ spindle speed:: 6000 U/min total power requirement: 30 kW weight of the machine ca.: 4,5 t dimensions of the machine ca.: 4,10x2,40x2,7 m Without accessories The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
