RACING Longitudinal travel of the X-axis mast 16,000mm Vertical travel of the Y-axis head 3,000mm Z-axis head transverse travel 1,250mm Cross stroke boring spindle W axis 700mm HEAD DIMENSIONS 410 X 505mm MANDREL Boring spindle diameter 140mm ISO 50 spindle attachment Spindle rotation speed: 5 – 3,000rpm ADVANCES Continuous working axes X, Y, W, Z 0.5 – 6,000mm/min Fast X, Y, Z axes 18,000 mm/min Rapid W axis 10,000mm/min Working thrust 2,000kg ENGINE POWER: Spindle motor in continuous service (S1%) (AC) 42 Kw Axis feed motors (AC) 50 Nm Auxiliary engines 4.5 Kw Machine in excellent condition.
Longitudinal stroke X 11,000 mm Vertical stroke W 3,000 mm Vertical stroke Z 1,000 mm Transverse stroke Y 4,600 mm Work progress 3,000 mm/min Fast forwards 8,000/10,000 Maximum thrust on x-axes 30,000 N Maximum thrust on the Y 20,000 N axes Maximum thrust on Z 20,000 N Spindle engine power 71 kW Constant torque spindle speed range 0-58 g/min Spindle speed range at constant power 58-518 g/min Maximum spindle torque (intermittent service S6) 10,000 Nm Power voltage 400 Vac Power frequency 50 Hz Absorbed current 150 A Total installed power 125(170) kW
working lenght 3.050 mm power 60 ton throat deepth 350 mm CNC cybelec nr.02 axes back gauge manual table compensation
120 ton x 4100mm (3700mm between frames) MODEVA 10 CNC Complete with STARMATIC ROBOT AUTOMATION TOOLING PACKAGE SOFETWARE PACKAGE
sheet width: 2500 mm plate thickness: 3,0 mm distance between columns: 2550 mm true cutting angle adjustable: - back stop - adjustable: max. 510 mm cutting gap adjustment: - mm total power requirement: kW weight of the machine ca.: 1,8 t dimensions: 3,3 x 1,4 x 1,8 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
x-travel: 12000 mm y-travel: 2000 mm z-travel: 1000 mm control: E.C.S. 2351 taper ISO: 50 P.D.B. Table dimensions: 450 x 450 mm spindle speeds: 0 - 1500 mm total power requirement: 35 kW weight of the machine ca.: t dimensions of the machine ca.: m Mist extraction Chip conveyor The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
spindle diameter: 130 mm x-travel: 10000 mm y-travel: 3500 mm z-travel: 1000 mm Control: Heidenhain type: TNC 155 workpiece weight: 300 t turning speeds: 1620 U/min spindle taper ISO: 50 One direction thrust bearing: 2 Angle head: 2 power capacity: 76 kW Plate area: 12000x9600 mm Thickness: 450 mm rotary table:: Colgar type: TRT1500 mm table surface area: 2000x2500 mm Table load: 20000 kg Travel: 2000 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Plate area: 109 m² The floor plate and the table are optional and will be charged extra The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
spindle diameter: 130 mm x-travel: 10000 mm y-travel: 3500 mm z-travel: 1000 mm Control: Heidenhain type: TNC 155 workpiece weight: 300 t turning speeds: 1620 U/min spindle taper ISO: 50 One direction thrust bearing: 2 Angle head: 2 power capacity: 76 kW Plate area: 12000x9000 mm rotary table:: Colgar type: TRT1500 mm table surface area: 2000x2500 mm Table load: 20000 kg Travel: 2000 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Plate area: 109 m² Panel is optional and we charged extra The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
