used ALZMETALL ab

with NC round table WALTER 1000 mm, see pictures

Alzmetall AB4SJ Tool holder MK4 automatic feed with 3 feed speeds 2 shoot stages and infinitely variable speed control right left barrel, thread cutting device Cooling agent device in the foot Round table with holes without rev counter Machine hood modern made of plastic with cracks and loechers Speed: 80-710 rpm Table diameter: 450 mm Max distance from spindle to foot: 1200 mm Extension to center spindle: 170 mm Machine hoe approx. 200 cm Bt323s8 SPECIAL PRICE due to visually poor condition according to photos, technically usable condition, the drill is not locked at the shaft drill spindle tool holder in the rotational motion (see photos). If the drill is not firmly in the drill spindle, it rotates through. Special price

Vertical drilling machine make ALZMETALL type Abomat 40Fabr. -No: 147 A built in 1968Drilling capacity in St / GG: 45/60 mmSpindle mount: MK 5Table size: 500 x 500 mm12 spindle speeds: 35 - 1400 rpm.7 automatic feeds: 0.04 - 0.3 mm / revSpindle head diameter: 62 mmDrilling carriage stroke: 400 mmDischarge: 330 mmMax. Distance table to spindle: 1165 mmMax. Distance base plate to spindle: 1550 mmDrive power: 4 hpDimensions L x W x H: 1350 x 600 x 2250 mmWeight approx. 1200 kgWith- semi-automatic workflow- electr. controlled jump feed- Two-hand releaseused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machine Tools

High performance horizontal boring mill make ALZMETALL type Abomat 30Machine -No: 346, built in 1981revolver drill headNumber of tool holders: 6-foldDrilling capacity: 35 mmDischarge: 330 mmSpindle mount: MK 4Longitudinal table: size 500Adjustment travel: 540 mmRotary tableOperation: manual-hydraulicDiameter: 600 mmfurther techn. Dates:Machining length min / max: 470/1170 mmInsert height of the workpiece: 1223 mmTop height: 235 mmMain motor: 3.2 kWHydraulic motor: 1.5 kWFeed rate: 1.1 kWExternal dimensions: 3000 x 1700 x 2100 mmSpace required incl. Hydraulic and control cabinet approx .: 4000 x 3000 mmWeight approx. 2.5 tonsWith- 6-fold turret GRAS type ARBO 308- Dividing head Fibrotact Y51 400 UN2RA graduation 2; 3; 4; 6; 8; 10; 12; 16; 20; 24; 240smallest partial angle 1.5 °- FIBRO rotary indexing table MY13 800NRA manual-hydraulic, smallest part angle 1 °- Feed FORKARDT F 400- slide ...

Vertical Boring Mill Fabr. ALZMETALL Type ABOMAT 35Machine No: 313 Year 198617155 operating hoursDrilling capacity in steel ST 60: 45 mmDrilling capacity in cast GG 20: 60 mmDrilling capacity steel ST 60: 60 mmThread cutting steel ST 60: M 42Thread cutting Cast GG 20: M 60Long spindle with cross wedge fracture: MK 4Discharge: 330 mmTable mounting surface: 560 x 450 mmBoring stroke: 700 mmRapid traction motor n = 150 min: 1.1 kWFeed motor: 0.25 kW n = 3000 minRapid traverse speed: 4.75 m / minFeed: 0.04 / 0.05 / 0.07 / 0.10 / 0.14Feed size optionally: 0.20 / 0.28 / 0.40 mm / revDrive power: 4.0 kWSpindle speed: 56-2500 rpm.Weight approx .: 1300 kgWith- 6-spindle head ARBO 30No. 139, built in 1989used, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be ...

High performance vertical boring machine make ALZMETALL type Abomat 20Machine -No: 212, built in 1982Drilling capacity in St / GG: 25/30 mmOutreach: 280 mmSpindle mount: MK 38 speeds: 160 - 1800 rpm.6 feeds: 71 - 180 mm / min.Table mounting surface: 400 x 500 mmDrilling carriage stroke: 800 mmRapid traverse speed: 4.5 m / min.Weight approx: 530 kgDrive power: 1.45 / 1.9 kWWith- Multi-spindle head- semi-automatic work process- electrically controlled jump feed- Switch cabinet- swiveling operating part- Central lubrication- Cooling device type B with separate tank with pump- Semi-automatic tapping attachment with guide cartridge- Connection flange for mounting a multi-spindle head- Coolant inlet via distributor with inlet to eachxa0xa0 Spindle of the MSK with 1 cock each- Feed unit for drilling carriage movementused, in good conditionPrice on request.Delivery: ex warehouse or location free ...

High performance vertical boring machine make ALZMETALL type Abomat 20Machine -No: 312 Year 1986Drilling capacity in St / GG: 25/30 mmOutreach: 280 mmSpindle mount: MK 38 speeds: 160 - 1800 rpm.6 feeds: 71 - 180 mm / min.Table mounting surface: 400 x 500 mmDrilling carriage stroke: 800 mmRapid traverse speed: 4.5 m / min.Weight approx. 530 kgWith- semi-automatic work process- electrically controlled jump feed- Switch cabinet- swiveling operating part- Central lubrication- Coolant device- electr. controlled free-cutting device- semi-automatic threadingxa0xa0 by means of Leit cartridge deviceused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like our offer and are always available for your queries.Best regardsM. WaldeckWAHO Machin ...

High performance vertical boring machine make ALZMETALL type Abomat 20Machine -No: 273, built in 1985Drilling capacity in St / GG: 25/30 mmOutreach: 280 mmSpindle mount: MK 38 speeds: 160 - 1800 rpm.6 feeds: 71 - 180 mm / min.Table mounting surface: 400 x 500 mmDrilling carriage stroke: 800 mmRapid traverse speed: 4.5 m / min.Weight approx: 530 kgDrive power: 1.45 / 1.9 kWWith- Multi-spindle head- Cooling device type B- Semi-automatic tapping attachment with guide cartridge- Connection flange for mounting a multi-spindle headxa0xa0 with distributor and flexible inlet pipes with stopcock- Feed unit for drilling carriage movement- swiveling operating part- Central lubricationused, in good conditionPrice on request.Delivery: ex warehouse or location free loading truck.Payment: net at takeover or by appointment.Technical data are not binding. Errors excepted.We would be pleased, if you like  ...

Column Drilling Machine ALZMETALL AB3 ESB Spindle: CM3 Rotation: 1 range 220 -800 RPM + 1 range 800-2900 RPM Table size: Length 615 mm x Width 470 mm Spindle travel: 160 mm Throat depth: 280 mm Speed adjustment by belt drive Rotative table at 360° Automatic Descent 3 speeds: 0,006 - 0,12 - 0,18 mm/min. Lubricant pump Voltage: 380 V Width: 800 mm Depth: 1300 mm Total height: 1900 mm Weight: approx 800 kg

Drill press, drill press, pillar drill press, pillar drill press, tapping machine, tapping machine -Manufacturer: Alzmetall, column drilling machine type AB3ES -Motor: 0.9/1.3 kW -Speeds: 65 - 1750 rpm, infinitely variable -Table size: 300 x 400 mm, travel 550 mm -Spindle mount: MK3 -Spindle stroke: 165 mm - Projection: 290 mm -Columns Ø: 115 mm -Dimensions: 900/560/H1840 mm -Weight: 336 kg

Drilling machine, pillar drilling machine, pillar drilling machine, pillar drilling machine, tapping machine, thread cutting machine -Manufacturer: Alzmetall, column drill type AB45/S -Motor: 3.3/4.1 kW -Speed speeds: 60 - 1530 rpm, continuously variable -Feed: 0.15/0.2/0.3/0.36 1/rev. -Table size: 450 x 600 mm, travel 640 mm -Spindle mount: MK4 -Spindle stroke: 180 mm -Throat: 350 mm -Columns Ø: 200 mm -Dimensions: 1050/720/H2000 mm -Weight: 728kg

Key data: 800 mm

Alzmetall ABHST MK 5 Masch.Nr. 246

Key data: 30 mm, 300 mm, 120 mm

Used Column Drilling Machine Int. Art. Ref. m3530 Manufacturer: Alzmetall Type AB3/ES Projection 300 mm Weight approx. 400 kg Total height approx. 1.80 m Speeds 80 - 1,400 rpm. Recording MK 3 Drill chuck 1 - 13 mm max. drilling depth 120 mm New quill spring installed Location: 59425 Unna The machine can be viewed under electricity. A forklift for loading is available. We reserve the right to sell in advance. It is possible to expertly inspect the items for sale on site. Specific questions should be clarified in advance. The information, such as technical data, dimensions, year of construction, condition are non-binding and have been shown to the best of our knowledge and belief. Errors are therefore reserved. The warranty/guarantee is excluded. The goods are sold from the location / warehouse, with the transfer of risk to the buyer there, this also applies ...

Drill, pillar drill, column drill, column drill -Manufacturer: Alzmetall, pillar drilling machine type AB5/S -Engine: VKS 3 kW -Speed: 40 - 800 rpm, continuously variable right-left rotation -Feed: 0.1 - 0.14 - 0.2 - 0.28 - 0.4 mm/rev. -Table size: Ø 500 mm, travel 470 mm -Spindle holder: MK5 -Spindle stroke: 240 mm -Projection: 380 mm -Column Ø: 220 mm -Dimensions: 1450/680/H2160 mm -Weight: 1262 kg

see side sheet below, with 2-spindle drill head Franz X. LINDNER SBS-2/2, spindle distance 300 mm, (translation 1:1)

Morse cone MK 3 Drilling performance: Steel 28 mm Casting 32 mm Ihivikt Extension 700mm 3 Pre-shed0.1 - 0.2 - 0.3 mm/U 15 Spindle speeds 50 - 1220 rpm Spindle stroke 165mm max. distance spindle - base plate 1300 mm max distance spindle clamping block approx. 800mm Dimensions clamping cube 470mm*550mm*500mm high Clamping area foot 870*700mm Hoe adjustment boom approx. 620 mm Spindle motor 1.1 / 1.7 kW Lifting motor 0.55 kW Outside mass: Length 1400 mm; width 700 mm; height 2300 mm Weight approx. 1100 kg

bore capacity in steel (diameter): 65 mm throat: 390 mm bore stroke: 250 mm spindle taper MT: 5 table-size: 880x670 mm spindle turning speed - stepless: 40-800 U/min weight of the machine ca.: 1.2 t www.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

number of spindles: 3 bore capacity in steel (diameter): 40 mm bore stroke: 180 mm weight of the machine ca.: 2,3 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Specifications: - Drilling capacity in steel ST 60 28 mm - Drilling capacity in steel ST 60 32 mm - Drilling spindle holder MK 3 long spindle - Drilling spindle stroke 180 mm - Drilling spindle speeds infinitely variable approx. 140 - 1600 rpm - 3 feeds 0.1 ; 0,2 ; 0.3 mm/U - Projection 290 mm - max distance table - drilling spindle 620 mm - Rotary table with 2 T-slots 450 mm - Height adjustable via rack and pinion with hand crank - Coolant device - Drive 380 V / 0.9 / 1.3 kW - Space requirement approx. W 750 x H 1900 x D 700 mm - Weight approx. 280 kg

Specifications: - Drilling capacity in steel ST 60 28 mm - Drilling capacity in steel ST 60 32 mm - Drilling spindle holder MK 3 long spindle - Drilling spindle stroke 180 mm - Drilling spindle speeds infinitely variable approx. 140 - 1600 rpm - 3 feeds 0.1 ; 0,2 ; 0.3 mm/U - Projection 290 mm - max distance table - drilling spindle 620 mm - Rotary table with 2 T-slots 450 mm - Height adjustable via rack and pinion with hand crank - Coolant device - Drive 380 V / 0.9 / 1.3 kW - Space requirement approx. W 750 x H 1900 x D 700 mm - Weight approx. 280 kg

Specifications: - Drilling capacity in steel ST 60 28 mm - Drilling capacity in steel ST 60 32 mm - Drilling spindle holder MK 3 long spindle - Drilling spindle stroke 180 mm - Drilling spindle speeds infinitely variable approx. 140 - 1600 rpm - 3 feeds 0.1 ; 0,2 ; 0.3 mm/U - Projection 290 mm - max distance table - drilling spindle 620 mm - Rotary table with 2 T-slots 450 mm - Height adjustable via rack and pinion with hand crank - Coolant device - Drive 380 V / 0.9 / 1.3 kW - Space requirement approx. W 750 x H 1900 x D 700 mm - Weight approx. 280 kg

weight: 1,4 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Drill press, drill press, stand drill, pillar drill -Table size: 400 mm -spindle taper: MK4 -Projection: 320 mm -Speeds: 80-700 rpm -Columns: Ø 160 mm -Spindle stroke: 175 mm -VIP transmission -Feed: 0.09-0.28 mm/rev -Tachometer: defective -Dimensions: 1100/500/H1960 mm -Weight: 650 kg

bore diameter: 65 mm throat: 380 mm Control: PLC-Steuerung bore spindle turning speed range: 63 - 1600 U/min table-size: 630 x 500 mm rapid traverse Z-axis: 4,75 m/min boring feeds:: 0,05 - 0,56 mm/U total power requirement: 9 kW weight of the machine ca.: 2,0 t dimensions of the machine ca.: 1,50 x 1,20 x 2,95 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
