ABA ff used machines

Code 61063 Description Surface grinding machine Make ABA Model FFU 2000/60 Serial No. 208 125 Control Abamatic 3 Year 1986 Tablesize 2510 x 500 mm Grinding surface L x B x H 2000 x 600 x 700 mm Magnetical plate size L x B 2000 x 500 mm Speed table movement 3 – 30 m/min. Max. distance table – centre grinding wheel 900 mm Grinding stone dim. Stone x Wide x Taper Ø 400 x 50 x Ø 127 mm Spindel power 26 kW Spindel speed 1600 - 3000 rpm Motor power 26 kW – 380 Volt Total electr.com. 34 kW Total space L x W x H 7000 x 3500 x 2650 mm Weight 10500 kgs Accessoiries Elec. Magneticplate 2000 x 500 mm Coolant with paperfilter Digital readout Grinding stones, etc. Condition Machine is in good condition

Surface Grinding Machine ABA FFV 1000/50 Travel X: 1000 mm Travel Y: 500 mm Travel Z: 400 mm Magnetic chuck dimensions: 1000 x 400 mm Auto stepover X / Y / Z Separate electrical panel Separate lubricant tank Separate hydraulic group Voltage: 380 V Length: 4000 mm Depth: 1700 mm Total height: 2300 mm Weight: approx 6 T

Surface Grinding Machine Aba FF450/30 BJ 1980

Surface Grinding Machine Aba FFK High-quality, hand-operated surface grinding machine Magnet size: 250 x 150 mm Dressing device on top of the spindle Maximum stroke in X direction: 390 mm Maximum stroke in Y-direction 180mm Height from magnet to spindle center: 395 mm Large Vernier Rings Includes 5 flanges with grinding wheels Dot diamond for magnet A dust extraction system is also available.

Surface grinder, grinding machine, horizontal surface grinder, surface grinder, magnetic grinder -Manufacturer: aba Abawerk, surface grinding machine-horizontal type FFK with magnetic plate -Magnetic plate: 360 x 122 mm -Traverse paths: x 390 mm / y 170 mm / z 260 mm -Drive: 2.0 kW -Grinding wheel: Ø170 mm, max. 245 mm -Coolant device -Transport dimensions: 1120/1100/H1630 mm -Total weight: 604 kg

grinding length:600 mm grinding width:300 mm total power requirement:7,5 kW number of spindle speeds:0-3000 grinding wheel motor:7,5 kW grinding wheel diameter:300 mm dimensions of grinding wheel:76 x 20 mm ABA magnetic table flat grinding machine

grinding length: 1000 mm grinding width: 500 mm workpiece height: 630 mm table-size: 1000x400 mm grinding wheel diameter: 400 mm weight of the machine ca.: 5.8 t Magnetic plate 1000x500mm www.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Grinding area: 600 x 400 mm Magnetic table Coolant tank various grinding wheels

grinding length: 1000 mm grinding width: 750 mm workpiece height: 700 mm Control: SIEMENS, SIMATIC S 7-1500 table surface area: 1050 x 640 mm table height over floor: 1000 mm table speeds: 3.000 - 30.000 mm/min cross feed of table continual: 5 - 5.000 mm/min cross feed of table intermittent: 0,1 - 65,0 mm vertical adjustment, 1 graduation: 0,002 mm rapid traverse vertical: 0,25 m/min grinding spindle speed: 50 - 2.500 U/min grinding wheel size: ø 400 x 50 x ø 127 mm workpiece weight: max. 1.000 kg table load: max. 1600 kg total power requirement: 33,2 kW weight of the machine ca.: 9,3 t dimensions of machine L x W x H: 4,50 x 2,37 x 2,65 m - complete electronic / electric renewed in 2018 Accessories: magnetic plate 1000 x 650 mm, grinding wheel with flange, wheel trueing attachment, extraction The data for this ad was created with ModulMWS - the software solution of Log ...

x-travel: 500 mm : breite 450 mm serial number: 386 weight of the machine ca.: 1,8 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding length: 1250 mm grinding width: 400 mm workpiece height: 550 mm table surface area: 1720 x 400 mm dimensions of grinding wheel: 400 x 50 x 127 mm table height over floor: mm : 1250 x 600 mm grinding spindle speed: 3000 U/min table load capacity: 1100 kp total power requirement: 13,8 kW weight of the machine ca.: 6,0 t dimensions of the machine ca.: 5,0 x 3,4 x 2,4 m Surface grinding machine - Magnetic grinding wheel - Coolant system - Documentation The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding length:1250 mm grinding width:400 mm workpiece height:550 mm workpiece weight:750 kg table-size:1720 x 400 mm magnetic clamping plate:1250 x 400 mm dist. center of grinding spindle - table:750 mm turning speed range - grinding wheel:3000 U/min Length movement of the table:1300 mm grinding wheel size:Ø 400 x 50 x 127 mm switchgear cabinet:inkl. hydraulic power unit:inkl. coolant:inkl. voltage:380 V table load:max. 1100 total power requirement:13,8 kW weight of the machine ca.:6000 kg dimensions of the machine ca.:5000 x 3400 x 2400 mm Documents:inkl.

aba FF 625 Surface grinding machine ABA Precision Surface Grinding Machine FF600/25 Grinding length 600mm Scrap width 250mm Electric Magnet 600x250mm Workpiece height 400mm Diamond puller Height adjustment digital Motor 3,27 KW 400 V 50 HZ Coolant device Grinding wheels and flanges Weight: approx. 1350 kg G&-5020-M1768

ABA Grinding Machine Starline CNC Profile Grinding Machine Surface Grinding Machine Hersteller [manufacturer]: ABA ELB Type [ type]: Starline Control unit: Siemens Sinumerik Incl. handwheel Baujahr[construction year]: 10/2004 Weight [weight]: 6000kg Approx. (W x D x H): 4.1m x 5.1m x 2.5m Full documentation is available. Inspection under power can be done at short notice. We will be happy to answer any further questions you may have. Phone +49 17621834834

This 3-axis ABA ECOLINE 1507 surface grinding machine was manufactured in 2010. It features a maximum grinding length of 1500 mm and a grinding width of 800 mm, with a robust table load capacity of 1500 kg. The machine is equipped with a Siemens SINUMERIK control unit and offers impressive feed speeds of up to 60,000 mm/min for the worktable. If you are looking to get high-quality grinding capabilities, consider the ABA ECOLINE 1507 machine we have for sale. Contact us for further details.

Used Electromagnetic clamping plate , from ABA grinding machine Technical data: Length: 600 mm Width: 300 mm

Franzenschneidemaschine - Fray DIE Cutter ABA G100 Year ca. 1972 - Serial-No. 5515329002 Online-Video-Inspection by Skype-Video We would be very pleased with your visit - more machines on Stock Available Immediately - Can be inspect On Stock Emskirchen / Nürnberg - Can be test

Micrometer screws, micrometer screws, outside micrometers, outside micrometers -Manufacturer: aba, outside micrometer -Measuring range: 0-25 mm -Reading: 0.01 mm -locking device -Number: 2x micrometer available -Price: per piece -other sizes: also available -Case dimensions: 175/90/H30 mm -Weight: 0.6 kg/pc.

2,000 litres process tank, cool/heatable, insulated, propeller agitator sideways probably ABAB

Gr. Grinding length: 620 mm gr. Grinding width: 250 mm table size: 200 x 620 mm grinding wheel dimensions: 200 x 220 x 51 mm Electr. Supply: 380 V, 1/1.8 kW space: 1650 x 1450 x 1800 mm weight: 1350 kg

Length: 600 mm Width: 300 mm

specifications: - Clamping area approx. 400 x 300 mm - Travel across x approx. 500mm - Travel along Y approx. 300mm - 2 Handwheels - Height 220 mm - 4 T - grooves 14 mm - Distance of the T - grooves approx. 72mm - Space required approx. W 1100 x D 900 x H 220 mm - Weight approx. 190 kg

new rear light, incorrectly ordered, from stock

grinding length: 1.000 mm grinding width: 600 mm workpiece height: 400 mm control: SINUMERK 840 D Grinding Area: : grinding range: max. 1.000 x 600 mm travel cross (z-axis): 540 mm distance table surface - grinding spindle centre: max. 600 mm Travel vertical (Y-axis): 500 mm Max. working height on new grinding wheel: 400 mm workpiece table: : Electro permanent magnetic plate: 800 x 500 mm pole pitch: 18 mm clamping force in 8 levels: - Table drive (X-axis): : Incremental encoder in the longitudinal axis X axi: - table speeds: 2-35.000 mm/min Electromechanical longitudinal movement: - by means of digital servo motor,: - toothed belt and ball screw: - Preloaded precision rolling guide size 35: - Central grease lubrication: - Automatic vertical feed (Y-axis): : min. feed size: 0,001 mm measuring system: Galsmaßstab Max. distance spindle centre - table: 700 Grinding head vertical: 550 mm El ...

grinding length: 1.000 mm grinding width: 600 mm workpiece height: 400 mm Control: SINUMERK 840 D Grinding Area: : grinding range: max. 1.000 x 600 mm travel cross (z-axis): 540 mm distance table surface - grinding spindle centre: max. 600 mm Travel vertical (Y-axis): 500 mm Max. working height on new grinding wheel: 400 mm workpiece table: : Electro permanent magnetic plate: 800 x 500 mm pole pitch: 18 mm clamping force in 8 levels: - Table drive (X-axis): : Incremental encoder in the longitudinal axis X axi: - table speeds: 2-35.000 mm/min Electromechanical longitudinal movement: - by means of digital servo motor,: - toothed belt and ball screw: - Preloaded precision rolling guide size 35: - Central grease lubrication: - Automatic vertical feed (Y-axis): : min. feed size: 0,001 mm measuring system: Galsmaßstab Max. distance spindle centre - table: 700 Grinding head vertical: 550 mm El ...
