weingarten presses used for sale

Weingarten Excenter Press

Type / type: N 25 Year of make: 1977 Manufacturer / make: Weingarten Rated pressure: 25 t Number of strokes: 140 / min Radius slide center to frame: 200 mm Window in frame: 240 mm distance table slide: 250 mm Stroke adjustment / adjustment of stroke: 8 ... 80 mm Ram adjustability/adjustment of ram: 50 mm Ram size / surface of ram: 355 x 220 mm Table size / surface of bed: 560x 400 mm Hole in table: 160 mm Power of main motor:3 kW Weight / weight: 2,23 t

Specifications: Capacity 40 tons 2 strokes 57 + 86 H/min Projection 250 mm Plunger stroke 8 - 88 mm Plunger adjustment approx. 63 mm Table , WxD approx. 570 x 450 mm Max. installation height approx. 330 mm

Eccentric press vineyard type AR160 tons With protective shield. YOC 1971 2 rotational speeds via mechanical gearbox Switchable. Central lubrication. Low-wear steep-threaded coupling. Table dimensions : 800x1000 mm Visits : possible at any time. Total weight approx. 10.5 tons

WEINGARTEN DE 200-20 press built in 1975 in Germany is used for precision workpiece machining. The rigid construction combined with a high press force of 200 tonnes make the machine the perfect solution for mass production of various types of parts. The process of precision sheet metal pressing can be fully automated when the WEINGARTEN press is retrofitted with a sheet metal feeder. Technical specifications of the WEINGARTEN DE200-20 200 t press - press force: 200 t - maximum slider stroke: 200 mm - minimum slider stroke: 15 mm - maximum number of slider strokes: 60/min - minimum number of slider strokes: 20/min - slider adjustment: 110 mm

Single column - eccentric press WEINGARTEN type E 40 Masch. No. 643 / 62 Year of construction 1963 Pressure capacity 40 ton. Projection 250 mm Table opening 150 x 80 and Ø 200 mm Table area 560 x 460 mm Plunger area 250 x 200 mm Adjustable ram stroke 8-88 mm Plunger adjustment 63 mm Installation height 320 mm Clamping pin bore Ø 40 mm Stroke rate 100 / 130 strokes / min. Motor power 2.2 / 3 kW Mains connection 400 volts, 50 Hz Table height above floor 840 mm - Clutch-brake combination thanks to WEINGARTEN friction threaded clutch with OT flow protection - Electric stroke release via two-hand operation - Overload protection by crushing plate - Manual grease central lubrication - Front crankshaft support bearing - Control cabinet adjacent - UVV for manual insertion work Space requirements L x W x H 1800 x 1500 x 2200 mm Weight 3.1 ton.

Weingarten AR 63 ton Capacity: 63 ton Max adjustable stroke: 8 > 100 mm Drawning speed: 56/84 str/min Dimension of the table: 620 x 500 mm Dia table hole: 250 mm Punchholder dia: 40 mm Course adjustment: 63 mm Weight: 4 ton

Key data: 80 t, 400 mm, 112 mm

Printing capacity: 80 ton Table surface: 750 x 550 mm Plunger adjustment: 80 mm Stroke length: 8 - 112 mm Stroke rate: 78 p/min. Projection: 400 mm Equipped with: - Air coupling - Safety screen Country of origin: Germany Motor power: Machine LxWxH: 2000 x 1200 x 2900 mm Machine weight approx.: 7000 kg

(1961) 100t Müller-Weingarten Eccentric Press High-Precision Mechanical Press This Müller-Weingarten model is a versatile industrial workhorse featuring a variable stroke and a high-performance 11 kW motor. Designed for heavy-duty applications, it can process material thicknesses up to 12 mm with a consistent operating speed of 55 strokes per minute. Technical Details ‍ Machine Type: Eccentric Press Manufacturer: Müller-Weingarten Model: ER 100 Year of Manufacture: 1961 Nominal Force: 100t Maximum Material Thickness: 12 mm Stroke Rate: 55 strokes/min Ram Stroke (Adjustable): 8 mm – 112 mm Ram Adjustment: 80 mm Shut Height (Die Space): 355 mm – 407 mm Overrun Time (Stopping Time): 0.174 Seconds Safety Distance: 278 mm Motor Power: 11 kW

(1963) 100t Müller-Weingarten Eccentric Press High-Precision Mechanical Press This Müller-Weingarten model is a versatile industrial workhorse featuring a variable stroke and a high-performance 11 kW motor. Designed for heavy-duty applications, it can process material thicknesses up to 12 mm with a consistent operating speed of 55 strokes per minute. Technical Details ‍ Machine Type: Eccentric Press Manufacturer: Müller-Weingarten Model: ER 100 Year of Manufacture: 1963 Nominal Force: 100t Maximum Material Thickness: 12 mm Stroke Rate: 55 strokes/min Ram Stroke (Adjustable): 8 mm – 112 mm Ram Adjustment: 80 mm Shut Height Range (Die Space): 355 mm – 407 mm Overrun Time (Stopping Time): 0.154 Seconds Safety Distance: 246 mm Motor Power: 11 kW

(1970) 200t Müller-Weingarten Eccentric Press Heavy-Duty Eccentric Press for High-Capacity Industrial Forming This powerful 1970 mechanical press is engineered for heavy-gauge metalworking, offering a significant 200-ton pressing capacity and a maximum sheet thickness of 28 mm. Technical Details ‍ Machine Type: Eccentric Press Manufacturer: Müller-Weingarten Model: AR 200 Year of Manufacture: 1970 Nominal Force: 200t Max. Thickness: 28 mm Stroke Rate: 32 strokes/min Ram Stroke: 40 – 180 mm Ram Adjustment: 110 mm

(1984) 100t Müller-Weingarten Eccentric Press High-Speed Single-Column Eccentric Press with Versatile Stroke Adjustment This Müller-Weingarten press is a highly adaptable industrial machine, featuring a 100-ton nominal force and an impressive stroke rate of 60 per minute. Technical Details ‍ Machine Type: Eccentric Press Manufacturer: Müller-Weingarten Model: ARP 100 Year of Manufacture: 1984 Nominal Force: 100t Stroke Rate: 60 strokes/min Throat Depth (Projection): 375 mm Frame Passage (Front to Back): approx. 570 mm Max. Distance (Table to Ram): 384 mm Adjustable Ram Stroke: 8 mm – 137 mm Intermediate Strokes: 8, 23, 43, 63, 81, 97, 111, 122, 130, 135, 137 mm Ram Adjustment: 80 mm Ram Clamping Surface (W x D): 700 mm × 450 mm Ram Shank Hole (Ø x Depth): 50 mm × 85 mm Ejector Travel: 55 mm Table Clamping Surface (W x D): 920 mm × 660 mm Tabl ...

(1979) 100t Müller-Weingarten Eccentric Press High-Utility Eccentric Press for Flexible Stamping and Forming Operations This Müller-Weingarten model is a versatile single-column (C-frame) press designed for high-speed production with a stroke rate of 60 per minute. It features a comprehensive range of 11 adjustable stroke settings, making it highly adaptable for various industrial metalworking tasks from shallow blanking to deeper forming. Technical Details ‍ Machine Type: Eccentric Press Manufacturer: Müller-Weingarten Model: ARP 100‍ Year of Manufacture: 1984‍ Nominal Force: 100t‍ Stroke Rate: 60 strokes/min‍ Throat Depth (Projection): 375 mm‍ Body Passage (Front to Back): approx. 570 mm‍ Max. Distance (Table to Ram): 384 mm (at bottom of stroke, adjustment at top)‍ Adjustable Ram Stroke: 8 mm – 137 mm‍ Intermediate Strokes: 8, 23, 43 ...

(1965) 125t Müller-Weingarten Eccentric Press Heavy-Duty Single-Column Press for Robust Metal Forming This Müller-Weingarten model is a reliable industrial workhorse capable of processing heavy-gauge sheet metal up to 13 mm in thickness. Technical Details ‍ Machine Type: Eccentric Press Manufacturer: Müller-Weingarten Model Type: ER 125 Year of Manufacture: 1965 Nominal Force: 125t Maximum Material Thickness: 13 mm Stroke Rate: 50 strokes/min Ram Stroke (Adjustable): 20 – 120 mm Ram Adjustment: 100 mm Overrun Time (Stopping Time): 0.34 seconds Safety Distance: 500 mm Motor Power: 11.0 kW

see picture in the appendix

pressure: 63 t distance between columns: 0 mm stroke: 160 mm table surface area: 630 x 500 mm dayligth: 400 mm total power requirement: kW weight of the machine ca.: 5 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 63 t throat: 320 mm stroke: 8-100 mm no. of strokes: 120 Hub/min ram - range of adjustment: 63 mm table surface area: 730x600 mm ram surface: 540x360 mm table height: 850 mm tool hole in ram: Ø40 mm weight of the machine ca.: 5,5 t dimensions of the machine ca.: BxTxH 2000x2000x3000 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 100 t throat: 315 mm stroke: 8 - 112 mm table surface area: 725 x 570 mm ram surface: 410 x 315 mm ram adjustment: 80 mm no. of strokes: 55 / 82 Hub/min tool shank hole (depth x diameter): 85 x 50 mm dayligth: 355 mm total power requirement: 7,5 kW weight of the machine ca.: 6 t dimensions of machine L x W x H: 2,00 x 1,00 x 2,87 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 500 t distance between columns: 1600 mm stroke: 60 mm max. ram stroke: 60 1 / min ram adjustment: 100 mm dayligth: 700 mm Table area: 1600x1400 mm ram surface: 1400x1150 mm total power requirement: kW weight of the machine ca.: 40 t dimensions of the machine ca.: m About usmore than 400 machines in the warehouse over 12000 m² storage area, crane capacity 70 tmore than 1000 items accessories for your workshopYou want to sell machines production lines or your company, then talk to us. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 100 t passage width: . mm stroke: . mm tracking travel: 45 mm safety distance: 208 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 100 t throat: 410 mm stroke: 8-112 mm no. of strokes doubel-strokes per min.: 55 / 82 ram - range of adjustment: 80 mm table surface area: 950 x 700 mm ram surface: 700x450 mm hole in the table: Ø 280 mm table height: 850 mm tool hole in ram: Ø 50 mm weight of the machine ca.: 7,0 t dimensions of the machine ca.: 1400x2200x2800 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 80 t throat: 300 mm stroke: 8-112 mm no. of strokes: 60 Hub/min ram adjustment: 80 mm table surface area: 700x550 mm ram surface: 400x300 mm table height: 870 mm hole in the table: Ø 280 mm tool hole in ram: Ø 50 mm weight of the machine ca.: 5,0 t dimensions of the machine ca.: 1500x2000x2700 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 40 t throat: 230 mm stroke: 8-88 mm throat: 230 mm no. of strokes: 130 Hub/min ram - range of adjustment: 63 mm table surface area: 560x450 mm ram surface: 250x200 mm hole in the table: Ø 190 mm table height: 790 mm tool hole in ram: Ø 40 mm weight of the machine ca.: 3,0 t dimensions of the machine ca.: 1000x1800x2500 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 63 t throat: 280 mm stroke: 8-100 mm ram surface: 310x260 mm table surface area: 620x500 mm hole in the table: Ø 250 mm no. of strokes: 56/84 Hub/min ram - range of adjustment: 63 mm weight of the machine ca.: 4,0 t dimensions of the machine ca.: 1200x1900x2800 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 100 t throat: 410 mm stroke: 8-112 mm no. of strokes: 55/82 Hub/min ram - range of adjustment: 80 mm table surface area: 950x700 mm ram surface: 700x450 mm hole in the table: Ø 280 mm table height: 800 mm total power requirement: 11 kW weight of the machine ca.: 7,5 t dimensions of the machine ca.: BxTxH 1600x2200x3000 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 80 t throat: 320 mm stroke: 8-112 mm no. of strokes: 60 Hub/min ram - range of adjustment: 80 mm : 355 mm table surface area: 720x550 mm ram surface: 400x310 mm sheet thickness - max.: 11 mm weight of the machine ca.: 9,5 t Overall size: 2000x2000x2700 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 10 t throat: 170 mm stroke: 6-60 mm no. of strokes: 160 Hub/min ram - range of adjustment: 40 mm table surface area: 420x320 mm ram surface: 180x140 mm hole in the table: Ø 120 mm table height: 850 mm tool hole in ram: Ø 32 mm weight of the machine ca.: 1 t dimensions of the machine ca.: 1200x1200x1900 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 80 t throat: 280 mm stroke: 8-112 mm no. of strokes: 55 / 82 Hub/min ram - range of adjustment: 80 mm table surface area: 800x570 mm ram surface: 560x355 mm hole in the table: Ø 280 mm table height: 800 mm tool hole in ram: Ø 50 mm total power requirement: 7,5 kW weight of the machine ca.: 6 t dimensions of the machine ca.: BxTxH 1600x2200x3000 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 63 t throat: 330 mm stroke: 8-100 mm no. of strokes: 56/84 Hub/min ram - range of adjustment: 63 mm table surface area: 850x600 mm ram surface: 550x360 mm hole in the table: Ø 240 mm table height: 800 mm tool hole in ram: Ø 40 mm weight of the machine ca.: 4,5 t dimensions of the machine ca.: 1300x2000x2700 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 125 t throat: 330 mm stroke: 20-120 mm no. of strokes: 50 Hub/min ram - range of adjustment: 100 mm table surface area: 800x640 mm ram surface: 500x400 mm hole in the table: Ø 330 mm table height: 850 mm tool hole in ram: Ø 50 mm weight of the machine ca.: 8 t dimensions of the machine ca.: 1500x2000x3000 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 63 t throat: 320 mm stroke: 8-100 mm no. of strokes: 120 Hub/min ram - range of adjustment: 63 mm table surface area: 860x620 mm ram surface: 540x360 mm hole in the table: Ø 270 mm table height: 850 mm tool hole in ram: Ø 50 mm weight of the machine ca.: 5,5 t dimensions of the machine ca.: BxTxH 1500x2000x2700 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 100 t throat: 415 mm stroke: 8-140 mm no. of strokes: 48 Hub/min ram - range of adjustment: 80 mm table surface area: 920x670 mm ram surface: 700x450 mm table height: 800 mm tool hole in ram: Ø 50 mm weight of the machine ca.: 8 t dimensions of the machine ca.: BxTxH 1500x2000x2800 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 160 t throat: 340 mm stroke: 20-120 mm no. of strokes: 45 Hub/min ram - range of adjustment: 100 mm table surface area: 800x620 mm ram surface: 500x400 mm hole in the table: Ø 360 mm tool hole in ram: Ø 50 mm weight of the machine ca.: 12 t dimensions of the machine ca.: 2200x2000x3600 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 63 t throat: 280 mm stroke: 8-100 mm no. of strokes: 56/84 Hub/min ram - range of adjustment: 63 mm table surface area: 620x500 mm ram surface: 310x260 mm hole in the table: Ø 250 mm table height: 850 mm tool hole in ram: Ø 40 mm weight of the machine ca.: 4 t dimensions of the machine ca.: 1200x1900x2800 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 160 t no. of strokes: 40 - 120 Hub/min sheet width: mm total power requirement: 40 kW Pressing capacity 160 ton Table clamping area 1,100 x 1,280 mm Ram clamping area 850 x 890 mm Distance between guides 1,120 mm Distance between columns (below guide ways) 1,350 mm Distance between Table and ram in upper position approx. 400 mm No. of strokes 40 - 120 /min Adjustment of stoke 67 / 115 / 160 mm Ram adjustment, motor driven 125 mm Ejector travel 50 mm Total electrical load, approx. 40 kW - 500 V - 50 Hz Weight, approx. 24,000 kg Accessories / Special Features WEINGARTEN Sheet Metal Uncoiler with overhead loop control (space saving because it does not need a loop-pit). Strip width 375 mm. The loop control guides the strip-material from the uncoiler to the machine thru a straightening device with automatic supervision. 8-track slide bearing guide. Automatic oil-circulation lubr ...

Press capacity: 30 ton Throat depth: 160 Ram stroke adjustable: 20 - 45 mm Slide adjustment: 10 / 60 mm Shut height (stroke down, adjustment up): 220 mm Table surface area : 470 x 300 mm Slide area: 250 x 190 mm Number of strokes: 80 - 240 s.p.m. Required power: 4 kW Dimensions L x W x H: 1.400 x 1.800 x 2.000 mm Weight of machine approx.: 2,67 ton

pressure: 63 t throat: 280 mm stroke: 8 - 100 mm no. of strokes: 65 Hub/min ram adjustment: 63 mm table surface area: 620 x 500 mm distance table/ram, max. stroke up, adjustment up: 415 mm hole in the table: 230 mm table height over floor: 800 mm ram surface: 310 x 255 mm power capacity: 5,5 kW total power requirement: kW weight of the machine ca.: 3,95 t dimensions of the machine ca.: 1,20 x 1,80 x 2,40 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 500 t distance between columns: 1220 mm max. ram stroke: 600 mm distance table/ram, max. stroke up, adjustment up: 1000 mm table surface area: 1600 x 1200 mm die-cushion pressure inside the table: 320 t stroke of drawing cushion in table: 150 mm drawing cushion surface in table: 750 x 812 mm die-cushion pressure in pusher: 180 t stroke of drawing cushion in pusher: 100 mm drawing cushion surface in pusher: 750 x 625 mm ram surface: 1600 x 1200 mm table height over floor: 800 mm feed down: 665 mm/sec feed up: 530 mm/sec working feed: 34 - 100 mm/sec quantity of oil: 2000 l power capacity: 180 kW weight: 40 t dimensions of the machine ca.: 3,2 x 2,4 x 7,5 m by using oil-hydraulic drive, hydraulic and electric control UVV, die cushion in bed and slide, adjustable drawing speed, punching limit with damping plunger lock, electric cabinet Our list price is WITHOUT starting the machin ...

pressure: 80 t throat: 280 mm stroke: 8 - 112 mm no. of strokes: 30 - 120 Hub/min distance table/ram, max. stroke up, adjustment up: 500 mm table surface area: 840 x 580 mm hole in the table: 150 mm table height over floor: 910 mm passage to the back: 640 mm ram surface: 560 x 300 mm ram adjustment: 80 mm power capacity: 7,5 kW total power requirement: kW weight of the machine ca.: 6,5 t dimensions of the machine ca.: 1,4 x 2,3 x 3,2 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

ram capacity: 2000 t return capacity: 150 t table-size: 1015 x 1050 mm ram head dimension: 975 x 1050 mm dist. between pillars (left to right): 975 mm dayligth: 1000 mm distance table/ram: 600 - 1000 mm ram stroke: 400 mm table height over floor: 800 mm height over floor: 3650 mm Table ejector: 63 KN Ram ejector: 650 KN Table ejector stroke: 100 mm Ram ejector stroke: 100 mm Lenght of ram slide guiding: 1400 mm : Idle speed downward: 235 mm/s working feed: max. 20 mm/sec Working speed at 10000 KN: 14 mm/s Working speed at 20000 KN: 5 mm/s Idle speed upward: 250 mm/s overtravel time: 220 ms safety distance: 352 mm total power requirement: 194 kW weight of the machine ca.: 105 t dimensions of the machine ca.: ca. 5,00 x 6,50 x 8,00 m Technical data without engagement: sizing press with oil-hydraulic drive, hydr. and electrical control depending on UVV, light barrier (Comp. Sick), ejector ...

pressure: 40 t throat: 240 mm stroke: 8-88 mm no. of strokes: 57/86 Hub/min ram - range of adjustment: 63 mm table surface area: 560x450 mm ram surface: 240x200 mm hole in the table: Ø100 mm table height: 840 mm tool hole in ram: Ø40 mm weight of the machine ca.: 3,5 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 25 t throat: 200 mm stroke: mm pressure: 25 t no. of strokes: 140 Hub/min window in frame: 240 mm adjustment of stroke: 8...80 mm ram - range of adjustment: 50 mm surface of ram: 355 x 220 mm table-size: 560 x 400 mm hole in table: 160 mm total power requirement: 3 kW weight of the machine ca.: 2,23 t dimensions of the machine ca.: m - distance table slide: 250 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 1000 t distance between columns: 5000 mm stroke: 500 mm Height of centres: 400 mm Motor output: kW reus: U/min Overall size: 6000 x 2500 mm Weight: 1000 kg Distance between centres: 3500 mm total power requirement: kW weight of the machine ca.: 220 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 63 t throat: 260 mm stroke: 8-100 mm ram - range of adjustment: 63 mm no. of strokes: 115 Hub/min : 316 mm table surface area: 630x490 mm ram surface: 315x260 mm hole in the table: Ø 140 mm total power requirement: 4 kW weight of the machine ca.: 7,5 t dimensions of the machine ca.: 2000x2000x2700 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 100 t throat: 375 mm stroke: 20-125 mm no. of strokes: 60 Hub/min ram - range of adjustment: 80 mm table surface area: 920x660 mm ram surface: 700x450 mm hole in the table: Ø90 mm tool hole in ram: Ø50 mm weight of the machine ca.: 8 t dimensions of the machine ca.: 2100x1500x3300 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

CONTROLS   conventional PRESS DESIGN   drive system: eccentric / crank   frame design: C-frame, single sided PRESS FORCES   total force (nominal): 100 to SLIDE   slide force: 100 to   stroke rate (max.): 72 /min SLIDE (MECHAN. PRESS)   slide adjustment: 80 mm   stroke adjustment: yes   stroke min.: 8 mm   stroke max.: 112 mm TOOL ASSEMBLY DIMENSIONS   shut height (stroke down, adjustment up), BDC: 407 mm ATTACHMENTS (PRESSES)   2-hand engagement: yes for safe tools only

Pressing force: 3150kN, table dimensions X/Y: 2500mm/1600mm, stroke (fixed): 280mm, stroke rate: 20-80strokes/min, weight: approx. 68000kg. Including Dreher transfer and feed line. The control system is defective. Documentation available. An on-site inspection is possible.

Industrial Metalworking & Welding Equipment Inventory Overview: Offering a collection of heavy-duty vintage and modern industrial machinery. This inventory includes high-capacity press brakes, plate rollers, and specialized Oerlikon welding systems. Bending & Rolling Machines - Plate Bending Roller (35/3150): Wilhelmsburger (1959) - Plate Bending Roller (RMA 2500/8): Chr. Häusler (1963) - Heavy-Duty Press Brake (650t): Scharinghaus (1957) - Heavy-Duty Press Brake (500t K 1/3 M): Scharinghaus (1956) - Heavy-Duty Press Brake (200t): Scharinghaus (1955) - Profile Bending Machine (BO232 K): Hercules (1960) - Ring Bending Machine: Auersbach (Year N/A) - Swivel Bending / Folding Machine: Manufacturer N/A - Small Plate Roller: Manufacturer N/A Cutting, Pressing & Machining - Guillotine Shear (ScTP 25/3150): VEB Pressen- u. Scheren ERFURT (1966) - Small Guillotine Shear: Weingarten (Year N ...

Press force: 100t, stroke rate: 60/min, ram stroke: 8mm-137mm, ram adjustment: 80mm, throat depth: 375mm, table dimensions X/Y/Z: 800mm/630mm, machine dimensions X/Y/Z: approx. 1500mm/2400mm/3500mm, weight: approx. 8800kg. An on-site inspection is possible.

Ram, rams for an eccentric press, single column press, punching machine, single column eccentric press, eccentric press - single column, press -Spare part: comes from a Weingarten eccentric press -Stroke adjustment: 10-80mm -Plunger area: 320 x 65 mm -Plunger mount: O 40 mm -Plunger adjustment thread: M64 x 6 mm -Plunger adjustment ball head: approx. 92 mm -Dimensions: 875/320/H190 mm -Weight: 164 kg -Pressure unknown

CONTROLS   PLC SIEMENS SIMATIC PRESS DESIGN   table cushion: yes PRESS FORCES   total force (nominal): 630 to PRESS TABLE   table surface (left-right): 2500 mm   table surface (front-back): 1300 mm DIE CUSHION (TABLE CUSHION)   cushion force: 250 to   stroke: 400 mm   cushion plate surface (left-right): 2450 mm   cushion plate surface (front-back): 1250 mm

pressure: 16 t throat: 210 mm stroke: 8-68 mm table:: 480 x 380 mm strokes per minute: 150 ram adjustment: 50 mm total power requirement: 3 kW weight of the machine ca.: 2 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 25 t throat: 220 mm stroke: 8 - 80 mm mm total power requirement: 2,2 kW weight of the machine ca.: 2 t dimensions of the machine ca.: 0,9 x 1,5 x 2,0 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width:2000 mm plate thickness:1.8 mm Controls:SIEMENS S7 PRESS DESIGN:. - frame design : H-frame :. - openings in uprights : yes :. - opening in table : yes :. - moving bolster : yes :. PRESS TABLE:. - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - height above floor level:375 mm RAM:. - ram force:800 to - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - stroke:350 mm - number of strokes max:55 /min RAM (MECHAN. PRESS):. - ram adjustment:350 mm TOOL ASSEMBLY DIMENSIONS:. - shut height (stroke down, adjustment up):1100 mm - distance between columns (H-frame):3100 mm - Free passage between side columns (width):2560 mm - Free passage between side columns (height):1500 mm DECOILER:. - design : single coil :. - sheet width max:2000 mm - sheet width (min):400 mm - max. weight of coil:30 to - max. diamet ...

pressure:800 t distance between columns:2900 mm stroke:350 mm Controls:SIEMENS PRESS DESIGN:. - frame design : H-frame :. - Drive type : mechnical :. - openings in uprights : yes :. - number of cushions:0 - opening in table : yes :. - moving bolster : yes :. PRESS FORCES:. - total force (nominal):800 to PRESS TABLE:. - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - rectangular breakthrough (width):2000 mm - rectangular breakthrough (front-back):1800 mm - height above floor level:850 mm RAM:. - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - stroke:350 mm - number of strokes max:55 /min RAM (MECHAN. PRESS):. - ram adjustment:350 mm TOOL ASSEMBLY DIMENSIONS:. - shut height (stroke down, adjustment up):1100 mm - distance between columns (H-frame):2900 mm - Free passage between side columns (width):2560 mm ...

band width:2000 mm plate thickness:1.8 mm number of rolls:13 Controls:SIEMENS DECOILER:. - design : single coil :. - sheet width max:2000 mm - sheet width (min):400 mm - max. weight of coil:30 to - max. diameter of coil:2000 mm - min. internal diameter of coil:610 mm FEEDERS:. - sheet width max:2000 mm - sheet thickness max:2 mm - feeding step max.:4000 mm LEVELER UNIT:. - sheet width max:2000 mm - sheet width (min):400 mm - sheet thickness max:1.8 mm - sheet thickness (min):0.6 mm - number of leveler rolls:13 - diameter of leveler rolls:50 mm

Total force (nominal):800 to Clamping surface (left-right):x mm Clamping surface (front-back):x mm table surface area:3200 X 2200 mm Total force (nominal):2-3-4-5- Presse - 600 to. to table surface area:2-3-4-5- Presse 3100 X1900 mm Last overhaul 2010/2020, consisting of: Circuit board washing system, manufacturer Neuhäuser, with 6 cleaning rollers, system no. 0905200, control unit by Siemens Blank automation, manufacturer Neuhäuser, type 19711594-00-0, year 2002, SN 369507/002, system no. FK42282, consisting of: destacking device, oiler, pallet changer, empty pallet discharge Gripper automation, manufacturer Olofström, type Doppin Loader 2000, SN 37719974886, system no. 0602300 Double-column press, manufacturer Weingarten, type ZS 1200.34 Year 1972, order no. 113 021, pressing force approx. 800 t, double action, stroke 850 mm, stroke adjustment 350 mm, height between table surface an ...

pressure:063 t throat:250 mm stroke:8 - 100 mm no. of strokes:56 / 84 /min distance table/ram, max. stroke up, adjustment up:415 mm table surface area:710 x 500 mm hole in the table:320 mm table height over floor:800 mm passage to the back:320 mm ram surface:450 x 280 mm ram adjustment:63 mm weight:4,1 t dimensions (W x D x H):1,35 x 2,0 x 2,6 m overload protection in ram:mechanical

Pressure:080 t throat:380 mm stroke:8 - 112 mm no. of strokes:60 /min distance table/ram, max. stroke up, adjustment up:472 mm table surface area:840 x 610 mm table height over floor:800 mm passage to the back:520 mm ram surface:650 x 400 mm ram adjustment:70 mm power capacity:7,5 kW weight:6,9 t Dimensions (WxDxH):1,1 x 2,15 x 3,2 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:mechanical ram counterbalance:pneumatic clutch-/ brake combination:pneumatic

Pressure:063 t throat:250 mm stroke:8 - 100 mm no. of strokes:120 /min distance table/ram, max. stroke up, adjustment up:415 mm table surface area:700 x 500 mm hole in the table:250 mm table height over floor:800 mm passage to the back:320 mm ram surface:450 x 280 mm ram adjustment:63 mm weight:4,5 t Dimensions (WxDxH):1,6 x 2,0 x 2,8 m overload protection in ram:mechanical

pressure:160 t distance between columns:1340 mm stroke:300 mm Distance table/ram, max. stroke up, adjustment up:620 mm table surface area:1300 x 900 mm table height over floor:930 mm side window:600 mm ram surface:1300 x 900 mm speed down:367 mm/s speed up:390 mm/s working speed:58 mm/s power requirement:30,0 kW weight:15,0 t Dimensions (WxDxH):2,5 x 2,2 x 4,0 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 foundation pit:not necessary

pressure:500 t distance between columns:2400 mm stroke:400 fix mm no. of strokes:13 - 23 /min Distance table/ram, max. stroke up, adjustment up:1600 mm table surface area:2300 x 1800 mm column travel -side:1600 mm ram surface:2170 x 1800 mm ram adjustment:300 mm total power requirement:110,0 kW Weight:135,0 t Dimensions (WxDxH):3,35 x 4,85 x 7,0 m clutch:pneumatic overload protection in ram:hydraulic ram adjustment:motoric

pressure:080 t throat:360 mm stroke:8 - 112 mm no. of strokes:78 /min distance table/ram, max. stroke up, adjustment up:467 mm table surface area:900 x 650 mm hole in the table:250 mm table height over floor:800 mm passage to the back:330 mm ram surface:650 x 400 mm ram adjustment:80 mm power requirement:11,0 kW dimensions (WxDxH):1,2 x 2,2 x 2,9 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:mechanisch

pressure:160 t throat:360 mm stroke:200 mm distance table/ram, max. stroke up, adjustment up:500 mm table surface area:920 x 700 mm Hole in the table:150 mm table height over floor:960 mm passage to the back:590 mm ram surface:620 x 560 mm speed down:390 mm/s speed up:390 mm/s working speed:58 mm/s power requirement:30,0 kW weight:16,0 t dimensions (WxDxH):1,6 x 2,5 x 3,6 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 depth stop:mechanisch

pressure:080 t throat:300 mm stroke:8 - 112 mm no. of strokes:60 /min distance table/ram, max. stroke up, adjustment up:467 mm table surface area:710 x 560 mm hole in the table:240 x 115 mm table height over floor:800 mm ram surface:400 x 315 mm ram adjustment:80 mm power requirement:7,5 kW weight:5,1 t dimensions (WxDxH):1,4 x 1,9 x 2,7 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:mechanical

pressure:060 t throat:220 mm stroke:6 - 94 mm no. of strokes:115 /min distance table/ram, max. stroke up, adjustment up:340 mm table surface area:680 x 400 mm hole in the table:120 x 70 mm table height over floor:750 mm passage to the back:290 mm ram surface:240 x 240 mm ram adjustment:57 mm power requirement:3,7 kW weight:2,8 t dimensions (WxDxH):1,5 x 1,5 x 2,2 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic

Pressure:630 t distance between columns:1600 mm stroke:fix 250 mm no. of strokes:20 /min distance table/ram, max. stroke up, adjustment up:900 mm table surface area:1550 x 1200 mm table height over floor:800 mm side window:620 mm ram surface:1360 x 1200 mm ram adjustment:160 mm height over floor:5,9 m height beneath floor:0,6 m power requirement:32,0 kW weight:59,0 t dimensions (WxDxH):3,0 x 2,2 x 6,5 m clutch:pneumatisch overload protection in ram:hydraulisch ram adjustment:motorisch ram counterbalance:pneumatisch

pressure:500 t distance between columns:3400 mm stroke:850 mm no. of strokes:9 - 18 /min distance table/ram, max. stroke up, adjustment up:2050 mm table surface area:3100 x 1900 mm table height over floor:400 mm side window:1550 mm ram surface:3100 x 1900 mm ram adjustment:350 mm pressure of drawing cushion in ram:70 t pressure of drawing cushion in table:140 t stroke of drawing cushion in table:0 - 250 mm stroke of drawing cushion in ram:150 mm height beneath floor:6,0 m height over floor:8,3 m weight:155,0 t dimensions (WxDxH):5,1 x 4,5 x 12,3 m Kind of drive:link drive tool changing unit:2 x

pressure:500 t distance between columns:3400 mm stroke:850 mm no. of strokes:9 - 18 /min distance table/ram, max. stroke up, adjustment up:2050 mm table surface area:3100 x 1900 mm table height over floor:400 mm side window:1550 mm ram surface:3100 x 1900 mm ram adjustment:350 mm pressure of drawing cushion in ram:70 t pressure of drawing cushion in table:140 t stroke of drawing cushion in table:0 - 250 mm stroke of drawing cushion in ram:150 mm height beneath floor:6,0 m height over floor:8,3 m weight:155,0 t dimensions (WxDxH):5,1 x 4,5 x 12,3 m Kind of drive:link drive tool changing unit:2 x

pressure:500 t distance between columns:3400 mm stroke:850 mm no. of strokes:9 - 18 /min distance table/ram, max. stroke up, adjustment up:2050 mm table surface area:3100 x 1900 mm table height over floor:400 mm side window:1550 mm ram surface:3100 x 1900 mm ram adjustment:350 mm pressure of drawing cushion in ram:70 t pressure of drawing cushion in table:140 t stroke of drawing cushion in table:0 - 250 mm stroke of drawing cushion in ram:150 mm height beneath floor:6,0 m height over floor:8,3 m weight:155,0 t dimensions (WxDxH):5,1 x 4,5 x 12,3 m Kind of drive:link drive tool changing unit:2 x

pressure:500 t distance between columns:3400 mm stroke:850 mm no. of strokes:9 - 18 /min distance table/ram, max. stroke up, adjustment up:2050 mm table surface area:3100 x 1900 mm table height over floor:400 mm side window:1550 mm ram surface:3100 x 1900 mm ram adjustment:350 mm pressure of drawing cushion in ram:70 t pressure of drawing cushion in table:140 t stroke of drawing cushion in table:0 - 250 mm stroke of drawing cushion in ram:150 mm height beneath floor:6,0 m height over floor:8,3 m weight:155,0 t dimensions (WxDxH):5,1 x 4,5 x 12,3 m Kind of drive:link drive overload protection in ram:hydraulic ram adjustment:motoric tool changing unit:2 x

pressure:063 t throat:280 mm stroke:8 - 100 mm no. of strokes:65 /min distance table/ram, max. stroke up, adjustment up:415 mm table surface area:620 x 500 mm hole in the table:230 mm table height over floor:800 mm ram surface:310 x 255 mm ram adjustment:63 mm power requirement:5,5 kW weight:3,95 t dimensions (WxDxH):1,2 x 1,8 x 2,4 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:mechanical

pressure:075 t throat:230 mm stroke:6 - 100 mm no. of strokes:105 /min distance table/ram, max. stroke up, adjustment up:354 mm table surface area:700 x 420 mm hole in the table:250 mm table height over floor:800 mm passage to the back:310 mm ram surface:264 x 270 mm ram adjustment:60 mm power requirement:5,5 kW weight:3,6 t dimensions (WxDxH):1,2 x 1,6 x 2,3 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1

pressure:150 t throat:350 mm stroke:6 - 122 mm no. of strokes:45 /min distance table/ram, max. stroke up, adjustment up:440 mm table surface area:820 x 600 mm hole in the table:330 mm table height over floor:820 mm ram surface:500 x 350 mm ram adjustment:75 mm power requirement:10,0 kW weight:7,3 t dimensions (WxDxH):1,6 x 2,2 x 2,9 m

pressure:150 t throat:350 mm stroke:6 - 122 mm no. of strokes:45 /min distance table/ram, max. stroke up, adjustment up:440 mm table surface area:820 x 600 mm hole in the table:350 mm table height over floor:800 mm ram surface:500 x 350 mm ram adjustment:75 mm power requirement:10,0 kW weight:7,1 t dimensions (WxDxH):1,5 x 2,1 x 2,9 m

pressure:100 t throat:375 mm stroke:20 - 125 mm no. of strokes:30 - 80 /min distance table/ram, max. stroke up, adjustment up:515 mm table surface area:900 x 635 mm hole in the table:280 mm table height over floor:800 mm passage to the back:570 mm ram surface:700 x 450 mm ram adjustment:80 mm power requirement:15,0 kW weight:8,0 t dimensions (WxDxH):1,5 x 2,4 x 3,5 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic overload protection in ram:hydraulic ram adjustment:motoric ram counterbalance:pneumatic

pressure:160 t throat:480 mm stroke fix:fix 180 mm no. of strokes:25 - 70 /min distance table/ram, max. stroke up, adjustment up:650 mm table surface area:1100 x 900 mm Hole in the table:450 mm table height over floor:900 mm passage to the back:700 mm ram surface:900 x 600 mm ram adjustment:144 mm power requirement:30,75 kW weight:15,3 t dimensions (WxDxH):2,0 x 2,4 x 3,75 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch-/ brake combination:pneumatic, Desch overload protection in ram:hydraulic ram counterbalance:pneumatic

pressure:315 t throat:480 mm stroke:20 - 190 mm no. of strokes:36 + 45 /min distance table/ram, max. stroke up, adjustment up:615 mm table surface area:1400 x 880 mm hole in the table:250 mm table height over floor:800 mm passage to the back:950 mm ram surface:850 x 630 mm ram adjustment:125 mm power requirement:33,0 kW weight:30,0 t dimensions (WxDxH):2,0 x 3,0 x 4,4 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch-/ brake combination:pneumatic overload protection in ram:hydraulic stroke adjustment:semi-automatic ram adjustment:motoric ram counterbalance:pneumatic

pressure:200 t stroke:30 - 160 mm no. of strokes:40 - 120 /min distance between columns:1500 mm distance between oil collecting pans:1300 mm distance table/ram, max. stroke up, adjustment up:860 mm hole in the table:550 x 300 mm table surface area:1250 x 1250 mm table height over floor:1000 mm column travel -side:600 x 530 mm ram surface:1250 x 1000 mm ram adjustment:125 mm Material width of feeder:30 - 500 mm Material thickness feeder:0,5 - 3,0 mm feeding length:0 - 999,9 mm power requirement:50,0 kW weight:34,0 t dimensions (WxDxH):4,0 x 1,7 x 5,2 m clutch-/ brake combination:pneumatisch, Ortlinghaus overload protection in ram:hydraulisch ram adjustment:automatisch stroke adjustment:automatisch ram counterbalance:pneumatisch roll feed:Weingarten, WE 60 Option: NEW electrical controls:Siemens S7-1500 F

pressure:080 t throat:280 mm stroke:8 - 112 mm no. of strokes:30 - 120 /min distance table/ram, max. stroke up, adjustment up:500 mm table surface area:840 x 580 mm hole in the table:150 mm table height over floor:910 mm passage to the back:640 mm ram surface:560 x 300 mm ram adjustment:80 mm power requirement:7,5 kW weight:8,0 t dimensions (WxDxH):1,6 x 2,3 x 3,3 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:hydraulisch ram adjustment:motoric

pressure:500 t stroke:fix 300 mm no. of strokes:20 - 70 Hub/min distance between columns:3100 mm side window:1400 mm distance table/ram, max. stroke up, adjustment up:1000 mm Table area:2800 x 1600 mm ram surface:2800 x 1450 mm ram adjustment:100 mm power requirement:90,0 kW weight:100,0 t Dimensions (WxDxH):5,75 x 3,2 x 7,8 m height above floor:6,4 m height beneath floor:1,4 m clutch:pneumatic; Ortlinghaus ram adjustment:motoric overload protection in ram:hydraulic ram counterbalance:pneumatic

pressure:160 t distance between columns:1360 mm stroke:300 mm Distance table/ram, max. stroke up, adjustment up:620 mm table surface area:1300 x 900 mm table height over floor:950 mm side window:640 mm ram surface:1300 x 900 mm power requirement:45,0 kW weight:16,0 t Dimensions (WxDxH):2,5 x 2,1 x 4,1 m cutting impact cushioning:hydraulic

Pressure:080 t throat:345 mm stroke:20 - 160 mm no. of strokes:65 /min distance table/ram, max. stroke up, adjustment up:495 mm table surface area:920 x 610 mm table height over floor:800 mm Hole in the table:280 mm passage to the back:670 mm ram surface:650 x 400 mm ram adjustment:50 mm power capacity:10,0 kW weight:7,7 t Dimensions (WxDxH):1,5 x 2,2 x 3,15 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:hydraulic ram adjustment:motoric

Force of pressure: 75 t projection: 300 mm table size: 620 x 800 mm Durchfalloch in the table: 225 x 325 mm table adjustment: 175 mm plunger surface: 180 x 475 mm slide adjustment: 80 mm stroke adjustment: 16-140 mm stroke rate: 90 / min drive motor: 380 V, 3 kW space: 1700 x 1200 x 2500 mm weight: 3300 kg

Force of pressure: 63 t table size: 610 x 800 mm throat depth: 350 mm stroke: 200 mm Electr. Supply: 380 V, 15 kW space: 1800 x 920 x 2440 mm weight: 3940 kg

; in order

Pressing force: 40 t table size: 670 x 470 mm plunger surface: 670 x 470 mm clearance between the pillars: 620/470 mm gr. Height: 740 mm Preß speed: 20 mm / s rapid traverse: 50 mm ejector force: 3T Electr. Supply: 380 V, 9.5 kW space: 2200 x 1875 x 3000 mm weight: 2400 kg
