schuler presses used for sale

Capacity: 50 ton Projection: 225 mm Stroke: 320 p/min Large table: 500 x 800 mm

Schuler PE4s 50/800 High Speed Press Manufacturer: Schuler Type: PE4s 50/800 High-speed press 61/21 600/3 Pressing force: 50 t Projection: 800 mm Stroke rate /min: 125-300 Plunger stroke: 40 mm Kohler unwinding reel 500.1 M We sell a large number of paternosters. The devices are in operation until 30.06.2021. After the purchase, there are also the documents for it From 01.07.21 the devices are ready for collection. Dismantling and transport by the buyer. Location is Hildesheim The dismantling, loading, as well as transport can alternatively be offered by us. In addition to about 50 paternosters, countless other machines are available. After purchase, the amount is due within 7 working days. Please also note our other offers. Have fun browsing and buying.

Specifications: Capacity 63 tons Stroke rate 140 h/min Projection 250 mm Plunger stroke 8-100 mm Table , WxD approx. 700 x 480 mm Installation height approx. 400 mm

Specifications: Capacity 63 tons 2 strokes 105 rpm and 140 rpm large projection 450 mm ! Plunger stroke 8-100 mm Plunger adjustment approx. 70 mm Table , WxD approx. 700 x 780 mm Plunger, W x D approx. 450 x 280 mm

Fully Automated Forging Hammer Line (2023) SCHULER KG H 6.3 B (63 KJ) Line Description The complete line consists of the following machines: ‍ Tilting Device, Stahlmann Step Conveyor, Stahlmann Cold conveyor belt Conductive Heating System, Stahlmann, E89, 2023 Transfer Gripper Hot Conveyor Belt with Lifting Device 2 Forging robot, Kuka, KR 30-3F, 2010 Safety Fence with Safety Doors Short-Stroke Die Forging Hammer, Schuler, KG H 6.3 B, 2023 Discharge / Extraction Robot, Kuka, KR 150/2, 2010 Output Station, Stahlmann, 2010 ‍ ‍ Technical Details ‍ (2023) Short-Stroke Die Forging Hammer SCHULER KGH 6.3B ‍Machine identification data Name: Short-Stroke Die Forging Hammer Model: KGH 6.3B Machine number: 119820 Year of manufacture: 2023‍ Operational parameters Working capacity max. 63 kJ Max. impact frequency 98/min Max. usable impact rate  ...

End mill, shank mill, milling cutter -Four-cutter -Roughing end mill -Diameter: 16 mm -Usable length: 20 mm -Type: HSSE -Quantity: 17 pieces -Sale: only complete set -Weight: 4 kg

Radius cutter, finger cutter, end mill, milling cutter -Six-cutter -Finish cutter -Shaft: Ø 25 mm -Diameter: 32 mm -Usable length: 70 mm -Angle: 60° -Type: HSS -Quantity: 4 pieces -Sale/Price: complete -Weight: 4 kg

End mill, roller cutter, milling cutter, disc cutter, slot cutter -Manufacturer: Schuler, end mill cutters, disc cutters -Type: 125Wx12x32 HSS K10 -Hole: Ø 32 mm -Quantity: 1x milling cutter available -Dimensions: Ø 125 x 12 mm -Weight: 0.5 kg

material width:320 mm coil weight:2,6 t material thickness:0,5 - 2,0 mm coil internal diameter:400 - 510 mm coil external diameter:1200 mm no. of straightening rolls:7 straightening roll diameter:50 mm number of draw-in rolls:2 band speed:0 - 30 m/min power capacity:1,5 kW weight:1,5 t

nominal force:100 t stroke:320 mm no. of strokes:35 /min distance between columns:360 / 250 mm Distance table/ram, max. stroke up, adjustment up:500 mm table surface area:320 x 450 mm table height over floor:660 mm ram surface:250 x 280 mm spindle diameter:125 mm power capacity:3,0 kW weight:4,5 t Dimensions (WxDxH):2,0 x 1,6 x 3,1 m

pressure: 1.000 t nominal power: 10.000 kN stroke length max.: 1.650 mm working feed: 62 mm/sec weight of tools max.: 40.000 kg voltage: 400 V total power requirement: 420 kW weight of the machine ca.: 254 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 63 t throat: 315 mm stroke: 8-100 mm no. of strokes: 140 Hub/min ram - range of adjustment: 63 mm table surface area: 1200x630 mm ram surface: 800x315 mm hole in the table: Ø 110 mm table height: 820 mm tool hole in ram: Ø 50 mm dayligth: 335 mm total power requirement: 7,5 kW weight of the machine ca.: 5 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 63 t throat: 440 mm stroke: 8-100 mm no. of strokes: 65 Hub/min ram - range of adjustment: 63 mm table surface area: 720x750 mm ram surface: 440x280 mm hole in the table: Ø 240 mm table height: 830 mm tool hole in ram: Ø 40 mm weight of the machine ca.: ca. 5,0 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Pressure total: 600 ton Ram stroke: 762 mm Slide adjustment: 406 mm Shut height (stroke down, adjustment up): 1322 mm Free frontal opening L-R: 3700 mm Table surface area : 3350 x 2134 mm Slide area: 3350 x 2134 mm Die cushion capacity in table: 180 ton Die cushion stroke: 305 mm Ejector in ram: 60 ton Ejector stroke in ram: 230 mm Number of strokes: 16 s.p.m. Required power: 90 kW Weight of machine approx.: 185 ton

SCHULER HYDRAP SH 630 - 1.6 x 1.3 (2005) Total weight 74,000 kg Rated force 6,300 kN Max. stroke length 600 mm Mounting height 900 mm Closes quickly 500 mm/s Max. working speed 23 mm/s Min. working speed 51 mm/s Base and tool max. (xH) 2,280 x 1,200 mm Base and tool min. (xH) 1,250 x 600 mm Tool height min. 300 mm Total tool weight max. 2,500 kg Total tool weight max. 5,000 kg Permissible eccentric hydraulic press load left right Permissible eccentric load front rear 490 kNm 250 kNm Installed power 295 kW Rated current 565 A Voltage 400 V Frequency 50 Hz Operating hydraulic pressure 278 bar Total oil volume 5.185 l Oil type HLP 68 in accordance with DIN 51524

sheet width: 5 mm plate thickness: 1000 mm distance between columns: mm total power requirement: 4 kW weight of the machine ca.: 2,8 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 25 t throat: 200 mm stroke: 8 - 80 mm no. of strokes: 180 Hub/min distance table/ram: 330 mm table surface area: 550 x 400 mm hole in the table: 60 mm table height over floor: 800 mm table height over floor: 800 mm passage to the back: 200 mm ram surface: 355 x 220 mm ram adjustment: 50 mm power capacity: 2,5 kW total power requirement: kW weight of the machine ca.: 2,5 t dimensions of the machine ca.: 1,2 x 1,8 x 2,4 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Sheet thickness iron: 0.75mm, sheet thickness steel: 0.5mm, working width: 780mm, stroke rate: 135/min. An on-site inspection is possible.

CONTROLS   PLC SIEMENS S7 PRESS DESIGN   drive system: knuckle-joint   frame design: H-frame, monoblock   openings in uprights: yes   number of suspensions: 2   feedstock transport direction: left to right PRESS FORCES   total force (nominal): 315 to   nominal work capacity: 38 kNm PRESS TABLE   table surface (left-right): 2000 mm   table surface (front-back): 1200 mm   thickness of bolster plate: 200 mm SLIDE   slide force: 315 to   table surface (left-right): 1995 mm   table surface (front-back): 1100 mm   stroke: 160 mm   stroke rate (max.): 80 /min SLIDE (MECHAN. PRESS)   slide adjustment: 140 mm   stroke rate (min.): 20 /min   stroke rate (max.): 80 /min   main drive power: 90 kW TOO ...

An electric guillotine shear L. Schuler (Göppingen) is available. Working width: 1000mm, max. sheet thickness iron/steel: 2.5mm/2mm, flywheel speed: 100rpm, power requirement: 4HP. An on-site inspection is possible.

Pressure total: 800 ton Ram stroke: 700 mm Slide adjustment: 600 mm Shut height (stroke down, adjustment up): 1475 mm Free frontal opening L-R: 3700 mm Free lateral opening F-B: 2300 mm Table surface area : 3600 x 2200 mm Slide area: 3500 x 2070 mm Die cushion capacity in table: 150 ton Die cushion stroke: 250 mm Die cushion pad area: 2780 x 1570 mm Ejector in ram: 60 ton Ejector stroke in ram: 150 mm Number of strokes: 7 - 21 s.p.m. Required power: kW Height over floor approx.: 9510 mm Weight of machine approx.: 260 ton

Press force: 250kN, ram stroke: 8mm-80mm, stroke rate: 180/min, installation height: 310mm, table dimensions X/Y: 550mm/400mm, ram dimensions X/Y: 355mm/220mm, machine dimensions X/Y/Z: approx. 1100mm/1400mm/2300mm, weight: approx. 2500kg. An on-site inspection is possible.

Pressure total: 1200 ton Ram stroke: 600 mm Slide adjustment: 600 mm Shut height (stroke down, adjustment up): 1600 mm Free frontal opening L-R: 4550 mm Table surface area : 4500 x 2700 mm Slide area: 4500 x 2700 mm Die cushion capacity in table: 225 ton Die cushion stroke: 200 mm Number of strokes: 9 s.p.m. Height over floor approx.: 9000 mm Weight of machine approx.: 344 ton

pressure: 200 t nominal power: 2000 kN stroke length max.: 1700 mm working feed: 50 mm/sec weight of tools max.: 50000 kg voltage: 400 V table-size: 4.800 x 2.400 mm total power requirement: 99 kW weight of the machine ca.: 113 t dimensions of the machine ca.: m passage width: mm stroke: mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Pressure total: 1200 ton Ram stroke: 600 mm Slide adjustment: 500 mm Shut height (stroke down, adjustment up): 1250 mm Free frontal opening L-R: 3550 mm Table surface area : 3500 x 2700 mm Slide area: 3500 x 2700 mm Die cushion capacity in table: 240 ton Die cushion stroke: 250 mm Ejector in ram: 95 ton Ejector stroke in ram: 150 Number of strokes: 10 - 16 s.p.m. Height over floor approx.: 9000 mm Weight of machine approx.: 280 ton

bushing cut-off diameter range 8-18 mm number of dies 5 number of stations (incl. cut off) 6 shaft length under head 120 mm cutting length 140 mm output - pieces/min 60-170 press power 100 to

Pressure total: 800 ton Ram stroke: 700 mm Slide adjustment: 600 mm Shut height (stroke down, adjustment up): 1500 mm Free frontal opening L-R: 3800 mm Free lateral opening F-B: 1450 x 1100 mm Table surface area : 3500 x 1900 mm Slide area: 3500 x 1900 mm Die cushion capacity in table: 150 ton Die cushion stroke: 250 mm Die cushion pad area: 2780 x 1570 mm Number of strokes: 7 - 18 s.p.m. Required power: 120 kW Height over floor approx.: 9510 mm Weight of machine approx.: 260 ton

material width: 650 mm coil weight: 15 t material thickness: 16 mm The year of construction is estimated, the system is as good as new The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

band width:1050 mm plate thickness:8 mm number of rolls:8 DECOILER:. - design : single coil :. - sheet width max:1050 mm - sheet width (min):150 mm - max. weight of coil:22 to - max. diameter of coil:2000 mm - min. internal diameter of coil:570 mm FEEDERS:. - feeder: type : roll feeder :. - sheet width max:1050 mm - sheet thickness max:150 mm LEVELER UNIT:. - sheet width max:1050 mm - sheet width (min):150 mm - sheet thickness max:8 mm - sheet thickness (min):2.5 mm - number of leveler rolls:8 - diameter of leveler rolls:96 mm - distance between leveler rolls:104 mm - diameter of feed rolls:160 mm - feed velocity min.:2 m/min - feed velocity max.:43.5 m/min ELECTRICAL SPECIFICATIONS:. - mains voltage:400 V - mains frequency:50 Hz Technical description : Sheet metal unrolling and straightening system for thick sheet metal up to 8 mm, consisting of: - LAWECO COIL LOA ...

pressure:40 t throat:220 mm stroke:8 / 88 mm table pass:ø- abgesetzt 225/200 mm ram head dimension:400 x 250 mm distance table/ram:228 mm stroke adjustable from - to:30 - 140 mm ram adjustment:63 mm thickness of bolster:80 mm no. of strokes:70 Hub/min total power requirement:5,5 kW weight of the machine ca.:2600 kg dimensions of the machine ca.:1100 x 1300 x 2300 mm Documents:vorhanden

pressure:125 t stroke:25 fix mm no. of strokes:70 - 700 /min distance between columns:1150 mm distance table/ram, max. stroke up, adjustment up:400 mm table surface area:1150 x 1000 mm hole in the table:900 x 220 mm side window:650 mm ram surface:990 x 850 mm ram adjustment:60 mm material width:250 mm material thickness:2,5 mm power requirement:46,5 kW weight:29,5 t roll feed:mechanical, Schuler, WK 8-250

pressure:063 t throat:450 mm stroke:8 - 100 mm no. of strokes:65 /min distance table/ram, max. stroke up, adjustment up:415 mm table surface area:720 x 800 mm hole in the table:280/250 mm table height over floor:800 mm passage to the back:290 mm ram surface:450 x 280 mm ram adjustment:63 mm power requirement:7,5 kW weight:4,7 t dimensions (WxDxH):1,3 x 2,0 x 2,65 m clutch:pneumatisch overload protection in ram:mechanisch

pressure:100 t throat:315 mm stroke:30 - 160 mm no. of strokes:40 /min distance table/ram, max. stroke up, adjustment up:460 mm table surface area:910 x 680 mm Hole in the table:400 mm table height over floor:800 mm passage to the back:400 mm ram surface:630 x 400 mm ram adjustment:80 mm power requirement:7,5 kW weight:7,5 t dimensions (WxDxH):1,7 x 2,0 x 3,0 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic overload protection in ram:mechanical ram counterbalance:pneumatic

pressure:3500 t stroke:900 mm Distance table / ram, stroke down:1000 mm distance table / ram, stroke up:1900 mm table surface area:3150 x 2150 mm ram surface:3150 x 2150 mm Total Weight of Tool max.:30,0 t Weight of Tool Top Part max.:20,0 t speed down:400 mm/s working speed:0,9 - 9,2 mm/s Hydraulic Operating Pressure:280 bar oil volume:5500 l rated current:760 A voltage:400 V frequency:50 Hz power requirement:425 kW weight:231,0 t

Pressure:080 t throat:280 mm stroke:20 - 120 mm no. of strokes:42 - 125 /min distance table/ram, max. stroke up, adjustment up:510 mm table surface area:700 x 560 mm hole in the table:280 mm table height over floor:800 mm passage to the back:320 mm ram surface:560 x 350 mm ram adjustment:72 mm Weight:5,2 t Dimensions (WxDxH):1,6 x 1,6 x 2,6 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic overload protection in ram:mechanical

pressure:025 t throat:200 mm stroke:8 - 80 mm no. of strokes:60 - 180 /min distance table/ram, max. stroke up, adjustment up:330 mm table surface area:560 x 400 mm hole in the table:150 mm table height over floor:800 mm passage to the back:240 mm ram surface:355 x 220 mm ram adjustment:50 mm weight:3,0 t dimensions (WxDxH):1,0 x 1,4 x 2,2 m infinitely variable drive:Stöber overload protection in ram:mechanical NEW electrical controls:Pilz

pressure:025 t throat:200 mm stroke:8 - 80 mm no. of strokes:180 /min distance table/ram, max. stroke up, adjustment up:330 mm table surface area:550 x 400 mm hole in the table:60 mm table height over floor:800 mm passage to the back:200 mm ram surface:355 x 220 mm ram adjustment:50 mm power requirement:2,7 kW weight:2,5 t dimensions (WxDxH):1,2 x 1,8 x 2,4 m overload protection in ram:mechanical

Pressure:250 t stroke:30 mm no. of strokes:60 - 500 /min Distance between columns:1500 mm distance table/ram, max. stroke up, adjustment up:390 mm table surface area:1580 x 1100 mm hole in the table:1270 x 300 mm table height over floor:1470 mm side window:600 mm ram surface:1500 x 900 mm ram adjustment:100 mm material width:500 mm material thickness:0,5 - 1,5 mm coil weight:6,5 t coil internal diameter:420 - 560 mm coil external diameter:1500 mm power capacity:45,0 kW Weight:44,0 t Dimensions (WxDxH):3,3 x 1,8 x 4,5 m clutch:pneumatisch ram adjustment:motorisch double decoiler:LH 2-1,5-500 straightening machine:R 500 roll feed:mechanisch; Schuler, WK 8-500

pressure:160 t throat:400 mm stroke:30 - 200 mm no. of strokes:50 /min distance table/ram, max. stroke up, adjustment up:600 mm table surface area:1000 x 770 mm table height over floor:810 mm hole in the table:360 mm Passage to the back:450 mm ram surface:710 x 450 mm ram adjustment:110 mm power requirement:15,0 kW weight:10,5 t Dimensions (WxDxH):1,7 x 2,0 x 3,2 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:hydraulic overload protection in ram:mechanical ram counterbalance:pneumatic

pressure:063 t throat:250 mm stroke:8 - 100 mm Stroke rate:60 - 160 / min Distance table/ram, max. stroke up, adjustment up:415 mm Table surface area:710 x 500 mm Hole in the table:250 / 280 mm Table height above floor:800 mm Passage to the back:290 mm Ram surface:450 x 280 mm Ram adjustment:63 mm Weight:4,3 t Dimensions (WxDxH):1,5 x 1,7 x 2,7 m infinitely variable drive:PIV clutch:pneumatic overload protection in ram:mechanical

pressure:063 t throat:250 mm stroke:8 - 100 mm Stroke rate:47 - 140 / min Distance table/ram, max. stroke up, adjustment up:415 mm Table surface area:710 x 480 mm Hole in the table:280 / 250 mm Table height above floor:800 mm Passage to the back:290 mm Ram surface:450 x 280 mm Ram adjustment:63 mm Weight:4,0 t Dimensions (WxDxH):1,5 x 1,6 x 2,7 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 infinitely variable drive:PIV clutch:pneumatic overload protection in ram:mechanical

pressure:600 t distance between columns:3640 mm stroke:350 mm no. of strokes:11 - 44 /min Distance table/ram, max. stroke up, adjustment up:1550 mm table surface area:3600 x 2500 mm sliding table:3600 x 2500 mm ram surface:3600 x 2500 mm Side window:2200 mm ram adjustment:400 mm material width coil line:500 - 1950 mm Material thickness at 1200 mm material width:0,6 - 2,5 mm Material thickness at 1850 mm material width:0,6 - 2,0 mm Material thickness at 1950 mm material width:0,6 - 1,75 mm Coil weight:35,0 t coil internal diameter:610 mm coil external diameter:900 - 1900 mm no. of straightening rolls:13 straightening roll diameter:50 mm Stack height:400 mm stacking dimensions - station 1+2 (L x W):150-2000 x 250-2000 mm stations:2 power requirement:112,0 + 35,0 kW Weight:390,0 t Dimensions (WxDxH):7,3 x 5,1 x 15,0 m Height above floor:9,1 m Height below floor:5,9 m clutch-/ brake combinat ...

Pressure total: 250 ton Ram stroke: 70 / 250 mm Slide adjustment: 160 mm Ejector in ram: 20 ton Ejector stroke in ram: 10 mm Shut height (stroke down, adjustment up): 520 mm Free lateral opening F-B: 1.300 mm Table surface area : 1.600 x 1.600 mm Slide area: 1.600 x 1.600 mm Number of strokes: 0 - 50 s.p.m. Required power: 33 kW Height over floor approx.: 5.500 mm Weight of machine approx.: 58 ton Roll feeder Material width: 1250 mm Material thickness: 0,3 - 1,6 mm Control: Siemens S7

Force of pressure: 75 t projection: 300 mm table size: 620 x 800 mm Durchfalloch in the table: 225 x 325 mm table adjustment: 175 mm plunger surface: 180 x 475 mm slide adjustment: 80 mm stroke adjustment: 16-140 mm stroke rate: 90 / min drive motor: 380 V, 3 kW space: 1700 x 1200 x 2500 mm weight: 3300 kg

Force of pressure: 63 t table size: 610 x 800 mm throat depth: 350 mm stroke: 200 mm Electr. Supply: 380 V, 15 kW space: 1800 x 920 x 2440 mm weight: 3940 kg

; in order

Pressing force: 40 t table size: 670 x 470 mm plunger surface: 670 x 470 mm clearance between the pillars: 620/470 mm gr. Height: 740 mm Preß speed: 20 mm / s rapid traverse: 50 mm ejector force: 3T Electr. Supply: 380 V, 9.5 kW space: 2200 x 1875 x 3000 mm weight: 2400 kg

Eccentric C stand press, little used C frame - eccentric press, used Type: PED 63.3 S4 manufacturer: WMW Year of construction: 1994 Pressing power / rated pressure: 63 t Sheet thickness / material thickn. 3.2 mm Table size / surface of bed: 800 x 580 mm Hole in the table / hole in table: 300 mm diameter. Stroke / stroke of slide: 8... 120 mm Number / number of strokes: 56 / 90 / min Tappet adjustment / adjustment of slide: 70 mm The maximum distance between Table and plunger / max distance between table and slide: 560 m Projection / Cap: mm Power of main motor / power of main motor: 6 kW Weight / weight: 5.5 t

The CNC press brake SMD PBH 110-3100-4C produced in 2006 is offered in a set with the ANTIL TWISTER F5 robot. Technical parameters : - manufacturer: SMD - type: PBH 110-3100-4C - year of production: 2006 - control: CNC CYBELEC ModEva 10 - overworked time: about 20,000 man-hours - pressure force: 110 tons - bending width: 3100 mm - maximum working speed: 10 mm / s - table width: 60 mm - table height: 960 mm - stroke: 465 mm - frame spacing: 2600 mm - throat: 410 mm - power supply: electric - 11.5 KW, 400 V three phases - oil tank capacity: 250 l - dimensions of the press: 3960 × 2045 × 3650 mm - total weight: 9500 kg Processing on a 3 m table and palletizing of finished details on 3 europallets.

Force of pressure: 30 to piston stroke: 150 mm table width: 185 mm passage (S): 530 mm bore (F): distance of 140 mm cylinders - table (F1): distance 150 mm cylinder - table (F2): 1030 mm cylinder movable (M): 200 mm width (A): (B depth of 800 mm): 700 mm height 1 (C): 1775 mm height 2 (D): 1805 mm weight: 162 kg

Pneumatic press 2643 Assembly through pivot table outside the working area With protective cage and release only with a retracted swing table Table size: 10 cm x 10 cm

Force of pressure: 50T piston stroke: 200 mm table width: 260 mm passage (S): 730 mm bore (F): distance 205 mm cylinder - table (F1): distance 75 mm cylinder - table (F2): 1050 mm cylinder movable (M): 240 mm width (A): 1040 mm depth (B): 800 mm height 1 (C): 1835 mm height 2 (D): 1880 mm weight approx.: 287 kg

Pneumatic press with foot-tripping

Maximum force: 1600 tons Slider stroke length: 400 mm Unattainable-course: 12 mm Number of courses of a slider per minute: 16 Number of single turn-on: 12 The closed height: 870 mm Adjustment: 220 mm Under-forginig plate: -From left to right: 1600 mm -From front to rear: 1600 mm -Thickness: 650 mm Slider overall dimensions: 1600x1600 mm Aperture in a table: 1000x1000 mm window dimensions in cheeks: 1650x1650 mm Course of a rigid pusher in a slider: 100 mm Force of a rigid pusher in a slider ton-force: 80 Main electric motor power: 110 kW Course of pneumatic pillow: 160 mm Force of pushing out of a pneumatic pillow ton-force: 71 Hydropneumatic pillow: -Working course: 250 mm -Force of pushing out ton-force: 25 -Force of a clip ton-force: 250 Press overall dimensions: 4670x4670x8110 mm Press weight: 140 tons

FRICTION BELT FOR SCREW PRESS DIRECT FROM THE MANUFACTURER! Description: -Chrome leather friction belt for screw presses, riveted, new! -Dimensions: 530 mm i. diameter x 50 mm high x 18 mm thick ON request make we the friction belts regarding to your sizes! For all machine types like SMS Hasenclever Berrenberg, Schuler, Weingarten, Vaccari, via, Mecolpress, Osterwalder... We deliver worldwide! We confirm best service and short delivery times.

FRICTION BELT DIRECT FROM THE MANUFACTURER! Description: -Chrome leather friction belt for screw press, riveted, new! -Dimensions: 530 mm i.diameter x 50 mm high x 18 mm thick ON request make we the friction belts regarding to your sizes! For all machine types like SMS Hasenclever Berrenberg, Schuler, Weingarten, Vaccari, via, Mecolpress, Osterwalder... We deliver worldwide!

SMG DS 315-1500/1300 CNC hydraulic press was manufactured in 1984 in Germany. The machine, consisting of two interconnected stations, is used for pressing metal workpieces in manual, semi-automatic and automatic mode with a pressing force of up to 315 tonnes. All the machine’s machining parameters are set using a CNC control with a full-colour, touchscreen display. The press is equipped with a hydraulic and pneumatic sheet metal feeder, servo drives for feed rollers to set a very precise stroke of up to 0.1 mm, safety cages and workpiece feed and drop control sensors. The SMG 315 T machine underwent a complete overhaul in 2007, during which components such as pumps and safety installations were replaced. Technical data of the SMG DS 315-1500/1300 press - maximum press force: 315 t - working table dimensions (L x W): 1500 x 1300 mm - upper machine point (from the table): 750 mm ...

Force of pressure: 100 t projection: 350 mm table size: 690 x 840 mm Durchfalloch in the table: 160 mm table adjustment: slide area: 450 x 600 mm slide adjustment: 80 mm stroke adjustment: 8-100 mm stroke rate: 60 / min drive motor: 380 V, 5.5 kW space: 1850 x 1850 x 2650 mm weight: 6800 kg

With the universal hand punch NPR-20 can both on the front page as also Center of the punch be punched, so may here A4 sheet at any point are processed. The punch is suitable for cutting of printed materials in the Office, in the printer or in the copy shop. With a Nutmesser can A4 sheets are grooved. The NPR-20 is suitable for all cutting work, which can be with the NPR-10 through out. A countertop if necessary Additionally facilitates the stamping work

SINO NCP 160 eccentric press built in China in 2018 by Sino Machinery & Tools (Dongguan) Co., LTD. performs machining of metal workpieces with a press force of 160 tonnes. The machine is equipped with high-quality components, including e.g. a 100 mm adjustable slider making up to 25 to 55 strokes per minute, and a YU JAIV PDH-120 indicator displaying the distance of the die between the table and the slider. The large working area, ease of operation and outstanding precision, guarantee excellent machining results. The press offers the possibility of combining it with an automatic feeding system in order to increase the number of parts produced and significantly reduce costs. The total weight of the machine is 13 tonnes. Technical data of the SINO NCP 160 press - maximum press force: 160 t - work area dimensions (L x W x H): 910 x 600 x 410 mm - bolster dimensions (L x W x H): 125 ...

SPK KB 2132 eccentric press was manufactured in the USSR in 1980. Operating with a force of 160 tonnes, the press of almost indestructible design offers the highest quality and precision during the most demanding workpiece machining. The machine’s equipment includes among others a pneumatic clutch, a large-area slider performing up to 71 strokes per minute, central lubrication and manual control. The total weight of the press is 13200 kg. Technical data of the SPK KB 2132 press - maximum press force: 160 t - work table dimensions (L x W): 1000 x 700 mm - maximum slider stroke: 160 mm - minimum slider stroke: 25 mm - slider dimensions (L x W): 580 x 460 mm - slider adjustment range: 120 mm - slider stroke rate: 71/min - intermediate plate thickness: 110 mm - distance between work table and slider (slider in lower position, largest stroke, connector unscrewed): 480 mm - bore ...

With the universal hole punch NPR-20 can both on the front page as also Center of the punch be punched, so may here A4 sheet at any point are processed. The punch is suitable for cutting of printed materials in the Office, in the printer or in the copy shop. With a Nutmesser can A4 sheets are grooved. The NPR-20 is suitable for all cutting work, which can be with the NPR-10 through out. A countertop if necessary Additionally facilitates the stamping work.

PLASOMAT PMS 63 CP eccentric press was manufactured in Poland in 2004. In order to meet all production requirements, the machine features a large area slider with the possibility of adjusting the height and number of strokes in the control cabinet. In addition, a stable, deformation-resistant monolithic structure combined with a high pressing force of 63 tonnes ensures the highest accuracy and precision in machining. All this makes the PMS 63 CP press the ideal choice for both small batch and high volume production. The offer includes additional equipment, consisting of among others 8 anti-vibration pads and an intermediate table. Technical specifications of the PLASOMAT PMS 63 CP press - maximum press force: 63 t (630 kN) - work table dimensions (L x W): 800 x 560 mm - number of slider strokes: 65-85/min - maximum slider stroke: 110 mm - minimum slider stroke: 8 mm - slider adj ...

A roll punching press for stamping is available up to A3. The die is pulled under the roll.

Pneumatic multi function press Operating pressure 6-8 bar Weight 106 kg dimensions 0.70 x 0.38 x 1.05 m Comments: Multi function punch air consumption 18 l per stroke, pneumatic punching operation via foot switch tripping

ULTRAPRAS UPV100TT SPECIAL hydraulic press built in 2022 Poland is the perfect choice for a range of demanding cold metal forming operations. This highly efficient and versatile machine can perform such operations as precision bending, profiling, flattening, bending, hole punching and stamping. Inside the robust design, there is a power unit-powered hydraulic piston with a diameter of 220 mm, which performs all these machining processes with a high press force of 100 tonnes. In addition, the entire working area is protected by light curtains, thanks to which the UltraPras four-column press also offers a high level of operational safety. During its service life, the machine has operated for just 595 hours and completed a total of 37042 work cycles. The UPV 100 TT SPECJAL 100t hydraulic press weighs 6500 kg. Technical specifications of the ULTRAPRAS UPV100TT SPECIAL press - maximum pre ...

Pressure: 65 tons -Stroke: 140 mm -Table size: 720 x 600 mm -Plunger surface: 500 x 300 mm -Tappet adjustment: 80 mm -Strokes: 20-40 per min. -. Weight: 6000 kg -Dimensions (L x W x H): height 3.1 m -Clamping hole ø 60 x 80 mm More info on request

Table 1750 x 920 mm, fixed stroke 101 mm, see pictures and description,; All right

Description of the chip press: Powerful metal chip press with chip shredder for long turnings. The area of application is the processing of large quantities of milled and turning chips. Materials: aluminum, steel, cast iron Drip pan as oil tank Geared motor for optimal agitator operation Hydraulic Compression Cylinder Hydraulic press cylinder with two coaxial sections Diameter of briquettes 60 mm Automatic briquette length adjustment with displacement transducers Inductive Proximity Sensors Pre-compaction cylinder in conjunction with special compression hydraulic cylinder that compacts the material in the bushing-bulkhead unit Briquette ejection system, consisting of a compression chamber and a bulkhead with special anti-wear treatment Highly efficient closed-circuit oil cooling system consisting of an air/oil heat exchanger Hydraulic system with B ...

ULTRAPRAS WKR70H hydraulic press built in 2021 by the Polish company SAKOMET is designed for even the most demanding cold metal forming operations. The operations, such as precise cutting, stamping, punching and extruding of workpieces, are performed with a force of 16 tonnes using a hydraulic cylinder with a diameter of 100 mm. Induction limiters additionally allow adjustment of the piston advance and retraction limits, making the machine adaptable to the working range of various tools. In turn, centrally beneath the piston is a large cross-cut work table with a 90mm diameter bore. The UltraPras WKR 70H 16t hydraulic press weighs 420 kg. Technical specifications of the ULTRAPRAS WKR70H press - press force: 16 t - piston stroke: 70 mm - piston diameter: 100 mm - maximum working speed: 9.8 mm/s - minimum working speed: 2 mm/s - return speed: 20 mm/s - work table dimensions (L x  ...

Tech. Data Nominal press force 1000 kN at maximum stroke adjustment - commute 6.5 mm 1250 kN at maximum stroke adjustment - commute 3.5 mm Strokes with endurance 125/83/63 Hube/min Usable stroke rate 50 50 38 / min. Throat depth 320 mm, clamp 380 mm Stroke adjustment 10-120 mm, Stosselverstellung 80 mm Stosselflaeche 800 x 320 mm, recording journal 50 / 85 Tabletop table top hole, 900 x 630 mm 230 mm, Durchfalloch in the table 300 / 400 x 250 mm Drive - 7,5 / 5,5 kW Bulk 1350 x 2080 x 2780 mm, Btto 8900 kg

Key data: 3 t, 150 mm

For sale in new condition HYUNDAE CETTA HHP-3 hydraulic press "more pieces" manufacturer: HYUNDAE "Korea" type: HHP-3 year of manufacture: 2018 load range: 1-3 tons Stroke [mm] 150 open height: 250 mm -safety light gate -two-handed operation .-mobile work table Hyundae press control Pressing rod closing speed: 178mm/sec Pressing rod pressing speed: 54mm/sec Opening speed 79 mm/s Table size: 450x360mm Max. Working pressure: 60kg·f/㎠ Hydraulic motor 1,5 kW 3 phase/4P 200v Weight: 350kg machine height "without table": 1415mm machine length: 950mm machine width: ca 700mm working table with casters or level bolts

various hand spindle presses small More: Foot pendulum press Jantsch

Transfer press KRUPP PST-A 160 built in 1980. Technical data of the KRUPP PST-A 160 press: - nominal pressure: 160 tons - cutting force grade 1: 400 KN - force between stands: 1200 KN - number of working steps including cutting stage: 11 - distance between stands: 200 mm - slider stroke: 210 mm - drawing depth: 70 mm - range of jumps, infinitely adjustable: 15-75 / min. - production range of jumps with repeatability of its setting: 25-75 / min. - number of actuation movements: 15-25 / min. - a usable work resource for a jump in the range of 25-75 strokes per minute. : 20,000 J - maximum load on a single step: 500 KN - maximum load of a single step using inserts: 630 KN - maximum width of the tape: approx. 340 mm - maximum diameter of the cut: 120 mm - minimum diameter of the pattern: 30 mm - distance between stands: 2450 mm - height of tool building at the lower posi ...

Press Walter

Pressure capacity: 8000 kg Maximum cutting area - 200 mm2 for material strength 40 kg / mm2 Horizontal radius 200 mm Clearance between the side walls 160 mm Fixed hub 35 mm Pin hole in the Stossel 38 x 60 mm Adjustability of the Stossels 70 mm Weight of 400 kg of the Presse Operating instructions The machine is located in the new value. State, probably never in use. Control actuator Stober

Description: Hydraulic single-column press with cycle feed Type: HEP 100 Specifications Electrical connection: 400 volts/50 Hz +/- 3 % Drive power: 5.5 kW Total power requirement: approx. 6.5 kW Control voltage: 24 volts/50 Hz +/- 3 % Hydr. Max. connection: 210 bar Set: 200 bar Performance data Ram speeds AB: approx. 48 mm/sec. at max. 100 kN compressive force Working speed AB reduced adjustable to: approx. 10 mm/sec. at max. 100 kN compressive force Ram speed ON approx. 96 mm/sec. at max. approx. 50 kN retraction force Plunger stroke: max. 200 mm Flow rate of the pump: approx. 15 l/min.

Universal - NPR-55U Stanze Knee lever punch -Punching of paper, cardboard and plastics. -for simple stamping -The cutting blades can be recorded from the shaft -The cutting blades can be created also not attached just under the pressure plate. -The pictured tools are not part of the offer.

Pneumatic pin press for printed circuit boards

PAD 63 A high-speed press was built in 1978 in Poland by Fabryka Pras Automatycznych Warszawa-Włochy. The machine is used for precision machining of uncoiled sheet metal. All machining processes, i.e. stamping, punching, cutting and bending are performed fully automatically with a high press force of 63 tonnes. The PAD 63A high-speed press on offer has undergone an overhaul. The total weight of the machine is 6300 kg. Technical specifications of the PAD 63 A press - maximum press force: 63 t - slider stroke number: 100-320/min - slider adjustment: 60 mm - maximum distance from work table to slider surface: 320 mm - distance between columns: 480 x 400 mm - motor power: 15 kW - grease pump motor power: 0,4 kW - weight of the PAD 63 A machine: 6300 kg

Technical data: -Compressive force 100 t -Throat 320 mm -Wide stand below the Guide 400 mm -Table size approx. 850 x 610 mm -Discontinued diarrhea hole in the table 335 / 300 mm -thickness of the table clamping plate 90 mm -gr. Height approx. 300 mm -Plunger area 600 x 335 mm -Adjustable height of the RAM 80 mm -Stroke adjustment 10-130 mm -Emissions er hub in the RAM 32 mm -Speed continuous operation approx. 56 / min -Drive 400 V / 11 kW -Space requirement approx. B H 1900 x 2800 X 2200 mm -Weight approx. 9000 kg Starring:-UVV press backup controller PREVENTA -Hydr. + pneumatically actuated clutch -LUTEX auxiliary braking system -Central lubrication

Hydraulic glue press with heating base, infinitely variable temperature setting, stuffenlose setting of the adhesive holding time, Power: 5 kW, 380 v 50 Hz; Two-hand operation.

Pneumatic pin press for printed circuit boards

Key data: 40 t, 1030 mm

For sale is an automated press brake with 1st hand robot system for serial sheet metal part forming. Press brake 2019 BYSTRONIC Xpert 40/1030 Robot 2019 KUKA KR10R 1100 sixx Specifications Press brake - Press force: 400kN (40t) - Working length: 1030mm - Control: ByVision Robot - Max. nominal load capacity: 11kg - Reach: 1100mm - Axles: 6-axle - Position repeatability: 0.02mm - CE certified safety modules Characteristics - Fully automated bending cell with integrated 6-axis industrial robot - from 1st hand - Dimensions (LxWxH): approx. 3.25m x 2.8m x 2.5m - ByVision Bending control terminal with 22-inch Full HD touchscreen Machine condition - Operating hours: 7,724 h - Cycle counter: 310,212 - Complete service history, regular inspections - Technically perfect condition - Functional test: can be demonstrated during inspection - Location: Niederroh ...

Hand lever press to push pins in printed circuit boards

Hand spindle press to push pins in printed circuit boards 2 presses on a plate, with a dial indicator.
