schiess lathes used for sale

Key data: 4000 mm, 5000 mm

Specifications Control SIEMENS SINUMERIK 840 Dsl Main dimensions and travels Face plate diameter 4,000 mm Circumferential diameter (max.) 5,000 mm Workpiece height (max.) 5,000 mm Total height of the machine 9,250 mm Maximum workpiece weight 80,000 kg Table base Y Horizontal table displacement 2,500 mm Crossbar Vertical adjustment of the crossbeam 3,200 mm in 50 steps Crossbeam Support (Right) Horizontal adjustment support - 2740 + 2740 mm Vertical displacement of the chisel slider 1,800 mm Cross-section of the chisel slider 250x210 mm Side Support (Right) Vertical adjustment support -25 + 2170 mm Horizontal displacement of the chisel slider 1,000 mm Cross-section of the chisel slider 250x210 mm Turning diameter max./min. 4,500/2,500 mm Main Drive: Main motor power 100 kW Face plate speed range 0.63 – 63 rpm. Maximum torque at the  ...

Description SHOOTING FRORIEP 40Dv Carousel Lathe. Modernized in 1998, among other things, a driven tool system (C-axis) was installed and the control was modernized to 840 C. Details Serial number 11330051 Year of construction 1980 Control SIEMENS electrical connection 400 V Face plate diameter 3,500 mm Workpiece height 3,000 mm Face plate over corridor 160 mm Total power requirement 71 kW Space requirement approx. 13 x 6 m Reconstruction 1998

Clamping claw box made of solid steel GR 9 (new) 4 pieces

Table 486 x 280 mm, X/Y/Z = 300/200/300 mm

Jig

Control SIEMENS Sinumerik 840D Specifications: Workspace - Max. rotation and turning diameter 2,000 mm - Max. turning height 2,000 mm - Face plate diameter 1,600 mm - Max. face plate load 11,200 kg - Chisel slide travel (vertical) 1,400 mm Smallest plunger diameter 330 mm Plunger cross-section 250 x 210 mm - Drive power of the main motor 71 kW - Crossbar adjustment 1,170 mm - Crossbeam support of central face plate to the right 1,170 mm - From the middle of the face plate to the left 25 mm Speed of faceplate: - Number of transmission stages 2 - 1 level 3.15-80 min-1 - 2 Level 12.5-315 min-1 - Lifter and support hydrostatically guided Feeds - X and Z 0.1 2000 mm/min - Rapid traverse X and Z 6,000 mm/min - Weight approx. 24,000 kg - Voltage 400 V 50 Hz - Connected load 175 kW - Space requirement L = 10,000 mm B = ...

Specifications Control Siemens Sinumerik 840 Dsl Main dimensions and travels Face plate diameter 3,500 mm Circumferential diameter (max.) 4,000 mm Workpiece height (max.) 3,000 mm Total height of the machine 7,250 mm Maximum workpiece weight 50,000 kg Table base Y Horizontal table displacement 2,000 mm Crossbar Vertical adjustment of the crossbeam 1,500 mm in 50 steps Crossbeam Support (Right) Horizontal adjustment support -25 + 2170 mm Vertical displacement of the chisel slide 1,800 mm Cross-section of the chisel slide 250x210 mm Tool Stations Crossbeam Support (Left) Horizontal adjustment support -25 + 2170 mm Vertical displacement of the chisel slide 1,800 mm Cross-section of the chisel slide 250x210 mm Tool Changer Main Drive: Main motor power 100 kW Face plate speed range 1-100 rpm. Maximum torque at the face plate 100  ...

Plate diameter 4200 mm Maximum turning diameter 4600 mm Max workpiece height under the cross member 4000 mm Max workpiece weight 100 t Travel RAM horizontal 2600 mm / min Travel RAM vertical 2000 mm / min Tool holder (powered tools) ISO 50 Table speed 40 rpm Main drive 120 kW Number of gear stages 4 Total connection value 180 kW Max torque on the flat disc 40000 kpm Max cutting force per support 10000 kp Crossbar support right and left Largest vertical path of the Chisel slider 2000 mm Cross-section of the chisel slider 285 x 310 mm Adjustment path of the crossbar 3500 mm Total weight of the machine 115,800 kg Accessories Automatic lubrication of the cross-bar guide on the stand Hydraulic weight compensation of the chisel sliders Milling spindle and C-axis c-axis 360,000 positions

Travel X-axis 9,500 mm Y-axis 4,100 mm Z-axis 950 mm W-axis 900 mm Main spindle speeds (infinitely adjustable): 3.15 - 1000 rpm Spindle motor power 58 kW Feed speed (infinitely adjustable): X-axis 0.1 - 9600 mm/min Y-axis 0.1 - 5600 mm/min Z-axis 0.1 - 5600 mm/min W-axis 0.1 - 5600 mm/min Accessories: Plate field: 6 x 4 m (CNC-controlled B- and V-axis) Table: 2 x 2 m (CNC-controlled B- and V-axis)

faceplate diameter: 2500 mm swing diameter: 3200 mm turning height: 3100 mm Control: R&D type: MTC 2x-2 workpiece weight: 20000 kg slide adjustment: 1600 mm side head - cross travel: 1000 mm Tool changer: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 1800 mm turning height: 1600 mm turning diameter over bed: 2150 mm turning speeds: 3,15 - 250 U/min voltage: 400 V total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

spindle diameter: 225 mm x-travel: 8000 mm y-travel: 5600 mm z-travel: 2100 mm w-axis: 1400 mm spindle turning speed - stepless: 0-650 U/min spindle taper ISO: 60 feed stepless: 5 - 3000 mm/min rapid traverse: 5 m/min weight of the machine ca.: 150 t dimensions of the machine ca.: 12 x 5 x 8 m total power requirement: 120 kW Ram type horizontal boring machine was reconditioned and modernized in 2006, original yom was 1972. Control Siemens 840 C. Machine will come with tools and a vertical milling head. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: 0 bore depth: 10000 mm number of spindles: 0 Control: Siemens Simatic Touch SPS swing over bed: 1050 mm swing diameter over bed slide: 1600 mm boring diameter: 50 - 310 mm centre height: 800 mm speeds:: 2,5 - 400 total power requirement: 74 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

4 pcs. rope pulleys for counter weight of a FB 225 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 220 mm turning length: 200 mm control: Siemens Sinumerik total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pitch taper:50 Aufnahme Detailed price on request depense on version and nos. ca. 500 - 1500 EUR + VAT /piece Diverse toolholders matching SCHIESS-VTL´s with SK 50 taper and T-slot clamping design! Diverse fixed boring bars in different dia. and length. Diverse boring bar adapter plates to adapt different boring bars. Diverse normal toolholders for toolshank 40 mm in version left or right

turning diameter over bed:3800 mm turning diameter over slide rest:3200 mm turning length:12000 mm faceplate turning speed range -stepless-:2 - 200 U/min max. workpiece weight:90.000 kg bed width:4000 mm 2 steadies

CNC LATHE SCHIESS STC 460 3 axis with Fanuc OI TC Year 2005 Turret 12 Position VDI 30 Tailstock Chipconveyer Max Swing over bed : 520 mm Max turning length : 550 mm

Ref. -No.: 10361 Manufacturer: SCHIESS Year of construction: 2023 Type of control: CNC Control: Siemens, Heidenhain, Fanuc - Configurable as required Storage location: Halberstadt Country of origin: Germany financing: nach Anfrage Support sleeve diameter: 130 mm X-Travel: 3000 mm Y-Travel: 2000 mm Z-Travel: 1600 mm Spindle stroke: 800 mm B-Axis: 360 ° W-Axis: 800 mm Spindle Taper: SK50 Max. Tool Weight: 25 kg Clamping Area: 1250 x 1250 (or configurable as required) mm T - groove width: 22 mm T - slot spacing: 160 mm Swivelling: Configurable as required ° Numbers Of Tools In Magazin: 40, 60, 120, 200, 240 Spindle Speed: 2900 RPM Max. Torque: 2500 Nm Drive Capacity - Spindle Motor: 41 kW

Technical data of used Schiess Froriep Boring Machine: CNC: Siemens 840 D Maximum transversal travel X axis: 13.770 mm Maximum vertical travel Y axis: 5.000 mm Z axis: 1.780 mm W axis: 950 mm V axis rotating support plane: 2.000 mm Rotating table dimensions: 5.000 x 3.500 mm Fixed table dimensions: 7.500 x 4.300 mm Maximum permissible load on the table: 120 ton Spindle power: 100 kW Spindle revolutions per minute: 710 rpm

Ref. -No.: 10362 Manufacturer: SCHIESS Year of construction: 2023 Type of control: CNC Control: Siemens - Heidenhain - Fanuc (configurable) Storage location: Halberstadt Country of origin: Germany financing: nach Anfrage Spindle Speed Max.: 3500 RPM Pallet diameter: 1600 mm Max. machining diameter: 2000 mm Number of claw boxes: 4 pc Clamping force per claw box: 55 kN Number of radial T-slots: 8 Max. speed for turning: 140 min-1 Max. speed for milling: 5 min-1 Max. torque for turning: 27000 Nm Max holding power: 36 kN positioning speed: 3000 mm Adjustment from center to right: 850 mm Shift from center to right (head and tool change): 2750 mm Adjustment from center to left: 850 mm Max feed rate: 2000 mm / min Max rapid traverse speed: 20000 mm / min Max. Feed force: 30 kN cross-section: 280 x 240 mm Max. cutting force when turning: 36 kN Max Spindle Torque: 1200 Nm Pressure: 6 bar Air requ ...

table length: 3000 mm table width: 3000 mm table load: 25 t total power requirement: kW weight of the machine ca.: t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Stock number 1210059 Machine Type Rotary Table Make SCHIESS Type 25/30 Control type X-way (mm) 2,000 Table dimensions (mm) 3,000 x 2,500 Table swivel (degrees) 360 Information Max. table load 40 ton

turning diameter: 1.600 mm max. swing diameter: 1.700 mm control: Siemens - 840D faceplate turning speed range: 1 - 320 U/min rapid traverse: 3.000 mm / min feed range: 1 - 3.000 mm/min size of pallet: 1.168 mm numbers of pallets: 2 main drive: 55 kW Vertical turret lathe with cnc | SCHIESS MOWEG - BERTHIEZ TFM 125 has been overhauled by SCHIESS MOWEG (RETROFIT) in 2007. The machine video from the production plant will be shared on request. The machine is in a well-maintained condition and can be inspected under power at any time in the Swiss factory location. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: TFM125 | TFM-125 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 1200 mm swing diameter: 1600 mm turning height: 1250 mm slide adjustment: 800 mm Control: Siemens type: 840 c power capacity: 56 kW : total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 1600 mm swing diameter: 2000 mm turning height: 1600 mm Control: Siemens Sinumerik 805 turning speeds: 1-250 U/min Table load: 12000 kg Control system manufacturer Siemens type Sinumerik 805 Accessories and cabinets can be purchased optionally The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solu ...

faceplate diameter: 1600 mm swing diameter: 1800 mm turning height: 1500 mm control: Siemens chip conveyor: Tool changer: type: 840 D mm workpiece weight: 10000 kg slide adjustment: 1000 mm ram head dimension: 240x240 mm turning speeds: 250 U/min main drive: 45 kW Accessories and cabinets can be purchased optionally The tech. Data are manufacturer or operator information and therefore non-binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data fo ...

spindle diameter: 180 mm x-travel: 8000 mm y-travel: 4000 mm Control: Siemens type: Sinumerik System 3 ram: horizontal adjustment: 800 mm Spindle travel W-axis: 1400 mm ram: diameter: 220 mm engine output: 75 kW turning speeds: 900 U/min Plate area: 8000x6000 mm angular milling head: total power requirement: kW weight of the machine ca.: t Overhauled in 1983 The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your  ...

Control Siemens ... Sinumerik 840 D Max.workpiece diameter ... 3200mm Turntable diameter ... 3000mm Max.table load... 14000kg Max. workpiece height ... 2200mm Axis Z ... 1155mm Max. workpiece weight ... 14000 kg Main engine power ... 81 kW Floor space... DXŠXV 7200x6400x6600mm The machine is in very good condition,

faceplate diameter: 1250 mm swing diameter: 1500 mm turning height: 1250 mm Control: Siemens type: 840 Dsl tool taper: 4 Pos. total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The machine was overhauled in 2015 by Matuschek. Siemens 840 DSL Shop Turn The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with  ...

spindle diameter: 225 mm x-travel: 8000 mm y-travel: 5600 mm z-travel: 2100 mm w-axis: 1400 mm spindle turning speed - stepless: 0-650 U/min spindle taper ISO: 60 feed stepless: 5 - 3000 mm/min rapid traverse: 5 m/min weight of the machine ca.: 150 t dimensions of the machine ca.: 12 x 5 x 8 m total power requirement: 120 kW Ram type horizontal boring machine was reconditioned and modernized in 2006, original yom was 1972. Control Siemens 840 C. Machine will come with tools and a vertical milling head. The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production li ...

- set off 4 heavy duty jaws for SCHIESS FRORIEP DV DF DZ DKE - Jaw width 90 mm - Jaw height 75 mm - Hole to hole jump length ways 125 mm - Hole to hole jump in width 250 mm

- set off 4 heavy duty jaws for SCHIESS FRORIEP DV DF DZ DKE - Jaw width 90 mm - Jaw height 75 mm - Hole to hole jump 125 mm

faceplate diameter: 2950 mm swing diameter: 3200 mm turning height: 3500 mm turning speeds: U/min main drive motor: 70 kW Control: FAGOR 8070 workpiece weight max.: 20 t column daylight: 3300 mm milling motor: 16 kW feeds crossrail-slide vertical: 3000 mm/min feeds crossrail-slide horizontal: 3000 mm/min total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m equipped with: - CNC Control FAGOR 8070 - C-axis (angular positioning of the table) - angular milling Head - Telescopic covers of the cross rail and columns guideways - Chip Conveyor The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 5500 mm swing diameter: 6000 mm turning height: 4400 mm turning speeds: - U/min main drive motor: - kW Control: FAGOR 8055 workpiece weight max.: 100 t ram stroke each side: 1500 mm cross rail - adjustment: 3000 mm total power requirement: - kW weight of the machine ca.: - t dimensions of the machine ca.: - m equipped with: - CNC Control 8055 - 1ram on Crossbeam The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 3800 mm turning diameter over slide rest: 3200 mm turning length: 12000 mm faceplate diameter: 3100 mm steady: 2 bed width: 4000 mm turning speeds: 200 U/min workpiece weight: 90.000 kg total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Hydrostatik Spindellagerung Hydrostatik Lynette The tech. Data are manufacturer or operator information and therefore non-binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your  ...

spindle diameter: 160 mm x-travel: 10500 mm y-travel: 4000 mm spindle taper: ISO 50 z-travel: 950 mm turning speeds: 3,15-1000 U/min transmission ratio: 4 spindle power: 58 kW Support sleeve: 340x400 mm w-travel: 900 mm Feed: x 0,12-9600 mm/U Feed: y/z/w 0,1-5600 mm/U Plate area: 39,5 m² Plate: 5400x3500 mm Plate: 5900x3500 mm T-slot - distance: 365 mm T-slots: 35/75 mm Thickness of the plate: 360 Control: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The tech. Data are manufacturer or operator information and therefore non-binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or ...

faceplate diameter: 2950 mm swing diameter: 3200 mm turning height: 3500 mm table load: 20 t feed range: 3000 mm/min main drive motor: 70 kW milling drive: 16,1 kW Control: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m CNC-control FAGOR 8070 C-axis with 360,000 positions Milling head Inspection under power in the factory possible. Machine location is Spain. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 5500 mm swing diameter: 6000 mm turning height: 4400 mm Control: FAGOR 8055 cross rail adjustment: 3000 mm ram adjustment: 1500 mm workpiece weight: 100 t faceplate speeds:: 1 - 25 U/min total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Retrofit in 2015 with CNC-control FAGOR 8055 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 5850 mm y-travel: 2500 mm z-travel: 1000 mm Control: 840D sl feeds x- + y-axis: 20 m/min feeds z-axis: 20 m/min acceleration: 5 m/qs spindle drive - main spindle: 60 kW spindle turning speed - stepless: 24.000 U/min max. torque on the working spindle: 87 Nm tool taper: HSK-A63/F80 c-axis: +/- 360 grad a- axis: +/- 100 grad tool changer: 20 stück coolant tank: 2300 l chip conveyor: surface area: 6.0002.500 mm number of T-slots: 18 flute distance: 125 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: 14,8x7,3x5,8 m Machine table Width 2,500 mm Length 6,000 mm Number of T-slots 20 Distance of T-slots 125 mm Dimensions of T-slots 18H8 mm Max. table load 8,000 kg Travels Cross rail: X axis 5,850 mm Cross slide: Y axis, horizontal 2,500 mm Z axis, vertical 1,000 mm Feeds X-, Y- and Z-axes ...

spindle taper: 2 x SK 40 forward bearing diameter: 110 mm milling head speed: 100 - 4500 U/min milling drive: 5,1 kW workpiece length - max.: 830 mm workpiece dia. with double equipment: max. 135 mm taper diameter: 78 g6 mm centre height: 260 mm turning speed range - stepless: max. 15 U/min distance of spindles: 135 mm spindle nose: DIN 55026 Gr. 5 : : stroke of workpiece slide: 810 mm Feed speed: max. 6 m/min. surface area: 200 x 1750 mm : tool post (Z-axis): stroke of tool slide: 120 mm Feed speed: max. 2 m/min. column movement: 200 mm : tail stock: tailstock quill stroke: 100 mm morse taper: 3 MK centre height: 260 mm axial distance of the quills: 135 mm passage of steadyrest: 40 - 80 mm control: SIEMENS SINUMERIK 810 weight of the machine ca.: 6,5 t with SIEMENS-control SINUMERIK 810/820 acc.: NC-dividing unit with back stop, various toolholders, steadies, running centres, coo ...

faceplate diameter: 2500 mm Thickness: 240 mm T-slot - distance: 175 mm total power requirement: . kW weight of the machine ca.: . kg dimensions of the machine ca.: . m Optional with 4 jaws €3750 The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 2500 mm Thickness: 240 mm T-slot - distance: 175 mm total power requirement: . kW weight of the machine ca.: . kg dimensions of the machine ca.: . m Optional with 4 jaws €3750 With bed from Schiess KZ 250 Optionally, a Schiess KZ 250 drive gear can be purchased for €9,500 The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created ...

faceplate diameter: 1800 mm turning height: 1600 mm turning diameter over bed: 2150 mm turning speeds: 3,15 - 250 U/min voltage: 400 V total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 2500 mm turning height: 1500 mm turning diameter over bed: 2700 mm turning speeds: 1,9 - 60 (16x) U/min voltage: 380 V total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter:2500 mm swing diameter:2500 mm swing diameter:2500 mm turning height:2500 mm turning speed range - faceplate:1,8 - 140 U/min workpiece weight max.:15.000 kg feeds: 0,03 - 6,3 mm/U rapid speed:2 m/min cross rail adjustment:2150 mm max. ram stroke:1500 mm power capacity:55 kW weight of the machine ca.:32 t dimensions of the machine ca.:4,1 x 7,6 x 6,0 m 1 turret head 1 RAM head

faceplate diameter:1600 mm swing diameter:1800 mm turning height:1500 mm max. ram stroke:1200 mm faceplate turning speed range -stepless-:2,5 - 250 U/min workpiece weight max.:10.000 kg ram head dimension:240 x 240 mm feed range:1 - 3000 mm/min power capacity:45 kW weight of the machine ca.:20 t modernized and overhauled in 2010 with CNC SIEMENS 840 D 12 positions automatic toolchanger telescopic covers splash guarding chip conveyor coolant attachment diverse toolholders

Made in Italy machine according to DIN 8606 Tip height: 260 mm Turning diameter over bed: 520 mm Swing over carriage: 300 mm Centre distance: 1500 mm Bed width: 400 mm Spindle bore: 82 mm Spindle nose: Camlock 8 " Spindle speeds: (24) 9-1600 rpm (option 11-2000 U/min) Engine output: 5.5 kW (option: 7.5 kW) feed Z-axis: (93) 0.028 6.43 mm / Rev Feed x axis: (93) 0.012 2.73 mm / Rev Thread, metric: (54) 0.5-224 mm Thread, Witworth: (55) 72 - 1/8 TPI Thread, module: (54) 0.5-112 mm Thread, Diametral Pitch: (54) 64 - 1/4 D.P.. Cross slide Lxw: 650 x 230 mm Transversal carriage stroke: 340 mm Upper carriage Lxw: 350 x 150 mm Upper carriage stroke: 150 mm Tailstock Quill diameter: 85 mm Tailstock Quill stroke: 200 mm Tailstock taper: MK 5 Weight: 3,100 kg Facilities: -Movement of the tailstock pneumatically supported -Acceptance Protocol according to DIN 8605, ...

Tip height: 330 mm centre distance: 1500 mm circular diameter: bed 690 mm spindle bore: 82 mm spindle retainer: short taper size 8 taper tailstock: 6 MK spindle speed: 7.1-1400 rpm feeds: longitudinal/plan 0.05 112/0.025 56 mm / U thread pitches: 0.25-560 mm electrical connection: 380 V, 15 kW space: 3350 x 1800 x 1400 mm weight: 4800 kg

Tip height: about quilt 300 mm centre distance: 1500 mm circular diameter: upper bed 640 mm spindle bore: 67 mm spindle retainer: Gr. 8 taper tailstock: 5 MK spindle speed: 18 - 900 rpm feeds: longitudinal/plan 0.063 0.032 2.1 mm / U thread pitches: 0.5-14 mm electrical connection: 380 V, approx. 7.5 kW space: 1550 x 3100 x 1250 mm weight: approx. 3500 kg hardly used and therefore well-preserved bed lathe

Made in Italy machine according to DIN 8605: lathe with increased accuracy. Tip height: 215 mm Turning diameter over bed: 430 mm Swing over carriage: 240 mm Top width: 1,000 mm Bed width: 290 mm Spindle bore: 52 mm Spindle nose: Camlock 6 " Spindle speeds variable: 6 Spindle speeds: 60-2,000 rpm S6/S1 engine power: 4 kW (option: 5.5 kW) feed Z-axis: (38) 0.05 - 1.88 mm / Rev Feed x axis: (38) 0.02 1,084 mm / Rev Thread cutting, metric: (30) 0.45-20 mm Thread cutting, Witworth: (35) 80-1 3/4 TPI Thread cutting, module: (25) 0.25-10 mm Thread cutting, Diametral Pitch: (30) 160-3 1/2 D.P.. Cross slide Lxw: 370 x 190 mm Transversal carriage stroke: 240 mm Upper carriage Lxw: 275 x 115 mm Upper carriage stroke: 120 mm Tailstock Quill diameter: 60 mm Tailstock Quill stroke: 135 mm Tailstock taper: MK 4 Weight: approx. 2,000 kg Facilities: -Infinitely variable  ...

Precision lathe with cycle automatic Make: Hamlet Model: E 70 x 2000 Year of construction: 1997 For food and feed shaft machining Technical data: Workspace Turning length: 2000 mm Swing over bed: 720 mm Swing over cross slide plan: 430 mm Displacement of the plan slide: 410 mm Bed width: 480 mm 3prpek3uq Spindle nose ACC. to DIN 55027: size 11 Spindle diameter in front bearing: 150 mm Spindle bore: 106 mm Inside taper of the main spindle: 112 metric Control: Siemens 805 Spindle gearbox newly stored according to the manufacturer ca. 2.500 EUR

Made in Italy Peak: 300 mm Rotary diameter over bed: 600 mm Rotary diameter via sled: 380 mm Peak: 1,500 mm Bed width: 400 mm Spindle bore: 82 mm Spindle nose: Camlock 8 " Spindle speeds: (12) 16-1200 U/min Engine power: 9.2 kW (special equipment/standard: 7.5 kW) Reprimor Z-axis: (93) 0.028-6.43 mm/U Feed X-axis: (93) 0.012-2.73 mm/U Thread, metric: (54) 0.5-224 mm Threads, Witworth: (55) 72-1/4 x8 TPI Thread, module: (54) 0.5-112 mm Threads, Diametral Pitch: (54) 64 -1/4 D.P. Crossleigh hub: 340 mm Oberslitten hub: 150 mm Riding stock pinol diameter: 85 mm Riding stove pinol stroke: 200 mm Ridstock cone: MK 5 Weight: About 3,200 kg Facilities: -3-axis digital display -Step-by-step speed adjustment -Automatic lubrication of the management railways -LED lighting -Micrometer bed strike -9.2 kW engine instead of 7.5 kW -Quick change holder system mul ...

Tip width: 700 mm Tip height: 150 mm Circulation diameter over bed: 300 mm Bed width: 180 mm Spindle bore: 38 mm Mounting in the spindle bore: MK 5 Speed range, infinitely variable: 30 - 450 / 150 - 3000 rpm Range of longitudinal feeds: (14) 0.07 - 0.65 mm/U Area of plan feeds: (11) 0.03 - 0.12 mm/U Metric threads: (18) 0.2 - 3.5 mm Inch Thread: (21) 8 - 56 Gg/1" Pinole path: 85 mm Pinole holder: MK 3 Engine power S1 100%: 1.5 kW / 400 V Motor recording power S6 40%: 2.2 kW / 400 V Machine dimensions (W x D x H): 1380 x 640 x 500 mm Weight approx.: 235 kg without base Delivery: - Digital display - 3-jaw chuck PO3-160 mm steel version - Feed flange 160 mm - Solid grain tips - Interchangeable wheels - Quick-release steel holder size 20-2 with 2 straight inserts - Slip clutch - Micrometer longitudinal stop - Plan sled with top support - Frequency inverter ...

1 x L+Z lathe Colchester Mascot 1600/600 Built: c.1975 Very stable lathe. Ideal machine for locksmiths or agricultural machine mechanics. Technical data: Turning diameter over crimson: 710 mm Turning diameter over bed:432 mm Turning diameter via support:267 mm Turning length: 1,000 mm Spindle speeds:20 - 1600 rpm Spindle bore:76 mm Drive motor:5.6 kW Feeds: 0.6 - 10 mm/u Metric threads: 40 (0.4 - 14 mm incline) Machine weight approx.:2000 kg Room requirements approx.:l:2.65 x w:1.1 x h:1.6 m Accessories: 3 - Jaw lining UVA 310 mm 4 Set of change jaws Bfraed8ae0 Tripan quick-change system 4 x Interchangeable holder running counter tip in tailstock (MK 5) Countertip in spindle Alternating wheels Manual Mudguard complete documentation The machine can be inspected at our warehouse in Reichenbach under electricity.

Stepless guide and pull spindle lathe TC 250 V Peak height: 250 mm Circulation diameter via slide: 350 mm Orbital diameter in the croation: 695 mm Tip width: 1500 mm Spindle nose: DIN 55029, Camlock, size 6 Bed width: 305 mm Cross slide path: 272 mm Upper slide path: 155 mm Spindle bore: 80 mm Speed range, infinitely variable: (3) 30 - 2200 rpm Whitworth Thread: (45) 2 - 72 TPI Metric Thread: (39) 0.2 - 14 mm Diametral Thread: (21) 8 - 44 D.P.I Module Thread: (18) 0.3 - 3.5 module Longitudinal feeds: 0.04 - 1.00 mm/U Flat feeds: 0.02 - 0.50 mm/U Engine power: 5.5 kW Dimensions LxWxH, approx.: 2900 x 1175 x 2040 mm Weight, approx.: 2,200 kg characteristics: - Toolmaker accuracy - Stepless speed control (3 pre-level steps) - Finely-balanced main spindle - Stable machine bed with hardened and ground guides - One-piece cast base - Adjustable precision cone roll ...

Machine details Stock number 1105-03330 Machine type guide and pull spindle lathe Make ERNAULT-SOMUA Type Cholet 550 Year of construction 1990 Control type conventional Storage location FRANCE Country of origin France Delivery time immediately Freight base EX WORK price Technical details Turning diameter over bed 550 mm Turning diameter via support 500 mm Turning length 1100 mm Tip height 250 mm Spindle bore 52 mm Inner cone 136 Spindle speeds 32-1800 rpm Feeds - bed slide / lengthwise 0.05-07 mm/w Feeds flat slide 0.033-0.45 mm/min Total power requirement 13 kW Weight of the machine ca. 2,3 t Space requirement approx. 2870 x 940 x 1400 m Information accessories: PARAT steel holder 4 STUCK 3 bake lining dia 250mm 2 AXIS DIGITAL

Maximum diameter to turn on the bench 2,110 mm Maximum diameter to turn on trolley 1,600 mm Maximum distance between platforms 12,830 mm Spindle hole diameter 155 mm Cone on spindle no. 120 metric Cone on spindle (with reduction) no. 6 clamps Cone on the counterpoint (6-bit reduction) no. 120 metrics Maximum stroke of the counterpoint 400 mm DSeed from the tool support plane to the axis of the 80 mm centers Main engine power 100 HP Spindle speed from 0.9 to 90 rpm with continuous variation Longitudinal feed no. 36: 0.2 to 12.8 Transverse advances No. 36: 0.1 to 6.6 Metric fillets #26: 1 to 42 Whitwoth fillets #17: 0.5 to 11 Quick forwards Maximum permissible load on the tips 50-60 ton Refrigerant liquid system

Peak height 2,600 mm Point distance 10,000 mm Closed bench 2,000x6,000 mm To be completed with CNC

Max length 8,000 mm Maximum turning diameter above wagon 1,250 mm Max vault over guides 1,650 mm Maximum turning diameter under spindle 2,000x700 mm Displayed – two axes

IN THE RETROFITTING PHASE Height tips 900 mm Point distance 7,000 mm Turnerable diameter on the bench 1,850 mm Turnerable diameter on trolley 1,350 mm Turnerable diameter on recess 2,150 mm Bench width 1,000 mm Bar passage diameter 206 mm ASA A1 15" spindle attachment Top speed 300 RPM Diameter of the tank counterpoint 220 mm Row stroke counterpoint 450 mm Withworth threads - metrics - diametrics - module Weight allowed between tips without lunettes 15 ton Weight allowed between tips with a 20-ton bezel

Height tips 220 mm Useful length 1,000 mm 42 mm bar pass

Equipped with no. 03 guides Overhauled with: guide grinding, CN conversion, new electrical and hydraulic system, hydraulic self-centering installation, shaving conveyor; CN Fagor 8055 Numerical Control – BT Maximum turnerable diameter 1800 mm 3-grife hydraulic self-centering with a diameter of 1450 mm with tightening force 30 Ton with 30 bar clamp L max turnerable 3000 mm Spindle engine power 110 Kw Maximum rotation speed 180 rpm Fast value axles 4000 mm/min M3/M4 Spindle Rotation Inversion Possibility 4 speed ranges Hydraulic counterpoint Maximum capacity of workpiece on counterpoint 12500 Kg It is currently possible to work details of up to 3000 mm length but the extension pallet is available to be able to work details up to 8 m in length. (un revised); Machine installed and working

Maximum turnerable diameter: 1040 mm Turning diameter above the wagon: 620 mm Maximum workable length: 5200 mm Spindle power: 40 kW CNC ECS Optical line measurement system Maximum flow between tips: 10 tons Machine complete with chip evacuator, 4-position hydraulic turret, safety shelters in compliance and spindle 3-jaw hydraulic self-centering AUTOBLOCK; Various accessories available (tool case, stretchers, lunettes...) EC 2018 remarking possibility

Platò diameter: 1300 mm Used lathe in good condition, available unless sold.

peak heights: 250 mm point distance: 1500 mm bar pass: 105 mm

Main technical data: - Tip distance: 6000 mm - Tip height: 640 mm - Lathe complete with spindle, tailstock and tool turret

Code 2841 Description Centerlathe Make Graziano Model SAG 12 Serial No. SAG 12 N 4475 Year 1976 Distance between centers 800 mm Swing over bed 320 mm Swing over gap 420 mm Swing over crossslide 176 mm Spindle bore 41 mm Number of spindle speeds 8 Spindle speeds 75-2000 rpm Feeds Longitude and cross Motor power 2 and 3 kW – 380 Volts Thread cutting Metric, W.W., Modul and D.P. Accessoiries 3 chuck Condition Machine is in normal condition.

Code 2876 Description Centerlathe Make Graziano Model SAG 12 Serial No. SAG 12 N 5150 Year 1980 Distance between centers 800 mm Swing over bed 320 mm Swing over gap 420 mm Swing over crossslide 176 mm Spindle bore 41 mm Number of spindle speeds 8 Spindle speeds 75-2000 rpm Feeds Longitude and cross Motor power 2 and 3 kW – 380 Volts Thread cutting Metric, W.W., Modul and D.P. Accessoiries 3 chuck Steadies Rapid toolpost Condition Machine is in normal condition.

Machine Details Warehouse number 1105-03364 Machine type lead and pull spindle lathe Make CAZENEUVE Type HB 525 X 1000 Year of construction 1965 Conventional control type Storage location HAGUENAU Country of origin France Delivery time Immediate Freight base EX WAREHOUSE Technical details Turning diameter over bed 500 mm Turning diameter via support 220 mm Turning length 1000 mm Spindle speeds 25-2000 rpm various accessories YES Information IN GOOD WORKING CONDITION LOT OFF ACCESSORIS WITH MULTIFIXE TOOL HOLDER SYSTEMS

Tip height: 250 mm Center width: 1500 mm Circulation Ø: over bed 500 mm Spindle bore: 63 mm Spindle holder: Size 8 Mounting cone tailstock: 5 MK Spindle speeds: 170 - 2240 rpm Feeds: longitudinal/flat 0.014-1/0.0063-0.45 mm/U Thread pitches: 0.1 - 112 mm electrical connection: 380 V, 7.5 kW Space requirement: 2300 x 1000 x 1400 mm Weight: 2360 kg

Figure shows MIOTAL® TC 180 x 1000 Center width: 750 mm Center height: 165 mm Orbit diameter over bed: Ø 330 mm Bed width: 190 mm Travel cross slide: 160 mm Travel upper carriage: 90 mm Spindle connection: DIN 55029 (Camlock) D 1 - 4 Spindle bore: Ø 40 mm chuck diameter: Ø 200 mm Spindle speed, infinitely variable: 30 - 2000 rpm Mechanical counters: 3 Motor power: 2.2 kW Longitudinal feeds Z: (40) 0.044 - 1.96 mm/rev Feed rates X: (40) 0.022 - 0.98 mm/rev Thread Metric: (32) 0.4 - 7.0 mm Thread inch: (32) 4 - 56 gg/inch Thread module: (32) 0.4 - 7,0 Diametrical thread: (32) 7.5 - 112 Quill diameter tailstock: Ø 40 mm Inner cone of the quill tailstock: MK 3 Quill stroke: 100 mm Lateral adjustment: ± 10 mm Weight, approx.: 650 kg Characteristics: - Acceptance protocol according to DIN - Precise, hardened and ground guides - Robust headstock with circula ...

Center height: 205 mm Orbit diameter over bed: 410 mm Center width: 1000 mm Bed width: 260 mm Spindle nose: DIN 55029 (Camlock) 9, size 6 Travel cross slide: 220 mm Travel upper slide: 125 mm Spindle bore: 52.5 mm Spindle speeds: 20 - 3000 min-1 Speed control: Infinitely variable Mechanical counters: 2 Motor power: 3.75 kW Coolant pump: 0.13 kW Longitudinal feeds Z: 0.05 - 1.7 mm/rev Face feeds X: 0.025 - 0.85 mm/rev Whitworth Thread: (45) 2 - 72 TPI Metric threads: (39) 0.2 - 14.0 mm Diametric thread: (21) 8 - 44 DP Module thread: (18) 0.3 - 3.5 MP Quill diameter: 52 mm Inner cone quilt: MK 4 Quill stroke: 150 mm Dimensions: 2270 x 1120 x 1900 mm Weight, approx.: 1500 kg Characteristics: - Tool mesh accuracy according to DIN 8605 - Infinitely variable speed control (2 countershafts) - Finely balanced main spindle - Stable machine bed with hardened and gro ...

Center width: 1000 mm Center height: 178 mm Orbit diameter over bed: Ø 356 mm Bed width: 190 mm Travel cross slide: 160 mm Travel upper carriage: 90 mm Spindle connection: DIN 55029 (Camlock) D 1 - 4 Spindle bore: Ø 40 mm chuck diameter: Ø 200 mm Spindle speed, infinitely variable: 30 - 2000 rpm Mechanical counters: 3 Motor power: 2.2 kW Longitudinal feeds Z: (40) 0.044 - 1.96 mm/rev Feed rates X: (40) 0.022 - 0.98 mm/rev Thread Metric: (32) 0.4 - 7.0 mm Thread inch: (32) 4 - 56 gg/inch Thread module: (32) 0.4 - 7,0  Diametrical thread: (32) 7.5 - 112  Quill diameter tailstock: Ø 40 mm Inner cone of the quill tailstock: MK 3 Quill stroke: 100 mm Lateral adjustment: ± 10 mm Weight, approx.: 750 kg Characteristics: - Acceptance protocol according to DIN - Precise, hardened and ground guides - Robust headstock with circulating oil lubrication, precision-be ...

Center height: 315 mm Center width: 1000 mm Circulating Ø: 630 mm Spindle bore: 74 mm Spindle holder: Size 8 Pick-up cone tailstock: 5 MK Spindle speeds: 7 - 710 rpm Feeds: longitudinal/flat 0.063-4/0.030-2 mm/rev Thread pitches: 1 - 14 mm electrical connection: 380 V kW Space requirement: 2750 x 1250 x 1380 mm Weight: approx. 4200 kg

Main technical data: Center height: 560 mm Distance between centers: 5000 mm Bar passage: 105 mm The lathe is in good condition, being cleaned and visible at Ns. site.

Technical data of the parallel lathe Kramatorsk mod. 1A670 used: - Diameter on the bench: 2500 mm - Diameter above wagon: 2200 mm - Spindle diameter: 2500 mm - Distance between tips: 19000 mm - Pallet width with 4 guides: 2300 mm - Weight allowed between the tips: 100 tons - Speed: from 0 to 130 RPM - Motor power: 140 kW - Tailstock cast: Ø 400 mm - New transverse axis ball screws X: Ø 80 mm - CNC: FAGOR 8055 TC - Weight: 150 ton - Dimensions: 25 x 4 x 3.3 m

Code 211321230614 Description Centerlathe Make ICOCA Model SJ – 410 x 1000 G Serial No. 8708004 Year 1987 Distance between centers 1000 mm Swing over bed 410 mm Swing over gap 650 mm Swing over cross slide 220 mm Spindle bore 51 mm Number of spindle speeds 12 Spindle speeds 40 – 2000 rpm Feeds Longitude and Cross Motor power 5 kW – 380 Volts Thread cutting Metric, W.W. Accessoiries 3 chuck Ø 230 mm Rapide toolpost Coolant Condition Machine is in very good condition

A Weiler Primus precision lathe with milling device is offered and extensive accessories in very good condition. A large part of the accessories are unused. Specifications: Center height 120 mm Distance between centers 420 mm Swing diameter over bed 245 mm Spindle bore 23 mm Spindle speeds 18 Speed range 60 - 3000 rpm Motor power 1.1 / 1.5 kW Motor spindle brake Large feed protection - chip protection hood External dimensions approx. Length 120cm Depth 750mm Height 170cm Weight approx. 500 kg Accessories: Multifix A - 5 steel brackets 3-jaw chuck Ø 125 mm 4-jaw chuck Ø 125 mm Various interchangeable jaws Thumper CGN-1969 Eccentric lathe chuck 80mm (unused) Face plate Carrier for rotary heart Standing bezel Moving bezel Collets for internal and external clamping Various moving bezels Extensive accessories for milling equipment such as clamping screws, cl ...

Key data: 165 mm, 750 mm, 2800 U/min

Manufacturer: Gildemeister Model N.E.F. 320 K Year of construction 2004 Condition Used Siemens control system Specifications Circulation diameter 320 mm Turning length 750 mm Speed range - main spindle 3500 rpm Drive power - main spindle 9 kW Bar diameter 50 mm Tool holder Multifix size B Tailstock mount MK 4 Rapid traverse X / Z 8 / 10 m/min Machine weight approx. 2.5 t Space requirement approx. 2500 x 1800 x 1885 mm Accessories: 3 Jaw chuck Forkardt 200 Tool package Documentation

Key data: 650 mm, 1300 mm, 1 U/min

Circulation diameter over bed 1300 mm, over support 1000 mm Center width 6000 mm Bore 130 mm Speed 1.6 - 630 1/min, infinitely variable in 3 ranges Longitudinal feeds 0.09 - 5 mm/rev Thread metr. 0.56 - 128 mm Thread inches 64 - 0.28 g/" Tailstock quill travel 250 mm Total connected load approx. 52 kW Rapid traverse Rotating bezel 2 fixed bezels closed 1 fixed bezel open Coolant tank with pump
