schiess boring mills and machining centers used for sale

Technical data of used Schiess Froriep Boring Machine: CNC: Siemens 840 D Maximum transversal travel X axis: 13.770 mm Maximum vertical travel Y axis: 5.000 mm Z axis: 1.780 mm W axis: 950 mm V axis rotating support plane: 2.000 mm Rotating table dimensions: 5.000 x 3.500 mm Fixed table dimensions: 7.500 x 4.300 mm Maximum permissible load on the table: 120 ton Spindle power: 100 kW Spindle revolutions per minute: 710 rpm

Travel X-axis 9,500 mm Y-axis 4,100 mm Z-axis 950 mm W-axis 900 mm Main spindle speeds (infinitely adjustable): 3.15 - 1000 rpm Spindle motor power 58 kW Feed speed (infinitely adjustable): X-axis 0.1 - 9600 mm/min Y-axis 0.1 - 5600 mm/min Z-axis 0.1 - 5600 mm/min W-axis 0.1 - 5600 mm/min Accessories: Plate field: 6 x 4 m (CNC-controlled B- and V-axis) Table: 2 x 2 m (CNC-controlled B- and V-axis)

spindle diameter: 225 mm x-travel: 8000 mm y-travel: 5600 mm z-travel: 2100 mm w-axis: 1400 mm spindle turning speed - stepless: 0-650 U/min spindle taper ISO: 60 feed stepless: 5 - 3000 mm/min rapid traverse: 5 m/min weight of the machine ca.: 150 t dimensions of the machine ca.: 12 x 5 x 8 m total power requirement: 120 kW Ram type horizontal boring machine was reconditioned and modernized in 2006, original yom was 1972. Control Siemens 840 C. Machine will come with tools and a vertical milling head. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

spindle diameter: 225 mm x-travel: 8000 mm y-travel: 5600 mm z-travel: 2100 mm w-axis: 1400 mm spindle turning speed - stepless: 0-650 U/min spindle taper ISO: 60 feed stepless: 5 - 3000 mm/min rapid traverse: 5 m/min weight of the machine ca.: 150 t dimensions of the machine ca.: 12 x 5 x 8 m total power requirement: 120 kW Ram type horizontal boring machine was reconditioned and modernized in 2006, original yom was 1972. Control Siemens 840 C. Machine will come with tools and a vertical milling head. The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production li ...

Ref. -No.: 10362 Manufacturer: SCHIESS Year of construction: 2023 Type of control: CNC Control: Siemens - Heidenhain - Fanuc (configurable) Storage location: Halberstadt Country of origin: Germany financing: nach Anfrage Spindle Speed Max.: 3500 RPM Pallet diameter: 1600 mm Max. machining diameter: 2000 mm Number of claw boxes: 4 pc Clamping force per claw box: 55 kN Number of radial T-slots: 8 Max. speed for turning: 140 min-1 Max. speed for milling: 5 min-1 Max. torque for turning: 27000 Nm Max holding power: 36 kN positioning speed: 3000 mm Adjustment from center to right: 850 mm Shift from center to right (head and tool change): 2750 mm Adjustment from center to left: 850 mm Max feed rate: 2000 mm / min Max rapid traverse speed: 20000 mm / min Max. Feed force: 30 kN cross-section: 280 x 240 mm Max. cutting force when turning: 36 kN Max Spindle Torque: 1200 Nm Pressure: 6 bar Air requ ...

Ref. -No.: 10361 Manufacturer: SCHIESS Year of construction: 2023 Type of control: CNC Control: Siemens, Heidenhain, Fanuc - Configurable as required Storage location: Halberstadt Country of origin: Germany financing: nach Anfrage Support sleeve diameter: 130 mm X-Travel: 3000 mm Y-Travel: 2000 mm Z-Travel: 1600 mm Spindle stroke: 800 mm B-Axis: 360 ° W-Axis: 800 mm Spindle Taper: SK50 Max. Tool Weight: 25 kg Clamping Area: 1250 x 1250 (or configurable as required) mm T - groove width: 22 mm T - slot spacing: 160 mm Swivelling: Configurable as required ° Numbers Of Tools In Magazin: 40, 60, 120, 200, 240 Spindle Speed: 2900 RPM Max. Torque: 2500 Nm Drive Capacity - Spindle Motor: 41 kW

Table 486 x 280 mm, X/Y/Z = 300/200/300 mm

Jig

Control SIEMENS Sinumerik 840D Specifications: Workspace - Max. rotation and turning diameter 2,000 mm - Max. turning height 2,000 mm - Face plate diameter 1,600 mm - Max. face plate load 11,200 kg - Chisel slide travel (vertical) 1,400 mm Smallest plunger diameter 330 mm Plunger cross-section 250 x 210 mm - Drive power of the main motor 71 kW - Crossbar adjustment 1,170 mm - Crossbeam support of central face plate to the right 1,170 mm - From the middle of the face plate to the left 25 mm Speed of faceplate: - Number of transmission stages 2 - 1 level 3.15-80 min-1 - 2 Level 12.5-315 min-1 - Lifter and support hydrostatically guided Feeds - X and Z 0.1 2000 mm/min - Rapid traverse X and Z 6,000 mm/min - Weight approx. 24,000 kg - Voltage 400 V 50 Hz - Connected load 175 kW - Space requirement L = 10,000 mm B = ...

Specifications Control Siemens Sinumerik 840 Dsl Main dimensions and travels Face plate diameter 3,500 mm Circumferential diameter (max.) 4,000 mm Workpiece height (max.) 3,000 mm Total height of the machine 7,250 mm Maximum workpiece weight 50,000 kg Table base Y Horizontal table displacement 2,000 mm Crossbar Vertical adjustment of the crossbeam 1,500 mm in 50 steps Crossbeam Support (Right) Horizontal adjustment support -25 + 2170 mm Vertical displacement of the chisel slide 1,800 mm Cross-section of the chisel slide 250x210 mm Tool Stations Crossbeam Support (Left) Horizontal adjustment support -25 + 2170 mm Vertical displacement of the chisel slide 1,800 mm Cross-section of the chisel slide 250x210 mm Tool Changer Main Drive: Main motor power 100 kW Face plate speed range 1-100 rpm. Maximum torque at the face plate 100  ...

Plate diameter 4200 mm Maximum turning diameter 4600 mm Max workpiece height under the cross member 4000 mm Max workpiece weight 100 t Travel RAM horizontal 2600 mm / min Travel RAM vertical 2000 mm / min Tool holder (powered tools) ISO 50 Table speed 40 rpm Main drive 120 kW Number of gear stages 4 Total connection value 180 kW Max torque on the flat disc 40000 kpm Max cutting force per support 10000 kp Crossbar support right and left Largest vertical path of the Chisel slider 2000 mm Cross-section of the chisel slider 285 x 310 mm Adjustment path of the crossbar 3500 mm Total weight of the machine 115,800 kg Accessories Automatic lubrication of the cross-bar guide on the stand Hydraulic weight compensation of the chisel sliders Milling spindle and C-axis c-axis 360,000 positions

Key data: 4000 mm, 5000 mm

Specifications Control SIEMENS SINUMERIK 840 Dsl Main dimensions and travels Face plate diameter 4,000 mm Circumferential diameter (max.) 5,000 mm Workpiece height (max.) 5,000 mm Total height of the machine 9,250 mm Maximum workpiece weight 80,000 kg Table base Y Horizontal table displacement 2,500 mm Crossbar Vertical adjustment of the crossbeam 3,200 mm in 50 steps Crossbeam Support (Right) Horizontal adjustment support - 2740 + 2740 mm Vertical displacement of the chisel slider 1,800 mm Cross-section of the chisel slider 250x210 mm Side Support (Right) Vertical adjustment support -25 + 2170 mm Horizontal displacement of the chisel slider 1,000 mm Cross-section of the chisel slider 250x210 mm Turning diameter max./min. 4,500/2,500 mm Main Drive: Main motor power 100 kW Face plate speed range 0.63 – 63 rpm. Maximum torque at the  ...

faceplate diameter: 2500 mm swing diameter: 3200 mm turning height: 3100 mm Control: R&D type: MTC 2x-2 workpiece weight: 20000 kg slide adjustment: 1600 mm side head - cross travel: 1000 mm Tool changer: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 1800 mm turning height: 1600 mm turning diameter over bed: 2150 mm turning speeds: 3,15 - 250 U/min voltage: 400 V total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: 0 bore depth: 10000 mm number of spindles: 0 Control: Siemens Simatic Touch SPS swing over bed: 1050 mm swing diameter over bed slide: 1600 mm boring diameter: 50 - 310 mm centre height: 800 mm speeds:: 2,5 - 400 total power requirement: 74 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

4 pcs. rope pulleys for counter weight of a FB 225 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 220 mm turning length: 200 mm control: Siemens Sinumerik total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Description SHOOTING FRORIEP 40Dv Carousel Lathe. Modernized in 1998, among other things, a driven tool system (C-axis) was installed and the control was modernized to 840 C. Details Serial number 11330051 Year of construction 1980 Control SIEMENS electrical connection 400 V Face plate diameter 3,500 mm Workpiece height 3,000 mm Face plate over corridor 160 mm Total power requirement 71 kW Space requirement approx. 13 x 6 m Reconstruction 1998

Clamping claw box made of solid steel GR 9 (new) 4 pieces

pitch taper:50 Aufnahme Detailed price on request depense on version and nos. ca. 500 - 1500 EUR + VAT /piece Diverse toolholders matching SCHIESS-VTL´s with SK 50 taper and T-slot clamping design! Diverse fixed boring bars in different dia. and length. Diverse boring bar adapter plates to adapt different boring bars. Diverse normal toolholders for toolshank 40 mm in version left or right

turning diameter over bed:3800 mm turning diameter over slide rest:3200 mm turning length:12000 mm faceplate turning speed range -stepless-:2 - 200 U/min max. workpiece weight:90.000 kg bed width:4000 mm 2 steadies

table length: 3000 mm table width: 3000 mm table load: 25 t total power requirement: kW weight of the machine ca.: t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Stock number 1210059 Machine Type Rotary Table Make SCHIESS Type 25/30 Control type X-way (mm) 2,000 Table dimensions (mm) 3,000 x 2,500 Table swivel (degrees) 360 Information Max. table load 40 ton

turning diameter: 1.600 mm max. swing diameter: 1.700 mm control: Siemens - 840D faceplate turning speed range: 1 - 320 U/min rapid traverse: 3.000 mm / min feed range: 1 - 3.000 mm/min size of pallet: 1.168 mm numbers of pallets: 2 main drive: 55 kW Vertical turret lathe with cnc | SCHIESS MOWEG - BERTHIEZ TFM 125 has been overhauled by SCHIESS MOWEG (RETROFIT) in 2007. The machine video from the production plant will be shared on request. The machine is in a well-maintained condition and can be inspected under power at any time in the Swiss factory location. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: TFM125 | TFM-125 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 1200 mm swing diameter: 1600 mm turning height: 1250 mm slide adjustment: 800 mm Control: Siemens type: 840 c power capacity: 56 kW : total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 1600 mm swing diameter: 2000 mm turning height: 1600 mm Control: Siemens Sinumerik 805 turning speeds: 1-250 U/min Table load: 12000 kg Control system manufacturer Siemens type Sinumerik 805 Accessories and cabinets can be purchased optionally The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solu ...

faceplate diameter: 1600 mm swing diameter: 1800 mm turning height: 1500 mm control: Siemens chip conveyor: Tool changer: type: 840 D mm workpiece weight: 10000 kg slide adjustment: 1000 mm ram head dimension: 240x240 mm turning speeds: 250 U/min main drive: 45 kW Accessories and cabinets can be purchased optionally The tech. Data are manufacturer or operator information and therefore non-binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data fo ...

spindle diameter: 180 mm x-travel: 8000 mm y-travel: 4000 mm Control: Siemens type: Sinumerik System 3 ram: horizontal adjustment: 800 mm Spindle travel W-axis: 1400 mm ram: diameter: 220 mm engine output: 75 kW turning speeds: 900 U/min Plate area: 8000x6000 mm angular milling head: total power requirement: kW weight of the machine ca.: t Overhauled in 1983 The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your  ...

Control Siemens ... Sinumerik 840 D Max.workpiece diameter ... 3200mm Turntable diameter ... 3000mm Max.table load... 14000kg Max. workpiece height ... 2200mm Axis Z ... 1155mm Max. workpiece weight ... 14000 kg Main engine power ... 81 kW Floor space... DXŠXV 7200x6400x6600mm The machine is in very good condition,

faceplate diameter: 1250 mm swing diameter: 1500 mm turning height: 1250 mm Control: Siemens type: 840 Dsl tool taper: 4 Pos. total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The machine was overhauled in 2015 by Matuschek. Siemens 840 DSL Shop Turn The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with  ...

- set off 4 heavy duty jaws for SCHIESS FRORIEP DV DF DZ DKE - Jaw width 90 mm - Jaw height 75 mm - Hole to hole jump length ways 125 mm - Hole to hole jump in width 250 mm

- set off 4 heavy duty jaws for SCHIESS FRORIEP DV DF DZ DKE - Jaw width 90 mm - Jaw height 75 mm - Hole to hole jump 125 mm

faceplate diameter: 2950 mm swing diameter: 3200 mm turning height: 3500 mm turning speeds: U/min main drive motor: 70 kW Control: FAGOR 8070 workpiece weight max.: 20 t column daylight: 3300 mm milling motor: 16 kW feeds crossrail-slide vertical: 3000 mm/min feeds crossrail-slide horizontal: 3000 mm/min total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m equipped with: - CNC Control FAGOR 8070 - C-axis (angular positioning of the table) - angular milling Head - Telescopic covers of the cross rail and columns guideways - Chip Conveyor The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 5500 mm swing diameter: 6000 mm turning height: 4400 mm turning speeds: - U/min main drive motor: - kW Control: FAGOR 8055 workpiece weight max.: 100 t ram stroke each side: 1500 mm cross rail - adjustment: 3000 mm total power requirement: - kW weight of the machine ca.: - t dimensions of the machine ca.: - m equipped with: - CNC Control 8055 - 1ram on Crossbeam The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 3800 mm turning diameter over slide rest: 3200 mm turning length: 12000 mm faceplate diameter: 3100 mm steady: 2 bed width: 4000 mm turning speeds: 200 U/min workpiece weight: 90.000 kg total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Hydrostatik Spindellagerung Hydrostatik Lynette The tech. Data are manufacturer or operator information and therefore non-binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your  ...

spindle diameter: 160 mm x-travel: 10500 mm y-travel: 4000 mm spindle taper: ISO 50 z-travel: 950 mm turning speeds: 3,15-1000 U/min transmission ratio: 4 spindle power: 58 kW Support sleeve: 340x400 mm w-travel: 900 mm Feed: x 0,12-9600 mm/U Feed: y/z/w 0,1-5600 mm/U Plate area: 39,5 m² Plate: 5400x3500 mm Plate: 5900x3500 mm T-slot - distance: 365 mm T-slots: 35/75 mm Thickness of the plate: 360 Control: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The tech. Data are manufacturer or operator information and therefore non-binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or ...

faceplate diameter: 2950 mm swing diameter: 3200 mm turning height: 3500 mm table load: 20 t feed range: 3000 mm/min main drive motor: 70 kW milling drive: 16,1 kW Control: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m CNC-control FAGOR 8070 C-axis with 360,000 positions Milling head Inspection under power in the factory possible. Machine location is Spain. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 5500 mm swing diameter: 6000 mm turning height: 4400 mm Control: FAGOR 8055 cross rail adjustment: 3000 mm ram adjustment: 1500 mm workpiece weight: 100 t faceplate speeds:: 1 - 25 U/min total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Retrofit in 2015 with CNC-control FAGOR 8055 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 5850 mm y-travel: 2500 mm z-travel: 1000 mm Control: 840D sl feeds x- + y-axis: 20 m/min feeds z-axis: 20 m/min acceleration: 5 m/qs spindle drive - main spindle: 60 kW spindle turning speed - stepless: 24.000 U/min max. torque on the working spindle: 87 Nm tool taper: HSK-A63/F80 c-axis: +/- 360 grad a- axis: +/- 100 grad tool changer: 20 stück coolant tank: 2300 l chip conveyor: surface area: 6.0002.500 mm number of T-slots: 18 flute distance: 125 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: 14,8x7,3x5,8 m Machine table Width 2,500 mm Length 6,000 mm Number of T-slots 20 Distance of T-slots 125 mm Dimensions of T-slots 18H8 mm Max. table load 8,000 kg Travels Cross rail: X axis 5,850 mm Cross slide: Y axis, horizontal 2,500 mm Z axis, vertical 1,000 mm Feeds X-, Y- and Z-axes ...

spindle taper: 2 x SK 40 forward bearing diameter: 110 mm milling head speed: 100 - 4500 U/min milling drive: 5,1 kW workpiece length - max.: 830 mm workpiece dia. with double equipment: max. 135 mm taper diameter: 78 g6 mm centre height: 260 mm turning speed range - stepless: max. 15 U/min distance of spindles: 135 mm spindle nose: DIN 55026 Gr. 5 : : stroke of workpiece slide: 810 mm Feed speed: max. 6 m/min. surface area: 200 x 1750 mm : tool post (Z-axis): stroke of tool slide: 120 mm Feed speed: max. 2 m/min. column movement: 200 mm : tail stock: tailstock quill stroke: 100 mm morse taper: 3 MK centre height: 260 mm axial distance of the quills: 135 mm passage of steadyrest: 40 - 80 mm control: SIEMENS SINUMERIK 810 weight of the machine ca.: 6,5 t with SIEMENS-control SINUMERIK 810/820 acc.: NC-dividing unit with back stop, various toolholders, steadies, running centres, coo ...

faceplate diameter: 2500 mm Thickness: 240 mm T-slot - distance: 175 mm total power requirement: . kW weight of the machine ca.: . kg dimensions of the machine ca.: . m Optional with 4 jaws €3750 The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 2500 mm Thickness: 240 mm T-slot - distance: 175 mm total power requirement: . kW weight of the machine ca.: . kg dimensions of the machine ca.: . m Optional with 4 jaws €3750 With bed from Schiess KZ 250 Optionally, a Schiess KZ 250 drive gear can be purchased for €9,500 The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created ...

faceplate diameter: 1800 mm turning height: 1600 mm turning diameter over bed: 2150 mm turning speeds: 3,15 - 250 U/min voltage: 400 V total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter:2500 mm swing diameter:2500 mm swing diameter:2500 mm turning height:2500 mm turning speed range - faceplate:1,8 - 140 U/min workpiece weight max.:15.000 kg feeds: 0,03 - 6,3 mm/U rapid speed:2 m/min cross rail adjustment:2150 mm max. ram stroke:1500 mm power capacity:55 kW weight of the machine ca.:32 t dimensions of the machine ca.:4,1 x 7,6 x 6,0 m 1 turret head 1 RAM head

faceplate diameter:1600 mm swing diameter:1800 mm turning height:1500 mm max. ram stroke:1200 mm faceplate turning speed range -stepless-:2,5 - 250 U/min workpiece weight max.:10.000 kg ram head dimension:240 x 240 mm feed range:1 - 3000 mm/min power capacity:45 kW weight of the machine ca.:20 t modernized and overhauled in 2010 with CNC SIEMENS 840 D 12 positions automatic toolchanger telescopic covers splash guarding chip conveyor coolant attachment diverse toolholders

Boring power:10 mm weight:590 kg connected load:2 kW dimensions::1500 x 1300 x 2300 mm

Shell end mills, shell mill cutters, milling cutters, disc milling cutters, slot milling cutters -Disc milling cutter: 105 x 19 mm, cross-cut -Socket: Ø 27 mm -Weight: 0.8 kg

Retrofitted in 2005 electrical / CNC control Siemens 840 d Retrofitted in 2012 and 2019 mechanical what made. Technical datas: Rotary spindle speed: 1.25-600 tr/min Spindle maximum power: 55 kW 215 tr/min Horizontal run of the upright on the bench - X 15,000/30,000 mm . X travel 30,000 mm is for both machine Vertical stroke of carriage on upright - Y (mm) 5,600 mm Spindle stroke - 1,100 mm Z: Flowing stroke - w: 1,100 mm Advance - X: 3-5000 mm / min Feed - Y: 3-5000 mm / min Feedrate - Z: 1.5 2,500 mm / min Total weight: 100,000 kg Foundation pit OSTEO. for both machine Length x width x height: 40,000 x 5,000 x 1,800 mm all accessories are available and can be sold at extra costs. For both machines are the following attachments available: â?¢ Chip conveyor For both machines including lubrication and coolend unit for the cutting operation &aci ...

Code 71145 Description Horizontal table borer Make UNION Model BFT 80 / 3-1 Serial number 18301 / 34 Year 1986 Spindle 80 mm Spindle taper ISO 40 Spindle out (W) 710 mm Table 1120 x 1000 mm Cross (X) 1000 mm Longitudinal (Z) 1600 mm Vertical (Y) 1000 mm Distance table-spindle 0 – 1000 mm 24 Spindlespeeds 8 - 1600 rpm Feeds 1 - 2500 mm/min Rapids 3 m/min. Motor 11 kW 380 Volts Size L x W x H 5500 x 3200 x 2800 mm Weigth 9 ton Accessoiries Facing head Ø 460 mm with 180 mm stroke 3 x DRO Heidenhain ( X-Y-Z ) Tool clamping Guideway protection Pendel control Cooling equipment Option ( extra price ) Universal millinghead Condition Machine is in good condition

Code 61080 Description Horizontal table borer Make UNION Model BFT 90/3 at Serial number 25 742 Year 1979 ( 1980 in use ) Control Heidenhain TNC 121 Spindle 102 mm Spindle taper ISO 50 Spindle out (W) 710 mm Table 1400 x 1250 mm Cross (X) 1000 mm Longitudinal (Z) 1600 mm Vertical (Y) 1000 mm Distance table-spindle 0 – 1000 mm Weight on table 3000 kg 24 Spindlespeeds 8 - 1600 rpm Feeds 1 - 3000 mm/min Rapids 3 m/min. Motor 11 kW 380 Volts Accessoiries 3 x DRO Heidenhain ( X-Y-Z ) Tool clamping Guideway protection Pendel control Cooling equipment Option ( extra price ) Universal millinghead with 600 mm gap

SCHARMANN HEAVYCUT 2 WFT 150 CNC Floor type Boring Mill Year 1978 Spindle Diameter: 5.9" (150mm) Milling Spindle Diameter: 11.02 (280mm) Spindle Taper: CAT 50 Ram Cross Section: 11.81" x 11.81" (300x300mm) Vertical Head Travel, Y-Axis: 137.79" (3500mm) Column Travel, X-Axis: 712.59" (18000mm) Quill Travel, Z-Axis: 23.43 (595mm) Ram Travel, W-Axis: 27.6" (700mm) Z & W Axis, Combined: 51.03" (1296mm) Spindle Speeds: 5.5-1000 RPM Spindle Feed Range: 0.003-240 IPM Rapid Traverse: 396 IPM Spindle Motor: 70 HP/ 105 HP EQUIPPED WITH: Heidenhain TNC 407 CNC Controls Ram and Spindle Travel Sliding Way Covers On X-Axis Bed Right Angle Head With 1 Degree Manual Indexing Hardened Ways Re-pained recently

Key data: 100 mm, 1600 mm, 1250 mm

DRO , TABLE 1250 X 1250

Control system Heidenhain TNC 415 Spindle diameter 130 mm Tapered hollow spindle ISO 50 Spindle speed range 10 to 1500 rpm Table transverse (X): 3500 mm Rolling headstock stand for (Y): 2000 mm Longitudinal displacement rack (W): 1250 mm Eject working spindle (Z): 800 mm Table load 12 000 kg Machine weight: 36 000 kg

TOS WHN 130 MC used machine Specifications System Heidenhain TNC 426 Working range Spindle diameter 140 [mm] Taper in the spindle ISO 50 Table transverse adjustment (X) 3000 [mm] Vertical headstock adjustment (Y) 2000 [mm] Vertical travel (Z) 1250 [mm] Spindle stroke (W) 560 [mm] 2X Clamping surface 1800 x 1600 [mm] Speed range 10 - 2500 [rpm] Main motor output 37,0 [kW] Max. workpiece weightƒ 8000 [kg] Accessories Tool changer for 60pcs Tool cooling Chip conveyor

Technical data Spindle dia 125mm ISA 50 taper stroke of the spindle 800 mm cross travel of table X 1200 mm vert. travel of headstock Y 1400 mm longit. ztravel of the table Z 1620 mm spindle speed infinitely variable 3,5-700 rpm table size 1200 x 1400 mm table load 6000 kg main motor DC 19 kw total input 22,79 kW spindle feed inf. variable 0 - 1,25 mm/rot working feeds inf. variable 0,3 - 1700 mm/min rapid traverse 2250 mm/min fine feed 3mm/min dimension LxWxH 7,4 x 4,8 x 3,6 m weight of the machine 21000 kg DRO Heidenhain

Skoda W 160 H/NR CNC Travel x= 14.500mm (bed is for the travel 18,500mm) Travel Y= 3.150mm Travel Z= 1.600mm Travel W= 1.250mm Spindle diameter 160mm Machine with ball screw Many accessories available: CNC control Siemens SINUMERIC 850 Rotary table ISO 16 2.200 x 2.200mm, capacity 16 ton included Chip conweyor : 19.000 mm + 12.000 mm Floor plates

W 200G with Siemens AC main motor. modernized the main drive by instalation of Siemens AC motor with SIMODRIVE 611. Original built ISO 60 taper and 630 rpm Main data: X=8000 mm Y=4150 mm Z =1600 mm W=2000 mm Spindle dia 200mm ISO 60 spindle speed max 800 rpm Accessories: DRO Philips available as original rotary table E 20 extra cost milling head IFH 1 and IV25, IFW 1, IFW2 IFW 3 NO floor plates

W100A Parameters 100mm, 1600mm Diameter of working spindle 100 mm Taper in spindle morse 6. Longitudinal adjustment of table (z) 1450 mm Cross adjustment of table (x) 1600 mm Motion of work head on frame (y) 1120 mm Slip out of working spindle (w) 900 mm Clamping area of table 1250 x 1250 mm Dimensions l x w x h 6710 x 3450 x 3000 mm Machine weight 14 000 kg Accessories: face plate, tail stock

Horizontal borer Wotan B105Y Spindle: 120 mm Travels: -X: 3000 mm -Y: 1450 mm -Z: 1280 mm Table: -1400 x 3000 mm -Rotating part: 1130 x 1500 mm (manually rotated to any degrees) -Max load: 7 tn Machine weight: about 25 ton

Machine Type: CNC Plate Boring Machine Make WOTAN Type Rapid 5C Year of manufacture 2004 Control type HEIDENHAIN iTNC 530 Spindle diameter 160 mm X-off (mm) 10,000 Y-off (mm) 3,800 Z-off (mm) 700 W-way 700 mm Tool holder Iso 50 Speeds from (rpm) 1.25 - 1250 Feed rate (mm/rev) 1 - 5000 mm/min Rapid traverse 5 mtr/min. Total power(KW) 120 /spindle 83 Length (mm) 14.500 Width (mm) 3,850 Height (mm) 7,360 Weight 62,300 kg Information - 2004 completely overhauled and converted to CNC by Dorries Scharmann Control HEIDENHAIN iTNC 530 - 5 different angle milling heads - Hydrostatic spindle bearing - Aerostatic guideways - Coolant device -Conveyor -Oil cooler

HBM STANKO 2A622 CNC

oven 550 industrial 2x2x6m temperature range 100 - 550C Wärmebehandlungsöfen Wärmeofen Wärmeprozessöfen Warmhalteofen Warmluftofen Herdwagenofen Rollenherdofen Kammerofen Drehtellerofen Wagenherdofen & Tunnelofen Poreba Gurutzpe Tacchi Geminis Tos Amutio cazeneuve Skoda Morando Niles Colchester Heyligenstaedt Kramatorsk Mondiale Safop Cazeneuve Alzmetall mas stankoimport csepel carlton kolb soraluce bergonzi flott Erfurt Weingarten smeral schuler ebu mueller zts kosice wlochy minster Stanko stankoimport glaser huta zygmunt aft donaldson eumuko Elblag Engel Demag Arburg Krauss Maffei Battenfeld Manesty Mazak Voronezh Trumpf Amada Cincinnati Netstal Rose Forgrove Illig Foremost Nissei Sandretto Fette Mazak Mori seiki Haas Okuma Gildemeister Doosan Daewoo traub hwacheon index Wema zeulenroda mueller Erfurt tox presso technik dunkes galdabini hare ponar zeulenrdoda eitel  ...

Skoda W200H - CNC Plate Boring Machine – Bearing Sleeve (RAM) Year of construction : 1992 Electrical & Electronics Overhaul : 2021 Spindle : 200 mm ( Ø ) ISO 60 X : 7,800 mm Y : 5,400 mm W : 900 mm ( spindle ) Z : 900 mm ( Carrying sleeve / RAM 520 x 520 mm ) Z1 : 2,000 mm (table) CNC rotary table : 2500 x 2000 mm – 40 T Spindle speed : 0.8 - 800 rpm Rapid traverse speed : 6000mm/min Spindle motor : 75 kw Total power : 140 kW Machine weight : 84 T (approx.) Control : FAGOR 8055 Processing heads 3 pieces 1.Angular translation head 2. Vertical milling head 3.Horizontal milling head Base plate : 4,480 mm x 1,145mm Conveyor

UNUSED: Facinghead of a Wotan BF 160 Horizontal borer.

Code 71144 Description Horizontal table borer Make PFEIFER Model F 80 / 100 Serial number 2342 Year 1982 Spindle 100 mm Spindle taper 50 ISO Spindle out (W) 500 mm Table 1000 x 850 mm Cross (X) 1200 mm Longitudinal (Z) 800 mm Vertical (Y) 800 mm Distance table-spindle 0 x 800 mm Speeds 18 steps Spindle speeds 14 – 1500 rpm 16 Feeds 0,03 – 6,0 mm/rev Rapids 2500 mm/rev Rapids all directions ( X-Y-Z-W-B) Motor 7,5 kW 380 Volts Accessoiries X-Y-Z axis are BALLSCREWS Tool clamping Pendant control Condition Machine is in very good condition

Union boring mill CBFK 150/2 from 1990 for sale. Is currently still in use,. Technical details / accessories / addition: x-travel 3000 mm y-travel 2000 mm z-travel 1600 mm Spindle diameter 150 mm Spindle holder ISO 50 Spindle stroke 700 mm Spindle speeds - infinitely variable 5 - 2500 rpm Rapid traverses 10000 mm/min Table clamping area 1600 x 2000 mm Workpiece weight approx. 20 t Spindle drive motor 50 kW Feeds x/y/z - infinitely variable 1 - 9999 mm/min Table positioning 360,000 ° Total power requirement approx. 70 kW Machine weight approx. 40 t Dimensions approx. 6.0 x 8.0 x 4.5 m In 2005: new 5-axis CNC control Dr. Heidenhain TNC 430 - electron. Handwheel HR 410 for all axles with V24 interface, punched tape reader, new electrics, new hydraulics, new servo motors, 60-speed chain tool change magazine model WM III k02 B-axis (round table adjustment) 360,000  ...

DEFUM WFM-100 boring machine was built in 1984 in Poland by the Dąbrowska Fabryka Obrabiarek DEFUM. The machine is designed for precision machining of workpieces with complex geometry and high weight. All machining processes, i.e. drilling, milling, boring and thread cutting, are performed on a stable work table by means of a powerful spindle with a diameter of 100 mm. The WFM 100 horizontal boring machine weighs 11000 kg. Technical specifications of the DEFUM WFM-100 drilling and milling machine - feed in the X/Y/Z axis: 1200/1000/600 mm - work table dimensions (L x W): 1100 x 1100 mm - maximum workpiece weight: 3000 kg - maximum spindle rotational speed: 1600 rpm - spindle diameter: 100 mm - spindle drive power: 18.5 kW - dimensions (L x W x H): 4610 x 3620 x 3110 mm - weight of the DEFUM machine: 11000 kg

Machine : Tools for boring mill / radial drilling machine Type: MK5 5 drill rods φ 40 , 30, .. L- 280 – 400mm 3 extensions MK5 – MK4 , L-400-520mm 1 boring tool Oerlikon MK5, φ 70, 6-260 5 top-mounted milling mandrels MK5 - φ 16, 22, 27,32,40mm 2 Clarkson clamp chucks 1 MK5 boring tool, adjustable, φ 60mm 2 Shots 2 milling cutters: End mill roughing/plain φ 56x100mm, / groove milling cutter 4 milling cutters: 2 roughing/plain φ 40x12o, 2 roughing cutters 1 Reduction from MK5 to SK40 Weight: approx. 70kg kg PRICE : € 600,- ex works ! A - T-slot size: approx. 21.5mm, B-35, thread M20 16 T-slot nuts 20 pcs threaded rods M20, L-120 – 400mm 3 x 2 pcs clamping claws 4 nuts long, 6 nuts, washers 2 blocks for adjustment with adjustment screw 4 blocks 80 x 60 x40mm ( underlay )

Specifications: X-axis 2,750 mm Y-axis 2,500 mm Z-axis 2,320 mm W-axis 700 mm Spindle power 50 kW Spindle diameter 130 mm Spindle speed 1.6 – 1,600 rpm. Tool holder SK 50 Control: CNC HEIDENHAIN TNC426 Table dimensions 2,000 x 1,800 mm max. table load 8 tons B-axis 360 A° Weight approx. 37,000 kg

Key data: 130 mm, 4000 mm, 2500 mm

TOSHIBA BP-130R22 Year 2007 SPINDLE DIAMETER 5.12" (130mm) TAPER IN SPINDLE #50 VERTICAL TRAVEL, Y-AXIS 100" (2500mm) CROSS TRAVEL, X-AXIS 160" (4000mm) SPINDLE TRAVEL, Z-AXIS 28" COLUMN TRAVEL, W-AXIS 60" TABLE SIZE (BUILT IN B-AXIS) 86.6" X 70.8" TABLE LOAD CAPACITY 44,000 LBS TABLE INDEXING B-AXIS 0.001 DEGREE SPINDLE SPEEDS (3-RANGES) 5-2500 RPM EQUIPPED WITH: TOSNUC 888 CNC CONTROL 60-STATION AUTOMATIC TOOL CHANGER THROUGH SPINDLE COOLANT CHIP & SPLASH ENCLOSURE CHIP CONVEYOR 40/30 HP SPINDLE MOTOR NOTES: INSPECT IN PLANT UNDER POWER

Key data: 130 , 3500 , 2000

CNC SIEMENS 840D X-axis (longitudinal) 3500 mm Y-axis (transverse) 2000 mm Z-axis (vertical) 1250 mm Table length 1800 mm Table width 1800 mm Maximum workpiece weight 12000 kg Spindle diameter 130 mm Maximum spindle speed 800 rpm Magazzino utensili 52 posti Spindle motor 37 kW Year of revision 2005 ------------------- Length x width x height 7200 × 7800 × 4900mm Weight 32000 kg

SKODA W200GNR 1978 /CNC MEFI 836 y.m. 2005 ball screws y 4150mm x 8000mm millng heads floor plates 5600x1885x400 rotary table E20 load 20tons

W160HC with ISO 50 y.m. 1987 xtravel 4000mm y travel 3150mm rotary table S35C load 35tons, 3150 x 2800mm milling heads, tools

Table capacity 80 TONS Clamping plate width mm 3550 length mm 4000 Carriage travel V mm 2000 Heidenhain scale Rotary axe B ROD 700 Table height mm 1460 Table weight kg 52000

Key data: 80 mm, 1700 mm, 1800 mm

Spindle Diameter: 80 mm Spindle Adapter: SK50 Spindle speeds: 11 - 1000 rpm. X-axis: 1700 mm Y-axis: 1800 mm Z-axis: 1800 mm Spindle off (W-axis): 710 mm Table dimensions: 1100 x 900 mm Elbo Digital Readout: On Y-axis and Z-axis Equipped with: -Turntable - Some tool containers Spindle motor: 7.5 KW Machine LxWxH: 5100 x 2650 x 3300 mm Machine Weight: 10 Ton

Horizontal Boring Machine CORNAC C100 Travel X: 1000 mm Travel Y: 1000 mm Travel Z: 1260 mm ixed table Cone SA 50 Spindle: Ø 100 mm Spindle exit: 550 mm Rotation: from 10 to 1250 RPM Table size: 1550 x 980 mm Surfacing plate: Ø 520 mm Spindle motor: 9,5 kW Scale 3 axes HEIDENHAIN Automatic Feeds: X - Y - Z Supplied with a set of cones Voltage: 380 V Dimensions (L x W x H): 4500 x 2100 x 2450 mm Weight: approx 8 T

Inv. Num. : 7631 Type: F80 Produzent: Pfeifer Erzeugt: 1976 Parametern: Maximale Drehzahl der Spindel: 1000 1/min Verfahrwege X-Achse: 1700 mm Verfahrwege Y-Achse: 1800 mm Verfahrwege Z-Achse: 1800 mm Verfahrwege W-Achse: 710 mm Spindeldurchmesser: 80 mm

spindle diameter 130 mm - ISO 50 tool - rated power of the spindle rotation motor 18.5 kW - installed power 4 0kW - spindle drive motor speed range 722-1455 rpm - spindle rotation range 2.25-900 rpm, 27 degrees - disc rotation range 2.25-180 rpm, 18 degrees - X axis feed speed range 0-5000 mm/min, stepless - Y axis feed speed range 0-5000 mm/min, stepless - Z axis feed speed range 0-3150 mm/min, stepless - B axis feed speed range 0-4000 mm/min, for Ø1m, steplessly Bg2Ltmk8Gq - machine weight 30 t

Monti MCS 100 NEW boring machine :::TECHNICAL SPECIFICATIONS::: CNC Model: Siemens CNC Version: 840D Tool Mount: ISO 50 Spindle power: 24Kw Number of spindle speeds: 4000 Number of tools: 60 X-axis travel: 2500mm Y-axis travel: 1500mm Z Axis Travel: 1700mm Fast feeds linear axes X Y Z: 20m/min Spindle spindle stroke : 600mm Rotary table: yes Table size: 1300 x 1500mm Allowable load on the table: 4000Kg Other technical data: The machine is being built this year Machine equipment: Anthropomorphic robot for tool change management Heidenhain Optical Scales :::D DIMENSIONS AND WEIGHT::: Weight: 23000Kg

STANKO 2N636GF1 Horizontal boring mill MITSUBISHI controler, new 2013 Spindle 125 mm Table 1600 x 1800 mm Max. horizontal (axial) movement of the spindle (Z') - 1000 mm Max. vertical movement of the headstock (Y)- 1400 mm Max. longitudinal movement of table (Z, W) - 1600 mm Max. lateral movement of table (X) - 1400 mm The largest mass of the processed product - 8 tons Spindle speed - 8 ... 1250 rpm Spindle Drive Electric Motor - 20 kW The weight of the machine is full - 34.6 tons

Key data: 102 mm, 1530 mm, 900 mm

Spindle diameter Ø 102 mm Taper ISO 50 Horizontal spindle travel 710 mm Cross travel (X) 1,530 mm Vertical Travel headstock (Y) 900 mm Longitudinal travel (Z) 1,500 mm Table 1,250 x 1,400 mm R.P.M. 8 – 1,600 (18x) kW 11 Volts 380 Cycles 50 Including: Digital readout
