engine plast peripheral equipment e.g. heating,cooling,drying used for sale

Various strand granulators are for sale - Strand granulator SG-200; 150; 100; 50 mm cutting rotor width All machines are connected and ready for testing. Visit possible by arrangement.

For sale is a used plate screen changer from the manufacturer BD Plast SRL. The screen changer is in a used but well maintained condition. Specifications: - Screen diameter: 250mm - Filter area: 491 cm² - Sealing ring PTFE/ Teflon - Heating capacity approx. 22kW - Number of control zones: 4 - Operating pressure max. 400 to 500 bar - Hydraulic unit designed for quick change - Throughput capability from 800 to 2,000 kg/h - Weight approx. 950 kg incl. documentation, documents, drawings, etc... Screen change can be visited by prior appointment.

BD PLAST SEMI-AUTOMATIC SCREENCHANGER, type BDO 400, constructed in 2017, complete with hydraulic pack, spare hydraulic piston, junction box with all connections, control cabinet is not included (available separately), offered AS IS, checked for good conditions, or totally reconditioned, (On separate offer) some new filters 24/110 and 12/64.

BD PLAST NON-STOP SCREENCHANGER, Constructed in 2013 Approx.500 operating hours. Screen diameter 250 mm Filter area 491 cm² Sealing ring PTFE / Teflon Heating capacity approx. 22 kW N. 4 heating areas Operating temp. max. 260°C Operating pressure max. 400 to 500 bar Hydraulic unit designed for quick change (accumulator preloaded with nitrogen) Weight 950 kg, installed power - used power in work: about 60-65% : 22

Materials: PVC // Film Width (Max): 1000 mm

Screw Diameter: 64 mm // Throughput: 480 kg/h

BD PLAST NON-STOP SCREENCHANGER, Machine reconditioned Screen Ø 300 mm, suitable for 160 - 180 mm extruders, Heating capacity approx. 25 kW N. 4 heating areas Hydraulic pack., Machine offered reconditioned, complete with Users manual, CE compliance, el.drawings, installed power - used power in work: about 60-65% : 25

Extrudeuse CM EVOLUTION PLAST type CM-EVO 230 Année. : 2019 Puissance : 50 KW Tension : 400 VOLTS Poids : 4000 KG

Additional independent injection unit with its own supply and control system

Battenfeld UTR 300 heating controller for control of Unilog 4000 B

Laboratory Heating Press EHSP20H – Used Demonstration Machine Table press / electric screw press with pressing pressure 20 KN (2 tons) With heating device up to 200 °C from above and below. Press drive with screw jack gear, reduction ratio 1 : 12, spindle diameter 32 mm, Pitch 6 mm, pressing area approx. 100 150 mm, clear height and stroke approx. 300 mm. Geared motor 0.37 KW, 1,390 rpm, 4-pole, with spur gear i = 1 : 5, Speed 150 mm / min. Max. dynamic load 20 kN. With reversing control, control box and motor protection plug. Sturdy press frame made of steel. Undertable made of high-quality aluminium profiles 4545 mm, table surface 600600 mm, Table top made of multiplex board. Total weight approx. 100 kg. The table press has a pressing pressure of 20 kN (dynamic load). Typical applications are pressing work with exact lining. Suitable for pressing bonding, embo ...

Laboratory heating press REITZ EHSP5H – used demonstration machine Heating press with pressing pressure 5 KN (0.5 tons) With heating device up to 200 °C from above and below. - Electric screw press press press force 5 KN (0.5 to) - Screw jack with spindle 20 mm, pitch 5 mm - Gear reduction ratio 1 : 10, 0.5 mm spindle travel per revolution - Clear width approx. 60 mm - Pressing area 100150mm - Heating device with temperature control, 2 heating plates 100 x 150 mm - With TECO electric motor 0.18 KW - With reversing contactor control (up – down buttons) and emergency stop - Motor protection plug against overload, with main switch - Machine table made of aluminum profiles and multiplex plate 700 700 mm - Total weight approx. 100 kg . Suitable for foil bonding and embossing. Due to self-locking of the spindle, long holding time with constant pressure. The scr ...

Various diameters Auction-ID: A1-43992-80

New drying centrifuge : 1.25 x 0.5 m Ø, with grill: 3 mm and motor : 50 hp at 3,000 rpm. Ready to get started? Contact us directly! Send us a WhatsApp message to (+34) 647 590 257 or an email to infogester.es for personalized advice.

Centrifuge New brand: GESTER, model: CG-1200V. Shaft length: 1.2 m and axis diameter: 0.5 cm. Engine: 50 hp at 3000 rpm. Pneumatic piston for cleaning on top. Electrical panel with triangle star.

Rotor diameter: 500 mm Rotor width: 1200 mm kW: 30

Dry air dryer Granulate dryer for drying and heating hygroscopic granules. Capacity 600 l. Heating capacity 4.5 kW. Optionally available with dehumidifier AZO LE 600 P.

Granule dryer for heating and drying hygroscopic plastic granules. Tank capacity 1200 l. Heating capacity 9 kW. Optionally available with air dryer AZO LE 400 K

Capacity: 50kg, max. operating temperature: 400°C, heating capacity: 3kW, insulation thickness: 80mm, diameter: 710mm, height: 1175mm, weight: 75kg. Documentation available. On-site inspection is possible.

AIR DRYING TUNNEL, for strands, dimensions 2.000 x 300 mm. (or bespoke), blower on bottom with 2 conveyors which send air through slits, constructed in AISI304 stainless steel

Drying container Piovan 2 x 100 L BJ 1998

A mechanical centrifugal dryer B+B Anlagenbau for plastic flakes and washed materials is available. 1) Mechanical dryer B+B Anlagenbau FH 50/150-V, year of manufacture: 2008, power: 30kW, max. relative humidity: 60%, machine dimensions X/Y/Z: approx. 4050mm/1150mm/3850mm, weight: approx. 1250kg. 2) Separation tank Weiss, material: stainless steel, machine dimensions X/Y/Z: approx. 3000mm/1500mm/1800mm. The motors and slides need to be overhauled. 3) Friction separator B+B Anlagenbau FAS 40-300, power: 22kW, speed: 1470rpm, max. relative humidity: 60%, separated material: PET/PE/PP. Total system dimensions X/Y/Z: approx. 6500mm/2100mm/3200mm, design: modular, cyclones: 2/bunker, process: conveying/separation/friction drying/final dewatering. Documentation available. An on-site inspection is possible.

SOREMA HIGH CAPACITY WASH LINE INCLUDING INTENSIVE HOT WASH, HOT RINSE, SINK FLOAT SEPARATION AND FINAL RINSE, APPROX. OVERALL FOOTPRINT: 40' WIDE X 90' LONG, ELECTRICAL CABINET - HOT WASH SYSTEM INCLUDES: (2) MODEL SHW-8000 WASHING SILOS, EACH SILO WITH CONTAINS (2) STR-16/20 INTENSIVE FRICTION WASHING REACTORS, FEED SCREWS, EXTRACTION SCREWS, & EXTRACTION PUMPS, (1) MODEL WCE-2000 WASHING CENTRIFUGE, PROCESS WATER RECYCLING TANK AND PUMPS, 72" DIA. MODEL VBC-1800 VIBRATING SCREEN, FEED SCREW, MODEL WCE-230 MULTI-STAGE WASHING CENTRIFUGE, (2) MODEL SCW-280 CONVEYING SCREWS - HOT RINSE SYSTEM INCLUDES (3) MODEL STR-16/20 STIRRERS WITH SEPARATION CYCLONES, MODEL WCE-1500 WASHING CENTRIFUGE, 72" DIA. MODEL VBC-1800, VIBRATING SCREEN, RECIRCULATING TANK, MODEL SCW-280 CONVEYING SCREW SINK FLOAT SEPARATION SYSTEM INCLUDES A STIRRER, MODEL VSP-20/55 SEPARATION TANK, 72" DIA. VB ...

SOREMA MODEL SA-1500 ASPIRATOR (ELUTRIATION) SYSTEM; APPROX. 58" WIDE X 17' HIGH, CYCLONE, AIRLOCK (NEW 2016)

granulate drying installation, to be combined with lot 23/24/25, Please note! Pick up by appointment Auction-ID: A1-43992-292

An essential ingredient for removing impurities from the material. With a specially developed rotor with replaceable blades, high friction is generated at the target fraction and thus ensures thorough cleaning. Maintenance hatches on both sides allow easy access to the interior. The housing and the screens underneath are made of stainless steel. A support frame is included as well as inlet and outlet nozzles for the water. More information on request!

Cooling tray type KW 1000-200-200 self-sufficient for strand cooling in the production of granules or filaments. - a mobile and height-adjustable base frame made of welded steel raw, left machine version, painted - Frame-height adjustment of the top edge of the water bath from 900 mm to 1050 mm - a VA cooling tray 1000x200x200mm - 2 pieces adjustable and mounted strand holder - clamped to water edge - 1 piece wiper bled for partial strand drying - 1 piece of adjustable tub plug for filling height adjustment - 1 piece of VA water tank (reservoir) as service water tank - 1 piece of bacon water pressure pump to supply the cooling tank with sufficient cooling water from the water tank - 1 piece of direct 1/2" fresh water connection via float switch and solenoid valve for connection to the customer's side Fresh water network - Tub overflow - drain pipe DN50 for connection to  ...

liter capacity: unbkt l coolant: unbkt pressure: unbkt t total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

The mixer combines hot and cold mixing. After hot mixing, the material automatically enters the cold mixer for mechanical cooling. -hot tank 800 l. - cooling tank 2000 l. - hot stirring time from 6 to 10 min. - cooling time from 10 to 15 min. - engine power 110 kW The device is adapted to the production of WPC terrace boards. Components needed for the product, such as PVC and wood dust or MDF dust, can be combined.

This cooling tank from Primac is in machine storage at Plastima Used Machinery. The Cooling Tank is from 1994 and is in great condition. - Brand: Primac - Model: CV.2C. 125/6 - Pipe diameter max: 125 mm - Cooling length: 6000 mm - Year of construction: 1994

WATER COOLING TANK, for strand pelletizers, Constructed in AISI4304 stainless steel, On 4 wheels (2 with brakes), Overall dimensions : LxWxH 2,5 x 0,5 x 1,0 mt., tank : LxWxH 2,5 x 0,5 x 0,25 mt.

Universal Components Mixer EM 300 in stainless steel, Fabr. MTI Detmold / Germany, built in 1997

An air-cooled monoblock water chiller Green Box for the plastics industry is available. Cooling capacity: approx. 20 injection molding machines, power: 25kW, refrigerant circuits: 2, refrigerant: R407C, cooling capacity: approx. 80kW, air flow rate: approx. 16500m³/h. Machine dimensions X/Y/Z: approx. 3300mm/1100mm/2100mm, weight: approx. 1300kg. Documentation available. An on-site inspection is possible.

Brand: Rollepaal Pipe Extrusion Technology B.V. Model: RSV 8/1 Year of construction: 2005 Pipe outer diameter max: 8 mm Cooling length: 1000 mm Spray pump: 2.2 kW

available is a complete Plant with Equipment to produce Airspring! 3 Roll Calender with line and 84" Twin Mill Bias Cutter Several Building machine several hydraulic Curing presses testing machine 3 x assembly lines Winder ...

3 granule colouring machines for injection moulding or blow moulding machines, as good as new

Bausano Modular Compact Line , All 7m Lenght + Tilting, Maximal Profile Section 180 x 100 mm,, Maximal Traction Force 10 kN, Maximal Speed 15 m/min, Specifications: Calibrator type BP/2P/ML, Lenght Calibrator Holder 2500 mm, Longitudinal Adjustement 600 mm ( Gear Motor- Traverse Motor 0.37 kW ), Transversal Adjustment 40 mm, Vertical Adjustment 880 / 1130 mm, Cooling Water 12 Connections, Vacuums Pumps 2 x 4 kW, Vacuum 16 Connections, Haul-off unit type TNP 15 -150 MB, Tracks Lenght x Wide 1500 x 150 mm, Track Max Opening 95 mm ( 2 Pneumatic Cylinders ), Max Speed : 25 m/min, Max Take Off 23 kN, 2 Direct Gear box Motor to everyone carterpillar , 2 x 1.1 kW, Saw type TAV 90, Max Vertical Adjustment 95 mm, Max Cutting Lenght 300 mm, Motor 1.5 kW, Shaves Suction Motor 1.1 kW

CALIBRATING TABLE BATTENFELD K 160 V2, 2 Speck v-pumps 4 kw / 2 sections, 16 x vacuum-connections, 12 x water-connections, Blower for drying, HAUL OFF BATTENFELD P 100 SV, 2-belt haul-off (type caterpillar), Contact 1.200 x 160 mm, Speed approx. 0,5 – 15 m/min., Motor-power approx. 4 kw, Pulling-power approx. -6.000 N maxi., SAW BATTENFELD SPR 32 P, Profile-saw upstroking, Blade Ø 300 mm, Chip/dust-suction, control panles,, Electric manuals available

VOBAU PROFILE DOWNSTREAM EQUIPMENT, Max Profile Section 250 x 100 mm,, Maximal Traction Force 20 kN, Maximal Speed 8.5 m/min, CALIBRATOR - 4000, Fixing Surface Calibration Tools 4.000 x 400 mm, 3 Vacuum Pumps 5 kW Each, Adjustments :, Longitudinal Lenght , Vertical Motorized,, Lateral Manual ., HAUL OFF - 175, Oscillating Pneumatic Top , Manual Down,, Carterpillers Adjustment, Carterpiller Length 175 x 2300 mm, 2 Gears Motors 2.2 kW , Each, Inverter Control , Maximal speed 8.5 m/min, SAW - 450, Ascending Saw , Suction Shaves, Translation Trolley Cut - 600 mm, Disc Ø 450 mm, Motor 2.5 kW, Tilting Table ., availability: immediate

Control System: Touch-screen operator panel Operation: Automatic color mixing and dosing Components of the Machine - Touch-screen control panel (CMA Challenger 151) - Integrated dosing & mixing system - Agitator / stirring unit (working components for mixing) - Pneumatic system / pressure control (pressure gauge and pneumatic connections) - Quick-release connections for tools/stirrers - Recipe management software (AURORA MIX / formula control system or equivalent), with integration into color-matching systems.

Blown film line especially for PP processing length: 6,300 mm width: 2,500 mm height: 4,200 mm Weight: 3.700 kg blowing capacity: 65 kg/hod. Film Thicknes: 0.015 – 0.1mm film width: 250 – 650mm Die- diameter 65 mm Winding speed: 5 – 60m/min. Power consumption: 72 kW

This material filler is equipped with a 1 kW electric motor. It can suck 2 kinds of materials into its large tank. The mounted controller can also regulate the ratio of materials. There are several of them. Other fillers, dyes and other machines are also for sale. Please see my other ads.

DL-2400 THREE LAYER CASTING MACHINE

PET Blow Moulding Machine - MAG PLASTIC The ideal blowing solution for PET bottles Year : 1994 Type : SSB 40 Input voltage : three-phase 400 V Frequency : 50 or 60 Hz ± 5% Total installed power : 86 kW (Option 102 kW) Weight: Approximately 5000 kg Number of molds: 4 Clamping force : 250 KN Total opening stroke : 120 mm

Inv. Num. : 8807 Type: PROVITE 2000/120 Producer: Plastmashines Germany Created: 2011 Parameters: Capacity: 400 kg/h Line mounting: Main control panel and monitoring system Mixing/homogenizing tanks Engines Extruder Vacuum pump for degassing Melt filter Closed Water Cooling and Pellet Drying System Unloading silo BOCO PARDUBICE Machines Corner Conveyor Belt Mercedes

Souffleuse PLASTIBLOW type PB1 E/S électrique 1 tete , 1 poste Diamètre vis : 50 mm Année : 2008 Volume du flacon max : 1 litre Force de fermeture : 35 KN Cadence à vide : 1,5 sec Rapport L/D : 25 Consommation moyenne : 5 KW/h Puissance moteur : 18 KW Puissance de chauffe. : 6,9 KW 4 zones de chauffe 3 ventilateurs Dimensions moule : 280 mm x 325 mm x (81 + 130 + 85 ) mm Dimensions machine ( L x l x H ) : 2,35 m x 3,80 m x 2,35 m Poids : 3650 KG

PLASTIMAC LAB EXTRUDER, for blown film, suitable for testing granulate, 25 mm screw diameter, 70 mm diam. die, 500 mm collection frame, 7,5 Hp drive, complete wuth supporting structure, (corona treatment+small printer can be sold separately if required), installed power - used power in work: about 60-65% : 7,5 Hp, working width: 500 mm, conditions: good
