eht presses used for sale

Specifications: - Max. working length 4050 mm - Column passage 3050 mm - Max. pressing force 110 t - Plunger stroke 200 mm - Projection 350 mm - Table height 900 mm - Opening width 400 mm - Drive power 17.5 kW - Space requirement approx. W 4250 x H 2850 x D 2200 mm - Weight approx. 15.0 t -with: - Control CYBELEC ModEva 10 S renewed in 2011 - Y 1+ 2 , X , Z - Two-hand control panel: -Mot. Back gauge 5 - 1000 mm - Front support arms - Split sharpening tool, - Universal die

Force of pressure: 150 t working width: 4500 mm clear stand width: 3050 mm stand projection: 300 mm rear gauge: 1000 mm Electr. Supply: 380 V, 18.5 kW weight: 14.8 t space: 4200 x 2000 x 3000/3150 mm

Force of pressure: 250 t working width: 3550 mm clear stand width: 3050 mm stand projection: 300 mm rear gauge: Yes Electr. Supply: 400 V, approx. 26 kW weight: 20 t space: 2100 x 3800 x 3100 mm

Key data: 6000 mm, 4 mm

With autom. Stacking and transport table, light barrier, cutting counter, with scrap diverter, compressed air required Machine is repaired, checked, cleaned by a professional and is then fully functional. Test run is carried out. Sheet width: 6000 mm Sheet thickness steel: l 4.0 mm Sheet thickness aluminium: 6.0 mm Sheet thickness front: 2.0 mm Colour: grey Total power requirement: 11 kw/63 A Machine weight: 19,500 kg Dimensions: 6800 x 3500 x 2300 mm without cutting gap adjustment Hydraulic hold-down device Brpmi77K7Oq Column projection: 200 mm Cutting angle adjustment fixed: 1 degree Back gauge: 10 - 1000 mm Machine number: 107640

EHT TRUMPF TruBend 8500-60 CNC press brake was built in 2007 in Germany by EHT Werkzeugmaschinen GmbH (now Trumpf Werkzeugmaschinen Teningen GmbH). The machine with a high press force of 500 tonnes is designed for economical machining of hard materials with a maximum length of 6050 mm. The robust, internal stress-free design combined with a powerful hydraulic system ensures the achievement of the best bending results, even during the most intensive challenges. All process parameters are programmed in CYBELEC CNC control, whose intuitive interface allows advanced machining programmes to be created in just a few steps. The TRUMPF TruBend 8500 CNC hydraulic press brake weighs 60 tonnes. Technical specifications of the EHT TRUMPF TruBend 8500-60 press brake - CNC controller: Cybelec ModEva 10S - maximum press force: 500 t (5000 kN) - maximum bending length: 6050 mm - X-axis stop range ...

Technical data: -maximum working length 1250 mm -Stand round 1050 mm -Max pressing force 80 t -Stroke 250 mm -Stand RADIUS 300 mm -Max height betw. Table - press bar 560 mm -Lifting speeds -Backward speed idle max 100 mm / sec. -Forward speed 100 mm / sec. -Backward press speed max. 12 mm / sec. -Total power 15 kW -Space requirement approx. B 1750 x H 3400 X 2000 mm -Weight approx. 8500 kg -with: - CNC - control CYBELEC DNC 7400 PSGY -controlled X - axis back gauge 5-1000 mm -Pneum. Z - axis in three stages. height-adjustable -manually movable and foldable stop fingers -controlled pneumatic die shift - hydr. Tool clamping -Manual crowning - 2 piece support arms -Pointed tool shared H 320 x L 1000 mm -Foot tool H 320 mm x L 1000 mm - universal matrix L 1000 mm

EHT TRUMPF TruBend 8230-40 CNC press brake was built in 2007 in Germany by EHT Werkzeugmaschinen GmbH (now Trumpf Werkzeugmaschinen Teningen GmbH). The machine, distinguished by its high productivity and excellent precision, is used for the economical machining of workpieces with a maximum length of 4050 mm. The rigid, internally stress-free design combined with a press force of 230 tonnes ensures excellent bending results, even during the most demanding challenges. The operator, in turn, has at his disposal a convenient foot switch and an intuitive CYBELEC CNC control, in which advanced machining programmes are created in just a few steps. The TRUMPF TruBend 8230 CNC hydraulic press brake weighs 18100 kg. Technical specifications of the EHT TRUMPF TruBend 8230-40 press brake - CNC controller: CYBELEC ModEva 10S - number of axes: 5 (X, X1, R, Z1, Z2) - maximum press force: 230 t (2 ...

Stop for press brake, bending machine, guillotine shear, drive shaft -Drive shafts: for stop, from press brake EHT type EHP 11-40, 2 pieces -Length: 515 mm -Hole: Ø 25 mm -Price: complete -Dimensions: Ø 50 x 515 mm -Weight 5.1 kg/pc.

Bending tool, die, upper knife, upper tool, straight tool, die tool, seam closing tool -Tool: from press brake EHT type EHP 11-40 -Measures: see drawing in the photos -Dimension: 4050/45 / H130 mm -Weight: 147 kg

Sheet metal shears, tin scissors, sheet metal scissors, hydraulic shears -Sheet shear: hydraulic -Cutting width: 2000 mm -Max. cutting thickness: steel 6 mm -Features: Back gauge, cutting gap adjustment -Space requirement: 3280/2700/H2060 mm -Transport dimensions: 2280/2700/H2060 mm -Weight: 5980 kg

pressure: 1500 kN chamfer lenght: 3550 mm distance between columns: 3044 mm Control: Cybelec 34 PS-CN column arm: 350 mm max. ram stroke: 220 mm dimensions of the machine ca.: 3200 x 4200 x 2100 m sheet support: hinten / back number of support arms: 2, verschiebbar / adjust. die shift: hydraulical tool clamping: upper tool quick change system: crown: 3 sets of tools included The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

EHT VarioPress 175-35 CNC press brake was built in 2004 in Germany by EHT Werkzeugmaschinen GmbH (now TRUMPF). The machine is designed for precision machining of workpieces with a maximum length of 3550 mm. The machining process is performed with a high press force of 175 tonnes, which, combined with an extremely stable design, guarantees excellent bending results, even during the most intensive challenges. All this is complemented by the advanced CYBELEC control system, which significantly facilitates the daily operation of the machine. The EHT VarioPress press brake weighs 14900 kg. Technical specifications of the EHT VarioPress 175-35 press brake - CNC controller: CYBELEC DNC 1200PS Eco/Col - maximum press force: 175 t - maximum sheet metal length: 3550 mm - front supports - connection power: 20.5 kW - current protection: 63 A - control voltage: 24 V - power supply: 3x 400  ...

sheet width:3050 mm plate thickness:4 mm total power requirement:9 kW weight of the machine ca.:6 t dimensions of the machine ca.:3900 x H 1850 x T 2100 mm

CNC Punching Press Manufacturer: EHT Type: Strippit 1500/30 Year of Make: 2000 CNC Control: Fanuc Working area without replacement: 2500 x 1500 mm Material thickness max.: 8 mm Punching force: 30 tons. Turret with 46 tool positions, including 4 index stations size D 3 programmable claws Metal table Used exclusively in single-shift operation incl. tools WILSON TOOL

pressure: 150 t chamfer lenght: 3550 mm distance between columns: 3050 mm Control: Cybelec DNC 880S stroke: 700 mm throat: 350 mm dimensions: 4400x2200x3940 mm weight of the machine ca.: 15.000 kg Accessories/equipment: - Bending aid in front of the machine - Parking space for bending aid - 3 stop fingers - Control conversion 2011 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 110 t chamfer lenght: 2550 mm Control: Cybelec CybTouch 15 weight: 9000 kg dimensions: 3000 x 2100 x 3000 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 6000 mm plate thickness: 6 mm distance between columns: 610 mm Control: Elgo 87 P2 total power requirement: 15 kW weight of the machine ca.: 22 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 3000 mm plate thickness: 4 mm distance between columns: 3050 mm total power requirement: 8 kW weight of the machine ca.: 4.8 t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

press capacity: 2250 kN quantity of oil: 400 l : DNC 1200PS Eco/Col weight of the machine ca.: ca. 15.500 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

fabric-no.: 202 395 working length: 2550 mm output: 2000 KN tracking travel: 13 mm safety distance: 176 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 320 t chamfer lenght: 7250 mm distance between columns: 6550 mm Control: throat: 400 mm ram - range of adjustment: 270 mm stroke: 270 mm table surface area: 7250x400 mm dayligth: 560 mm fence: 5-1000 ja /nein total power requirement: kW weight of the machine ca.: 53 t dimensions of the machine ca.: m Central crowning Rip fence Mower adjustment Die adjustment Hydraulic ram clamping Hand/foot control The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are ...

Pressing force: 200t/2000kN, bending length: 3550mm, upright distance: 3050mm, upright projection: 350mm, max. ram stroke: 200mm, max. ram-to-table distance: 540mm. Dimensions X/Y/Z: approx. 4400mm/2100mm/3200mm, weight: approx. 16000kg, control: Cybelec DNC 800. Including a matrix, 2x upper tool (30°/60°) and a new light barrier. Documentation available. On-site inspection is possible.

An EHT hydraulic guillotine shear refurbished in 2023 is available. Cutting length: 3000mm, max. sheet thickness steel/VA: 4mm/2mm, backgauge: 10mm-1000mm, adjustment speed: 180mm/s, stroke rate: 18-31 strokes/min, oil volume: 160l. Machine dimensions X/Y/Z: approx. 3700mm/2100mm/2150mm, weight: approx. 4800kg, operating hours: 44024h. The cylinders, blades and hoses were overhauled in 2023. On-site inspection is possible.

Key data: 3050 mm, 6 mm

3000 x 6mm Elgo P50 Rear sheet supports

sheet width: 3200 mm plate thickness: 4.0 mm ST distance between columns: 3300 mm upper clamping bar adjustment: 400 mm Adjustment folding beam: 80.0 mm pivoting angle: 180 Grad clamping capacity max.: 200 KN rear stop: 10.0 - 1600 mm oil volume: 160 Liter total power requirement: 9.8 kW weight: 8500 kg range L-W-H: ~ 4900 x 2000 x 2300 mm From a maintenance workshop Good / well-maintained condition () - in checked conditions - machinevideo - https://www.youtube.com/watch?v=RY-amZooeX4 Equipment: - Robust CNC folding machine - CNC control unit - CYBELEC DNC 80 PP Swiveling control panel, front right 2D graphic display for display and multiple simulation 2D graphic programming Easy handling - CNC electro-motorized backgauge Travel range 10.0 - 1,600 mm Pneumatic / lowerable stop fingers Adjustment speed max. 250 mm/sec. Rear sheet support table with brushes - Electro-motorized l ...

pressure: 85.0 t chamfer lenght: 2050 mm distance between columns: 1650 mm column arm: 400 mm stroke: 240 mm dayligth: 320 - 560 mm ajustment speed: 150 mm/sec working feed: 15.0 mm/sec return speed: 150 mm/sec back stop - adjustable: 5.0 - 1000 mm table width: 110 mm work height max.: 1050 mm operating pressure: max. 297 bar compressed air: 4.5 - 6.0 bar oil volume: 200 l operating pressure: 340 bar total power requirement: 7.5 kW weight of the machine ca.: 5900 kg range L-W-H: 4100 x 2100 x 2750 mm with increased installation height / piston stroke well-maintained condition () - in checked condition - machine video - https://www.youtube.com/watch?v=ikl6RNZWeiU Equipment: - CNC electro-hydraulic press brake - including CYBELEC CNC control swiveling control panel at the front right external screen - CNC axis adjustment: Y1 - Y2 - X - R - Z1 - Z2 - I + CNC crowning - CNC electro-motor ...

pressure: 225 t chamfer lenght: 3050 mm distance between columns: 2550 mm column arm: 300 mm ajustment speed: 110 mm/sec work speed: 9.0 mm/sec return speed: 130 mm/sec work stroke: 240 mm dayligth: 320 - 560 mm table height: 1000 mm table width: 200 mm oil volume: 350 ltr. operating pressure: max. 296 bar air pressure: 4.5 - 6.0 bar voltage: 400 Volt total power requirement: 18.5 kW weight: 14900 kg range L-W-H: 5180 x 2400 x 3100 mm - in checked condition - machine video - https://www.youtube.com/watch?v=ebbbzSYMxKw Furnishing: - electro-hydraulic CNC die bending/press brake - CYBELEC CNC control ModEva 12S, swiveling at the front right High-resolution graphic color screen 14 inches Representation as a line, area or volume drawing of the product Clear, concise menus in the operators language Large tools and products library - CNC-controlled back gauge adjustment (X-axis) Stop rang ...

pressure: 150 t chamfer lenght: 4050 mm distance between columns: 3550 mm Control: CYBELEC ModEva Pac throat: 350 mm distance between table / ram: 430 mm table width: 250 mm stroke: 250 mm total power requirement: 18,5 kW weight of the machine ca.: 16500 kg dimensions of the machine ca.: 4400x2100x3200 mm Equipment/accessories: - Control conversion at the end of 2018 - Electric backgauge 1250 mm - 10-stage die displacement - crowning - EHT 26 mm tool holder - Axes controlled: Y1,Y2,X,R - Sheet metal holding table - 4x manually adjustable stop fingers - pneum. Upper tool clamping - Safety light curtain - 3x height-adjustable support arms - Oil cooler - 2-hand foot switch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Offer 25376 Specifications: - Max. cutting width 3050 mm - Max. cutting capacity at 45 Kp/mm² 13 mm - Hydr. Cutting angle adjustment - Number of hold-downs 13 pcs - Front angle stop - 4 pieces of front support arms -Mot. Positioning-controlled backgauge 10 - 1000 mm - Cut line illumination - Rear space protection with side grilles + light barrier - E - Footswitch - Drive 400 V / 20 kW - Space requirement approx. W 4350 x H 2100 x D 2200 mm - Weight approx. 8.5 t

Inv. Num. : 8740 Type: VR 13-31 Producer: EHT Generated: Parameters: Maximum cutting length: 3100 mm Maximum cutting thickness: 13 mm

pressure: 170 t chamfer lenght: 4050 mm voltage: 3x400 V weight of the machine ca.: 16300 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 3100 mm plate thickness: 4.0 mm thickness at Niro-steel: 2.5 mm cutting angle adjustment: 1.0 ° back stop - adjustable: 10 - 1000 mm adjustment speed: 180 mm/s down holder: 21 Stück strokes per minute: 18 - 31 oil volume: 160 L Control: ELGO P8511 column arm: 200 mm distance between columns: 3050 mm 0: max. 300 bar voltage: 400 V main drive: 9.0 kW weight of the machine ca.: 4800 kg. dimensions of the machine ca.: 3660 x 2070 x 2140 mm from a maintenance workshop Equipment: - electro-hydraulic sheet metal shear swing cut - machine frame = all-steel welded construction - ELGO NC control model P8511, control panel at the front left for positioning the electro-motoric rear stop target/actual position value input possible adjustment by three-phase motor via toothed belt - support table with ball rollers there are recessed grips between the table plates - front finger guar ...

pressure: 135 t chamfer lenght: 3050 mm distance between columns: 2550 mm dayligth: 320 - 560 mm stroke: 240 mm working feed: 10.0 mm/sec return speed: 150 mm/sec column arm: 400 mm work height max.: 1050 mm control: DNC 1200 PS/B operating pressure: max. 297 bar compressed air: 4.5 - 6.0 bar connected load: 15.0 kW oil volume: 250 ltr. weight: 11500 kg range L-W-H: 5240 x 2400 x 2900 mm good/well-Maintained conditions used in Aluminum processing - in checked conditions - machine Video - https://www.youtube.com/watch?v=z-Bxibk_8uE Features: - CNC Electro-Hydraulic Press Brake - CYBELEC CNC Control Model DNC 1200 PS/B Swiveling Control Panel, Front Right Numerical Programming Tool & Program Library - CNC Controlled Axes: Y1 + Y2 + X + R + CNC Crowning - CNC Electro-Motorized Backgauge (X-Axis) with 3x Manually Adjustable Backgauge Fingers (Z-Axis) Maximum Travel Speed: 250 mm/sec - ...

pressure: 225 t chamfer lenght: 2050 mm distance between columns: 1550 mm control: CYBELEC DNC 1200 PS Eco stroke: 550 mm table height: 700 mm throat: 405 mm distance between table / ram: 320-870 mm column arm: 405 mm weight of the machine ca.: 14.000 kg Accessories / equipment: - controlled axes: Y1 - Y2 - X - R - Z1 and Z2 can be moved manually - Lasersafe angle measurement - Pneumatically adjustable support table - pneumatic upper and lower tool clamping - 2-hand foot control - manual crowning The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 3050 mm plate thickness: 6 mm weight: 7.000 kg range L-W-H: 3450x2200x1750 mm Equipment/accessories: - adjustable support table - Sheet support - angle stop - Sheet support arms - foot switch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 3050 mm plate thickness: 6 mm rear stop: 10-1000 mm cutting angle: 0,5 - 2,5 ° down holder: 20 Stk no. of strokes: 14 - 23 Hub/min work height max.: 900 mm oil volume: 140 l total power requirement: 11 kW dimensions of the machine ca.: 4000 x 2150 x 1900 mm weight: 7800 kg Equipment: - ELGO control unit type P50 - Automatic cutting angle adjustment - Automatic cutting gap adjustment - electric back gauge - Pneumatic sheet holding device - Light barrier behind the machine - 4 support arms - front finger guard - foot switch - Angle stop 0 - 180 - Operating instructions The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

This EHT ECOCUT was manufactured in 2003. A robust hydraulic shearing machine, it features a cutting length of 3,050 mm and a thickness capacity of 13 mm. It operates with an 18.5 kW main motor and includes an ELGO P8511 control for precision. Consider the opportunity to buy this EHT ECOCUT hydraulic shearing machine. Contact us for more information.

plate thickness: 16 mm cutting length: 4075 mm weight: 23 t output: 45 kw The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 125 t chamfer lenght: 3550 mm distance between columns: 3050 mm column arm: 300 mm stroke of ram: 240 mm quantity of oil: 200 l control: CYBELEC Cybtouch 15 range L-W-H: 4500x2200x3000 mm Equipment/accessories: - manual crowning - 3 x manual stop fingers - die displacement - pneum. upper tool clamping - foot switch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 135 t chamfer lenght: 3050 mm distance between columns: 2550 mm stroke: 400 mm quantity of oil: 300 l Control: Cybelec Visitouch total power requirement: 15 kW weight of the machine ca.: 10.700 Kg range L-W-H: 4200x2200x3200 mm Equipment: - Controlled axes: Y1, Y2, X, R, Z1, Z2 - SICK” light barrier in front of the machine - Side safety guards - Protective grille behind the machine - foot switch - incl. tools The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 4050 mm plate thickness: 10 mm column arm: 100 mm table height: 900 mm Number of hold downs: 21 Stück cutting angle: 2 ° total power requirement: 22 kW weight of the machine ca.: 17.100 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 3050 mm plate thickness: 10 mm control: Elgo 87 P2 : 11 - 31 Hub/min cutting angle adjustment: 1 - 4 ° Number of hold downs: 16 Stück : 900 kg : 11 kW table width: 700 mm table height: 800 mm range L-W-H: 4000 x 2220 x 1830 mm weight: 6300 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 3050 mm plate thickness: 16 mm distance between columns: 3100 mm no. of strokes: 16 Hub/min back stop - adjustable: 10 - 1000 mm cutting angle: 0,5 - 2,5 ° down holder: 13 Stück oil volume: 300 l total power requirement: 22 kW weight: 14000 kg dimensions: 4100 x 2300 x 2000 mm Features: - Electro-hydraulic slide-guided sheet metal shear - With ELGO P9724 NC digital control unit Input of target/actual values from the backgauge possible Digital display - Electro-hydraulic cutting angle adjustment - Electro-hydraulic cutting gap adjustment - Front finger guard - 1x sturdy side stop, with T-slot & mm scale - 3x front support arms - Hydraulic sheet metal hold-down - 2x emergency stop buttons at the front - Rear safety guard (protective grille) - Original operating manual Special accessories included: - Backgauge system conveyor belt with pneumatic sheet metal holding device ...

Working width: 3100mm, usable cutting length: 3050mm, max. sheet thickness: 16mm, stroke rate: 12/min, backgauge range: 10mm-1000mm, throat depth: 300mm, table width: 350mm, max. hydraulic pressure: 280bar, oil volume: 480l. Machine dimensions X/Y/Z: approx. 3700mm/2200mm/2000mm, weight: approx. 6600kg. An on-site inspection is possible.

; in order

Force of pressure: 75 t projection: 300 mm table size: 620 x 800 mm Durchfalloch in the table: 225 x 325 mm table adjustment: 175 mm plunger surface: 180 x 475 mm slide adjustment: 80 mm stroke adjustment: 16-140 mm stroke rate: 90 / min drive motor: 380 V, 3 kW space: 1700 x 1200 x 2500 mm weight: 3300 kg

Force of pressure: 63 t table size: 610 x 800 mm throat depth: 350 mm stroke: 200 mm Electr. Supply: 380 V, 15 kW space: 1800 x 920 x 2440 mm weight: 3940 kg

Eccentric C stand press, little used C frame - eccentric press, used Type: PED 63.3 S4 manufacturer: WMW Year of construction: 1994 Pressing power / rated pressure: 63 t Sheet thickness / material thickn. 3.2 mm Table size / surface of bed: 800 x 580 mm Hole in the table / hole in table: 300 mm diameter. Stroke / stroke of slide: 8... 120 mm Number / number of strokes: 56 / 90 / min Tappet adjustment / adjustment of slide: 70 mm The maximum distance between Table and plunger / max distance between table and slide: 560 m Projection / Cap: mm Power of main motor / power of main motor: 6 kW Weight / weight: 5.5 t

Pressing force: 40 t table size: 670 x 470 mm plunger surface: 670 x 470 mm clearance between the pillars: 620/470 mm gr. Height: 740 mm Preß speed: 20 mm / s rapid traverse: 50 mm ejector force: 3T Electr. Supply: 380 V, 9.5 kW space: 2200 x 1875 x 3000 mm weight: 2400 kg

Capacity: 50 ton Projection: 225 mm Stroke: 320 p/min Large table: 500 x 800 mm

The CNC press brake SMD PBH 110-3100-4C produced in 2006 is offered in a set with the ANTIL TWISTER F5 robot. Technical parameters : - manufacturer: SMD - type: PBH 110-3100-4C - year of production: 2006 - control: CNC CYBELEC ModEva 10 - overworked time: about 20,000 man-hours - pressure force: 110 tons - bending width: 3100 mm - maximum working speed: 10 mm / s - table width: 60 mm - table height: 960 mm - stroke: 465 mm - frame spacing: 2600 mm - throat: 410 mm - power supply: electric - 11.5 KW, 400 V three phases - oil tank capacity: 250 l - dimensions of the press: 3960 × 2045 × 3650 mm - total weight: 9500 kg Processing on a 3 m table and palletizing of finished details on 3 europallets.

Force of pressure: 30 to piston stroke: 150 mm table width: 185 mm passage (S): 530 mm bore (F): distance of 140 mm cylinders - table (F1): distance 150 mm cylinder - table (F2): 1030 mm cylinder movable (M): 200 mm width (A): (B depth of 800 mm): 700 mm height 1 (C): 1775 mm height 2 (D): 1805 mm weight: 162 kg

Pneumatic press 2643 Assembly through pivot table outside the working area With protective cage and release only with a retracted swing table Table size: 10 cm x 10 cm

Force of pressure: 50T piston stroke: 200 mm table width: 260 mm passage (S): 730 mm bore (F): distance 205 mm cylinder - table (F1): distance 75 mm cylinder - table (F2): 1050 mm cylinder movable (M): 240 mm width (A): 1040 mm depth (B): 800 mm height 1 (C): 1835 mm height 2 (D): 1880 mm weight approx.: 287 kg

Pneumatic press with foot-tripping

Maximum force: 1600 tons Slider stroke length: 400 mm Unattainable-course: 12 mm Number of courses of a slider per minute: 16 Number of single turn-on: 12 The closed height: 870 mm Adjustment: 220 mm Under-forginig plate: -From left to right: 1600 mm -From front to rear: 1600 mm -Thickness: 650 mm Slider overall dimensions: 1600x1600 mm Aperture in a table: 1000x1000 mm window dimensions in cheeks: 1650x1650 mm Course of a rigid pusher in a slider: 100 mm Force of a rigid pusher in a slider ton-force: 80 Main electric motor power: 110 kW Course of pneumatic pillow: 160 mm Force of pushing out of a pneumatic pillow ton-force: 71 Hydropneumatic pillow: -Working course: 250 mm -Force of pushing out ton-force: 25 -Force of a clip ton-force: 250 Press overall dimensions: 4670x4670x8110 mm Press weight: 140 tons

FRICTION BELT FOR SCREW PRESS DIRECT FROM THE MANUFACTURER! Description: -Chrome leather friction belt for screw presses, riveted, new! -Dimensions: 530 mm i. diameter x 50 mm high x 18 mm thick ON request make we the friction belts regarding to your sizes! For all machine types like SMS Hasenclever Berrenberg, Schuler, Weingarten, Vaccari, via, Mecolpress, Osterwalder... We deliver worldwide! We confirm best service and short delivery times.

Schuler PE4s 50/800 High Speed Press Manufacturer: Schuler Type: PE4s 50/800 High-speed press 61/21 600/3 Pressing force: 50 t Projection: 800 mm Stroke rate /min: 125-300 Plunger stroke: 40 mm Kohler unwinding reel 500.1 M We sell a large number of paternosters. The devices are in operation until 30.06.2021. After the purchase, there are also the documents for it From 01.07.21 the devices are ready for collection. Dismantling and transport by the buyer. Location is Hildesheim The dismantling, loading, as well as transport can alternatively be offered by us. In addition to about 50 paternosters, countless other machines are available. After purchase, the amount is due within 7 working days. Please also note our other offers. Have fun browsing and buying.

FRICTION BELT DIRECT FROM THE MANUFACTURER! Description: -Chrome leather friction belt for screw press, riveted, new! -Dimensions: 530 mm i.diameter x 50 mm high x 18 mm thick ON request make we the friction belts regarding to your sizes! For all machine types like SMS Hasenclever Berrenberg, Schuler, Weingarten, Vaccari, via, Mecolpress, Osterwalder... We deliver worldwide!

SMG DS 315-1500/1300 CNC hydraulic press was manufactured in 1984 in Germany. The machine, consisting of two interconnected stations, is used for pressing metal workpieces in manual, semi-automatic and automatic mode with a pressing force of up to 315 tonnes. All the machine’s machining parameters are set using a CNC control with a full-colour, touchscreen display. The press is equipped with a hydraulic and pneumatic sheet metal feeder, servo drives for feed rollers to set a very precise stroke of up to 0.1 mm, safety cages and workpiece feed and drop control sensors. The SMG 315 T machine underwent a complete overhaul in 2007, during which components such as pumps and safety installations were replaced. Technical data of the SMG DS 315-1500/1300 press - maximum press force: 315 t - working table dimensions (L x W): 1500 x 1300 mm - upper machine point (from the table): 750 mm ...

Force of pressure: 100 t projection: 350 mm table size: 690 x 840 mm Durchfalloch in the table: 160 mm table adjustment: slide area: 450 x 600 mm slide adjustment: 80 mm stroke adjustment: 8-100 mm stroke rate: 60 / min drive motor: 380 V, 5.5 kW space: 1850 x 1850 x 2650 mm weight: 6800 kg

With the universal hand punch NPR-20 can both on the front page as also Center of the punch be punched, so may here A4 sheet at any point are processed. The punch is suitable for cutting of printed materials in the Office, in the printer or in the copy shop. With a Nutmesser can A4 sheets are grooved. The NPR-20 is suitable for all cutting work, which can be with the NPR-10 through out. A countertop if necessary Additionally facilitates the stamping work

SINO NCP 160 eccentric press built in China in 2018 by Sino Machinery & Tools (Dongguan) Co., LTD. performs machining of metal workpieces with a press force of 160 tonnes. The machine is equipped with high-quality components, including e.g. a 100 mm adjustable slider making up to 25 to 55 strokes per minute, and a YU JAIV PDH-120 indicator displaying the distance of the die between the table and the slider. The large working area, ease of operation and outstanding precision, guarantee excellent machining results. The press offers the possibility of combining it with an automatic feeding system in order to increase the number of parts produced and significantly reduce costs. The total weight of the machine is 13 tonnes. Technical data of the SINO NCP 160 press - maximum press force: 160 t - work area dimensions (L x W x H): 910 x 600 x 410 mm - bolster dimensions (L x W x H): 125 ...

SPK KB 2132 eccentric press was manufactured in the USSR in 1980. Operating with a force of 160 tonnes, the press of almost indestructible design offers the highest quality and precision during the most demanding workpiece machining. The machine’s equipment includes among others a pneumatic clutch, a large-area slider performing up to 71 strokes per minute, central lubrication and manual control. The total weight of the press is 13200 kg. Technical data of the SPK KB 2132 press - maximum press force: 160 t - work table dimensions (L x W): 1000 x 700 mm - maximum slider stroke: 160 mm - minimum slider stroke: 25 mm - slider dimensions (L x W): 580 x 460 mm - slider adjustment range: 120 mm - slider stroke rate: 71/min - intermediate plate thickness: 110 mm - distance between work table and slider (slider in lower position, largest stroke, connector unscrewed): 480 mm - bore ...

With the universal hole punch NPR-20 can both on the front page as also Center of the punch be punched, so may here A4 sheet at any point are processed. The punch is suitable for cutting of printed materials in the Office, in the printer or in the copy shop. With a Nutmesser can A4 sheets are grooved. The NPR-20 is suitable for all cutting work, which can be with the NPR-10 through out. A countertop if necessary Additionally facilitates the stamping work.

PLASOMAT PMS 63 CP eccentric press was manufactured in Poland in 2004. In order to meet all production requirements, the machine features a large area slider with the possibility of adjusting the height and number of strokes in the control cabinet. In addition, a stable, deformation-resistant monolithic structure combined with a high pressing force of 63 tonnes ensures the highest accuracy and precision in machining. All this makes the PMS 63 CP press the ideal choice for both small batch and high volume production. The offer includes additional equipment, consisting of among others 8 anti-vibration pads and an intermediate table. Technical specifications of the PLASOMAT PMS 63 CP press - maximum press force: 63 t (630 kN) - work table dimensions (L x W): 800 x 560 mm - number of slider strokes: 65-85/min - maximum slider stroke: 110 mm - minimum slider stroke: 8 mm - slider adj ...

A roll punching press for stamping is available up to A3. The die is pulled under the roll.

Pneumatic multi function press Operating pressure 6-8 bar Weight 106 kg dimensions 0.70 x 0.38 x 1.05 m Comments: Multi function punch air consumption 18 l per stroke, pneumatic punching operation via foot switch tripping

ULTRAPRAS UPV100TT SPECIAL hydraulic press built in 2022 Poland is the perfect choice for a range of demanding cold metal forming operations. This highly efficient and versatile machine can perform such operations as precision bending, profiling, flattening, bending, hole punching and stamping. Inside the robust design, there is a power unit-powered hydraulic piston with a diameter of 220 mm, which performs all these machining processes with a high press force of 100 tonnes. In addition, the entire working area is protected by light curtains, thanks to which the UltraPras four-column press also offers a high level of operational safety. During its service life, the machine has operated for just 595 hours and completed a total of 37042 work cycles. The UPV 100 TT SPECJAL 100t hydraulic press weighs 6500 kg. Technical specifications of the ULTRAPRAS UPV100TT SPECIAL press - maximum pre ...

Pressure: 65 tons -Stroke: 140 mm -Table size: 720 x 600 mm -Plunger surface: 500 x 300 mm -Tappet adjustment: 80 mm -Strokes: 20-40 per min. -. Weight: 6000 kg -Dimensions (L x W x H): height 3.1 m -Clamping hole ø 60 x 80 mm More info on request

Table 1750 x 920 mm, fixed stroke 101 mm, see pictures and description,; All right

Description of the chip press: Powerful metal chip press with chip shredder for long turnings. The area of application is the processing of large quantities of milled and turning chips. Materials: aluminum, steel, cast iron Drip pan as oil tank Geared motor for optimal agitator operation Hydraulic Compression Cylinder Hydraulic press cylinder with two coaxial sections Diameter of briquettes 60 mm Automatic briquette length adjustment with displacement transducers Inductive Proximity Sensors Pre-compaction cylinder in conjunction with special compression hydraulic cylinder that compacts the material in the bushing-bulkhead unit Briquette ejection system, consisting of a compression chamber and a bulkhead with special anti-wear treatment Highly efficient closed-circuit oil cooling system consisting of an air/oil heat exchanger Hydraulic system with B ...

ULTRAPRAS WKR70H hydraulic press built in 2021 by the Polish company SAKOMET is designed for even the most demanding cold metal forming operations. The operations, such as precise cutting, stamping, punching and extruding of workpieces, are performed with a force of 16 tonnes using a hydraulic cylinder with a diameter of 100 mm. Induction limiters additionally allow adjustment of the piston advance and retraction limits, making the machine adaptable to the working range of various tools. In turn, centrally beneath the piston is a large cross-cut work table with a 90mm diameter bore. The UltraPras WKR 70H 16t hydraulic press weighs 420 kg. Technical specifications of the ULTRAPRAS WKR70H press - press force: 16 t - piston stroke: 70 mm - piston diameter: 100 mm - maximum working speed: 9.8 mm/s - minimum working speed: 2 mm/s - return speed: 20 mm/s - work table dimensions (L x  ...

Tech. Data Nominal press force 1000 kN at maximum stroke adjustment - commute 6.5 mm 1250 kN at maximum stroke adjustment - commute 3.5 mm Strokes with endurance 125/83/63 Hube/min Usable stroke rate 50 50 38 / min. Throat depth 320 mm, clamp 380 mm Stroke adjustment 10-120 mm, Stosselverstellung 80 mm Stosselflaeche 800 x 320 mm, recording journal 50 / 85 Tabletop table top hole, 900 x 630 mm 230 mm, Durchfalloch in the table 300 / 400 x 250 mm Drive - 7,5 / 5,5 kW Bulk 1350 x 2080 x 2780 mm, Btto 8900 kg

various hand spindle presses small More: Foot pendulum press Jantsch

Transfer press KRUPP PST-A 160 built in 1980. Technical data of the KRUPP PST-A 160 press: - nominal pressure: 160 tons - cutting force grade 1: 400 KN - force between stands: 1200 KN - number of working steps including cutting stage: 11 - distance between stands: 200 mm - slider stroke: 210 mm - drawing depth: 70 mm - range of jumps, infinitely adjustable: 15-75 / min. - production range of jumps with repeatability of its setting: 25-75 / min. - number of actuation movements: 15-25 / min. - a usable work resource for a jump in the range of 25-75 strokes per minute. : 20,000 J - maximum load on a single step: 500 KN - maximum load of a single step using inserts: 630 KN - maximum width of the tape: approx. 340 mm - maximum diameter of the cut: 120 mm - minimum diameter of the pattern: 30 mm - distance between stands: 2450 mm - height of tool building at the lower posi ...

Technical data: -Compressive force 100 t -Throat 320 mm -Wide stand below the Guide 400 mm -Table size approx. 850 x 610 mm -Discontinued diarrhea hole in the table 335 / 300 mm -thickness of the table clamping plate 90 mm -gr. Height approx. 300 mm -Plunger area 600 x 335 mm -Adjustable height of the RAM 80 mm -Stroke adjustment 10-130 mm -Emissions er hub in the RAM 32 mm -Speed continuous operation approx. 56 / min -Drive 400 V / 11 kW -Space requirement approx. B H 1900 x 2800 X 2200 mm -Weight approx. 9000 kg Starring:-UVV press backup controller PREVENTA -Hydr. + pneumatically actuated clutch -LUTEX auxiliary braking system -Central lubrication

Pressure capacity: 8000 kg Maximum cutting area - 200 mm2 for material strength 40 kg / mm2 Horizontal radius 200 mm Clearance between the side walls 160 mm Fixed hub 35 mm Pin hole in the Stossel 38 x 60 mm Adjustability of the Stossels 70 mm Weight of 400 kg of the Presse Operating instructions The machine is located in the new value. State, probably never in use. Control actuator Stober

Universal - NPR-55U Stanze Knee lever punch -Punching of paper, cardboard and plastics. -for simple stamping -The cutting blades can be recorded from the shaft -The cutting blades can be created also not attached just under the pressure plate. -The pictured tools are not part of the offer.

Pneumatic pin press for printed circuit boards

Key data: 3 t, 150 mm

For sale in new condition HYUNDAE CETTA HHP-3 hydraulic press "more pieces" manufacturer: HYUNDAE "Korea" type: HHP-3 year of manufacture: 2018 load range: 1-3 tons Stroke [mm] 150 open height: 250 mm -safety light gate -two-handed operation .-mobile work table Hyundae press control Pressing rod closing speed: 178mm/sec Pressing rod pressing speed: 54mm/sec Opening speed 79 mm/s Table size: 450x360mm Max. Working pressure: 60kg·f/㎠ Hydraulic motor 1,5 kW 3 phase/4P 200v Weight: 350kg machine height "without table": 1415mm machine length: 950mm machine width: ca 700mm working table with casters or level bolts

Hydraulic glue press with heating base, infinitely variable temperature setting, stuffenlose setting of the adhesive holding time, Power: 5 kW, 380 v 50 Hz; Two-hand operation.

Pneumatic pin press for printed circuit boards

Press Walter
