wire edm used for sale

Key data: 700 mm, 2900 kg

For sale; Mitsubishi die-sinking EDM machine type EA12D. The travel paths along the X, Y and Z axes are 400 x 300 x 300 mm. The maximum workpiece dimensions are 1000 x 650 x 350 mm. Control is Mitsubishi M700 CNC met 64-bit Fuzzy Logic. Maximum unit weight is 1000 kg. maximum electrode weight is 50 kg. The machine is equipped with a 4-station electrode changer with C-axis including 4 pieces of tool holder and transformer.

Year of construction 2006 Control Fanuc 18iS-WB Travel X/Y/Z/V/U 550/370/310/120/120 mm i-Plus high-performance generator Wire system: AWF system for automatic and safe threading. Start hole search function, threading in the cutting gap, short circuit Alarm function Equipment:Dielectric cooler, coolant tank, Aut. Rotary Insertion, Interface RS 232, El. Handwheel, Manuals Stenter frame: Erowa Please ask for price and pictures! This offer is aimed exclusively at entrepreneurs within the meaning of § 14 BGB. No returns for used goods. 3 months warranty.

CONTROLS    AGIEVISION TECHNICAL SPECIFICATION   Table-size          : 600 mm   Table-size          : 450 mm   Adjustment of  x-axis: 350 mm   Adjustment of  y-axis: 250 mm ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   total weight approx.: 6000 kg Regular service by AGIEOperating hours: 122'829hEroding hours: 23'101h SW disks available

1 x EDM machine Agie Cut Classic 2S BJ 2004 1 x EDM machine Agie cut Evolution BC2 BJ 1997

CONTROLS   CNC controls WORKING RANGE -CUBIC-   X-axis travel: 250 mm   Y-axis travel: 160 mm   Z-axis travel: 250 mm TECHNICAL SPECIFICATION   Table-size          : 480 mm   Table-size          : 330 mm   Adjustment of  x-axis: 250 mm   Adjustment of  y-axis: 160 mm ELECTRICAL SPECIFICATIONS   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 1200 mm   space requirements -front/back-: 1200 mm   total height: 2500 mm   total weight approx.: 1000 kg Equipment: -Agietron Compact 1 30A/C-axis / DAI 1-P -AGIE Fuzzytron -14" color screen -Fire extinguishing system -3-compartment electrode  ...

Inv. Num. : 8903 Type: Robofil 510 Producer: Charmilles Created: 1999 Parameters: Max. travel length of the X-axis: 250 mm Max. travel length of the Y-axis: 160 mm Max. travel length of the Z-axis: 150 mm Max. workpiece dimensions: 700 x 300 x 150 mm Max. workpiece weight: 200 kg Machine height: 2085 mm Machine length: 1660 mm Machine width: 1580 mm Machine weight: 2480 kg

Universal machine for eroding and grinding various PCD tools up to 250 mm in diameter and 200 mm in length in production and service. Accessories: Total enclosure,, Extraction N183,, Cooling and cleaning device for dielectric,, Automatic fire extinguishing device,, Loader for erosion disc sets with CNC-controlled swivel arm for loading and unloading, 1 set of gripper fingers for workpiece automation HSK 63/SK40, Workpiece carrier adaptation A-axis from SK 50 to HSK 63 A,, 1 exchange element with flange,, 1 x flushing kit,, Test bar, X axis travel: 440 mm, B-axis: +/- 15°, Y axis travel: 876 mm, Z-axis travel: 420 mm, E-axis swivel range: 210°, A-axis rotation range: 360°, workpiece carrier base: SK 50, workpiece length max.: 200 mm, Workpiece diameter max.: 250 mm, workpiece weight: 15 kg, Connected load approx.: 6.7 kW 400V/50 Hz, Weight approx: 7000 kg, Dimensions W x D x H =: 1987  ...

This 3-axis CHARMILLES ROBOFORM 35 die-sinking EDM machine was manufactured in 2000. It features low working hours and comes with additional accessories including various UPC pallets, tool holders, a Diebold shrink wrapping machine, and a cooler. Consider the opportunity to buy this CHARMILLES ROBOFORM 35 die-sinking EDM machine. Contact us for more information.

This GF Agie Charmilles Form E600 Erosion machine was manufactured in the year 2018 in China. It is equipped with a GF AC FORM HMI control unit.

This 4-axis PENTA 1060 CNC die-sinking EDM machine was manufactured in 2014. Ideal for detailed and precise metalwork, it offers advanced control and efficiency. Consider the opportunity to buy this PENTA 1060 CNC die-sinking EDM machine. Contact us for more information.

This Sodick AG60L Die-sink EDM machine was manufactured in 2012. It features a ceramic table measuring 750 x 550 mm and can handle a maximum workpiece weight of 1500 kg. The machine includes a linear motor, glass scales, and a remote control for enhanced precision and ease of use. Consider the opportunity to buy this Sodick AG60L die-sink EDM machine. Contact us for more information about this machine.

This AgieCharmilles FORM 30 was manufactured in 2014. A robust die-sinking EDM machine, its ideal for detailed and precise metalwork. Consider the opportunity to buy this AgieCharmilles FORM 30 die-sinking edm machine. Contact us for more information.

This 4-axis AgieCharmilles FORM 30 die-sinking EDM machine was manufactured in 2016. It features X, Y, and Z-axis movements of 600 mm, 400 mm, and 400 mm respectively, and a C axis for enhanced versatility. The table measures 800 x 600 mm, supporting workpieces up to 1000 x 700 x 400 mm. Weighing 4200 kg, consider the opportunity to buy this AgieCharmilles FORM 30 die-sinking EDM machine. Contact us for further details regarding this machine.

This CHARMILLES ROBOFORM 51 Erosion machine was made in 1998. The machine has a table size of 750x500 mm.

This 3-axis Makino EDNC 30 die-sinking EDM machine was manufactured in 1998. It features travel paths of 300mm in X, 250mm in Y, and 250mm in Z, a table size of 500 × 350 mm, and can handle a maximum workpiece weight of 500 kg. Consider the opportunity to buy this Makino EDNC 30 die-sinking EDM machine. Contact us for more information about this machine.

EDM machine Mitsubishi MV 1200 R

The Charmilles Robofil 2020 is a high-precision Wire Electrical Discharge Machine (Wire EDM). Manufactured in Switzerland, this machine is designed for detailed "erosion" work, making it a staple in toolmaking and the production of complex medical or industrial components. Here is a clean, structured text block for the Charmilles Robofil 2020 (1994) that you can copy and paste directly into an online listing or equipment database. --------------------------------------------------------------- Machine Specifications: Charmilles Robofil 2020 General Information - Manufacturer: Charmilles Technologies (Switzerland) - Model: Robofil 2020 - Year of Manufacture: 1994 - Machine Type: CNC Wire-Cut Electrical Discharge Machine (Wire EDM) Technical Travel & Capacity - X-Axis Travel: 320 mm (12.5") - Y-Axis Travel: 220 mm (8.6") - Z-Axis Travel: 116 mm (4.5") - U/V Axis Travel: ± 48 mm (fo ...

CONTROLS   CNC controls TECHNICAL SPECIFICATION   Case size: 860 mm   .. x: 620 mm   Adjustment of  x-axis: 350 mm   Adjustment of  y-axis: 250 mm   Erosion stroke: 350 mm   Max. dist. table-electr.clamp.surf.: 520 mm ELECTRICAL SPECIFICATIONS   mains power supply: 8.3 kVA   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 2700 mm   space requirements -front/back-: 1900 mm   total height: 2600 mm   total weight approx.: 3000 kg Description - Work container can be lowered - C axis for rotation, indexing and erosion - AGIEVISION control incl. TECTRON, AGIESETUP 2D - USER SEQUENCE, SPACETRACK, AGIEPATH with GEOEDITOR - Electrode changer 28 times - Incl. EROWA pneumatic chuck

This 3-axis CHARMILLES ROBOFORM CT 400 was manufactured in 1996. It features X-axis travel of 450 mm, Y-axis travel of 320 mm, and Z-axis travel of 410 mm. The tank dimensions are 1195x800x400 mm, supporting a maximum workpiece weight of 800 kg. If you are looking to get high-quality die-sinking capabilities, consider the CHARMILLES ROBOFORM CT 400 machine we have for sale. Contact us for more information.

Suitable for the automatic processing of PCD-tipped milling cutters, shank tools, disc-shaped tools such as saws, milling cutters etc. using the wire-electro-erosion process., Accessories:, Total enclosure,, Adaptation to A-axis on HSK63-A,E incl. test mandrel Ø 25 mm System HSK63 A,E, Integrated loading system and workpiece magazine for automated processing of up to 12 workpieces., Probe,, Automatic central lubrication,, Coolant system for dielectric fluid,, Automatic fire extinguishing system,, Mist extractor,, Machine lamp., Cutter outside diameter: Max. 320 mm, Shank tool diameter: 10-320 mm, Outside diameter disc-shaped tools: Max. 320 mm, Cutting length: max. 480 mm, Tool weight: max. 20 kg, X axis travel: 500 mm, Y-axis travel: 300 mm, W-axis travel: 200 mm, A-axis rotation range: 360 °, E-axis swivel range: 180 °, Required space for the machine: 2535 x 2200 x 2280 mm, Weight a ...

This 4-axis Mitsubishi EA 12S die-sinking EDM machine was manufactured in 2016 in Japan. It features X/Y/Z travels of 400/300/300 mm, a maximum workpiece weight of 700 kg, and a stainless steel table measuring 700 × 500 mm. Equipped with a C-axis and Erowa chuck, it also includes a dielectric filtration system with a 400 L tank. Consider the opportunity to buy this Mitsubishi EA 12S die-sinking EDM machine. Contact us for more information about this machine.

EDM machine Charmilles Robofil 100

This 3-axis AGIE AGIETRON Innovation 2 die-sinking EDM machine was manufactured in 2002. It features a robust AGIEVISION control system, a 28-position electrode changer, and a C-axis for rotation, indexing, and erosion. The machine can handle workpieces up to 650 x 580 x 250 mm and 400 kg. It boasts a high-performance AGIE IPG generator with a removal rate of 450 mm³/min for copper/steel. Consider the opportunity to buy this AGIE AGIETRON Innovation 2. Contact us for more information.

This Mitsubishi Electric SG12M die-sinking EDM machine was manufactured in 2020. It features a robust 3750 kg weight, with a maximum workpiece weight capacity of 1000 kg. The machine includes a dielectric fluid chiller unit and a dual paper filter system, ensuring optimal operational conditions. The working tank has an automatic elevation system and hinji open-door for ease of use. If you are looking to get high-quality die-sinking capabilities, consider the Mitsubishi Electric SG12M machine we have for sale. Contact us for more information.

This 3-axis CHARMILLES HD10 start hole drilling machine was manufactured in 2002. It features a work table size of 600x300mm, XY-travel of 350x250mm, and can handle a maximum workpiece weight of 450kg. Ideal for precise erosion tasks, the CHARMILLES HD10 machine we have for sale represents a robust addition to any machining setup. Contact us for further details regarding this machine.

2 x EDM machines Charmilles Robofil 2020 BJ 1994 and Charmilles Robofil 4020 BJ 1996

EDM machine Ingersoll OPS 600

Manufacturer:Agie Model: Agiecut Challenge 2 Year of Manufacture: 2001 Machine Type : Wire EDM Machine Find more here - / Contact us at -

This 3-axis Zimmer+Kreim Genius 700 Magic 3 was manufactured in 2009. It features a table with T-slots, dimensions of 575 x 500 mm, and a 24-position electrode changer. The machine can handle a maximum workpiece weight of 700 kg and offers a travel range of 400 x 350 x 350 mm. Consider the opportunity to buy this Zimmer+Kreim Genius 700 Magic 3 die-sinking EDM machine. Contact us for more information about this machine.

This Sodick AD 55 L die-sinking EDM machine was manufactured in 2016. It features a work tank with internal dimensions of 1200 x 800 x 500 mm and a capacity of 470 liters, supporting a maximum workpiece weight of 1000 kg. Equipped with a cooling unit for the linear motor, a C-axis, and a SGF generator unit, it offers robust performance for precision applications. Contact us for more information about this machine.

Sinking EDM machine SEIBU-WALTER SW-5000C5/AWF2B, xyz axis approx. 300x200x400 mm, dead weight approx. 1,300 kg, DEFECTIVE!

This 6-axis VOLLMER QXD 250 grinding machine was manufactured in 2017. It features a robust 3 Phase 380Volts, 50hz, 8.7KVA power supply and a substantial coolant tank capacity of 310 liters. With a machine weight of 7,200kg and comprehensive axis movement, including a 360-degree swivel angle on the A-Axis and +/-20 degrees on the B-Axis, consider the opportunity to buy this VOLLMER QXD 250 grinding machine. Contact us for more information about this machine.

This 4-axis AgieCharmilles FORM 30 was manufactured in 2017. It features a stroke of 600mm x 400mm x 400mm, with axis speeds up to 6 m/min. The machine can handle workpiece weights up to 1000kg and dimensions of 1000 x 700 x 400 mm. It includes a dielectric unit with a 750l capacity and a robust weight of 4400kg. Consider the opportunity to buy this AgieCharmilles FORM 30 die-sinking EDM machine. Contact us for more information about this machine.

This 4-axis OPS INGERSOLL Gantry 1200 was manufactured in 2007. It features a 3000-liter dielectric capacity, machine feet, two heavy-duty pallets, and a 3R clamping system. Ideal for precision die-sinking EDM applications. Contact us for more information about this machine.

This 3-axis AgieCharmilles CABINET FORM20 die-sinking EDM machine was manufactured in 2012. Ideal for precision mold making and tooling applications, it offers robust performance and reliability. If you are looking to get high-quality die-sinking capabilities, consider the AgieCharmilles CABINET FORM20 machine we have for sale. Contact us for more information.

2011 OPS Ingersoll Gantry Eagle 5 (often referred to as the Eagle G5 or Gantry Eagle 500) is a high-precision Sinker EDM (Electric Discharge Machining) machine. Feature Specification X / Y / Z Travels 525 mm / 400 mm / 450 mm Work Tank Type Drop-tank (rises/falls for easy access) Max Workpiece Weight 1,000 kg (2,205 lbs) Generator Eagle PowerSPARK (60 Amp standard, 110 Amp optional) Z-Axis Jump Speed 18 m/min (This is exceptionally fast for EDM) Find more here - / Contact us at -

Die-sinking edm machine manufactured in 2005. This Exeron 310 machine features a table dimension of 550 × 350 mm and a maximum workpiece weight capacity of 500 kg. With a robust design, it weighs 1,600 kg and has overall dimensions of 2,300 x 1,600 x 2,400 mm. Consider the opportunity to buy this Exeron 310 die-sinking edm machine. Contact us for further details.

This 3s Sodick AG55L die-sinking edm machine was manufactured in 2008. With a magazine capacity of 32 positions and a maximum workpiece weight of 1000 kg, it offers robust capabilities for precision machining. The X travel reaches 550 mm and Y travel extends to 400 mm, making it suitable for various applications. Consider the opportunity to buy this Sodick AG55L die-sinking edm machine. Contact us for further details.

This 3-axis CDM Rovella BF 600 die-sinking EDM machine was manufactured in 1997. It features a 1400x700 mm working area and comes with equipment included. If you are looking to get high-quality die-sinking capabilities, consider the CDM Rovella BF 600 machine we have for sale. Contact us for more information about this machine.

This 3-axis ONA DB300 die-sinking EDM machine was manufactured in 2006. It features an X-axis travel of 300 mm, Y-axis travel of 200 mm, and Z-axis travel of 250 mm. The work table dimensions are 400 x 300 mm, with a maximum workpiece weight of 200 kg. If you are looking to get high-quality die-sinking capabilities, consider the ONA DB300 machine we have for sale. Contact us for further details.

This 3-axis CHARMILLES Roboform 350 die-sinking EDM machine was manufactured in 2006. It features travel paths of 350 x 250 x 300 mm and can accommodate a maximum electrode weight of 25 kg. The machine has a power consumption of 7.5 kVA and weighs 2350 kg. If you are looking to get high-quality die-sinking capabilities, consider the CHARMILLES Roboform 350 machine we have for sale. Contact us for further details.

The machine is in good technical condition, after prior agreement it is possible to test it. Workpiece weight (max.): 1,000 kg X-axis travel distance: 600 mm Y-axis stroke: 400 mm Z-axis stroke: 310 mm Wire diameter (max.): 0.3 mm Workpiece height (max.): 310 mm Width (max.): 1,050 mm X-axis feed: 600 m/min Y-axis feed speed: 1,000 m/min Table load: 1,000 kg Equipment: refrigerator, compressor

This 3-axis AgieCharmilles Spirit 3 was manufactured in 2008. It features an integrated C-axis and electrode magazine, multitasking operating system with object-oriented graphical interface (AEP Spirit), and a table size of 850×650 mm. Movement range includes X:550, Y:400, Z:350. Consider the opportunity to buy this AgieCharmilles Spirit 3 wire EDM machine. Contact us for more information about this machine.

This 4-axis AGIE AGIETRON SPIRIT 3 die-sinking EDM machine was manufactured in 2007. It features an X travel of 550 mm, Y travel of 400 mm, and Z travel of 350 mm, with a maximum workpiece weight of 1,000 kg. The machine includes a high-performance 72 Amp generator and a tool changer capacity of 10 electrodes. If you are looking to get high-quality die-sinking capabilities, consider the AGIE AGIETRON SPIRIT 3 machine we have for sale. Contact us for further details.

Auction-ID: A1-44905-123

This 3-axis HUBER OCT-3020 NA die-sinking EDM machine was manufactured in 2006. It features a travel of 300 mm in the X-axis, 200 mm in the Y-axis, and 350 mm in the Z-axis, accommodating workpieces up to 460 x 210 x 200 mm. If you are looking to get high-quality die-sinking capabilities, consider the HUBER OCT-3020 NA machine we have for sale. Contact us for further details.

This 3-axis AGIE AGIETRON INTEGRAL 2 was manufactured in 2006. It features a travel of 350 mm in the X-axis, 250 mm in the Y-axis, and 350 mm in the Z-axis. The machine can accommodate workpieces up to 840 x 670 x 250 mm and has a maximum electrode weight of 100 kg. If you are looking to get high-quality die-sinking capabilities, consider the AGIE AGIETRON INTEGRAL 2 machine we have for sale. Contact us for further details.

Refurbished 2022 Travel distances: X= 350 mm, Y= 250 mm, Z= 256 mm Travel of U/V axis: +/- 70 mm Maximum conicity: 30° at 100 mm height Maximum workpiece dimensions: 750 x 550 x 250 (150 in the bath) mm Maximum workpiece weight: 200 (in bath) / 450 (without bath) kg Achievable surface quality: Ra: 0.30 μm Medium contour tolerance: +/- 6 μm Maximum cutting rate: 300 mm²/min Available wire diameters: 0.20 – 0.33 mm Water bath machine with autom. Wire threading and rethreading after wire breakage

This 4-axis +GF+ AgieCharmilles FO 350SP die-sinking EDM machine was manufactured in 2013. It features a stable EDM generator, a fully operational 360° C-axis with a rotational speed of 100 rpm, and a substantial work area of 800 × 550 × 370 mm. Well-maintained and operational until its last day, consider the opportunity to buy this +GF+ AgieCharmilles FO 350SP die-sinking EDM machine. Contact us for more information about this machine.

Machine Details - Manufacturer: Sodick - Model: AD55L - Year of manufacture: February 2016 Electrical Specifications - Supply voltage: 200 V - Phase: 3-phase - Frequency: 50/60 Hz - Rated capacity: 8.5 kVA - Full load current: 24 A - RMS symmetrical amps: 50 A Operating Hours - Total operating hours: 3050 - Machining hours: 1470 - Included Accessories - Electrode holder - Approximately 20 clamping brackets - 1 dial gauge - DI and electrical components installed in the machine Additional Information The storage system expired in 2022. DI unit and all electrical components are installed and remain with the machine. A test piece can be machined upon request prior to purchase Find more here - / Contact us at -
