Ø grinding wheel dimensions (od x id x width): 325 x 175 x 125 mm, Ø min / max to grinding: 1.5 / 50 mm, Regulating wheel width: 125 mm, Regulating wheel speed nº: infinite, Infeed (auto / manual): Auto 125 mm max., Regulating wheel dimensions (od x id x width): 220 x 125 x 125 mm, Grinding wheel width: 125 mm, Maximum infeed grinding length: 125 mm, Motor power grinding wheelhead: 7,5 Kw, Long: 1.520 mm, Width: 1.020 mm, High: 1.260 mm, Weight: 1,600 Kg.

Technical data Table length: 840 mm Table width: 250 mm Grinding length: 600 mm Grinding width: 350 mm Execution: hydraulic Max. distance from table to spindle-centreline: 550 mm Longitudinal travel (X-axis): 620 mm Cross travel (z-axis): 320 mm Automatic cross-feed: stepless up to: 1.2 m/min Table speeds: stepless from: 1 m/min up to: 25 m/min Automatic vertical feed: from: 0.002 mm up to: 0.060 mm Diameter of grinding wheel: 300 mm Width of the grinding wheel: 50 mm Wheel int. diameter: 76 mm Grinding wheel speeds: number (steps): 2 from: 1400 rpm up to: 2800 rpm Voltage 50 Hz 3x: 380 Volt Grinding spindle motor: 5.2 HP Machine´s weight about: 2800 kg Overall dimensions machine: Length: 2800 mm Width: 1800 mm Height: 2200 mm Various accessories: Wheel trueing attachment Set of flanges: 2 x

Technical data Table length: 1100 mm Table width: 600 mm Grinding length: 1200 mm Grinding width: 550 mm Grinding height: 400 mm Table load max.: 750 kg Longitudinal travel (X-axis): 1300 mm Transversal travel (y axis): 470 mm Automatic cross-feed: stepless up to: 2.5 m/min Table speeds: stepless from: 1 m/min up to: 30 m/min Automatic vertical feed: up to: 300 mm/min Diameter of grinding wheel: 400 mm Width of the grinding wheel: 100 mm Wheel int. diameter: 127 mm Grinding wheel speeds: from: 1440 rpm Voltage 50 Hz 3x: 400 Volt Grinding spindle motor: 7.5 kW Machine´s weight about: 6700 kg Overall dimensions machine: Length: 4800 mm Width: 2300 mm Height: 2300 mm Various accessories: Coolant system Paper filter facility: 460 mm Magnetic plate: Length: 1200 mm Width: 500 mm Wheel trueing attachment Digital readout number of axis:: X - Z Manufacturer: Heidenhain Lamp Central lubrif ...

Rogers 300 HYD Knife Roll Grinder Model: 300 HYD Size 102 Year of arrival at the plant: 1961 Space used by the machine: 7 x 2 x 1,8m Worktable dimensions: 2600 x 250,50 mm. Longitudinal table travel (stroke): 3000 mm. Magnetic system of the table: EML 15 - 115 Volts - 13 Amp - 1500 Watts. Longitudinal slide feed: 0 - 28 m/min. Cross travel without abrasive wheel: 200 mm. Cross travel with new abrasive wheel: 92 mm. Vertical Capacity: 200 mm. Abrasive wheel: Ring abrasive wheel, 26" outer dia., made up of 10 segments type 53 (S/G FLAT RS-801-B) of 6.1/2 "x 2 "x6". Each segment must indicate the maximum RPM for the ring. Abrasive wheel head speed: 560 Rpm. Cooling tank capacity: 259 liters

TECHNICAL INFORMATION:, Grinding wheel dimensions (h x w x d x w) 325 x 175 x 125 mm, Ø min/max to be ground 1,5 / 50 mm, Width of regulating wheel 125 mm, Lubrication (auto/manual) Manual, Type of control (cnc/manual) Manual, Plongee (auto/manual) Auto 125 mm max., Dimensions of regulating wheel (h x w x d x w) 220 x 125 x 125 x 125 mm, Grinding wheel width 125 mm, Max. length to be ground in plunge plunge plunge 125 mm, Motor power grinding wheel head 7,5 Kw, DIMENSIONS AND WEIGHT:, Length 1520 mm, Width 1020 mm, Height 1260 mm, Weight 1600 Kg

Centerless external cylindrical grinding machines Herminghausen SR 40-3 Machine Was improved and rebuilt by the company Ebert. Thus type designation CL 43. Original price 299.000, - €. Operating voltage: 400 volts, power consumption: 22 kW, workpiece diameter 2 - 130 mm, largest grinding length for through grinding 250 mm, grinding wheel diameter min/max 400/600 mm, grinding wheel bore 604.8 mm, control wheel diameter min/max 220/300 mm, control wheel bore 152.4 mm, grinding wheel circumferential speed 40 m/s, control spindle speed infinitely adjustable 0 - 200 rpm, control Siemens S7, cooling lubricant supply unit, weight of the machine ca. 6000 medical history Errors excepted!

NC – controlled precision rotary table face grinding machine with vertical grinding spindle and cup grinding wheel - brand new Rotary table diameter 400 mm Largest grindable diameter 400 mm Rotary table speeds 0 to 50 rpm infinitely variable Maximum workpiece weight 75 kg Cup grinding wheel Ø 200 mm x H 80 mm Grinding wheel speed 280 to 2,800 rpm infinitely variable Maximum workpiece height 170 mm Smallest programmable infeed dimension of the grinding wheel 0.001 mm Grinding wheel drive power 3 kW Rotary table drive power 0.5 kW Weight approx. 650 kg

grinding length: 630 mm grinding width: 200 mm workpiece height: 400 mm x-travel: max. 710 mm y-travel: max. 250 mm distance between table/spindle: max. 500 mm table surface area: 600 x 200 mm table speed -stepless-: 2 - 18 m/min cross feed of table continual: 0 - 4 m/min cross feed of table intermittent: 0,2 - 20 mm/Hub grinding wheel size: ø 200 x 20 mm grinding wheel hole diameter: ø 51 mm grinding spindle speed: 2830 U/min grinding wheel motor: 1,1 kW total power requirement: 6,5 kW weight of the machine ca.: 1,4 t Accessories: magnetic plate 600 x 200 mm, DRO on Z-axis, various grinding wheels, 1 grinding wheel with flange, wheel trueing attachment, wet grinding attachment The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

WEINIG Rondamat 912, S/N 912-497 – fully automatic tool grinding machine • Automatic re-sharpening of straight planing knives in the cutter head with conventional or hydro-clamping • Automatic resharpening of cutters in the hydroplaning head (in front of the chest) • Automatic dividing head for up to 36 cutting edges • concentricity tolerance of less than 0.005 mm • Integrated coolant device • Table feed infinitely variable (forward / return) • Easy operation via membrane keypad and digital displays Specifications • Grinding mandrel D=50 mm • Planer head diameter min. 80 mm to max. 280 mm • Grinding length max. 260 mm • Table stroke 500 mm • Programmable knife count from 2 – 36 • Programmable grinding cycles per tool 1-9 • Clearance angle infinitely adjustable 15° – 35° • Axis angle max. 15° • Grinding spindle speed n=4,600 r ...

control: SIDAC (Touch) Number of axles: 2 St. centre height: 100 mm centre distance: 650 mm grinding wheel dia. x width: 350x32 mm grinding wheel hole diameter: 127 mm grinding wheel turining speeds: 1600-2200 U/min grinding head - revolution: -15/+30 ° cross slide - travel: 170 mm workpiece spindle head:: turning speed range - stepless: 30-1200 U/min grinding head swivelling: 0-90 Grad spindle bore: 24 mm spindle cone MT: 4 tailstock quill taper MT: 2 table travel longitudinal: 650 mm max. angular position of the table: 15/30 ° motor: 400 V grinding wheel motor: 3 PS dimensions of the machine ca.: 2.0x1.6x1.8 m weight of the machine ca.: 2.3 t dressing device: grinding wheel flanges: number: 3 The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Heavy-duty castor, polyurethane heavy-duty wheel, PU wheel Pagus wheel diameter: Ø 200 mm wheel width: 80 mm for shaft diameter: Ø 50 mm Shaft length in wheel: 88 mm New ! Dimensions: 200 x 200 x 88 mm

Heavy duty roller, polyurethane heavy duty wheel, PU wheel PAGUS wheel diameter: Ø 180 mm wheel width: 50 mm for shaft diameter: Ø 35 mm Shaft length in wheel: 50 mm groove width: 10 mm New Dimensions: 180 x 180 x 50 mm

Key data: 1000 mm, 285 mm, 1000 mm

Studer S33 CNC Universal Cylindrical Grinder New 2018 CNC Control: yes Type of CNC Control: Fanuc Oi-TD Capabilities and Features: 350mm x 1000mm OD Grinding Wheel Dimensions: 500 x 63 x 203,2 mm X-Axis Travel: 285 mm Z-Axis Travel: 1000 mm Resolutiion: 0,0001 mm Max. work piece weight between centers: 80 kg Swivel Table: -15 - +225 ° Indexing: B axis Automatic 1° Hirth Coupling Grinding wheel size: 500 x 63 x 203,2 mm Peripheral speed max.: 50 m/sec Motor power capacity: 14.47HP / 11kW Work piece spindle head: See Specs Below: See Specs Below Number of revolutions: 1 - 1.500 rpm Workhead Motor Power capacity: 1,6 / 3 kW Spindle passage: 30 mm Fitting taper: MK 5 Center Height: 175 mm Workload: 80 kg Machine-Datasheet - Overall: SEE BELOW C-Axis: 0,0001 ° Tailstock: yes Tailstock: - Taper Center Size: MK 4 Travel:: See Below X-Axis ...

CNC-controlled erosion machine for the processing (erosion, grinding, polishing) of PCD tipped tools up to 400 mm diameter and 400 mm length, according to disc-electrical-erosion processes for use in service and in production., Accessories:, Total enclosure,, Software path management,, Software end mill (207/208),, Software disc-shaped workpieces on the front side (221/222/223/224),, Software profiled workpieces (233/234/239/240),, Software hogger, hogger profiled (255/256/257/258/260/261/262/263), Software for disc-shaped workpieces (264/265),, Software for end and joint milling cutters (267/268/277/278),, Software step tools (271),, Software scoring saws (299),, Software saws flat tooth (301), Software saws one sided with bevel (302/303),, Software saws alternating teeth (304),, Software saws trapezoid trapezoid tooth (309),, Software saws flat roof tooth (310),, Software saws flat-tra ...

Heavy-duty castors, heavy-duty wheel, tire, forklift drive wheel -Manufacturer: Gumasol heavy duty roller heavy duty wheel -Wheel size: 250/80-170 -Number: 5x wheel available -Price per piece -Weight: 5.1 kg/pc.

Chassis, jockey wheel, load wheel tandem, load rollers -Chassis: load wheel tandem for pallet trucks, electric forklifts -Wheel: Ø 80 mm -Recording/Dimensions: see photos -Number: 2x load wheel available -Price per piece -Dimensions: 220/125/H80 mm -Weight: 4.2 kg

Running gear, support wheel, load wheel tandem, load rollers, steering roller, support roller, fixed roller, swivel wheel -Manufacturer: Powerthane / Jungheinrich, jockey wheel from electric pallet truck ECE 20 -Wheel size: 180 x 65 mm -Number: 1x support roller available -Price per piece -Dimensions: 235/160/H240 mm -Weight: 13,1 kg/pc.

Running gear, support wheel, load wheel tandem, load rollers, steering roller, support roller, fixed roller, swivel wheel -Manufacturer: Powerthane / Jungheinrich, jockey wheel from electric pallet truck ECE 20 -Wheel size: 180 x 65 mm -Number: 1x support roller available -Price per piece -Dimensions: 240/160/H280 mm -Weight: 13 kg/pc.

Heavy duty castors, heavy duty wheel, tire, forklift drive wheel -Heavy duty wheel: forklift drive wheel -Wheel size: Ø 228 x 90 mm -Pitch circle: Ø 65/12 mm -Weight: 7.6 kg

WEINIG Rondamat R 912 S/N 912-497, YOC 1995 – Ref.-No. 119130 – fully automatic tool grinding machine • Automatic resharpening of straight planer knives in the cutter head with conventional or hydro clamping • Automatic resharpening of milling cutters in the hydraulic planer head (in front of the chest) • Automatic divider for up to 36 cutting edges • Concentricity tolerance below 0.005 mm • Integrated coolant device • Table feed infinitely variable (forward / return) • Easy operation via membrane keypad and digital displays Specifications • Abrasive mandrel D=50 mm • Planer head diameter min. 80 mm to max. 280 mm • Grinding length max. 260 mm • Table stroke 500 mm • Programmable number of knives from 2 – 36 • Programmable grinding circuits per tool 1-9 • Free-angle infinitely adjustable 15° – 35° • Axis angle max. 15° • Gr ...

Max grinding diameter - 200 mm working grinding wheel - 508 x 305 x 254/280 mm Rotational speed of the working grinding wheel - 1240 rpm. Sliding wheel - 270 x 150 x 254/280 mm The rotational speed of the feed wheel - 15-250 rpm. The turning angle of the spindle of the feed grinding wheel In the vertical plane - 0-8 ° In the horizontal plane - ± 4 ° Overall dimensions of the machine tool: length 2565 x width 1650 x height 1700 mm weight of the grinder: approx. 5200 kg

max diameter of the tooth heads wheel: 300 mm minimum diameter of the bottom of the grooves: 10 mm max number of teeth: 130 min. number of teeth: 12 (10) max module: 5 max angle of teeth inclination: 45 degrees sled stroke: 180 mm max object weight: 60 kg max diameter of grinding wheel: 350 mm min. grinding wheel diameter: 270 mm grinding wheel width: 62/84 mm grinding wheel hole: 160 mm

Cylindrical Grinder GU32x60S Capacity Distance between centers 600 mm Swivel over table Ø320 mm Max. load of centers 100 kg Max. external grinding diameter Ø300 mm Wheel head Swivel angle ±30° Manual distance 160 mm Auto. rapid advance 40 mm Sliding seat supplementary displacement 95 (total 295) mm Min. setting unit (micro-adjust) 0.001 mm One turn of handwheel (graduation) 2 (0.005) mm Grinding wheel O.D. x width x I.D. Ø405 x 50 x Ø127 mm Speed (belt type) 1783 r.p.m. (50 Hz) / 1940 r.p.m. (60 Hz) Work spindle head Swivel angle 120° (+90°, -30°) Center taper MT. 4 Spindle speed (variable) 10~300 r.p.m. Max. load of spindle (tool holder includer) 35 kg (max. length : 150 mm) Tailstock Taper center MT. 4 Stroke 25 mm Table Swivel angle -2° ~ +10° Traverse speed 50 / 5400 mm/min Auto. reciprocate min. stroke 8 mm F ...

Ribon RUR1500 metric, Italy made, universal OD/ID grinding machine, in very good condition, with low hours. The machine has electric table movement, and sold with many accessories. Now stock clearance, price reduced by 15% from 9350 to 7950 EUR net! (2020.07.12.) EXW price, loaded for free on suitable truck. EU shipping at very friendly prices. Please ask if any questions. B/C: 1500mm Max. grinding diameter: 320mm Centre height: 160mm Max. weight suspended between centres: 170Kg Size of the grinding wheel: 355 (410) x 32 (60) x 127mm (The cover could take 455mm wheel) Work spindle bore: 24mm Work spindle taper: Morse 4 Taper of centre support: Morse 3 Speed of wheel: 1500/ 1730 RPM Work spindle speed: 35-310 F p. perc one increment on X wheel: 0.005mm Table swing: + - 5° Work spindle housing swing: -30° és + 90° ID spindle diameter: ...

Ø grinding wheel dimensions (od x id x width): Ø610 x Ø304.8 x 254 mm, Ø min / max to grinding: 1.5 / 125 mm, Regulating wheel width: 254 mm, Regulating wheel speed nº: infinite, Diamond dressing speed: 225 min1, Infeed (auto / manual): 254 mm, Regulating wheel dimensions (od x id x width): Ø355 x Ø203.2 x 254 mm, Grinding wheel width: 254 mm, Maximum infeed grinding length: 254 mm, Motor power grinding wheelhead: 30 kW, Power hydraulic motor: 0,37 kW, Long: 5.175 mm, Width: 2.950 mm, Weight: 8.375 kg

Ø grinding wheel dimensions (od x id x width): 325 x 175 x 125 mm, Ø min / max to grinding: 1.5 / 50 mm, Regulating wheel width: 125 mm, Regulating wheel speed nº: infinite, Dressing (auto / manual): 1.5 / 50 mm, Infeed (auto / manual): Automatic / Automatic, Regulating wheel dimensions (od x id x width): 220 x 125 x 125 mm, Grinding wheel width: 125 mm, Maximum infeed grinding length: 125 mm, Motor power grinding wheelhead: 7,5 Kw, Long: 1.520 mm, Width: 1.020 mm, High: 1.260 mm, Weight: 1,600 Kg., Accessories included:

: neu : ca. 6 Monate ab Auftragse : Taiwan : 111210 € : 2213.08 € : 730 mm : 1.200 x 500 mm : 1200 mm : 1.200 x 500 mm : max. 30 m/min : 3.7 kW : 27 kVA kW : 4600 mm : 3040 mm : 2200 mm : 6400 kg : 990 mm : 930 kg : 1250 kg : 405 x 50 x 127 mm : 560 mm : 0 - 2.250 mm/min : 0,001 - 32 mm : 560 mm : 0 - 675 mm/min : 0,001 - 0,04 mm : 0,001 mm : 500 - 2.000 U/min : 11 kW iSurface control with Touch screen for 3 axes fully automatic surface and plunge grinding system 10.4” TFT high resolution color control to ensure ease of operation Rough increment, finish increment, spark out (0-9 times), and automatic grinding cycle Cycle interrupt, flip over for part inspection &, final dimensions set Wheelhead will rise up to end, start or reference positionnd table parks at left or right side after cycle is completed Display accuracy 0.0001mm Max. table speed (X axis) 30 m/min vertical feed by ...

CN Centerless grinding machine, ROSSI MONZA 1500 CN, currently being overhauled and fully electrically/electronically retrofitted, Siemens electronics with touchscreen, brushless motor on Z (workpiece diameter) and regulating wheel (adjustable RPM), step motor on grinding wheel dressing increment, auto size compensation after grinding wheel dressing, Grinding wheel 350 mm 610 mm dia, This machine can be inspected in our warehouse in Gussago BS Italy Centreless grinding is a procedure for grinding cylindrical bodies and is used for mass production of rollers cylindrical, conical rollers, jet needles, pump pistons, hydraulic sliders, crosses, drills etc. During centerless plunge grinding, the workpiece is ground in one pass thanks to the translation of the grinding wheel. For this purpose, the grinding wheels and the adjustment discs have a negative profile of the piece to work which is g ...

Ø grinding wheel dimensions (od x id x width): Ø 406 x Ø 203 x 200 mm, Ø min / max to grinding: 1.5 / 100 mm, Regulating wheel width: 200 mm, Min / max regulating wheel speed (r.p.m.): 10/250 rpm, Regulating wheel dimensions (od x id x width): Ø 270 x Ø 140 x 200 mm, Grinding wheel width: 200 mm, Maximum infeed grinding length: 200 mm, Motor power grinding wheelhead: 15 kW, Long: 2020 mm, Width: 1300 mm, High: 1420 mm, Weight: 4200 kg

Suitable for automatic grinding of tooth faces and tooth backs on carbide-tipped circular saw blades., Accessories:, Total enclosure including coolant system,, Motorized setting of the rake and clearance angle,, Preselection of the direction of rotation of the grinding wheel and automatic change of direction of rotation,, Grinding speed and grinding path stepless adjustable,, Operating system modified Windows version,, Storage of approx. 4,000 programs possible,, Standard software package for tooth geometries according to the program overview,, Program for grinding saw blades with group teeth, with different tooth geometries,, Program for newly fitted and broken teeth,, Software package for multi-surface machining on the positive chip and flank face,, oscillating grinding on the face and top,, Automatic grinding wheel compensation,, Automatic central lubrication,, Feed pawl 2 mm,, 1 sawb ...

Swivel Arm Vertical Grinding Machine DELTA Type LB 300 Swivel Arm Grinding Machine Fabr. No.: 0495 Year of construction 2004 Grinding range 330 x 140 mm Magnet 250 x 150 mm Grinding height Grinding wheel - magnet approx. 220 mm Grinding height Grinding wheel - clamping surface approx. 280 mm Center of center of column to center of spindle 300mm Grinding wheel diameter 178 mm Fine adjustment 0.01 mm Grinding wheel speed 2840 rpm. Motor power 2.2 kW Mains connection 380 volts, 50 Hz - Depth adjustment via handwheel on the right side of the spindle housing, fine adjustment via knurled wheel on the handwheel - mechanical magnet 250 x 150 mm, overall height 63 mm (grinding height without magnet approx. 280 mm) - Wet grinding device in the machine base - Dressing diamond for swivelling in Space requirement L x W x H 850 x 800 x 1630 mm Weight 380 kg very good condition; used

Distance between centers : 1000 mm Centers height : 175 mm Grinding wheel holder headstock orientation : 0 - 180 ° Grinding wheel holder headstock indexing precision : 5 ° Grinding wheel dimensions : 500 x 63 x 203 mm Cutting speed : 35 m/sec Headstock power : 7.5 kW Maximum workpiece weight : 130 kg Table orientation : 10 ° headstock rotation speed : 35-520 rpm EQUIPMENT : Sensitron 6 : Internal grinding spindle : 1 Measuring head MOVOMATIC ES124 for the diameter : 1 Tailstock : 1 Diamond grinding device for external wheel : 1 Radius grinding devic : 1 Display 2 axes HEIDENHAIN : 1 Lubricating tank with paper filtration : 1 Set of grinding wheel holders and grinding wheels : 1

FOR SALE SULZER ASV 25/30 ENGINE NEW GENUINE SPARE PARTS AT TURKEY HAVE A GOOD DAY SIR. WE HAVE MANY NEW GENUINE SPARE PARTS OF SULZER ASV 25/30 ENGINE AT OUR STOCK. WE VE 200 ITEMS AT OUR STOCK. PLS FIND 100 ITEMS WITH PARTS NUMBER ON BELOW. IF YOU INTEREST PLS DO NEED HESITATE TO CONTACT WITH US.. NO. ONE - SULZER 12 ASV 25/30 PART NO. 1 NEW CYLINDER LINER 5001001 1 PCS 2 NEW PISTON 3404001 4 PCS 3 NEW CAM SHAFT SECTION 10107001 3 PCS 4 NEW COMPLETE LUBRICATION PUMP 30004 K 1 PCS 5 RECON CONNECTING ROD 1 PC 6 NEW LOWER CRANK BEARING D = 225 MM 02103 B 7 PAIRS 7 NEW UPER CRANK BEARING D = 225 M 02103A 7 PAIRS 8 NEW BEARING SHELL HELPED D = 195MM 03004A 12 PAIRS 9 NEW THRUST BEARING HELPED 2103001 2 PAIRS 10 NEW BOLT WITH OVERSIZE 701007/0VERSIZE 12 PCS 11 NEW BEARING SHELL HELPED D = 195MM 03004A 12 PAIRS 12 NEW BEARING SHELL HELPED D = 194.5MM 03004B 511200- ...

Gr. Swing diameter: 600 mm Top width: 2200 mm Gr. Grinding diameter on grinding wheel 800 mm Ø: 125 mm Wheels Ø use of put sticks: 20-125 mm Grinding wheel dimensions: 800 x 28-800 x 42 x 305 mm 2 wheel speeds 3 workpiece speed: 32, 55 and 96 RPM Table Shift manual coarse/fine: 10/2 mm Machine. Feed speed of the grinding wheel: 0,005 - 0,025 mm Table 6-speed: 120-1540 mm / min Grinding spindle stock drive: 8 kW Electr. Supply: 380/400 V, 10 kW Space requirements: 6100 x 2300 x 1600 mm Weight: 7T

Grinding wheel diameter x W: 200 x 32 mm Grinding wheel bore: 32 mm Grinding wheel grain: K 36 / K 80 RPM: 2850 RPM S1 engine power output 100%: 0.90 kW Motor power S6 40%: 1.25 kW Voltage: 400 V Width: 510 mm Depth: 270 mm Height: 310 mm Weight: approx. 25 kg Scope of delivery: Roughing wheel K 36 Simple disk K 80 Spark cover on both sides Workpiece support Base extra charge available. Special price including delivery to 1 address Germany (Mainland).

Stock number 1105-02617 Machine type flat grinding machine Make Elf Type OPTIMALLY 4250 NC-K Built in 1993 Control type NC Storage warehouse Country of origin Germany Delivery time immediately Exhibition Hall, ver free freight basis Technical details Grinding length 450 mm Grinding width 250 mm Workpiece height 375 mm Table length 800 mm Table width 250 mm maximum work-piece weight 400 kg Autom. Cross feed adjustable 3-50 mm / stroke Vertical delivery, 1 Division 0.001 - 0.06 mm Grinding wheel diameter 300 mm Grinding wheel width 50 mm Grinding wheel diameter 36 mm Voltage 380 V Grinding spindle motor 3.7 / 4.7 kW Total power demand 9 kW Machine weight approx. 2.6 t Space requirement of approx. 2800 X 2500 2300 mm Additional information automatic delivery -Electro magnetic clamping plate with straight fine pole pitch, dimens ...

2019 technically overhauled and repainted. - Grinding range of 20 to 400 mm with grinding wheel of 200 mm - up to 450 mm with smaller grinding wheel - Zaehne numbers 20 to 999 - Tooth ahehes 0 to 20 mm - Grinding wheel diameter max. 200 mm - Stroke numbers 40 to 180 - Weight approx. 990 kg - Automatic grinding wheel delivery via electronic preselection; max. removal 4 mm. - Removal sequence according to zaehne number preselection in 0.02 mm increments - Automatic grinding wheels profiling device with automatic. Compensation of removal. - Cycle can be pre-predictable according to zaehne number. - Leaf stuetze - Central lubrication - Accessories - Operating instructions and operator tool

Grinding length: 0 mm Grinding width: 0 mm Grinding height: 0 mm Wheel diameter: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Table length: 400 mm Table width: 150 mm Grinding length: 400 mm Grinding width: 150 mm Execution: hydraulic Max. distance from table to spindle-centreline: 350 mm Table speeds: stepless from: 2.00 m/min up to: 20.0 m/min Automatic vertical feed: from: 0.0020 mm up to: 0.013 mm Diameter of grinding wheel: 200 mm Width of the grinding wheel: 16 mm Grinding wheel speeds: from: 2800 rpm Voltage 50 Hz 3x: 380 Volt Grinding spindle motor: 2.30 HP Machine´s weight about: 900 kg Overall dimensions machine: Length: 1300 mm Width: 1200 mm Height: 1500 mm

Grinding diameter: 0 mm Grinding length: 0 mm Workpiece weight: 0 kg CNC Brand: 0 CNC Model: 0 Technical data Centre height: 100 mm Distance between centres: 400 mm Grinding wheel: Diameter: 300 mm Width: 50 mm Bore: 127.0 mm grinding wheel width: 60 mm Grinding wheel speeds: number (steps): 3 from: 1500 rpm up to: 1900 rpm Work piece spindle head: speeds: stepless from: 65 rpm up to: 500 rpm rotatable: 360 ° Spindle hole: 23 mm Spindle taper:: 4 MT Taper in tailstock:: 3 MT Table angular displacement: 9 ° Table speed: stepless up to: 5.0 m/min Voltage 50 Hz 3x: 380 Volt External Grinding wheel motor: 2.5 HP Workhead spindle motor: 0.5 HP Total power required: 4.0 HP Machine´s weight about: 2100 kg Overall dimensions machine: Length: 1600 mm Width: 1200 mm Height: 1550 mm Various accessories: Tailstock with fine adjustement Coolant system Set of grinding wheels Set of flanges Fi ...

Drill diameter maximum: 0 mm Drill diameter minimum: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Min. drill capacity: 3 mm Max. drill capacity: 40 mm Spitzwinkel min.: 40 ° max.: 180 ° Diameter of grinding wheel: 200 mm Width of the grinding wheel: 250 mm Drilling cap. of grind.wheel: 32 mm Grinding wheel speeds: from: 2800 rpm Voltage 50 Hz 3x: 380 Volt Grinding spindle motor: 0.76 kW Machine´s weight about: 170 kg Overall dimensions machine: Length: 840 mm Width: 820 mm Height: 1200 mm Various accessories: 6-jaw chuck diameter: 130 mm Lamp Set of grinding wheels Set of flanges Coolant system Set of service tools

+ ATTENTION - PRICE DROP! + Prices are rising, ours are falling! + Our prices are reduced by 50% now, + due to warehouse restructuring! + Also, consider taking a look at our other offers in stock. Horiz. Surface Grinding Machine JUNG G 60 manufacturer: JUNG type: G 60 mach.-Nr.: 14508 comm.-Nr.: 0400/090/270/0760 stock-Nr.: 1913 + Regular Price: 2.850,- € > Reduced Price: 1.425,- € BN + All prices are shown without taxes (net price) Technical Data (According to manufacturer) table clamping surface: 600 x 200 mm max. grinding length: 600 mm max. grinding width: 200 mm table speed: infinitely adjustable up to 15 m / min. max. grinding wheel – Ø : 200 mm max. grinding wheel width: 30 mm drive power: 1,6 kW weight: ca. 1.100 kg standing area: W 1,60 x D 1,30 x H 1,80 m features automatic cross feed hydr. table adjustment, infinitel ...

Grinding diameter: 0 mm Grinding length: 0 mm Workpiece weight: 0 kg CNC Brand: 0 CNC Model: 0 Technical data Centre height: 100 mm Distance between centres: 400 mm Max. Longitudinal travel: 420 mm Grinding wheel: Diameter: 350 mm Width: 50 mm grinding wheel width: 50 mm Table load max.: 20 kg Workpiece weight on centres max.: 20 kg Grinding wheel speeds: Peripheral speed: 30 m/s Angular displacement: 15 / 30 ° Work piece spindle head: speeds: stepless from: 30 rpm up to: 1200 rpm Spindle taper:: 4 MT Table angular displacement: 30 ° Table speed: stepless from: 100 mm/min up to: 3500 mm/min Voltage 50 Hz 3x: 380 Volt External Grinding wheel motor: 3 kW Total power required: 10 kVA Machine´s weight about: 1600 kg Overall dimensions machine: Length: 1500 mm Width: 1400 mm Height: 1400 mm Various accessories: Set of flanges Safety device

Grinding diameter: 0 mm Grinding length: 0 mm Workpiece weight: 0 kg CNC Brand: 0 CNC Model: 0 Technical data Centre height: 100 mm Distance between centres: 400 mm Grinding wheel: Diameter: 300 mm Width: 50 mm Bore: 127.0 mm grinding wheel width: 60 mm Grinding wheel speeds: number (steps): 3 from: 1500 rpm up to: 1900 rpm Work piece spindle head: speeds: stepless from: 65 rpm up to: 500 rpm rotatable: 360 ° Spindle hole: 23 mm Spindle taper:: 4 MT Taper in tailstock:: 3 MT Table angular displacement: 9 ° Table speed: stepless up to: 5.0 m/min Voltage 50 Hz 3x: 380 Volt External Grinding wheel motor: 2.5 HP Workhead spindle motor: 0.5 HP Total power required: 4.0 HP Machine´s weight about: 2100 kg Overall dimensions machine: Length: 1600 mm Width: 1200 mm Height: 1550 mm Various accessories: 3-jaw chuck diameter: 135 mm Macnetic chuck diameter: 150 mm Coolant system Paper filte ...

Machine details Bearing number 1105-03191 Machine type flat grinding machine Make sit Type RP 800 Built in 1991 Control type NC Warehouse LAGER Country of origin Germany Delivery time immediately Freight base from the exhibition hall, free Technical details Grinding length 800 mm Grinding width 400 mm Workpiece height 475 mm Table length 1100 mm Table width 500 mm max. workpiece weight 700 kg Auto. Cross feed adjustable 3-50 mm/stroke Vertical delivery, 1 tick mark 0.001 - 0.06 mm Grinding wheel diameter 300 mm Grinding wheel width 50 mm Grinding wheel bore diameter 76.2 mm Connection voltage 380 V Grinding spindle motor 3.7 / 4.5 kW Total power requirement 4.5 kW Machine weight approx. 4.5 t Room requirement approx. 3500x2000x2700 mm Information Automatic delivery, - Electro-magnetic clamping plate with straight fine pole division, dimensions 800x400mm  ...

Grinding diameter: 0 mm Grinding length: 0 mm Workpiece weight: 0 kg CNC Brand: 0 CNC Model: 0 Technical data Centre height: 100 mm Distance between centres: 400 mm Grinding wheel right and left hand Grinding wheel: Diameter: 300 mm Width: 50 mm Bore: 127.0 mm Grinding wheel speeds: number (steps): 3 from: 1500 rpm up to: 1900 rpm Work piece spindle head: speeds: stepless from: 65 rpm up to: 500 rpm rotatable: 360 ° Spindle hole: 23 mm Spindle taper:: 4 MT Taper in tailstock:: 3 MT Table angular displacement: 9 ° Table speed: stepless up to: 5.0 m/min Voltage 50 Hz 3x: 380 Volt External Grinding wheel motor: 2.5 HP Total power required: 4.0 HP Machine´s weight about: 1600 kg Overall dimensions machine: Length: 1600 mm Width: 1200 mm Height: 1550 mm Various accessories: Set of increase letters: 50 mm Quick closing attachment: W 20

Grinding diameter: 0 mm Grinding length: 0 mm Workpiece weight: 0 kg CNC Brand: 0 CNC Model: 0 Control: SPS SIEMENS SIMATIC HMI TOUCH Technical data Centre height: 100 mm Distance between centres: 400 mm Max. Longitudinal travel: 400 mm Grinding wheel: Diameter: 350 mm Width: 50 mm Bore grinding wheel width: 50 mm Table load max.: 20 kg Workpiece weight on centres max.: 20 kg Grinding wheel speeds: Peripheral speed: 30 m/s Angular displacement: 15 / 30 ° Work piece spindle head: speeds: stepless from: 30 rpm up to: 1200 rpm rotatable: 90 ° Spindle taper:: 4 MT Table angular displacement: 30 ° X axis (transversal): 0.01-9 mm/min Table speed: stepless from: 100 mm/min up to: 3500 mm/min Voltage 50 Hz 3x: 380 Volt Internal Grinding wheel motor: 1.1 kW Total power required: 10 kVA Machine´s weight about: 1500 kg Overall dimensions machine: Length: 1600 mm Width: 1400 mm Height: 160 ...

Grinding diameter: 0 mm Grinding length: 0 mm Workpiece weight: 0 kg CNC Brand: 0 CNC Model: 0 Technical data Centre height: 175 mm Distance between centres: 1000 mm Grinding wheel: Diameter: 400 mm Width: 50 mm Bore: 127.0 mm grinding wheel width: 80 mm Grinding wheel speeds: number (steps): 4 from: 1450 rpm up to: 2300 rpm Angular displacement: 90 ° Work piece spindle head: speeds: stepless from: 30 rpm up to: 600 rpm rotatable: 90 ° Spindle taper:: 5 MT Taper in tailstock:: 3 MT Table angular displacement: 10 ° Table speed: stepless from: 0.10 m/min up to: 6.0 m/min Voltage 50 Hz 3x: 380 Volt External Grinding wheel motor: 4.0 HP Machine´s weight about: 2200 kg Overall dimensions machine: Length: 2500 mm Width: 1300 mm Height: 1400 mm Various accessories: Tailstock with fine adjustement Internal grinding attachment Measuring instrument: MARPOSS Coolant system Set of grinding ...

Grinding diameter: 0 mm Grinding length: 0 mm Workpiece weight: 0 kg CNC Brand: 0 CNC Model: 0 Control: GE FANUC Series 16-GC Operating hours: 30291 Technical data Centre height: 100 mm Distance between centres: 400 mm Grinding wheel: Diameter: 300 mm Width: 32 mm Bore: 127 mm max. grinding wheel width: 50 mm Grinding wheel speeds: number (steps): 3 from: 1600 rpm up to: 2200 rpm Peripheral speed: 35 m/s Rotatable grinding spindle head (b-axis): 30 ° Longitudinal slide: Max. travel: 420 mm Max. grinding length: 400 mm Resolution of the scale: 0.0001 mm Feed range: 0.001 - 10000 mm/min Transversal slide: Max. travel: 150 mm Resolution of the scale: 0.001 mm Feed range: 0.001 - 10000 mm/min Work piece spindle head: speeds: stepless from: 30 rpm up to: 10000 rpm Max. table angular displacement: 15 ° Voltage 50 Hz 3x: 380 Volt Grinding spindle motor: 3 kW Workpiece spindle motor: 1.1 ...

Grinding diameter: 0 mm Grinding length: 0 mm Workpiece weight: 0 kg CNC Brand: 0 CNC Model: 0 Technical data Centre height: 150 mm Distance between centres: 680 mm Max. Longitudinal travel: 620 mm Grinding wheel: Diameter: 350 mm Bore: 127.0 mm grinding wheel width: 50 mm Grinding wheel speeds: number (steps): 3 from: 1640 rpm up to: 2300 rpm Work piece spindle head: speeds: stepless from: 65 rpm up to: 500 rpm rotatable: 360 ° Spindle taper:: 5 MT Taper in tailstock:: 3 MT Table angular displacement: 8 ° Table speed: stepless up to: 5.0 m/min Voltage 50 Hz 3x: 380 Volt External Grinding wheel motor: 4.0 HP Total power required: 6.8 HP Machine´s weight about: 2500 kg Overall dimensions machine: Length: 2700 mm Width: 1800 mm Height: 1900 mm Various accessories: Digital readout number of axis:: 2 Manufacturer: Tschudin Checkomatic Paper filter facility Sparking-out attachment La ...

Grinding diameter: 0 mm Grinding length: 0 mm Workpiece weight: 0 kg CNC Brand: 0 CNC Model: 0 Technical data Centre height: 100 mm Distance between centres: 680 mm Max. Longitudinal travel: 620 mm Grinding wheel: Diameter: 350 mm Bore: 127.0 mm grinding wheel width: 50 mm Grinding wheel speeds: number (steps): 3 from: 1640 rpm up to: 2300 rpm Work piece spindle head: speeds: stepless from: 65 rpm up to: 500 rpm rotatable: 360 ° Spindle taper:: 5 MT Taper in tailstock:: 3 MT Table angular displacement: 8 ° Table speed: stepless up to: 5.0 m/min Voltage 50 Hz 3x: 380 Volt External Grinding wheel motor: 4.0 HP Total power required: 6.8 HP Machine´s weight about: 2500 kg Overall dimensions machine: Length: 2700 mm Width: 1800 mm Height: 1900 mm Various accessories: Internal grinding attachment swivellable: Spindle speeds: 50 rpm Coolant system Paper filter facility Sparking-out att ...
