vertical turret lathe used for sale

This 5-axis AMADA EM 2510NT turret punch press was manufactured in 2005. It features a punching force of 200 kN, a turret capacity of 45 stations, and a maximum sheet size of 1270 × 5000 mm. The machine has a rapid traverse speed of 100 m/min on the X-axis and 80 m/min on the Y-axis. If you are looking to get high-quality punching capabilities, consider the AMADA EM 2510NT machine we have for sale. Contact us for further details.

Overview The Zalkin screw capper top is made of stainless steel and has 22 capping heads. The running direction is from left to right (clockwise). It comes with an electronic height adjustment. 28 mm aluminum closures have been processed. The maximum output is 36,000 bottles per hour. Tech Specs: Pitch circle diameter 731.11 mm Number of closing elements 22 Pitch 104,4mm Running direction left-right (clockwise) Material: SST Electronic height adjustment Closures: 28mm aluminum closures Accesories: Six new closing elements Closure sorting unit Spare parts lists and technical documentation

L + Z lathe HOLZMANN type ED 914GNMasch. No. 20265 Year of construction 2006Center width 800 mmTurning diameter over bed 300 mmCenter height over bed 150 mmTurning diameter over support 190 mmCenter height over support 95 mmSpindle bore 38 mmSpindle speed 70 - 1400 rpm. 9 stepsFeed longitudinal and flatChuck flange Short taper DIN 55029 D1-4 Camlock 63 mmTailstock inner taper MK 3Drive power 1.5 kWNet connection 400 volts, 50 Hz- Spindle speed over 9 gear stages - 4-jaws

Vertical band saw HESKA type ESA 4Fabr. No. 681174 year of construction approx. 1985Roller diameter 420 mmThroat depth 400 mmTable size 500 x 500 mmCutting height 285 mmSaw blade length min. 3200 - max. 3400 mmSaw blade speed Gear stage (1) 15-140 m/min. Saw blade speed gear stage (2) 150-1400 m/min. Motor power 1.5 kWNet connection 380 volts, 50 Hz - stepless saw blade speed via PIV gearbox with handwheel adjustment and 2 gear steps - saw table swivel in 2 axes -

Vertical band saw MÖSSNER REKORD type SM 420Masch. No. 17010 Year of construction 1968Roller diameter 420 mmRadius in width 415 mmRadius in height 265 mmTable size 605 x 600 mmBelt speed 18 - 562 m/min. 8 stepsSaw blade length min/max. 3150 / 3260 mmDrive power 1.1 / 1.7 kWNet connection 380 V 50 Hz- Saw blade speed over 4 gear stages and 2 motor speeds- Saw blade butt welder IDEAL BS 0-16 with scissors and grindstone- swivelling work table in 2

Vertical band saw JAESPA type MSU 4Fabr. No. 724749 year of construction approx. 1980Roller diameter 420 mmProjection 400 mmTable size 610 x 610 mmCutting height 260 mmSaw blade length min. 3200 - max. 3400 mmSaw blade speed 10-1500 m/min. infinitely variableMains connection 400 volts, 50 Hz- infinitely variable saw blade speed via 2 gear stages and infinitely variable via belt drive- Saw table swivel- Saw blade butt welding machine IDEAL BS0-16- Saw blade shear- Sharpening stone for grinding the weld seamSpace requirement L x W

Modula Lift ML50D Vertical Storage Lift Modula are automatic vertical carrier storage systems based on the concept of vertical storage and saving floor space. You can store any type of material safely, cleanly and efficiently, saving up to 90% of floor space. The Modula are the result of more than 30 years of experience of an Italian company with high-tech products • Minimal energy consumption • Automatic weight monitoring during beam retraction • Dynamic storage location assignment of the carriers in the device according to the heights of the stored goods • Equipment frame made of galvanized steel profiles • Vertical drive with steel-core reinforced Eagle timing belt • Extractor guide system with 6 HDPE rollers per side • Management of the carriers with differentiated payload Manufacturer: Modula Year of Make: 2021 Model: Modula Lift ML 50D Height: ...

Vertical CNC centre lathe, uses / outdated machine type: Emag VSC 200 control: Siemens 840 C construction year: From the in 1995 to the in 2007 overtakes TECHNICAL DATA: speed area / speeds: [1 / min].: 6,000 Drehmoment:/torque [Nm]: 480 Max dreh-? over bed swing diam .: 290 mms impulse achievement / power: [kW] 34 feed ? / chuck diam. 200 mms revolver / turret: 12-fold, VDI 40, shoemaker powered work witness / driven tools 7.8 kW Verfahrwege: X axis / x-travel: 550 mms Z-Achse/z-travel: 200 mms express way / rapidly travel: (X/Z) [m / min] 30 / 20 prepush / feeds: (X/Z) [m / min]. 11 KN connected load: [KW] 36 kW machine weight: [kg] 6,500 equipment signs: filings sponsor / chip conveyor, crowd

CNC Vertical Lathe VTL with Tool Changer.You Ji GTH-35/45 ATC-I.Year of manufacture 2012.Fanuc 0i-TD CNC Control.Face plate diameter 3500 mm.Hydrostatic table - Load max. 50 t.Swing diameter max. 4500 mm.Turning diameter max. 4000 mm.Turning height max. 2200 mm.Ram cross travel X -1750/+2160 mm.Ram vertical travel Z 1500 mm.Table drive 60/75 KW.Table turning speeds 2 ~ 75 mm.Torque at the table 67330 Nm.Tool magazine with 16 positions.Tool taper 7/24 BT 60.Floor space required 12375 x 8210 mm.Machine height 7920 mm.Full guarding.3-colour signal lamp (tower).AS NEW - 200 run hours !Available immediately.; As new

Table diameter: 2,000 mm Max diameter of workpiece: 3,000 mm Main drive: 60 KW Speed rotation of the table: 2.8 - 162 rpm Max workpiece height under the cross member: 2,500 mm Travel RAM: 1,750 mm Tool magazine: 12 workstations Machine Weight: 35 t Accessories: Grinding spindle and various tool holders 3000 rpm Wheel diameter 250 mm

Machine weight: 20,000 kg Faceplate diameter 1250 mm Number of supports: 1 pcs Dimensions: height 4250 mm width 5630 mm depth of 3550 mm Extras: copying apparatus, turret head on the vertical support Technical condition at the time of sale: Replacement rotary amplifier on thyristor converter. Not operated since 1994 p. Small repair and adjustment of electrical and mechanical parts. The maximum dimensions of a workpiece Height 1150 mm The diameter of 1400 mm Weight 8000 kg

chuck diameter, mm 7100 (8000) Max. work piece diameter, mm 8000 Max. work piece height, mm 3200 Max. work piece weight, kg 125000 Chuck speed, rpm 0,22...20,1 Max. ram movement of vertical support, mm 2000 Max. movement of vertical, mm 4275 Support feed range, mm/min 0,0352...285 Support rapid feed, mm/min 2500 Supports possible work angle, deg. -15...+40 Jaws, units 4 Machine overall dimensions, mm 8615 x 17600 x 9800 Machine weight, kg app. 247300

turning diameter: mm swing diameter: mm turning height: mm total power requirement: kW weight of the machine ca.: t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Used machine in good condition. Available for immediate delivery. - Control: SIEMENS 840 D - Axes: 2 - Cutting feed rate (X x Z): 0.1 - 3.000 mm / min - Power of driven tool: 37 kW - Weight: 25 t

Used machine in good condition. Available for immediate delivery. - Power source : 30 kVA - Control: CNC HEIDENHAIN TMC 530 - Tool magazine capacity: 20 # - Maximum tool diameter ?: 65 mm - Weight: 7.5 t

Used machine in good condition. Available for immediate delivery. - Control: SINUMERIK 880 T 3 - Max. length: 400 mm - Tool-holder cone: CONO ISO 50 - Tool magazine capacity: 16 #

turning diameter: mm swing diameter: mm turning height: mm total power requirement: kW weight of the machine ca.: t required space: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

An Emag vertical CNC lathe is available. Clamping chuck diameter: 250mm, max. circulation diameter: 270mm, max. machining diameter: 250mm, max. machining length: 175mm, speed: 4500rpm, tool positions: 12, tool holder: VDI 40, travel X/Z: 660mm/300mm, rapid traverse X/Z: 60m/30m/min. Machine dimensions X/Y/Z: approx. 4300mm/1600mm/3300mm, weight: approx. 7500kg, control: Fanuc Series 32i-Model A, operating hours: 64137h. Including automatic loading and unloading with pick-up spindle and integrated part diverter and workpiece storage. Documentation available. On-site inspection is possible.

CNC vertical lathe Type: SKJ 12 NC Manufacturer: TOS Control: Mefi Max workpiece diameter: 1400 mm Clamping plate diameter: 1250 mm Maximum workpiece height: 1150 mm Maximum workpiece weight: 6000 kg Clamping plate speed: 2.5 - 225 rpm Main motor power: 37 kW Machine weight: 13000 kg In good condition, under power Find more here - / Contact us at -

CNC Vertical Turret Lathe with C axis and live tool 3 Turning Plates Changer (translating pallet system) EQUIPPED WITH: Siemens Sinumerik 840C CNC Control (2015 Retrofit) Vertical Ram with Live Spindle Pallet Changer (3-Pallets) 16-Station Automatic Tool Changer C-Axis Table Year 2005 CNC Siemens 840 C Max. turning dia.: 2200 mm Max. turning height: 1800 mm Ram travel: 1500 mm Main drive: 75 kW Live spindle: 15 kW Spindle rotations: 45- 1350 1/min Max. workpiece weight: 12 000 kg Pallet changer with 3 pallets (turning plates) Tool magazine: Right: 8 turning tools Left: 8 boring/milling tools Feeds: 0,1-6000 mm/min Carriage feed: Vertical: 1500 mm Horizontal: 1320 mm Table rotation (2 ranges): 2,5 – 70 / 10-280 Max. table torque: 50 000 Nm Machine weight: 43 Ton Machine HxWxL: 6,8 m x 10 m x 9,7 m

Offered is a CNC vertical turning machine - pick-up system. Chuck diameter: approx. 160mm - 200mm, swing diameter: approx. 270mm, travels X/Z: approx. 500 - 600mm/approx. 160 - 200mm, max. spindle speed: 6000rpm, tool carrier: 12-station turret, drive system: Siemens SIMODRIVE 611, hydraulic unit: available, coolant system: including pumps and filter (One Eye Ind. magnetic filter installed), hinged belt chip conveyor. Inspection is possible by appointment.

CONTROLS   CNC controls SIEMENS BASIC FUNCTIONS   number of spindles: 2   number of turrets: 1   number of c-axes: 2 WORKING RANGE TURNING   turning diameter (max): 100 mm   worpiece length max.: 150 mm MAIN SPINDLE   spindle revolutions (max): 6000 /min TOOL MAGAZINE   number of positions: 12 ELECTRICAL SPECIFICATIONS   total power consumption: 36 kW   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   total weight approx.: 7000 kg ATTACHMENTS (TURNING)   hydraulic system: yes   European CE standards: yes Machines in good condition: - Integrated pick-up automation - Two EMAG machines configured in a line are for sale. - A robot destacking unit with 100% parts inspection can also be purchased.

Dörries Contumat VCE 2000-160Year of manuf. : 1991 Control : Siemens 840 Dsl Turning diam. : 1600 mmTurning length : 1800 mm____________Description:In General:Year of manufacture:1991 / 2010Control system retrofit:2010Control system:Siemens 840 DslCircumferential diameter:2,000 mmTurning diameter:1,600 mmTurning height:1,800 mmTable / Faceplate:Technology:Gear-driven tableSpeed:315 rpmPower:105 kWMax. torque:50,000 NmFaceplate:1,600 mmMax. table load:12,000 kgTool carrier:Crossbeam travel (vertical):1,200 mmChisel slide travel:1,500 mmSupport travel (horizontal):2,300 (+/-1,150) mmPenetration diameter:340 mmChisel slide cross-section:240 x 240 mmEquipment:Tool magazine:20 stationsChip removal:Chip conveyorCoolant supply:Coolant system with filterTool measurement:ProbeSet-up:Electronic handwheelTool holders:Various tool holdersControl system overhaul:Year of overhauling:2010Technol ...

CONTROLS   CNC controls FANUC BASIC FUNCTIONS   number of spindles: 1   number of turrets: 1 WORKING RANGE TURNING   turning diameter (max): 220 mm   worpiece length max.: 175 mm MAIN SPINDLE   spindle revolutions (max): 6000 /min X/Z SLIDE   Z-axis travel: 300 mm   X-axis travel: 660 mm ELECTRICAL SPECIFICATIONS   total power consumption: 36 kW   mains voltage: 400 V   mains frequency: 50 Hz DIMENSIONS / WEIGHTS   space requirements -left/right-: 3820 mm   space requirements -front/back-: 2040 mm   total height: 2400 mm   total weight approx.: 6500 kg

Manufacturer: EMAG Year of manufacture: 2009 Model: VTC 250 Find more here - / Contact us at -

DÖRRIES SCHARMANN VCE 3000 / 280 CNC Vertikaldrehmaschine Modernisierung: im Rahmen des Retrofits im Jahr 2014 auf Siemens SINUMERIK 840D SL Arbeitsbereich Tischdurchmesser: 2.800 mm Max. Umlaufdurchmesser / Drehdurchmesser: 3.000 mm Max. Tischbelastung: 25.000 kg Max. Drehhöhe: ca. 2.100 mm Verfahrweg X-Achse: ±1.550 mm Verfahrweg Z-Achse / RAM-Hub: 1.500 mm Hauptantrieb und Spindeln Hauptantrieb: Siemens-Hauptmotor Antriebsleistung: 130 kW Max. Spindeldrehzahl: 4.500 min⁻¹ Betriebsart: S6, 40 % Ausstattung: 2 vertikale Spindeln Werkzeugwechsler und Peripherie o    2 automatische Werkzeugwechsler o    Kühlschmierstoffanlage o    Späneförderer o    Ölnebelabsaugung o    2 separate Hydraulikaggregate Betriebsstunden: ca. 12.571 Stunden laut mechanischem Betriebsstundenzähler

Technical details Manufacturer: INDEX-Werke GmbH & Co. KG Serial number: 040033 Type: Vertical CNC production lathe Year: 2006 Operating hours: 91318 h Power: 20–28 kW Control system: Siemens / INDEX Control Power supply: 400 V Configuration: - Vertical CNC turning center - High-rigidity machine structure - Fully enclosed machining area - Production-oriented design Application: - Precision CNC turning - Machining of disc-shaped components - High-volume production - Industrial machining operations Construction: - Heavy-duty cast-iron machine frame - Vertical spindle configuration - Siemens/INDEX CNC control system Dimensions: - Length: 2600 mm - Width: 1600 mm - Height: 2200 mm Weight: Approx. 5500 kg Condition: Used Observed condition: - 91318 operating hours - Designed for precision production machining - Machine offered complete or alternatively f ...

Technical details Manufacturer: INDEX-Werke GmbH & Co. KG Serial number: 040018 Type: Vertical CNC turning center Year: 2005 Operating hours: 91318 h Power: 20–28 kW Maximum spindle speed: 5000 rpm Power supply: 400 V Configuration: - Vertical CNC turning center - High-rigidity machine structure - High thermal stability design - Fully enclosed machining area Application: - Precision CNC turning - Machining of disc-shaped components - Heavy-duty industrial machining - High-volume production Construction: - Heavy-duty cast-iron machine frame - Vertical spindle configuration - Industrial CNC turning center Dimensions: - Length: 2600 mm - Width: 1600 mm - Height: 2200 mm Weight: Approx. 5500 kg Condition: Used Observed condition: - 91318 operating hours - Designed for continuous industrial operation - Machine offered complete or alternatively for spare  ...

Technical details Manufacturer: INDEX-Werke GmbH & Co. KG Serial number: 101098 Type: Vertical pickup CNC lathe Year: 2007 Operating hours: 5426 h Power: 16–24 kW Chuck diameter: 160 mm Maximum workpiece diameter: 210 mm Configuration: - Vertical pickup spindle - Self-loading spindle system - Modular machine design - Fully enclosed machining area - CNC production configuration Application: - High-volume production machining - Precision turning of small and medium components - Automated production lines - Disc and flange machining Construction: - Heavy-duty cast-iron machine frame - Vertical spindle configuration - Pickup loading technology Dimensions: - Length: 3800 mm - Width: 1450 mm - Height: 3500 mm Weight: Approx. 5500 kg Condition: Used Observed condition: - 5426 operating hours - Modular pickup-spindle design for automated production - Machi ...

Technical data: Completely overhauled in 2001 Circulation diameter over bed: 1000 mm Diameter in recess: 1120 mm Circulation diameter over bed slide: 690 mm max. height above floor: 1110 mm max. height above bed: 460 mm Bed width: 800 mm Width of recess in front of the plan disc: 550 mm

Tip height: 330 mm centre distance: 1500 mm circular diameter: bed 690 mm spindle bore: 82 mm spindle retainer: short taper size 8 taper tailstock: 6 MK spindle speed: 7.1-1400 rpm feeds: longitudinal/plan 0.05 112/0.025 56 mm / U thread pitches: 0.25-560 mm electrical connection: 380 V, 15 kW space: 3350 x 1800 x 1400 mm weight: 4800 kg

Tip height: about quilt 300 mm centre distance: 1500 mm circular diameter: upper bed 640 mm spindle bore: 67 mm spindle retainer: Gr. 8 taper tailstock: 5 MK spindle speed: 18 - 900 rpm feeds: longitudinal/plan 0.063 0.032 2.1 mm / U thread pitches: 0.5-14 mm electrical connection: 380 V, approx. 7.5 kW space: 1550 x 3100 x 1250 mm weight: approx. 3500 kg hardly used and therefore well-preserved bed lathe

Made in Italy machine according to DIN 8606 Tip height: 260 mm Turning diameter over bed: 520 mm Swing over carriage: 300 mm Centre distance: 1500 mm Bed width: 400 mm Spindle bore: 82 mm Spindle nose: Camlock 8 " Spindle speeds: (24) 9-1600 rpm (option 11-2000 U/min) Engine output: 5.5 kW (option: 7.5 kW) feed Z-axis: (93) 0.028 6.43 mm / Rev Feed x axis: (93) 0.012 2.73 mm / Rev Thread, metric: (54) 0.5-224 mm Thread, Witworth: (55) 72 - 1/8 TPI Thread, module: (54) 0.5-112 mm Thread, Diametral Pitch: (54) 64 - 1/4 D.P.. Cross slide Lxw: 650 x 230 mm Transversal carriage stroke: 340 mm Upper carriage Lxw: 350 x 150 mm Upper carriage stroke: 150 mm Tailstock Quill diameter: 85 mm Tailstock Quill stroke: 200 mm Tailstock taper: MK 5 Weight: 3,100 kg Facilities: -Movement of the tailstock pneumatically supported -Acceptance Protocol according to DIN 8605, ...

Made in Italy machine according to DIN 8605: lathe with increased accuracy. Tip height: 215 mm Turning diameter over bed: 430 mm Swing over carriage: 240 mm Top width: 1,000 mm Bed width: 290 mm Spindle bore: 52 mm Spindle nose: Camlock 6 " Spindle speeds variable: 6 Spindle speeds: 60-2,000 rpm S6/S1 engine power: 4 kW (option: 5.5 kW) feed Z-axis: (38) 0.05 - 1.88 mm / Rev Feed x axis: (38) 0.02 1,084 mm / Rev Thread cutting, metric: (30) 0.45-20 mm Thread cutting, Witworth: (35) 80-1 3/4 TPI Thread cutting, module: (25) 0.25-10 mm Thread cutting, Diametral Pitch: (30) 160-3 1/2 D.P.. Cross slide Lxw: 370 x 190 mm Transversal carriage stroke: 240 mm Upper carriage Lxw: 275 x 115 mm Upper carriage stroke: 120 mm Tailstock Quill diameter: 60 mm Tailstock Quill stroke: 135 mm Tailstock taper: MK 4 Weight: approx. 2,000 kg Facilities: -Infinitely variable  ...

Made in Italy Peak: 300 mm Rotary diameter over bed: 600 mm Rotary diameter via sled: 380 mm Peak: 1,500 mm Bed width: 400 mm Spindle bore: 82 mm Spindle nose: Camlock 8 " Spindle speeds: (12) 16-1200 U/min Engine power: 9.2 kW (special equipment/standard: 7.5 kW) Reprimor Z-axis: (93) 0.028-6.43 mm/U Feed X-axis: (93) 0.012-2.73 mm/U Thread, metric: (54) 0.5-224 mm Threads, Witworth: (55) 72-1/4 x8 TPI Thread, module: (54) 0.5-112 mm Threads, Diametral Pitch: (54) 64 -1/4 D.P. Crossleigh hub: 340 mm Oberslitten hub: 150 mm Riding stock pinol diameter: 85 mm Riding stove pinol stroke: 200 mm Ridstock cone: MK 5 Weight: About 3,200 kg Facilities: -3-axis digital display -Step-by-step speed adjustment -Automatic lubrication of the management railways -LED lighting -Micrometer bed strike -9.2 kW engine instead of 7.5 kW -Quick change holder system mul ...

Precision lathe with cycle automatic Make: Hamlet Model: E 70 x 2000 Year of construction: 1997 For food and feed shaft machining Technical data: Workspace Turning length: 2000 mm Swing over bed: 720 mm Swing over cross slide plan: 430 mm Displacement of the plan slide: 410 mm Bed width: 480 mm 3prpek3uq Spindle nose ACC. to DIN 55027: size 11 Spindle diameter in front bearing: 150 mm Spindle bore: 106 mm Inside taper of the main spindle: 112 metric Control: Siemens 805 Spindle gearbox newly stored according to the manufacturer ca. 2.500 EUR

Tip width: 700 mm Tip height: 150 mm Circulation diameter over bed: 300 mm Bed width: 180 mm Spindle bore: 38 mm Mounting in the spindle bore: MK 5 Speed range, infinitely variable: 30 - 450 / 150 - 3000 rpm Range of longitudinal feeds: (14) 0.07 - 0.65 mm/U Area of plan feeds: (11) 0.03 - 0.12 mm/U Metric threads: (18) 0.2 - 3.5 mm Inch Thread: (21) 8 - 56 Gg/1" Pinole path: 85 mm Pinole holder: MK 3 Engine power S1 100%: 1.5 kW / 400 V Motor recording power S6 40%: 2.2 kW / 400 V Machine dimensions (W x D x H): 1380 x 640 x 500 mm Weight approx.: 235 kg without base Delivery: - Digital display - 3-jaw chuck PO3-160 mm steel version - Feed flange 160 mm - Solid grain tips - Interchangeable wheels - Quick-release steel holder size 20-2 with 2 straight inserts - Slip clutch - Micrometer longitudinal stop - Plan sled with top support - Frequency inverter ...

1 x L+Z lathe Colchester Mascot 1600/600 Built: c.1975 Very stable lathe. Ideal machine for locksmiths or agricultural machine mechanics. Technical data: Turning diameter over crimson: 710 mm Turning diameter over bed:432 mm Turning diameter via support:267 mm Turning length: 1,000 mm Spindle speeds:20 - 1600 rpm Spindle bore:76 mm Drive motor:5.6 kW Feeds: 0.6 - 10 mm/u Metric threads: 40 (0.4 - 14 mm incline) Machine weight approx.:2000 kg Room requirements approx.:l:2.65 x w:1.1 x h:1.6 m Accessories: 3 - Jaw lining UVA 310 mm 4 Set of change jaws Bfraed8ae0 Tripan quick-change system 4 x Interchangeable holder running counter tip in tailstock (MK 5) Countertip in spindle Alternating wheels Manual Mudguard complete documentation The machine can be inspected at our warehouse in Reichenbach under electricity.

Stepless guide and pull spindle lathe TC 250 V Peak height: 250 mm Circulation diameter via slide: 350 mm Orbital diameter in the croation: 695 mm Tip width: 1500 mm Spindle nose: DIN 55029, Camlock, size 6 Bed width: 305 mm Cross slide path: 272 mm Upper slide path: 155 mm Spindle bore: 80 mm Speed range, infinitely variable: (3) 30 - 2200 rpm Whitworth Thread: (45) 2 - 72 TPI Metric Thread: (39) 0.2 - 14 mm Diametral Thread: (21) 8 - 44 D.P.I Module Thread: (18) 0.3 - 3.5 module Longitudinal feeds: 0.04 - 1.00 mm/U Flat feeds: 0.02 - 0.50 mm/U Engine power: 5.5 kW Dimensions LxWxH, approx.: 2900 x 1175 x 2040 mm Weight, approx.: 2,200 kg characteristics: - Toolmaker accuracy - Stepless speed control (3 pre-level steps) - Finely-balanced main spindle - Stable machine bed with hardened and ground guides - One-piece cast base - Adjustable precision cone roll ...

Maximum diameter to turn on the bench 2,110 mm Maximum diameter to turn on trolley 1,600 mm Maximum distance between platforms 12,830 mm Spindle hole diameter 155 mm Cone on spindle no. 120 metric Cone on spindle (with reduction) no. 6 clamps Cone on the counterpoint (6-bit reduction) no. 120 metrics Maximum stroke of the counterpoint 400 mm DSeed from the tool support plane to the axis of the 80 mm centers Main engine power 100 HP Spindle speed from 0.9 to 90 rpm with continuous variation Longitudinal feed no. 36: 0.2 to 12.8 Transverse advances No. 36: 0.1 to 6.6 Metric fillets #26: 1 to 42 Whitwoth fillets #17: 0.5 to 11 Quick forwards Maximum permissible load on the tips 50-60 ton Refrigerant liquid system

Peak height 2,600 mm Point distance 10,000 mm Closed bench 2,000x6,000 mm To be completed with CNC

Height tips 220 mm Useful length 1,000 mm 42 mm bar pass

Equipped with no. 03 guides Overhauled with: guide grinding, CN conversion, new electrical and hydraulic system, hydraulic self-centering installation, shaving conveyor; CN Fagor 8055 Numerical Control – BT Maximum turnerable diameter 1800 mm 3-grife hydraulic self-centering with a diameter of 1450 mm with tightening force 30 Ton with 30 bar clamp L max turnerable 3000 mm Spindle engine power 110 Kw Maximum rotation speed 180 rpm Fast value axles 4000 mm/min M3/M4 Spindle Rotation Inversion Possibility 4 speed ranges Hydraulic counterpoint Maximum capacity of workpiece on counterpoint 12500 Kg It is currently possible to work details of up to 3000 mm length but the extension pallet is available to be able to work details up to 8 m in length. (un revised); Machine installed and working

Platò diameter: 1300 mm Used lathe in good condition, available unless sold.

Max length 8,000 mm Maximum turning diameter above wagon 1,250 mm Max vault over guides 1,650 mm Maximum turning diameter under spindle 2,000x700 mm Displayed – two axes

IN THE RETROFITTING PHASE Height tips 900 mm Point distance 7,000 mm Turnerable diameter on the bench 1,850 mm Turnerable diameter on trolley 1,350 mm Turnerable diameter on recess 2,150 mm Bench width 1,000 mm Bar passage diameter 206 mm ASA A1 15" spindle attachment Top speed 300 RPM Diameter of the tank counterpoint 220 mm Row stroke counterpoint 450 mm Withworth threads - metrics - diametrics - module Weight allowed between tips without lunettes 15 ton Weight allowed between tips with a 20-ton bezel

Maximum turnerable diameter: 1040 mm Turning diameter above the wagon: 620 mm Maximum workable length: 5200 mm Spindle power: 40 kW CNC ECS Optical line measurement system Maximum flow between tips: 10 tons Machine complete with chip evacuator, 4-position hydraulic turret, safety shelters in compliance and spindle 3-jaw hydraulic self-centering AUTOBLOCK; Various accessories available (tool case, stretchers, lunettes...) EC 2018 remarking possibility

peak heights: 250 mm point distance: 1500 mm bar pass: 105 mm

Main technical data: - Tip distance: 6000 mm - Tip height: 640 mm - Lathe complete with spindle, tailstock and tool turret
