127,551 used machines on RESALE, but how to find them? Machine Search
turning diameter: 200 mm turning length: 508 mm x-axis: 176 mm z-axis: 520 mm control: Fanuc-Series O-TD total power requirement: kW weight of the machine ca.: 3,2 t dimensions of the machine ca.: 2,73x1,98x1,64 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: 430 mm turning length: 1500 mm swing diameter over bed slide: mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Weibert DB 460XL Vario Lathe Diameter max. 305mm Center Size x Height: 460 x 155mm Spindle head thread M33 x 3.5 MK2 3 speeds: 650-1430, 1240-2790, 1600-3800 rpm Electronically variable Rotating grain tip Four-pronged driver Swivel steel support 150mm, 300mm Clamping washer 145mm Quill adjustment: 55mm Motor 550W 230V 50Hz Dimensions (LxWxH): 900 x 340 x 410mm Net weight approx. 38kg G&STÜ-5920462
RAFAMET KCI 320/400N CNC vertical turret lathe manufactured in 2011 in Poland, can perform complex production programmes on large-size workpieces, thanks to one turning head and three milling heads set at different angles. The machine, with its compact frame structure made of high-quality grey cast iron, is distinguished by its high geometric stability, high rigidity and excellent vibration damping. The CNC vertical turret lathe KCI 320/400N performs precision turning, milling, drilling and boring of cylindrical, conical and curved surfaces with the aid of the applied heads. One of them is a special milling head (offset), used to perform drilling and milling operations with the position of the tool axis offset from the spindle axis in a direction parallel to the slide travel plane. On the other hand, the turning head allows to mount CAPTO turning tools in horizontal and vertical socke ...
DMG GILDEMEISTER CTX 410 CNC lathe built in 2006 is an extremely powerful machine designed for precision machining of workpieces with a maximum diameter of 320 mm. The machining process is performed inside a large, fully illuminated workspace using reliable components in the form of cutting tools and a high-speed spindle. The specially designed inclined bed effectively dampens all vibrations and oscillations, resulting in better quality of the machined surface and increased tool life. The offered DMG CTX 410 CNC turning center is also equipped with an integrated chip conveyor and a perfectly optimised, intuitive HEIDENHAIN CNC control. The total weight of the machine is approximately 6000 kg. Technical specifications of the DMG GILDEMEISTER CTX 410 turning center - CNC controller: HEIDENHAIN - turning diameter: 320 mm - turning length: 600 mm - feed in the X/Z axis: 250/635 mm - ...
Key data: 760 mm, 1504 mm
Mazatrol Matrix Control max. turning diameter 760 mm max. turning length 1,504 mm Spindle motor main spindle 30 kW Max. speed main spindle 3,300 rpm C-axis, 0.0001° 3-jaw chuck, Kitagawa diam. 300 mm Y-axis 230 mm Spindle motor milling spindle 18.5 kW max. speed milling spindle 12,000 rpm B-axis, 0.0001° Tool changer with 40 stations Capto C6 System Hydraulic bezel, SMW Autoblok, clamping range up to 165 mm NC controlled tailstock, integrated MK5 rotating quill Tooleye Cooling by the milling spindle, 15 bar 3-jaw chuck Kitagawa B-15 Conveyor Dimensions L/W/H 4,912 mm/ 2,343 mm/ 2,798 mm Weight 12,800 kg CE mark
General: Year of construction 2006 Management Heidenhain plus IT Travel X 150 mm Z 650 mm Y 80 mm Program duration 10,600 h Spindle: Spindle speed 5,000 rpm Spindle bore 65 mm Turning diameter over face slide 375 mm Turning length 635 mm Revolver: Tool holder VDI30 Number of stations 12-fold with AGW Dimensions and weight: Dimensions 5,000 mm x 2,500 mm x 2,800 mm Weight approx. 5,800 kg
RAFAMET KCH 360/450 vertical turret lathe was built in 1987 in Poland by Fabryka Obrabiarek RAFAMET. The machine is used for precise machining of large and heavy workpieces whose size does not allow effective machining with standard machines. RAFAMET KCH 360/450 is distinguished by its stable design, equipped with two vertical supports and one side support. Machining is performed on a work table with a diameter of 3600 mm by means of a reliable vertical spindle. The work table offers 20-position speed adjustment in the range of 0.6 to 50 rpm, enabling precise adjustment of the parameters to the production requirements. The position of the head in all linear axes is continuously monitored by state-of-the-art SONY digital readout, which ensures high precision measurement. All this makes the offered KCH 360/450 vertical turret lathe an excellent choice for, among others, the energy, ship ...
Inv. Num. : 7877 Type: TH 4010 Producer: OPTIMUM Created: 2018 Parameters: Maximum turning length: 1000 mm Maximum turning diameter over bed: 410 mm Minimum spindle speed: 45 1/min Maximum spindle speed: 1800 1/min Cone: MK 3 Rotary spindle pass-through diameter: 52 mm Power consumption: 1.5/2.4 kW Length: 1920 mm Width: 740 mm Height: 1222 mm
CNC lathe Gildemeister Twin 42 RG2 Year of Make: 2004 Control Siemens 840D Powerline Turning diameter 145 mm Max. bar passage 45 mm Spindle Head Flat Flange 120 h5 Chuck 130 / 140 mm Main spindle speed 20–7,000 min⁻¹ Main spindle power 28 / 22 kW (40/100 % ED) Torque main spindle 180 / 140 Nm Sub-spindle Yes, same performance X-axis 220 mm Z-axis 320 mm Y-axis ±30 mm Rapid traverse X/Y/Z 30 / 15 / 30 m/min Turret 2 × 12 stations Tool holder VDI 25 Machine weight approx. 5,300 kg Connected load approx. 40 kVA Type 60° inclined bed, linear guides Chip conveyor Bürener type SPE 63/30- 250 Z60 Tool monitoring system Artis type CTM Tailstock mounted on sub-spindle carriage, tailstock stroke = 230mm Tailstock force = 300 daN Centrifuge MK3 Overload clutch for the X and Z axes of slides 1 and 2 Bar machining package consisting of: Workpiece collection device ...
Key data: 3600 mm, 4200 mm, 4800 mm
Specifications Control Siemens Sinumerik 840 Dsl Main dimensions and travels Face plate diameter 3,600 mm Circumferential diameter (max.) 4,200 mm Workpiece height (max.) 4,800 mm Total height of the machine 8,700 mm Maximum workpiece weight 80,000 kg. Table base Y Horizontal table displacement 2,000 mm Crossbar Vertical adjustment of the crossbeam in 100 mm increments 2,800 mm Crossbeam Support (Right) Horizontal adjustment support - 1,800 to + 2,200 mm Vertical displacement of the chisel slide valve 1,500 mm Cross-section of the chisel slide 240x240 mm Tool stations 20 pcs. Side Support (Right) Vertical adjustment support 2,800 mm Horizontal displacement of the chisel slide valve 1,000 mm Cross-section of the chisel slide 240x240 mm Turning diameter max./min. 4500/2500 mm Tool Changer Main Drive: Main motor power 105 kW Face plate speed ...
turning diameter: 500 mm turning length: 1100 mm control: Pfillips 432 turning diameter over slide rest: 420 mm spindle turning speed range: 3000 U/min spindle passage: 82 mm Tool changer: 12 tool taper: VDI 40 total power requirement: kW weight of the machine ca.: 5,7 t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: 325 mm turning length: 600 mm control: Siemens type: 840D Turret 12-fold, 12 stations: live tooling: turning speeds: 5000 U/min power capacity: 25 kW y-axis: mm c-axis: total power requirement: 35 kW weight of the machine ca.: 6,5 t dimensions of the machine ca.: 3,5x2,5x2,1 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Key data: 420 mm, 1524 mm, 3300 1/min
Stock number: 3963 CNC LATHE Manufacturer: MAZAK, Type: INTEGREX 400 III-S Machine NO.: 173882, Year of manufacture: 2005 Specifications: Max. circumferential diameter 420 mm dia. Max. turn. About Bed 850 mm Dia. Turning length 1524 mm Main motor power 30 kw Main spindle speed range 3300 rpm Drilling through drawing tube 102 mm dia. C axis - head spindle movement 0.001 degrees Y axis +/- 115 mm B Axis Movement -30/+195 degrees B axis spindle speed 12000 rpm B axis spindle effect 18.5 B axis tool system Capto C6 Sub-spindle C axis - counter pindle movement 0.001 degrees Engine power sub-spindle 26/22 Kw Total Power Consumption 99.9 kva Control Mazatrol 640 Fabr. Spindle Hours 7167 Hours Controlled in 6 Axes Accessories: ATC Tool magazine with 40 stations Hydr. Chuck main spindle 300 mm dia Hydr. Chuck Subspindle 300 mm dia ...
turning diameter: max. 420 mm turning length: 1250 mm control: INDEX, C 200-4 D swing diameter: 630 mm travel x1: 320 mm travel z1: 1250 mm travel x2: 170 mm travel z2: 1250 mm travel x3: 320 mm travel z3: 1250 mm main spindle speed: max. 3000 U/min main spindle drive: 53 kW spindle passage: 102 mm spindle head: DIN 55026 Gr. 11 max. torque on the spindle: 675 Nm sub spindle - spindle speed range: max. 3000 U/min sub spindle drive: 53 kW sub spindle - spindle passage: 102 sub spindle - spindle head: DIN 55026 Gr. 11 sub spindle - spindle torque: 675 Nm travel sub spindle: 1250 mm feed power: X1 14000/Z1 14000 N rapid traverse: X1 20/Z1 40 m/min feed power: X2 8600/Z2 14000 N rapid traverse: X2 20/Z2 40 m/min feed power: X3 14000/Z3 14000 N rapid traverse: X3 20/Z3 40 m/min numbers of turret head positions: Rev. 1 = 12 numbers of turret head positions: Rev. 2 = 10 numbers of turret head p ...
turning diameter: 120 mm turning length: 380 mm control: Fanuc 18 iTB max. swing diameter: 300 mm : : 8000 min/-1 : 7,5 kW : 26 Nm spindle nose: 100 mm spindle passage: 32 mm A-Axis: : 8000 min/-1 : 5,5 kW : 23 Nm spindle nose: 100 mm spindle passage: 32 mm : : 12 pos. tool taper: VDI 16 Sub Spindle: x-axis: 400 mm z-axis: 400 mm feeds:: rapid traverse: 12 m/min total power requirement: 20 kW weight of the machine ca.: 2,3 t dimensions of the machine ca.: 2,8 x 2 x 1,7 m 2022 New glass scale Heidenhain and replacement of smaller parts, new FANUC CNC Keyboard CNC - Ultra precision turning centre (X-, Z-, E-, C-Axe) - CNC control Fanuc 18iTB - Main and counter spindle - SAUTER tool turret 16-fold (0.5.480.510) VDI 16 - Linear tool slide - automatic doors - Chip tray - Coolant system with fine filter (high Pressure Pump) - 3 jaw chucks - Various clamping devices/pressure collets - Vari ...
faceplate diameter: 3300 mm swing diameter: 4000 mm turning height: 3050 mm workpiece weight: 25 t faceplate turning speed range: 8 - 40 U/min ram swivable +/-: 30 ° main drive motor: 55 kW Control: Heidenhain TNC 640 total power requirement: ca. 85 kW weight of the machine ca.: 85 t dimensions of the machine ca.: 8,0 x 7,7 x 6,7 m Conversion and modernisation in 2024 equipped with: - CNC control Heidenhain TNC 640 & Handwheel - 2 swivelling ram supports (1x CNC controlled) - chip conveyor The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Inv. Num. : 8329 Type: KMX 413 Producer: MANURHIN Created: 2018 Parameters: Control system: FANUC Hours: 9473 h Max. rod diameter: 16 mm Number of axles: 4 plus 2 pieces Maximum spindle speed: 12000 1/min Spindle bore: 19 mm Spindle stroke: 130 mm Equipment: Collets Bar Feeder Spindle adjustment for 16 mm rod without adjusting the rod end
Circulation/rotation Ø over bed: 475 mm Rotation/rotation Ø via cross slide: 260 mm Sledge path plan: 260 mm centre distance: 1000 / 1500 / 2000 mm power capacity: 22 kW Gear stages. m= manual / e= electric.: 2 e Spindle head DIN 55026 / DIN 55027: A6 / 6 Spindle Ø in front bearing: 115 mm spindle bore: 78 / 70 mm turning speed range (V-constant): 1 - 3.000 U/min feed range flat: 1µ - 1.000 mm/U feed range lengthwise and thread: 1µ - 2.000 mm/U Rapid traverse plan/longitudinal: 5 / 10 m/min diameter of quill: 70 mm quill travel: 120 mm quill inner cone: 5 MK This machine is used for the production of individual parts and small batches from simple to the most complex contours. It is characterised by: --> Ease of operation Precision Working range
Key data: 270 mm, 470 mm, 270 mm
Turning length: 470 mm Turning diameter over bed: 270 mm Turning diameter over cross slide: 145 mm Spindle speeds: 56 - 4000 rpm Spindle Passage: 26 mm Digital Readout: On X and Y Axes Country of origin: Netherlands Engine power: 1.75 hp Machine weight: 900 kg Machine LxWxH: 1200 x 460 x 1200 mm
turning diameter: max. 560 mm turning length: 600 mm control: 840D powerline Siemens greates pass round over bed: 680 mm Swing dia. over traverse guideway: 565 mm centre distance: 620 mm Main spindle:: turning speed range - main spindle: 20 - 5.000 min/-1 power capacity - main spindel: 25 / 37 kW max. Torque: 390 Nm spindle nose: 170H5 spindle bearing diameter: 120 mm usable bar diameter: 65 mm max. chucking diameter: 250 mm C-Axis: 0,025° / 360 ° Subspindel:: Spindle speed range subspindle: 20 - 7.000 min/-1 power capacity - Sub spindle: 25 / 33 kW max. Torque: 213 Nm spindle bearing diameter: 90 mm spindle bore: 57 mm spindle nose: 140H5 C-Axis: 0,025° / 360 ° turret:: number of toolpositions: 12 pos. Number of driven toolspositions: 12 pos. Spindle speed - driven tools: max. 4.500 min -1 power capacity - driven tools: 12,2 kW tool taper: VDI 40 DIN 69880 Tool dimensions with sq ...
A Gildemeister CNC double-spindle turning and milling center including coolant system and chip conveyor is available. Turning diameter over bed: 640mm, machining diameter: 400mm, center distance: 1930mm, travel X/Z: 550mm/1585mm, travel Y: +/-110mm, B-axis: +/-120° (interpolating), C-axis: 360°. Main spindle: power: 36kW/45kW, speed: 4000rpm, torque: 600Nm-730Nm, bore: 107mm. Milling spindle: Speed: 12000rpm, power: 13.2kW/22kW, torque: 100Nm. Tool places: 60, carrier: turret 12-fold star SW 380, machine dimensions X/Y/Z: approx. 9300mm/4600mm/3100mm, weight: approx. 20000kg, control: Siemens Sinumerik 840D powerline. Documentation available. On-site inspection is possible.
turning diameter: 400 mm turning length: 600 mm control: Turn Plus CNC Pilot 3190 total power requirement: 44 kVA weight of the machine ca.: 5 t dimensions of the machine ca.: 6 2,5 2 m Machine has been in use until now ( 2-axis turning ) Known defects: - Driven tools without function - Tailstock leaking - out of service - Sporadic problems hydraulics / leaking The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Key data: 750 mm, 1524 mm
Control Mazatrol Matrix Max. Rotary Diameter 760 mm Max. turning length 1,524 mm Travel X-axis: 630 mm Y-axis: 230 mm Z-axis: 1,585 mm W-axis: 1,530 mm B-axis -30 to 210° Rapid traverse X/Y/Z/W 50/40/50/30 m/min Main spindle Drive power: 30 kW Max. spindle speed 3,300 rpm C-axis Max. bar passage: 102 mm Sub-spindle Drive power: 26kW Max. spindle speed 4,000 rpm C-axis Milling spindle Drive power: 18.5 kW Max. spindle speed: 12,000 rpm B-axis: 0.0001° Capto C6 Tool magazine / ATC 80 tool positions Max. tool diameter: 90/125 mm Max. tool length: 400 mm Max. tool weight: 10 kg Special equipment Cooling by the spindle High pressure pump 70 bar 20 l/min . PLC with 7 pressure levels Chip conveyor MAYFRAN CONSEP 2000 II 70 bar 20 l/min . PLC with 7 pressure levels Interface for bar feeder Automatic Parts Catcher Synchronized Threading ...
turning diameter: 400 mm swing diameter: 420 mm x-travel: 850 mm z-travel: 315 mm spindle head DIN 55026 - Size: 11 spindle bearing diameter: 140 mm turning speeds: max. 4000 U/min tool turret 12 times: C5 Capto rapid traverse x + z axis: 45 / 30 m/min feeding force: 11 kN total power requirement: 58 kW weight of the machine ca.: 9 t dimensions of the machine ca.: 9,5 x 4,5 x 3 m Hard turning Dry machining Chip conveyor Promot Portal and Cellmaster No clamping device available No tools available no Cellmaster accessories available The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: 658 mm workpiece length - max.: 1519 mm control: Mazatrol Matrix 2 swing diameter: 658 mm clamping range for bar work: 102 mm workpiece weight: 1000 kg ------------ MAIN SPINDLE ------------: turning speeds: 35 - 3300 U/min passage of spindle: 112 mm c-axis: 0,0001 spindle motor: 30/22 kW spindle nose: A2-8 milling spindle: spindle motor: 22 / 15 kW milling head speed: 12000 U/min b-axis: -30 / +210 ° travel -x axis: 615 mm travel -y axis: 260 mm travel -z axis: 1585 mm rapid travel x/y/z: 50 / 40 / 50 m/min 2nd Spindle:: spindle turning speed range: 4000 U/min spindle motor: 26 / 22 kW spindle nose: A2-8 spindle passage: 91 mm w-axis: 1539 mm total power requirement: 108,53 kVA weight of the machine ca.: 18 t dimensions of the machine ca.: 5,2 x 2,8 x 2,75 m - CNC control Mazatrol Matrix 2 - Main & counter spindle - Milling spindle (Capto C6) - 36-position tool cha ...
The machine is in good technical condition, after prior agreement it is possible to test it. Control system: Fanuc Max. turning diameter: ø65mm Max. workpiece length: 300mm Turret head: 2x12 driven positions Bar feeder: IEMCA master 880 MP Cooling + chip conveyor
CNC Lathe Manufacturer: Gildemeister Type: CTX 420 linear V3 Year of Make: 2003 Control: Heidenhain Plus IT Circumferential diameter over bed: 680 mm Circumferential diameter over face slide: 565 mm Plan travel: 260 mm Longitudinal travel: 635 mm Drive power: 40/ 100% 25/37 kW Speed range from – to: 20 – 5000 rpm Weight approx.: 6500 Kg Equipment: Driven tools: 12 stations Tool carrier: 12-cavity Sauter revolver VDI 30 Partial hollow clamps Tailstock Quill stroke automatic Quill holder: Mk 5 Conveyor Measuring arm Oil mist extraction Errors excepted
DMG MORI NEF 400 CNC turning center was built in 2009 in Poland by FAMOT Pleszew S.A. The machine, distinguished by its compact design and high efficiency, is used for precision machining of workpieces with a maximum diameter of 350 mm. The machining process is performed inside a fully illuminated workspace by means of a high-speed spindle and precision cutting tools taken from a 12-position turret. The extremely rigid design eliminates any vibration and oscillation, ensuring maximum process stability during even the most intense challenges. All these features make the DMG NEF 400 the best choice for any industrial plant. The GILDEMEISTER NEF 400 CNC lathe was used for prototyping and worked for a total of 6492 hours. The offer also includes extensive equipment, consisting of, among others, an advanced HEIDENHAIN CNC control, driven tools and a chip conveyor. Technical specificatio ...
GILDEMEISTER CTX 400E CNC turning center was built in 2000 in Germany by GILDEMEISTER Drehmaschinen GmbH. The machine, designed for machining workpieces with a maximum diameter of 570 mm, is distinguished by its high precision and reliability. The large working area is equipped with a 12-position turret and a spindle, whose high-powered motor allows all modern cutting tools to be fully utilised. The CTX 400E CNC lathe weighs approximately 5300 kg. Technical specifications of the GILDEMEISTER CTX 400E metal lathe - maximum turning diameter: 440 mm - maximum turning diameter over bed: 570 mm - maximum turning diameter over slide: 420 mm - maximum turning length: 635 mm - distance between centers: 700 mm - feed in the X/Z axis: 220/635 mm - maximum spindle rotational speed: 5000 rpm - spindle bore diameter: 79 mm - spindle drive power: 21 kW - 12-position turret - number of ro ...
turning diameter: 475 / 260 mm turning length: 1000 mm control: Heidenhain Manual Plus turret head: 12 x VDI 30 total power requirement: 25 kW weight of the machine ca.: 3 t dimensions of the machine ca.: 2,51,52 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Key data: 650 mm, 1500 mm
Year of construction 2014, commissioning 2017 OSP P300S Controller Travel: X1/X2 axle: 695/235 mm Y-axis: 300 mm Z1/Z2 axle: 1,600/1,461 mm B-axis: -30° to +210° Max. turning diameter: 650 mm Big Bore main spindle 32/22 kW, spindle nose A2-11, max. speed: 3,000 rpm, Max. torque: 955 Nm, bore 112 mm Hollow Clamping Cylinder SMW VNK320-127, Bore 127 mm 3-jaw chuck Forkardt 3QLK 315-88 Z11 Pressure reducing valve 8-70 bar Milling spindle 22 kW, max. speed: 12,000 rpm Tool magazine with 40 tool positions, HSK-A63 Lower turret with 12 tool stations Self-centered bezel on the lower turret Hydraulic bezel SMW SLU-X-3.2-ZS, clamping range: 50-200 mm Programmable tailstock Renishaw RMP Probes Drum trough filter TMF300 with 980 L tank 8 bar circulation pump 70 bar high pressure pump Hinge belt chip conveyor Tool monitoring system for tool life and breakage Tool measur ...
Universal CNC lathe INDEX G 400 RATIO Line Hersteller [manufacturer]: INDEX Type [ type]: G 400 Control unit: Siemens C200-4D incl. milling of cylindrical tracks Incl. handwheel Baujahr[construction year]: 10/2004 Turning length 1250 Main spindle D102 with swing-in gear 1700 Nm Size 11 Hollow Clamping Cylinder 102 ARB-SPI ALIGNMENT. AND SWITCHING DEVICE TOOL CARRIER 1 COMPL. AXES X,Y,Z,B with turning/milling operation Disc turret VDI40 10 stations MILLING SPINDLE HSK A63 Tool carrier axles 2 XZ Disc turret VDI40 10 stations SUB-SPINDLE D102 DIRECT DRIVE 1300Nm Size 11 Hollow Clamping Cylinder 102 ARB-SPI ALIGNMENT. AND SWITCHING DEVICE DISC MAGAZINE ON THE LEFT OF THE HSK63 SINGLE-SWING GEARBOX WITH 32 TOOL HOLDERS DISC MAGAZINE RIGHT COMPL. M.32 TOOL HOLDERS HSK 63A Travel path: X= 320mm Z=1250mm Displacement measuring system X-axis glass mast. (abs) Fe ...
Key data: 660 mm, 983 mm
CONTROL PANEL FANUC F31-IA5 AXIS MOVEMENT X 750 MM / Y ± 210 MM / MM / Z 1.220 MM ROTARY AXIS MOVEMENT B + / - 120 ° / C 360 °/ 0.001 ° MAX. TURNING DIAMETER 660 MM MAX. TURNING LENGTH 983 MM SPINDLE - 1 CHUCK SPİNDLE SPEED 3.000 MIN/-1 CHUCK DIAMETER 12 INC / 315 MM BAR CAPACITY 90 MM TOOL SPINDLE SPEED ( S1 ) 12.000 MIN/-1 TOOL HOLDERS CAPTO C6 NUMBER OF TOOL POSITION 100 SPINDLE - 2 SPİNDLE SPEED RANGE SUP SPİNDLE 3.000 MIN/-1 CHUCK DIAMATER SUP SPINDLE 12 INC / 315 MM WEIGHT OF THE MACHINE 22.300 KG DIMENSIONS OF THE MACHINE 5.33 X 3.27 X 2.93 M
turning length: 4.500 mm greates pass round over bed: 810 - 760 mm swing diameter over slide rest: 740 mm control: SIEMENS - 840 C max. turning diameter: 800 mm turning diameter over slide: 740 mm travel -x2 axis: 875 mm travel -z2 axis: 5.200 mm CNC Turning- and Milling Center | NILES-SIMMONS - N40 MCT 4500 equipped with a turret for driven tools as well as NC steady rest and tailstock. Additional equipment: - Centering points, - Jaw sets, - Clamping jaws, The machine is in a well-maintained condition and can be inspected at any time under power. Please refer to further technical details in the attachement of the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: N-40 | N 40 | N40MCT4500 | N40MCT The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
chuck diameter: 500 mm swing diameter over bed slide: 700 mm control: Siemens travel -x axis: 630 mm travel -z axis: 500 mm CNC turning and milling center vertical | EMAG - VMC 450 MT The machine is in very good condition. Please note that the technical details were added from comparable machines. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: VMC450MT | VMC 450MT | VMC-450 | VMC-450MT The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: 660/275 mm turning length: 1498 mm control: Fanuc/Mori Seiki MSX 701 total power requirement: 90 kVA weight of the machine ca.: 26,6 t dimensions of the machine ca.: 5301 x 2997 x 2788 mm 9-axis CNC turning and milling centre Fanuc MSX-701 CNC control Milling spindle at top (B axis), as full 4th axis, positioning 0.0001 deg. 40-position tool magazine 10-position turret at bottom, all positions driven 2 x 3-jaw quick-change chuck KNCS-N 315/91 KNOLL high-pressure coolant system, pressure setting 12/25/35/45/55/62 and 72 bar, with maintenance-free rotary filter system Chip conveyor Drain system for main spindle chuck (controlled via M function) Drain system for tool cutting edge (controlled via M function) Coolant gun incl. accessories Oil mist extraction Direct measuring system X1, X2, Y-axis Bar loader interface Double foot switch for both spindles Island ...
turning diameter: 400 mm turning length: 1100 mm control: Siemens Sinumerik 840D SL greates pass round over bed: 500 mm Swing dia. over traverse guideway: 370 mm Main spindle:: Max. rpm: 5000 min/-1 power capacity - main spindel: 17 / 25.5 kW max. Torque: 345 Nm spindle diameter in front bearing: 130 mm spindle bore: 67 mm chucking diameter: 325 mm spindle nose: A8 axis stroke:: x-axis: 750 mm y-axis: +/- 100 mm z-axis: 1200 mm feeds:: rapid traverse: 40 / 40 / 40 m/min Tailstock:: tailstock: 1200 mm taper of center: Mk 5 tension force: max. 8 kN milling head: b-axis: +/- 120 ° tool taper: HSK A 63 tool piece magazine with: 60 spindle turning speed - stepless: 12000 U/min spindle motor: 10,5 kW max. torque on the spindle: 90 Nm total power requirement: - kVA weight of the machine ca.: 9 t dimensions of the machine ca.: 4,6 x 2,5 x 2,82 m Equipped with: - Siemens 840D SlimLine / Cel ...
Parallel Lathe SCULFORT type MAXICAP SENIOR 380 x 4000 RN Between points: 4000 mm Maxi Ø on bench: Ø 780 mm Maxi Ø over saddle: Ø 580 mm (rear trolley dismantled) - Ø 500 mm (without rear trolley dismantled) Maxi diameter in brocken bed: Ø 1160 mm Width in brocken bed: 400 mm Spindle: Ø 80 mm Spindle speed: from 16 to 1280 RPM Square turret 3-jaws chuck Ø 400 mm Threadings: Metric + Withworth 3 points steady max Ø 350 mm Tailstock CM6 Motor power: 13 CV Feeds: auto transverse + longitudinal Clutch rapid used Lubricant tank Dimensions (L x W x H): 6500 x 1800 x 1900 mm Weight: approx 7 T
CNC Turning/Milling Centers CTX 410 Management Heidenhain Plus IT - 3 cheek chuck - Driven tool stations - Tailstock - Chip conveyors - Coolant tank
CNC Turning/Milling Centers CTX 410 /2 Management Heidenhain Plus IT - 3 cheek chuck - Driven tool stations - Tailstock - Chip conveyors - Coolant tank
CNC lathe Okuma LB 4000 EX – MY C750 Control: OSP-P200L Year of Make: 2008 Turning length: 750 mm Turning diameter: 430 mm Swivel diameter over bed: Ø 670 mm Swivel diameter over slide: Ø 480 mm Speed: 42 – 4,200 rpm Tool turret V12 (all places driven) Equipment: One touch IGF Chip conveyor Touchsetter 3-jaw chuck (Kitagawa B212)
This Gildemeister CTX 400 S2 Lathe was manufactured in the year 1998 in Germany and has 65655 production hours. It is equipped with a HEIDENHAIN CNC PILOT 3190/4290 control unit. The machine has a spindle speed of 25-5000 rpm.
This 5-axis Mazak Integrex 400Y was manufactured in 2000. Ideal for complex machining, this turn-mill centre machine integrates multiple operations. Consider the opportunity to buy this Mazak Integrex 400Y Turn-Mill Centre machine. Contact us for more information.
This 3-Axis DMG MORI CLX 450 V4 was manufactured in 2020 and features advanced technology cycles like drilling, threading, and grooving, along with a main spindle speed of 4,000 rpm. Its equipped with a turret that includes 12 driven tools and 6 BT stations, and boasts a direct measurement system in X and Y axis with a Y-axis range of +/- 60mm. Control is managed by the sophisticated SIEMENS 840D. Buy this DMG MORI CLX 450 V4 lathe to leverage its precision capabilities. For further details, please contact us.
This 12-axis Citizen Cincom M16-4M8 was manufactured in 2021, featuring a robust configuration with up to 38 tools, including gang, turret, and back tool post options. It supports a rapid feed rate of 32 m/min, with specialized rates for X2, Y2, and B axes. The main spindle motor outputs 2.2/3.7 kW, ensuring efficient operations. Consider the opportunity to buy this Citizen Cincom M16-4M8 Swiss type turning machine. Contact us for more information about this machine.
This 4-axis DMG CTX 420 Linear V6 was manufactured in 2002. It features a Siemens 840D Powerline control, VDI 40 tool holder, Y-axis, chip conveyor, and a counter spindle. The machine has been fully overhauled by Eichten Werkzeugmaschinen GmbH, ensuring it is in perfect condition. If you are looking to get high-quality turn-mill capabilities, consider the DMG CTX 420 Linear V6 machine we have for sale. Contact us for more information.
This 3-axis KERN CD 480/2000 horizontal turning machine was manufactured in 2010. It features a Heidenhain Manual Plus 620 control, C-axis, driven tools, a 12-fold revolver, and a chip conveyor. With a spindle speed of up to 3000 UpM and a spindle bore of 82 mm, its ideal for precise turning operations. Consider the opportunity to buy this KERN CD 480/2000 horizontal turning machine. Contact us for more information.
Key data: 640 mm, 1500 mm
Turning/milling center GILDEMEISTER GMX 400 linear Year of Make: 2003 Control: Sinumerik Power line Technical data: Drive power main spindle ISM 90: 36/45 KW (100/40%) Main spindle speed: Torque main spindle: Bar Passage: 90mm Number of magazine slots: 120 pcs. Tool holder milling spindle: HSK 63 Drive power counter spindle ISM 90: 36/45KW (100/40%) Speed of sub-spindle: Torque sub-spindle: Bar Passage: 90mm B-axis / milling spindle: Drive power: Speed: Torque: Tool holder: HSK z3 Lower turret: X-axis: Z-axis: Speed Driven Tools: Number of turret slots: 12 pcs. Tool holder: VDI 40 Accessories: - Chip conveyors - High-pressure system with 20bar - Preparation of 3D probes - Tailstock function counter spindle - Automatic sliding doors
This 3-axis Gildemeister CTX 420 linear was manufactured in 2003. It features a max turning diameter over bed of 680 mm and a chuck diameter of 250 mm, suitable for diverse turning tasks. Equipped with a bar feeder and driven tools, it enhances productivity and precision. If you are looking to get high-quality turning capabilities, consider the Gildemeister CTX 420 linear machine we have for sale. Contact us for more information about this machine.
