vertical lathe dia used for sale

\" Conventional lead and tension spindle lathe – turning length approx. 1,200 mm – Ø 475 mm Chuck lead and tension spindle lathe made by Boehringer Bros. (VDF), industrial version. Equipment: • 3-jaw chuck Ø 475 mm • Tailstock • Rotating center punch • Extensive accessories in the side cabinet (jaws, holders, inserts, etc.) • Coolant device • Controls on the support Turning length approx. 1,200 mm.Condition: Used machine with age-related signs of use. Visually appropriate to the age. Manufacturer: Gebr. Boehringer GmbH Type: Lead and pull spindle lathe Turning length: approx. 1,200 mm Chuck diameter: Ø 475 mm Spindle bore: approx. 80 mm • Dimensions in mm (LxWxH) approx. 3,450 x 1,300 x 1,700 mm \" Auction-ID: A7-46417-373

X-axis travel: 150 mm Z-axis travel: 520 mm Tailstock stroke: 340 mm Self-centering head diameter: 210 mm X-axis repeatability +/- 0.003 mm Z-axis repeatability +/- 0.005 mm Sale intended only for revampists or scrap dealers NOT Working - Faulty Board Auction-ID: A7-46538-33

turning diameter:1600 mm turning length:12000 mm control:FAGOR 8050 Used CNC Lathe with FAGOR 8050 and extensive accessories. For further technical data and accessories, pls browse the Appendix. Parallellathe WMW mod. 4 GUIDE-WAYS ¦ CNC: FAGOR 8050 ¦ bed: monolithic ¦ centres height: 800 mm ¦ centres distance: 12000 mm ¦ swing over cross-slide: 1250 mm ¦ turret: automatic 4 positions ¦ tailstock: motorized ¦ tailstock connection: hydraulic ¦ platform: diam. 1000 mm ¦ steady rests: nr.02 ¦ chip conveyor Warranty: none Take advantage of the favorable leasing and hire-purchase terms from IKB Leasing. Ask us about it.

turning diameter over bed:2600 mm turning diameter over slide rest:2200 mm turning length:5000 mm faceplate:2050 mm number of spindle speeds:0,7 - 70 rpm total power requirement:ca. 22 kw Height of centres: 1350 mm Distance between centres: 5000 mm Swing over cross slide: 2600 mm Spindle power: 30 HP Spindle speed: 0,7 - 70 rpm Longitudinal swift Control on the carriage Chuck: diam. 2050 mm

turning diameter:570 mm turning length:1000 mm dimensions of the machine ca.:3,25 x 2,03 x 1,95 m Tool disc turret for 8 tools with VDI 30. Not for power tools machine manual, technical documentation; Accessories: 3-jaw chuck, various tool holders Video is available

General CNC slant bed lathe Traub is available. Tool stations: 12, tool holder: VDI40, turning diameter: 180mm, max. swing diameter: 450mm, max. turning length: 490mm, bar capacity: 60mm, travel X/Z: 160mm/490mm, rapid traverse: 15m/min, feed rate: 10m/min, machine dimensions X/Y/Z: approx. 3100mm/2000mm/1800mm, weight: approx. 4250kg, control: Traub System TX-8. An on-site inspection is possible.

number of spindles:6 spindle passage:22 mm ?Bar feeder complete is 4.70 meters - for 3 meters of material ?The machine is still on ?Materail to be processed on the machine: Steel ?Production with OIL Machine has only Single-NCU without PCU. The complete energy supply of all 6 main spindles was replaced in April 25. No socket for powered tools!

Universal lathe with cycle control VDF Boehringer VDF 400 DUS Control: Siemens Sinumerik 840 Year of Make: 2014 Internal machine no. 57 Turning length: 1,000 mm Turning diameter over bed / face slide: 420 / 235 mm Displacement of face slides: 250 mm Max. speed: 10 – 3,000 rpm Accessories: - Bezel - Suction - 3- Jaw chuck Schunk 250-62 - Tool holder

Key data: 430 mm, 1400 mm

Guide and pull spindle 32 A 380V 12.5 KW Speeds 18 - 1400 rpm Spindle passage 90 mm Lamp 4-way quick coupler with 14 pick-ups 3 interchangeable jaw sets Röhm Jaw Chuck with 33 cm Bezel Length 1.10 m Width 3 m Height 1.40 m Weight 2.5 T

Key data: 280 mm, 400 mm

Technical data: Manufacturer: Spinner Type: TC 52 MC Year of Make: 2007 Control: Siemens 810D Shop Turn Travels: X 200 mm, Z 570 mm Switch-on hours: 4,364 h Turning diameter: max. 280 mm Circumferential diameter: max. 400 mm Main spindle Speed: 5,000 rpm Spindle passage: 52 mm Tools Revolver: 12-speed Tool holder: VDI 30 Number of driven tools: all Dimensions and weight Weight: approx. 3,500 kg Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: Chip conveyor Interface for bar feeders 3-jaw chuck

Professional Industrial Machine Digital display 3-jaw chuck 200 mm. 4-jaw chuck Face Plate Fixed bezel Steady bezel Multifix steel holder. Machine Light Foot brake Chip tray, chip protection wall Hardened and ground bed sheets Complete coolant system Feed protection Machine feet Machine Tool Turning diameter over bed 400 mm Turning diameter over support 260 mm Turning length 1500 mm Turning diameter in the offset 570 mm Speed 45 - 1800 rpm Tip height 210 mm Spindle bore 52 mm Tailstock quill holder MK 4 Connection voltage 400 V Total power requirement 3.5 kW Machine weight approx. 1.5 t Dimensions approx. 2.6 x 1.1 x 1.7 m Auction-ID: A7-46460-424

Demonstration machine Speed in 6 steps 125 - 2000rpm. 3-jaw chuck 125 mm. 4-jaw chuck 125 mm. (Independent) Fixed bezel. Rotating bezel. 4-fold steel holder. Scout tub. Back wall. Spindle protection. Hardened bed rails. Longitudinal feed with left/right shift. Set of interchangeable wheels. Related tools. Turning diameter over bed 250 mm Turning diameter over support 140 mm Turning length 550 mm Speed 125 - 2000 rpm Tip height 125 mm Spindle bore 26 mm Tailstock quill holder MK 2 MK Tailstock quill stroke 65 mm Connection voltage 230 V Total power requirement 0.8 kW Machine weight approx. 0.135 t Space requirement approx. 1.25 x 0.6 x 0.6 m Condition: never used / new (5) Auction-ID: A7-46460-428

OKUMA CNC Lathe Serial Number: 103965 Power: 29.44 kW Control: Okuma OSP7000L Tool turret and hydraulic plate Includes chip conveyor and external control panel Diameter on bed: 620 mm Diameter on trolley: 420 mm Distance between points: 650 mm Spindle speed: 65–3500 rpm 12-position turret Fast feeds: X 15 m/min, Z 15 m/min Bar capacity: 80 mm CE marking Untested operation This item is delivered loaded by truck. The costs of dismantling and loading are borne by the buyer. Auction-ID: A7-46053-10

Professional lathe 3-jaw chuck 4-jaw chuck Face Plate Fixed bezel Steady bezel Quick-change steel holder with 4 cassettes Halogen Machine Light Chip tray, chip protection wall Hardened and ground bed sheets Complete coolant system Feed protection Machine Tools Turning diameter over bed 320 mm Turning diameter over support 200 mm Turning length 900 mm Speed 75 - 2000 rpm Tip height 160 mm Spindle bore 50 mm Tailstock quill mount MK 3 Connection voltage 230 V Total power requirement 1.5 kW Machine weight approx. 0.29 t Space requirement approx. 2.0 x 0.8 x 1.56 m Condition: never used / new (5) Auction-ID: A7-46460-498

turning diameter:270 -300 mm turning length:710 mm total power requirement:43 kW weight of the machine ca.:8,5 t dimensions of the machine ca.:3,16 x 2,15 x 2,15 m The machine does not include a chuck or tools ? the machine was originally purchased without these accessories. The G300 has X, Z, Y, C, SP, and driven tools. A bar feeder can be used, but the machine does not have one.

turning diameter:220 mm turning length:310 mm total power requirement:17 kW weight of the machine ca.:3,3 t dimensions of the machine ca.:2,25 x 1,63 x 1940 m greates pass round over bed:430 mm bore diameter:45 mm centre distance:687 mm slide travel radial ( X-axis ):160 mm slide travel axial ( Z-axis ):310 mm spindle turning speed range:0-6.300 U/min

TRAUB automatic multi-spindle CNC lathe line equipped with ACTRA-25T control. Includes BECHET (France) bar feeder, serial number 148. Equipped with chip conveyor and automatic parts evacuation system. Fully automated loading and unloading system. Machine with closed protection cabin. Configuration oriented to high-cadence mass production. Suitable for machining small and medium-sized parts. Control panel with manual controls and CNC control. Source of the feeder: Cluses, Haute-Savoie (France). It is sold as a complete line consisting of lathe, bar feeder and evacuation system. Auction-ID: A7-46053-3

turning diameter:220 mm turning length:700 / 665 mm total power requirement:17 kW weight of the machine ca.:2,6 t dimensions of the machine ca.:2,63 x 1,98 x 1,94 m greates pass round over bed:430 mm Part length max.:510 slide travel radial ( X-axis ):160 mm bore diameter:45 mm Texte, Bilder, Grafiken, Layout, Strukturen und Algorithmen etc. unterliegen weltweitem Urheberrecht. Unerlaubte Verwendung der Daten, werden sowohl strafrechtlich als auch zivilrechtlich verfolgt. Das ausschließliche Urheber- / Nutzungsrecht dieser Daten wurde nachfolgender Person eingeräumt. Copyright © 2005-2026, Josef Weber. All rights reserved.

OKUMA CNC Lathe Serial Number: 131693 Power: 45 kW Control: OKUMA OSP-P200L 2 axes + C Diameter on bed: 620 mm Diameter on trolley: 420 mm Distance between points: 1270 mm Chainring: 400 mm Bar capacity: 80 mm Spindle speed: 35–3500 rpm 12-position motorized turret type VDI Fast feeds: X 20 m/min, Z 25 m/min MT5 tailstock Includes chip extractor and presetting Untested operation This item is delivered loaded by truck. The costs of dismantling and loading are borne by the buyer. Auction-ID: A7-46053-11

Professional lathe Digital display 3-jaw chuck 4-jaw chuck Face Plate Fixed bezel Steady bezel Quick-change steel holder with 4 cassettes Halogen Machine Light Chip tray, chip protection wall Hardened and ground bed sheets Complete coolant system Feed protection Machine Tools Rotating center punch Turning diameter over bed 320 mm Turning diameter over support 200 mm Turning length 900 mm Speed 75 - 2000 rpm Tip height 160 mm Spindle bore 50 mm Tailstock quill holder MK 3 MK Connection voltage 230 V Total power requirement 1.5 kW Machine weight approx. 0.29 t Space requirement approx. 2.0 x 0.8 x 1.56 m Condition: never used / new (5) Auction-ID: A7-46460-442

Professional Industrial Machine (400Volt) 3-axis digital display 3-jaw chuck 180 mm. 4-jaw chuck 200 mm. Face Plate 280mm Fixed bezel Steady bezel 4-fold steel holder. Halogen Machine Light Machine Light Foot brake Removable chip tray, chip protection wall Hardened and ground bed sheets Complete coolant system Feed protection Machine Tools Turning diameter over bed 360 mm Turning diameter over support 220 mm Turning length 1000 mm Turning diameter in the offset 380 mm Speed 70 - 2000 rpm Center height 180 mm Spindle bore 50 mm Tailstock quill holder MK 3 MK Connection voltage 230 V Total power requirement 1.8 kW Machine weight approx. 0.65 t Space requirement approx. 2.0 x 0.8 x 1.56 m Condition: never used / new (5) Auction-ID: A7-46460-571

turning diameter over bed:350 mm turning diameter over slide rest:240 mm turning length:800 mm Spindle RPM:40 - 2000 in 8 Stufen 1/min total power requirement:3 kW Spindle bore:26 mm tailstock quill taper MT:MK 2 dimensions of the machine ca.:1,5 x 1,0 x 1,6 m weight of the machine ca.:1,9 t Very well maintened center lathe with accessories - 3-jaw, 4-jaw chuck - tailstock with center - 1 boring head - RAPID quick tool change device with 3 holder - saddle mounted steady rest - collant device - set of collets appr. 75% size B 32

3-axis digital display 3-jaw chuck 200 mm. 4-jaw chuck 200 mm. Face Plate 320mm Fixed bezel Steady bezel 4-fold steel holder. Halogen Machine Light Machine Light Foot brake Removable chip tray, chip protection wall Hardened and ground bed sheets Complete coolant system Feed protection Machine Tools Turning diameter over bed 400 mm Turning diameter over support 264 mm Turning length 1000 mm Turning diameter in the offset 550 mm Speed 44 - 2000 rpm Center height 200 mm Spindle bore 52 mm Tailstock quill holder MK 4 MK Connection voltage 400 V Total power requirement 1.5 / 2.4 kW Machine weight approx. 0.9 t Dimensions approx. 1.9 x 0.8 x 1.56 m Condition: never used / new (5) Auction-ID: A7-46460-557

turning diameter:500 mm turning length:1500 mm spindle motor:16 kW Spindle RPM:1 - 2500 1/min taper in tailstock MT:5 tailstock quill stroke:160 mm tailstock quill diameter:70 mm total power requirement:22 kW weight of the machine ca.:3,2 t dimensions of the machine ca.:3,2 x 1,8 x 1,4 m Machine with Heidenhain Manual plus control - Multifix quick tool change device - 3-jaw chuck - sliding splash door - various accessories.

SINO Digital Display 3-jaw chuck 200 mm. 4-jaw chuck 200 mm. Face Plate 250mm Fixed bezel Quick-change steel holder with 4 pcs steel holder Machine Light Chip tray, chip protection wall Hardened and ground bed sheets Feed protection Machine Tools Turning diameter over bed 320 mm Turning diameter over support 200 mm Turning length 900 mm Turning diameter in the offset 320 mm Speed 75 - 2000 rpm Tip height 160 mm Spindle bore 38 mm Tailstock quill mount MK 3 Connection voltage 400 V Total power requirement 1.5 kW Machine weight approx. 0.4 t Space requirement approx. 1.6 x 0.75 x 1.7 m Condition: never used / new (5) Auction-ID: A7-46460-500

turning diameter over bed:500 mm turning diameter over slide rest:310 mm turning length:1500 mm spindle turning speed range:7 - 710 U/min feed range:5,6 - 224 mm/min total power requirement:15 kW weight of the machine ca.:3,7 t dimensions of the machine ca.:2,9 x 1,4 x 1,6 m Machine with 2-axis digital readout - MULTIFIX quick tool change device - 3-jaw chuck

turning diameter over bed:1000 mm turning diameter over slide rest:750 mm turning length:3000 mm weight of the machine ca.:12 t dimensions of the machine ca.:6x2,5x1,8 m spindle bore:110 mm turning speed range:900 U/min Year:1986 Equipment: - Coolant device - 1 static steady rest - 1 rotating steady rest - Faceplate 1.000 mm - Digital display - Rapid traverse

Equipped with - 27 mm spindle passage - Adjustable guide tracks - Powerful motor with 0.75 kW - High resolution of the axis spindles for exact positioning - Attention without digital display Scope of delivery: 3-jaw chuck 100 mm, interchangeable wheel set, splash guard. Turning diameter over bed 250 mm Turning diameter over support 130 mm Turning length 700 mm Speed 115 - 1620 rpm Tip height 125 mm Spindle bore 27 mm Tailstock quill holder MK 2 Tailstock quill stroke 40 mm Metric threads 0.2 - 3.5 mm Thread - Inch 8 - 56 inch. Thread - Module 0.2 - 12.5 mm Swivel range +/- upper slide 45 ° Connection voltage 400 V Total power requirement 0.75 kW Machine weight approx. 0.15 t Dimensions approx. 1.41 x 0.61 x 0.41 m Condition: never used / new (5) Auction-ID: A7-46460-542

FANUC CNC Lathe Serial Number: S2-1342 Power: 13 kW CNC Control: FANUC 0i-TA Spindle speed: up to 4500 rpm (max. 6000 rpm) 12-position turret Turning diameter: 180 mm Z-axis travel: 300 mm 160 mm hydraulic plate Bar pitch: 52 mm Coolant capacity: 40 L Suitable for the production of small and medium-sized parts Untested operation This item is delivered loaded by truck. The costs of dismantling and loading are borne by the buyer. Auction-ID: A7-46053-12

turning diameter:145 mm turning length:210 mm total power requirement:40 kW swing diameter:145 mm Spindle bore sp. 1:56 mm Spindle bore sp. 2:56 mm swing diameter over face slide:145 mm greates pass round over bed:145 mm RPM Main Spindle:7.000 1/min number of workpiece supports:12 Shank diameter:25 mm C-axis RPM:2.000 1/min Chuck diameter spindle 1:140 mm Chuck diameter Spindle 2:140 mm Number of tools:12 fach St. Tool bore:VDI 25 Shank diameter:25 mm weight of the machine ca.:5.300 kg dimensions of the machine ca.:5.000 x 4.100 x 2.050 mm Slide path flat: X1, X2, X3: 220mm, 120mm ( 145mm ) Longitudinal slide travel: Z1, Z2, Z3: 320mm, 345mm, 380mm Vertical slide travel Y1: +/- 30mm Longitudinal spindle travel Z3: 380mm Clamping tube inner draw tube 46mm diameter Speed range main drive 1+2 up to 7,000 rpm Speed of driven tools up to 6,000 rpm Main and counter spindle collet chuck 1 axial ...

3-axis digital display 3-jaw chuck 200 mm. 4-jaw chuck 200 mm. Face Plate 320mm Fixed bezel Steady bezel 4-fold steel holder. Halogen Machine Light Machine Light Foot brake Removable chip tray, chip protection wall Hardened and ground bed sheets Complete coolant system Feed protection Machine Tools Turning diameter over bed 400 mm Turning diameter over support 264 mm Turning length 1000 mm Turning diameter in the offset 550 mm Speed 44 - 2000 rpm Center height 200 mm Spindle bore 52 mm Tailstock quill holder MK 4 MK Connection voltage 400 V Total power requirement 1.5 / 2.4 kW Machine weight approx. 0.9 t Dimensions approx. 1.9 x 0.8 x 1.56 m Condition: never used / new (5) Auction-ID: A7-46460-514

turning diameter:570 mm turning length:- mm control:- Diameter of rotation above the bed slide:360 mm Maximum width:2.000 mm revolutions per minute:max. 2500 U/min :11 kW max. longitudinal feed:7,5 m/min max. transverse feed:7,5 m/min rapid traverse longitudinal:12 m/min rapid traverse cross:15 m/min Pinole diameter:95 mm Pinolenhub:220 mm Pinolen intake: MK 5 weight of the machine ca.:2,97 t dimensions of the machine ca.:3,8m x 1,3m x 2m m Technical description: - Tool turret - automatic - 8-fold (see also options) - CAPTO Revolver Disc - Machine bed - made of perlite casting GG-26 - high stiffness due to strong ribbing - Bed slides - guideways hardened and ground - automatic lubrication of the bed rail - Reitstock - manual - Quick clamp - Operator station - two movable handwheels on the operator panel - a movable handwheel - Control - "Siemens 828 D" CNC control - Siemens "Comfort" (in ...

turning diameter:500 mm turning length:1500 mm Technical Specifications: ·Turning diameter over cross slide: 290 mm ·Spindle bore: 71 mm ·Speed range: 3?2,800 rpm ·Rapid traverse speed: 10 / 5 m/min ·Feed rate: 1?2,000 mm/min ·Total power requirement: 22 kW ·Machine weight: approx. 3.2 t ·Space requirement: approx. 3.0 × 1.6 × 2.0 m

turning diameter:356 mm turning length:700 mm y-axis:±60 mm spindle drive:18 kW counterspindle motor:15 kW Direct drive for driven tools:5,5 kW Motor starting torque:640 Nm Main spindle mount:A2-8 counter spindle mount:A2-6 Rod passage:80 mm main spindle speeds::4.000 U/min Drehzahl angetriebene Werkzeuge :6.000 U/min rapid traverse speed:30 m/min auf X- und Z-Achse machine weight ab.:5.800 kg 12-station turret, all positions driven C-axis on both spindles Belt-driven and infinitely variable drive on all motors Prismatic guideways on all axes Oil cooler for both spindles, manufacturer Daikin Automatic, dialog-guided programming system MAPPS Automatic monitoring of tool load and tool wear Two Renishaw measuring arms for automatic tool measurement Interfaces: USB, PCMCIA card, and RS-232 port Interface for bar feeder Automatic parts catcher Dual foot pedal for independent opening and clos ...

turning diameter:570 mm turning length:635 mm travel -x axis:220 mm travel -z axis:635 mm Torque:240 Nm feed::X: 20m/min; T: 24m/min disc turret:12 fach main spindle speeds::25-25.000 dimensions of the machine ca.:3210 x 1750 x 1750 mm weight of the machine ca.:5.300 t

turning diameter:x. 350 mm turning length:985 mm swing dia.:610 mm clamping range for bar work:77 mm speeds:350 - 4.000 U/min Torque:465 Nm spindle nose:A2 - 8" spindle bore diameter:88 mm chucking diameter:254 mm numbers of tools:12 travel -x axis:190 mm travel -z axis:1.025 mm rapid traverse X-axis:30 m/min rapid traverse Z-axis:33 m/min Tailstock Travel:1.010 mm tailstock taper MT:4

turning diameter over bed:570 mm turning diameter over slide rest:365 mm turning length:2.000 mm feed per revolution:0,06 - 58/ 0,03 -28 mm spindle turning speed range:11,2 - 2.240 U/min spindle bore:62 mm spindle head:8 nach DIN 55022 total power requirement:15 kW dimensions of the machine ca.:4,5 x 1,5 x 1,4 m weight of the machine ca.:4,8 t

turning diameter:1070 mm turning length:8500 mm total power requirement:62 kW turning diameter over slide rest:800 mm spindle bore:128 mm max. workpiece weight between centers:8000 kg max. workpiece weight:12000 kg bore spindle turning speed range:1,120-01120 U/min tailstock quill diameter:200 mm dimensions of the machine ca.:12 x 2,8 x 2,4 m Machine equiped with Alan Bradley 9 series CNC control - SAUTER 6-postiion revolving head - 360 mm seld centering steady rest - 385 mm rotary work rest (used for gun barrels) - faceplate 800 mm - chip conveyor

turning diameter:830 mm turning length:4.000 mm turning diameter over bed slide:540 spindle bore:130 mm turning speed range:2 - 1.600 U/min rapid speed:4/5 m/min feed speeds:1 - 2.000 mm/min total power requirement:55 kW dimensions of the machine ca.:7 x 2,2 x 2 m weight of the machine ca.:7,5 t

turning diameter:500 mm turning length:1000 mm control:MANUAL PLUS Grundig total power requirement:24 kVA weight of the machine ca.:2650 kg dimensions of the machine ca.:2500 x 1750 x 1850 mm swing diameter over face slide:290 mm chuck:Ø max. 260 mm cross movement:260 mm spindle head:DIN 55027 Größe 8 spindle bore diameter:70 mm rapid travel - longitudinal/face:8 /6 m/min spindle speeds::8 - 2800 tailstock travel:180 mm tailstock quill taper MT:5 Documents:vorhanden

turning diameter over bed:240 mm turning length:450 mm total power requirement:0,5 kW weight of the machine ca.:120 kg dimensions of the machine ca.:1500 x 600 x 1200 mm centre height:120 mm spindle bore:21 mm revolutions per minute: 75 - 2980 U/min

turning diameter:480 mm turning length:1250 mm control:H 645 weight of the machine ca.:8 t dimensions of the machine ca.:5 x 2 x 2 m centre distance:1580 mm swing over bed:495 mm swing diameter:üb.Querschlitten ca.350 mm working area:1600 mm control:H645 connected load:50 kW

control: Numeriksteuerung CNC 700 K total power requirement:28 KVA weight of the machine ca.:7,8 t dimensions of the machine ca.:6610 x 2280 x 2235 mm work height max.:1060 mm greates pass round over bed:305 mm spindle bore:82 mm Documents:vorhanden

turning length:630 mm total power requirement:16 kW weight of the machine ca.:5 t dimensions of the machine ca.:3400 x 1500 x 1600 mm swing diameter over slide rest:Hinterdrehschlitten 250 mm centre height:über Hinterdrehschlitten 150 mm center height over bed:300 mm turning spindle:Kopf DIN 55021 Gr. 8 centre distance:1000 mm accessories::2 Schränke Wechselräder

turning diameter:500 mm turning length:1000 mm control:MANUAL PLUS Grundig total power requirement:24 kVA weight of the machine ca.:2650 kg dimensions of the machine ca.:2500 x 1750 x 1850 mm swing diameter over face slide:290 mm chuck:Ø max. 260 mm cross movement:260 mm spindle head:DIN 55027 Größe 8 spindle bore diameter:70 mm rapid travel - longitudinal/face:8 /6 m/min spindle speeds::8 - 2800 tailstock travel:180 mm tailstock quill taper MT:5

turning length:2000 mm control:- total power requirement:25 kW weight of the machine ca.:3 t dimensions of the machine ca.:3800 x 1800 x 1850 mm swing over bed:500 mm swing diameter over face slide:280 mm control:Zyklen-Steuerung Heidenhain bed width:350 mm Documents:vorhanden

turning diameter:1600 mm turning length:3000 mm centre height:800 mm turning diameter over bed:1600 mm turning diameter over bed slide:1400 mm turning dia. over face-slide:1200 mm max. workpiece weight between centers:20 to speeds:5,6 -800 1/min transmission ratio:3 spindle bore:112 mm turret (x-stations):8 / VDI 60 travel -x axis:850 mm travel -z axis:3020 mm rapid power traverse in X-and Z direction:6 / 10 m/min power maindrive:46 kW weight of the machine ca.:22 to. dimensions of the machine ca.:7,2 x 4 (3,11) x 2,7 m tech-in lathe, flatbed, tailstock, 8-pos. BARUFFALDI turret with 4 live tools, power 9kW, 4-pos. BARUFFALDI square-headed turret horizontal, C-axis, 3-jaw hydr. chuck SMW Autoblock KNCS 800/165, dia. 800mm, quick adjustment, power cylinder with 2 pressure clamping system, chipconveyor, coolant device, accessories

turning diameter:230 mm turning length:810 mm centre distance:1.000 mm turning diameter over bed:460 mm spindle passage:56 mm chucking diameter:200 mm turret head:8 x VDI 30 Pos. turning speeds:3.100 1/min max. workpiece weight:570 kg spindle motor:18 kW dimensions of the machine ca.:3,7 x 1,9 x 1,8 m weight of the machine ca.:2,9 t teach-in lathe, PARAT tooling-system, hand operated collet chuck, 3 jaw chuck, 4 toolholders

bar material dia.:38 mm turning length:350 mm turning speeds:7.000 / 7.000 U/min number of tools:30 (3 x 10) driven tools:ja / yes control:FANUC 31i-B5 rapid traverse:30 m/min total power requirement:10,5 kVA weight of the machine ca.:6,5 t dimensions of the machine ca.:2,50 x 1,45 x 1,75 plus Lademagazin m work piece power:4 kW toolpiece turning speed range:5.700 1/min main spindle power:11 kW sub spindle power:7,5 kW CNC sliding headstock machine STAR ST 38, 3 turrets, 12 CNC Axis (X1/Z1/Y1/C1/X2/Z2/Y2/YA2/C2/X3/Z3/Y3, Fireextinguisher KRAFT und BAUER FB 703, partscatcher and conveyor belt (for long parts), LTA oilmist suction, chiller for oil, machining with oil as coolant, reading hours: approx. 14.500 hours "machine on", approx. 4.100 hours "machining"

bar material dia.:65 mm turning length:644 mm turning dia. over bed:600 mm turning diameter over slide:430 mm y-axis:100 (+-50) mm turning speeds:2x 5.000 1/min positive location each:2x C-Achse, 0,001° Grad Sub spindle:ja/yes turret (x-stations):2x 12 VDI 30 Pos. driven tools:2x 12 Pos. turning speeds:2x 4.000 1/min control:FANUC 18 iTB total power requirement:30 kVA weight of the machine ca.:8 t dimensions of the machine ca.:3,5 x 2,5 x 2,3 m turning- milling center with Y-axis, collet device on main and subspindle, high pressure pumps 2x 14bar, parts catcher/conveyor, barloader ENTL 10-65, chip conveyor, lot of accessories approx. 54.500 hours "machine on", 30.500 h "automatic", 14.000 h "feeding"
