vertical lathe dia used for sale

Echea A-II-6000 lathe. Distance between centers: 6.000mm. Swing: 820mm. Swing in carriage: 600mm. Swing in gap: 1.140mm. Bed widht: 510mm. Spindle: 82mm. Speeds: 12. (12-850rpm). Motor power: 25cv. Max. weight with 1 steady rest: 7.700Kg. Equipped with chuck and 2 steady rest. Weight: 9.600Kg.

Description SHOOTING FRORIEP 40Dv Carousel Lathe. Modernized in 1998, among other things, a driven tool system (C-axis) was installed and the control was modernized to 840 C. Details Serial number 11330051 Year of construction 1980 Control SIEMENS electrical connection 400 V Face plate diameter 3,500 mm Workpiece height 3,000 mm Face plate over corridor 160 mm Total power requirement 71 kW Space requirement approx. 13 x 6 m Reconstruction 1998

Lathe with 4 tools only for 3-cylinder crank shaft

weight of the machine ca.:18 t centre distance:700 mm max. swing diameter:200 mm Lathe with 4 tools only for 3-cylinder crank shaft

MAKE CHIRON MODEL MILL 800 5 axis 5 axis machininng center (milling/turning from bar) Under power in our warehouse in Gussago BS Italy Mimu Machine tools CNC Fanuc 18iMBS (5 simoultaneous axis 1) X, Y, Z (mm) 800 – 500 - 550 Rapids (Highspeed) 60 m/min Swivelling head CNC controlled (B axis) +/- 100° Turning spindle Peiseler Milling spindle 12.000 giri / 140 Nm (v nota 2) Tools 65 Tool type HSK-A 63 DIN 69893 Tool-change time 1,5 sec (v nota 3) Table 1400x500 Max table load 1200 kgs 90fjsieew Coolant through spindle 70 bar (see note 4) CNC controlled clamping/rotating unit for 6th face machining (v. nota 5) Pressurised linear encoders Swarf conveyor Renishaw-ready Y.O.M. 2006 Weight 7500 kgs Turning package Max dia 65mm RPM: 15 / 4500 Max 42,5 KW / 90 Nm. Hydraulic clamping 800 Nm. Bar loader ILS-RBK- 10012 65 Diameters min/max 5/65 mm L= 600-1200 mm Highspeed (2) 60m/min. Spindl ...

weight of the machine ca.:18 t centre distance:700 mm max. swing diameter:200 mm Lathe with 4 tools only for 3-cylinder crank shaft

number of spindles:6 spindle passage:18 mm turning length:63/50 mm weight of the machine ca.:4,5 t spindle drive motor:11 kW

number of spindles:6 spindle passage:18 mm turning length:63/50 mm weight of the machine ca.:8,6 t spindle drive motor:11 kW

Parallel Lathe SOCOMO type STAR 305 Between points: 700 mm Maxi Ø on bench: Ø 320 mm Maxi Ø over saddle: Ø 175 mm Spindle diameter: Ø 36 mm Rotation: from 70 to 2000 RPM 3-jaws chuck Ø 200 mm Threadings: Metric + Whitworth Tailstock: CM3 Auto feeds longitudinal + transversal Length: 1800 mm Depth: 800 mm Total height: 1200 mm Weight: approx 1 T

milling device for Skoda lathe SUT160

SCHAUBLIN 125 High precision lathe Diameter over the bed 270 mm Diameter over cross slide 120 mm Height of centers 125 mm Bed length 1000 mm Distance between centers 500 mm Spindle speed 45-3000 rpm Spindle nose Camlock D1-3 " Rapid traverse of the carriage 440 mm/min Longitudinal stroke 90 mm Cross travel 130 mm Vertical power feed 4-260 mm/min Metric threads 0.25-3.5 mm Spindle for collets B32 Tailstock cone MK 2 English pitches 112-6/1″ Special pitches 0.25-8 mm Top slide travel 100 mm Cross slide travel 180 mm Dimension 1500 x 850 x 1300 mm Weight approx. 950 kg

turning diameter:360 mm turning length:520 mm total power requirement:20 kW weight of the machine ca.:3,8 t dimensions of the machine ca.:3 x 2 x 2 m

WAHLI Multi 76 multi purpose lathe Mach. No. 227 Wahli Frères S.A. in Bévilard, Switzerland For turning and milling. Spindle head vertical adjustment. Center height 125 mm ( 70-230 mm) Distance between centers 550 mm Spindle speeds 50-3000 rpm. Travels Z/X - 350/100 mm Spindle diameter 16 mm Max. working diameter 100 mm Power: 2-speed 0.5/0.9 kW motor

Machining diameter max: 36 mm Maximum spindle speed: 6300 rpm No. of Spindles: 2 Controller: Traub TX8i Toolchanger 1: No. of tools: 12 positions X-axis travel: 50 mm Z-axis travel: 50 mm Toolchanger fronside: No. of tools: 7 positions Speeds: 150 - 3000 Rpm 300 - 6000 Rpm Max. diameter: 40 mm X-axis travel: 370 mm Z-axis travel: 250 mm Toolchanger backside: No. of tools: 5 Speeds: 150 - 3000 Rpm 300 - 6000 Rpm Max. diameter: 40 mm X-axis travel: 73 mm Barfeeder: FMB Turbo 5-42 Barlength: 3200 mm Bardiameter: 5 - 42 mm Country of origin: Germany Machine LxWxH: 3400 x 1300 x 1700 mm Machine weight: 4000 kg

turning diameter:360 mm turning length:520 mm total power requirement:20 kW weight of the machine ca.:3,8 t dimensions of the machine ca.:3 x 2 x 2 m

Inv. Num. : 6598 Type: SK 12 Producer: ZPS Created: 1964, GO 1994 Parameters: Table diameter: 1180 mm Clamping plate speed: 5.3-225 1/min Max. turning diameter: 1350 mm Max. workpiece height: 900 mm Max. workpiece weight: 5000 kg Length: 2360 mm Width: 3860 mm Height: 4260 mm Weight: 18300 kg

Lathe Manufacturer: Schaerer Model: UN 200 Center distance: 1600mm

Out of valve production

Gurutzpe Super BT lathe. Distance between centers: 8.000mm. Swing: 2.000mm. Swing in carriage: 1.680mm. Swing on gap: 2.360mm. Spindle bore: 102mm. Equipped with chuck and steady rest. DRO Fagor. CE protections and european certificate for second hand machines.

Disc lathe Lathe for plates, bowls, rings, wheels, etc. Manufacturer: Hempel Model: ERSP / ER/Sp 4 Workpiece diameter: max. 400 mm Workpiece thickness: max. 80 mm

Lathe Speeds: 40 - 2000 rpm Tension - lead screw Distance between centers 1 m Center height 230 mm Length 2.50 m Width 1.20 m Height 1.60 m Multifix B recording Accessories Machine unchecked

Clamping claw box made of solid steel GR 9 (new) 4 pieces

Göltebodt quick-change holder 21 x 300107 € 100,-- 3 x 300114 € 100,-- 1 x 300125 € 150,-- 1 x 300105 € 75,--

weight of the machine ca.:2,5 t spindle passage:65 mm

turning length:400 mm total power requirement:45 kW weight of the machine ca.:4 t dimensions of the machine ca.:3,58 x 1,91 x 2,05 m spindle passage:45 mm

WEIBERT WJ-1200 Lathe Distance between centers 1200mm Center height 215mm Spindle thread M33 Spindle speeds 500/1000/2000/2800 Motor output power 1.5KW Face plate Hand rest concurrent grain tip 400V and 230V G&WJ-1200 Net price 1639,-€ with VAT 1950,-€ Option: spindle speeds infinitely variable net 790,-€

SPINNER TTC 300- 52 SMMCY CNC Lathe YOM 2012 Twin-opposed-spindle, twin-turret lathe Control FANUC 31iT Swing diameter 400 mm Max. turning dia ~200-250 mm Max. turning length 400 mm Travels: X1 180 mm, X2 110 mm, Z 450 mm, Y +40/-40 mm Rapid traverse: X1 15 m/min, X2 15 m/min, Z 24 m/min, Y 15 m/min With C-axis Main Spindle 1: Motor spindle with water cooling With hollow shaft measuring system for C-axis drive mounted directly on the spindle shaft Spindle bore 52 mm Spindle speed 0-5000 rpm/ 19 kW Performance Pmax 23,5 kW Torque 150 Nm Spindle nose A6/DIN Sub-Spindle 2: Motor spindle with water cooling With hollow shaft measuring system for C-axis drive mounted directly on the spindle shaft Can be moved on a slide to take over spindle 1 Spindle speed 0-7000 rpm/ 8 kW Performance Pmax 13,8 kW Torque 189 Nm Spindle nose 100 mm Turret 1: At the top of the ...

turning diameter:500 mm turning length:1000 mm weight of the machine ca.:7,3 t dimensions of the machine ca.:6,5 x 4,45 x 2,21 m

turning diameter over bed:100 mm turning diameter over slide rest:70 mm turning length:80 mm total power requirement:1,0 kW weight of the machine ca.:0,5 t dimensions of the machine ca.:0,7 x 0,6 x 1,2 m facing lathe with manual feed, various accessories

turning diameter:500 mm turning diameter over bed:500 mm turning dia. over base-slide:290 mm centre distance:1000 mm centre height:250 mm z-travel:1350 mm speeds:10 - 3000 U/min

Parallel Lathe GEMA LZ 160 Between points: 1000 mm Maxi Ø on bench: 310 mm Maxi Ø over saddle: 180 mm Maxi diameter in brocken bed: Ø 420 mm x Length 200 mm Spindle diameterØ 44 mm Spindle speed: from 48 to 1500 RPM TRIPAN Turret Supplied with 2 tool holders 3-jaws chuck Ø 200 mm Threadings: Metric + Whitworth Tailstock: CM3 Auto feeds longitudinal + transversal Lubricant pump Voltage: 380 V Dimensions (L x W x H): 2100 x 800 x 1300 mm Weight: approx 1,3 T

turning diameter:650 mm turning length:1.500 mm chucking diameter:400 mm

turning diameter over bed:340 mm turning diameter over slide rest:190 mm turning length:700 mm spindle bore:50 mm shaving-spindle speed range:40 - 3.000 U/min dimensions of the machine ca.:2 x 1 x 1,6 m total power requirement:6 kW weight of the machine ca.:1,2 t

RAFAMET Wheel Turning Lathe XAD 112

Railway Wheel Lathe RAFAMET UBB112

Face plate diameter: 1.250mm Center height above foundation slab: 1,250mm Weight: 19t Power: 55Kw Max. torque on the face plate: 31,500Nm Maximum workpiece mass between centres: 16,000 kg Speed range: 2.24 – 224 rpm

turning length:800 mm total power requirement:380 V weight of the machine ca.:1400 kg dimensions of the machine ca.:2200 x 1200 x 1300 m centre height:160 mm chucking diameter:150 mm

turning diameter over slide rest:280 mm turning length:4000 mm total power requirement:7,8 kW weight of the machine ca.:6 t dimensions of the machine ca.:5,9 x 1,9 x 1,40 m

weight of the machine ca.:3 t

turning length:140 mm dimensions of the machine ca.:4 x 2 x 1,9 m

DBK 1300 Lathe Center height above machine bed: 220 mm Distance between centers: 1300 mm Center height over palm rest support: 160 mm Spindle speed: 0 to 3000 rpm Headstock, thread holder: M33 Tailstock Morse cone mount: MK2 Pinolenweg/tail spindle travel: 100 mm Motor power S1 (100%) / S6: 1.1kW/1.5kW Mains voltage: 230 V or 400 V Net weight: 160 kg G&HM-DBK1300

turning diameter over bed:340 mm turning diameter over slide rest:190 mm turning length:700 mm spindle bore:50 mm spindle turning speed range:40 - 3000 U/min total power requirement:6 kW weight of the machine ca.:1,0 t dimensions of the machine ca.:2 x 1 x 1,6 m

turning diameter over bed:930 mm turning diameter over slide rest:630 mm turning length:6000 mm turning dia. in gap:1250 mm spindle bore:95 mm turning speed range:8 - 800 U/min total power requirement:25 kW dimensions of the machine ca.:9 x 2 x 1,9 m faceplate 2 steadies coolant attachment taper turning attachment

turning diameter over bed:3800 mm turning diameter over slide rest:3200 mm turning length:12000 mm faceplate turning speed range -stepless-:2 - 200 U/min max. workpiece weight:90.000 kg bed width:4000 mm 2 steadies

Lathe TOS SUI 40-50 Center width 1500 mm Circulation over machine bed 500 mm Circulation over support 320 mm Spindle speed 14 to 2240 rpm Quick Release - Steel Bracket § Jaw wedge bar chuck Machine is ready for operation and in good condition

Article: Programme-controlled automatic lathe Manufacturer: Traub Type: TF60 / 140 Yob: 1978 Bar automat Please, contact us for getting more information and pictures on mail(at)tar-mc.com or www.tar-mc.com

Unchecked

Guide and tension spindle lathe machine - With photocopying device - 3-jaw chuck 200mm - 2 Mutifix quick-change steel holders - Moving center punch - Machine light - Chip tray Turning diameter over bed 410 mm Turning diameter over support 260 mm Turning length 1000 mm Turning diameter in the offset mm Speed 40 - 2000 rpm Center height 205 mm Spindle bore 50 mm Total power requirement 4.5 KW Machine weight approx. 1.6 t Dimensions approx. 2.4 x 1.3 x 1.5 m

Lathes with: - Digital display - Quick-release steel holder - 3-jaw chuck 200mm and 160mm - Chip tray - Centering tip Turning diameter over bed 460 mm Turning diameter over support 280 mm Turning length 1000 mm Center height 230 mm Circumferential diameter in offset 720 mm Spindle bore 53 mm Spindle speeds 28 - 1250 rpm Total power requirement 4.0 kW Machine weight approx. 1.8 t Dimensions approx. 2.4 x 1.4 x 1.75 mm

CNC LATHE Inv. No. 12.710C1 Make MONDIALE Model GALLIC 420 CNC Control FANUC 10TF Serial number CNCG16AC Centre distance 870 mm Max. swing over Bed Ø 420 mm Max. swing over Cross Slide Ø 214 mm Spindle bore Ø 69 mm R.P.M. 45 – 2500 (inf. var.) kW 11 Volts 400 Cycles 50 Including: 6 Pos. turret Coolant
