vdf lathe used for sale

turning diameter: 720 mm turning length: 4000 mm control: Siemens 805 turn - diameter over facing slide: 360 mm spindle diameter: 100 mm spindle passage: 100 mm 3-jaw-chuck diameter: 400 mm 4-jaw-chuck diameter: 250 mm steady: 360 mm total power requirement: 22 kW weight of the machine ca.: t dimensions of the machine ca.: m 3- jaw chuck diameter: 400 mm 4- jaw chuck diameter: 250 mm Fixed bezel diameter: 360 mmIncludes: 4 jaw turrets and coolant. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 2100 mm turning diameter over slide rest: 1300 mm turning length: 6800 mm workpiece weight: 25000 kg main drive motor: 140 kW Control: Siemens type: 840 C faceplate: 1100 mm bed width: 2500 mm steady: 800 mm steady: 800 mm steady: 800 mm steady: 600 mm chip conveyor: total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 1300 mm turning diameter over slide rest: 900 mm turning length: 8000 mm spindle diameter: 153 mm total power requirement: 37 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 300 mm turning length: 1500 mm control: FanucSystem 6 T total power requirement: kW weight of the machine ca.: 5 t dimensions of the machine ca.: 4x2x1,5 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 250 mm turning diameter over slide rest: 130 mm turning length: 700 mm turning speeds: 115 - 1620 U/min centre height: 125 mm spindle bore: 27 mm tailstock quill taper MT: 2 tailstock quill stroke: 40 mm metric threading: 0,2 - 3,5 mm thread - inch: 8 - 56 inch. thread - module: 0,2 - 12,5 mm swival range +/-: Oberschlitten 45 ° connected load frequency: 400 V total power requirement: 0,75 kW weight of the machine ca.: 0,15 t dimensions of the machine ca.: 1,41 x 0,61 x 0,41 m Equipped with - 2-axis digital measuring system with position indicator - manufactured according to DIN 8606 - 27 mm spindle passage - adjustable guideways by adjustable strips - Strong engine with 0.75 kW - High resolution of the axis spindles for exact positioning Delivery: 3-jaw chuck 100 mm, change gear set, splash guard 3-axis digital measuring system fully assembled. The data for ...

turning diameter over bed: 250 mm turning diameter over slide rest: 130 mm turning length: 700 mm turning speeds: 115 - 1620 U/min centre height: 125 mm spindle bore: 27 mm tailstock quill taper MT: 2 tailstock quill stroke: 40 mm metric threading: 0,2 - 3,5 mm thread - inch: 8 - 56 inch. thread - module: 0,2 - 12,5 mm swival range +/-: Oberschlitten 45 ° connected load frequency: 400 V total power requirement: 0,75 kW weight of the machine ca.: 0,15 t dimensions of the machine ca.: 1,41 x 0,61 x 0,41 m Equipped with - 2-axis digital measuring system with position indicator - manufactured according to DIN 8606 - 27 mm spindle passage - adjustable guideways by adjustable strips - Strong engine with 0.75 kW - High resolution of the axis spindles for exact positioning Delivery: 3-jaw chuck 100 mm, change gear set, splash guard 3-axis digital measuring system fully assembled. The data for ...

turning diameter over bed: 320 mm turning diameter over slide rest: 220 mm turning length: 600 mm turning diameter in the gap: 320 mm turning speeds: 60 - 1650 U/min centre height: 160 mm spindle bore: 38 mm tailstock quill taper MT: 3 MK connected load frequency: 400 V total power requirement: 1,1 kW weight of the machine ca.: 340 Kg dimensions of the machine ca.: 1,4 x 0,75 x 0,7 m Center lathe with: 3-jaw chuck 160 mm. 4-jaw chuck 200 mm. Faceplate 200mm Fixed bezel Continuous bezel 4-way steel holder. Halogen machine light Chip tray, chip protection wall Hardened and ground bed tracks Longitudinal and cross feed Complete coolant system Forage protection Set of change gears Machine tools The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 720 mm turning length: 2000 mm control: Siemens 805 greates pass round over bed: 720 mm bed width: 480 mm spindle diameter in front bearing: 150 mm spindle bore: 106 mm swing diameter over face slide: 430 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

centre distance: 8500 mm turning diameter over bed: 1070 mm turning diameter over slide rest: 800 mm spindle bore: 128 mm turning speeds: 1,12 - 1120 U/min Control: Alan Bradley 9-series total power requirement: 62 kW weight of the machine ca.: t dimensions of the machine ca.: m 3 Shear Bed, Carriage can bypass Steady Rest and Tailstock 6-position Sauter Turret 360 mm Capacity Self Centering Hydraulic Steady Rest 385 mm Capacity Rotaring Work Support (Used for Gun Barrels) 800 mm 4-Jaw Chuck Tailstock Quill diameter Ø 200 mm Tailstock Taper M.T. 6 Chip Conveyor The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 1800 mm turning height: 1600 mm turning diameter over bed: 2150 mm turning speeds: 3,15 - 250 U/min voltage: 400 V total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 1740 mm turning diameter over slide rest: 1300 mm turning length: 16000 mm turning speeds: 4-180 U/min Rapid travel: chip conveyor: digital readout: steady: total power requirement: kW weight of the machine ca.: t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 3100 mm swing diameter: 3600 mm turning height: 3600 mm control: Fagor 8035 table load: 35 t turning speeds: 0,32 - 40 U/min max. ram stroke: 3000 mm table load: 35 t turning speeds: 0,32-40 U/min total power requirement: 70 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 800 mm turning diameter over slide rest: 530 mm turning length: 8000 mm turning dia. in gap: 1080 mm spindle diameter: 95 mm speed: 8-800 (21x) U/min total power requirement: 15/22 kW weight of the machine ca.: t dimensions of the machine ca.: m 4-Jaw chuck 3-Jaw chuck 2x Steady Rest 4-Way toolpost The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 720 mm turning length: 2250 mm control: CNCN 300 turning diameter over bed slide: 480 mm 3-jaw-chuck diameter: 650 mm total power requirement: 44 kW weight of the machine ca.: t dimensions of the machine ca.: m Voltage 380VHertz 503-jaw chuck ø (mm) 650 Including: Turret, 9 positionChip conveyor The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 3050 mm turning diameter over slide rest: 2500 mm turning length: 21200 mm Control: Siemens type: 840D turning speeds: 0,236-60 U/min faceplate: 3000 mm main drive motor: 200 kW tailstock quill diameter: 900 mm roll stand: steady: 1200 mm steady: 1200 mm steady: 750 mm steady: 750 mm with live steady: 2000 mm faceplate: 2000 mm Thickness: 330 mm workpiece weight: 200 t total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 1200 mm swing diameter: 1400 mm turning height: 1250 mm stroke of ram - solid: 750 mm Side head: 650 mm turning speeds: 4-210 U/min total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 1000 mm swing diameter: 1400 mm turning height: 1400 mm control: SIEMENS 850M total power requirement: 125 kW weight of the machine ca.: 38 t dimensions of the machine ca.: m Stocknumber 1020042 Type of machine CNC VTL Make PIETRO CARNAGHI Type AC 10 CNC Build in 1987 Type of control Siemens 850 M/E Faceplate diameter 1000 mm Max. Swing diameter 1400 mm Turning height max. 1400 mm Total Power (KW) totaal 125 Lenght (mm) 11000 Width (mm) 8000 Height (mm) 6000 Weight 38000 kg Additional information with driven tools with pallet changer The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter over bed: 1800 mm turning diameter over slide rest: 1200 mm turning length: 16000 mm turning dia. in gap: 2300 mm spindle diameter: 150 mm speed: 1 - 300 U/min total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

faceplate diameter: 3.000 mm swing diameter: 7.000 mm turning height: 3.000 mm Control: FANUC 18i-TB total power requirement: 60/75 kW weight of the machine ca.: t dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
