BILLHöFERMFK 76 Laminating machine Billhöfer MFK 76 + asked 76 laminating machine
Ref.Nr: 2339 manufacturer Billhöfer model MFK 76 + asked 76 year built: 1986 Max sheet size: 760 x 1020 mm availability: immediately condition: go ...
used machine
Billhöfer MFK 76 + asked 76 laminating machine;
Ref.Nr: 2339 manufacturer Billhöfer model MFK 76 + asked 76 year built: 1986 Max sheet size: 760 x 1020 mm availability: immediately condition: good price: on technical request spezification: • laminating machine (water based) • feeding Mabeg feeder with suction belt • laminator Billhöfer MFK76 water based glue laminator;
• Seperator seperator Billhöfer BAT76 • a water based laminating machine which is capable to run thermal ;
STOCKA-14BE5678-1650x1640 Laminating machine Stock A-14BE5678-1650 x 1640, 2007
Ref.Nr: 2336 manufacturer stock model A-14BE5678-1650 x 1640 built year: 2007 Max sheet size: 1650 x 1640 mm availability: immediately condition: very good price: on technical request ...
used machine
Stock A-14BE5678-1650 x 1640, 2007;
Ref.Nr: 2336 manufacturer stock model A-14BE5678-1650 x 1640 built year: 2007 Max sheet size: 1650 x 1640 mm availability: immediately condition: very good price: on technical request spezification: • A-B-E-F-G wave;
• Minimum carrier sheet thickness: 0.6 mm (approx. 350 g7m sqm);
• Maximum carrier sheet thickness: 8 mm;
• Minimum print sheet thickness: 100 g m ²;
• Maximum print sheet thickness: 800 g m ²;
EK 76-50 film laminator
Mabeg feeder
Automatic pile suction feed back with separation
TM 76 automatic sheet separator
Water heater
Jogging table delivery
Working hours: 21.500
used machine
EK 76-50 film laminator;
Mabeg feeder;
Automatic pile suction feed back with separation;
TM 76 automatic sheet separator;
Water heater;
Jogging table delivery;
Working hours: 21.500;
SEALImage 62 P Laminating machine Name (German) name (English) name (Turkish)
Maximum working width: 1615 mm (63.6 in)
Maximum heated width: 1575 mm (62 in)
Maximum diameter material: 210 mm (8 14 inches)
Maximum lead temperature: 120 ° C ...
used machine
Name (German) name (English) name (Turkish);
Maximum working width: 1615 mm (63.6 in);
Maximum heated width: 1575 mm (62 in);
Maximum diameter material: 210 mm (8 14 inches);
Maximum lead temperature: 120 ° C (250 ° F) maximum opening of the rollers: 29 mm (1 18 inch) maximum substrate thickness: 25.4 mm (1 inch);
Community capacity (core Innendm.): 76.2 mm;
Steel high-release silicone coated V Max.: 1.8 m min (6 ft min)
ZOCCATELLI1450 Laminating machine Laminator - paper over board
Zoccatelli
Model 1450
Year 2001
Working width 1450 mm
Substrate Feeder suction belt bottom feeder
Laminate Feeder by hand
Details with pressing belt
Delivery delivery on a table
Foot ...
used machine
Laminator - paper over board;
Zoccatelli;
Model 1450;
Year 2001;
Working width 1450 mm;
Substrate Feeder suction belt bottom feeder;
Laminate Feeder by hand;
Details with pressing belt;
Delivery delivery on a table;
Footprint when "closed" 210 x 780 cm;
Condition sold fully refurbished;
Option by standard we sell this machine with traditional board alignment, optional we can built on a system with higher accuracy;
Available on request
SANTE MACBESante Macbe Laminating machine Solventless laminator mod. Sante Mecbi
High performance laminator, compact design, operator friendly and with quick job change-over.
One operator is required during job change-over, start-up and production.
The bo ...
Solventless laminator mod. Sante Mecbi;
High performance laminator, compact design, operator friendly and with quick job change-over.;
;
One operator is required during job change-over, start-up and production.;
;
The bonding unit is close to secondary unwinder and therefore suitable for Alu foil.;
;
Heavy duty and reliable construction with an Italian style guards all around to cover various utilities on board without unpairing the access for service.;
;
Mod. Sante is a solventless laminating machine suited to laminate the following material:;
;
- polyethylenepaper PSPE;
;
- OPP polyethylene PSOPP;
;
- paperalluminium AL 6,5 micronpaper Malboro;
;
- alluminiumpolyethylene metal OPPPE;
;
- OPP alluminium metal OPPOPP;
;
- PETAL;
;
- PETPE;
;
;
;
2.0. Main technical features;
;
Coating width 1200 mm;
;
Max webs width 1220 mm;
;
Mechanical speed 300 mmin;
;
Production speed up to 300 mmin (according to material);
;
Max OD reel at unwind 800 mm;
;
ICD at rewind 76 mm ;
;
Max OD reel at rewind 800 mm;
;
ICD at unwind 76 mm;
;
Painted light grey RAL 9018;
;
Designed and built according EC regulations actually in force;
;
Working pressure – 6 bars;
;
Motors – 37 KW;
;
Two pieces Corema – 26 KW;
;
Motor ventilation – 2,2 KW;
;
Total installed power – 66 KW;
;
Power supply voltage – 380400 V; 50 Hz;
;
Power cabinet – height=2100 mm; length= 1200 mm; width= 600 mm.;
;
Machine dimensions – height= 3000 mm (with ventilation aspiration 3500 mm); length= 5195 mm; width= 2450 mm;
;
;
;
;
;
;
;
Built in two main frame units:;
;
- Parent unwinder and coater;
;
- Bonding unit with secondary unwinder and rewinder (an overhead structure provides the necessary connection).;
;
;
;
The frames of the main units are steel made, thickness 60 mm. The heavy duty design prevents from any vibration, even at full production capacity.;
;
The adhesive is supplied through a trailing system (pneumatic operated) to assure a better uniformity.;
;
A capacity sensor detects the adhesive level to restore on automatic mode the proper level.;
;
A stainless steel tray (AISI 304) under premetering rollers is used to collect the unused amount of adhesive at the job end and to collect the solvent used for cleaning purpose only.;
;
2.1. Transfer roller coated with special rubber suitable to resist up to 80°C (could be necessary for certain adhesive) and to solvent for cleaning. Driven by a mechanical transmission at a different speed ration.;
;
Quick changeover of the transfer roller with hoist.;
;
Loaded by two large diameter air pistons.;
;
2.2. Coating roller double wall, with spiral water flow inside. Chrome plated roller face, grinded and polished with OD 190 mm. Driven by dc motor, master of the line.;
;
2.3. Back-up roller, rubber coated, air loaded with two pistons at the preset pressure. OD equal to 150 mm.;
;
3.0.Secondary unwinder;
;
3.1. Description as per parent.;
;
4.0.Bonding;
;
4.1.Bonding roller, heavy duty, chrome plated grinded and minor like finished with OD 224 mm.;
;
4.2.Driven by own dc motor with automatic web tension control via load cell.;
;
4.3.Rotary joint for water flow.;
;
4.4. Back up roller, rubber coated, air loaded with two pistons at present pressure. OD equal to 150 mm.;
;
5.0. Rewinder;
;
5.1.Center winding mode with constant web tension via pneumatic loaded dancer.;
;
5.2.Lay-on roller air loaded.;
;
5.3.The dc motor is located within frames.;
;
6.0. Overhead structure;
;
6.1.Web path rollers.;
;
6.2.Solid steel frames with rails for electric synchronized hoists of loadunload reels at unwindersrewinders and for quick changeover of the transfer roller with load capacity of 250 + 250 daN (optional 500 + 500 daN).;
;
6.3.Fan to collect eventual fumes coming out from coater or bonding nip assembled on antivibration pads.;
;
7.0. Utilities ad additional;
;
7.1.Main electric cabinet vertical with interlocked main switch, internal lighting, ventilation.;
;
7.2.Cable connection from electric cabinet to machine from top.;
;
7.3.Air compressed FRV filter at infeed 7 bar.;
;
7.4.Cupboard with service keys, kit of spares.;
;
8.0. Thermocontrol unit;
;
8.1.Two thermocontrol units with electropump, pressure gauges, thermometer, probes, including pipings on board.
year 2006
1300mm
Technical Specifications:
Type Of Laminator:Solvent and Solventless
Working Width: 1315
Unwinder Diameter: 1000
Rewinder Diameter: 1000
Drying System:Gas
Mechanical Speed: 400
In ...
used machine
year 2006;
;
1300mm;
;
Technical Specifications:;
Type Of Laminator:Solvent and Solventless;
;
Working Width: 1315;
;
Unwinder Diameter: 1000;
;
Rewinder Diameter: 1000;
;
Drying System:Gas;
;
Mechanical Speed: 400;
;
In production!
FOLIANTCastor 530 SF Laminating machine max. size 53 x 74 cm
age 2010
material 100 - 600 gm2
speed up to 50 m min (neutral running)
stream feeder with suction head
delivery with pallet stacker
In 2011 upgrade from Castor 520 to 530 SF
Delivery time: ...
used machine
max. size 53 x 74 cm;
age 2010;
material 100 - 600 gm2;
speed up to 50 m min (neutral running);
stream feeder with suction head;
delivery with pallet stacker;
In 2011 upgrade from Castor 520 to 530 SF;
Delivery time: immediately;
;
Please ask for price.;
;
We ship and install worldwide!
KARMAVAB laminating machine VAB FEED-automatic laminating machine
made in Switzerland
year 1981
size: 140 x 120 cm
size: 50 x 60 cm
speed up to 2,500 sheetsh
till 8 mm thickness
machines length 11.20 m
in production
used machine
VAB FEED-automatic laminating machine;
made in Switzerland;
year 1981;
size: 140 x 120 cm;
size: 50 x 60 cm;
speed up to 2,500 sheetsh;
till 8 mm thickness;
machines length 11.20 m;
in production;
