ACTIW OY, FINLANDACTIW 4200 pallets Automated Pallet Warehouse 4200 pallets Fully Automatic Pallet Warehouse
This is a multilevel fully automated warehouse for various goods which can be placed on standard storage pallets. Total hold in capacity of this Actiw System is 4200 pallets and it has ...
used machine
Fully Automatic Pallet Warehouse
This is a multilevel fully automated warehouse for various goods which can be placed on standard storage pallets. Total hold in capacity of this Actiw System is 4200 pallets and it has loading and unloading capacity of 240 pallets / hour. Actiw Systems is the total warehouse management system which has hardware and software for moving storage pallets to and from storage, storing, sorting, staging, picking and loading (and unloading) palletized products fully automatically. Actiw System can be integrated as a part company's logistic system and it has Siemens Simatic S7 PLCs with Ethernet connections.
The warehouse structure is made of bolted, coated / galvanized carbon steel and product is stored in four layers. In addition to four storage layers, this warehouse has two floors under these storage floors for VTC and truck loading purposes. This Actiw System consist of roller conveyor system for in-feed and discharge palletize products and 4 Vertical Transfer Conveyors (VTC pallet elevators) of which 3 can both load and unload and 1 for unloading only. To move pallets inside of storing layer, there are two type of transfer units, Cross Aisle Transfer lanes with cross sectional moving CAT Carts and Deep Lane Transfer lane with DLT Carts. CAT units are taking pallets from VTC and handing them over to DLT Carts when loading the store and reverse when unloading the store. DLT carts are designed so that they can leave and take a pallet from this lane and thus the product is store on these DLT lanes. All carts are electric gear motor driven with wire systems.
Warehouse is still in the operation and for seriously interested we have pdf-files with schematics and more detailed technical & function descriptions as well as we can organize site visits. The system has complete documentation in English and Russian and full after sales services from Finnish manufacturer. Location is Saint Petersburg, Russia.
Technical Data:
Manufacturer Naaraharju Oy / Actiw Oy Finland
Made in year 2004
Storage capacity 4200 pallets
Loading and unloading capacity 240 pallets / hour
Storage Lanes (DLT Lanes) 17 psc/level
DLT Carts 72 pcs
Cross aisles 16 pcs
CAT Carts 16 pcs
VTL Lifts 4 pcs
Warehouse length 76 m
Warehouse width 27 m
Warehouse total height 14 m
Pallet dimensions: 1250 x 850 x 1800 mm (EUR Pallet)
1200 x 850 x 1800 mm
Max pallet weight 900 kg
KARDEXXP500 KARDEX SHUTTLE Is for sale: KARDEX SHUTTLE XP500, year of build: 2004.
Bb8cokebqs
Unit dimensions: Hxwxd: 5250 x 3400 x 2700 mm. facilities: 30 shelves. Dimensions: Wxd: 3050 x 864 mm. load capacity: 260 kgprro shelf. The machine is ...
used machine
Is for sale: KARDEX SHUTTLE XP500, year of build: 2004.
Bb8cokebqs
Unit dimensions: Hxwxd: 5250 x 3400 x 2700 mm. facilities: 30 shelves. Dimensions: Wxd: 3050 x 864 mm. load capacity: 260 kgprro shelf. The machine is in good condition and is available from 16.07.2018.
KASTOUNICOMPACT 1.5 Long goods storage system (honeycomb storage) 2228 Long goods storage system (honeycomb storage, hiking cassette principle), KASTO, UNICOMPACT 1.5, for up to 6, 60 m long, 2.228 cassettes, 1.5 to / cassette - used -: Manufacturer: Kasto Type: UNICOMPACT 1.5 Year of ...
used machine
Long goods storage system (honeycomb storage, hiking cassette principle), KASTO, UNICOMPACT 1.5, for up to 6, 60 m long, 2.228 cassettes, 1.5 to / cassette - used -:
Manufacturer: Kasto Type: UNICOMPACT 1.5 Year of construction: 2006 Technical data for: Cassette: Type 1 Usable dimensions: width: 650 mm, Bela de height: 400 mm External dimensions: Length: 6.800 mm, width: 720 mm, height: 450 mm Load capacity per cartridge: 1.5 t Number of campsites: 2.228 piece Speed Stacker crane: Longitudinal drive 2.0-120 m / min. Hoist 2.0-60 m / min. cassette drawbar: 2.0 80 m / min. Performance of stacker crane: based on station 2 and 3:48 double cycles per hour System dimensions: Height (without housing): 18.495 mm Height (with enclosure): 21.000 mm Length (without pallet storage enclosure): 36.190 mm Length (with pallet storage enclosure): 40,000 mm Width (without stops): 21,400 mm POS. 1.0 rack serving unit 1 piece Version with two tape creation to the realization of the principle of KASTO hiking cassette. Chassis and mast in welded design Lifting beam Cassette two-seat for the realization of the principle of KASTO hiking cassettes. POS. 3.0 long gut cassette 2.228 piece Long cargo box, not self-supporting, without corrosion protection (lightly oiled). Slide out cold profiled special profiles, end edges framing when driving in d
BMAlift Load lift part lift elevator Kleinteileheber-by means of the bended wearing roller guide is structured inside-load capacity: 200 kg only for goods no passenger transport car for europallets Stahlkostruktion hot-dip galvanized - CE documentation in G ...
Kleinteileheber-by means of the bended wearing roller guide is structured inside-load capacity: 200 kg only for goods no passenger transport car for europallets Stahlkostruktion hot-dip galvanized - CE documentation in German, such as operating instructions.-lifting 3350 mm; exactly adapted to your needs - ready hold positions selectable - last stage with get Zein enclosure such as the Türe-of Deadman control in the terminal box (lift moves only in the pressed state) - assembled CEE 16 amp door locking device on the upper floor -. Get Zein enclosure can away as also the door to load can be increased to 500 kg
FEHR Long goods warehouse system, up to 6, 60 m, 1906 K Long goods storage system (honeycomb storage, hiking cassette principle), Fehr, for up to 6, 60 m long goods, ca. 1.906 cassettes - used -: Price from site: EUR39.500.-(net), for the destruction of the self! Manu ...
used machine
Long goods storage system (honeycomb storage, hiking cassette principle), Fehr, for up to 6, 60 m long goods, ca. 1.906 cassettes - used -:
Price from site: EUR39.500.-(net), for the destruction of the self!
Manufacturer: Fehr Year of construction: 1989 (actually was never really in operation) Cassettes: High option: 472 units Low version: 1434 Kassettenmasse unfortunately not yet available (must be between 6 and 7m) Load RGB: 5 to. Load-bearing capacity of the cartridges: unfortunately still does not exist, should be 1.5 to but in mind. Available from: Expansion should take place around March/April 2017, while, the facade and the roof of the Hall should remain; a steel maker previously strengthened the support for the roof and the façade so that the bearing can be removed. The Hall is accessible by truck on the side of the ramp, ramp area is empty granted for handling the dismantling to dismantle Condition: used Location: Switzerland
DEXION Heavy duty - running-in shelf, 1000 kg, Heavy duty - drive-in rack system for Euro-pallets, 1 000 kg, approx. 230 pitches - used -: price from site: EUR5.950.-(net), dismantled! Manufacturer: Dexion Type: P-90 Deepstor Year of construction: 2011 Frame: P ...
used machine
Heavy duty - drive-in rack system for Euro-pallets, 1 000 kg, approx. 230 pitches - used -: price from site: EUR5.950.-(net), dismantled!
Manufacturer: Dexion Type: P-90 Deepstor Year of construction: 2011 Frame: P90-H Field width: 1,370 mm Frame height: approx. 4, 50 m Conditioning consists of about 7 channels Pallet weight: 1,000 kg Load per layer: 9,000 kg Max. Field capacity: 18,000 kg Pallet width: 1200 mm OK 1st Edition: 2,205 mm OK 2nd Edition: 4.005mm Edition pairs per box: 2 Condition: good - very good Available: available now Location: NRW space Bochum Euro pallets in Exchange!
Drive-in racking, 800 kg, 1080 pallets Used drive-in rack system for Euro-pallets, 800 kg, approx. 1.080 pitches -- -: Price per pitch from location: 22.-EUR (net), dismantled and loaded! Manufacturer: should probably be - clarified Dexion Year of co ...
Used drive-in rack system for Euro-pallets, 800 kg, approx. 1.080 pitches -- -:
Price per pitch from location: 22.-EUR (net), dismantled and loaded!
Manufacturer: should probably be - clarified Dexion Year of constr.: must be - submitted but not really old for Euro pallets 1,20 x 0, 80 m Maximum weight per pallet: 800kg Frame height: 7, 56 m Block 1 capacity: 504 pallet places External dimensions (width): 21.340mm
P108 - used approx. 40 m³ / 40,000 litres polyester tank / GRP tank, double-skinned, flat bottom tank, Speidel tank, including as new ullage device(approx. one year).
Manufacturer Speidel, aboveground storage tank, vertically standing on flat bottom, in good condition.
volume: approx. 40 m / 40,000 litres
material: polyester / GRP
diameter: approx. 3.00 m
height: approx. 6.50 m
year of construction: 2001
Double-skinned, for media with a specific weight of up to 1.4 kg / litre. The container can be used as a storage tank for many different media.
Price upon request.
Transport can be arranged at low cost. Also we can modify the tank to suit your demands, just ask us.
More information and offers on our site:
profi-tanks(dot)de
138-266/18 KLSo Paternoster no. of working stations:13 Stückpositions: allowable maximum weight:4500 kgtotal power requirement: kWweight of the machine ca.:3000 kgdimensions of the machine ca.:3360 x 1800 x 3100 mmAbmessungen Fachböden | Shelve D ...
used machine
no. of working stations:13 Stück positions: allowable maximum weight:4500 kg total power requirement: kW weight of the machine ca.:3000 kg dimensions of the machine ca.:3360 x 1800 x 3100 mm
Abmessungen Fachböden | Shelve Dimensions Breite | Width: 2600mm Tiefe | Dept: 380 mm Höhe | Height: 110 mm
P109 - used approx. 50 m³ / 50,000 litres polyester silo / GRP-silo, vertically standing, with funnel and support frame 3 x 3 m, in good condition. Twice in stock.
volume: approx. 50 m³ / 50,000 litres
material: polyester / GRP
diameter: approx. Ø 3.00 m
height silo: approx. 8.50 m
height with support frame: approx. 12.00 m
The container can be used as storage silo for water, liquid feed, flour, whey, potato steam skins, salt brine, dried fodder, molasses, etc.
Price upon request.
Transport can be arranged at low cost. Also we can modify the tank to suit your demands, just ask us.
More information and offers on our site:
profi-tanks(dot)de
