universal machine milling used for sale

X-axis: 1000/1245mm, Y-axis: 630mm, Z-axis: 550mm, angle table: 1200x630mm, quill stroke: 75mm, tool holder: SK40, drive power: 7.5kW, spindle speed (continuously variable): 20-7,000/min, feeds: 1-20,000mm/min, rapid traverse: 20,000mm/min, connected load: 14kW, rated current: 24A, control: HEIDENHAIN TNC 426 with hand-held control unit, total connected load: 17kVA, weight: 6t, operating hours, machine on: 122,355h, control on: 18,579h, program run: 36,747h, with Knoll 400 K-1 scraper belt conveyor. Equipment: manually swivelling vertical milling head, protective enclosure with viewing window, coolant system, chip conveyor, HEIDENHAIN 3D touch probe TS 642. An on-site inspection is possible.

X-axis: 500mm, y-axis: 430mm, z-axis: 400mm, table dimensions: 510x450x410mm, max. table load: 250kg, angular clamping table: 800x390mm, feed rate x-/y-axis: 4-1600mm/min, z-axis: 4-1000mm/min, feed force: 5000N on all axes, rapid traverse x-/y-axis: 1.6m/min, z-axis: 1m/min, tool holder (DIN 2079): ISO 40, cutter drawbar thread: M16, hydromechanical tool clamping: 12,000Nm, quill stroke: 80mm, drive power: 3kW, 18-speed sliding-gear transmission: manually or automatically selectable, torque: 5Nm, spindle speed: 50-2500rpm, connected load: 6kW, control: Heidenhain TNC 114B (hand control type HS262), display resolution: 0.005mm, length: 1400mm, width: 1300mm, height: 1830mm, weight: 1.6t, space requirement: 2300x2300x2400mm, equipment: machine light, coolant tank: 18l, external coolant supply: 3bar, various tool holders, spindle tool. On-site inspection is possible.

INTOS ?ebrák FN 20 Fräsmaschine Universal + Zubehör Hersteller: INTOS ?ebrák Typ: FN 20 Zustand: gebraucht Baujahr: 2003 Gewicht der Maschine: 910 kg Abmessung: ? Länge mm: 1690 ? Breite mm: 1270 ? Höhe mm: 1175 Aufspannfläche des Senkrechttisches: 216 x 680 Aufspannfläche des Winkeltisches: 240 x 600 Die breite und Abstand der T-Nuten mm: 12H8 x 45 0,1 Spindeldurchmesser im Vorderlager mm: 45 Spindelkegel: ISO 40 Spindeldrehzahlen: 18 Bereich U/min: 50 ? 2000 Vorschübe : 18 Bereich mm: 8 ? 400 Eilvorschub mm/min: 1340 Bewegung des Spindelstockes: ? von Hand: 200 ? selbstständig: 190 Durch Verstellung des Halters erzielte Auslegung mm: 42 Tischlängsbewegung: ? von Hand mm: 300 ? selbstständig mm: 290 Senkrechtbewegung des Tisches: ? von Hand mm: 350 ? selbstständig mm: 340 Lieferumfang: ? INTOS ?ebrák FN 20 Fräsmaschine Universal ? Zubehör  ...

DECKEL FP1 Aktiv Fräsmaschine Hersteller: Deckel Typ: FP1 Aktiv Zustand: sehr gut Steuerungsart konventionell Steuerung Aktiv HEIDENHAIN TNC X-Weg 300 mm Y-Weg 160 mm Z-Weg 340 mm Werkzeugaufnahme SK40 Drehzahl 40-2000 U/min. Steuerung Aktiv HEIDENHAIN TNC Gesamtleistungsbedarf 2 kW Maschinengewicht ca. 0,73 t Raumbedarf ca TBH 1200x1100x1600 mm

Universalfräsmaschine Deckel FP4M Aktiv Hersteller: Deckel Typ: FP4M Zustand: gebraucht, gut Digitalanzeige: 3 ? Achsen- Digitalanzeige Heidenhain Verfahrwege: X ? Achse: ca. 500 mm Y ? Achse: ca. 400 mm Z ? Achse: ca. 400 mm Tischaufspannfläche: ca. 700 x 400 mm Drehzahlbereich: ca. 50 ? 2500 U/min Werkzeugaufnahme: ISO 40 Werkzeugklemmung hydraulisch Antriebsleistung: ca. 6,0 kW Vorschübe & Eilgänge: in allen 3 Achsen Vorschubbereich: ca. 8 ? 630 mm/min Eilgänge: ca. 3,0 m/min L x B x H: ca. 2300 x 1800 x 1800 mm Gewicht: ca. 1750 kg Maschinenleuchte Spindelschutz Lieferumfang: ? 10x Werkzeugaufnahmen ? Hochdruckschraubstock Allmatic ? Dokumentation ? Spindelschutz

Kunzmann WF 600 M Fräsmaschine (2012) Hersteller: Kunzmann Typ: WF 600 M Baujahr: 2012 Zustand: gebraucht, sehr gut Steuerung: Heidenhain TNC 124 X ? Achse 600 mm Y ? Achse 400 mm Z ? Achse 400 mm Tischlänge 650 mm Tischbreite 350 mm Spindeldrehzahl 4500 U/min Vertikalpinole und Horizontalpinole ? SK40 Hydraulisches Anzugssystem Hauptantriebsmotor: 5,5 kW Abmessungen ca.: 2 x 2 x 2 m Gewicht ca 2000 Kg Kühlmittelanlage Lieferumfang: ? Dokumentation ? Maschinenleuchte ? Maschinenfüße ? Maschinenschraubstock

X-axis: 500mm, Y-axis: 450mm, Z-axis: 400mm, swivel rotary table dimensions: 630x500mm, max. table load: 200kg, swivel range: -5 to 110°, continuously variable speed: 20-10,000/min, drive power (100%/40% duty cycle): 9kW/13kW, torque (40% duty cycle): 82Nm, input resolution: 0.01mm, positioning tolerance: 0.010mm, rapid traverse: 24m/min, feed speed: 20m/min, number of SK40 tool positions (DIN 69871): 30, tool diameter (speed-dependent): D80-D130, max. tool length: 290mm, max. tool weight: 6kg, connected load: 17kW, control: Siemens 840D Powerline ShopMill, length: 4860mm, width: 4350mm, height: 2424mm, transport dimensions: 2210x2120x2150mm, weight: 4.05t, operating hours power-on time: 35,880h, spindle hours: 9609h. Equipment: digital drive and hydraulic clamping (positioning operation only), electronic angle display and plane transformation, chain magazine with double gripper, additi ...

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)SK40 interfaceTool clamping SK 40 for pull-studs DIN 69872

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)4th Axis package4th Axis package Option includes: - rotary table type EA-510.L NE with indirect measuring system - electrical and pneumatic preparation - software preparation to work with rotary table - cycle TRACYL which allows to define contour on the cylinder - swSK40 interfaceTool clamping SK 40 for pull-studs DIN 69872

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsTorque (100% DC)57 NmMax. torque83 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)4th Axis package4th Axis package Option includes: - rotary table type EA-510.L NE with indirect measuring system - electrical and pneumatic preparation - software preparation to work with rotary table - cycle TRACYL which allows to define contour on the cylinder - swSK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Electronic HandwheelExternal electronic Handwhe ...

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)SK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Air coolant external and internalAir coolant external and internal (through spindle centre) switchable via M-FunctionElectronic HandwheelExternal electronic Handwheel

Huvema X: 790 - Y: 420 - Z: 420 mm Max longitudinal travel X-axe: 790 mm Max cross-travel Y-axe: 420 mm Max travel Z-axe: 420 mm Max height workpiece: 440 mm Power on spindle: 3 HP Max quill travel Z´: 127 mm Admission in boring head (ISO): ISO 40 Spindlespeeds: 50 > 3750 rpm Table size: 1300 x 260 mm Digital screen: yes Weight: 1760 kg

x-travel: 300 mm y-travel: 200 mm z-travel: 350 mm tool taper: SK40 spindle turning speed range: 110 - 1230 U/min table-size: 270 x 700 mm total power requirement: 3,7 kW weight of the machine ca.: 900 kg dimensions of the machine ca.: 1400 x 1400 x 1700 mm Features: - 3-axis digital display - Milling head swivels ± 45 degrees - Coolant system - User manual The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

For sale is a REFORM UWF 32 D universal milling machine, built in 1996, in a robust industrial version. The machine is equipped with a HEIDENHAIN 3-axis digital display and has a generous milling table of approx. 800 × 400 mm. Thanks to its solid conventional design, it is ideally suited for tool and machine construction, maintenance, repair work, as well as the production of individual parts and small series. The machine is in a good used, age-appropriate condition. Signs of use and paint wear are present and can be seen in the pictures. Technical data Manufacturer REFORM Model / Type UWF 32 D Machine type: Universal milling machine Year of manufacture 1996 Serial No. 11.031 Power 1.87 kW Table size approx. 800 × 400 mm Digital display HEIDENHAIN Display 3 axes Operation conventional / manual Milling head vertical version Router Table T-slot Table Machine vi ...

Maho MH 1000 S X: 1000 - Y: 560 - Z: 800 mm CNC Max longitudinal travel X-axe: 1000 mm Max cross-travel Y-axe: 560 mm Max travel Z-axe: 800 mm Power on spindle: 15 kW Admission in boring head (ISO): ISO 50 Spindlespeeds: 2000 rpm Table size: 1250 x 800 mm Control: Philips 432 Length: 4600 mm Depth : 2500 mm Height: 2300 mm Weight: 7,5 ton Toolholder: yes

x-travel: 700 mm y-travel: 400 mm z-travel: 350 mm table-size: 920 x 300 mm control: konventionell tool adaptor: SK40 turning speed range: 40 - 2000 U/min quill stroke: 50 mm total power requirement: 2,4 kW weight of the machine ca.: 1,1 t dimensions: 1,4 x 1,6 x 2,1 m Equipment: - Heidenhain digital readout - Coolant system The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Deckel-Maho DMU50 X: 500 - Y: 400 - Z: 400 mm CNC Max longitudinal travel X-axe: 500 mm Max cross-travel Y-axe: 400 mm Max travel Z-axe: 400 mm Power on spindle: 13 kW Admission in boring head (ISO): BT 40 Spindlespeeds: 20 > 9000 rpm Table size: 700 x 500 mm Control: Heidenhain TNC 426 Length: 2700 mm Depth : 2700 mm Height: 2500 mm Weight: 3,5 ton Toolholder: yes Number of tools: 16 positions

Used machine DMF200/8 Machine type: Universal milling center Model No.:DMF200/8 Manufacturer: DMGMORI Control: CELOS with Siemens 840D sl Operate Year of manufacture: 2023 Location:Germany Equipment: - Travelling column milling machine DMF 200/8 - NC swivel milling head (B-axis) - Motor spindle speedMASTER® - Tool holder SK40 DIN - Spindle speed 20 - 15,000 rpm 21 kW/16 kW - Chain magazine for 40 tools, - Chip conveyor (scraper belt) - Fixed table with integrated rotary table - Internal coolant supply 40 bar/600ll with paper belt filter - Oil and emulsion mist separators - Blowing air through the spindle center - Infrared probe PP60 optical - 3D quickSET - Laser tool measurement Blum LC50 Technical data Travel range X-axis approx. 2000 mm Y-axis approx. 800 mm Z-axis approx. 850 mm B-axis (head) +-120° ° Rotary table in table 800 mm Table size appro ...

Key data: 800 mm, 300 mm, 630 mm

Universal Milling Machine GAMBIN 11 M Travel X: 800 mm Travel Y: 300 mm Travel Z: 630 mm Cone: SA 30 Spindle speed: from 25 to 1800 RPM Table size: 1300 x 300 mm Horizontally + vertically tilting head Spindle motor: 4,8 KW Auto Feeds X - Y - Z Spindle body exit: 240 mm Lubrification Voltage: 380 V Width: 2000 mm Depth: 2100 mm Total height: 1800 mm Weight: approx 2,2 T

Key data: 1000 mm, 300 mm, 600 mm

Universal Milling Machine VERNIER type FV Travel X: 1000 mm Travel Y: 300 mm Travel Z: 600 mm Cone SA 40 Spindle speed: from 32 to 1500 RPM Table size: Length 1500 x Width 320 mm Horizontally + vertically tilting head Scale 3 axes ACURITE Feeds auto X - Y - Z Length: 2200 mm Depth: 2100 mm Total height: 1900 mm Weight: approx 2,5 T

Key data: 800 mm, 300 mm, 500 mm

Milling Machine VERNIER FV 250 E Travel X: 800 mm Travel Y: 300 mm Travel Z: 500 mm Cone: SA 40 Spindle speed: from 45 to 2000 RPM Table size: 1060 x 250 mm Horizontally + vertically tilting head Auto Feeds X - Y - Z Lubricant pump Voltage: 380 V Width: 1600 mm Depth: 2000 mm Total height: 1700 mm Weight: approx 2 T

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)SK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Electronic HandwheelExternal electronic Handwheel

CharacteristicsMaximum load (table centre)1200 KgDimensions (L x W x H)3,02 x 2,98 x 2,61 mRapid feed X / Y / Z30/30/30 m/minMovement X / Y / Z1050/530/510 mmSpindle taperBT 40 Tool Magazine with30 PositionsDrive power (25% DC)37 kWDrive power (100% DC)22 kWTable surface1350 x 600 mmSpeed max.12000 rpmWeight approx.7000 KgGeneralVertical Machining Center; Control: Control M730UM with CELOS CELOS - ERGOline TouchCELOS - ERGOline Touch to facilitate machine operation incl. 21.5 ERGOline Touch ® control with multi touch screens Uniform management, documentation and visualization of order, process - and machine data Networkable with CAD / CAM User friendly and pHigh-torque spindle 12,000min-1, 37/ 22 kW (#40)High-torque Spindle 12,000 min-1, 37/22 kW (#40) Motor spindle powerMASTER® Spindle speed: 12,000 min-1 Output: 37/22 kW (50/30 HP) (10%ED/cont) Torque: 360/177 Nm (265.52/130.55 ft·l ...

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsTorque (100% DC)43 NmMax. torque64 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.10000 rpmWeight approx.5600 KgSK40 interfaceTool clamping SK 40 for pull-studs DIN 69872

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)4th Axis package4th Axis package Option includes: - rotary table type EA-510.L NE with indirect measuring system - electrical and pneumatic preparation - software preparation to work with rotary table - cycle TRACYL which allows to define contour on the cylinder - swSK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Air coolant external and internalAir coolant ex ...

CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgGeneralVertical Machining Center; Control: Control SIEMENS 828D Mechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)SK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Air coolant external and internalAir coolant external and internal (through spindle centre) switchable via M-FunctionElectronic HandwheelExternal electronic Handwheel

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)SK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Electronic HandwheelExternal electronic Handwheel

x-travel: 560 mm y-travel: 300 mm z-travel: 420 mm digital readout: 3 Achsen HEIDENHAIN table-size: 1100 x 250 mm spindle turning speed range: 40 - 1180 U/min spindle taper ISO: 40 feeds: 18 - 384 mm/min milling motor: 3,7 kW coolant: voltage: 400 V total power requirement: 5,5 kW weight of the machine ca.: 1,1 t dimensions of the machine ca.: 1,45 x 1,70 x 1,90 m - Serial-No.: 6760 - 3-axis digital readout HEIDENHAIN - rapid traverse - central lubrication - coolant device - machine light The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

CharacteristicsTable surface850 x 650 mmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.5600 KgGeneralVertical Machining Center; Control: Control SIEMENS 828D Mechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)SK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Electronic HandwheelExternal electronic Handwheel

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsTable surface850 x 650 mmSpeed max.12000 rpmDrive power (100% DC)9 kWDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)Tool Clamping BT 40Tool Clamping BT 40 for pull-studs DIN 69872 (differently from standard)Electronic HandwheelExternal electronic Handwheel

GeneralVertical Machining Center; Control: Control SIEMENS 828D CharacteristicsSpeed max.12000 rpmDimensions (L x W x H)3,07 x 2,67 x 2,84 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z550/550/510 mmSpindle taperBT 40 Tool Magazine with24 PositionsTorque (100% DC)57 NmMax. torque83 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWTable surface850 x 650 mmWeight approx.5600 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)Tool Clamping BT 40Tool Clamping BT 40 for pull-studs DIN 69872 (differently from standard)Electronic HandwheelExternal electronic Handwheel

GeneralVertical Machining Center; Control: Control SIEMENS SINUMERIK ONE CharacteristicsTable surface1400 x 600 mmDimensions (L x W x H)2,74 x 2,74 x 2,86 mRapid feed X / Y / Z24/24/24 m/minMovement X / Y / Z1100/550/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with24 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmWeight approx.6950 KgMechanical preparation for Oil-Mist Extractor UnitMechanical preparation for Oil-Mist Extractor Unit (opening diameter: D150 mm)SK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Electronic HandwheelExternal electronic Handwheel

GeneralVertical Machining Centres; Control: 3D-control Heidenhain TNC 620 CharacteristicsMaximum load (table centre)1000 KgDimensions (L x W x H)3,93 x 3,49 x 2,94 (6,3 x 5,5 x 2,94) mRapid feed X / Y / Z30/30/30 m/minMovement X / Y / Z1100/560/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with30 PositionsDrive power (40% DC)13 kWMax. torque83 NmTorque (100% DC)57 NmDrive power (100% DC)9 kWSpeed max.12000 rpmTable surface1400 x 560 mmWeight approx.6050 KgDirect measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SystemDMG MORI IoTconnectorIoTconnector connects DMG MORI machines as well as third-party machines with CELOS. Standardized interfaces enable data exchange between the IoTconnector and CELOS APPs such as the NETservice. The integrated firewall with automatic updates ensures the hProduction Package 20 bar with chip conveyorProduction Package ...

GeneralVertical Machining Centres; Control: 3D-control Heidenhain TNC 620 CharacteristicsTable surface1400 x 560 mmDimensions (L x W x H)3,93 x 3,49 x 2,94 (6,3 x 5,6 x 2,94) mRapid feed X / Y / Z30/30/30 m/minMovement X / Y / Z1100/560/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with60 PositionsMax. torque121 NmTorque (100% DC)84 NmDrive power (40% DC)20 kWDrive power (100% DC)14,5 kWSpeed max.15000 rpmMaximum load (table centre)1000 KgWeight approx.6200 KgDirect measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SystemDMG MORI IoTconnectorIoTconnector connects DMG MORI machines as well as third-party machines with CELOS. Standardized interfaces enable data exchange between the IoTconnector and CELOS APPs such as the NETservice. The integrated firewall with automatic updates ensures the hProduction Package 40 barProduction Package 40 bar Option  ...

GeneralVertical Machining Centres; Control: DMG MORI SLIMline® Multi-Touch control CharacteristicsTable surface1400 x 560 mmDimensions (L x W x H)3,93 x 3,49 x 2,94 (6,3 x 5,5 x 2,94) mRapid feed X / Y / Z30/30/30 m/minMovement X / Y / Z1100/560/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with60 PositionsMax. torque121 NmTorque (100% DC)84 NmDrive power (40% DC)20 kWDrive power (100% DC)14,5 kWSpeed max.15000 rpmMaximum load (table centre)1000 KgWeight approx.6200 KgDirect measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SystemDMG MORI IoTconnectorIoTconnector connects DMG MORI machines as well as third-party machines with CELOS. Standardized interfaces enable data exchange between the IoTconnector and CELOS APPs such as the NETservice. The integrated firewall with automatic updates ensures the hProduction Package 1 with Chip ConveyorProductio ...

GeneralVertical Machining Centres; Control: 3D-control Heidenhain TNC 620 CharacteristicsTable surface1400 x 560 mmDimensions (L x W x H)3,93 x 3,49 x 2,94 (6,3 x 5,5 x 2,94) mRapid feed X / Y / Z30/30/30 m/minMovement X / Y / Z1100/560/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with30 PositionsMax. torque83 NmTorque (100% DC)57 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmMaximum load (table centre)1000 KgWeight approx.6050 KgDirect measuring system X,Y,ZDirect Measuring System X, Y, Z inclusive Air Purge for Measuring SystemProduction Package 3 with Chip ConveyorProduction Package 3 Option includes: - Internal coolant supply 40 bar; - Tank capacity: 600l with papertype filter; - Chip conveyor (scraper type) with tank capacity: 250 l (left) - Bed and ATC arm flushing via M-Function - Coolant spray gun for swarfPrep. 4th axis EA 510.L indirect (Heidenhain ...

GeneralVertical Machining Centres; Control: 3D-control Heidenhain TNC 620 CharacteristicsTable surface900 x 560 mmDimensions (L x W x H)3,03 x 3,49 x 2,94 (5,8 x 5,5 x2,94) mRapid feed X / Y / Z30/30/30 m/minMovement X / Y / Z600/560/510 mmSpindle taperSK 40 DIN 69871 Tool Magazine with30 PositionsMax. torque82 NmTorque (100% DC)54 NmDrive power (40% DC)13 kWDrive power (100% DC)9 kWSpeed max.12000 rpmMaximum load (table centre)600 KgWeight approx.5200 KgSK40 interfaceTool clamping SK 40 for pull-studs DIN 69872Production package 2 with Chip ConveyorProduction Package 2 Option includes: - Internal coolant supply 20 bar; - Tank capacity: 600l with papertype filter; - Chip conveyor (scraper type) with tank capacity: 200 l (left) - Bed and ATC arm flushing via M-Function - Coolant spray gun for swarfPrep. 4th axis EA 510.L indirect (Heidenhain)Preparation for rotary table (4th axis) Lehman ...

A CNC universal bed-type milling machine is offered. Table setup area: approx. 1300mm, operating hours: approx. 100h, spindle hours S1: 54h, program run time: 159h, control: HEIDENHAIN TNC 320, operating voltage: 400V, total rated current: 50A, fuse rating: 63A, spindle speed: 32-1400rpm, control: HEIDENHAIN TNC 320. Equipped with full enclosure, coolant system, work area lighting, chip guard. Weight: approx. 4500kg, overall dimensions X/Y/Z: approx. 3500mm/2000mm/2200mm. Inspection by prior arrangement is possible.

x-travel: 350 mm y-travel: 260 mm w-axis: 450 mm z-axis: 110 mm tool taper: SF 32 Quickchange-System turning speed range - stepless: 50-6300 U/min table surface area: 670 x 320 mm table load: 0,2 t feed range - table: manuell mm/min feed for quill 1:: manuell mm/U total power requirement: 2,9 kW weight of the machine ca.: 0,9 t dimensions of the machine ca.: BTH 1,47 x 1,34 x 2,10 m Infinitely variable electronic spindle speed control: 50–6,300 rpm (with 5 memory presets) Power: 2.9 kW (100%), 40 Nm max. Clockwise/counter-clockwise thread cutting Adjustable quill depth stop Precision height adjustment with fitted column wedge Includes machine base with integrated tool cabinet Fine depth feed via handwheel Precision coordinate table incl. direct measuring system Heidenhain digital position display Swiveling tool rack for 12 SF32 tools Incl. Heidenhain digital readout Incl. coolant pump  ...

Key data: 880 mm, 630 mm, 630 mm

CNC Universal – Milling & Drilling Machine DECKEL MAHO DMU 80 T With track control Heidenhain iTNC 530 Year of Make: 2002 Travel: X 880 Y 630 Z 630 Speed range: 0 – 18,000 rpm infinitely variable ( SK 40 ) With the following accessories: NC Rotary Table 0 700 mm integrated into Rigid Angle Table 1250 mm x 700 mm Clamping surface Vertical tool changer with 32 magazine positions (SK 40) Full protection cabin with sliding doors and interior lighting Electronic handwheel Operating mode 3 + 4 Spiral Screw Conveyor Coolant Setup 3-Piece Height Adjustable Machine Shoes Spindle Oil Cooler Control cabinet cooling unit (Rittal) Operating Instructions

Auction-ID: A1-40982-1

Control: CNC Table size (LXW) 920x280mm Max workpiece weight: 250kg Auction-ID: A1-40982-62

Control Conventional Horizontal/vertical Horizontal and vertical Table length [mm] 1520 Table width [mm] 385 Main spindle power [kW] 11 Auction-ID: A1-40982-93

Number of axles [pcs.] 3 X-axis travel [mm] 800 Y-axis displacement [mm] 450 Z-axis travel [mm] 500 Table length [mm] 1050 Table width [mm] 625 Tool holder ISO40 Min. spindle speed [rpm] 32 Max. spindle speed [rpm] 1600 Options Digital readout └ Type of digital readout Heidenhain Auction-ID: A1-40982-38

Universal milling machine CME (Spain) Model FU-1E Longitudinal displacement : 1000 mm Transverse travel : 300 mm Displacement height : 500 mm Table dimensions : 1300 x 300 mm Machine dimensions W x D x H : 1900 x 1500 x 2200 mm Universal Huron type milling head with ISO 40 holder Includes various tool mounts and milling Auction-ID: A1-47364-111

Has a defect in X-axis magnetic linear field. This needs to be repaired. Number of axles [pcs.] 3 B-axis rotation [°] 105 Table length [mm] 3.100 Table width [mm] 900 Auction-ID: A1-40982-4

Mori Seiki DuraVertikal 5080 3Axis Machining Center (11/2006) Manufacturer: Mori Seiki Type: auto_awesome Source language: English 587 Table length 1350 mm Table width 600 mm Number of T-profiles 6 T-profile width 18 mm Max. table load 1000 kg Longitudinal travel (x-axis) 1050 mm Transverse travel (y-axis) 530 mm Travel (z-axis) 510 mm Max. tool diameter 125 mm tool weight 8 kg Spindle nose bt 40 Distance spindle nose table 150 - 660 mm By 0 rpm Until 10,000 rpm Voltage 50 Hz 3x 400 volts Spindle performance 22 kW Total power requirement 58 kVA Machine weight approx. 8,030 kg Length 2,500 mm Width 2,350 mm Height 2,700 mm Give feedback Translation results available Year of manufacture: 11/2006 Condition: used, good, in production Incl. tools in the turret Auction-ID: A7-50270-26

Has problems with startup/control, problem unknown Vertical 3 Axles Main spindle power [kW] 2.2 Digital readout Auction-ID: A1-40982-55

Auction-ID: A1-40982-73

Table length [mm] 1100 Table width [mm] 250 Number of axles [pcs.] 3 Auction-ID: A1-40982-71
