universal internal grinding used for sale

grinding length:600 mm grinding width:250 mm workpiece height:380 mm :Sinumerik max. dia. of grinding wheel:300 mm weight:4000 kg total power requirement:12,5 kW grinding wheels:Ø 400 mm max. width of grinding wheel:100 mm grinding wheel hole diameter:127 mm turning speeds:470 - 12030 1/min x-axis:600 mm y-axis:300 mm z-axis:250 mm grinding range:450 x 200 mm distance spindle nose and table:500 mm table load:250 kg dimensions of the machine ca.:2600 x 2100 x 2400 mm switchgear cabinet:1300 x 800 x 2000 mm hydraulical unit::450 x 350 x 500 mm Documents:vorhanden

grinding length:1250 mm grinding width:400 mm workpiece height:550 mm workpiece weight:750 kg table-size:1720 x 400 mm magnetic clamping plate:1250 x 400 mm dist. center of grinding spindle - table:750 mm turning speed range - grinding wheel:3000 U/min Length movement of the table:1300 mm grinding wheel size:Ø 400 x 50 x 127 mm switchgear cabinet:inkl. hydraulic power unit:inkl. coolant:inkl. voltage:380 V table load:max. 1100 total power requirement:13,8 kW weight of the machine ca.:6000 kg dimensions of the machine ca.:5000 x 3400 x 2400 mm Documents:inkl.

grinding length:1000 mm grinding width:250 mm workpiece height:400 mm total power requirement:12 kW weight of the machine ca.:3,8 t dimensions of the machine ca.:3.300 x 1.800 x 2.300 mm hydraulic power unit:400 x1000 x 1500 mm control cabinet:2 Stück, 1000 x 1400 x 1500 mm

grinding length:150 mm total power requirement:3 x 380 /220 V weight of the machine ca.:2100 kg dimensions of the machine ca.:1200 x 1700 x 2000 mm grinding wheel diameter:280 - 350 mm grinding wheel width max.:20 mm workpiece diameter:65 - 120 mm workpiece turning speeds:1,5 -20 U/min Documents:vorhanden

grinding length:1500 mm grinding width:700 mm workpiece height:580 mm table load capacity:2380 kp table speed -stepless-:5 - 35 m/min grinding wheel dia. x width:500 x 100 x 203 mm grinding wheel motor:18 kW speeds::stufenlos elektronisch total power requirement:35 kW weight of the machine ca.:12 t dimensions of the machine ca.:5,3 x 2,9 x 3,8 (3,18) m surface grinding machine, paper-filter, DRO 3 axis, automatic infeed, el.handwheel, full cabin

x-travel:400 mm y-travel:250 mm workpiece height:500 mm grinding diameter:220 mm table surface area:600 x 320 mm throat:310 mm range of angles:12 ° grinding wheel stroke - vertical:110 mm stroke speeds:0 - 6 m/min grinding spindle speed:bis 50000 U/min peripheral speed:max. 35 m/sec capacity:ca. 7 kVA power capacity:6 kW weight of the machine ca.:2 t dimensions of the machine ca.:3 x 3 x 3 m rotary table d = 300 mm frequency changer Texte, Bilder, Grafiken, Layout, Strukturen und Algorithmen etc. unterliegen weltweitem Urheberrecht. Unerlaubte Verwendung der Daten, werden sowohl strafrechtlich als auch zivilrechtlich verfolgt. Das ausschließliche Urheber- / Nutzungsrecht dieser Daten wurde nachfolgender Person eingeräumt. Copyright © 2005-2024, Josef Weber. All rights reserved.

grinding length:600 mm grinding width:300 mm workpiece height:450 mm total power requirement:8 kW weight of the machine ca.:2,2 t dimensions of the machine ca.:2,8 x 3,0 x 2,0 m grinding spindle speed:1440 / 2905 U/min with magnetic plate 600 x 200 mm autom. vertical feed coolant attachment Texte, Bilder, Grafiken, Layout, Strukturen und Algorithmen etc. unterliegen weltweitem Urheberrecht. Unerlaubte Verwendung der Daten, werden sowohl strafrechtlich als auch zivilrechtlich verfolgt. Das ausschließliche Urheber- / Nutzungsrecht dieser Daten wurde nachfolgender Person eingeräumt. Copyright © 2005-2024, Josef Weber. All rights reserved.

grinding diameter:300 mm grinding length:600 mm centre height:190 mm z-axis:865 mm x-axis:250 mm clamping length:1000 mm peripheral speed:45 m/sec grinding slide swivable +/-:8 ° grinding wheel width x diameter:80 x 508 mm work piece spindle speed:1 - 800 U/min weight of the machine ca.:5 t Machine with SIemens 840 C control - coolant device - Marposs measuring device

grinding length:4000 mm grinding width:1450 mm workpiece height:1250 mm distance between columns:1460 mm table surface area:4000 x 1250 mm max. workpiece weight:11.000 kg cross rail adjustment:1250 mm table feed:1- 45 m/min total power requirement:40 kW dimensions of the machine ca.:12,3 x 6 x 4,8 m .machine is in top condition for high precision work! with CNC SIEMENS 840 D 1 universal grinding head, 7,5 kW swivelling of the grinding spindle +/-110° grinding wheel dimension 500 x 60 mm vertical stroke 350 mm with dressing unit 1 surface grinding head, 22,5 kW grinding wheel dimension 600 x 100 mm vertical stroke 150 mm with dressing unit 6 magnetic plates on the table diverse grinding wheel flanges

grinding length:1250 mm grinding width:600 mm workpiece height:730 mm table surface area:1720 x 500 mm headstock: dist. table - spindle center:900 mm max. longitudinal movement:X-1450 feed range:10 - 20.000 mm/min vertical movement:Y-730 mm feed range:0,2 - 3.000 mm/min cross travel:Z-550 mm feed range:5 - 5.000 mm/min power capacity:1500 U/min.- 44 kW / 8000 U/min. - 38 kW kW grinding wheel turining speeds:50-6.000 U/min cutting speed:max. 80 m/sec. weight of the machine ca.:11 t with CNC SIEMENS 840 C auto. dynamic balncing system integrated in the grinding conus profile grinding unit ( on table mounted ) Diamant profile rollers ( dia. max 140 mm , width max. 200 mm, hole 52 H3 ) speed 3000 rpm two magnetic plates ( 1000 x 400 mm, 1200 x 350 mm ) divers Flanges ect.

This grinder is ideal for regrinding tools such as face mills, drills, TIG welding needles and much more. comes standard with: Accessories for lathe tools Accessories for drills Accessories for milling 5C Spring Collet (4-6-8-10-12 mm) Clutch wrench 38-42 Grinding wheel wrench Allen key M3-M8 Screwdriver Diamond grinding wheel Ø 100 x 50 x 20 Grinding wheel: Ø 100 x 50 x 20 Diamond Pen Spring Collet: 3/16" - 5/16" - 3/8" - 1/2" Grinding range 3 -28 mm Angle adjustable from - to horizontal 0-180 degrees Angle adjustable from - to vertical 0-45 degrees Angle adjustable from - to negative 0-52 degrees Clamping range 3 - 28mm mm Speed 5200 rpm Connected load 230 / 250 volts / watt Disc diameter 100 x 50 x 20 mm Machine weight approx. 45 kg Dimensions L x W x H 0.5 x 0.4 x 0.4 m Condition: never used / new (5)

" CNC tool grinding machine SAACKE UWIA-CNC – Sinumerik 810 CNC universal tool grinding machine SAACKE type UWIA-CNC with Siemens Sinumerik 810 control including extensive accessory package, extraction system and cooling water treatment. The machine is suitable for grinding shape milling cutters, roller milling cutters, disc milling cutters, end mills, hobbing cutters, reamers, cutter heads, countersinks and taps up to Ø 200 mm . Age-appropriate optical condition. Functional. Viewing under power possible by appointment.>br Working area • Center height: 150 mm • Grinding length: 300 mm • Usable table area: 710 x 120 mm • Motorized table stroke: 300 mm • Table speed: 0.005 – 5 m/min axes • Transverse stroke Z-axis: 200 mm • Height stroke Y-axis: 200 mm • Swivel vertically: 360° • Swivel horizontally: 210° Grinding spindle • Ø 60 mm • 4 speeds: 2100 / 3000 ...

" Double-spindle deburring machine / grinding and brushing machine Stationary deburring or grinding machine in heavy industrial design with two horizontally arranged spindles. A main spindle with clamped abrasive media, an additional spindle (according to the switch "additional spindle") can be switched on separately. Machine with protective tray/work tray, emergency stop, main switch and separate control cabinet. Extraction connection available (pipe connection on the side). Control panel with: • Main switch • Emergency stop • On/off button • Switch additional spindle • Brake switch • Operating hour meter (Kübler Codix) Solid welded steel construction, can be screwed together stably. Used condition with usual signs of wear. External dimensions approx.: 1200 x 1100 x 1300 mm (W x D x H) Double-spindle design Electrical connection via separate control cabinet Extraction con ...

WMA1 version: - With grinding cycles vertical axis and additional automatic dressing compensation - With grinding wheel compensation - Automatic dressing by means of hydraulic dresser and calculation of the dressing value during the roughing process various grinding wheels max table load: 700 kg Table longitudinal movement: 900 mm Table feed: 10-25 m/mm Min./Max.: Distance spindle nose table: 170 - 600 mm Handwheel pitch vertical: 0.001 mm Handwheel rotation vertical: 0.1 mm Automatic grinding feed: 0.001 - 0.025 mm Vertical rapid traverse (Y-axis): 300 mm/min Cross travel: 450 mm Transverse feed per stroke: 1.5 - 10 mm Transverse Traverse: 1000 mm/min Handwheel pitch transverse: 0.02 mm Handwheel rotation transversely: 5 mm Grinding spindle motor: 5.5 kw Grinding wheel: 355 x 38 x 127 mm Hydraulic motor: 2.25 kW
