universal cylindrical grinding used for sale

Cylindrical grinding machine, external cylindrical grinding machine, internal cylindrical grinding machine, centering grinder, center grinder -Image below: MK5 -grinding wheel mount: -Motor data: 0.3 kW 1380 rpm -Dimensions: 370/180/H480 mm -Weight: 36 kg

Semi-automatic machine Workpiece diameter 40-400 mm Max. workpiece length 2000 mm Spindle rotation frequency 16-1460 rpm Workpiece spindle speed 3-180 rpm Max. diameter of grinding: -In steady rest 120 mm -Without steady rest 360 mm Max. grinding length 1800 mm Height of centers above the table- 210 mm Max. work-piece weight- 1000 kg Grinding wheel dia min/max 500-750 mm Max. length of table travel- 1800 mm Spindle taper- Morze 6 Motor power: 13 kW Periodical feed of grinding headstock: -Max.: 0,030±0,0025 mm -Min.: 0,0025±0,0006 mm Max. axial travel of grinding headstock spindle: ±2,5 mm

Code 71164 Description Universal Hydraulic Cylindrical Grinder Make SHIGIYA SEIKI Model GU – 27.100 H Serial No. 10222 Year 1978 Grinding length, max. 1000 mm Grinding diameter, max. 265 mm Centre height 135 mm Max. Weight workpiece 130 kg Table tilting angle - 3° till + 7° Table speeds 0,05 – 7 m/min Diam. Grinding wheel 350 mm Width Grinding wheel, max. 25 – 50 mm Motorpower grindingwheel 3,7 kW Speeds workpieceholder steples from 17 – 250 rpm Total power 9,3 kVA 380 Volts Machine size L x W x H 4,0 x 1,8 x 1,6 meter Weight 3200 kg Accessories Coolant, books, electric cabinet,etc. Condition Machine is in good condition

Code 101237 Description Universal Cylindrical Grinder Make WMW Heckert Model SA 5 U x 630 Serial No. 3115 Year 1981 Grinding length, max. 630 mm Grinding diameter, max. 275 mm Centerheight 140 mm Max. Weight workpiece 125 kg Table tilting angle - 5° till + 11,5° Diam. Grinding wheel 500 mm Width Grinding wheel, max. 100 mm Motorpower grindingwheel 5,5 kW Speeds workpieceholder 31,5 – 710 rpm Total power 12,5 kVA 380 Volts Machine size L x W x H 3,9 x 2,3 x 1,6 meter Weight 4800 kg Accessories coolant with magnetic some tooling Condition Machine is in good condition

grinding diameter: 250 mm grinding length: 1000 mm centre height: 125 mm grinding wheel diameter: 500 mm grinding wheel width: 80 (100) mm bore: 203,2 mm : MK5 work piece spindle speed: 20-400 U/min workpiece spindle - bore: mm workpiece spindle swivable +/-: 360 ° grinding head swivellable +/-: 0 ° grinding spindle speed: U/min : 0-9,99 mm/Ø : 0-9,99 mm/Ø table swivelabel +/-: 10 ° longitudinal feed of the table: mm table speeds: 0,02-6 m/min : 130 kg max. workpiece weight -without tailstock: 130 inkl. Spannung kg cross travel: 270 mm tailstock quill taper MT: 3 quill travel: 30 mm total power requirement: 5,5-7,5 kW weight of the machine ca.: 2,7 t dimensions of the machine ca.: m As the world’s leading company in Kellenberger overhaul and retrofit we are not only able to deliver machines in a quality similar to a new machine and with warranty, but we can also offer you the serv ...

With matching spacer rings according to photos. Scope of delivery according to photo 1.

! ENTER THE + WORLD! Conventional TSCHUDIN HTG 310 + with innovation and protection packages

grinding diameter: 5 - 255 mm grinding length: 300 mm centre height: 130 mm grinding length at plunge grinding: 50 mm control: SINUMERIK 805 grinding spindle speed: 25 - 1400 U/min work piece spindle speed: 0 - 500 U/min feed of grinding spindle slide cross: 0 - 5000 mm/min table speeds: 0 - 5 m/min grinding wheel diameter: 450 mm total power requirement: 10 kW weight of the machine ca.: 2,3 t dimensions of the machine ca.: 2,65 x 2,2 x 2,35 m Accessories: grinding wheel with flange, 3-jaw chuck, electron. hand wheel The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

grinding diameter: 250 mm grinding length: 600 mm centre height: 125 mm grinding wheel diameter: 500 mm grinding wheel width: 80 (100) mm bore: 203,2 mm : MK5 work piece spindle speed: 20-400 U/min workpiece spindle - bore: mm workpiece spindle swivable +/-: 360 ° grinding head swivellable +/-: 0 ° grinding spindle speed: U/min : 0-9,99 mm/Ø : 0-9,99 mm/Ø table swivelabel +/-: 10 ° longitudinal feed of the table: 700 mm table speeds: 0,02-6 m/min : 130 kg max. workpiece weight -without tailstock: 130 inkl. Spannung kg cross travel: 270 mm tailstock quill taper MT: 3 quill travel: 30 mm total power requirement: 5,5-7,5 kW weight of the machine ca.: 2,7 t dimensions of the machine ca.: m As the world’s leading company in Kellenberger overhaul and retrofit we are not only able to deliver machines in a quality similar to a new machine and with warranty, but we can also offer you the s ...

Center height: 180 mm Grinding diameter: Ø 290 mm Distance between centers: 1000 mm Lots of equipment

Schaudt ZX11 - Premium Overhauled [RETROFIT] - Compact cross slide CNC grinding machine - Tip height: 180 mm - Grinding length: 600 mm - Control: Siemens Sinumerik ONE or Fanuc - Workpiece weight: approx. 80kg - Workpiece headstock: MK4 - Tailstock: MK4 - Installation dimensions: approx. 2,700x2,400 mm Options: (other options also possible) - Balancing & grinding sensors - In-process measuring device for length & Ø - Dressing spindle for diaform roller - B-axis for swivelling grinding headstock - Automatic door drive - suitable automation - Peak increase - u.v.m. on request / customer request

Schaudt PS51 600 - Premium Overhauled [RETROFIT] - CNC production grinding machine for large-scale production - Tip height: 180 mm - Grinding length: 600 mm - Control: Siemens Sinumerik ONE or Fanuc - Workpiece weight: approx. 300kg - Workpiece headstock: MK5 - Tailstock: MK5 - Installation dimensions: approx. 4,100x2,800 mm Options: (other options also possible) - Balancing & grinding sensors - In-process measuring device for length & Ø - Dressing spindle for diaform roller - Automatic door drive - Grinding headstock swivelled to fixed stop - suitable automation - Peak increase - u.v.m. on request / customer request

Schaudt ZX11 - Premium Overhauled [RETROFIT] - CNC grinding machine for individual requirements - Tip height: 180 / 250 mm - Grinding length: 2,500 mm - Control: Siemens Sinumerik ONE or Fanuc - Workpiece weight: approx. 600kg - Workpiece headstock: MK5 - Tailstock: MK5 - Installation dimensions: approx. 7,200x2,600 mm Options: (other options also possible) - Balancing & grinding sensors - In-process measuring device for length & Ø - Dressing spindle for diaform roller - B-axis for swivelling grinding headstock - Internal loop device - Upgrade to non-circular & thread grinding - Automatic door drive - suitable automation - Peak increase - u.v.m. on request / customer request

Schaudt PF4 1000 - Premium overhaul [RETROFIT] - CNC grinding machine for individual requirements - Tip height: 180 mm - Grinding length: 1,000 mm - Control: Siemens Sinumerik ONE or Fanuc - Workpiece weight: approx. 300kg - Workpiece headstock: MK4 - Tailstock: MK4 - Installation dimensions: approx. 4,500x2,400 mm Options: (other options also possible) - Balancing & grinding sensors - In-process measuring device for length & Ø - Dressing spindle for diaform roller - B-axis for swivelling grinding headstock - Second / Third External Loop Unit - Internal loop device - Upgrade to non-circular & thread grinding - Automatic door drive - suitable automation - Peak increase - u.v.m. on request / customer request

Schaudt & Studer Grinding Machines - Premium Overhauled [RETROFIT] - various conventional, cycle-controlled & CNC grinding machines - for various workpiece Ø - with grinding lengths from 200 to 3,000 mm - Control: Siemens Sinumerik ONE or Fanuc - Workpiece weight: according to customer requirements - The attractive alternative to the new machine - We are also happy to overhaul your machine, more information on our homepage Options: (other options also possible) - Balancing & grinding sensors - In-process measuring device for length & Ø - Dressing spindle for diaform roller - B-axis for swivelling grinding headstock - Second / Third External Loop Unit - Internal loop device - Upgrade to non-circular & thread grinding - Automatic door drive - suitable automation - Peak increase - u.v.m. on request / customer request

CNC centerless grinding machine Monzesi mod Monza 510 CNC 6 axes complete with piece loading and unloading system CNC Fanuc 160i-T Under power in our warehouse in Gussago BS. Mimu machine tools Italy

Centerless external cylindrical grinding machines Herminghausen SR 40-3 Machine Was improved and rebuilt by the company Ebert. Thus type designation CL 43. Original price 299.000, - €. Operating voltage: 400 volts, power consumption: 22 kW, workpiece diameter 2 - 130 mm, largest grinding length for through grinding 250 mm, grinding wheel diameter min/max 400/600 mm, grinding wheel bore 604.8 mm, control wheel diameter min/max 220/300 mm, control wheel bore 152.4 mm, grinding wheel circumferential speed 40 m/s, control spindle speed infinitely adjustable 0 - 200 rpm, control Siemens S7, cooling lubricant supply unit, weight of the machine ca. 6000 medical history Errors excepted!

CNC external cylindrical grinding machine, brand Studer, type S40-4, Bi 1987, Documents are available. The price is net

grinding length:400 mm workpiece weight:250 kg weight of the machine ca.:4,1 t swing diameter:250 mm grinding spindle speed:2387, 2938 U/min

Technical data of Used Universal cylindrical grinding machines Cometa HSP 2000: Wheel diameter: 762 mm Max diameter working: 800 mm Center height: 410 mm Working lenght: 2000 mm Wheel power: 15 hP Weight: 11 ton

grinding diameter:4000 mm centre height:310 mm weight of the machine ca.:17 t dimensions of the machine ca.:10.5 x 3.6 x 1,9 m

grinding diameter:3 - 150 mm grinding length:200 mm total power requirement:380V, 50Hz, 30 kW dimensions of the machine ca.:5 x 3 x 2,5 m

grinding diameter: 0,2 - 190 mm grinding length:400 mm centre height:100 mm weight of the machine ca.:1,6 t dimensions of the machine ca.:2 x 1,5 x 1,8 m

Ref. -No.: 10301 Manufacturer: TITAN Year of construction: 1990 Type of control: Konventionell Storage location: Halberstadt Country of origin: USA Max. Grinding length: 1.500 mm Max. Workpiece Weight: 300 kg Grinding Diameter: 350 mm Max. Dia. Of Grinding Wheel: 280-500 mm Grinding Wheel Width: 80-100 mm

Without pallet;

MAX DIAM 450 . MAX LENGHT 1600

Grinding lenght 6000 mm Grinding diameter 1050 mm

Dot height: 150mm, Distance between points: 1000mm, Grinding wheel dimensions (od x id x width): Ø400xØ127x50mm, Internal grinding head: 4 units, Centre height: 150mm, Max. workpiece weight: 80Kg, X-axis travel (transverse): 350mm, X-axis speed: 10 meters per minute, Z-axis travel (longitudinal): 1000mm, Z-axis speed: 12 meters per minute, Z-axis resolution: 0.00004, B-axis swivel range: 210°, B-axis resolution: 0.0001°, Drive capacity: 10 HP, Grinding wheel diameter: 400mm, Max. width Grinding wheel width: 63mm, Spindle speed range: 0-1000 RPM, Spindle swivel range: 0° - 90°, Tailstock stroke: 30mm, Equipped with: Fanuc 21i-TB CNC Control, Dimensions: 3350x 2130x 2130, Weight: 4535Kg, Accesories: Steady rests, magnetic plate, 3-jaw chuck, balancer, sensitron 6, coolant with paper and magnetic filter, fume extractor, etc.

Weight: 6300 Kg, cnc brand: FANUC, Accessories: Refrigeration equipment with paper filter

Distance between centers: 1000 mm, Height of points: 230 mm, Main engine power: 9.2 Kw, Working wheel dimensions (od x id x width): 500x80x203.2mm, Ø max to be rectified: 460 mm, Tailstock cone: MORSE 4, Workpiece head cone: MORSE 5, Max. Z axis travel : 1115 mm, Max. X axis travel: 260 mm, Approximate dimensions (length x width): 440x370 cm, Approximate Weight: 4700 Kg

Distance between points: 1000 mm, Point height: 175 mm, grinding length: 500 mm, Ø max to be rectified: 300 mm, inner cone: Morse 5, Working wheel motor power: 7.5 Kw, Longitudinal travel of the carriage (X axis): 267 mm, Transverse travel of the carriage (Z axis): 650 mm, cnc brand: FANUC, cnc model: 16-T

Distance between points: 760 mm, Max travel Z axis: 650 mm, Maximum length to be rectified: 430 mm, Ø max to be rectified: 250 mm, Height of points: 125 mm, Ø max. molar: 500 mm, Max travel X axis: 320 mm, cnc brand: FANUC, cnc model: 18i-T, Ø max. wheel: 400 mm, main motor power: 7.5 Kw, Z and X axis resolution: 0.1µmm, Distance between centers: 430 mm, Workpiece head cone: MORSE 5, Ø of the workpiece head hole: 38 mm, tailstock cone: MORSE 4, Accessories: FELSOMAT gantry loader with SIEMENS CNC; Refrigeration equipment with paper filter; Forkardt automatic mooring plate; automatic tailstock; Cooled grinding wheel shaft; Spare ball screw; MARPOSS Automatic Grinding Wheel Balancer and Gauge , Dimensions (length x width): 2500x2000 mm, Weight: 4700 Kg

Distance between points: 1000 mm, Ø max to be rectified: 350 mm, Max travel Z axis: 1.180 mm, Max travel X axis: 350 mm, Height of points: 180 mm, Ø max to be rectified with the left wheel: 350 mm, Left grinding wheel dimensions (od x id x width): Ø450xØ203x80 mm, Working wheel dimensions (od x id x width): 508x203.2x80mm, Right grinding wheel dimensions (od x id x width): Ø300xØ127x40 mm, cnc brand: FANUC, cnc model: 18TC, Main engine power: 7.5 Kw, Maximum weight between points: 120 Kg, Total installed power: 15 KW, Standard peripheral speed: 45 m/s, Automatic grinding head rotation with Hirt 2.5º: +5º_-180º, B axis control system: Incremental encoder + 2.5º Hirt ring, B axis motor: 2.5 Nm at 3000 rpm, X axis speed: 10,000 mm/min, X axis resolution: 0.0005 mm, Z axis speed: 10,000 mm/min, Z axis resolution: 0.005 mm, Z axis table rotation: 0º_9º, Workpiece head cone: MORSE  ...

GENERAL Project No.: 905670 Quantity: 1 pcs. Manufacturer: TACCHELLA Type: Elektra 1018 MPC Control: MPC Year of Make: 1999 Condition: Used machine Layers approx.: less than 1 layer DESCRIPTION CYLINDRICAL GRINDING Max. grinding diameter 350 mm Max. grinding length 1000 mm Center height 180 mm Center width 1000 mm GRINDING SPINDLE UNIT Travel in X/Z 350/1180 mm Max. rapid traverse speed in X/Z 10/10 m/min Grinding headstock can be swivelled manually Belt-driven grinding spindle for external grinding wheel right with max. diameter x width x bore 400x50x127 mm left with max. diameter x width x bore 450x80x203 mm Max. circumferential speed 35 m/s2 Max. power at ED 10-40/100% 7.5 kW Mounting MK5/ASA4 TAILSTOCK Tailstock can be moved manually Tailstock quill holder MK4 Cylinder Fine Adjustment Tailstock Manual Dresser with dressing tile on tailstoc ...

Distance between points: 1100 mm, Center height: 175 mm, Maximum diameter to be rectified: 270 mm, Maximum piece weight: 135 Kg, Working wheel dimensions (od x id x width): Ø508xØ304.8x80 mm, Main engine power: 7.5 Kw, numerical control: Fanuc 21 Oi-T

Distance between points: 1000 mm, Ø max to be rectified: 400 mm, Maximum length to be rectified: 600 mm, Max travel Z axis: 1300 mm, Max travel X axis: 378 mm, Height of points: 205 mm, Ø of the grinding wheel: 600 mm, Grinding wheel width: 63 mm, Maximum width of grinding wheel: 125 mm, Grinding wheel hole Ø: 203 mm, cnc brand: SIEMENS, cnc model: 840D, Main engine power: 22 Kw, Grinding wheel speed: 45 m/s, tailstock cone: mk5, Counterpoint tour: 100 mm, Workpiece head cone: mk5, Workpiece head rotation: 90º, Maximum piece weight: 300 Kg, Working accuracy of the machine: IT4 ISO, Fine taper adjustment +/-: O, 1 mm/a, speed of the working feed of the table: from 0 to 7.5 m/min, Plan dimensions: 4500x3000x2500 mm, Weight approx.: 8000 Kg

Total power: 38 KVA, Max. length to be rectified: 800 mm, Height of points: 150 mm, Max. piece weight: 80 Kg, Working precision: IT4 ISO, Dimensions of the external grinding wheel: Ø400xØ127x63mm, Max width of grinding wheel: 63 mm, Power of outdoor grinding wheel: 7.5 Kw, Grinding wheel rotation speed: 45 m/s, Max travel X axis: 350 mm, Workpiece head cone: MORSE 5, Workhead spindle speed: 0-1000 rpm, Swivel angle of the working head: 90º, Tailstock cone: MORSE 4, Tailstock stroke: 90 mm, Max travel Z axis: 1000 mm, Table adjustment angle: +/- 8º 30, CNC control: SIEMENS, cnc model: 840 D

Distance between points: 500 mm, Height of points: 100 mm, Ø of the grinding wheel: 300 mm, Normal grinding wheel width: 25 mm, Maximum usable width of the grinding wheel: 50 mm, Grinding wheel hole: 127 mm, Workpiece holder head: 75-110-150-220-275-375-550-750 rpm, Tilt table in degrees: 8º, Hydraulic table speed: 0.10/6 m/min, Automatic fast forward: 20 mm, Advance in depth: 0.10 to 1 mm, Plongee feed rate: 0.10-5 mm/min, Fine-tuning time regulation in seconds: 60s, Workpiece holder head motor: 2 speeds: 0.38/0.55 HP, Motor head for grinding wheels: 3 CV, Hydraulic pump motor: 0.5 HP, Cooling pump motor: 0.10 HP, Internal grinding apparatus: 0.75 HP, Points: Morse 4 and 3, Weight approx.: 1600 Kg

Surfaces reference plates, roughness measures MASSI cylindrical grinding TGL 4763 Rz 0.8 μm - Rz 20 μm in wooden box Dimensions: 345 x 125 x 40 mm

Surface reference plates, roughness measures MASSI cylindrical grinding TGL 4763 Rz 0.63 μm - Rz 2.5 μm in wooden box Dimensions: 240 x 125 x 40 mm

Surface reference plates, roughness measures MASSI cylindrical grinding TGL 4763 Rz 0.1 μm - Rz 0.4 μm in wooden box Dimensions: 240 x 125 x 40 mm

Surface reference plates, roughness measures MASSI cylindrical grinding TGL 4763 Rz 1.6 μm - Rz 20 μm in wooden box Dimensions: 240 x 125 x 40 mm

TOS BUC 63A/3000 Cylindrical Grinding Machine Grinding Diameter 630 mm Grinding Length 3000 mm Height of centers 315 mm Workpiece Weight 2500 Kg Max. Grinding wheel dimensions 750 x 100 x 305 mm Spindle Speed 840/970 rpm Workpiece Spindle Speed 8 - 315 rpm Grinding support stroke 90 / 280 mm Table Speed: Variable - from 0.01 to 3.6 m / min Grinding Head Swivel 90 Degree Table Swivel +/- 5 Degree Work Head Tilts from 90 taper - Morse 6 Spindle Drive 15 KW Machine Dimensions 10000 x 3400 x 2000 mm Machine Weight 13.7 Ton Machine weight approx. 12 t Space requirement approx. 12 x 4.3 x 1.9 m Total power input 22 kW

Distance between points: 760 mm, Max travel Z axis: 650 mm, Maximum length to be rectified: 430 mm, Max. diameter to be rectified: 250 mm, Height of points: 125 mm, Max. grinding wheel diameter: 500 mm, Max travel X axis: 320 mm, CNC brand: FANUC, CNC model: 18TB, Main engine power: 7.5 Kw, Z and X axis resolution: 0.1 µmm, Workpiece holder head cone: MORSE 5, Ø of the hole in the workpiece holder head: 38 mm, tailstock cone: MORSE 4, Rotation speed of the workhead: 8 to 800 rpm, Dimensions (length x width): 2500x2000 mm, Weight: 4700 Kg

External/Internal Cylindrical Grinding GENDRON RU 28.100 Between points: 1000 mm Maxi grinding diameter: Ø 290 mm Tool holder rotation: from 70 to 370 RPM 4-jaws Ø 200 mm chuck Grinding wheel: Ø 300 mm Auto pass plug Swivel table External hydraulic group External lulbricant tank Voltage: 380 V Dimensions (L x W x H): 3000 x 1900 x 2000 mm Weight: approx 3 T

Center height: 135mm, max. sanding length (shaft): 500mm, max. sanding diameter: 270mm, sanding wheel diameter: 400mm, power requirement: 7.5kW, machine dimensions X/Y/Z: approx. 2000mm/1300mm/1300mm, weight: approx. 1700kg.

Grinding wheel diameter: 220mm, grinding wheel width: 5mm, base body width: 20mm, bore diameter: 52mm. Test piece: diameter: 100mm, width: 300mm, profile height: 35mm. Small workpiece: Outer diameter: 400mm, bore diameter: 205mm, wheel width: 100mm, torque: 20Nm, weight including mandrel: 200kg. Large workpieces: Outer diameter: 700mm, bore diameter: 350mm, disk width: 300mm, torque: 800Nm, weight: 250kg. Accuracy: Repeat accuracy: less than 2µm, axial and radial run-out accuracy (large spindle): less than 2µm at 400mm diameter, axial and radial run-out accuracy (small spindle): less than 2µm at 200mm diameter, parallelism over 300mm between test piece and workpiece axis: less than 2µm. Tool spindle speed: 10000rpm, small workpiece spindle: 23000rpm, large workpiece spindle: 6000rpm, test piece spindle: 1000rpm.

Two Loeser centerless round polishing machines are available. Workpiece diameter range: 10mm-30mm, workpiece length range: 100mm-1000mm, stations: 2, working direction: left-right, magazine with input and output table: 1000mm/1000mm. Including magazines and input and output table. Documentation available. On-site inspection is possible. Expected to be available from April 2025.

A Karstens cylindrical grinding machine with display is available. Center height: 180mm, grinding diameter: 360mm, center width: 650mm, max. workpiece weight flying/between centers: 70kg/250kg. Grinding wheel outer diameter: 400mm, face diameter: 250mm, peripheral speed: 35m/s, speed: 450rpm, mounting cone: MK4, quill diameter: 50mm, fine adjustment: 0.08mm. Machine dimensions X/Y: approx. 3250mm/2150mm, weight: approx. 3600kg. On-site inspection is possible.
