turning lathe used for sale

BOEHRINGER VDF DUS 1000 CNC lathe was built in 1993 in Germany. The machine, designed for machining workpieces with a maximum diameter of 1000 mm, delivers excellent turning results during even the most intensive challenges, thanks to its extremely stable design and reliable components. The spindle is driven by an stepless AC motor, which allows efficient turning in two different, optimally adapted speed ranges. All axes, on the other hand, have powerful servo drives, guaranteeing excellent dynamics and positioning accuracy throughout the machine’s lifetime. This is rounded off by an intuitive SIEMENS CNC control with many functions for easy operation and programming. The BOEHRINGER VDF 1000 DUS lathe weighs approximately 10100 kg. Technical specifications of BOEHRINGER VDF DUS 1000 metal lathe - turning diameter above the bed: 1000 mm - turning diameter over transverse slide: 710 ...

Specifications Control Siemens Sinumerik 840 Dsl Main dimensions and travels Face plate diameter 3,500 mm Circumferential diameter (max.) 4,000 mm Workpiece height (max.) 3,000 mm Total height of the machine 7,250 mm Maximum workpiece weight 50,000 kg Table base Y Horizontal table displacement 2,000 mm Crossbar Vertical adjustment of the crossbeam 1,500 mm in 50 steps Crossbeam Support (Right) Horizontal adjustment support -25 + 2170 mm Vertical displacement of the chisel slide 1,800 mm Cross-section of the chisel slide 250x210 mm Tool Stations Crossbeam Support (Left) Horizontal adjustment support -25 + 2170 mm Vertical displacement of the chisel slide 1,800 mm Cross-section of the chisel slide 250x210 mm Tool Changer Main Drive: Main motor power 100 kW Face plate speed range 1-100 rpm. Maximum torque at the face plate 100  ...

CNC slot machine Gildemeister GLD 25 with counter spindle Technical data: Manufacturer: Gildemeister Type: GLD 25 Built: 1999 Control: FANUC Series O-T Main spindle: - max. turning diameter: 25 mm - max. speed: 8,000 rpm - maximum stroke (Z-axis): 160 mm Counter spindle: - max. turning diameter: 25 mm - max. speed: 8,000 rpm - maximum stroke (C-axis): 265 mm - Rapid speed C-axis 15 m/min Sled: - Slide: X= 30 mm, Y= 220 mm - Rapid x-axis 10 m/min - Rapid y-axis 15 m/min - Number of WZ on the sled: 5 + 3 (driven) - Speed WZ (driven) : 6,000 rpm Accessories: - Chip conveyor -Bar loader: IEMCA MINI BOSS 325/32 Dimensions LxWxH: - Machine with chip conveyor 3150 x 1100 x 1700 mm - Bar loader 3900 x 800 x 1400 mm Weight: - Machine: approx.2000 Kg - Bar loader: approx. 1000 kg. - Total weight: approx. 3,000 kg

3 re-lathes, see pictures

Key data: 400 mm, 1100 mm, 3500 1/min

Machine Details Stock-No. 1105-04040 Type of machine CNC Lathe Make NAKAMURA Type SC 300 L Year of manufacture 1998 Type of control CNC Storage location FRANCE Country of origin Japan Delivery time by arrangement from the location Freight basis EX WORK Price Technical details turning diameter 350 mm turning length 1150 mm control FANUC 21 t turning diameter over slide 300 mm turning speeds 3500 rpm rapid traverse 20/25 (X,Z) m/min power capacity 22 kW Additional information NICE MACHINE TURNING LENG 1150 CNC FANUC 18 T WITH LIVE TOOLS ANS C AXIS CHIP CONVOYER HYDRAULICK STEADY SMW Technical details and information subject to amendments and errors. 2024 Created with ModulMWS by LogoTech oHG

Machine Type: CNC Lathe Manufacturer: GILDEMEISTER Type CTX 500 S2 Year of construction 1998 Control CNC Pilot Heidenhain Country of origin Germany Delivery time by arrangement Freight base from location Technical details Turning diameter max. 445 mm Turning length 1,000 mm Control CNC Pilot Heidenhain Circumferential diameter 680 mm Main spindle: Speed range – main spindle 18 - 3,600 rpm/-1 Drive power – main spindle 23 kW Max. torque 650 Nm Spindle nose 220h5 Chuck diameter 315 / 400 Spindle bearing diameter 140 mm Spindle bore 107 mm Tool turret: Number of tool positions 12 pos. Tool holder 40 DIN69880 Travel: x-travel 320 mm z-travel 1,097 mm Tailstock: Quill stroke 120 mm Tailstock mount MK 5 Quill pressure 14 kN Feeds: Rapid traverse X : 24 / Z : 30 m/min Feed force X: 8 / Z: 15 kN Total power requirement 58 kVA Machine weight approx ...

MAX DIAMETER OF ROD: 100 MM MAX CUTTING DIAMETER: 552 MM MAX TURNING LENGTH: 1.195 MM TURRET: 16 ROTATION SPEED: 2800 RPM CONTROL: FANUC 32 B INCLUDES: AUTOBLOK STEADY SLU-3.1 – ZS CAPACITY: 20-165 MM AUTOMATIC FEEDER FOR BARS BREUNING – MOD. MUK 10016-II

Table diameter 2.000 mm Working diameter 2.000 mm Machine under retrofit/rebuilding to install CNC Mechanical ready, totally rebuilt.

Key data: 490 mm, 515 mm

tock-No. 1105-04043 Type of machine CNC Turning- and Milling Center Make MORI SEIKI Type NL1500SY/500 Year of manufacture 2006 Type of control CNC Storage location HAGUENAU FRANCE Country of origin Japan Delivery time immediately Freight basis ex Warehouse Price Technical details turning diameter 490 mm turning length 515 mm control MSX-850 max. bar capacity 52 mm Travel -X Axis 280 mm Travel -Z AXIS 490 mm max. speed main spindle 6000 min-1 spindle taper 1 A2-6 C - Axis 0.001 ° Spindle bearing diameter 110/75 mm No. of tools in turret 1 12 Shaft Cross Cut 25 x 25 mm Shank diameter 50 / 32 mm Turret Change Time 0.25 s max. spindle speed driven tools 6000 min-1 rapid power traverse in X-and Z direction 30 m/min Rapids C - Axes 400 min -1 drive capacity - spindle motor 18.5 kW power capacity - driven tools 5.5 kW swing diameter over face slide 278 mm gre ...

Key data: 85 mm, 255 mm, 6300 1/min

CNC lathe Emco E25 Powermill TCM Commissioning 03/2019 At call! Siemens 828D Shopturn Main spindle spindle passage 25mm PF - 6,300 1/min Turret 12-speed VDI16 driven tools 6,000 1/min PC Keyboard Machine set-up and fastening material Parts collection device Emco Standard Bar Feeder Interface Machine Status Lamp LED Multiflow Cleaning Gun 8-bar high-pressure coolant device Power Chuck 95/3 Röhm Pliers chuck KZF 20 for 148E Tool holder pact stationary/driven 9 pieces Radial Milling Holder VDI16 2 WStück Axial Milling Holder VDI16 2 WStück OPC UA / Siemens interface The options list is complete! No interest in dealer enquiries! No separate dealer price! WB mechanics GmbH is a precision mechanics workshop that markets its used machines on its own. We are not a machine dealer, but the machine user! The machine is in use in our company until it is sold a ...

CNC fine lathe Make: PetrolGer Type: TNL Control: Siemens 810T Built: 1991 Equipment and accessories: - Swivel loader system - Small conveyor belt - Charging-unloading gripper - Chip conveyors - Foot lever for clamping and relaxing the collet

Key data: 370 mm, 650 mm, 3500 1/min

Machine Details Stock-No. 1105-04067 Type of machine CNC Lathe Make DAEWOO Type PUMA 250 B Year of manufacture 1998 Type of control CNC Storage location HAGUENAU FRANCE Country of origin Corea Delivery time to be agreed Freight basis ex Site Technical details turning diameter 370 mm turning length 648 mm control Fanuc 18 t bar diameter 77 mm swing dia. 570 mm swing diameter over cross slide guide 255 mm max. turning diameter 255 mm drive capacity - spindle motor 18.5/22 kW turning speeds 3500 rpm Turret (X-Stations) 10 pos. JAPAN rapid traverse X-axis 24 m/min total power requirement 32 kW weight of the machine approx. 6 t dimensions of the machine approx. 3.43 X 1.85 X 2 m Additional information GOOD MACHINE WITH CNC FANUC 21 IT 3 JAW CHUCK DIA 250 MM SCHIP CONVoYEUR TOOL SETTER COOLANT INTERLOKED GUARDS

MACHINE IS IN GOOD WORKING CONDITION Machine need center horse and support for the clamp cutting tools. Bj0ie7dcoa Machine Has ben used in Switzerland, after thay realize they need that both suports, they took it off and use on other lathe.

Machine details Bearing number 1105-03132 Machine type CNC lathe - slantbed machine Made GILDEMEISTER Type CTX 400 Built in 2000 Control type CNC Warehouse FRANCE Country of origin Germany Delivery time SOFORT Freight base from location, free loading truck Technical details Turning diameter 570 mm Turning length 635 mm Control Heidenhain CNC Pilot 4290 Turning diameter over bed slide 420 mm Spindle speeds - infinitely 25-5000 rpm Number of driven tools 6 mm Drive 5 kW Information CNC Heidenhain Pilot 4290 C-axis with 5 FESTE vdi holders 1 3 BAKE FOOD 1 X SPAENEFOERDERER WITH REITSTOCK + LNS STANGEN VORCHUB

Inv. Num: 5302 Type: DL 10G Producer: Profika Generated: 2011 Parameters: Control system: FANUC 0iMATE-TD Maximum rotation length: 185 mm Max turning diameter: 170 mm Maximum spindle speed: 3500 rpm Lathe length: 1980 mm Lathe width: 1420 mm Weight: 2750 kg

ovenn 650 inner dimensions 1x1x2m t max 650 C PLC Auto door Schachtofen Haubenofen Rollenherdöfen Durchstoßöfen Härten Glühen Normalisieren Weichglühen Vergüten Anlassen Entspannen Durchschuböfen Hubbalkenöfen Hubherdöfen Trockenöfen Rollenherdöfen Drehherdöfen Kammeröfen Mehrkammeröfen Verfahrbare zirlguss Haubenöfen Herdwagenöfen Poreba Gurutzpe Tacchi Geminis Tos Amutio cazeneuve Skoda Morando Niles Colchester Heyligenstaedt Kramatorsk Mondiale Safop Cazeneuve Alzmetall mas stankoimport csepel carlton kolb soraluce bergonzi flott Erfurt Weingarten smeral schuler ebu mueller zts kosice wlochy minster Stanko stankoimport glaser huta zygmunt aft donaldson eumuko Elblag Engel Demag Arburg Krauss Maffei Battenfeld Manesty Mazak Voronezh Trumpf Amada Cincinnati Netstal Rose Forgrove Illig Foremost Nissei Sandretto Fette Mazak Mori seiki Haas Okuma Gildemei ...

Manufacturer: WEILER Machine Tools Type: DZ 28 CNC Built: 1997 Connection power 25 kW Numerically controlled linear turning center for the production of precision workpieces in the small parts sector. The two machines are driven via a controller. As shown, the machine includes vertical material supply, the machining machine with chip conveyor and control devices, control cabinet and hydraulic unit. The machine was in operation at the site in Germany until production ceased. The machine is dismantled.

BIGLIA SMART TURN B1200 CNC automatic lathe was built in 2008 in Italy by OFFICINE E. BIGLIA & C. S.p.A. The machine, dedicated to the precise, multi-axis machining of workpieces with a maximum diameter of 580 mm, was created as an effective answer to the daily challenges of modern business. For this purpose, it features modern components with excellent technical characteristics inside a large work space, such as two spindles (main spindle and sub-spindle) and a 40-position tool magazine. The high-speed operation of the tool magazine further significantly speeds up production time and reduces machine downtime to a minimum. The SMART TURN B1200 S CNC turning center is offered with a wide range of equipment, including a bar feeder, Y-axis and FANUC intelligent CNC control. The total weight of the machine is 7000 kg. Technical specifications of the BIGLIA SMART TURN B1200 CNC lathe Gene ...

Lathe was bought fully reconditioned from a reseller in 1996 and has been used since 2010. Mechanically is in good conditions, NC is to be checked.

GILDEMEISTER TWIN 65 CNC automatic lathe was built in 2005 in Germany by GILDEMEISTER Drehmaschinen GmbH. The machine is used for precise, multi-axis machining of workpieces with complex geometries. To increase overall production efficiency, a combination of two spindles and two 12-position turrets with excellent technical specifications are used inside the large working area. Both spindles feature a C-axis with a high indexing accuracy of ± 0.002 mm, which facilitates complex machining operations that require precise positioning of the workpiece. All this is complemented by an intelligent SIEMENS CNC control with an intuitive interface. The GILDEMEISTER CNC turning center weighs 10000 kg. Technical specifications of the GILDEMEISTER TWIN 65 CNC lathe General data - number of axes: 8 (X1, X2, X3, Y1, B, Z1, Z2, Z3) - feed in the X1/X2/X3 axis: 300/180/175 mm - feed in the Y1/B ax ...

Furnace (heat treatment machine) 650 T max 650 Celsius inner dimensions 1.5x1.5x2m Poreba Gurutzpe Tacchi Geminis Tos Amutio cazeneuve Skoda Morando Niles Colchester Heyligenstaedt Kramatorsk Mondiale Safop Cazeneuve Alzmetall mas stankoimport csepel carlton kolb soraluce bergonzi flott Erfurt Weingarten smeral schuler ebu mueller zts kosice wlochy minster Stanko stankoimport glaser huta zygmunt aft donaldson eumuko Elblag Engel Demag Arburg Krauss Maffei Battenfeld Manesty Mazak Voronezh Trumpf Amada Cincinnati Netstal Rose Forgrove Illig Foremost Nissei Sandretto Fette Mazak Mori seiki Haas Okuma Gildemeister Doosan Daewoo traub hwacheon index Wema zeulenroda mueller Erfurt tox presso technik dunkes galdabini hare ponar zeulenrdoda eitel

The machine is in good technical condition, a test run is possible by prior arrangement. Hours: 8,981 Upper driven tool turrets with Y-axis, lower driven turret, double slide with two spindles. Control: FANUC 31i-B. Max. circumferential diameter above the bed: 300 mm Max. circumferential diameter over the support: 230 mm Max. turning diameter above the bed with upper turret: 230 mm Max. turning diameter above the bed with lower turret: 230 mm Max. turning length: 600 mm Max. distance between the ends of the right and left spindle: 980 mm Milling area outside the axis of rotation due to Y-axis: 100 mm (+/- 50 mm) Max. rod diameter (left spindle): 65 mm Max. rod diameter (right spindle): 65 mm Max. permissible workpiece weight without sub-spindle (incl. chuck weight = 23 kg): 12 kg Total weight: 7,800 kg Accessories: SS 2500 bar feeder, length 200–1 ...

Spindle diameter 3,000 mm Turnerable diameter 3,200 mm Maximum workable height 2,000 mm Weight allowed over spindle 40 ton Pump engine power 63 kW Spindle rotation speed 0.66-62 RPM Machine weight 86,000 kg Dimensions 9.345x5.120x6.030 mm

The machine is in good technical condition, a test run is possible by prior arrangement. (spindle 32 mm) + Mitsubishi E60 control. Bar feeder included – for bars up to 3000 mm! Max. turning diameter: 60 mm Max. turning length: 120 mm Circulation diameter over cross slide: 120 mm X-axis: 170 mm Z-axis: 170 mm Spindle bore: 34 mm Max. bar diameter when using the loader: 32 mm Spindle holder: diameter 85 mm Spindle motor: 3.7 kW Spindle speed: 100–5,000 rpm Rapid traverse (X and Z axis): 15 m/min Min. program input: 0.001 mm Max. tool diameter: 16 mm Machine dimensions (L x W x H): 1200 x 1000 x 1500 mm

Platform diameter 2,800 mm Max turnerable diameter 3,200 mm Maximum height of the workpiece 1,600 mm Weight allowed above platform 16,000 kg Main engine power platform 55 kW Spindle RPM 1.25-63 Spindle No. Crossbar stroke 1,240 mm Horizontal head stroke 1,720 mm Vertical head stroke 1,200 mm Total machine weight 43 ton

The machine is in good technical condition, an inspection by prior arrangement is possible. Max. turning diameter: 465 mm Max. circumferential diameter: 680 mm Max. rotation diameter via cross slide: 465 mm Max. width of the cross-section: 315 mm Travel in X/Z: 300/1050 mm 315mm 3-Jaw Hydraulic Chuck Max. spindle speed: 3250 rpm Spindle bore: 76 mm Spindle drive power (40%/100% ED): 33/22 kW Max. spindle torque (40%/100% ED): 630/420 Nm Max. speed driven tools: 4000 rpm Programmable tailstock, tool measurement, chip conveyor S/No. 8045000336E (2011) Installed power: 50 kVA Power supply: 400 V; 50/60 Hz Dimensions (L x W x H): 5250 x 2300 x 2000 mm Machine weight: 8000 kg

CNC controller: Mitsubishi M-720BM (MAPPS 2) Capacity X-axis travel mm: 260 Z-axis travel mm: 520 C-axis: 360º (0.001°) Turning length mm: 515 Max. turning diameter mm: ø: Ø356 Upper turret Tool holder: 12 Main spindle Speed spindle rpm: 5000 Drive power spindle kW: 15/11 Spindle bore mm: 73 Manufacturer: KITAGAWA Counter spindle Counter spindle travel mm: 525 Equipment Chip conveyor Signal lamp Tool measuring arm Workarea light Working time hours Under power: 7.456 Cutting Time: 5.423 Basic machine dimensions / weight Length mm: 3.495 Width mm: 2.050 Height mm: 2.230 Weight kg: 5.800

Ø max. of the piece: 2200 mm Ø clamping of the table: 2000 mm Maximum load on the table: 12000 kg Maximum height of the piece: 1200 mm RAM Stroke (Z): 720 mm Main engine power: 55 kW

platform diameter: 1450 mm (HYDRAULIC - hydraulic spindle) maximum diameter of the piece: 1650 mm maximum height of the piece under the crossbar: 1200 mm - under tool holder: 1000 mm maximum workpiece weight: 11000 Kg mobile crossbar running on the plinth: 900 mm fast movement speed: 400 mm/min. slow displacement speed: 100 mm/min positioning accuracy on the base: +/- 0.1/100 mm main drive engine power: 60 KW platform advancement range: 2-280 rot/min number steps speed change box 3 work support stroke (X-axis): 1542 mm vertical stroke work support sled (Z-axis): 1200 mm sled section: 250x250 mm Milling shaft cone: ISO 50 milling engine power: 22 KW milling shaft speed range: 20-2000 rot/min X-Z axis work feed range: 1-4000 rot/min fast forward: 6000 rot/min C axis feed (slow-regimo milling rotation): 1-360 °/min X, Z, C: 45 N ...

Table diameter: 1,200 mm Maximum turnerable diameter: 1,350 mm Spindle power: 47.7 Kw Maximum turnable height: 950 mm Table capacity: 6 ton Table rotation speed: 2.22 ÷ 200 rpm Vertical RAM wagon stroke: 1,000 mm Vertical turret wagon stroke: 760 mm Tilt vertical wagons: 35 ° Total weight: 16 ton CNC FAGOR 8055 Year 1979 REVISED IN 2009

General Manufacturer: Spinner Type: TTC300 65SMMCY Control: Siemens 840D SL ShopTurn Year of Make: 2015 Travel X1 / X2 / Z / Y: 180 / 110 / 450 / +40-40 mm Rapid traverse X1 / X2 / Z / Y: 15 / 15 / 15 / 24 m/min Turning Spindle 1 Speed: 4,000 rpm Chuck size: 250 mm Spindle passage: 52 mm Spindle power S1 / S6: 21 / 27 kW Torque S1 / S6: 201 / 258 Nm Turning spindle 2 Speed: 7,000 rpm Chuck size: 130 mm Spindle power S1 / S3: 6 / 8.5 kW Torque S1 / S3: 49 / 68 Nm Revolver Number of tools: 12 + 12 (BMT45) Rotating Tools: 12+12 (BMT45) Speed: 6,000 rpm Power S1 / S3: 2.3 / 3.5 kW Torque S1 / S3: 7 / 11 Nm Dimensions and weight Dimensions: 2,700 mm x 1,900 mm x 2,165 mm Weight: 5,100 kg Condition Condition: Used Functional: Tested and fully functional Other equipment and accessories included: IKZ 50 bar with belt filter system Parts Conveyor Belt w ...

Table diameter 1450mm Maximum working diameter 1600mm Maximum height under the crossbar 1000mm Two balanced RAM Quota viewers Machine working in good condition Machine weight 18 ton This morando vertical lathe is in excellent condition and ready to be installed.

Spindle diameter 2,000 mm Turnerable diameter 2,000 mm MACHINE IN MECHANICAL/ELECTRIC RETROFIT PHASE

The machine is in good technical condition, after prior agreement possible to test. Control system – Siemens Including filtration. Bed inclination Bed material Number of guides 45 cast iron 3 (4 with Y-axis option) WORKING SPACE (V1- V4) Swing diameter over bed inch 19.69 Swing diameter over cross slide inch 11.42 Largest turning diameter inch 7.87 200 ч Distance between centers inch 30.71 Largest turning length inch 19.69 15.82 20 Max. weight of flying unsupported part of workpiece lb 35 Max. distance of center of gravity of flying unsupported part of workpiece inch 165 from spindle face Max. workpiece weight clamped between centers lb 100 X-axis travel length inches 7.48 Y-axis travel length (OР.) inches 3.14 (+/- 1.57) Z1-axis travel length inches Z3-axis travel length inches Spindle axis height above floor inches 20.67 21.65 39.26 (38.77+1.18) MAIN SPINDLE Spindle face (flat face ...

CN FAGOR 8055-T Machine equipped with quota viewers, turret 2nd pentagonal wagon Spindle diameter 2,000 mm Maximum turntable height 1,310 mm RAM stroke 1,000 mm Maximum diameter 2,200 mm Spindle Max Speed 150 rpm Nr. 3 wagons type 1 RAM 1 turret 1 side Main engine power 52 kW

Maximum turnerable diameter 1200 mm Maximum permissible diameter 1250 mm Spindle engine power (S1/S6) 55 / 66 Kw Spindle maximum laps 1200 rpm ASA 15" Spindle Attachment Fast speeds 12 m/min X-axis stroke 750 mm Z-axis stroke 750 mm Rated engine torque 20 (X)-20 (Z) Nm Peak engine torque 80(X)-80(Z) Nm Nominal thrust force 1200(X) -120 (Z) N Screw pitch 10 (X) -10 (Z) mm Tools 24 Crown HIRT tool attachment Maximum weight per cell 15 kg Tool change cycle time 10 seconds Maximum weight on tool change ~ 250 Average tool weight ~ 10 Maximum milling tool diameter 150 mm Maximum tool length 350 mm Siemens Sinumerik Control

Ø plateau: 1250 mm Top speed: 500 rpm - 2 ranges Ø false plateau: 1450 mm Maximum piece: 1550 mm Maximum height of the piece: 1200 mm RAM stroke: 800 mm Crossbar stroke: 850 mm Tool warehouse: 10 ATC CNC Siemens 810 D

CNC controller: SIEMENS SINUMERIK 840D-ERGOLINE Capacity X-axis travel mm: 725 Y-axis travel mm: ± 50 Z-axis travel mm: 300 Turning length mm: 160 Max. turning diameter mm: ø: 250 Swing over bed mm: ø: 320 Tool magazine Magazine places: 16 Tool holder: VDI-30 Tool length max. mm: 390 Tool diameter max. mm: 140 Lower turret Number of tool slots St .: 12 Speed driven tools RPM: 4.000 Drive power driven tools kW: 11,7 Milling function: Yes Main spindle Speed spindle rpm: 5.000 Drive power spindle kW: 11,7 (40% ED) Maximun torque Nm: 280 / 360 (100% / 40% ED) Coolant system Tank capacity liter: 980 L High-pressure bar: 8 / 20 Equipment Chip conveyor CE conformity Coolant gun Air blast / coolant switch-over Internal coolant supply Paper band filter Automatic workpiece magazine loader - 16 positions x ø 220 Working time hours ...

Ø board: 1250 mm Maximum turnerable: 1500 mm Useful height: 1355 mm Vertical crossbar stroke: 800 mm Ram vertical stroke: 1000 mm Toolholder number: 15 Table pruned: 12000 kg CNC Tesla NS 642 C Fast: 8 m/min Power: 40 kW Weight: 27.2 ton

Used lathe from Wagner Wagner WDE 500 Lathe, cycle-controlled Only approx. 1700 operating hours Turning diameter 500 mm Turning length 1500 mm Control Siemens 802 C Circumferential diameter over bed carriage 280 mm Spindle bore diameter 82 mm Number of Controlled Axes 2 Speed range 20- 3000 rpm Rapid traverse speed 5 m/min Number of receptacles in the turret 1 Multifix "C" Tailstock Yes MK 5 Drive power 7.5 kW Machine weight approx. 3.0 t Dimensions L x W x H 3.3 x 1.7 x 1.7 m Cycle-controlled CNC lathe in good condition. Accessories: - Coolant device - Basic holder - 3- Jaw chuck - various PARAT tool holders

Ø board: 1,800 mm Maximum working ø: 2,000 mm Max. Turning height: 1,250 mm Max. weight on the table: 15 tons X-axis: 2700 mm Z-axis: 1200 mm Axis C 360 ° Table speed: 3 - 300 rpm Board engine: 60 kw RAM: 250 x 300 mm Work progress: 0 - 2000 mm/min. Nc: FANUC 15 T SERIES ATC: 50 ISO 50 tools Total weight: 58 ton

DATASHEET – RAMO TN20 CNC LATHE Manufacturer: RAMO Industrie SA Model: TN20 Numerical control: NUM 1060 (Telemechanical) Type: Inclined Bench CNC Lathe Condition: Good general condition, visible machine under power ⚙️ TECHNICAL SPECIFICATIONS Power supply: 3 × 400 V – 50 Hz Current rating: 63 A Control voltage: 110 V ~ Signaling voltage: 110 V ~ Lighting voltage: 220 V ~ Clutch voltage: 24 V = MECHANICAL CAPACITIES (TN20 standard) Turning diameter above the bed: 420 mm Turning diameter above carriage: 250 mm Length between toes: 500 mm Z-axis travel: 500 mm X-axis travel: 200 mm Spindle passage: Ø 40 mm Spindle speed: 30 to 4000 rpm Spindle Cone: Camlock D1-4 Spindle motor power: 7.5 kW Fast feeds: 10 m/min (X and Z axis) Tool Turret: 8 automatic positions DIMENSIONS AND WEIGHT Dimensions (W × D × H): app ...

Key data: 420 mm, 650 mm

Machine Type: CNC Lathe Manufacturer: Okuma Type: LB400M-1SC Year of Make: 2000 Commissioning: 2001 Control: OSP-U100L Spindle hours: 14502 hrs Delivery time: in stock Machinery - Interior extraction from Hengst Filtration (built in 2023) - Touchsetter, tool measurement - C-axis (main spindle) - Tool breakage and wear monitoring - 3-jaw chuck, Kitagawa B210, Ø250 - Tailstock available - Coolant supply, also available through the tool - Dialogue programming IGF - Chip conveyor (scraper) Technical details - Max. turning length: 650 mm - Max. turning diameter: 420 mm - X-axis travel: 300 mm - Travel Z-axis: 675 mm - Travel C-axis: 360° - Chuck passage: 72 mm - Spindle passage: 95 mm - Clamping cylinder passage: 95 mm - Tool holder: VDI 40 - Tool stations: Stations 12 - Spindle speed: 2800 rpm - Main spindle power: 22/30 kW - M-spindle ...

Code 71139 DESCRIPTION CNC Center lathe with 2 axis Make P B R Model T 30 SNC x 1500 S/N 30 H / 87 Year 1996 Control Siemens Sinumerik 805 Distance between centers 1500 mm Max. swing 630 mm Max. swing over slide 330 mm Spindle bore 105 mm Spindle speed in 2 ranges stepless ( in program ) 7 – 310 / 44 - 2000 rpm Motor power 15 kW Connected load 33 KVA Machine weight 5500 kg Accessories 8 ATC Duplomatic toolholder R 10 Hydraulic 3 chuck Ø 315 mm 1 fixed steady with 320 mm bore 1 open steady cooling equipment Condition Machine is in good condition

Code 81176 DESCRIPTION CNC Center lathe with 2 axis Make P B R Model T 30 SNC x 3000 S/N 30 – S / 80 Year 1995 Control Heidenhain Manual Plus ( 1998 ) Distance between centers 3000 mm Max. swing 630 mm Max. swing over slide 330 mm Spindle bore 105 mm Spindle speed in 2 ranges stepless ( in program ) 7 – 310 / 44 - 2000 rpm Motor power 15 kW Connected load 33 KVA Machine weight 6000 kg Accessories 3 chuck of 315 mm 1 fixed steady 1 open steady cooling equipment Condition Machine is in good condition

Key data: 370 mm, 600 mm

Machine Type: CNC Lathe Manufacturer: Okuma Type: LU300-2ST Year of Make: 2005 Control: OSP-E100L Delivery time: in stock Machinery  Parts conveyor belt and parts collection tray – workpiece chute with removal conveyor belt incl. electrical kit  2 disc turret with VDI40 (12 + 8 stations)  Power clamping cylinder for hollow chips – Hole in the drawbar 52mm  Extension Kit "D" – Kit one touch IGF-D  Open/close chuck while the spindle is running via M-Code  Reinforced coolant pump 8 bar  Coolant on A and B turrets can be switched via M function  Interface for connecting rod feed  Chip conveyor Technical details  Swing diameter over bed: 530mm  Swing diameter over slide: 380mm  Distance between the tips: 600mm  Max. turning diameter: 370mm  Max. turning length: 600mm  Travel X-axis: upper 260mm  ...

to turn the cans by 180° for example before and after the pasteurizer/can warmer/can coding suitable for all can types: Standard, Sleek, Slim

Key data: 340 mm, 1000 mm

Machine Type: CNC Lathe Manufacturer: Okuma Type: LU15-M Year of Make: 2000 Control: OSP-U100L Country of origin: Japan Delivery time: in stock Long turning length-1000 mm Towable Tailstock – Automatic G152 Partial hollow clamping device The lathe is in very good condition. The basic and additional equipment makes it possible to process long turning lengths of up to 1000 mm with this used machine. Effective productions continue to be achieved thanks to the towable tailstock – automatic, the tool breakage/wear control, the partial hollow clamping device, the K-pump and the dialogue programming (IGF). An optimal machine for economical and reliable production. The machine is user-friendly and can be integrated into production immediately. Machinery Spindle motor VAC built 22/15 kW Long turning length – 1000 mm towable tailstock – automatic G152 3-jaw chuck Forka ...

General Manufacturer: Stama Type: MT 733 two Year of Make: 2020 Control: Siemens Sinumerik 840D SL Travel: X 615 mm Y 290 mm Z 500 mm Rapid traverse: 65 m/min Feed: x 4,000 N / Y 4,000 N / Z 8,000 N Main spindle unit Speed: 12,500 rpm Tool holder: HSK-T63 Pull-in force: 18 kN Spindle bearing diameter: 80 mm Tool magazine Number of available magazine slots: 64 Tool diameter max. when fully equipped: 78 mm Tool diameter max. with free secondary positions: 140 mm Tool length: max. 300 mm Tool holder: HSK-A/T63 Tool weight: max. 10 kg Total chain load: max. 115 kg Rotary swivel unit Swivel angle: +30 to -180° Swivel axis repeatability: ±1" Swivel axis speed: max. 61 1/min Clamping torque tangential swivel axis: 3,000 Nm Clamping torque tangential counter bearing: 1,800 Nm Condition Condition: Used Functional: tested and fully functional

Heid S-200 CNC Lathe Manufacturer: Heid Type: S 200 Machine Type: CNC Lathe Tailstock travel: 175 mm Tailstock quill holder: Morse cone: 4 MK Quill stroke: 140 mm Quill diameter: 95 mm Pressure capacity: 17 kN Connection 50 Hz 3x: 380 Volts Total power requirement: 65 kVA Spindle speeds: Infinitely variable from 0 rpm to: 4000 rpm Spindle bore: 77 mm Tool shank cross-section: 25x25 mm Turning diameter above the bed: 420 mm Turning diameter maximum: 250 mm Turret slide: Longitudinal travel (Z-axis): 1150 mm Flat travel (X-axis): 230 mm More items - new and used - can be found in our shop! International shipping costs on request!
