tr used for sale

General SKU361Y907 LocationBarneveld CEcheck Main Features MaterialHastelloy Motor1.5 KW Inlet diameter25 mm Specified Features - Basket centrifuge Basket centrifugecheck Perforated basketcheck Basket sizesDia 300 x 150 mm Wall thickness3 mm Mechanical operatedcheck Motor1,5 kW (230 V, 2855 rpm (Ex)) With variable speed drivecheck Max. basket speed3500 rpm MaterialStainless steel 2.4602 (Hastelloy C-22) General MakeGFT trenntechnik SerialV 456-00 TypeV 30-0 Year of construction2000 Mounted on framecheck Mounted on wheelscheck With switchcheck With switchgearcheck Floorspace1,40 x 0,6 m Total height1,8 m Weight500 kg Extra information Made of Hastelloy 2.4602 drum housing and lid, diameter 300 x length 150 mm, capacity 5 L, payload 8 kg, filter bag ejection,Basket centrifugesPowdered foodsGeneric medicinesFine chemicalsStarchOther chemicalBiotechnologyAgroc ...

Telescopic roller conveyor / roller telescopic, Budde. for loading and unloading trucks etc. e.g. with tires - used - : Price from location: only 5.950.-€ (net), incl. loading! Manufacturer: Budde Type: TRM03-5 Year of Make: 2015 Machine number: 04764 Length extended: 14m Length retracted: 4.94m Width Wheels 84cm Width: 104cm Works flawlessly Roller conveyor is not driven – works by gravity Stands normally on feet Pull-out is driven, or motorized Condition: good Available: immediately Location: D-66620 Nonnweiler-Otzenhausen A video showing the device in function is available, we will be happy to send it on request, e.g. via WhatsApp

3 x Trumpf bending machines (hydraulic press brakes): • TrumaBend V50 | Year of manufacture 1997 • TrumaBend V85 | Year of manufacture 1997 • TrumaBend V85 S | Year of manufacture 2001 Condition & Maintenance: As can be seen in the attached pictures, all machines were fully serviced as part of the annual UVV inspection. The last inspection took place for all plants in the summer of 2026. The machines are currently still in ongoing production operation and are fully operational.

Trumpf V230 for sale. 4axis plus disposable bending aid

Trumpf bending machine 7036 for sale

Hydraulic control block for Trumpf V130

Hydraulic Control Block For Trumpf V50 For Sale

We sell a Trima K2 head machine in TOP CONDITION

table length: 0600 mm table width: 420 mm table height: 300 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Main spindle: Speed 4,000 rpm Power 18.5 kW Bar passage 65 mm Sub-spindle: Speed 4,000 rpm Power 11 kW Bar passage 65 mm Ejector: Hydraulic with flushing Travel in Z 520 mm Rapid traverse in Z 30 m/min Tool carrier I (X/Y/Z): Technology 10-station turret Tool holder VDI30 Tool drive 4,000 rpm, 4 kW, 16 Nm Travel in X/Y/Z 140/70/450 mm Rapid traverse in X/Y/Z 15/6/30 m/min Tool carrier II (X/Z): 10-station turret Tool holder VDI30 Tool drive 4,000 rpm, 4 kW, 16 Nm Travel in X/Z 140/450 mm Rapid traverse in X/Z 15/30 m/min Equipment/accessories: CNC Control TX 8i Chip management Chip conveyor Coolant management Mahle coolant plant with paper belt filter Bar Feeder, FMB Turbo 8-80 - 3m Length Precast Removal Hydraulic Parts Gripper with Conveyor Belt Oil mist extraction

x-travel: 1.350 mm y-travel: 1.150 mm z-travel: 895 mm a-axis: +16/-120 ° c-axis: 360 ° number of spindle speeds: 24.000 U/min/rpm tool adaptor: HSK-A63 spindle drive: NEW 34 kW table diameter: 1.100 mm table weight: 1.600 Kg Tools changer: 46 fach/tools total power requirement: kW weight of the machine ca.: 19 t dimensions of the machine ca.: 4.590 x 6.990 x 3.150 mm 3-position pallet changer with 1,000 × 840 mm table RENISHAW OMP60 workpiece probe Laser tool measurement system APS – Advanced Process System APS Extended ITS – Intelligent Thermal Control Kinematic options Chip conveyor with TSC (Through-Spindle Coolant) Compressed air supply through the spindle Minimum quantity lubrication (MQL) using oil mist The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

turning diameter: 275 mm turning length: 900 mm control: TRAUB TX8i Main- opposite spindle: spindle passage: 65 mm power capacity at 100 % load: 25,20 kW power capacity at 40 % load: 30,20 KW max. torque at 40% / 100% load: 180 / 135 Nm spindle turning speed - stepless: 1 - 5.000 U/min spindle diameter in front bearing: 110 mm C-axis: 1 - 500 U/min worktool support: No. 1 x-axis: 290 mm y-axis: 165 mm z-axis: 600/950 mm B - axis: 360 ° rapid traverse X/Y/Z: 18 / 18 / 30 m/min feed capacity X/Y/Z: 10 / 10 / 7 kN number of tools: 2x2 + 2x2 number of driven tools: 2x2 + 2x2 mm toolpiece turning speed range: 8.000 / 2.000 U/min power capacity at 25 % load: 5,80 kW max. torque at 25% load: 4x18,6 / 4x74 Nm tool taper: TRAUB Ø60 worktool support: No.2 / No.3 / No.4 x-axis: 170 mm z-axis: 600/950 mm y-axis: +/- 60 mm rapid traverse X/Y/Z: 18 / 15 / 30 m/min feed capacity X/Y/Z: 10 / 10 / 7 k ...

AIRCOOLED CHILLER TRANE CGAM140 SE CPCT 380.9 KW Cooling capacity: 380.9 kW / 108.3 tons (12/7 — 35°C) Year of manufacture: 2018 Refrigerant circuit: 2 pcs. Heat exchanger: Plate Condenser: Copper / Aluminum Compressors: 2 pcs. Danfoss CSHN250K0AK0 (scroll) + 4 pcs. Danfoss CSHN315K0AK0 (scroll) Type of refrigerant: R410A Number of fans: 8 pcs. Dimensions: 4.23x2.28x2.35 m Weight: 3055 kg Working hours: 1046/6424/646/6684/723/705 h. Condition: Good

ID3893 OMP Water treatment / Wasseraufbereitung year/Year of construction 2008 Water treatment Water treatment

Key data: 600 mm, 165 mm

TECHNICAL DATA: Saw blade: Ø 600 mm Cutting height: max. 165 mm Cutting width at the base: 460 mm Installed power: 7.5 kW EQUIPPED WITH: 01 Feeder roller conveyor with air stops: 1900 mm 01 Discharge roller conveyor: 1900 mm

Offered is an extensive machinery package for textile processing, automatic cutting, laser cutting, industrial sewing, die cutting and riveting. 1) CO₂ laser cutting and engraving machine Trotec Rayjet 50 with associated extraction system, working area: approx. 457mm/305mm, laser power: 30W, max. processing speed: approx. 1.5m/s, Aigner/Trotec Atmos Cube extraction system, year of manufacture: 2020, airflow rate: 320m³/h. 2) Single-needle lockstitch flatbed sewing machine with triple feed and large vertical-axis hook Dürkopp Adler 867 ECO, subclass 867-190020-M, max. stitch length: approx. 9mm, clearance: approx. 335mm, clearance height: approx. 125mm. 3) Single-needle high-speed lockstitch sewing machine Juki DDL-9000B-SS, year of manufacture: 2019, max. sewing speed: approx. 5000stitches/min, max. stitch length: approx. 5mm, needle bar stroke: approx. 30.7mm. 4) Single-needle high- ...

AIRCOOLED CHILLER TRANE CGAM140 380.9 KW Cooling capacity: 380.9 kW / 108.3 tons (12/7 — 35°C) Year of manufacture: 2015 Refrigerant circuit: 2 pcs. Heat exchanger: Plate Condenser: Copper / Aluminum Compressors: 2 pcs. Trane CSHN250K0AK0 (scroll) + 4 pcs. Trane CSHN315K0AK0 (scroll) Type of refrigerant: R410A Number of fans: 8 pcs. Dimensions: 4.23x2.28x2.35 m Weight: 3055 kg Working hours: 2171/480/901/5586/1787/2459 h. Condition: Good

AIRCOOLED CHILLER TRANE CGAM 80 SE SQ 217 KW Cooling capacity: 217.0 kW / 61.7 tons (12/7 — 35°C) Year of manufacture: 2017 Options: Hydraulic module. Refrigerant circuit: 2 pcs. Heat exchanger: Plate Condenser: Copper / Aluminum Compressors: 3 pcs. Trane CSHN250K0BKM (scroll) + 1 pcs. Trane CSHN250K0AK0 (scroll) Type of refrigerant: R410A Number of fans: 6 pcs. Hydraulic module: 2 pcs. water pump Wilo DPL65/175(142), expansion vessel, buffer tank 500 l. Dimensions: 4.4x2.3x2.45 m Weight: 2500 kg Working hours: 30882/30124/30723/30428 h. Condition: Good

Working width: 3000 mm working depth: 1200 mm Number of pressing surfaces: 3 Stk. range L-W-H: 4500 x 2200 x 2100 mm Weight: 1500 kg TRIMWEX hydraulische 3 - Etagenpresse Typ SLV - HPR3 - 100 Technische Daten - Arbeitslänge 3000 mm - Arbeitsbreite 1200 mm - Verleimdicke 20 - 100 mm - Anzahl der Ebene: 3 - Verpressung erfolgt mit einseitigem hydraulischen Zylinder - Anzahl der Zylinder pro Ebene 6 - die Druckzylinder sind fest - Zylindertyp Ø 50 x 150 mm - Spezifische Druck 4,5 kg/cm2 - Anzahl der Niederhaltern pro Ebene 4 - jeder Niederhalter hat einen pneumatischen Zylinder - Typ der pneumatische Zylinder Ø 50 x 75 mm - jeder Niederhalter hat eigenes Ventil für Ein/Aus der Luft - Druckregulation mit Regulator - Hydraulisches Aggregat - Pumpendurchfluss 5,5 l - Leistung der Hydromotor 2,20 kW - max. Druck für der Hydromotor 30 - 130 bar - Parkplatz für die Niederhal ...

Cutting set - creel 96x96 mm for Treif Speckschneider Felix 100, Argon, Flexon and Husky Cutting set: 6x6 mm Cutting set: 12x12 mm Cutting set: 20x20 mm Cutting set: 24x24 mm Cutting set: 32x32 mm Strip creel: 4 x 48 mm

Reference ID PP-62886 Category Flatbed Die Cutter Manufacturer Iberica Model TR105F Year Built 2004 Color - Impression - Working Hours - Speed - - Max. size 750 x 1050 mm Min. Size - Condition Good Location Europe Availability Immediately Machine Description 27632 hours Stripping station Max. size: 750 x 1050 mm. Min. size: 350 x 450 mm. Min grammage: 90g/m2 Max. for solid: 1.5 mm. Max. for corrugated: 3 mm. Max. pressure 300 T Max. speed: 9000 ark/h 1 mm. Plates system with micrometric In production

Key data: 800 kW, 600 kg, 500 kW

Sawing area: 6000 x 2500 mm, incl. extraction

AIRCOOLED CHILLER TRANE CGAM 090 SE CPCT 249 KW Cooling capacity: 249.0 kW / 70.8 tons (12/7 — 35°C) Year of manufacture: 2018 Refrigerant circuit: 2 pcs. Heat exchanger: Plate Condenser: Copper / Aluminum Compressors: 2 pcs. Danfoss DSH295A4AB (scroll) + 2 pcs. Danfoss DSH240A4AB (scroll) Type of refrigerant: R410A Number of fans: 6 pcs. Dimensions: 4.2x2.4x2.43 m Weight: 2600 kg Working hours: 16329/16421/9087/9844 h. Condition: Good

Manual trolley, trolley, crane trolley, trolley drive, crane trolley, trolley, girder trolley, monorail trolley, running trolley, trolley, monorail trolley -Manufacturer: Abus, running gear suspension -Type: unfortunately without a type designation -Beam width: up to 265 mm -Load capacity: 580 kg -Dimensions: see photos -Dimensions: 320/210/H165 mm -Weight: 6.4 kg

Manual trolley, trolley, crane trolley, trolley drive, crane trolley, trolley, girder trolley, monorail trolley, running trolley, trolley, monorail trolley -Manufacturer: Demag, running gear chassis -Type: unfortunately without a type designation -Beam width: up to 155 mm -Load capacity: kg -Dimensions: see photos -Dimensions: 250/195/H180 mm -Weight: 9.5 kg

Ref. -No.: 10553 Manufacturer: HANDTMANN / BAVIUS Year of construction: 2014 Type of control: CNC-Steuerung Control: Heidenhain TNC 640 Storage location: Halberstadt Country of origin: Germany Machine-No.: 200XXXXX X-Travel: 1270 mm Y-Travel: 1100 mm Z-Travel: 900 mm Table Height: Ø 1200 mm Table Load: 2000 kg Max. Tool Weight: 20 kg Max. Tool Length: 90 x 200 / 24 x 400 mm Max. Tool Diameter: Ø 130 mm Tool Taper: HSK 100 Numbers Of Tools In Magazin: 40 Tool Piece Magazine With: 140 Pcs./pcs. Spindle Turning Speed - Stepless: 14.000 RPM Max. Torque: 15000 Nm Rapid Traverse X-Axis: max. 60 m / min Rapid Travel Y-Axis: max. 60 m / min Rapid Traverse Z-Axis: max. 60 m / min Machine length: 7500 mm Machine width: 5500 mm Machine Height: 3500 mm Weight Of The Machine Ca.: 26 t Rapid traverse C-axis: max. 25 RPM Rapid traverse A-axis: max. 20 RPM A-axis (swivel axis): - 30 / + 120 ° C-axis  ...

Ref. -No.: 10621 Manufacturer: PAMA Year of construction: 2008 Type of control: CNC-Steuerung Control: SIEMENS SINUMERIK 840 D PL Storage location: Halberstadt Country of origin: Italy X-Travel: 3500 mm Y-Travel: 2500 mm Z-Travel: 2200 mm W-Axis: 800 mm Bore Spindle Diameter: 160 mm Table Load: 12000 kg Tool Taper: ISO 50 BIG PLUS Turning Speeds: 3500 RPM Max. Torque: 2.765 Nm Rapid Travel X/Y/Z: 25000 mm / min Drive Capacity - Spindle Motor: 46 kW Internal cooling: 15 / 45 bar External cooling: 50 / 4 bar Table surface: 1600 x 2000 mm Spindle speed gear stage 1: 2.120 1 / min Spindle speed gear stage 2: 2.765 1 / min Further information: Automatic tool changer SK50 DIN 69871, 80 positions. Automatic angle milling head TS 35 with 360 positions, speed 2,000 rpm and torque 2,000 Nm. Automatic universal milling head TU25C (2-axis), speed 3,000 rpm and torque 800 Nm. Automatic accessory chan ...

Internal cylindrical grinding machine, Tripet Swiss, 1991, Grinding slide. 0.5 - 30mm, Grinding depth: 50, Center height: 102, Axles: Z , Y, U, B, V, , autom. Chuck, ...

6x Cloos Qineo Tronic 450 MIG/MAG welding machines, 1x Cloos GLC 451-C welding machine and 1x Cloos GLC 553/MC3 welding machine are available, 1) 6x Cloos Qineo Tronic 450 MIG/MAG welding machines, welding current: 40-450A, welding current at 60% duty cycle: 450A/36.5V, welding current at 100% duty cycle: 350A/31.5V, open-circuit voltage: 77-98V, mains voltage: 380-480V/50Hz/3-phase, power cable: 4x6mm², mains fuse protection: 400V/32A, protection rating: IP23, insulation class: F, cooling method: F, dimensions (without wire feeder): 1011x517x703mm, weight (without wire feeder): 88kg, year of manufacture: 5x2017, 1x2016, 2) 1x Cloos GLC 451-C welding machine, year of manufacture: 2003, 3) 1x Cloos GLC 553/MC3 welding machine, year of manufacture: 2008, additionally, 21 welding torches with long torch necks, 12x500mm, 4x600mm, 5x1500mm, and 53 FKS400 Autogen Ritter welding torch hose ass ...

Laser power: 45W, laser wavelength: 10.6µm, supply voltage: 230V, frequency: 50/60Hz. Including Aigner/Trotec Atmos Cube Speedy extraction system, year of manufacture: 2021, airflow rate: 320m³/h, negative pressure: 8500Pa, power consumption: 1.2kW, operating hours of the extraction system according to the display: approx. 296h, as well as additional accessories. The machine is in excellent condition and has very few operating hours. Inspection possible by appointment.

Standard configuration Machine ⦁ C frame ⦁ Press beam ⦁ Spherical bearing of the press beam with press beam tilting ⦁ On-Demand Servo Drive with 4-cylinder technology ⦁ Distance measurement system (Y axis) with dynamic deflection compensation ⦁ Hydraulic oil filling (life-long filling) ⦁ Extension of the open height/stroke Backgauge ⦁ Gauge fingers (2 pieces) Tool clamp ⦁ TRUMPF hydraulic lower tool clamp Control ⦁ Touchpoint TruBend machine control ⦁ Integrated TRUMPF technology data ⦁ 21.5 touchscreen ⦁ User management system Data transmission ⦁ USB interface ⦁ RJ45 network interface ⦁ Network capability ⦁ Central Link ⦁ Remote support interface Operation ⦁ Operating unit with foot switches ⦁ Communications rail ⦁ MobileControl Safety ⦁ CE marking ⦁ Standard safety device ⦁ Lateral sliding doors ⦁ Rear roller gate Advanced stan ...

Standard configuration Machine ⦁ C frame ⦁ Highly dynamic electromechanical direct drive ⦁ Electrical cabinet air conditioning up to an ambient temperature of 40 °C Backgauge system ⦁ 6-axis backgauge (X1, X2, R1, R2, Z1, and Z2 axes) with backgauge sensor system Tool clamping system ⦁ Segmented Wila tool clamps without Tool Identification System (TIS) Control system ⦁ Machine control with touch operation ⦁ Mobile operator terminal Operation ⦁ Lighting integrated in safety fencing Data transmission ⦁ USB interface ⦁ RJ45 network interface ⦁ Network capability ⦁ Remote support interface Bend Master (15) ⦁ Stable base body and manipulator ⦁ Floor track ⦁ Electric drives ⦁ Gripper coupling on the BendMaster ⦁ Pivoting-jaw gripper with jaws LoadMaster Bend ⦁ Handling system ⦁ Multi-suction device with bellows suction cups ⦁ Double sheet de ...

Standard configuration Machine ⦁ Box frame ⦁ Hybrid axis system ⦁ Linear magazine with 20 stations for clamps and tools ⦁ Hydraulic clamps (2 pcs.) ⦁ Drives with maintenance-free three-phase motors ⦁ Repositioning device with programmable presser foot ⦁ 1st index pin (right inner) ⦁ Foot switch for closing clamps ⦁ Part chute, right including good parts container ⦁ Part flap, left with sensor ⦁ Stripper monitoring ⦁ Brush tables with loading and unloading aid Safety ⦁ CE marking according to the Machinery Directive ⦁ Three-beam safety light barrier Punching head ⦁ Delta Drive ⦁ Rotary single station tool adapter ⦁ Programmable presser foot position ⦁ Tool length compensation ⦁ Punch spray lubrication ⦁ Punching slug vacuum ⦁ Forming function ⦁ Punch stroke counter Control ⦁ TRUMPF control based on Rexroth IndraMotion MTX ⦁ Touchpoint p ...

Key data: 170 t

Trumpf Press Brake Trumabend V170, 1700KN, Stroke: 365,. L-530cm, W- 240cm, H-300cm, Weight: 18to,

Key data: 170 t

Trumpf Press Brake Trumabend V170, 1700KN, Stroke: 365,. L-530cm, W- 240cm, H-300cm, Weight: 18to,

The machine is in good technical condition; it can be tested by prior arrangement.

The machine is in good technical condition; it can be tested by prior arrangement.

Technical data: Manufacturer: trotec Type: SpeedMarker 700 SZ SX Year of Make: 2019 Laser Laser Type: FL 20 MOPA Max. average output power: 20 W Max. pulse energy: 1 mJ Laser diode:

tube: 4500 mm : 76,1 x 4,0 mm : 200 mm total power requirement: 3,5 kW machine weight ab.: 1.500 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Qty. 1 Second-hand Vertical Aluminium Profile Powder Coating Line Mfc.: TRASMETAL, GEMA & SIEMENS Built: 1992 The pistol range converted by TREVISAN in 1996 Full refurbished of the pretreatment section by TREVISAN in 2017 The system described here is used for vertical powder coating of aluminum profiles Parts to be treated: Aluminum profiles with 6.5 m Production performance: about 400 profiles/hour Hanging distance: 150 mm Speed considered: 1 m/min for normal profiles The system design has been taken into consideration average values. Weight 5 Kg/profile (7m). The maximum profile section to be treated is 240x120 mm. The oven is still in almost its original condition, while all other components, such as the transport system, the transport chains, the painting booth and the coating technologies, as well as the pre-treatment and final treatment line, have been constantly optimi ...

CONTROLS   electronic controls SITEC/TRUMPF system: - Laser welding system with rotary table, 2 units per side - Laser welding with Trumpf BEO D 70 welding optics - Beam guidance via laser light cable (LLK) - Inline laser monitoring system for weld seam monitoring - Weld penetration depth: 1.5 mm - Shielding gas welding possible! For aluminum or stainless steel

Quick-change tool holder, tool holder head, quick-change tool holder, quick-change boring bar holder, quick-change boring bar holder, quick-change turning tool holder -Quick-change tool holder: Quick-change turning tool holder -Type: M10 tool holder H30 x 145 mm -Recording dimensions: see photos -Number: 2x steel holders available -Price: per piece -Dimensions: 90/145/H100 mm -Weight: 3.0 kg

Quick-change tool holder, tool holder head, quick-change tool holder, quick-change boring bar holder, quick-change boring bar holder, quick-change turning tool holder -Quick-change tool holder: Quick-change turning tool holder -Type: Tool holder H18 x 90 mm -Recording dimensions: see photos -Number: 4x steel holders available -Price: per piece -Dimensions: 90/40/H85 mm -Weight: 0.8 kg

Quick-change tool holder, tool holder head, quick-change tool holder, quick-change boring bar holder, quick-change boring bar holder, quick-change turning tool holder -Quick-change tool holder: Quick-change turning tool holder -Type: 331 -Recording dimensions: see photos -Number: 12x steel holders available -Price: per piece -Dimensions: 120/40/H105 mm -Weight: 1.4 kg/pc.

Quick-change tool holder, tool holder head, quick-change tool holder, quick-change boring bar holder, quick-change boring bar holder, quick-change turning tool holder -Quick-change tool holder: Quick-change turning tool holder -Type: 332 -Recording dimensions: see photos -Number: 2x steel holders available -Price: per piece -Dimensions: 120/90/H100 mm -Weight: 2.4 kg/pc.

Quick-change tool holder, tool holder head, quick-change tool holder, quick-change boring bar holder, quick-change boring bar holder, quick-change turning tool holder -Quick-change tool holder: Quick-change turning tool holder -Type: 232 SP -Recording dimensions: see photos -Quantity: 1x steel holder available -Dimensions: 80/60/H85 mm -Weight: 0.9 kg

turning diameter:1600 mm turning length:12000 mm control:FAGOR 8050 Used CNC Lathe with FAGOR 8050 and extensive accessories. For further technical data and accessories, pls browse the Appendix. Parallellathe WMW mod. 4 GUIDE-WAYS ¦ CNC: FAGOR 8050 ¦ bed: monolithic ¦ centres height: 800 mm ¦ centres distance: 12000 mm ¦ swing over cross-slide: 1250 mm ¦ turret: automatic 4 positions ¦ tailstock: motorized ¦ tailstock connection: hydraulic ¦ platform: diam. 1000 mm ¦ steady rests: nr.02 ¦ chip conveyor Warranty: none Take advantage of the favorable leasing and hire-purchase terms from IKB Leasing. Ask us about it.

length:12192 mm width:2438 mm height:2896 mm weight:4580 kg Total weight:34000 kg charge:29420 kg Cooling Container Internal dimensions: Length 11585mm Width 2290mm Height 2545mm Pallet spaces 23

tube diameter:40-90 mm wall strength:20 mm weight of the machine ca.:11 t dimensions of the machine ca.:4 x 1,6 x 1,35 m bending radius max.:270 mm This machine is a mandrel bending machine that was designed exclusively for the production of pipe bends with pipes of 40 mm ? 90 mm outer diameter with a maximum wall thickness of 20 mm or for processing solid materials up to 70 mm outer diameter (max. section modulus 64.7 cm³) and is therefore intended only for this purpose. Scope of delivery, machine equipment, basic equipment ? Pipe length/usable length for mandrel bending: 3000 mm ? Radius range max. 270 mm ? Bending height 1050 mm ? Electro-hydraulic drive ? Clockwise bending direction ? With hollow shaft to achieve small radii ? Counter bearing rotates ? Rotates up to 180 degrees with a maximum tool radius of 270 mm ? Forward movement controlled via hydraulic cylinder with pressure va ...

turning diameter:275 mm turning length:900 mm spindle passage:65 mm power capacity at 100 % load:25/20 kW spindle turning speed range:1 - 5000 U/min spindle diameter in front bearing:110 mm c-axis:1 - 500 U/min. number of workpiece supports:4 tool turret:1 x-axis:290 mm y-axis:165 mm z-axis:360 mm b-axis:360 ° rapid speed:18/30 m/min number of tools:2x2 + 2x2 number of driven tools:2x2 + 2x2 mm toolpiece turning speed range:8000 / 2000 U/min power capacity:25% ED 5,8 kW tool taper:TRAUB 60 tool turret:2/3/4 x-axis:170 mm z-axis:600/950 mm y-axis:+/- 60 mm rapid speed:18/15/30 m/min number of driven tools:10 mm toolpiece turning speed range:1 - 6000 U/min power capacity:25% ED 5,8 kW tool taper:DIN 69880 40 x 63 total power requirement:95 kW weight of the machine ca.:16 t dimensions of the machine ca.:10,0 x 3,5 x 3,0 m with CNC TRAUB TX 8i, Barloader TRAUB Stamag DNH61 / 3000, Main and  ...
