CNC Turning Machines STYLE 750

The machine is in good technical condition, testing is possible after prior agreement. The machine was installed in 07/2023 and was used very little. The machine was switched on for 3900 hours, of which 540 hours the spindle was running. Swing diameter over bed mm 750 MACHINE SPECIFICATIONS STYLE 750 Machine STYLE 750 Swing diameter over bed mm 750 Swing diameter over slide mm 530 Distance between centers mm 4000 Bed width mm 450 Maximum load between centers kg 1800 Maximum load in combination with fixed steady rest (type U) kg 2500 Main spindle Main motor power (S6) kW 26 Maximum spindle speed (number of gears) rpm 2000 (3) Spindle bore mm Ø105 Spindle taper A2-11 X and Z axis X axis ball screw Ø mm 32 Z axis ball screw Ø mm 50 Rapid traverse m/min 8. Feed range mm/min 0.01-2000 Tailstock Ø quill mm 125 Quill stroke mm 225 Quill taper MT 6 General Weight kg 8150 Machine color Frame RAL 7021 Sheet RAL 9006 Machine dimensions m 6.3/2.3/2.2  The machine will be delivered including: - Machine lighting: LED - Cooling - Automatic lubrication - Steel ball screw covers - Full coverage - Sliding door in the front of the machine - Electronic handwheel - Constant cutting speed, chip conveyor belt  and including additional accessories: - Automatic tool changer, 8 positions, VDI-50 - More massive tailstock, desktop version SW - 26 kW main motor, Handwheel, Oil separator - Steady rest D50-300mm, Steady rest D60-400mm - Coolant pump switch - 3 jaw chuck D315 – Schunk Rota S Plus2.0 - Speed potentiometer - LED lamp, LAN, stronger cooling with gun Swing diameter above the slide mm 530 Distance between centers mm 4000 Bed width mm 450 Maximum load between centers kg 1800. Maximum load in combination with fixed steady rest (type U) kg 2500 Main spindle Main motor power (S6) kW 26 Maximum spindle speed (number of gears) rpm 2000 (3) Spindle bore mm Ø105 Spindle taper A2-11 X and Z axis X axis ball screw Ø mm 32 Z axis ball screw Ø mm 50 Rapid traverse m/min 8 Feed range mm/min 0.01-2000 Tailstock Quill Ø mm 125 Quill stroke mm 225 Quill taper MT 6 General Weight kg 8150 Machine color Frame RAL 7021 Sheet metal RAL 9006 Machine dimensions m 6.3/2.3/2.2 Ø The machine will be delivered including: - Machine lighting: LED - Cooling - Automatic lubrication - Steel ball screw covers - Full enclosure Sliding door in the front of the machine - Electronic handwheel - Constant cutting speed, chip conveyor belt Ø and including additional accessories: - Automatic tool changer, 8 positions, VDI-50 - More massive tailstock, desktop version SW - 26 kW main motor, Handwheel, Oil separator - Steady rest D50-300mm, Steady rest D60-400mm - Coolant pump switch - 3-jaw chuck D315 - Schunk Rota S Plus2.0 - Speed potentiometer - LED lamp, LAN, stronger cooling with gun
seller offer No. resale 31830
