straightening press used for sale

Key data: 3 mm, 3000 mm, 130 m/min

One used Ravni starigtening and cutting machine for 3.0 to 8.0mm wire. Cutting length: 3.000mm Machine is equipped with double pay off for 3 t spools and dust abstructor Year: 2014

Pressing force: 5000kN, max. operating pressure: 500bar, portal clearance: 2600mm, opening height: 470mm, max. straightening ram stroke: 500mm, min. edge distance: 375mm, rapid traverse: 450mm/min, straightening speed: 45mm/min, return speed: 1100mm/min, feed rate: 12m/min, max. feed force: 5000kN, table height: 1000mm. Machine dimensions X/Y/Z: approx. 4600mm/3250mm/3250mm, weight: approx. 32000kg. Documentation available. An on-site inspection is possible.

Offered is a straightening machine with cold rolling unit. 2-fold wire coil payoff, installed are: GSG COMBI rolling stand year 1994, GSG KWG.3 rolling stand year 1991, roller driver GSG ERT year 2007, straightening and cutting unit Wafios RBK51M year 2000, wire drawing unit 1 pass, wire diameter 6.0mm-12.0mm, max. speed 120m/min, min. cutting length 1600mm, cutting rate up to 80cuts/min, inlet strength approx. 50daN/mm². Package dimensions for finished material up to max. 14000mm length, up to 1000 bars per bundle. Length of the system approx. 5000mm. The system is offered without safety fence. Viewing possible by arrangement.

Wire diameter range: 2.5 - 7.0 mm Section lengths: max. 4,000 mm Feed speed; 40 - 80 ntr/min complete with non-driven wire reel

Wire gauge range: 1.5 - 7.0 mm Section lengths: max. 1,000 mm Feed speed: 29 - 90 mtr./min

Wire gauge range: 1.5 - 7.0 mm Section lengths: up to 8,000 mm Feed speed:

Sheet width - max.: 200 mm Straightening roller diameter: 40 mm Number of leveling rollers: 5 Driven infeed and outfeed rollers Sheet thickness - min: 0.4 mm Sheet thickness - max.: 2.0 mm Weight: 170 Infinitely variable feed speed Clockwise and counterclockwise rotation Operating mode selector switch for manual and automatic operation Belt loop control very good condition

Ungerer 1800 x 5 mm Max sheetwide: 1800 mm Max sheetthickness: 0,7 > 5 mm Max speed: 16 m/min Number of flattingcoils: 9+8 rolls (dia 55 mm) Power : 28 HP Weight: 9,7 ton

Dimeco afwikkel-/terugwikkelapparaat Dimeco microvoeder - maximale breedte: 815 mm - maximale dikte: 3,5 mm

Ungerer RP 1500 x 3 mm Max sheetwide: 1500 mm Max sheetthickness: 3 mm

A Wafios wire straightening and cutting machine with a straightening attachment of 1000mm is available. Wire diameter range: 1.5mm-7mm, cutting length range: 20mm-3000mm, straightening rotor speed: 6800rpm, pitch: 71/69, cutting stroke: 270/min, machine dimensions X/Y/Z: approx. 3300mm/1200mm/1800mm, weight: approx. 1400kg. An on-site inspection is possible.

double wire processing diameter range 0,8-2 mm cutting length 1000 mm speed - meters/min 80

diameter range 4-10 mm cutting length 3000 mm speed - meters/min 130

diameter range 7-14 mm cutting length 3000 mm speed - meters/min 90

diameter range 5-13 mm cutting length 2000 mm speed - meters/min 21 - 90

diameter range 3-10 mm cutting length 2000 mm speed - meters/min 22-71

diameter range 1-8 mm cutting length 3000 mm speed - meters/min 13-56

flying shears diameter range 8-16 mm cutting length 520-6000 mm speed - meters/min 25-75 diameter range 8-14 mm

diameter range 1,5-7 mm cutting length 2000 mm speed - meters/min 90

wire diameter range 1,5-7,0mm cutting length 3000 mm speed - meters/min 5-120

diameter range 3-10 mm cutting length 2000 mm speed - meters/min 120

Container rotating device, welding rotating device, roller stand, rotators, pipe straightening system, shaft straightening system -Pipe straightening system for: steel pipes or shafts, flame straightening with water cooling -Drainage channel and water pump -2x: Counter-holder prism -Counter bearing: adjustable -Dimensions: 4000/870/H810 mm -Empty weight: 500 kg

Straightening machine, wire straightening machine, unwinder, straightening machine combination, pay-off reel, wire unwinder, double reel, reel, pay-off reel, motor-driven reel for wire processing, punch, eccentric press, hydraulic press, punching machine, motor reel, winding roll, unwinder, wire unwinder -Wire straightening machine: decoiler-straightener combination -Type:not visible -Note: without documentation -Engine: Fukota 1.5 kW -Straightening rollers: for Ø 20 mm, see photos -Receiving rollers: Ø 152/215 x 1330 mm -Total dimensions: 3040/2450/H2525 mm -Weight: 2080 kg

sheet width:2000 mm plate thickness:1.8 mm Controls:SIEMENS S7 PRESS DESIGN:. - frame design : H-frame :. - openings in uprights : yes :. - opening in table : yes :. - moving bolster : yes :. PRESS TABLE:. - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - height above floor level:375 mm RAM:. - ram force:800 to - clamping surface (left-right):2800 mm - clamping surface (front-back):2800 mm - stroke:350 mm - number of strokes max:55 /min RAM (MECHAN. PRESS):. - ram adjustment:350 mm TOOL ASSEMBLY DIMENSIONS:. - shut height (stroke down, adjustment up):1100 mm - distance between columns (H-frame):3100 mm - Free passage between side columns (width):2560 mm - Free passage between side columns (height):1500 mm DECOILER:. - design : single coil :. - sheet width max:2000 mm - sheet width (min):400 mm - max. weight of coil:30 to - max. diamet ...

band width:1050 mm plate thickness:8 mm number of rolls:8 DECOILER:. - design : single coil :. - sheet width max:1050 mm - sheet width (min):150 mm - max. weight of coil:22 to - max. diameter of coil:2000 mm - min. internal diameter of coil:570 mm FEEDERS:. - feeder: type : roll feeder :. - sheet width max:1050 mm - sheet thickness max:150 mm LEVELER UNIT:. - sheet width max:1050 mm - sheet width (min):150 mm - sheet thickness max:8 mm - sheet thickness (min):2.5 mm - number of leveler rolls:8 - diameter of leveler rolls:96 mm - distance between leveler rolls:104 mm - diameter of feed rolls:160 mm - feed velocity min.:2 m/min - feed velocity max.:43.5 m/min ELECTRICAL SPECIFICATIONS:. - mains voltage:400 V - mains frequency:50 Hz Technical description : Sheet metal unrolling and straightening system for thick sheet metal up to 8 mm, consisting of: - LAWECO COIL LOA ...

band width:2000 mm plate thickness:1.8 mm number of rolls:13 Controls:SIEMENS DECOILER:. - design : single coil :. - sheet width max:2000 mm - sheet width (min):400 mm - max. weight of coil:30 to - max. diameter of coil:2000 mm - min. internal diameter of coil:610 mm FEEDERS:. - sheet width max:2000 mm - sheet thickness max:2 mm - feeding step max.:4000 mm LEVELER UNIT:. - sheet width max:2000 mm - sheet width (min):400 mm - sheet thickness max:1.8 mm - sheet thickness (min):0.6 mm - number of leveler rolls:13 - diameter of leveler rolls:50 mm

material width:180 mm coil weight:0,75 t material thickness:2,0 - 6,0 mm coil external diameter:400 - 1250 mm no. of straightening rolls:5 number of draw-in rolls:2 band speed:20 m/min power requirement:4,0 kW weight:2,8 t dimensions (WxDxH):1,4 x 2,45 x 1,85 m snubber roll:pneumatic

material width:500 mm coil weight:2 x 2,0 t material thickness:1,0 - 6,0 mm coil internal diameter:350 - 420 mm coil external diameter:1600 mm no. of straightening rolls:9 straightening roll diameter:50 mm number of draw-in rolls:2 speed:0 - 40 m/min material thickness at 500 mm material width:3,5 mm power requirement:17,5 kW Dimensions (WxDxH):2,3 x 4,2 x 2,4 m straightening machine:RM 5050.4/9 double decoiler:AH 2000/2/M snubber roll:pneumatic interchangeable jaws:130 mm expansion of the inner diameter

material width:800 mm coil weight:12,0 t coil internal diameter:470 - 520 mm coil external diameter:1500 mm material thickness:0,4 - 2,5 mm no. of straightening rolls:8 straightening roll diameter:53 mm number of draw-in rolls:2 inlet roll diameter:160 mm speed:35 m/min material thickness at 150 mm material width:2,5 mm material thickness at 650 mm material width:1,5 mm material thickness at 800 mm material width:1,0 mm straightening machine:RM 8-53/160-800 decoiler:HE 200-1000

material width:250 mm coil weight:2,5 t coil internal diameter:430 - 520 mm coil external diameter:1650 mm material thickness:0,5-6 mm no. of straightening rolls:7 straightening roll diameter:60 mm number of draw-in rolls:2 weight straightener:1,2 t weight decoiler:1,4 t dimensions straightener (WxDxH):1,2 x 1,2 x 2,0 m dimensions decoiler (WxDxH):1,8 x 1,8 x 2,3 m expansion:hydraulic

material width:450 mm material thickness:1,0 - 14,0 mm coil weight:10,0 t coil internal diameter:470 - 520 mm coil external diameter:1100 - 2000 mm no. of straightening rolls:12 straightening roll diameter:2x70 / 2x96 / 8x127 mm number of draw-in rolls:2 inlet roll diameter:160 mm min. material width:100 mm speed:15 m/min power requirement:75,0 kW weight of decoiler:6,4 t weight of straightening machine:12,8 t dimensions decoiler (WxDxH):3,1 x 1,4 x 3,7 mm dimensions straightener (WxDxH):2,5 x 3,4 x 2,7 mm straightening machine:RMS-Vario-12-70/96/127-0450 infinitely variable drive:insert drive upper straightening part:hydraulic liftable loop bridge:hydraulic driven threading wedge:hydraulic decoiler:HES 12-650 infinitely variable drive:insert drive lag brake:pneumatic snubber roll:hydraulic; motoric driven expansion:hydraulic coil lifting device:hydraulic cropping shears:HS-150-0450

material width coil line:600 mm coil weight in kg:2 x 3000 kg coil internal diameter:460 - 630 mm coil external diameter:1500 mm material thickness coil line:0,5 - 3,0 mm Number of Straightening rolls:9 roll diameter:30 mm material cross-cut:1200 mm² weight:9,5 t Dimensions (WxDxH):4,3 x 2,6 x 2,6 m straightening machine:30.600/9 double decoiler:Kohler, 3000.2 ausiliary drive:hydraulic lag brake:pneumatic expansion:hydraulic snubber roll:hydraulic; motoric driven

Pneumatic press, pneumatic press BOSCH type 0840 002 002Fabr. No. 041 Year of construction 1980Compressive force 18 KN = 1,8 ton. at 5 bar 15 kN = 1.5 ton. at 4 bar 12 kN = 1.2 ton. at 3 bar 8 kN = 0.8 ton. at 2 bar 6 kN = 0.6 ton. at 1.8 barprojection 100 mmram stroke 70 mmtable surface 245 x 200ram area 45 mminstallation height max. 235 mmClamping pin hole 20 mm with clamping screwCompressed air requirement 5 bar- Press force infinitely adjustable via pressure regulator- Pneumatic cylinder with plunger

used membrane chamber filter press / filter press Passavant Noggerath 1200 x 1200 frame size: K1200 / 110 format of the filter records: 1200x1200 execution: unanimously (filtrate derivation by a collective management) material of the filter records: PP material of the membrane records: PP number of the filter chambers: 100 max. / 33 strength of the filter cake: 30 mms mix pack filtration surface: 230 max. / 76m? filtration volumes: 2985 max. / 985 litres filtration pressure in the chambers: 8 cash max. pressure under the membrane: 15 cash max. temperature with filtration: 20 °C max. material of the filter cloth: PP working pressure in the hydraulic cylinder: 400 cash max. dimension of the chamber filter press: Length: 9,786 mms, width: 2,550 mms, height 2,100 mms weight of the chamber filter press without mud: 18,210 kg of MAX hydraulic oil: OH-HM 32  ...

Used chamber filter press / filter press Rittershaus & Blecher / R & B 800 x 800 Plate size: 800 x 800 mm Chamber number: 100 pieces Filter pressure: 15 bar

If mobile chamber filter press / used filter press Filox 800 x 800 construction year: In 1980 record format: 800 x 800 mms benefit length: 5,200 mms chamber number: 88 pieces cake thickness: 25 mms filter pressure: 15 cash Schliessdruck: Min 300 cash, max. 320 cash whole filter surface: approx. 98 square metres cake volumes ges .: approx. 1,100 litres engine tension: 380 V, 50 hertz protective kind: IP 44 record material: PP expiry: openly service side: on the left cloths: Optionally

Used chamber filter press / filter press Rittershaus & Blecher / R & B AEHIS /1200 x 1200 Plate size: 1200 x 1200 mm Useful length: 2500 mm Chamber number: 44 pieces Cake thickness: 30 mm Filter pressure: 16 bar Closing pressure: min. 380 bar / max. 440 bar Total filter area: 110.5 m2 Cake volume totalling: 1504 litres

Chamber filter pressing rack Filox uses 1200 x 1200 with approx. 100 records

Used chamber filter press / filter press Rittershaus & Blecher / R & B 1500 x 1500 Plate size: 1500 x 1500 Useful length: 9000 mm Chamber number: 129 Cake thickness: 30 mm Filter pressure: 16 bar Closing pressure: 380 bar Test pressure: 440 bar Operating temperature: 50 C Total filter area: 460 m2 Cake volume totalling: 6.2 m3 Motor voltage: 380 volts Plate material: PP Operation page: Right and left Plate transport: fully automatic

Used membrane filter press / filter press Rittershaus & Blecher / R & B 1200 x 1200 (Mix) Plate size: 1200 x 1200 mm Membrane plates: 54 pieces Chamber plates: 55 pieces Membrane pressure: 15 mm Filter pressure: 10 bar Closing pressure: min. 350 bar, max. 380 bar Total filter area: 242 m2 Cake volume totalling: 4320 litres Number of filter presses: 2 pieces

Used chamber filter press / filter press Rittershaus & Blecher / R & B AEH 800 x 800 Plate size: 800 x 800 mm Useful length: 3500 mm Chamber number: 64 pieces Cake thickness: 20 mm Filter pressure: 15 bar Closing pressure: Min. 240 bar / max. 300 bar Total filter area: 64 m2 Cake volume totalling: 640 litres

Used chamber filter press / filter press Rittershaus & Blecher / R & B 1500 x 1500 Plate size: 1500x1500mm Cake thickness: 30 mm Useful length: 6065 mm Chamber number: 80 pieces Total filter area: approx. 320 m2 Filter cake volume: approx. 4 m3 Filter pressure: 15 bar Closing pressure: min. 300 bar / max. 400 bar Expiration: closed Plate material: PP

Used chamber filter press / filter press Rittershaus & Blecher / R & B 1200 x 1200 Plate size: 1200x1200mm Cake thickness: 30 mm Useful length: 3500 mm Chamber number: 58 pieces Filter pressure: 15 bar Closing pressure: min. 300 bar / max. 400 bar Total filter area: approx. 1.8 m3 Expiration: closed Plate material: PP Filter cloth cleaning system: optional Filter cloths: optional

used chamber filter press / filter press Passavant A 1500 record size: 1500 x 1,500 mms benefit length: 10,510 mms chamber number: 160 pieces cake thickness: 30 mms cake contents: 8.4 m3 filter pressure: 16 cash Schliessdruck: 380 volts expiry: unanimously whole filter surface: 614.5 m² engine tension: 380 volts / 50 hertz

Used chamber filter press / filter press Rittershaus & Blecher / R & B 500 x 500 Side holm guided Plate size: 500x500mm Cake thickness: 25 mm Useful length: 2200 mm Chamber number: 47 pieces Filter pressure: 15 bar Closing pressure: min. 220 bar / max. 260 bar Cake volume: approx. 3.9 m3 Total filter area: approx. 17.4 m2 Expiration: closed Plate material: PP Plate transport: manual Filter cloths: optional Pump: Abel diaphragm pump optional

Used membrane filter press / filter press Rittershaus & Blecher / R & B 1200 x 1200 Plate size: 1200x1200mm Cake thickness: 40 mm Useful length: 5300 mm Number of plates: 71 pieces Filter pressure: 8 bar Membrane pressure: 15 bar Expiration: closed Plate transport: automatic Filter cloth cleaning system: yes Filter cloths: optional Membrane mix package incl. control cabinet, filling pumps, membrane pressure pumps The facility is in very good condition.

used chamber filter press / filter press Netzsch 1200 x 1200 record size: 1200x1200mm cake thickness: 30 mms benefit length: 8,200 mms chamber number: 120piece filter pressure: 15 bars record transport: at the side automatically

Used chamber filter press / filter press Rittershaus & Blecher / R & B 1200 x 1200 Plate size: 1200x1200mm Cake thickness: 30 mm Useful length: 5300 mm Number of plates: 72 pieces Filter pressure: 15 bar Expiration: closed Plate material: PP Filter cloth cleaning system: optional Filter cloths: optional

Used chamber filter press / filter press Rittershaus & Blecher / R & B 2000 x 2000 Plate size: 2000x2000mm Cake thickness: 20 mm / 30 mm Useful length: 12000 mm Chamber number: 121 units Filter pressure: 15 bar Closing pressure: min. 300 bar / max. 320 bar Cake volume: approx. 8.1 m3 Expiration: closed Plate material: PP
