stork bepak used for sale

A complete bottle filling, sterilizing, capping, labelling, cartoning and palletizing line for the wine industry is available. Bottle filling capacity: 4000 bottles/h, bottle format sets: 1l and 0.75l Schlegel/Bordeaux/Bugunder/0.5l/0.25l, sterilizer capacity: 4000 bottles/h, capper capacity: 8000 bottles/h, labelling capacity: 10000 bottles/h, capping capacity: 10000 bottles/h, carton formats: 12 and 6-bottle crates/12 and 6-bottle cartons, palletizing capacity: 1000 cartons/h. Line components: 1) Normpack Compact Form CF 670/980 carton folding machine, year of manufacture: 2000, output: approx. 650 cartons/h, 2) Stork VV-24 L.W. bottle filling machine, Year of manufacture: 1977, 3) Silmo ST XII/110 v ozone immersion bath sterilizer, year of manufacture: 1983, bottle formats: all standard wine bottles, 4) Miho LC 2000 caustic tester, year of manufacture: 2003, 5) Kapsler Robino & Galand ...

1) Eccentric screw pump Johstadt AFJ 70.1 S, year of manufacture: 2011. 2) Eccentric screw pump Johstadt FJ 70.1 S, year of manufacture: 2015. 3) Eccentric screw pump Stöber/HEW/Netzsch DC30-2061-200-U/EEXF100L/U/NE40B, year of manufacture: 1989. 4) Centrifugal pump Stork CN32-200G1S3L1, year of manufacture: 1997. 5) Centrifugal pump Siemens&Hinsch m.b.H/Loher&Söhne AKHK6101/eA132 MA-U, year of manufacture: 1970. 6) Centrifugal pump with electric motor EMK/SPX EC2-HS160M1-2/CC40-200 R6S2L2. 7) Electric motor Siemens 1LA2 130-2CA60, year of manufacture: 1997. 8) Electric motor VEM. VEM electric motor. 9) Electric motor with gearbox Nord SK 132 S/4-2 TF, SK 33-132S/4-2 TF, year of manufacture: 2011. 10) Blower Gebhardt Ventilatoren KEM 61-0200-4 X-14-11. 11) Side channel pump SERO/HEW SVM 111 K,V,60-2,32 Dex 80L/4K, year of manufacture: 2015. 12) Side channel pump SERO/VEM SVM 111 K,V,60 ...

Height=2.61 m, Overall length= 1.25 m, Overall width= 6 m, Net weight= 2000 kg,

Injection moulding machine Stork N-2500-1400 Injection unit: Spray pressure (max.) 2100 bar Spray volume (max.) 595 cc Injection weight hp (max.) 565 g Spraying speed (max) 299 cc/s Nozzle (immersion depth) Clamping unit: Clamping force 250 tons Locking force 275 tons Size of the clamping plate (hor. + vert.) 920 X 920 Opening stroke (max.) 575 mm Max. tool weight Tool height (min./max.) 200-685 Clear width between the bars 585-585 mm Discharge stroke (max.) 175 mm Ejector diameter max.80 mm Centering ring (DS-AWS) 160 mm Max. clear width between clamping p. Options: Core pull (time limit switch) Freely programmable Ejector plate (end position control)  ...

STORK PEGASUS ROTARY SCREEN PRINTER STORK PEGASUS ROTARY SCREEN PRINTER. TYPE 3200/24/20 .Year 2001 20 colours installed on a 24 position print block. Max printing width 3200mm Repeat sizes 640/914mm . Magnet System print paste application. Comprising : High entry with fabric guide rollers E+L KF 2020 edge guiders ,dust extraction unit. Reconditioned and upgraded January, 2024 Fabric passage onto a Curved Plate with Thermoplast , Wet Gluing.Belt Washing. STORK APOLLO Dryer ,Type 3200. 2 compartments ,Gas heated with support conveyor. Ext with fabric take off rollers and plaiter. Find more here - / Contact us at -

3 x Injection moulding machines Stork 440 to 1 x Injection moulding machine Stork 660 to 2 x Injection moulding machine Stork 900 to

Type: TSO600/96/4 TH Serial number: 10064051 Year of constructon: 2007 Model: right hand execution Belt width: 600 mm Belt length: 96 m Tiers: 2 x 4 pc Heating: thermal oil, 400 kW at 180°C Steam: max 1500 kg/h Exhaust: Ø 252 mm, 1000 m³/h Compressed air: 6 - 8 Bar Cold water: 1 - 20°C, 3 m³/h Hot water: 20 - 60°C, 4 m³/h Power: 3 x 400V, 50Hz, 40kW Dimensions: 11040 x 4000 x 4975 mm Weight: 20000 kg With belt washer and CIP

Stork VS 80/12 filler with 80 filling valves and 12head aluminium screw capper, year of manufacturring: 1992, capacity: approx: up to 24.000 bph by 1,0 ltr. bottles including original CIP device integrated by Stork on the back side, so that the filler, including the filling valves, can be integrated into an existing CIP system. delivery time: Oktober /November 2026 The machine can be inspected any time.

Key data: 3300 kN, 62 mm

Stork S+3300-2150 Year of Make: 2008 Clamping force: 330 tons Screw diameter: 62 mm Max. opening distance: 620 mm Injection pressure: 2100 bar Material: PP

Key data: 1500 kN, 45 mm

Stork S+S1500-850 Year of Make: 2011 Clamping force: 150 tons. Screw diameter: 45 mm Max opening distance: 480 mm Injection pressure: 2100 bar used for PP thin-wall packaging

Model: TEM630 Year: 2007 Condition: Used Serial Number: 10063138 Stock Number: 2196P Belt width: 630 mm Power: 3 x 400V, 50Hz, 2kW Dimensions: 2100 x 1250 x 1500 mm Weight: 300 kg

Used juice bottling line. LINE WITH A CAPACITY OF UP TO 12,000 BOTTLES/HOUR – production capacity for 330 ml bottles 1. Round bottle with a capacity of: - 250 ml – line capacity 9,000–12,000 bottles/hour – round bottle - 330 ml – line capacity 9,000–12,000 bottles/hour – round bottle - 750 ml - line capacity 5,000 bottles/hour - round bottle 2. Twist-off cap: - diameter 43 mm - diameter 38 mm 3. Label types: - cold glue (two-piece) Line configuration: 1. DNB-15 semi-automatic bottle depalletizer. 2. PBSz – 01 - 40 bottle rinser. 3. STORK VS 32 bottling monoblock. 4. AUTOMATIC TWIST-OFF CAPSULATOR with steam injection function, automatic, in-line capping machine (capsulator) model GG100. 5. KRONES BONOMATIC rotary labeler for cylindrical products. 6. VENUS APB-15 automatic bottle packing machine. 7. Videojet CIJ printer – model VJ 1620 8. LOB- ...

Used juice bottling line into cylindrical glass bottles. Line Capacity: 250 ml – line capacity 9,000 – 12,000 pcs/h 330 ml – line capacity 9,000 – 12,000 pcs/h 750 ml – line capacity 5,000 pcs/ Twist-off cap bottles with diameters of 43 and 38 mm The line includes the following devices: Bottle depalletizer type DNB-15. Bottle scrubber type PBSz – 01 – 40. Stork monoblock type VS 32. 32 fillers. Year of manufacture 2015. Automatic cap capping machine with steam injection function model GG100. Rotary labeller from KRONES BONOMATIC Automatic Bottle Packer Type VENUS APB – 15. 10 cycles/min CIJ Videojet Inkjet Printer Model VJ 1620- Linear Bottle Dryer type LOB-25. Pasteurizer. Transporters.

GLUING MACHINE, STORK, TYPE: ERT 630 Technical description: Bandwidht: 630 mm Material: Stainless steel Aisi 304 Power supply: 380/440 V - 50/60Hz Dimensions: 1500 x 1200 x 1800 mm

Model: HVV 16, 16 filling valves. Overhauled in 2013 filling valves: 16 working direction: right-left (CCW) filling system: vacuum filling

Key data: 9000 kN, 115 mm

STORK SXN 9000-8600 - 900 T Clamping force : 900 T Reference : SXN 9000-8600 Year : 2000 Screw diameter : 115 mm Max. material pressure : 1600 bar Injection volume : 5349 cm3 Injection capacity : 5062 g Injection speed : 599 mm/s Plasticizing: 123 g/s Distance between tie bars : 1010 x 1010mm Column diameter: 190 mm Working hours: 38,900 h Weight of clamping unit: 38,000 kg Weight of injection unit: 11,700 kg

Key data: 14000 kN, 133 mm

Clamping force : 1400 T Reference : SXN 14000-12500 Year : 2001 Screw diameter : 133 mm Max. material pressure : 1600 bar Injection volume : 8336 cm3 Injection capacity : 7919 g Injection speed : 771 mm/s Plasticizing: 143 g/s Distance between tie bars: 1300 x 1300mm Column diameter: 220 mm Working hours: 51,500 h

Complete bottle forming, filling and packing line for 1,5 liter sterilized milk with blowers, filler, capper, sterilization towers, palletizers etc. The line is already dismantled and boxed in crates., General:, Size of the bottles: 1,5 liter milk bottle with stopper (cap), Bottle dimensions: width 93,9 mm, height 282 mm, Weight bottle: 44 gram, weight aluminium 0,4 gram and weight cap 4 gram, Material of the bottle / Compesition: PE (Polyethylene), Neck diameter of the bottle: 46,7 mm, Bottle closed with a aluminum and easy peelable cover, Capacity of the line: 7.000 bottles per hour, Product: Whole cow’s milk, which has been treated with a heating process in such conditions of temperature and time able to ensure the destruction of microorganisms and the inactivity of their resistance forms., Closed bottle shelf life: 6 months since the date of manufacture, Opened bottle: maximum thre ...

200 Stork live bird boxes, (2x) 5 floors, dimensions floors: (10x) 1100 mm x 1140 mm, total dimensions: (200x) 2450 mm x 1200 mm x 1460 mm. The boxes are expected to be available from August. Collection by appointment.

100 Stork live bird boxes, (2x) 5 floors, dimensions floors: (10x) 1100 mm x 1140 mm, total dimensions: (100x) 2450 mm x 1200 mm x 1460 mm. The boxes are expected to be available from August. Collection by appointment.

Line is consisting of:, Townsend MasterFormer, Type: TA1521, Serial number: 10080439, Year of construction: 2010, Stork MasterFill, Type: MTFII, Serial number: 0441010, Year of construction: 2010, Stork Master Slice, Type: DRST, Serial number: 0420410, Year of construction: 2010, Caliber: 50 mm, Karl Schnell vacuumfiller, Type: P10SE, 596P, Serial number: 22045, Year of construction: 2010, Power: 3 x 400V, 50Hz, 10.9kW, Weight: 1180 kg, Risco vacuumfiller, Type: RS303, Serial number: T310021, Year of construction: 2010, Power: 3 x 400V, 50Hz, 7.7kW, Weight: 830 kg, With RS70 grinding head

With belt washer and CIP, Model: Right hand execution, Belt width: 600 mm, Belt length: 96 m, Tiers: 2 x 4 pc, Heating: thermal oil, 400 kW at 180°C, Steam: max 1500 kg/h, Exhaust: Ø 252 mm, 1000 m³/h, Compressed air: 6 - 8 Bar, Cold water: 1 - 20°C, 3 m³/h, Hot water: 20 - 60°C, 4 m³/h, Power: 3 x 400V, 50Hz, 40kW, Dimensions: 11040 x 4000 x 4975 mm, Weight: 20000 kg

Used STORK glass line for spirits 12000 BPH - shaped, taperedTechnical Specifications & Performance DataThis complete used bottling line for glass bottles is engineered around a Stork rinser–filler–capper monoblock with vacuum filling, complemented by wet-glue front, back, and neck labeling. It is a second hand industrial packaging solution designed for efficient beverage production on round, shaped, and tapered glass containers.Line type: Complete glass bottling lineProduction speed: 200 BPM (approximately 12,000 bottles per hour)Bottle shapes: Round, shaped, taperedFormats: Compatible with 0.35L, 0.7L, 0.75L, 1.14L bottle formatsContainers: Designed for Glass bottle handlingFilling principle: Vacuum fillingLabeling: Wet glue labeller for front, back, and neck labelsElectrical supply: 415 V / 50 Hz on most equipment; select components 240 V / 50 HzKey equipment and model refer ...

General SKU070A418 MakeStork Plaatwellerij Velsen No.1308 Year of construction1979 LocationBarneveld Pressure Working pressure4.5 Bar Vacuum possiblecheck Working pressure jacket3 Bar Main Features MaterialStainless steel Volume800 Ltr. Motor11 KW Specified Features - Stainless Steel Reactor Reactorcheck Capacity1000 l, Useful 800 l Vessel sizesdia. 1042 x 1000mm Dished bottomcheck Conical bottomcheck Dished top sidecheck Manholecheck hand hole dia. 200 mm Top connectionsdia. 150 mm + dia. 40 mm + 2x dia. 25 mm Outletdia. 145 mm With jacketcheck vollume: 80 Ltr Max. temperature150°C With propellor stirrermake Ekato, type EM-060 With paddle stirrercheck Motor11,0 KW, (380/660 Volt, 960 rpm (Ex)) Speed mixing shaft99 rpm Stainless Steel Reactors MaterialStainless steel 1.4571 (316Ti) Information Floorspace1,4 x 1,4 m Total height3,0 m Weight1600 kg ATE ...

Auction-ID: A1-47050-25

Belt width: 630 mm, Power: 3 x 400V, 50Hz, 2kW, Dimensions: 2100 x 1250 x 1500 mm, Weight: 300 kg

Used STORK minature line fro glass & PET 200 BPMTechnical Specifications & Performance DataThis used bottling line is engineered for miniature formats and optimized for high-efficiency beverage production. Configured specifically for 50 ml bottles, it handles both PET and Glass containers and supports multiple shapes including flask, oval, and round. The core of the line is a Stork rinser–filler–capper monoblock with a 36-head rinsing/filling carousel and a 9-head capping turret. Downstream operations include a Krones Autocol 3-station self-adhesive labeling machine for front and back labels, integrated inspection and rejection systems, and complete case packing, sealing, coding, and conveying.Production speed: 200 BPM (miniature 0.05L bottles)Filling type: vacuum filling Bottle formats: Compatible with 0.05L bottle formatContainers: Designed for PET and Glass bottle handlingSu ...
