sk 50 used for sale

Trumpf TruLaser Robot 5020Year of manuf. : 2010 ____________Description:TruDisk 3302 laser system:- TRUMPF TruDisk 3302 with a beam quality of 8 mm mrad:- Output power of 3.3 kW at the workpiece:- Laser system with 1 cavity:- Beam delivery system comprising an optical assembly for a single optical path, a fast switch (50 ms switching time) and a pilot laser including electrical control:- Integrated power supply and real-time capable control system for the evaluation and visualisation of operational data:- Fast laser power control:- TruControl 1000 control system:- Storage capacity for 199 laser programmes:- Safety monitoring in accordance with laser safety class 1, including a central safety lock:- Protection class IP54:- 10.4 panel computer with TFT touchscreenExtension of the beam path:Plus 1 additional laser light cable output, including interface card:consisting of::# Optical a ...

Trumpf TruBend Center 5030Year of manuf. : 2021 ____________Description:TruBend Center 5030:- Robust machine frame: - Angular direct drive:- Crowning system:- Machine control with touchscreen operation:- TecZone Fold programming – floating licence:- 2-axis part manipulator with suction modules:- 5-axis backgauge:- Optical angle assistant:- ToolMaster:- Hold-down tools:- OBW90 and UBW90 bending toolsTechnical specificationsMinimum bending depth (standard tool):145 mmMinimum bending depth (with additional hold-down tool):40 mmMaximum bending length:3,123 mmMinimum bending length:80 mmHold-down force:101 tMaximum box height:220 mmMinimum material thickness:0.4 mmMaximum steel material thickness:3 mmMaximum stainless steel material thickness:2.2 mmMaximum aluminium material thickness:4 mmRapid traverse Y-axis (press beam):250 mm/s5-axis backgauge:1,700 mm/sToolMaster Bend:2,400 mm/sD ...

ZNHZ-508A Envelope Making Machine - Lidograf printing machines Menu Home About us Offer Gallery We buy Contact en pl ZNHZ-508A Envelope Making Machine Search: Search Technical condition: New Used Categories: Bookbinding machinery Bookletmakers Box production Collators Creasers Die Cutting Machines Folding machines Gluing machines Guillotines Joggers and Lifts Laminators Offset printing machinery Others Packaging machines Paper drills Perfect binders Pile turners Spare parts Stitching machines ZNHZ-508A Envelope Making Machine Price: 7000 EUR Download PDF ZNHZ-508A Envelope Making Machine Paper weight 70 – 150 g/m² Production rate 3000 – 9000 pcs/h Maximum folded envelope size Western Style 324 x 229 mm Min. folded envelope size 100 x 100 mm Power 8 kW Weight 3000 kg Dimensions 6600 x 1200 x 1300 mm Year of manufacture 2014. Key advantages of the machine: – A bottom-mounted vacuum  ...

Renz Punch 500 Perforator - Lidograf printing machines Menu Home About us Offer Gallery We buy Contact en pl Renz Punch 500 Perforator Search: Search Technical condition: New Used Categories: Bookbinding machinery Bookletmakers Box production Collators Creasers Die Cutting Machines Folding machines Gluing machines Guillotines Joggers and Lifts Laminators Offset printing machinery Others Packaging machines Paper drills Perfect binders Pile turners Spare parts Stitching machines Renz Punch 500 Perforator Price: 5250 EUR Download PDF Renz Punch 500 Perforator The unit is in very good condition. It is a newer model featuring adjustable side guides. Electrically driven and operated via a foot pedal. Includes a 3:1 pitch perforation tool (4 mm hole) with a thumb-cut (hanger notch) feature. Manufacturer’s description: Perforation machine with a working width of up to 500 mm. Designed for cont ...

Standard configuration Machine ⦁ Stable C-frame for easy access ⦁ Ball-fitted tables ⦁ Coordinate guide for high-precision machining ⦁ Linear magazine for tool stations and clamps ⦁ 21 tool stations, 4 clamps ⦁ Part chute for small parts 80 x 50 mm ⦁ Parts flap 500 x 500 mm ⦁ Good parts container ⦁ Ability to retrofit ToolMaster Linear ⦁ 1st index pin position inner side (right or left) Punching station ⦁ Electro-hydraulic punching head ⦁ Rotatable single station tool adapter ⦁ Manually adjustable presser foot force ⦁ Programmable pressure foot (active /passive / repositioning) ⦁ Tool length compensation ⦁ Spray lubrication for punches ⦁ Vacuum slug removal with condition monitoring ⦁ Stroke rate punch ⦁ Monitoring of fill level of tapping and tool lubrication ⦁ On-Demand-Drive ⦁ Stripper position measurement system with function sheet thick ...

Renz Mobi 500 semi-automatic spiral binding machine - Lidograf printing machines Menu Home About us Offer Gallery We buy Contact en pl Renz Mobi 500 semi-automatic spiral binding machine Search: Search Technical condition: New Used Categories: Bookbinding machinery Bookletmakers Box production Collators Creasers Die Cutting Machines Folding machines Gluing machines Guillotines Joggers and Lifts Laminators Offset printing machinery Others Packaging machines Paper drills Perfect binders Pile turners Spare parts Stitching machines Renz Mobi 500 semi-automatic spiral binding machine Price: 26500 EUR Download PDF Renz Mobi 500 semi-automatic spiral binding machine In very good condition; manufactured in 2016. A semi-automatic wire-o (spiral) binding machine from the German company RENZ: • Operated via a touchscreen display. • Features the fastest format-changeover capability in its class, ...

turning diameter: max. 240 mm turning length: 470 mm control: 840 D sl Operate 4.8 Celos greates pass round over bed: 500 mm swing diameter over slide rest: 290 mm centre distance: 780 mm Main spindle:: turning speed range - main spindle: max. 6.000 min/-1 power capacity - main spindel: 13 / 14 kW max. Torque: 171,5 / 192 Nm inner draw tube diameter: 52 mm C-Axis: 0,001 ° spindle diameter in front bearing: 100 mm spindle nose: FL 140H5 Subspindle:: Spindle speed range subspindle: max. 6.000 min/-1 power capacity - Sub spindle: 12,6 / 16,2 kW max. Torque: 48 / 62 Nm inner draw tube diameter: 37 mm C-Axis: 0,001 ° spindle diameter in front bearing: 90 mm spindle nose: FL 140H5 turret:: number of toolpositions: 12 pos. Number of driven toolspositions: 12 pos. tool taper: VDI 30 Spindle speed - driven tool stations: max. 5.000 min -1 power capacity - driven tool-stations: 4,18 kW max. T ...

MBO T500-2/4 folding module + T-500-2-X cross-folding knife unit - Lidograf printing machines Menu Home About us Offer Gallery We buy Contact en pl MBO T500-2/4 folding module + T-500-2-X cross-folding knife unit Search: Search Technical condition: New Used Categories: Bookbinding machinery Bookletmakers Box production Collators Creasers Die Cutting Machines Folding machines Gluing machines Guillotines Joggers and Lifts Laminators Offset printing machinery Others Packaging machines Paper drills Perfect binders Pile turners Spare parts Stitching machines MBO T500-2/4 folding module + T-500-2-X cross-folding knife unit Price: 3000 EUR Download PDF MBO T500-2/4 folding module + T-500-2-X cross-folding knife unit Machine in very good condition, ready for production. From the original owner. This is a secondary (cross-folding) module for an MBO folding machine, complete with an additional kni ...

Fetzel TLM 500 V4 Laminating Machine - Lidograf printing machines Menu Home About us Offer Gallery We buy Contact en pl Fetzel TLM 500 V4 Laminating Machine Search: Search Technical condition: New Used Categories: Bookbinding machinery Bookletmakers Box production Collators Creasers Die Cutting Machines Folding machines Gluing machines Guillotines Joggers and Lifts Laminators Offset printing machinery Others Packaging machines Paper drills Perfect binders Pile turners Spare parts Stitching machines Fetzel TLM 500 V4 Laminating Machine Price: 15000 EUR Download PDF Fetzel TLM 500 V4 Laminating Machine The machine is 100% functional and in perfect condition. This is an advanced, high-performance automated system, well-suited for commercial lamination services. Manufactured in Austria. Technical specifications: Max. sheet size: 520 mm x 720 mm Min. sheet size: 200 mm x 290 mm Min. paper wei ...

Mosca RO-M-P5 Fusion 650×500 Strapping Machine - Lidograf printing machines Menu Home About us Offer Gallery We buy Contact en pl Mosca RO-M-P5 Fusion 650×500 Strapping Machine Search: Search Technical condition: New Used Categories: Bookbinding machinery Bookletmakers Box production Collators Creasers Die Cutting Machines Folding machines Gluing machines Guillotines Joggers and Lifts Laminators Offset printing machinery Others Packaging machines Paper drills Perfect binders Pile turners Spare parts Stitching machines Mosca RO-M-P5 Fusion 650×500 Strapping Machine Price: 3500 EUR Download PDF Mosca RO-M-P5 Fusion 650×500 Strapping Machine The machine is 100% functional and ready for production. Manufacturer: Mosca, Germany. An indispensable piece of equipment for shipping departments, ideal for securing heavy packages such as those containing leaflets or catalogs. The 5mm PP (polypro ...

Radial fan, dust extraction blower, fan, extraction, dust blower, blower, exhaust fan -Manufacturer: Novenco, dust extraction blower radial fan type CNA-500 DE X -Motor: Loher 4 kW 1415 rpm -Volume flow rate: 8000 m³/h -Connection: Inlet Ø 490 mm -Connection: Output 500 x 350 mm -Fan wheel: Ø 560 x 140 mm -Dimensions: 1000/770/H855 mm -Weight: 107 kg

This 4-axis Okuma SPACE CENTER MA-500HA was manufactured in 2004. It features a spindle speed of 20,000 rpm and a tool magazine capacity of 40 tools, ensuring efficient machining operations. The machine is equipped with a BLUM laser tool measuring system and includes two-sided fixture blocks for versatility. If you are looking to get high-quality machining capabilities, consider the Okuma SPACE CENTER MA-500HA horizontal machining centre we have for sale. Contact us for further details.

Machining center in vertical design with automatic return Workpiece dimensions: Length: 200 to 3050 mm Width: 50 to 1250 mm Thickness: 8 to 80 mm weight max 60 kg Performance - 2x vertical drilling unit separately controllable with variable speed. right left V10/32mm. 2.3 kW. Drill length 70 mm, D= max 35 mm - 2x horizontal drilling unit, 6 spindles in X direction, variable speed. right left can be controlled separately. Drill length 70 mm, D= max 20 mm - 2x horizontal drilling unit, 2 spindles in Y direction, variable speed. right left can be controlled separately. Drill length 70 mm, D= max 20 mm - Grooving saw unit X-Y can be swiveled 0°/90° saw diameter 125 mm, rpm 1500-7500 frequency controlled - Dowel insertion station for automatic insertion of dowels on the two transverse workpiece edges 1x left side / 1x right side glue pump, vibrating guide for dowels 8 x 35/40 mm - pl ...

Technical data Maximum pressure: 54 tons Power connection: 400V / 7.5 kW Pressing force: 5.62 kg/cm² Year of Make: 2004 Bale size: 1200x800x1200 mm Productivity: approx. 2 bales/hour Bale weight: approx. 500 kg Bale tying only with wire Machine is fully functional, after technical inspection and after renovation

Used Illig RDM 37/ 10 with top heater, No Sheet Sag Control, Heater moved forward manually, Auto-unwind stand, mechanical indexing, Auto start mechanism, Pneumatic Plug assist, Form Area 475 x 250 mm, Max. Film width 495 mm, Max. Draw 100 mm, Age 1975, basic Machine, in production Condition, Please make an offer !

pressure: 50.0 t punching cross-cut in cmm: 27.0 in 14.0 mm ST round bar steel: 32 + 17 mm square edge steel: 30 + 18 mm L-beam: 100 x 10 mm throat: 200 mm shear: flat material: 190 x 10 mm blade length: 200 mm stroke - stepless adjustable: 10 - 28 mm stroke: 14 - 28 H/min total power requirement: 4.0 kW weight: 900 kg range L-W-H: 950 x 650 x 1730 mm from a maintenance workshop in good condition () Equipment: - Compact electro-hydraulic combined structural steel shear with notching station with punching station flat bar shear angle steel shear round and square bar shear - Support table at the notching station - Support table at the punching station - Stripper at the punching station - 1x mobile foot switch - Assortment of various punches and dies - Original operating manual The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

x-travel: 500 mm y-travel: 340 mm z-travel: 525 mm control: Heidenhain total power requirement: kW weight of the machine ca.: 2500 kg dimensions of the machine ca.: m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

- ATEX: II G / 2G c IIA – T2 - Year of construction: 2013 - Motor: 2.5 kW / 400 V, 50 Hz, 2875 rpm - High-pressure fan: 5,077 Pa / 3,300 Pa - V (m³/h): 103 - Very few operating hours - In perfect condition

turning diameter:500 mm turning length:1000 mm control:Siemens 840 D spindle:42 / 28 kW spindle turning speed - stepless:31 - 4000 1/min max. torque on the spindle:345 Nm c-axis:360000 x 0,001° feeds -stepless-:0 - 10000 mm/min rapid traverse:10000 mm/min turret stations / rotary tool stations:12/12 VDI 40 RPM of rotary tools:2000 1/min diameter of quill:90 mm quill stroke:80 mm tailstock quill taper ISO:SK 30 Tailstock Travel:600 mm Power rotary tools:3,5 kW :22,5 Nm Rotary tool holders:4 ax./ 4 rad. spindle passage:66 mm total power requirement:30 kW weight of the machine ca.:7,5 t dimensions of the machine ca.:8x 3 x 4 m

x-travel:630 mm y-travel:600 mm z-travel:650 mm control:MSC 502 (Fanuc 16) Spindle RPM:12000 1/min spindle drive:22 / 18,5 kW rapid travel x/y/z:32 m/min Pallet dimension:500x500 mm numbers of pallets:2 table load:0,5 t working diameter:max. 610 mm Number of tool station:60 BT40 max. tool length:360 mm max. tool weight:12 kg tool changing time:1,3 sec B-axis positioning (non continuous):1 total power requirement:50 kVA weight of the machine ca.:14 t dimensions of the machine ca.:3,3 x 5,8 x 3,2 m spindle load monitor:Typ C This horizontal machining center comes with a pallet changer with 2 pallets, and has the following options: ATC 60 tool stations, High pressure coolant trough spindle interface,

feed pressure:10 bar airflow volume:1,06 m³/min Motor RPM:3920 1/min total power requirement:7,5 kW electrics - voltage/frequency:400/50 V/Hz machine weight approx.:250 kg dimensions L x W x H:1,5 x 2 x 2 m Professional, soundproofed compressor with the lowest noise level in its class, designed to eliminate noise problems in working environments. The powerful 5.5 hp pump unit guarantees maximum efficiency and reliability. It is also equipped with an additional intake silencer, a belt tensioning device that regulates belt tension and facilitates replacement, and a forced ventilation fan for better cooling. The control panel with star-delta start control is positioned for easy reading and operation. The opening front door allows for easy maintenance.

turning diameter:1600 mm turning length:12000 mm control:FAGOR 8050 Used CNC Lathe with FAGOR 8050 and extensive accessories. For further technical data and accessories, pls browse the Appendix. Parallellathe WMW mod. 4 GUIDE-WAYS ¦ CNC: FAGOR 8050 ¦ bed: monolithic ¦ centres height: 800 mm ¦ centres distance: 12000 mm ¦ swing over cross-slide: 1250 mm ¦ turret: automatic 4 positions ¦ tailstock: motorized ¦ tailstock connection: hydraulic ¦ platform: diam. 1000 mm ¦ steady rests: nr.02 ¦ chip conveyor Warranty: none Take advantage of the favorable leasing and hire-purchase terms from IKB Leasing. Ask us about it.

x-travel:630 mm y-travel:630 mm z-travel:500 mm number of spindle speeds:0 - 15000 spindle motor:32 kW size of pallet:500 x 500 mm b-axis:36000 x 0,001 ° no. of workpieces in the magazine:61 Stück tool taper:HSK 63 weight of the machine ca.:15 t Single-Spindle Mechanical processing cylinder head VR6

max. wheel diameter:780 mm gear width:130 mm max. module:10 weight of the machine ca.:8,5 t no. of strokes:30 Hub/min Hier fully functional machine, Little used There are some Tools and Change gears Liebherr WSC501 CNC gear shaping machine, used, ready for use Manufacturer: Liebherr Type: WSC 501 Mach.- No.: 4407/05 Year of manufacture: 1985 Details: Max. gear shaping module: 8mm (30°gears possible up to module 10°) Max. gear width: 130mm Diameter of the machine table: 500mm Maximum wheel diameter: 780mm Shut height ? table: 650mm Stroke rate min. 30DH/min Continuously adjustable max. 1500 DH/min. Operating voltage: 380V Frequency: 50Hz Control voltage: 110V Connected load: 36 kVA Rated current: 55A Weight: 8500kg Dimensions: approx. 4,85 x 3,655 x 3,78 (width x depth x height in m) The machine has seen only very limited use in our company. It remains fully operational and can be dem ...

x-travel:760 mm y-travel:760 mm z-travel:760 mm b-axis:360.000 x 0.001 ° spindle drive:26 / 18,5 (40% / 100%) kW spindle turning speed range:50 - 15000 U/min Tool bore:KSK-A63 max. table loading capacity:500 kg total power requirement:43 kW weight of the machine ca.:11,5 t dimensions of the machine ca.:2,7 x 4,73 x 2,87 m

turning diameter over bed:500 mm turning diameter over slide rest:310 mm turning length:1500 mm spindle turning speed range:7 - 710 U/min feed range:5,6 - 224 mm/min total power requirement:15 kW weight of the machine ca.:3,7 t dimensions of the machine ca.:2,9 x 1,4 x 1,6 m Machine with 2-axis digital readout - MULTIFIX quick tool change device - 3-jaw chuck

turning diameter:500 mm turning length:1000 mm control:MANUAL PLUS Grundig total power requirement:24 kVA weight of the machine ca.:2650 kg dimensions of the machine ca.:2500 x 1750 x 1850 mm swing diameter over face slide:290 mm chuck:Ø max. 260 mm cross movement:260 mm spindle head:DIN 55027 Größe 8 spindle bore diameter:70 mm rapid travel - longitudinal/face:8 /6 m/min spindle speeds::8 - 2800 tailstock travel:180 mm tailstock quill taper MT:5 Documents:vorhanden

turning diameter:500 mm turning length:1000 mm control:MANUAL PLUS Grundig total power requirement:24 kVA weight of the machine ca.:2650 kg dimensions of the machine ca.:2500 x 1750 x 1850 mm swing diameter over face slide:290 mm chuck:Ø max. 260 mm cross movement:260 mm spindle head:DIN 55027 Größe 8 spindle bore diameter:70 mm rapid travel - longitudinal/face:8 /6 m/min spindle speeds::8 - 2800 tailstock travel:180 mm tailstock quill taper MT:5

turning length:2000 mm control:- total power requirement:25 kW weight of the machine ca.:3 t dimensions of the machine ca.:3800 x 1800 x 1850 mm swing over bed:500 mm swing diameter over face slide:280 mm control:Zyklen-Steuerung Heidenhain bed width:350 mm Documents:vorhanden

grinding length:600 mm grinding width:250 mm workpiece height:380 mm :Sinumerik max. dia. of grinding wheel:300 mm weight:4000 kg total power requirement:12,5 kW grinding wheels:Ø 400 mm max. width of grinding wheel:100 mm grinding wheel hole diameter:127 mm turning speeds:470 - 12030 1/min x-axis:600 mm y-axis:300 mm z-axis:250 mm grinding range:450 x 200 mm distance spindle nose and table:500 mm table load:250 kg dimensions of the machine ca.:2600 x 2100 x 2400 mm switchgear cabinet:1300 x 800 x 2000 mm hydraulical unit::450 x 350 x 500 mm Documents:vorhanden

faceplate diameter:5000 mm swing diameter:6100 mm turning height:2400 mm ram stroke each side:1490 mm ram head dimension:340 x 340 mm max. workpiece weight:100.000 kg total power requirement:100 kW weight of the machine ca.:155 t faceplate turning speed range:0,4 - 50 U/min with 2 axes CNC SIEMENS 840 D

Pressure:500 t distance between columns:1550 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:900 mm table surface area:1200 x 1300 mm pressure of drawing cushion in table:250 t stroke of drawing cushion in table:150 mm die cushion area:950 x 950 mm table height over floor:1245 mm side window:1250 mm ram surface:1200 x 1300 mm speed down:750 mm/s speed up:780 mm/s working speed:105 mm/s oil volume:4000 l power requirement:263,0 kW weight:45,0 t Dimensions (WxDxH):3,3 x 3,3 x 6,1 m height over floor:6,1 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic cutting impact cushioning:motoric adjustable

pressure:500 t distance between columns:2400 mm stroke:400 fix mm no. of strokes:13 - 23 /min Distance table/ram, max. stroke up, adjustment up:1600 mm table surface area:2300 x 1800 mm column travel -side:1600 mm ram surface:2170 x 1800 mm ram adjustment:300 mm total power requirement:110,0 kW Weight:135,0 t Dimensions (WxDxH):3,35 x 4,85 x 7,0 m clutch:pneumatic overload protection in ram:hydraulic ram adjustment:motoric

pressure:500 t distance between columns:2240 mm stroke:1180 mm distance table/ram, max. stroke up, adjustment up:1800 mm table surface area:2050 x 1800 mm pressure of drawing cushion in table:250 t stroke of drawing cushion in table:380 mm drawing cushion surface in table:1800 x 1200 mm pressure of drawing cushion in ram:122 t stroke of drawing cushion in ram:200 mm drawing cushion area in ram:1800 x 1200 mm ram surface:2215 x 1800 mm table height over floor:500 mm speed down:400 mm/s speed up:10 - 400 mm/s working speed:10 - 100 mm/s depth of the foundation:3,0 m power requirement:122 + 75 + 64,5 kW weight:110,0 t Dimensions (WxDxH):3,6 x 2,2 x 8,5 m height over floor:6,8 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table and ram:hydraulic

pressure:500 t distance between columns:3200 mm stroke:1250 mm distance table/ram, max. stroke up, adjustment up:1810 mm table surface area:3000 x 1900 mm pressure of drawing cushion in ram:150 t stroke of drawing cushion in ram:200 mm drawing cushion area in ram:2400 x 1200 mm ram surface:3160 x 1900 mm speed down:400 mm/s speed up:250 mm/s working speed:18 - 58 mm/s height over floor:6,5 m power requirement:90,0 + 36,5 kW weight:110 t German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in ram:hydraulic

pressure:500 t stroke:40 - 160 mm no. of strokes:32 / 48 /min distance between columns:1620 mm distance table/ram, max. stroke up, adjustment up:660 mm table surface area:1600 x 1300 mm table height over floor:750 mm column travel -side:400 x 430 mm ram surface:1400 x 1200 mm ram adjustment:120 mm pressure of drawing cushion in table:60 t stroke of drawing cushion in table:100 mm drawing cushion surface in table:1300 x 810 mm material width of feeder:1000 mm material thickness of feeder:- 6,0 mm feed length:350 mm height beneath floor:0,3 m power requirement:44,0 / 66,0 kW weight:56,0 t Dimensions (WxDxH):3,55 x 2,55 x 5,1/5,8 m height beneath floor without drawing cushion:0,3 m height beneath floor with drawing cushion:1,0 m clutch-/ brake combination:pneumatic; Desch overload protection in ram:mechanical ram counterbalance:pneumatic ram adjustment:motoric drawing cushion in table:pneum ...

pressure:500 t stroke:40 - 160 mm no. of strokes:32 / 48 /min distance between columns:1620 mm distance table/ram, max. stroke up, adjustment up:660 mm table surface area:1600 x 1300 mm table height over floor:750 mm column travel -side:400 x 430 mm ram surface:1400 x 1200 mm ram adjustment:120 mm material width of feeder:1000 mm material thickness of feeder:- 6,0 mm feed length:350 mm power requirement:44,0 / 66,0 kW weight:56,0 t Dimensions (WxDxH):3,55 x 2,55 x 5,1/5,8 m height beneath floor:0,3 m pneumatic clutch-brake combination:Desch Mechanical pincers feed:Obru, BVK 3.10.3

pressure:500 t stroke:40 - 160 mm no. of strokes:32 / 48 /min distance between columns:1620 mm distance table/ram, max. stroke up, adjustment up:660 mm table surface area:1600 x 1300 mm table height over floor:750 mm column travel -side:400 x 430 mm ram surface:1400 x 1200 mm ram adjustment:120 mm pressure of drawing cushion in table:60 t stroke of drawing cushion in table:100 mm drawing cushion surface in table:1300 x 810 mm material width of feeder:1000 mm material thickness of feeder:- 6,0 mm feed length:350 mm power requirement:44,0 / 66,0 kW weight:56,0 t Dimensions (WxDxH):3,55 x 2,55 x 5,1/5,8 m height beneath floor without drawing cushion:0,3 m height beneath floor with drawing cushion:1,0 m pneumatic clutch-brake combination:Desch drawing cushion in table:pneumatic Mechanical pincers feed:Obru, BVK 3.10.3

material width:600 mm coil weight:5,0 t material thickness: - 5,0 mm coil internal diameter:360 - 660 mm coil external diameter:1500 mm no. of straightening rolls:9 straightening roll diameter:80 mm number of draw-in rolls:2 material cross-cut:1600 mm² weight of feeeder-straightener:2,5 t weight of decoiler:1,5 t dimensions feeder-straightener (WxDxH):1,7 x 1,7 x 2,6 mm dimensions decoiler (WxDxH):1,8 x 2,0 x 2,3 mm feeder-straightener:VCRL 650, Bj. 1994, GR 2001 height adjustment:motorisch alligator opening:hydraulisch decoiler:SHR 5000, Bj. 2000 expansion:hydraulisch

pressure:500 t distance between columns:3400 mm stroke:850 mm no. of strokes:9 - 18 /min distance table/ram, max. stroke up, adjustment up:2050 mm table surface area:3100 x 1900 mm table height over floor:400 mm side window:1550 mm ram surface:3100 x 1900 mm ram adjustment:350 mm pressure of drawing cushion in ram:70 t pressure of drawing cushion in table:140 t stroke of drawing cushion in table:0 - 250 mm stroke of drawing cushion in ram:150 mm height beneath floor:6,0 m height over floor:8,3 m weight:155,0 t dimensions (WxDxH):5,1 x 4,5 x 12,3 m Kind of drive:link drive tool changing unit:2 x

pressure:500 t distance between columns:3400 mm stroke:850 mm no. of strokes:9 - 18 /min distance table/ram, max. stroke up, adjustment up:2050 mm table surface area:3100 x 1900 mm table height over floor:400 mm side window:1550 mm ram surface:3100 x 1900 mm ram adjustment:350 mm pressure of drawing cushion in ram:70 t pressure of drawing cushion in table:140 t stroke of drawing cushion in table:0 - 250 mm stroke of drawing cushion in ram:150 mm height beneath floor:6,0 m height over floor:8,3 m weight:155,0 t dimensions (WxDxH):5,1 x 4,5 x 12,3 m Kind of drive:link drive tool changing unit:2 x

pressure:500 t distance between columns:3400 mm stroke:850 mm no. of strokes:9 - 18 /min distance table/ram, max. stroke up, adjustment up:2050 mm table surface area:3100 x 1900 mm table height over floor:400 mm side window:1550 mm ram surface:3100 x 1900 mm ram adjustment:350 mm pressure of drawing cushion in ram:70 t pressure of drawing cushion in table:140 t stroke of drawing cushion in table:0 - 250 mm stroke of drawing cushion in ram:150 mm height beneath floor:6,0 m height over floor:8,3 m weight:155,0 t dimensions (WxDxH):5,1 x 4,5 x 12,3 m Kind of drive:link drive tool changing unit:2 x

pressure:500 t distance between columns:3400 mm stroke:850 mm no. of strokes:9 - 18 /min distance table/ram, max. stroke up, adjustment up:2050 mm table surface area:3100 x 1900 mm table height over floor:400 mm side window:1550 mm ram surface:3100 x 1900 mm ram adjustment:350 mm pressure of drawing cushion in ram:70 t pressure of drawing cushion in table:140 t stroke of drawing cushion in table:0 - 250 mm stroke of drawing cushion in ram:150 mm height beneath floor:6,0 m height over floor:8,3 m weight:155,0 t dimensions (WxDxH):5,1 x 4,5 x 12,3 m Kind of drive:link drive overload protection in ram:hydraulic ram adjustment:motoric tool changing unit:2 x

material width:500 mm coil weight:2 x 2,0 t material thickness:1,0 - 6,0 mm coil internal diameter:350 - 420 mm coil external diameter:1600 mm no. of straightening rolls:9 straightening roll diameter:50 mm number of draw-in rolls:2 speed:0 - 40 m/min material thickness at 500 mm material width:3,5 mm power requirement:17,5 kW Dimensions (WxDxH):2,3 x 4,2 x 2,4 m straightening machine:RM 5050.4/9 double decoiler:AH 2000/2/M snubber roll:pneumatic interchangeable jaws:130 mm expansion of the inner diameter

pressure:500 t distance between columns:1220 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:1000 mm table surface area:1600 x 1200 mm pressure of drawing cushion in table:320 t stroke of drawing cushion in table:150 mm drawing cushion surface in table:750 x 625 mm pressure of drawing cushion in ram:180 t stroke of drawing cushion in ram:100 mm drawing cushion area in ram:750 x 625 mm ram surface:1600 x 1200 mm table height over floor:800 mm speed down:665 mm/s speed up:530 mm/s working speed:34 - 100 mm/s quantity of oil:2000 l power requirement:180,0 kW weight:40,0 t Dimensions (WxDxH):3,2 x 2,4 x 7,5 m Depth of foundation pit:4,1 m Height above floor:5,55 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2

material width:500 mm coil weight:3,0 t material thickness:0,2 - 2,5 mm coil internal diameter:470 - 530 mm coil external diameter:1400 mm no. of straightening rolls:9 straightening roll diameter:40 mm number of inlet and outlet rolls:4 material cross-cut:1200 mm² speed:1,5 - 30 m/min dimensions decoiler (WxDxH):1,9 x 0,6 x 1,7 m weight decoiler:1,1 t dimensions straightener (WxDxH):3,3 x 1,3 x 2,7 m weight straightener:3,0 t straightening machine:RYD 40 x 500 decoiler:DY 500 x 3000 coil lifting device:hydraulic rool feed:elektronic; AESL 500-2,8 threading device:hydraulic expansion:hydraulic

pressure:500 t distance between columns:1910 mm stroke:500 mm Distance table/ram, max. stroke up, adjustment up:700 mm table surfache without cutting impact cushions:1910 x 1360 mm table surfache with cutting impact cushions:1600 x 1360 mm table height over floor:800 mm ram surface:1600 x 1270 mm Side window:600 mm speed down:400 mm/s speed up:330 mm/s working speed:10 - 28 mm/s oil volume:1200 l power requirement:60,0 kW weight:40,0 t Dimensions (WxDxH):3,6 x 2,5 x 5,0 m height over floor:4,5 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 cutting impact cushioning:hydraulic ram interlocking:hydraulic

pressure:500 t stroke:fix 300 mm no. of strokes:20 - 70 Hub/min distance between columns:3100 mm side window:1400 mm distance table/ram, max. stroke up, adjustment up:1000 mm Table area:2800 x 1600 mm ram surface:2800 x 1450 mm ram adjustment:100 mm power requirement:90,0 kW weight:100,0 t Dimensions (WxDxH):5,75 x 3,2 x 7,8 m height above floor:6,4 m height beneath floor:1,4 m clutch:pneumatic; Ortlinghaus ram adjustment:motoric overload protection in ram:hydraulic ram counterbalance:pneumatic

Used POLYTYPE BDM 501, 6-Color Round Cup Printer, age 1992, Consisting of :-, Automatic Elevator Tray-feeder, Cross Conveyor to main Print unit, Universal screw Denester, CUBITRON Corona Pretreatment System with leak-tester, 8-mandrel Indexing Turret, with Mandrel Holders for Cups, 6 x individually hinged dry-offset Print Heads, Each Print Head consisting of Print cylinder,, radial and axial Print adjustment with micro-register during operation of the Printer, 2 x Form Rubber Rollers dia. 71 and 100 mm, 2 x Oscillating rollers, 2 x Idler Rollers, 1 x Ink Transfer roller (Ductor Roller), 1 x Ink Fountain, Fountain Rollers water cooled, Ink Washing System on Print Heads, UVITERNO MonoJumbo 6015 6kW on-Mandrel UV-Curing Unit, Dual timming Belt Take-off with Air Assist, Short conveyor to counter Stacker station, Return Elevator for Counted Cup Stacks, Max. Cup dia. 135 mm, Max. Height of Cup ...

x-travel: 730 mm y-travel: 730 mm z-travel: 880 mm total power requirement: 57 kVA weight of the machine ca.: 11,5 t dimensions of the machine ca.: 5,5 x 3,0 x 2,8 m Operating hours and spindle hours: 23.323 / 15.894 CNC control: Siemens 840D sl TECHNICAL DATA: X-axis travel: 730 mm Y-axis travel: 730 mm Z-axis travel: 880 mm Max. spindle speed: 12.000 rpm Max. torque: 102 Nm Tool taper: SK40 Max. workpiece weight per pallet: 500 kg Max. workpiece diameter: 630 mm Max. workpiece height: 900 mm B-axis (table) indexing: 360 x 1 degree Number of tool positions: 40 FEED RATES Max. feed rate: 60.000 mm/min Rapid traverse: 60 m/min Jog feed rate: 0 – 5.000 mm/min Total power requirement: 57 kVA Machine weight: approx. 11.5 tonnes Space requirement: 5.5 x 3.0 x 2.8 m EQUIPMENT AND ACCESSORIES 2-station pallet changer, pallet size: 500 x 500 mm Chip conveyor, high-pressure coolant system (40 b ...
