137,838 used machines on RESALE, but how to find them? Machine Search
Diameter over the bed 1600mm. Diameter over the slide is 1250mm. Workpiece diameter min, 320mm. Workpiece length 8000mm. Spindle bore 80 mm. The greatest total cutting force is 16 tons. The greatest weight of the workpiece, 40 tons. Power el. drive motor, 76 kW. Machine dimensions: 14520x2965x2330 mm. Machine weight, 61 t.
Center height [mm] 625 Auction-ID: A1-40982-120
General Description Heavy-duty faceplate lathe manufactured by HEYLIGENSTAEDT , Germany. Designed for precision turning, facing and boring of large rings, discs, shafts and other oversized workpieces exceeding the capacity of conventional engine lathes. The machine is equipped with a large faceplate, heavy carriage and has been modernized with a Schneider Electric variable frequency drive. Technical Details Manufacturer: HEYLIGENSTAEDT Model: Not identified Machine type: Heavy-duty faceplate lathe Year: Not confirmed Large faceplate: Approx. 2,500 mm diameter Conventional manual control Mechanical variable-speed drive: P.I.V. Antrieb Werner Reimers K.G., Variant MRHC 23 Gear No.: 29946061 Oil capacity (P.I.V. drive): Approx. 5.5 L Variable frequency drive: Schneider Electric Altivar 630 (ATV630D11N4), 11 kW Original German spindle speed and feed charts Condition Good ...
- Sino SDS6-3V 3-axis position display - magnetic and manual spindle brake - 3 jaw chucks ø 250 mm - 4 jaw linings ø 320 mm - Stop Z-axis - fixed & running bezels - Multifix Type C incl. 4 holders - Face disc - Lighting system - Coolant sealing Specification - Center width: 1000 mm - Circulating Ø over bed: 500 mm - Circulation Ø over slide: 325 mm - Orbital Ø in eruption: 630 mm - Bed width: 330 mm - Spindle bore Ø: 80 mm - Spindle cone: Metric 80 C8 / D1 - D8 - Speed range: 24 - 1600 rpm - Speed levels: 15 - Metric threads: 0.5 - 28 mm (66 steps) - Inch thread: 1 - 56 tpi (66 steps) - Module thread: 0.5 - 3.5 mm (33 steps) - Thread with diametrical slope: 8 - 56 dp (33 steps) - Longitudinal feed: 0.072 - 4.038 mm/rev (66 steps) - Transverse feed: 0.036 - 2.019 mm/rev (66 steps) - Tool holder: 25 x 25 mm - Tailstock Pinole Ø: 65 mm - Tailstock pinole ...
Gurutzpe Super A lathe. Distance between centers: 6.000mm. Swing: 1020mm. Swing in carriage: 745mm. Swing on gap: 1440mm. Spindle bore: 140mm. Speeds: 16 (9-500rpm). Equipped with 4 independent chuck and steady rest. Equipped with new universal chuck of 500mm. Equipped with new DRO Fagor. Equipped with new Multifix turret. Motorized carriage. CE protections and european certificate for second hand machines.
Copy machine, copying lathe with electronic control Make: Hempel Model: CKE 15 Working length max. 1500 mm Workpiece diameter max. 250 mm Milling motor 11 KW Spindle motor 3 KW Hydraulic motor 3 KW Grinding motor 0.55 KW, hydraulic grinding unit Noise/dust protection cabin
COLCHESTER MASTIFF V/S 1800 universal lathe was built in Great Britain in 1998. The machine allows machining a workpiece with a maximum length of 2000 mm and a diameter of 560 mm (above the bed) or 370 mm (above the support). The 11 kW spindle of the lathe with reading rotates at 1800 rpm. The lathe is equipped with a MITSUBISHI Freqrol A200 inverter and a SONY LH52 digital display. Total weight of the machine is 3250 kg. Technical data of the lathe COLCHESTER MASTIFF V/S 1800 - turning length: 2000 mm - turning diameter above the bed: 560 mm - turning diameter over support: 370 mm - inverter: MITSUBISHI Freqrol A200 - digital display: SONY LH52 - spindle speed: 1800 rpm - spindle bore diameter: 90 mm - spindle power: 11 kW - MASTIFF VS 1800 machine dimensions: (L x W x H): 3750 x 1700 x 2100 mm - total weight: 3250 kg
COLOMBO lathe, H points 800x1500, hydraulic tailstock, displayed.
SMT Lathe 80001350 The machine was designed and manufactured to produce rotor shafts for power tools. The machine is designed and manufactured to perform the following operations automatically. - Load/unload parts automatically from/to tool carrier line with a pick-up & placement unit between the shaft ends. - Rotate ring seat + flat rotate commutator + rotate commutator. - Ring mounting - Commutator side - Ring mounting - Drive wheel side The machine has several production programs to produce different parts. Each program uniquely corresponds to a wave type Specifications Anchor wavelength from up to 92.5 - 163.1 mm Bearing pin diameter commutator side 8; 10; 12.5 mm Drive side 12; 8 mm Min. Available length bearing position 3.6 mm Package diameter 52; 55; 59 mm Ring dimensions Outer diameter 40 - 57.4 mm Inner diameter 37.4 - 56 mm Ring width 4 - 8 mm R ...
Thread-cutting gears, number of teeth: 30, 57, 60, 105, 120, 127, equipment: lead screw for thread cutting, separate feed system, automatic longitudinal and cross feed, change gear for feed and thread gearbox, back gear in the headstock, three-jaw chuck, cross slide and compound slide, four-way tool post, tailstock, an on-site inspection is possible.
turning diameter: 1250 mm turning length: 1500 mm swing diameter over bed slide: 850 mm total power requirement: 22 kW weight of the machine ca.: 6 t dimensions of the machine ca.: 3100x2150x1825 m Brand: JMTCL Type: CW61125B Distance between centers: 1.500 mm Centerheight: 625 mm Swing over bed: 1.250 mm ø Swing over support: 850 mm ø Maximum turning diameter : 1.250ø x 1.500 mm ø Spindle boring: 135 mm ø The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter: 800 mm turning length: 4000 mm control: cnc total power requirement: kW weight of the machine ca.: 7,3 t dimensions of the machine ca.: 6,6x2,2x2 m Brand: Phoenix Type: FL 8040 CNC IT Year of make: 2001 Distance between centers: 4.000 mm Centre height: 400 mm Swing over bed: 800 mm ø Swing over support: 510 mm ø Swing in the gap: 1.100 mm ø Spindle boring: 250 mm ø Steady rest: 350 mm ø 3-Jaw chuck: 630 mm ø Machine dimensions (lxwxh): 6.500 x 2.200 x 2.000 mm Machine weight: 7.300 kg The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
Machine weight: 20,000 kg Faceplate diameter 1250 mm Number of supports: 1 pcs Dimensions: height 4250 mm width 5630 mm depth of 3550 mm Extras: copying apparatus, turret head on the vertical support Technical condition at the time of sale: Replacement rotary amplifier on thyristor converter. Not operated since 1994 p. Small repair and adjustment of electrical and mechanical parts. The maximum dimensions of a workpiece Height 1150 mm The diameter of 1400 mm Weight 8000 kg
GENERAL Project No.: 905398 Quantity: 1 pcs. Manufacturer: EMAG Type: VL 3 Control: Fanuc 18i TB Year of construction: 2001/2022 State of condition: Refurbished machine Layers approx.: 2-3 layers DESCRIPTION TURN circulation diameter over bed cover 210 mm chuck diameter 170 mm speed main spindle 7500 1/min power main spindle at ED 10-40/100% 25/16 kW torque main spindle at ED 10-40/100% 134/85 Nm Spindle diameter in the front bearing Main spindle 80 mm Spindle flange size main spindle size 5 (DIN 55026) Axes on the main spindle unit X/Z Travel in X/Y/Z main spindle unit 400/-/200 mm rapid traverse speed in X/Y/Z main spindle unit 60/-/30 m/min Feed force in X/Y/Z main spindle unit 5000/-/5000 N Direct displacement measuring system main spindle unit X/Z Full clamping cylinder on the main spindle Revolver bottom Number of stations/driven by 12/12 Tool ho ...
Stencil lathe Manufacturer: Hempel Model: HH 9 Heavy-duty version with oil-hydraulic control Max.: Workpiece length: 900mm Hydraulic sliding supports: 5 pcs.
SU 125/3000 Swing over the bed 1250 mm Circular diameter above the 940 mm Tip distance 3000 mm Diameter of clamping plate 1250 mm Maximum workload of the workpiece 6000 kg Machine weight approx. 10,000 kg Delivery items of the accessories : - facing head 710 - 3-jaw chuck 630 - steady rests
Copy lathe Brand: Röhrsdorfer model: 83 199 Year of construction: 1987 Workpiece length 100 - 460 mm Kantel dimensions: 20 x 60 mm Equipment: Workpiece magazine Turning knives Template-controlled rotary blade knife, 3x
Center height: 120 mm Center width: 450 mm Spindle passage/bore: 23 mm Board width: 100 mm Speeds: (12) 180 - 2240 min-1 Travel upper carriage: 140 mm Tailstock mount: MK 2 Quill stroke: 80 mm Motor power: 2.5 kW Connection: 400 V Dimensions approx.: 1300 x 880 x 1250 mm Weight approx.: 600 kg Equipment: Piercing device Quick release holder System Multifix, size Aa Machine light Coolant device
Manufacturer UNIVERSAL LATHE POTISJE EXCELLENT CONDITION, USED ONLY FOR SUPERFINISH AFTER GRINDING Model PA-45 Year Condition used Location Slovenia Price 26.500,00 € Category Lathe Subcategories Stock Number Serial Number Max turning lenght 3000mm Turning over bed 600 mm, Spindle bore 140 mm, Turning in cranking 1.200 mm Face plate 800 mm
Dear customers, currently we offer a used lathe, for processing wood, metal and plastic, of the brand Zimmermann for sale. Here are some technical data of the machine: Turning length: 1,500 mm Tip height above bed: 300 mm Tip height above support: 160 mm Adjustment travel cross support: 1,500 mm Adjustment travel plan support: 260 mm Adjustable travel upper support: 260 mm Main spindle power: 2.2 kW Speed: 375 - 2,700 rpm Dimensions: 2,600 x 900 x 1,200 mm Weight: 650 kg If you have any further questions, please do not hesitate to contact us. to your inquiries.
Lathe Manufacturer: Meusser & Co. - Frankfurt am Main
Lathe Manufacturer: Meusser & Co. Frankfurt am Main
A center lathe with 2-axis digital readout is offered. Tool holder, coolant supply and transparent guard. Inspection possible by prior arrangement.
A CNC lathe is offered. Equipped with three-jaw chuck, tool turret and hydraulic unit. Control: TRAUB SYSTEM TX 8. Inspection possible by prior arrangement.
Designation: Bar feeder Manufacturer: SAMECA Type: Quick Sam 45 Year of construction 1996 Condition: used, functional Delivery: ex site, including truck loading Operating instructions are available
A lathe with CNC control is offered. Equipped with three-jaw chuck, tailstock, tool holder, cutting fluid supply and machine enclosure. Control: HEIDENHAIN. Inspection possible by prior arrangement.
A CNC lathe with bar feeder is offered. Equipped with an IRCO Breuning PROFImat bar feeder and KNOLL 400 S - 1/200 chip conveyor. Control: INDEX C200-4D / Siemens SINUMERIK 840C. Condition: in need of repair, maintenance required. Hoses and guide channels of the bar feeder are defective. The emergency stop currently cannot be reset. The oil pressure/air pressure switch trips the circuit breaker. Inspection possible by appointment.
A compact CNC lathe is offered. Control: Siemens. Condition: defective. Turret enable signal is missing. Inspection possible by appointment.
Echea A-II-6000 lathe. Distance between centers: 6.000mm. Swing: 820mm. Swing in carriage: 600mm. Swing in gap: 1.140mm. Bed widht: 510mm. Spindle: 82mm. Speeds: 12. (12-850rpm). Motor power: 25cv. Max. weight with 1 steady rest: 7.700Kg. Equipped with chuck and 2 steady rest. Weight: 9.600Kg.
turning diameter: 1040/1900 mm turning length: 2000/3000/1250 mm swing diameter over bed slide: 740 mm total power requirement: kW weight of the machine ca.: t dimensions of the machine ca.: m Make: EST-Ticino type: 520/2000 distance between centers min/max: 2000/3000 mm center height 520 mm Max. turning diameter over bed 1040 mm Max. turning diameter over support 710 mm max. turning diameter/length 1900 x 1250 mm spindle passage 135 mm with 3 jaw chuck with 4-jaw chuck quick change holder in very good and immediately ready condition The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
faceplate diameter: 1130 mm swing diameter: 1500 mm turning height: 1100 mm faceplate diameter: mm swing diameter: mm total power requirement: 30 kW weight of the machine ca.: t dimensions of the machine ca.: m Brand: STANKO TYPEL 1512 Build in: 1977 with pneumatick 3-jaw stuck 1130 mm max. turning diameter 1500 mm max. turning height 1100 mm Motor 30 KW The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
turning diameter:1390 mm turning length:14000 mm weight of the machine ca.:13 t More information can be found in the Appendix.
weight of the machine ca.:18 t centre distance:700 mm max. swing diameter:200 mm Lathe with 4 tools only for 3-cylinder crank shaft
Description SHOOTING FRORIEP 40Dv Carousel Lathe. Modernized in 1998, among other things, a driven tool system (C-axis) was installed and the control was modernized to 840 C. Details Serial number 11330051 Year of construction 1980 Control SIEMENS electrical connection 400 V Face plate diameter 3,500 mm Workpiece height 3,000 mm Face plate over corridor 160 mm Total power requirement 71 kW Space requirement approx. 13 x 6 m Reconstruction 1998
turning diameter:360 mm turning length:520 mm total power requirement:20 kW weight of the machine ca.:3,8 t dimensions of the machine ca.:3 x 2 x 2 m
turning diameter:360 mm turning length:520 mm total power requirement:20 kW weight of the machine ca.:3,8 t dimensions of the machine ca.:3 x 2 x 2 m
turning length:400 mm total power requirement:45 kW weight of the machine ca.:4 t dimensions of the machine ca.:3,58 x 1,91 x 2,05 m spindle passage:45 mm
Control SIEMENS Swing diameter over bed 350 mm Turning diameter 180 mm Distance between centers 500 mm Spindle speed 4000 min-1 Tailstock Multifix Accessories
turning diameter:500 mm turning length:1000 mm weight of the machine ca.:7,3 t dimensions of the machine ca.:6,5 x 4,45 x 2,21 m
turning diameter over bed:100 mm turning diameter over slide rest:70 mm turning length:80 mm total power requirement:1,0 kW weight of the machine ca.:0,5 t dimensions of the machine ca.:0,7 x 0,6 x 1,2 m facing lathe with manual feed, various accessories
Parallel Lathe SOCOMO type STAR 305 Between points: 700 mm Maxi Ø on bench: Ø 320 mm Maxi Ø over saddle: Ø 175 mm Spindle diameter: Ø 36 mm Rotation: from 70 to 2000 RPM 3-jaws chuck Ø 200 mm Threadings: Metric + Whitworth Tailstock: CM3 Auto feeds longitudinal + transversal Length: 1800 mm Depth: 800 mm Total height: 1200 mm Weight: approx 1 T
PROMA SPF-1000PH universal lathe was manufactured in 2019 in the Czech Republic. The machine is designed for precision machining of internal and external cylindrical, conical and end faces, as well as grooving, bar turning, drilling and threading with adjustable thread stroke size. The optimum rotation speed scale and high-quality cast iron construction, allows the use of high-speed steel and carbide-tipped tools. Workpieces with a maximum length of 1000 mm are machined in a fully illuminated workspace using a powerful spindle with 12 speed stages ranging between 25 and 1800 rpm. Among the extensive equipment of the conventional lathe are a SINO SDS6-3V digital readout and a 3-jaw universal chuck. The total weight of the PROMA SPF 1000PH machine is 2635 kg. Technical specifications of the PROMA SPF-1000PH lathe - maximum turning length: 1000 mm - maximum turning diameter (above t ...
turning diameter:500 mm turning diameter over bed:500 mm turning dia. over base-slide:290 mm centre distance:1000 mm centre height:250 mm z-travel:1350 mm speeds:10 - 3000 U/min
maximum number of results exceeded
please refine your search
5.000 €
