side squaring used for sale

A line for the production of water packed into PET bottles in the following formats: 0.5 L, 1.5 L and 2.0 L. Line capacity: approx. 15,000 bph The line consists of the machines sent in the previous messages: 1) KHS filling triblock filling machine 45-80-10 1998 (approx. 20,000 bph), control: SIEMENS S7-200 - washing KHS, Innoclean FR-EM 45 bottles - KHS filler, Innofill EV 80 - capping machine ALCOA KUPI 10/540 (max. 25.000 bph) 2) labelling machine KRONES Contiroll 745 - 2000 (16.000 bph), control: S7-300  3) PET BOTTLE BLOWING MACHINE - SIDEL SBO 16 - 1998 (16.000 bph) 4) packing machine with a tunnel - ZVT PSP 032 S, year 1998 5) device for controlling the level of liquid in bottles - METEC Promecon 2000 5) LANFRANCHI air conveyors with control cabinet (transport of PET bottles from SIDEL to KHS)  6) a set of KHS Innoline plate conveyors - several ...

Original Molds for SIDEL SBO 10 totally 12 sets, year 2017 JADE has 12 sets of 10+1 pc PET bottle blow molder aluminum molds for sale, all made by SIDEL France in year 2017. Molds were used in SIDEL SBO 10 blow molder with energy saving air recovery system type SIDEL AirEco. Molds are for PET bottles from 250 ml to 2.0 liters with neck standard PCO 1881 (short neck) product being still and sparkling water. This SBO 10 was operated only 16 months (with 12 sets of molds) and thus molds are in excellent condition. Delivery will include also standalone shelves for holding the moulds safely in production and two sets of stretch rods

Labelling Machine SIDEL Flexible SL90 F85 Cold Glue / Self-Adhesive This SIDEL SL90 labelling machine has three roll feed labelling modules for the application of adhesive (pressure sensitive PSL) labels and three pre-cut cold-glue paper labelling stations both designed for round glass bottles 275 – 660 ml. Operation is anticlockwise. Machine has been operated from 2012 to 2020 when it was dismantled and placed in a warehouse. The labelling machine SL90 operates in continuous mode and automatically adjusts the flow of incoming and outgoing containers. It is also equipped with a camera vision system which is installed in the initial section of the central carousel to detect and identify the containers. It also ensures correct application of the labels on even more complex formats. This system is ideal with containers made of glass, PET and other transparent materials. The con ...

W 85 | PET BLOWER SIDEL SBO 6 YEAR: 1999 SPEED: 7.800 BPH MODEL: SBO 6 SERIE 2 NUMBER OF CAVITIES: 6 PREFORM TIPPER SIDEL HOPPER AND PREFORM FEEDER SIDEL STAMP NOT INCLUDED SAFETY PROTECTIONS

W 84 | BLOW MOULDING MACHINE SIDEL YEAR: 1998 SPEED: 7.200 BPH SUL 1.5 L MODEL: SBO 6/10 SERIE 1 NUMBER OF CAVITIES: 6 BOTTLE NECK FORMAT 29/25 MM PREFORM ELEVATOR/ORIENTATOR STAMP NOT INCLUDED WORKED HOURS: 47.000 SAFETY PROTECTIONS

Blowing machine SIDEL SBO 16 / 20 capacity: approx. 25.000 bph - by 2,0 ltr. PET bottles year of manufacturing: 2011 working hours: 37.000 max. capacity: 32.000 bph neck type: 38 mm widemouth neck includes: - preform tipper - preform hopper / elevator - Sidel AGR preform disinfection - Sidel Predis Ultra Clean - vulcanic water/oil thermoregulator - electrical cabinet - control panel - Sidel PCC The machine is in an excellent conditon.

Used Blow Moulding Machine Sidel SBO6 2 Year 2005 9000 bph The machinery has been disconnected from the functioning production The PLC is present and its functionality is ensured The machinery as a whole is in a good state of maintenance pre production maintenance is still recommended because the blow molding machine has been in storage for about 12 months Transport is a large load therefore outside the normal gauge We can supply all necessary spare parts for this blow molding machine [...for more information send your inquiry to the seller.] refno: SO81

Used Filling Line Sidel For Water 2014 Air Compressor ABC 3HA 4 TFK LT 200kw Air compressor Low Fusheng SA75 75KW Ice water Machine Nanjing Wuzhou LSBLG 1290DT 1256 8KW 298 8KW Ice water machine Shanghai Baoqing WA 78W PT4EN I 49kw Blow Molding Machine SIDEL SBO20 Blower Capacity 36000P H Power 406KW Spindle heads 262 pcs Manipulator 10pcs each Blow moulding satation 20 pcs SIDEL Filling Machine Capacity 36000P H Power 35KW Filling Valves 60pcs Capping heads 15 pcs SIDEL 36000 bph Labelling Machine Capacity 600B min Power 50KW Vacuum drum 1 set Scaleplate 2 pcs Capping heads 20 pcs SMI Shrink Wrapper Capacity 35 P Min Power 75KW Divider 4 sets Infeed 4 sets Former 5 sets TW Benifit Palletizer with Conveyor and Divider Capacity 35 P M Power 25KW Used Filling Line Sidel For Water 2014 this complete line for water is in excellent conditions and ready immediately for sale [...for more inform ...

Used Stretch blow molding machine SIDE linear SBM speed 2000 BPH Manufacturer and year SIDE Spain 2002 Mold 8 5 L with 2 cavities square Can blow preforms for 3 5 6 8 liters with a neck size of 48 mm Has hopper No compressor or cooler are offered The machine is in good condition and regularly maintained Dimensions width 2245 mm length 3600 mm height 2060 mm Space required for the Used Stretch blow molding machine The blower itself needs about 20 m2 and the rest depends on what equipment you will get compressor cooler The blower power is 80 kW High pressure required Max 40 bar air 300m3 h otherwise it worked with 32 33 bars Low pressure 6 10 bar 100m3 h The refrigerator should be cooled to 6 10 C at a pressure of 3 5 bar Technical documentation is available Spare parts are available Stopped working 2 years ago but can be seen in operation [...for more information send your inquiry to the  ...

Used Blow Molding Machine Sidel 1992 Manufacturer SIDEL Model SBO2 Year 1992 Speed b h 3000 Processed formats 0 25ml 2 liter Accident prevention protections Yes Manuals available Yes Revisions available Yes Operating status In production Number of cavities 2 Preform neck type Preform 1881 weight 9000kg Quick format change Yes Preform loader Yes Preform orientator Yes Compressor No Chiller No Air recovery system No PLC type Mitsubishi Spare parts available Yes Hours worked 2000 Consumption Volt 360 Kw 40 Hz 100 Notes Machine working stabile suitable to be connect with filler machine The machine has been completely updated hmi electronics and new plc [...for more information send your inquiry to the seller.] refno: SO96

Used Complete Pet Line Sidel 1995 SIDEL PET production line for carbonated mineral water with efficient performance 16 000 BPH 1 5 litre low 1881 cork The machines of the following used bottling line can also be offered with pre production maintenance This could make it possible to improve the efficiency of the line which today is about 80 of the rated speed The machine brands it contains are primarily international and still all on the market as spare parts Composition 1 Blow moulding machine model SIDEL model SBO 16 16 with cooler and 40 bar compressor Year of manufacture 1995 2 A set of air conveyors for PET bottles corresponding to the productivity of the line Year of manufacture 1995 3 Triblock brand SIDEL model 44 100 12 rinser formed by 44 pcs Bottling 100 pcs Capper and AROL 12 pcs Year of manufacture 1995 4 Elevator for loading and feeding the screw plastic cupper to the bunker  ...

Used Complete PET Filling Line 2001 Looking for a complete PET filling line to increase your production capacity We have just what you need a used complete PET filling line from 2001 that can handle up to 18 000 bottles per hour Here are the details of the line Blowing machine Krones Contiform S 16 year of manufacturing 2002 with air recovery system including preform feeding system Air conveyor Sidel year of manufacturing 2001 Tribloc Sidel Alsim 100 140 20 with 100 rinsing stations 140 mechanical volumetric filling valves and 2 head Arol plastic screw capper year of manufacturing 2001 This also includes a cap feeding system by Meyer Mixer GEA year of manufacturing 2001 Complete bottle conveyor system GEBO including conveyor lubrication system Labelling machine Krones Contiroll to label OPP labels from the roll by hot glue year of manufacturing 2003 Shrink packer and heating tunnel Krone ...

Sidel SBO 10 Used Blow Molding Machine 1994 The Sidel SBO 10 Used Blow Molding Machine 1994 is a high quality machine manufactured by Sidel This machine is designed to create containers made from PET material and comes in a format of 1 5 L The model number of this machine is SBO10 and it was produced in the year 1994 The Sidel SBO 10 has a speed of 10000 bottles per hour making it an ideal choice for businesses looking for a reliable and efficient production process This machine comes equipped with ten cavities allowing for the creation of multiple containers simultaneously It also includes a preform loader preforms tipper and preforms unscrambler which work together to ensure that the preforms are loaded and positioned correctly for the blow molding process The Sidel SBO 10 Used Blow Molding Machine 1994 does not come equipped with a compressor or chiller so these will need to be provid ...

Sidel Cermex Used Wrap Around Packer Efficient Packaging for Glass Containers We have a used wrap around packer from Sidel Cermex available for purchase This packer is specifically designed for glass containers in 0 33 L format and can pack up to 12 000 boxes per hour of 24 bottles each Features and Specifications The packer has a straight entrance and is highly efficient ensuring that your production line runs smoothly The machine is currently in a ready for operation state and comes equipped with safety features and manuals making it easy to operate and maintain Additional Details The packer is in need of revision but is still capable of efficiently packing your glass containers into boxes With its high speed and reliable performance this machine is an excellent investment for any production line Invest in Your Production Line Today If you are looking for reliable and efficient packagi ...

Used blow moulding machine Sidel SBO 8 series 2 up to 12000 bph Introduction of the blow moulding machine Sidel SBO 8 In the bottling field the choice of suitable machinery is crucial The used Sidel SBO 8 blow molding machine series 2 stands out for its production capacity and reliability Designed in 2004 this 2 series represents a cost effective option for companies looking for efficiency and quality in the bottling sector Technical details The Sidel SBO 8 series 2 is a bottle blowing machine that has accumulated 19857 working hours This data reflects the experience and resistance of the machinery over the years It is important to note that the machine is sold without molds This offers considerable flexibility in terms of customization and adaptability to specific production needs Maintenance and Reliability of the blow moulding machine Sidel SBO 8 The last maintenance intervention was  ...

Overview This labeller was built in 2015 by French company Sidel. The machine can be visited. Techn. Details Capacity: up-to 25 000 bph (depending on label length) Label position: wrap-around Label material: plastic, from roll

Used Combi Sidel Bottling Line 2006 Are you in search of a top tier bottling solution for your still water product Look no further than the exceptional Used Combi Sidel Bottling Line from the year 2006 With a proven track record in the industry this Sidel Line offers unparalleled performance and efficiency ensuring that your production process remains seamless while maintaining the highest quality standards Key Features of Sidel Combi line 1 Impressive Speed The Used Sidel Bottling Line manufactured in 2006 boasts a remarkable speed of 25 200 bottles per hour BPH This means your production output can meet demanding market requirements without compromising on precision and excellence 2 Dedicated to PET Crafted specifically for PET containers this Used Combi Sidel Bottling Line is optimized to handle PET packaging with the utmost care This ensures that your still water products are preserv ...

Overview This machine was built in 1998 by French manufacturer Sidel. The machine is in very good working condition, is already professionally dismantled and stored in a warehouse. Techn. Details Capacity: 7.200 bph in 1,5L Number of moulds:  6 (molds not included) Equipped with quick change for shell molds Number of heating modules: 10 modules Neck personalization: 29/25           Working hours: 47.000 only            Machine was regularily maintained       Machine equipped with:                     Sidel preforms elevator to unscrambler Sidel preforms unscrambler & feeder Sidel oven & blowing wheel for 6 molds Sidel electrical cabinet Sidel PCC drive & control panel Big set of spare parts list upon request

Overview The blow moulder was built in 1999 by French manufacturer SIDEL. The machine is in very good working condition, still in production and can be viewed in person. Techn. Details Current capacity: 23.400 bph at 1.25L Working hours: 40.000                   Number of moulds: 18       Moulds type: Shell type quick change Formats produced: 1.25L Bottles: Cylindrical petaloid base Oven type: Sidel Neck personalization: PCO 1881  Type of preforms: with recycled PET resin Machine was regularly maintained     Machine equipped with:                     Sidel preform tipper Sidel hopper with cover & feeder Sidel preforms unscrambler Sidel preforms infeed rail Blowing station for 18 moulds Sidel electrical cabinet with Siemens Sidel PCC drive & control

General SKU108Y770 LocationBarneveld Year of construction1996 Main Features MaterialStainless steel Number of1 heads Dosing1000 ml Specified Features - Piston filler MaterialStainless steel Piston filler(1x) Dosingmax. ± 1000 Ml Number of pistons:1 (dia. 95x200mm) Number of filling heads:1 With hopperequipped with stirrer and electric heating Mounted on framecheck With switchgearcheck Mounted on wheelscheck Floorspace1,8x1,3 M Total height2,6 MPiston fillersHema (Sidel)Packaging machines > Piston fillersBrand > Hema (Sidel) What you can expect from Foeth: -- Machine is in working condition -- At a reduced price compared to new -- Ready for shipping to any destination worldwide -- You are welcome to inspect the machine in Barneveld, The Netherlands. Please visit us in Barneveld for many more machines!

Tetra-Plast LX-2 (Sidel) PET bottles blow moulding machine for sale, maximum capacity of 3.000 bottles per hour with zero working hours completed in 2011. The machine was dry cycled and tested by a Tetra-Pak (Sidel) technician. The machine has the following components: 1. Main PET bottles blow moulding module 2. Silo with elevator for preforms 3. Chiller for cooling MTA-TAE 051 4. Moulds lifting device The moulds are not included in the price. The price given is Ex-Works our warehouse. The Tetra-Plast LX-2 (Sidel) PET bottles blow moulding machine for sale with two moulds, serial nr. 40102/2542, maximum capacity of 3.000 bottles per hour with zero working hours, and size of bottles between 0 and 2 liters. The machine was completed, dry-cycled and tested in 2011. It does not come with a pressure compressor. The machine does the movements with a press. The mould was ...

PET bottle blow molding machine, with a production capacity of up to 4000 bottles/h (depending on the format). For formats between 0.25 liters up to 3 liters. Composed by: - Oven for heating preforms composed of 6 heating modules with 8 infrared lamps each. - Preform transfer wheel - Compressed air blowing body in two stages, low pressure pre-blowing and subsequent high pressure blowing. - Bottle transfer wheel Delivered with pallet turner. Available documentation

PET Blow molding machine SIDEL SBO 18 Manufacturer: SIDEL Model: SBO 18 Manufactured in: 2001 Capacity: 26.500 bph Working hours: approx. 44.000 hours The machine was uploaded with a new program in 2006 and its output upgraded to 26,500 bph. The machine includes preform tippers for 2 Octabins each. Preform vertical conveyor up to the entry into the machine.

Overview The blowing machine TMS 2001 G was manufactured in 2001 by Spanish manufacturer SIDE. It processes with a capacity of 1,000 bph at 5l. The machine is stored because the former user has changed to a new one. It is located in Spain and has already been disassembled and available immediately. Tech Specs Capacity: 1,000 bph at 5000 ml    Additional Equipment No blow molds included CP: Siemens simatic MP270

Overview This complete filling and packaging line for PET bottles is designed for an output of 18,000 bottles per hour and different bottle formats can be run. The line is still in production and will be vacant in spring 2024, as it will be replaced by a larger one. Individual machines  Preform tipper | Tanner | KPT-2020 | 2004 Compressor | Atlas Copco | - | 2004 Blow molder | SIG Corpoplast | BLOMAX 12 | 2004  Capacity: 18,000 bph  12 cavities Min./ max. volume: 0.2l - 3.0l  Bottle length min./ max.: 107mm/ 350mm Preform length min./ max.: 60mm/ 200mm  Dimensions (LxWxH): 6.947mm x 4.419mm x 3.357mm  Including Cooling unit, preform tipper, PET erector Filler | SIG Simonazzi (now SIDEL) | EUROSTAR 2000 | 2003 Capacity: 21,500 bph Number of filling valves: 100 Format: designed for 0.5l, others: 1.0l -1.5l  Closure type: plastic 28mm  Ozomix plant | Aeraque | Ozomix 300K | 2004 ...

Overview This SIDEL blow moulder and KHS filling monobloc were both manufactured in 1999. They are still in production until the end of October and can be viewed in person. Technical Details Blow moulder | SIDEL | SBO 18 Series 2 | 1999 Current capacity: 23.400 bph in 1.25L Working hours: 40.000                   Number of moulds: 18            Moulds type: Shell type quick change Formats produced: 1.25L Bottles: Cylindrical petaloid base Oven type: Sidel Neck personalization: PCO 1881  Type of preforms: with recycled PET resin Machine was regularly maintained     Machine equipped with:                     Sidel preform tipper Sidel hopper with cover & feeder Sidel preforms unscrambler Sidel preforms infeed rail Blowing station for 18 moulds Sidel electrical cabinet with Siemens Sidel PCC drive & control Lanfranchi bottles buffer storag ...

Sidel Cermex Used Palletizer High Quality Glass Container Palletizing We have a used palletizer from Sidel Cermex available for purchase This palletizer is specifically designed for glass containers in 0 33 L format and is capable of palletizing bundles Features and Specifications The palletizer is a conventional automatic type and has a fixed type of operation The low level type of handling ensures that the machine is highly efficient and safe to operate The machine is currently in a ready for operation state and comes equipped with safety features and manuals making it easy to operate and maintain Additional Features The palletizer comes with an empty pallet magazine a PLC and transfer conveyors for boxes connected with a wrap around packer The machine also has transfers inside for full pallets ensuring seamless operation and efficient palletizing Invest in Your Production Line Today I ...

Used SIDEL ROLLQUATTRO F45 Labeling Machine up to 20000 bph Introduction of the Used SIDEL ROLLQUATTRO F45 In the dynamic realm of beverage manufacturing ensuring accuracy and efficiency in labeling processes is paramount This is exemplified by the comprehensive work performed by the used SIDEL ROLLQUATTRO F45 labeling machine renowned for its capacity to handle up to 20000 bottles per hour bph which stands as a testament to cutting edge labeling technology Technical Specifications Introduced by Sidel in 1999 the SIDEL ROLLQUATTRO F45 is specifically engineered for PET containers Its versatility shines through as it can accommodate bottle sizes ranging from 0 33 L to 1 20 L ensuring adaptability across various product lines Operational Details Powered by 36 meticulously designed plates and mechanical cams the machine guarantees precise label positioning with each cycle Moreover its count ...

TRIBLOK ALSIM (Sidel) from the production of mineral water from Western Europe, still in production, dismantling by a professional company Mark ALSIM Sidel Type Washer/Filler/Sealer Year of production 1997 Dimensions Length L 7564 mm Width W 8700 mm Height H 3446 mm Description Alsim Rinser Asmojet (1997) and 1x Alsim Filler RV.P (1997), capping machine; lots of spare parts Power supply 380V 50Hz three phase Voltage 24V Power 32.5kW Syrup feed - pressure 1 - 1.5 bar Water supply-pressure 1 - 1.5 bar CO2 power supply 10 - 12 bar Compressed air 6 bar Air consumption 500Nl/min Compressed air connection ½ gas CO2 power supply DN25 Water supply DN65 Product output DN100 Product power DN50

Sidel Cermex SW 21.40 case packing machine Sidel Cermex SW 21.40 case packing machine Manufacturer: Sidel Type: SW 21.40 Year of manufacturing: 2009 Available: Immediately Speed max: 11,000 cartons/min Length: 150/450 mm Width: 140/375 Hight: 110/400

Manufacturer : Sidel Model: 99000863608   Power supply: 220 V Cutting capacity: ? 60 - 160 mm Maximum length 400 mm Maximum number of simultaneous cuts: 4

Overview This complete can filling line for CSD & Beer was manufactured 2012 by French company Sidel. The line is still set up but no longer in use. Techn. Details Capacity: 27,000 cans per hour Beverages: Carbonated soft drinks, Beer Can type/Lid: 330 ml with 202 super end double seam Components Sidel Sweep off A/Z empty can depalletizer Magnoni vacuum transfer Magnoni gravity rinser Sidel Starcan MS 50V filler Ferrum F 706G seamer Sidel Starblend D3 EX 0433 EX460 mixer Sidel ML 2.4.ST1 CIP tank (4000L) Sidel CWD35/144 pasteurizer Magnoni can dryer (after seamer) Magnoni can dryer (after coder) Sidel TSP3 SDI BW tray & shrink packer Manual palletising Rotoplat semi-automatic pallet wrapper Conveyors

Overview  The blowing machine was manufactured by Sidel in 2004 and has only been used by a mineral water company. The machine has been regularly maintained and is in good condition. The seller bought a bigger machine, therefor this machine is available for sale. Technical Details  Capacity: 9,600 bph with 1.5 l and 12,000 bph with 0,5 l Number of cavities: 8 Formats / moulds included: 1,5l Bottle neck: PCO 1881 and 29/25 Additional equipment  Preform kipper Preform hopper Preform feeder

Overview The blow moulder was built in 2011 by French manufacturer SIDEL. The machine is in very good working condition, is already professionally dismantled and stored in a warehouse. Techn. Details        Working hours: 37.289 h Capacity Max. 32.000 bph Recently produced at 25.600 bph at 2.0L Number of moulds: 16 hot or cold molds Molds: Hot molds up to 75°C, or standard Equipped with quick change Oven type: Sidel Universal Eco2 C3 special filters Number of heating modules: 20 modules Neck personalization: 38 mm Machine was regularily maintained                           Machine equipped with:                     Sidel preforms tipper Sidel preforms hopper & feeder AGR preforms disinfection Sidel Predis Ultra Clean Vulcanic water/oil thermoregulator Sidel electrical cabinet Sidel control panel Sidel PCC

Used blow molding Sidel SBO 12 Series 2 The Sidel SBO 12 Series 2 represents a culmination of this evolution boasting advanced features and capabilities Over time blow molding machines have become indispensable in modern manufacturing Reliable Performance and Durability of the Used blow molding Sidel SBO 12 Series 2 Moreover the blow molding machine stands out for its exceptional performance and durability With a modest operational lifespan of 45 000 hours it has proven to be a reliable workhorse in the production line Its robust construction and precise engineering ensure consistent quality and productivity making it a valuable asset for manufacturing operations Comprehensive Maintenance Support In addition maintenance and servicing are crucial aspects of ensuring the longevity and performance of blow molding machines Sidel a leading manufacturer in the industry offers comprehensive sup ...

4-side squaring and edge banding line Machine 1: Fixed side right, moving side left Rolling chain, feed 10 - 40 m/min Controlls NC 21 Panel thickness 8 - 60 mm Max. panel width 1500 mm Edges: coil 0,3 - 3 mm, strips 0,4 - 20 mm Entry fence for veneered panels Equipment: 1+1 Compact-twin hogger, 2 motors 6,6 kW 1+1 Compact hot melt unit A20 with panel edge pre-heating, glue roller Q34, twin coil magazine, lateral pressure rollers C including anti-stick application 1+1 Free space for solid wood edges up to 2,54 m length 1+1 Rough trimming, 2 x 1,5 kW 1+1 Fine- or radius trimming, 2 x 0,4 kW (edges up to 6 mm) 1+1 Universal shaper 8,1 kW 1+1 Universal shaper 8,1 kW 1+1 Edge sander KS 10 1+1 Disc sander DS 40 1+1 Disc sander DS 40 Angular transfer to the right, TWR 24/30/12/S Panel sizes: width 250 - 1200 mm, length 250 - 3000 mm, thickness 8 - 45 mm Machine 2 Machine II + infeed magazine TW ...

Panel thickness: 12 - 60 mm Feed speed: 18 m/min Edge thickness: 0,3 - 3 mm for coil edges Equipment: Programmable fence at the infeed Squaring device: 2 x 3,0 KW Glue application unit: A34 double edge magazine for 2 coils Lateral pressure rollers, thickness programmable, 1 driven, 2 non-driven rollers End trims HL84/85, programmable change straight/chamfer, 2 motors 0,18 kW Rough trimming: 2 x 0,55 KW Contour trimming FK 13, 2 x 0,55 KW Profile scrapers PN10 Flat scrapers Buffing unit Controlls: HOMATIC NC21

Panel thickness: 8 - 50 mm Thickness of the edges: 0,4- 3 mm Feed speed 8 - 11 m / min PU pressure rollers Equipment: Non-stick spray system Squaring unit, 2 motors 2,2 kW Panel edge heating Edge magazine for coil and strips Hot melt application with roller Airtec AT4510 unit The Airtec aggregate is positioned so you can use Airtec or the standard glue pot Motorized side pressure unit End trims, 2 motors, pneumatic positioning straight and with chamfer trimming unit above / below Contour trimming unit Profile scraping unit Glue scraping unit Polishing unit Detergent spray system central lubrication Powertouch control

Fixed side at the left Feedspeed 18 - 25 m/min Working width min 60mm for panel thickness 22mm, 105mm for panel thickness 40mm Panel overhang 30mm Panel thickness 8 - 60 mm in stead of 12 - 40 mm (with limitations) Coil edge thickness: 0,3 - 3 mm, strips 0,4 - 20 mm Coil diameter 830 mm Equipment: Sprayers release agent Squaring device with 2 motors each 3 kW Edge heating Edge magazine for 2 coils, guillotine for edges up to 3 mm Glueing part A20 with quickmelt application Lateral pressure zone K, 1 driven and 6 after pressing rollers End trims HL84, 2 motors each 0,8kW Rough trimming, 2 motors 1,5kW Contour trimming, 2 exchange units Profile scraping PN10 Flat scrapers FA11 Sprayers cleaning agent Buffing Automation package straight/chamfer: -Automatic adjustment infeed fence -Automatic setting of pressure rollers -Pneumatic setting of end trims -Pneumatic setting of rough trims -Automa ...

Single sided edge bander with squaring device Edges: 0,4 to 12 mm Panel thickness: 10 to 55 mm Min. panel width: 60 mm Feed speed 12,5 m/min Equipment: Squaring device Heating zone Coil- and stripmagazine Glue unit Pressure zone End trimmer Chamfer trimming Mutlifunctional milling aggregate Profile scraping glue scrapers Buffing

Motorised height-adjustment Sound enclosure over all trimming motors Equipment: Coil and strip magazine Hot melt unit Pressure zone End trims, chamfer and straight, automatic adjustment Top/bottom rough trimming Top/bottom fine trimming, tilting, Contour trimming unit Scraping unit Buffing unit return conveyor Ligmatech ZHR 05

Single sided edge bander with hot melt, fixed side at the right, pre-milling unit Edge thickness: 0,4 to 12 mm Workpiece thickness: 8 - 60 mm Feedspeed 8-20 m/min (limited to 10 m/min using the contour trimming) Workpiece transport by chain, top pressures with rubber rollers Sound enclosure over all trimming motors Equipment: Adjustable fence Pre-milling with 2 shapers, each 2,2 kW Coil and strip magazine Hot melt unit, Quickmelt type Pressure zone with1 driven and 2 non-driven pneum. Loaded rollers End trims, 2 x 0,35 kW motors, straight and chamfer 15? Top/bottom trimming, motors 2 x 0,35 kW Radius trimmming Contour trimming unit, leading and following edge, 2 x 0,35 kW Radius scraping unit Glue scrapers Buffing unit Controlls PC 20+

Fixed side at the left Feedspeed 18 - 25 m/min Working width min 60mm for panel thickness 22mm, 105mm for panel thickness 40mm Panel overhang 30mm Panel thickness 8 - 60 mm in stead of 12 - 40 mm (with limitations) Coil edge thickness: 0,3 - 3 mm, strips 0,4 - 20 mm Coil diameter 830 mm Equipment: Sprayers release agent Squaring device with 2 motors each 3 kW Edge heating Edge magazine for 2 coils, guillotine for edges up to 3 mm Glueing part A20 with quickmelt application Lateral pressure zone K, 1 driven and 6 after pressing rollers End trims HL84, 2 motors each 0,8kW Rough trimming, 2 motors 1,5kW Contour trimming, 2 exchange units Profile scraping PN10 Flat scrapers FA11 Sprayers cleaning agent Buffing Automation package straight/chamfer: -Automatic adjustment infeed fence -Automatic setting of pressure rollers -Pneumatic setting of end trims -Pneumatic setting of rough trims -Automa ...

Workpiece thickness: 8 - 90 mm, electronically adjustable Feed rate: 18-32 m/min frequency controlled Edge thickness: 0.3 - 3 mm for roll edges, strips up to 20 mm Equipment: Inlet guide automatically adjustable via the control, extension 500 mm Joint milling unit: 2 x 3.0 KW workpiece preheating Gluing unit A34 edging magazine for roll Pressure zone with 1 driven, 6 non-driven rollers, automatic adjustment from the control Cutting unit WK14, straight, 2 motors 0.8 kW Pre-milling unit: 2 x 1.5 KW, pneumatic adjustment Form milling unit FF 12 automatic, 2 motors 0.4 kW radius/phase milling unit FF12 automatic 4 motors 0.4 KW universal milling aggregate controlled UF11, 4 kW Profile scrapers PN20 Glue scrapers Nozzles for detergent and anti-stick Polishing unit Control: Power Control PC22

Workpiece thickness: 12 - 60 mm Feed speed: 18 - 24 m/min Edge thickness: 0.4 - 6 mm for roll edges, 0.4 - 20 mm for strips Equipment: manual fence at the infeed workpiece preheating Bonding unit: QA34 / A20 edge magazine Pressure zone with 1 driven, 6 non-driven rollers, automatic adjustment from the control Hood unit HL83, automatic adjustment phase/straight, 2 motors 0.4 kW Pre-milling unit: 2 x 1.5 KW Milling unit, with sensing, tiltable, 0.4 kW Mold milling unit FF 12, 4-way tool changer, 4 motors 0.4 kW universal milling unit profile sanding unit edge sanding unit Control: HOMATIC NC21

Workpiece thickness: 8 - 50 mm Edge thickness: Coil edges 0.4 - 3 mm Feed speed 10 m/min Equipment: manual height adjustment. Joint milling unit, 2 motors Panel edge heating Gluing area Pressure zone 1 driven and 2 non-driven rollers End trims, 2 x 0,8 kW motors, straight and chamfer 15? Top and bottom trimming Profile scraping unit for PVC edging Glue scrapers

Edge banding installation consisting of the following elements: - feed table TB 10/10/20 - edge bander KAR 610/20/PU/S2 - panel turning station cross/longitudinal TD 51/30/12 - destacking robot KUKA KR 180-2 PA - Ligmatech return system installation specifications: workpiece dimensions length 300 - 3200 mm width 120 - 1200 mm (for dogs), 1800 mm (equal to longitudinal entry) thickness 12 - 60 mm weight max 80 kg edging material 0.4 - 2.0 mm throughput speed 25m/min robot 10 strokes /min Equipment edge bander: Infeed fence automatically adjustable anti adhesive sprayers Squaring device UF20: 2 x 4.0 KW Workpiece preheating Glue application unit PU34 6-fold edge magazine for rolls Pressure zone with 1 driven, 6 non-driven rollers, automatic adjustment End trims HL86, pneumatic adjustment phase/straight, 2 motors 0.22 kW Rough trimming: 2 x 0.55 KW Contour trimming FF12 , 4 motors 0.4 kW Pr ...

Panel thickness: 12 - 60 mm Feed speed: 18 - 24 m/min Edge thickness: 0,4 - 3 mm for coil edges, 0,4 - 20 mm for strips / solid wood Equipment: Help carriage feeding the panels rectangular automatic fence at the infeed Squaring device: 2 x 3,0 KW Panel edge pre-heater Hot melt unit: QA34 / A20 edge magazine Lateral pressure rollers, thickness programmable, 1 driven, 6 non-driven rollers End trims HL83, programmable change straight/chamfer, 2 motors 0,5 kW Rough trimming: 2 x 1,5 KW Top/bottom fine trimming, tilting, 2 x 0,4 kW Contour trimming FK 13, 2 x 0,4 KW, with 8-fold toolchangers Universal milling motor 4kW Profile scrapers Flat scrapers Buffing unit with oscillation Controlls: HOMATIC NC16

4 sides trimming line

Longitudinal saw without lamella support Cutting length 6200 mm Cutting width 600 mm Cutting height 170 mm Saw motor 11 kw Built in 1989
