side grinding used for sale

Gebr. Carousel multi-station grinding machine

Knuth RSM 1000 CNC B cylindrical grinding machine G-Plus in good condition from 2013 (commissioning 2014) with many accessories Grinding length: 1,000 mm Center height: 180 mm Outer grinding diameter: 8 - 320 mm Z-axis travel (outer): 1,000 mm Inner grinding diameter: 30 - 100 mm Z-axis travel (internal): 125 mm Weight piece: max. 150 kg Table swivel range: -7° ; +3° Table feed: 10 - 5,000 mm/min. Grinding spindle power: 5.5 kW Total engine power: 12.8 kW Weight: 5.3 t Complete operating instructions for the machine and programming (Knuth GPlus 450) Price plus VAT

Grinding machine, angle grinder, lathe grinder, thread drill grinder, milling cutter grinder, surface grinder, drill grinder, bench grinder -Grinding attachment: for tool grinding machine or lathe for internal cylindrical grinding with dressing device -Motor power: 0.7 kW -Dimensions: see photos -Equipment: coolant connection, dressing device -Dimensions: 600/540/H330 mm -Weight: 49kg

Studer S31 Spw.: 1000mm/ Sph.: 175mm Fanuc 16i- TB Control Commissioning 2004 Strokes X-axis 285mm/ Z-axis 1150mm Universal cylindrical grinding machine 2x external and 1x internal grinding

For sale is: 1 piece used CNC surface grinding machine Manufacturer: Jung Type: 740C Year: 1996 Siemens 840 controller Electromagnet 700 x 400mm Complete metal powder filter and conveyor system Machine weight: 6.000Kg For more technical data, see pictures. Complete documentation, some new grinding wheels included Videos can be sent on request. The machine can be viewed in our warehouse in 09599 Freiberg.

Surface grinding machine from Ziersch & Baltrusch in good condition Sanding area: 450 x 200 mm Weight: 1600 kg

ELB Perfect BD 15 PLC surface grinding machine, grinding area 1500 x 550 mm, grinding wheel 400 x 100 mm, electric perm magnetic clamping plate 1500 x 550 mm, automatic dresser with compensation, paper belt filter, the machine is overhauled, grinding spindle rebeared, guideways are scraped, meets the tolerance of a new machine. We are happy to take over the installation / training on site, as well as the subsequent service

ELB Perfect BD 10 SPS, built in 2003, grinding area 1000 x 400 x 400 mm, the machine was overhauled in 2012 and equipped with the new ELB Easy Grind control, accessories: Electric Perm magnetic clamping plate 1000 x 600 mm, Automatic straight dresser for the grinding wheel mounted on spindle box, with dressing compensation, coolant tank with paper belt filter, suction. The machine is functionally tested and can be viewed under power at our site, we are also happy to take over the installation and training on site.

Digital display: 2 axes Grinding area: 600 x 250 mm Electro-permanent magnet: 600 x 200 P=4 mm Table load without magnet max.: 250 kg Distance between table and spindle centre: 500 mm Column elevation: 120 mm Overhead dresser dresser Dressing Amount Compensation Automatic Grinding spindle motor: 2.3 - 9.3 kW Grinding spindle speed: 1,000 - 4,000 U-1 Grinding spindle speed control Grinding wheel dimensions A-Ø max x width max x bore: 250x25x50.8 mm Table Clamp Preparation of extraction without suction device Belt filter basins Flanges Grinding wheel Documentation Actuators Voltage: 400 V / 50 Hz Total connection: 10 kVA Machine weight approx.: 2.000 kg Approx. space: 2,600x1,800x2,300 mm

Technische Daten Technical Data Center height 175 mm Grinding length 600 mm Speed Spindle / Spindle Speed 1500 rpm Grinding wheel 400x50x127 mm If you are interested in this machine, please contact us, we will be happy to send you a detailed offer If you are interested in this machine, please contact us and we will be pleased to send you a detailed offer

Discus Werke DSH 600/1000 Side Surface Grinding Machine This type of machine is a machine with a motor-driven grinding spindle. The clamping and grinding of the workpieces is carried out with clamping devices tailored to the respective work. The devices are attached to the machine bed. The column saddle on which the motor spindle is mounted serves as a feed, dressing and pendulum slide. Manufacturer: Diskus Werke Model: DSH 600/1000 Serial number: 6299 Type: Side Surface Grinding Machine Cooling lubricant: Isocool 1020 BF Coolant volume: 400 liters Concentration: 2.5% (x factor 1.6 ≙ 4%) Year of construction: 1964 Condition: used The side surface grinding machine is located in Hildesheim and can be dismantled and picked up by the customer there. Dismantling and transport according to offer and agreement also possible by us. Complete plant closure,  ...

I sell a 4-side brush machine suitable for windows, turrets, tables, etc. Futura MS120 Y1 X2, built in 2005 Working width 1200mm Working height 200mm Total weight 2500kg Configuration: Side grinding heads left - right H.170mm 2 underheads left - right nylon B.140mm Oscillating top head B.260mm Large grinding heads top - bottom B.1150mm Machine together with all the heads on the picture. Available the same.

Small 4-side brushing/grinding machine for small parts. Minimum part length 250 m ! SPECIFICATIONS: Feed belt speed: 3-20 m/min. Spindle diameter: ø 40 mm Length of horizontal spindle shaft: 150 mm Length of vertical spindle shaft: 100 mm Maximum brush diameter: ø 200 mm Spindle speed as standard: 1000 ot/min (possibility of infinitely variable control) Power of the main motors as standard: 4x1.1 kW Power of the motor for the feed of the conveyor belt: 0.55 kW Diameter of the suction nozzle: 2 x ø 120 mm Maximum material height: 100 mm Maximum material width: 150 mm Minimum length: 250 mm (must be advised) Weight of the machine: 450 kg Compact machine with quick adjustment and optional parameters. KuSING has been manufacturing woodworking machines since 1991. In the field of 4-sided brushes, we offer a wide range of machines for every application. Parameter chang ...

Technical data: Displacement of the grinding head: .60 mm Axis Shift: .50 mm Total power requirement: 25 kW Grinding pressure: 10-1000 N Grinding wheel diameter: 650 mm

Technical data: max. grinding length: 4300 mm max. grinding diameter: 800 mm Grinding wheel dimension: 700x70x305 mm max. workpiece weight: 10 to. Grinding spindle Speed: 650-1300 rpm

Grinding body dimension: 200 x 40 x 76 mm Circumference speed: 30 m / sec Follow-up value: 0.7 kW Weight: approx. 250 kg Specification: Double grinding bracket with integrated suction

Tip height 120 mm, grinding length 1000 mm, 8 spindle speeds 55 - 600 rpm, spindle head holder MK 3, table sash. infinitely adjustable, table swivel 7 each, delivery by hand or automatically, grinding wheel-dm. max 400 mm, Grinding wheel width approx. 60 mm, tailstock holder MK 2, connection value approx. 3.5 kW, automatic working cycle, express speed 30 mm, automatic. Piercing loops. The machine is functional and does not require a geometric revision. Accessories on request!

Water-cooled grinding spindle motor for JUNKER Quickpiont 13.5 kW ,380/660 V ,25/14.5 A ,2940 rpm ,50 HZ

universal tool sanding machine manufacturer fa Kellenberger (Strausak) the machine is geometrical and also funktionmig in a very good state. Spitzenh?he: 125 mms top width: 680 mms L?ngsbewegung: 500 mms Arbeitsfl?che of the table: 1030 x 214 mms Q?rzustellung: 280 mms mm H?henverstellung Schleifkopf:300 wheel area Schleiftisch: + 90 °/-45 ° wheel area Schleifkopf: 350 ° Horizontally wheel area Schleifkopf: 360 ° Vertically Schleifspindel 4 speeds: 2250-3000-4500-6000 revos Schleifscheibendurchme?er: 250 mms Antriebsleistung:Schleifsp .: 1.5 kW Sony 2-axes digital display 0,001 mms

Technical data: Displacement of the grinding head: .60 mm Axis Shift: .50 mm Total power requirement: 25 kW Contact force: 10-1000 N Grinding wheel diameter: 650 mm Grinding wheel width: 8-20 mm

Fabric grinding belts of M3 1260 mm x 13 mm P150 for metalworking

Waldrich-Coburg leadership roads and surfaces sanding machine type: 0-15 SNC 2520 X/3 m Max.-Schleiflaenge: 3420 mms Max.-Schleifbreite: 1450 mms Max.-working height: 1005 mms Aufspannflaeche length: 3000 mms Aufspannflaeche width: 1250 mms accessories: -table fine adjustment -Papierbandfilter-Anlage -Schipmke-Haan DK150 V - back chill arrangement surface need: L=11,8m B=4,9m H=4,7m weight: 29.4 to . their prize image we await with pleasure. OTHER: the machine still stands live and can be visited any time.

a palette with 145 kg - 4 pieces new Schleifscheiben D=350mm, 2 pieces used Schleifscheiben with flange, 10x Abrichtrollen. a palette with 319 kg - 4 pieces Schleifscheiben D=400mm uses with flange and an Abrichtrolle.eine palette with 257 kg - 22 pieces Abrichtrollen with flange

Machine number: 3728-87 Grinding length 2000 mm (Roll grinding machine)

Working diameter: 40 - 250 mm Automatic work piece loading and removing for ball diameters: 40 - 105 mm Manual loading for diameters: 105 - 170 mm Direct ball attaching: 170 - 250 mm Rotation speed, stepless: 10 - 300 rpm Grinding spindle speed range: -160 - 3150 rpm -80 - 1580 rpm -38 - 775 rpm -20 - 385 rpm Weight: 6,5 tn Electrical connection: 17 kW Year of manufacturing: 1991

ė engine capacity exceeding 1.1 kW (900 RPM). 310 x 250 mm grinding shaft. 2 clamping ė velen styles (the rubber surface), diameter 30 mm. the preparation of Į (i) the measurements x 350 x 655 mm, 505. the preparation of Į weight 20 kg.

Kellenberger: 1000 U 125 Machine was totally dismantled and rebuilt from the ground up. All sheet metal and aluminum parts are laminated. Work piece headstock newly stored. Completely overhauled hydraulic, All filter replaced.

R + L 85776 Outer. 70 mm Length 220 mm

Belt/ozilierend swiveling Roll in the table

Technical data: Shift of the grinding head: ±60 mm Axis shift: ±50 mm Total power: 25 kW Pressure: 10-1000 N Grinding wheel diameter: 650 mm Wheel width: 8-20 mm

Technical data: with stand, 50 Hz, DAB ED 25% Engine: 3 Capacity: 1.75 A Capacity: 736 W Voltage: 380 V

Grinding wheel flange for Kellenberger / Strausak u.-Miwatec grinding machines type 57 U / W in special design. Questions us please at we do extensive accessories for these machine types.

Grinding wheels recording for Kellenberger / Strausak u.-Miwatec grinders. Grinding wheel holder for 76 mm bore. More technical info. on request.

Longitudinal stroke max. approx. 680 mm Transverse stroke Max 250 mm greatest distance spindle Center to table top approximately 525 mm Magnet size approx. 600 x 200 x 90 mm Disk size 300 x 50 x 76.2 mm Speed infinitely variable 1000--3000 U/min Dimensions, B x T x H approx. 3.2 x 1.8 x 2.5 m Spindle motor approx. 2.8 8.4 kW Weight of the machine CA. 3,3 tons Facilities: -with automatic vertical delivery -Roughing, Wiles, from fires and lifting by the adjustable potentiometers -Loading position is approached after slipping automatic -Rapid traverse across approx. 1.2 m/min via electric motor -Labour / rapid traverse along approx. 5 mm / min 40 m/min with servo motor and toothed belt drive -Rapid traverse vertical approx. 0.2 m / min -Digital display for lateral and vertical axis -Quick lifting system approximately 180 strokes / min -Straight electric, dresser with size and speed comp ...

Grinding wheels recording for Kellenberger / Strausak u.-Miwatec grinders. Wheels shot 38 mm. For more details please call us. We carry special accessories in our program. We repair and repaired on the spot and make complete engine overhauls Special grinding machines

Reduction sleeves for work piece headstock recording MK 5 Reduction MK 5 / MK 1 MK 5 / MK 2 MK 5 / MK 3 MK 5 / MK 4 Reduction sleeves with forcing nut. Price indication per piece. We carry new & - used Center points in special dimensions.

We give our wheel bearing. Vitrified bonded grinding wheels for metal processing. From 100 mm to 600 mm in diameter. We carry also diamond and CBN wheels for tool grinding machines new and used. Strausak Fleximat 91 we have yet complete disc sets for all common diameters for the machining of solid carbide and HSS milling and drilling tools. Price and info. on request.

We give our wheel bearing. Ceramic grinding wheels of different binding and hardness. Dimensions von75 mm to 600 mm. The discs are new, unused, and undamaged. Retail possible, price on request.

We have a very wide range of accessories for Kellenberger - Santiago &-Miwatecmaschinen. Grinding wheel flanges new u. - used. Chuck flange recordings MK 5 SK 50 for magnetic Chuck, three & four-jaw Chuck. Running with Center points, and fixed. Three-jaw four-jaw &-special Chuck. Magnetic clamping plates, cross - ring - Sternpolteileung. Truing devices, RADIUS &-inclined dressing Lynetten 2 & 3 jaw

We offer a new Movomatic Tischlängspositionier Setup. The device is new, unused and undamaged. The device is longer years in our camp, we have never used this. It is also can be used with security at other cylindrical grinders manufacturers.

Accessories fur WU 3 ms, apparatus of part of, round loop facility, etc. More info on request

Complete wheel sets for the production and subsequent sharpening of HSS and carbide tools. Single diamond and CBN discs. for the manufacturing and Resharpening. Grinding wheel shots short and long run. Spacer discs for grinding wheel flanges.

Grinding range 650 300 mm - digital display -autom. Vertical delivery

Tip height: workpiece or grinding diameter 500 mm centre distance: approx. 2000 mm maximum workpiece weight: 1200 kg wheel dimensions: 600 Ø x 300 mm wheel speeds: 965 RPM elect. Supply: 380 V, approx. 15 kW space: 2300 x 9000 x 2000 mm weight: 13000 kg

Tip height: Grinding diameter 250 mm centre distance: loop length 575 mm grinding wheel dimensions: 500 x 60 x 127 mm Electr. Supply: 380 V, approx. 9 kVA kW space: 2650 x 2600 x 2240 mm weight: 3400 kg

Work table: 750 x 290 mm, table height: 185 mm band length: 2600 mm strap width: 150 mm abrasive belt rear: 850 x 200 mm grinding unit swiveling: 90°-45° belt speed: 20 m / sec. Additional table: 330 x 330 mm oscillation stroke: 20 mm Oszilationsmotor: 0.25 (0.34 kW) suction connection Ø: 120 mm motor power output S1 100%: 3.0 kW (4,0 PS) motor power S6 40%: 4,5 kW (6.0 HP) voltage: 400 V machine dimensions (W x D x H): 1700 x 700 x 1080 mm weight approx.: 180 kg

Gr. Grinding length: 600 mm gr. Grinding width: 350 mm table - longitudinal movement: 35-600 mm grinding wheel dimensions: 300 x 50 x 76 mm wheel speeds: 1440 / 2890 RPM elect. Supply: 380 V, 5/6 kW space: 1950 x 1650 x 2200 mm weight: approx. 2500 kg

Band dimensions: 150 x 2000 mm speed: 14.5 / 29 m / sec. Contact plate: 200 mm / 155 mm plan grinding table diameter: 460 x 150 mm Extractor connection: 100 mm in diameter engine power: 4 kW

Surface grinding machine. Magnetic chuck of 550x250mm. Table travel: 700mm. Grind surface area: 600x350mm. Max. height: 375mm. Cross travel: 300mm. Wheel: 350x127x50 / 300x127x100 Weight: 2900Kg.
