sheet bending machines used for sale

Unbek. Type, YOC ca. 1990, Revision 2002 Specifications: - Bending capacity at 45 kg / mm² up to approx. Ø 25 x 3 mm - Bending angle left + right selectable - Hydr. Double-sided bending function - Hydr. Delivery ° - Drive 400 V / 11 kW - Space requirement approx. W 1750 x H 2200 x D 2300 mm - Weight approx. 1600 kg - with - bending angle adjustment - Hydr. Voltage - Bending tools

• 3000w IPG with Picking • Sorting Unit LSR & Combo Storage H38 • Large Format 3000 x 1500mm • Year 2014 • Servo Electric - High Speed 30 Ton Punching Head • ONLY 535 HOURS!

Very high-quality CNC – controlled precision sheet metal bending machine with automatic bending sequence calculation – automatic, CNC – controlled double-sided pre-bending – conical bending device Roll diameter 350 mm Smallest weft diameter 1.1 x the roll diameter = 385 mm Maximum bending length 3,000 mm Nominal pre-bending performance over the entire bending length at 5 x D = 18 mm for sheet steel/ST40 Nominal bending performance over the entire bending length at 5 x D = 22 mm sheet steel/ST40 Drive power 22 kW Weight 13,500 kg. Three hydraulically driven rollers (one hydraulic motor per roller) - The rollers run in bronze plain bearings Hydraulic linear sub-roller adjustment Hard chrome-plated piston rods Hardened and ground rollers PILZ® Laser Validation BECKHOFF® CNC – Control with Ethernet technology and large touch screen DANFOSS® Precision Hydraul ...

Very high-quality CNC – controlled precision sheet metal bending machine with automatic bending sequence calculation – automatic, CNC – controlled double-sided pre-bending – conical bending device Roll diameter 350 mm Smallest weft diameter 1.1 x the roll diameter = 385 mm Maximum bending length 3,000 mm Nominal pre-bending performance over the entire bending length at 5 x D = 18 mm for sheet steel/ST40 Nominal bending performance over the entire bending length at 5 x D = 22 mm sheet steel/ST40 Drive power 22 kW Weight 13,500 kg. Three hydraulically driven rollers (one hydraulic motor per roller) - The rollers run in bronze plain bearings Hydraulic linear sub-roller adjustment Hard chrome-plated piston rods Hardened and ground rollers PILZ® Laser Validation BECKHOFF® CNC – Control with Ethernet technology and large touch screen DANFOSS® Precision Hydraul ...

Very high-quality CNC – controlled precision sheet metal bending machine with automatic bending sequence calculation – automatic, CNC – controlled double-sided pre-bending – conical bending device Roll diameter 350 mm Smallest weft diameter 1.1 x the roll diameter = 385 mm Maximum bending length 3,000 mm Nominal pre-bending performance over the entire bending length at 5 x D = 18 mm for sheet steel/ST40 Nominal bending performance over the entire bending length at 5 x D = 22 mm sheet steel/ST40 Drive power 22 kW Weight 13,500 kg. Three hydraulically driven rollers (one hydraulic motor per roller) - The rollers run in bronze plain bearings Hydraulic linear sub-roller adjustment Hard chrome-plated piston rods Hardened and ground rollers PILZ® Laser Validation BECKHOFF® CNC – Control with Ethernet technology and large touch screen DANFOSS® Precision Hydraul ...

MEP Multimatic SA8, year of construction 1995 Straightening and cutting system for reinforcing steel, fully automatic, complete functional system, immediately available Plant still in operation and can be demonstrated.

1 Wire bending machine OMCG date 1997 technical status good , soft ware to be refurbished 2.Tube bending machine OMCG date 1998 technical status good, software to be refurbished

Equipment: 1 sledge feeder on the right 3 press modules á 180 kN = 540 kN 4 normal carriage units 1 narrow carriage unit Workspace: Wire thickness range: up to 10 mm Belt width: up to 100 mm Feed length: up to 250 mm Power: up to 132 rpm

Equipment: 1 sledge feeder on the right 1 two-point eccentric press 70 kN 4 normal carriage units 1 narrow carriage unit Workspace: Wire thickness range: up to 3.5 mm Bandwidth: up to 32 mm Feed length: up to 170 mm Power: up to 250 rpm

Equipment: 1 sledge feeder on the right 1 two-point eccentric press 250 kN 4 normal carriage units 1 narrow carriage unit Workspace: Wire thickness range: up to 5.0 mm Belt width: up to 40 mm Feed length: up to 320 mm Power: up to 132 rpm

Machine in working condition

Brand BENDMAK Type CYL-ST-170-20-5,0 Working lenght 2100 mm Pre-Bending 5 mm Max Thickness 5 mm Top Roll 170 mm Min Bending 255 mm Motor Power 4 kW Bending Speed 4,8 m/min. Dimensions L x W x H 4000 x 1100 x 1130 mm Weight 2300 kg Year 2015 Extra information Cone Bending device Induction hardened rolls Motorized Up and Down movement of the Back Roll Digital readout for Displaying positions of the Back Roll 2 Separte Control Units Cast Iron Body

Round bending machine - large

Bending machine - hydraulic

Trumpf TRUBEND 5085 - WORKING INSIDE PRODUCTION WORKING HORS: PRESENT ON PHOTO OF SCREEN Year 2011 Compression force: 85 tonnes Table length: 2,200 mm Free travel speed: 220 mm/s Accessories: Increased lift height from 230 mm to 615 mm. 5-axis bending. Hydraulic tool clamping at the bottom. Hydraulic tool clamping at top. Automatic bombing. Bendguard guard ACB angle measurement FOR CLIENT WE ORGANIZE AS WELL DISMANTLING AND TRANSPORT

We sell on behalf a pipe and profile bending machine of the company Knuth (type KPB 50 ). The condition is AS NEW and has a lot of accessories. Pictures to follow

Manufacturer: Haeusler Type: VRM HY 4000 x 45 Stock number: 0973 Year of construction: 2001 Bending length: 4000 mm Bending strength: 45 mm Bending (cold): 38 mm Drive power: 100 kW Number of reels: 4 Adjustable rollers: 3 Type of adjustment of the rollers: hydraulic Top roll diameter: 710 mm Underroll diameter: 640 mm Side roller diameter: 520 mm Working speed: 2+4 m/min (up to 8m/min) Machine weight (with roller): 78 t Accessories Electronic synchronization Air-cooled oil cooler Upper support device Side cylinder support device (10t) Inlet table (20t) hydr. Bubble storage Cone bending device

Tube range up to: 48,3x3,25mm (E235mitRm =2xD) Bending radius up to: 125 mm Control: electronic ( + known 4-fold bending angle preselection ) Bending angle maximum: 180° Bending speed: 20°/s Dimensions L / W / H: 2380 / 800 / 1250 mm Weight: approx. 650 kg Electr. Power: 2.4 kW incl. sawing unit with visualization of the saw position via line laser Deburring unit, drive unit for assembly attachments Tube positioning - length and twisting 2-axis positioning indicator, premature mandrel retraction Auto. Mandrel lubrication (minimum quantities) Interface for network connection and data import

mandrel bending machine Tansfluid DB 628 Year of construction: year 1995 Drive power Drive power 1.5 kW Drive drive hydraulic cylinder & roller chain Pipe range bending type 4-28 mm Bending angle bending angle 190° (without tube) Bending radius bending radius 1.5 x D – 2.0 x D Nominal pressure nominal pressure 250 bar Operating pressure 3095 mm n. right. Flow rate delivery rate 4.5 l/min

Roller bench Material thickness 1 mm Usable length 1,275 m Weight 200 kg

Max. bending length: 2000 mm Max. sheet thickness: 8 mm steel Clockwise and counterclockwise rotation Motorized rear roller infeed Safety kill switch Conical rounds possible

100 ton x 3000mm 3i Graphic control 8 Axis With tooling

Technical data of the used Lisse Z4-30 calender: Upper roller diameter: 230 mm Diameter of lower rollers: 170 mm Machine dimensions: 4800 x 1250 x 1300(h) mm

Technical data of the Faccin HAV 3162 hydraulic plate calender used: Upper roller diameter: 620 mm Diameter of side rollers: 550 mm Machine dimensions: 8600 x 3500 x 3700(h) mm Weight: 90.000 kg

Inv. Num. : 6907 Type: B/90 Producer: Curvatubi Generated:- Parameters: Tube diameter: 50-60 mm

Key data: 60 mm, 2 mm

Bending capacity: Ø60 x 2 mm Bending angle: 0 - 180° Turret: 12-way adjustment Mandrel length: 4500 mm Bending tools: - Ø 22 mm - Ø 25 mm - Ø 48 mm Equipped with: - 3 thorns - Mandrel retraction device - Foot pedal - Bending speed adjustment Country of origin: the Netherlands Motor power: 7.5 kW Machine LxWxH: 5350 x 1100 x 1100 mm Machine weight: 2300 kg

Automatic 3D wire bending machine was manufactured in Poland in 2022. The machine is used to automatically bend cut wire with a diameter of 4 to 8 mm. The structure made of thick-walled steel profiles, together with high-quality components, guarantee high bending precision and reliable operation. The automatic wire bending machine is equipped with a bending head with carriage and grippers and a wire feeding module consisting of a cut wire magazine and a choiceor mechanism. The workpiece taken from the magazine with a capacity of 150 kg, is fed via the wire choiceor mechanism into the feed channel, where it is pushed into the bending head and processed. At the end of the process, the bent wire falls into a receiving hopper or support table. All the capabilities of the wire bending machine are controlled by an installed PLC with an intuitive interface, taking care of the performance  ...

Manufacturer: Sahinler Type: PK-30 F Year of construction: 2018 Shafts: 30 mm Lower rollers: 118 mm Top roller: 148 mm Rotation: 26-12 rpm Location: Homburg, Germany

Serialnumber: 20610011 Year of construction: 2020 Volt / Hz / Kw: 400 V / 50 Hz / 0.75 Kw Country of origin: Germany

Hydraulic mandrel bending machine with a lot of accessories Preselection of 8 different bending angles with digital display Digital length display as well as digital display of torsion Max. effective length: 6096 mm Round tube steel (S 235): 60.0 x 6.0 mm Round tube stainless steel (S 355): 60.0 x 4.0 mm Square tube steel: 50 x 50 x 4.0 mm Rectangular tube steel: 60 x 40 x 2.0 mm Max. bending angle: 180° Weight: approx. 1800 kg

Specifications Ø tubes / radius in mm: Ø 22 / 67 Ø tubes / radius in mm: Ø 10 / 36

Bending capacity: Ø45 mm Bending angle: 0 - 180° Bending turret: 8-fold angle adjustment Mandrel length: 4000 mm Bending tools: 1x Ø 16 mm 2x Ø 17 mm 3x Ø 20 mm 2x Ø 27 mm 1x Ø 28 mm 2x Ø 30 mm Equipped with: - 4 Thorns - Mandrel retraction device Country of origin: Germany Motor power: 3 kW Machine LxWxH: 400 x 100 x 120 cm Machine weight: 1500 kg

Diameter Capacity 3-10 mm Bending arm lenght 755 mm

Max tube diameter 76 mm Max thickness 3 mm Max bending degree 180 Bending radius max 260 mm

Inv. Num. : 5648 Type: XOTM 60 Producer: UNIT Created: 2004 Parameters: Minimum tube diameter: 20 mm Maximum tube diameter: 60 mm Machine length: 4900 mm Machine weight: 130 kg

Inv. Num. : 1609 Type: CB90VZB SL 6000 Producer: DYNOBEND B.V. Created: 2013 Parameters: Control system: IGES Maximum tube diameter: 100 mm Maximum bending angle: 200 h Precise bending: 1/10 st Number of axles: 3 pieces Maximum bending length: 6300 mm Tube rotation: 360 pcs Strength: 70 kN Repeatability: 0.1 mm Programmable speed Compatible with systems: Windows. Novell and Linux Process Planning Software 3D bends Tools for bending pipes with a diameter of 76 and 70 mm

Inv. Num. : 3168 Type: SE 80.3 Producer: RASI Created: 2003 Parameters: Minimum tube diameter: 4 mm Maximum tube diameter: 82 x 2.6 mm Minimum bending radius: 34 mm Maximum bending radius: 228 mm Maximum bending angle: 195 h Total power requirement: 11 kW Maximum bending length: 3-6 m Maximum resistance torque: 12.7 cm³ Operating voltage: 400 V Control voltage: 24 V Feed speed: 0-60 m/min Machine height: 1200 mm Machine length: 7000 mm Machine width: 1300 mm Equipment: Bending tools

- Round tube steel DM 6 – 42 x 5 mm - Round tube stainless steel DM 6 – 42 x 3 mm - Pipe push-on length max. 6,000 mm - Programmable logic controller up to 20 angles - Digital display of longitudinal displacement - Digital display of torsion - Programmable, anticipatory mandrel retraction - Mandrel lubrication system by hand pump - Wrinkle smoother receptacle - Bending speed max. 13°/sec - Bending angle up to 180° + 10° deflection - Manual feed - Manual twisting - Right bending direction - Radii from 1.5 D - Incl. bending tool : - DM 12 mm - radius 36 mm ) / DM 15 mm - radius 37.5 mm - DM 18 mm - radius 36 mm - DM 22 mm, radius 44 mm with mandrel - DM 42 mm, radius 44 mm with mandrel

CNC – controlled profile and tube bending machine for demanding and precise bending work with hollow sections and tubes. With our machines, aluminium – steel / stainless steel – various plastics such as PVC window profiles (depending on the application) can be bent with repeatable accuracy, regardless of the material. Depending on the equipment, our machines can also be used for three-dimensional bending work. Our REPANDUS models can work both horizontally and vertically. The models of the REPANDUS series work with a fixed upper roller and two movable lower rollers – this means that the straight end piece is relatively short compared to machine concepts with fixed lower rollers. The machine body is made of vibration-absorbing cast steel Shaft diameter of upper and lower rollers Ø 70 mm Shafts made of special steel – hardened and ground Bending force 190 kN Maximu ...

CNC – controlled profile and tube bending machine for demanding and precise bending work with hollow sections and tubes. With our machines, aluminium – steel / stainless steel – various plastics such as PVC window profiles (depending on the application) can be bent with repeatable accuracy, regardless of the material. Depending on the equipment, our machines can also be used for three-dimensional bending work. Our REPANDUS models can work both horizontally and vertically. The models of the REPANDUS series work with a fixed upper roller and two movable lower rollers – this means that the straight end piece is relatively short compared to machine concepts with fixed lower rollers. The machine body is made of vibration-absorbing cast steel Shaft diameter of upper and lower rollers Ø 70 mm Shafts made of special steel – hardened and ground Bending force 190 kN Maximu ...

Offer 24126 Specifications: - Bending process mot. with automatic or manual operation - Bending capacity square bar ST 37 up to approx. 30 mm - Bending capacity flat bar ST 37 up to approx. 30 x 8 mm - Bending length between the twisting units adjustable up to approx. 1200 mm - Min. twist length 10 x material thickness ( long side ) - Bending time preselection / bending length twist preselection - Right – counterclockwise -Tailstock - Elbow + ring bending device GRB 66 with various roller sets - Bending performance - flat steel 60x10 mm high, R 700 mm - Flat steel 70x12 mm flat R 500 mm - Round tube 1 1/2" x 2 R 800 mm - Square tube 40x40x3 R 1500 mm - Angle 45x6 R 600 mm - Round tube roll sets steel 1 1/4" , plastic 1 1/2" - Standard roller set - Space requirement approx. W 1850 x H 1300 x D 700 mm - Drive 400 V / 2.2 kW ...

Used, technically overhauled reinforcing steel bending machine. Rotation of the bending plate 5/7.5/10/15 Power requirement 3.15/3.65 KW 2 footswitches with emergency stop function. Bending capacity max. 1 piece 45mm D. Reinforcing steel or 3 bars 28mm D. The control system is upgraded to Siemens Touch Display CC. Latest standard. 1 set of standard bending tool.

- min/ max bending thickness 10/60 mm - bending width 4500 mm - weight of bending rolls 172 t - dimensions L11,19 x W5,08 x H5,6 m

2000mm 66 ton Y1 Y2 R1 Z1 Z2 X1 X2 Excellent condition With tooling

Key data: 1000 mm, 1 mm

with rebate groove and wire insertion grooves Machine is repaired, checked, cleaned by a professional and is then fully functional. Test run is carried out. Sheet width: 1000 mm Sheet thickness: 1.0 mm . Colour: blue Machine weight: 45 kg Space requirement: 1200 x 400 x 1000 mm Shaft diameter: 50 mm

Profile Bending Machine SOCAD type CP 13.8 Outer wing angle capacity: 80x80x8 mm Flat on field capacity: 55 x 30 mm Flat on flat capacity: 75 x 20 mm T capacity: 80 x 80 mm Square capacity: 55 x 55 mm Equippeed with 1 fluted trainer roller Ø 300 x Ht 150 mm + 2 rollers Ø 260 x thickness 110 mm Voltage: 380 V Motor power: 8 CV Dimensions (L x W x H): 1800 x 1200 x 1400 mm Weight: 2,5 T

Diameter Capacity 3-10 mm Bending arm lenght 755 mm

Wire diameter between 3-8 mm

- Working area pipe steel  up to 30 mm x 2 mm - Pipe working area stainless steel  up to 30 mm x 1.5 mm - Pipe extension length 2,000 mm - Bending angle up to 180° + 10° overbending - Automatic bending sequence ( bending, twisting, longitudinal ) - CNC control - Input PC with software Transpro V2 + Tanspro V2 package (indication of previous owner) - Function triggering via hand switch - Clockwise bending direction - Radius range max. 125 mm mm -Auto. Mandrel lubrication - Laser scanner for security area - Incl. existing used tool for stainless steel pipe 1 mm  15, 18, 22, 28 mm Bending radius 1.5 D (various wrinkle smoothers, mandrels

Key data: 2040 mm, 1 mm

with rebate groove in the upper shaft, with steel wheel and scale, solid, stable construction, with wire inserts, 70 mm feed of the rear roller, Machine is repaired, checked, cleaned by a professional and is then fully functional. Test run is carried out. Sheet width: 2040 mm Sheet thickness: 1.0 mm Colour: green Machine weight: 600 kg Dimensions: 2200 x 650 mm Diameter:. 70 mm Machine number: 8413105
