shears lvd used for sale

Key data: 500 t, 6100 mm, 4060 mm

Compressive force 5000 kN Pressure 290 bar Working length 6100 mm Stand width 4060 mm Stroke 500 mm Distance between table and ram raised 770 mm Column projection 400 mm Table width 200 mm max. tablespoon. 2500 kN/m Closing speed 100 mm/s Working speed 9 mm/s Return speed 80 mm/s Main motor 37 KW Oil capacity 650 L Machine weight approx. 69 t LVD graphical 3-D Touch-B control with 19" screen Y1-Y2 electronic lowering adjustment and synchronization of cylinders EASY-Form Laser at W axis Backgauge CNC axes Y1,Y2,X,R,V, manual Z1-Z2, X-duo back gauge: stop range 1000mm, adjustment range 600mm, rewind accuracy 0.025mm, adjustment speed 550mm/s R-axis - height adjustment of the stop beam 200 mm, repeatability +- 0.1mm, adjustment speed 50mm/s V-axis crowning system 80/15 - 80/20 Clamping piece ram for vertically removable and autocentric tools Two front stops on  ...

This 3s LVD Orion 3015 Plus was manufactured in 2013. It features a powerful 2500 W Fanuc HF-excited CO₂ laser, capable of cutting various materials with a maximum sheet size of 3000 × 1500 mm and a weight of 570 kg. The machine offers impressive positioning speeds of 100 m/min on the X/Y axes. Consider the opportunity to buy this LVD Orion 3015 Plus fiber laser cutting machine. Contact us for further details.

8 assen: Y1 / Y2 / X / X#39; / R / Z1 / Z2 / V met Easy Form lasermeetsysteem met CNC-bombardement met Lazer Safe-bescherming met Willa hydraulische klemming boven en onder Turbo-versie Capacity: 220 ton x 4100 mm Backgauge: CNC Control: 2D Touch Passage between uprights: 3150 mm Max stroke: 200 mm Max distance between table -- ram: 400 mm Depth of throat: 400 mm Table width: 120 mm Locking speed: 120 mm/sec Working speed: 21 mm/sec Returning speed: 200 mm/sec Electric motor (power): 42 kW Length: 6320 mm Depth: 2850 mm Height: 3600 mm Weight: 20 ton Capacity: 220 ton Bending length: 4100 mm

- CNC Crowning - Hydraulic tool clamping - EFL Easy form laser measuring & correction system - Set Tooling  - Laser guide protection - Controlled axis Y1/Y2/X/R/V-Axis

- Only 100 Working (table/guiders/tooling still in prohibitor) - Installed never used in production only testing - CNC T1 + T2 + T3 Bending help support arm in front - 3 x HH 2600 Module backgauge 3 x Z1+R1+Delta1 - Lower Tooling set Variable VLA 50-150 mm - Upper Tooling set LVD 505  - Adjustment V-Axis 59,3 to 249,3 mm - Thermotec Oil chiller GC25T-35 max. 2200 kPa - CADMAN TOUCH with the best software for pressbrakes  - Hydraulic top tool clamping - Table width 500 mm - Troath in column 1000 mm

- Thick turret WILSON tool system - Large package tooling WILSON - Auto indexing Rotation tools included - Laser Safety guids included

sheet width: 4100 mm plate thickness: 6.35 mm thickness at Niro-steel: 4.00 mm cutting angle: 0.5 - 2.5 ° cutting gap adjustment: 0.05 - 0.8 mm no. of strokes: 9 - 26 Hub/min back stop - adjustable: 10.0 - 750 mm down holder: 22 Stk. oil volume: 200 ltr. engine output: 7.5 kW weight: 8000 kg. range L-W-H: 5145 x 2200 x 1750 mm From a maintenance workshop Very well-maintained / good condition With very few operating hours () Current list price approx. 60.000 euros Special price upon request Features: - Robust electro-hydraulic, slide-guided sheet metal shear - LVD control panel centrally located on the front of the machine (left) - Electro-hydraulic cutting angle adjustment Includes digital display of actual values - Manual cutting gap adjustment via handwheel from the front (left) Includes analog value display - Electro-motorized backgauge with ball screws Includes digital act ...

pressure: 100 t chamfer lenght: 3000 mm distance between columns: 2550 mm stroke: 150 mm total power requirement: . kVA Number of working hours: . h workpiece: workpiece: Number of strokes: total power requirement: kW weight of the machine ca.: 8,3 t dimensions of the machine ca.: m Back gauge 400mm Throat 250mm Speed: 8mm /S kW: 6,5 Volts: 380 The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your ...

sheet width: 6200 mm plate thickness: 8 mm throat: 60 mm distance between columns: 6400 mm cutting angle adjustment: 0,5 bis 2 ° total power requirement: 13 kW weight of the machine ca.: 19 t Cutting width: 6,200 mm Max. sheet thickness: 8 mm Throat depth: 60 mm Distance between side frames: 6,400 mm Cutting angle adjustment: 0.5° – 2.0° Total power requirement: 13 kW Machine weight: approx. 19 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

pressure: 320 t chamfer lenght: 6100 mm control: MNC 95 c Number of working hours: 4312 h voltage: 380 V / 50 Hz V : 7.100 x 2.450 x 3.400 mm total power requirement: 22 kW weight of the machine ca.: 26 t Maximum press force: 320 t Bending length: 6,100 mm Distance between side frames: 5,500 mm Control system: MNC 95 C Maximum ram stroke: 250 mm Maximum daylight (table to ram): 500 mm Throat depth: 300 mm Table width: 250 mm Approach speed: 80 mm/s Working speed: 7 mm/s Return speed: 70 mm/s Oil tank capacity: 350 l Operating hours: 4,312 h Power supply: 380 V / 50 Hz Total connected load: 22 kW Machine weight: approx. 26 t The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 3100 mm plate thickness: 6.35 mm thickness at Niro-steel: 4.00 mm cutting angle: 0.5 - 2.5 ° cutting gap adjustment: 0.05 - 0.8 mm no. of strokes: 12 - 50 Hub/min back stop - adjustable: 1000 mm Control: DELEM DAC 360 oil volume: 120 ltr. engine output: 9.5 kW weight: 7000 kg. range L-W-H: 3950 x 1950 x 1680 mm well-maintained condition () equipped with new DELEM control unit Equipment: - electro-hydraulic, guided plate shear - DELEM CNC control unit type DAC 360 front control panel, swiveling front left - Electro-hydraulic cutting angle adjustment - Electro-hydraulic cutting gap adjustment - electro-motorized backgauge, with ball screws - 1x extra-long side fence with T-slot mm scale The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 3050 mm plate thickness: 13.0 mm thickness at Niro-steel: 8.0 mm cutting angle: 0.5 - 2.5 ° no. of strokes: 8 - 25 Hub/min back stop - adjustable: max. 1.000 mm Control: SIEMENS Number of downholders: 13 Stk. oil volume: 300 ltr. engine output: 21.0 kW weight: 8700 kg. range L-W-H: 3950 x 2200 x 1900 mm Features: - Robust electro-hydraulic sheet metal shear Design: Circuit-guided - NC electro-motorized backgauge with SIEMENS NC control unit OP 7 Input of target and actual position values - NC electro-hydraulic cutting angle adjustment - Manual cutting gap adjustment, from the front via handwheel - Recessed grips in the front support table - Front finger guard - 1x long side fence - 1x long support arm - 1x freely movable foot switch - Original operating instructions (NL) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: gebraucht : 1998 : 090148 : prompt, Zwischenverkauf v : Belgien : 24900 € : 1 : 3100 mm : 6 mm : 0.5 - 3.5 ° : 9.5 kW : 950 mm : 4070 mm : 2330 mm : 3400 mm : 1850 mm : 5500 kg Motorized backgauge 1000 mm, ball screws, digital display Cutting gap adjustment from the front with handwheel Cutting length adjusment Cutting angle adjustment Downholer safety guard Rear safety via light barrier Foot pedal Table supports with ball bearings 1 side arm 1500 mm 2 support arms Operating manual in German with CE declaration of conformity BUYING USED MACHINERY IS A MATTER OF TRUST - OUR TRANSPARENCY PROMISE We offer you maximum security and complete transparency. • HONEST INSIGHTS: Detailed photos and functional videos of the current condition • LIVE ON-SITE CHECK: Live testing is possible at our facility • DIGITAL DEMONSTRATION: Individual live demonstration via video call • RISK-FREE PU ...

pressure: 220 t chamfer lenght: 4100 mm distance between columns: 3150 mm stroke of upper beam: 300 mm dayligth: 570 mm working feed: 21.0 mm/sec return speed: 200.0 mm/sec work height max.: 970 mm Control: PPS-TS Touch total power requirement: 37.0 kW weight: 27500 kg range L-W-H: 5100 x 1950 x 2850 mm Well-maintained condition () Special price upon request Equipment: - CNC electro-hydraulic press brakes Intuitive, touchscreen-based user interface Easy navigation Tool and program library Control system The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Tafelschere LVD HST ? C 40/6 Hersteller: LVD Type: HST ? C 40/6 Baujahr: 1995 Zustand: gut, gebraucht. Hydraulik neu abgedichtet. Messer geschärft Schnittleistung in ST37 6,35 mm Maxi. Schnittlänge 4050 mm El. Hinteranschlag 1000mm El. Schnittwinkel 0,5 bis 2 ° El. Schnittspaltregelung 0,05-0,8mm Trittfrequenz 10 bis 45 Hübe / min 7,5 kW Motor Ölbehälter 150L Gewicht 9500 kg Transportmaße L x T x H ca. 5,0 x 2,2 x 2,2m Aufstellmaße L x T x H ca. 5,0 x 3,1 x 2,2m Auflagetisch mit Kugelrollen 3x Auflagearme 1,5m Skala Dokumentation

3 assen: Y1 / Y2 / X Capacity: 160 ton x 3100 mm Backgauge: CNC Control: 2D Touch Passage between uprights: 2550 mm Max stroke: 200 mm Max distance between table -- ram: 400 mm Depth of throat: 300 mm Table width: 180 mm Locking speed: 100 mm/sec Working speed: 10 mm/sec Returning speed: 79 mm/sec Electric motor (power): 14 kW Length: 3500 mm Depth: 2350 mm Height: 2850 mm Weight: 9 ton

LVD PPEB 320 ton x 6100 mm CNC Capacity: 320 ton x 6100 mm Backgauge: CNC Control: Cadman B Touch Passage between uprights: 5050 mm Max stroke: 300 mm Max distance between table -- ram: 570 mm Depth of throat: 400 mm Table width: 200 mm Locking speed: 120 mm/sec Working speed: 14 mm/sec Returning speed: 130 mm/sec Electric motor (power): 42 kW Length: 8000 mm Depth: 3200 mm Height: 3775 mm Weight: 36 ton Capacity: 320 ton Bending length: 6100 mm

pressure: 200 t chamfer lenght: 4100 mm distance between columns: 3150 mm stroke of upper beam: 200 mm dayligth: 425 mm throat: 300 mm working feed: 9.0 mm/sec return speed: 90.0 mm/sec work height max.: 980 mm back stop - adjustable: ca. 700 mm Control: PPS-TS Touch oil volume: 350 l total power requirement: 18.0 kW weight: 12.000 kg range L-W-H: 5100 x 1950 x 2850 mm Well-maintained condition () Current new price approx. € 110.000 Special price on request - in checked conditions - machinevideo - https://www.youtube.com/watch?v=ZX9Ap23e__s Equipment: - CNC electro-hydraulic press brakes - with LVD CNC PPS-TS TOUCH control unit intuitive, touchscreen-based user interface simple navigation tool and program library X-axis control and position display Y-axis control and position display swivel-mounted control panel (front left) - CNC-controlled axes: Y1/Y2 + X - CNC motorized bac ...

pressure: 40.0 t chamfer lenght: 1250 mm distance between columns: 890 mm work stroke: 100 mm dayligth: 300 mm column arm: 200 mm table width: 140 mm ajustment speed: 100 mm/sec working feed: 10.0 mm/sec return speed: 90.0 mm/sec tank: 63.0 l total power requirement: 3.0 kW weight of the machine ca.: 2000 kg range L-W-H: 1555 x 1075 x 2149 mm from a vocational training workshop very good condition (!) Features: - conventional hydraulic press brake - swiveling control unit (front left) - electric backgauge (X-axis) incl. digital display for gauge position movement via electric push-buttons (creep and rapid traverse speeds) - manual adjustment of bending depth (Y1 + Y2 axes) handwheel with analog position indicator - 2x manually adjustable gauge fingers (R + Z axes) - 1x upper tool - 1x reversible universal die block - pressure gauge / pressure indicator - 1x mobile control unit The ...

Pressure drops Auction-ID: A3-46147-2632

Not working - electrical fault. Power: 9.5kW Auction-ID: A3-46152-6144

Tool boxes with drawers not included, but tooling. machine ready for transport and to be assessed on viewing day Full truck needed for transport Auction-ID: A1-48649-93

Guillotine shear LOTZE type HSS 20 / 7Cutting length 2050 mmCutting thickness 7 mmwith single back gauge; used

Hydraulic guillotine shears STEINER type HTS 30/20 RMasch. No. 315 Year of construction 1982Cutting length 3050 mmCutting thickness 20 mmBack gauge 800 mm controlledMotor power approx. 30 kWNet connection 400 volts, 50 Hz- Back gauge with positioning control ELGO- Back gauge adjustment via ball screws- Safety light barrier SICK front as protection against interference- 3 pieces Material Support arms with ball rollers- Electric foot switch- Replacement knifeSpace requirement of the basic machine L x W x H 4650 x 2610 x 3200

Guillotine Shears, Metal Shears DIGEP Type OL 3Workshop Overhauled Guillotine ShearFabr. No. 1312 Year of construction 1977Cutting length 1250 mm (nominal cutting length)Cutting length max. 1300 mmCutting thickness at 450 N/mm² 3 mmSingle back gauge 500 mmStand projection 200 mmCutting angle 2 stroke rate at full cutting length max. 50 strokes/min. Working height 860 mmMotor power 2.2 kWNew connection 380 Volt, 50 Hz- LED cutting area-Lighting- Simple backgauge with manual adjustment- Mechanical

Hand lever shears VEB Scherenbau Nossen type ScDH10Knife length: 180 mmSheet thickness: max. 10 mmFlat material: 50x15 mm4-edge solid material: 22x22 mmRound steel: 24 mmAngle steel: 60x7mmT-steel: 60x7mmon mobile undercarriageWeight: approx. 150 kg; used

Hydr. Swing cut guillotine shears HERA type HSS IIIFabr. No. 598 Year of manufacture 1986Cutting length 3100 mmCutting thickness 3 mmStand projection 200 mmKnife strokes 25 strokes/min. Mains connection 380 Volt, 50 HzMotor power 3 kW- motorized adjustable back gauge 1070 mm- actual digital display for the back gauge- cutting gap adjustment- cutting length adjustment- front side stop left 1000 mm- 4 pieces sheet metal support arms 1000 mm- el. Foot switchSpace requirement without sheet metal support arms L x W x H 3630 x

Swing-cut guillotine shears KÖLLSCHEN type BSK 2000/2Fabr. No. 69 1307 Year of construction 1969Cutting length 2000 mmCutting thickness 2 mmStand projection 90 mmWorking height 920 mmMains connection 380 volts, 50 HzEngine power 4 kW- Drive via geared motor with brake and crankshaft- mechanical sheet metal hold-down- manual back gauge 500 mm- stop adjustment via 2 handwheels, rear on the backgauge guide with measuring scale- front side stop left 720 mm- electric foot switch- manual

Hydraulic guillotine shears FASTI type 509 - 25/4Masch. No. 5418 Year of construction 1991Cutting length 2535 mmCutting thickness 4 mmBack gauge 5-1000 mm (controlled)Cutting angle adjustableHydraulic pressure max. 290 barMotor power 7.5 kWNeching connection 400 volts, 50 Hz- Back gauge with positioning control ELGO ELECTRIC Type 85- Sheet metal holding device under the back gauge- Manual cutting gap adjustment with dial gauge display on the right and left- Stepless cutting length adjustment- Hydraulic

Working width: 1040 mm sheet thickness: 12 mm rear gauge: hand up to 500 mm power: 380 V, 11 kW space: 2500 x 2150 x 1900 mm weight: 4100 kg

Working width: 2500 mm sheet thickness: 4 mm throat depth: 70 mm rear gauge: 520 mm power: 380 V, 6.3 kW space: 3200 x 2300 x 1270 mm weight: 4600 kg

McIntyre 200B Shear Available with or without a stand, this machine might look small but it has a big cutting capacity Small but powerful McIntyre's wide experience in hydraulic equipment manufacture has enabled us to build an 8” shear with a staggering cutting force. Although equipped with only a blade, the high shear force and wide tip to tip opening on the McIntyre 200B means that it can deal efficiently with a whole range of non- ferrous cleaning and sizing operations - in particular larger diameter electric cables and valves. In most cases - if your metal will fit into the jaw of the 200B, then this machine will cut it. Our company can provide this equipment with short delivery time.

JMC 407 overhauled new model / young device Drive: 7,5 KW Weight: 880 kg 4 x reversible knives Truck intake/wheels

Sheet metal width - 170 mm, Sheet thickness 8 mm. 80 x 10 mm, flat steel Steel bar cutting stencils for round and square Knife length 170 mm. Sheet holding device Machine length 800 mm (1000 mm with moveable base) Machine height 500 mm plus 560 mm for base Machine weight 255 kg,. on mobile base

McIntyre 407 CAT Shear Designed to recover the precious metals found in Catalytic converters, JMC Cat shears also versatile enough to be used anywhere in your yard. Purpose Built McIntyre Cat shears have been purpose built for recovering precious metals from catalytic converters. The Catalytic converter is simply placed in the jaws and cut. The movement of the jaw is directly controlled by the moveable foot pedal and a V clamp holds the Cat in place during cutting. Once cut, the pinched end of the converter can be re-opened using the side bracket attached to the top jaw, allowing the contents to be poured out.

the machine with two motors each 5.5 kw and blades 40 mm 2 hooks machine complete with hopper and stood and as well as a new control panel

Reinforced steel scissors Round iron scissors Scissors Manufacturers Muhr and Bender Type 50N/22 and 50N/28 50N/22 intersects at 450N/mm2: Round: 22mm Square 22mm Flat: 35x10mm 50N/28 intersects at 450N/mm2: Round: 28mm Square 24mm Flat: 40x15mm Both machines new and ovp Special price

McIntyre 407 Shear An affordable efficient 407mm (16") blade shear with enough power and speed to handle a wide variety of cutting tasks Robust, affordable, efficient Built originally for scrapyard use, the McIntyre 407 shear is robust enough to withstand the most difficult of working environments. It is now our most popular alligator shear with more than 2000 still in daily use worldwide. The McIntyre 407 is able to handle; automotive scrap, whole gear boxes, cylinder heads and blocks, oversized gate valves and of course all the usual non ferrous metal separations. The 407 can also be used to cut ferrous metals. Why

Hand lever plate and profile steel shears heavy and stable outing cuts sheets, round steel (approx. 15mm), flat steel and T-profiles Mounted on base Special price

McIntyre 500 CAT Shear The 500 CAT is designed for those needing just a bit more blade length without an equivalent increase in price. Versatile The 500 CAT gives customers just a bit more blade length without a big price increase. It is powerful enough to handle most non ferrous cleaning and sizing operations, and can also be fitted with an optional bracket enabling it to assist when processing catalytic converters. Long-lasting In common with all JMC shears, the 500 CAT has been designed and built to last. Blades are deep hardened for extended life, hardened chrome rod is used in the hydraulic ram, and components are all choiceed according to their quality over and above their price.

Manufacturer: Mc INTYRE Blade length: 150 mm Blade opening: 105 mm Cutting capacity: 25 tons Rods ST 37: 25 mm diameter Number of strokes at ¼ opening: 20 / min Number of strokes at ½ opening: 12 / min Number of strokes at full aperture: 9 / min Dimensions (L x W x H): 660 x 520 x 620 mm Weight: 150 kg Drive: 1.5 kw / 230 Volt Control: foot pedal

Working width: 3050 mm sheet thickness: 6 mm throat depth: back gauge: 650 mm power: 380 V, 16 kW space: 3680 x 2060 x 1870 mm weight: 7580 kg

McIntyre 500HD Shear This new generation shear is faster and more powerful than any other machine of its size. Featuring an automatic hold down clamp and 20 inch blade, this model is available as electric or diesel Fast and strong This 508mm, 20 inch, blade shear has been built for speed and power, and will outperform every other machine in its field. The McIntyre 500HD has enough shear force to deal with a wide range of operations and materials including: the cleaning of automotive aluminium scrap, whole gearboxes, cylinder heads and blocks, oversized gate valves, and the handling of all non-ferrous separations. It can also be used for cropping ferrous metals.

Professional steel shears for tin locksmiths, assembly plants, Teaching work pieces, particularly stable construction stable application with shear encoder made of encoded steel tooth lever translation lever securing via rotary spring knives made of high-quality tool steel, hoisted and ground continuously adjustable holder cuts of sheets, flat steel steel mm: 18 knife length mm: 175 Net weight kg: 47.5 room requirements approx.0.5x0.25x2 m; ready for use
