CTP thermal plates 58000 plates hand feeding plate stacker Server Workstation TIFF shooter

CTP plate setter Advantage DL+ Plate developing machine VPP 68 Find more here - / Contact us at -

Kodak Achieve T400 Platesetter Age: 2022 Max. Plate size: 838 x 990 mm Min. Plate size: 267 x 215 mm Max. image area: 827.9 x 990 mm Speed: up to 28 plates/hour Resolution: 2500 dpi 830 nm platesetter Semi automatic plate loading and unloading Harleqin Multi RIP 13.0 Dongle

KODAK Magnus VLF MTA Large Format Thermal Platesetter with MCU Multi-Cassette Unit (Four Cassettes) New TH 7 laser (May 2022) with only 1296 laser hours 2400 dpi Z-Speed Panel counter: 258861 Minimum size: 483 x 394 mm Maximum size: 1600 x 2083 mm Material flow from right to left with Prinergy TIFF Shooter Dell PowerEdge 7330 Plate development machine built in 206 Year of Make: 2006

KODAK Magnus VLF MTA Large Format Thermal Platesetter with MCU Multi-Cassette Unit (Four Cassettes) New TH 7 laser (08/2022) with only 2615 laser hours 2400 dpi Z-Speed Panel counter: 395443 Minimum size: 483 x 394 mm Maximum size: 1600 x 2083 mm Material flow from left to right with Prinergy TIFF Shooter Year of Make: 2016 New TH 7 laser (08/2022) with only 2615 laser hours

- Maximum panel format 2080 x 1600 mm, min. plate format 655 x 410 mm - 128 laser diodes, blue laser 405nm for UV light sensitive analog standard plates - Resolution 2,400 dpi - Optionally with automatic plate feeder PHS system with 5 cassettes at call Price from location on request

new motherboard with Part Number 503-00286A or Visible Number 637-00173A-A

Flexo Laser FL- Piccolo (Xeikon) – flexo CTP year 2008 fiber laser 20W – 1.25 plates/h approx. 3,000 m2 exposed rotating external drum vacuum Digital Exposable Photopolymer Flexo Plates all thickness, all brands exposable size 635 x 762 mm Resolution 2540 dpi data format separated 1 bit tiff weight 500 kg good condition

Min. plate format: 240 x 240 mm Max. plate format: 676 x 760 mm - SCL - MCL - Inline punching - Stacker PST 26C - incl. RIP

Prepress machine model CTP Type: Suprasetter A52/A75, GEN III Manufacturer: Heidelberg Year: 2011 Complete with RIP and decommissioning SW Number of exposed plates: 113,000 Number of exposed m2: 46,000 RIP: Metadimension 10.01 Decommissioning: Prinect Signa Station 10.02 The imaging unit is in excellent condition with regular service and a low number of exposed plates Find more here - / Contact us at -

Fully automatic machine with automatic plate feeder consisting of 5 cassettes, identical to AGFA Avalon N8-60 XT, available at short notice, price on request

Heidelberg Suprasetter A52/A74 Age: 2008 machine is in use in school Max. format: 670 x 525 mm Min. format: 240 x 240 mm Total Counter: only 907 exposes 64 Diodes Resolution: 2540 dpi For Thermal Plates Prinect MetaDimension 2015 Punching Device

Manufacturer: Presstec Model: Dimension Excel Year of Manufacture: 2005 Type of Machine : CTP Computer-to-Plate Setter Operating Hours: 23.693 Plates Included: - PAT Extraction Unit UF-02 / UF-270 A - Control Computer - Harlequin RIP Software Condition: Used Find more here - / Contact us at -

Kodak Magnus 400 F with stacker, using Kodak Sonora XTRA 3 process free plates, under power in print shop. Available immediately.

CTP System Creo Trendsetter VLF 5880; good condition; Video Die Cutter Hatchet OPU 200 VB Bj.2017; Observation Unit Mega Steel; Development machine Kodak THDX 165 Bj.2014; intermediate table; Outlet table. CTP System Creo Trendsetter VLF 5880; good condition; optical video punch Beil OPU 200 VB year 2017; control terminal Mega steel; processor Kodak THDX 165 year 2014; intermediate table; outfeed table.

Drawer printer with possibility of loading up to 4 rolls of 150 m with a maximum width of 42 (106 cm). Print with Pearl Océ Crystal Point toner technology that guarantees valuable results in both CAD and color with a print speed of 30 seconds for A0 size

The system produces pressready aluminium plates, without the use of chemical processing, in a daylight environment suitable for commercial printers, quick printers and inplants, small and midsize newspapers and book printers. The PlateWriter 3600 Pro is based on a new technology that takes inkjet platemaking to a completely new level in productivity and usability. The PlateWriter 3600 Pro is based on the wellknown and stable solvent ink technology (same as used in the PlateWriter 2000/2400 systems) ensuring increased stability and reliability in day to day production operations. Furthermore the PlateWriter 3600 Pro is introduced in a modern design with easy access for cleaning and maintenance. This makes the user experience even better than the earlier PlateWriter models. PlateWriter 3600 Pro is an enhanced format model offering landscape plate loading for an even higher throughput speed ...

Agfa Acento S + Agfa Azura 95 thermal laser technology 830 nm production speed 20 plates / hour plate thickness from 0.15 to 0.3 mm 32 laser diodes software RIP Agfa ApogeeX

BasysPrint 867 1500DPI Fully Automatic with 4 Cassettes and Bacher Punch One laser module with 2560 hours, optionally a second module can be offered. Operating counter plates: 404960 pieces Machine was discontinued due to plate conversion to thermal Dismantled by BasysPrint technicians and secured for transport. If you are interested, videos of the functionality can be sent via WhatsApp BasysPrint 867 1500DPI fully automatic printer with 4 cassettes and Bacher die-cutting unit One laser module with 2560 hours of operation; a second module is available as an option. Plate counter: 404,960 The machine was sold due to a plate conversion to thermal printing. Dismantled and secured for transport by BasysPrint technicians. If interested, videos of the functionality can be sent via WhatsApp.

CTP HEIDELBERG SUPRASETTER A 52/ A 75 ATL -Year 2009 Thermal CTP -Laser Type: Laserhead (64 diodes, 160 mW, 2540 dpi ) Gen II -Approx 78.000 plates, 3.600 hours of work -Min. Plate size: 240x240 mm -Max. Plate size: 676x760 mm -Speed: up to 17/22 plates/hour -Manual plate loading -Internal plate punch Bacher system with 2 positions -Autoloader - ATL two plate storage cassettes ( max capacity of 50 plates in A1 size ) -Automatic paper separation from plate to plate -Heidelberg Prinect Metashooter included, computer and monitor -Always under Heidelberg Italy maintenance -Available in June, in very nice conditions

Manufacturer: Kodak Model: Magnus 400 II Year of Manufacture: 2010 Type of Machine : CTP System Electrical supply: 220 V, 50 Hz, 16 A Pneumatics: 6 Bar Certifications: CE, CSA (C/US) Condition: Used, good condition, Autoloader requires service on plate suction. Machine has been idle but remains connected to power supply. Complete System Included in the Sale Multi-Cassette Unit (MCU) U/G - Fully automatic with interleaved paper feeder, 4 die-cutting heads (Heidelberg) and 3 magazine drawers Magnus 400 II S - 6-sided thermal imagesetter Conveyor for Magnus 400 II - Plate transport unit Plateslider Magnus 400 - Transfer to plate stacker Stacker 860 - Stacker for receiving the imaged printing plate Kodak Compressor for Magnus 800/400 with MCU Atlas Copco Airpower GX2FF, 230 V / 50 Hz, 240 l/min, 250 litres Agfa Azura C 95 Washout Unit - Ground drip tray included. Cleane ...

A Kodak thermal computer-to-print system with peripheral devices is available. Workflow: Prinergy EVO RTPO, laser wavelength: 830nm, imager sides: 6, cassette drawers: 3, punching heads: 4, max. plate dimensions X/Y/Z: 762mm/685mm/228mm, resolution: 3048dpi, screen ruling: 250lpi, repeat accuracy: +/-5µm, production capacity: approx. 17plates/h, max. cassette capacity: 180. System dimensions X/Y/Z: approx. 3350mm/1850mm/1850mm, weight: approx. 2000kg. Including a multi-cassette unit MCU U/G, 6-side thermal platesetter Magnus 400 II S, plate transport unit, plate stacker transfer, printing plate stacker 860, Kodak Compressor with Atlas GX2FF and washout unit with collecting tray Agfa Azura C 95. The autoloader has a suction problem with the printing plates. Documentation available. An on-site inspection is possible.

- T6300 CTP - Hand feed - Stacker - Running time ca. 12.596 h - Exposure time: ca. 1.858 h - Plate winding cycles ca. 33.935

-Model : Thermal platesetter KODAK CREO LOTEM 800 II QUANTUM S YEAR 2009 -Totally refurbished from Kodak in 2013 -Software version 3.82.12 -Autoloader with 1 cassette of 50 plates capacity , Internal punching system -Approx 13.000 plates done , speed 19 plates per/hour -Included : RIP Creo Prinergy installed with 2 computers and monitors -Stacker Egraftech year 2013 -Plate size: max 1130x900 mms. -Resolution: up to 2540 dpi -Available immediately , complete with all accessories, in good conditions

max. plate size: 680 x 780 mm min. plate size: 240 x 240 mm max. speed plates: 20 /h incl. RIP chemical free The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Platesize 1422 x 1804 mm, upgradable up to 1600 x 2083 mm, High-Z-Speed thermal laserhead technology, APL / 2 segments (right-eject), Inline 2 point punch units, Interface to online processor, Open workflow connectivity for direct and 3rd party 1-bit-TIFF connectivity, Under Premier fullservice maintenance contract, Available from currently plugged-in live operation - standby for worldwide shipping, Specified service bundle for dismantling and worldwide transport-ready export packaging, Available at short notice, price on request

Machine: Dainippon Screen PlateRite 4300S (2013) Type: 4-page Thermal CTP Platesetter Laser Technology: 32-channel infrared laser diode Maximum Plate Size: 830 x 660 mm (32.6" x 25.9") Minimum Plate Size: 324 x 370 mm (12.8" x 14.6") Plate Thickness: 0.15 to 0.3 mm (5.9 to 11.8 mil) Productivity: Up to 21 plates per hour (at 2,400 dpi) Resolutions: 1200, 2400, 2438, 2540, 4000 dpi Loading Configuration: Manual loading (optional auto-loader compatible) Dimensions (W x D x H): 1750 x 1030 x 1178 mm (68.9" x 40.6" x 46.4") Weight: Approx. 650 kg (1,430 lbs) Luxel T6300 CTP S Find more here - / Contact us at -

max. format 66 x 83 cm Year of construction 2008 Screen PT - R 4300 E CTP System for Thermal Plates 4 Sides Thermal Platesetter Autoloader Inline punching HD Autoplate / Bacher 425 mm Azura C 95 Processor Plate stackers Harlequin RIP Delivery date: Immediately

Kodak Trendsetter 400 III Quantum year 2008 continuous load thermal head 1.7 - 2500 hours 2400 dpi debris Dell Optiplex 3000 available in September

ICTP 2000, built 2010, with navigator RIP for windows 2000/2003/ XP, Dell Optiplex 760 hardware, CD manuals, cleaning kit, dongle and repro materials such as ifinisher, liguid dot reserve drying lamps, etc. In very nice kept condition. Available immediately. Can ship worldwide.
