Fujitsu Luxel T-9000 CTP (Model PT-R8100) – CTP Plate Setter - Quantity: 1 - Manufacturer: Fujitsu - Type: Luxel T-9000 CTP E - Model: PT-R8100 - Application: Imaging of thermal CTP printing plates - Plate size: up to approx. 1,165 x 940 mm - Resolution: up to 2,400 dpi - Plate thickness: 0.15 – 0.30 mm - Laser technology: Thermal laser (multi-channel) - Output speed: approx. 20–30 plates/hour (depending on resolution) - Compatible with various workflow systems - Sturdy construction for prepress environments

100rpm Auction-ID: A1-51267-5246

Resolution: 2400 dpi Manual plate feed line Speed 21 pl/hr. Max. plate size max. 838 x 990 mm mm plate size min. 267 x 215 mm mm

CTP Computer-to-Plate Imagesetter For Thermal Plates 830nm, 2xLaser Heads, Solution: 2400, 2540 dpi, Format: Max. 790x1030mm, Min. 370x323mm, Plate Thickness: 0.15-0.35mm, Speed: 23 Plates/Hour

Presstek Dimension Exel with external Affinity chilling unit, AMS -air management system, Dell Dimension computer, serial tools, connecting cables and some repro materials. Very clean and maintained. Available immediately.

Agfa Avalon N4-30 PT-R4600E, Year 2018 only approx.16K plates done Apogee Workflow RIP Inline punch Stacker ST 95EX Azura C95 Clean out unit Etc. Available: at short term

AGFA Acento E (Screen 4100 E) year 2006 16 diodes plate winding cycles 66.600 exposure time 5,800 h PC with ApogeeX good condition

Kodak Trndsetter Q800 with developer year 2016. Model TJ1903 developer EL125T In production X speed, 42 plates per hour software

Agfa Acento S + Agfa Azura 95 Year: 2005 Technical details: Technology: thermal laser, 830 nm Production speed: 20 plates / hour Plate thickness: 0.15 to 0.3 mm Laser diodes: 32 RIP software: Agfa ApogeeX

CTP thermal plates 58000 plates hand feeding plate stacker Server Workstation TIFF shooter

TH7 laser head, T-Speed 60 plates/hour, max. plate format 950 x 1163 mm, including automatic pallet loader APL, inline punch, maintained by Kodak Germany, Immediately available, conditions and price on request

CTP plate setter Advantage DL+ Plate developing machine VPP 68 Find more here - .ucymachines/ Contact us at - sales@ucymachines

KODAK Magnus VLF MTA Large Format Thermal Platesetter with MCU Multi-Cassette Unit (Four Cassettes) New TH 7 laser (May 2022) with only 1296 laser hours 2400 dpi Z-Speed Panel counter: 258861 Minimum size: 483 x 394 mm Maximum size: 1600 x 2083 mm Material flow from right to left with Prinergy TIFF Shooter Dell PowerEdge 7330 Plate development machine built in 206 Year of Make: 2006

KODAK Magnus VLF MTA Large Format Thermal Platesetter with MCU Multi-Cassette Unit (Four Cassettes) New TH 7 laser (08/2022) with only 2615 laser hours 2400 dpi Z-Speed Panel counter: 395443 Minimum size: 483 x 394 mm Maximum size: 1600 x 2083 mm Material flow from left to right with Prinergy TIFF Shooter Year of Make: 2016 New TH 7 laser (08/2022) with only 2615 laser hours

new motherboard with Part Number 503-00286A or Visible Number 637-00173A-A

Min. plate format: 240 x 240 mm Max. plate format: 676 x 760 mm - SCL - MCL - Inline punching - Stacker PST 26C - incl. RIP

Flexo Laser FL- Piccolo (Xeikon) – flexo CTP year 2008 fiber laser 20W – 1.25 plates/h approx. 3,000 m2 exposed rotating external drum vacuum Digital Exposable Photopolymer Flexo Plates all thickness, all brands exposable size 635 x 762 mm Resolution 2540 dpi data format separated 1 bit tiff weight 500 kg good condition

Prepress machine model CTP Type: Suprasetter A52/A75, GEN III Manufacturer: Heidelberg Year: 2011 Complete with RIP and decommissioning SW Number of exposed plates: 113,000 Number of exposed m2: 46,000 RIP: Metadimension 10.01 Decommissioning: Prinect Signa Station 10.02 The imaging unit is in excellent condition with regular service and a low number of exposed plates Imcluded hand hole punch Find more here - .ucymachines/ Contact us at - sales@ucymachines

Manufacturer: Presstec Model: Dimension Excel Year of Manufacture: 2005 Type of Machine : CTP Computer-to-Plate Setter Operating Hours: 23.693 Plates Included: - PAT Extraction Unit UF-02 / UF-270 A - Control Computer - Harlequin RIP Software Condition: Used Find more here - .ucymachines/ Contact us at - sales@ucymachines

BasysPrint 867 1500DPI Fully Automatic with 4 Cassettes and Bacher Punch One laser module with 2560 hours, optionally a second module can be offered. Operating counter plates: 404960 pieces Machine was discontinued due to plate conversion to thermal Dismantled by BasysPrint technicians and secured for transport. If you are interested, videos of the functionality can be sent via WhatsApp BasysPrint 867 1500DPI fully automatic printer with 4 cassettes and Bacher die-cutting unit One laser module with 2560 hours of operation; a second module is available as an option. Plate counter: 404,960 The machine was sold due to a plate conversion to thermal printing. Dismantled and secured for transport by BasysPrint technicians. If interested, videos of the functionality can be sent via WhatsApp.

CTP System Creo Trendsetter VLF 5880; good condition; Video Die Cutter Hatchet OPU 200 VB Bj.2017; Observation Unit Mega Steel; Development machine Kodak THDX 165 Bj.2014; intermediate table; Outlet table. CTP System Creo Trendsetter VLF 5880; good condition; optical video punch Beil OPU 200 VB year 2017; control terminal Mega steel; processor Kodak THDX 165 year 2014; intermediate table; outfeed table.

Manufacturer: Kodak Model: Magnus 400 II Year of Manufacture: 2010 Type of Machine : CTP System Electrical supply: 220 V, 50 Hz, 16 A Pneumatics: 6 Bar Certifications: CE, CSA (C/US) Condition: Used, good condition, Autoloader requires service on plate suction. Machine has been idle but remains connected to power supply. Complete System Included in the Sale Multi-Cassette Unit (MCU) U/G - Fully automatic with interleaved paper feeder, 4 die-cutting heads (Heidelberg) and 3 magazine drawers Magnus 400 II S - 6-sided thermal imagesetter Conveyor for Magnus 400 II - Plate transport unit Plateslider Magnus 400 - Transfer to plate stacker Stacker 860 - Stacker for receiving the imaged printing plate Agfa Azura C 95 Washout Unit - Ground drip tray included. Cleaned, ready for use, plus 4 new rollers. Find more here - .ucymachines/ Contact us at - sales@ucymachines

A Kodak thermal computer-to-print system with peripheral devices is available. Workflow: Prinergy EVO RTPO, laser wavelength: 830nm, imager sides: 6, cassette drawers: 3, punching heads: 4, max. plate dimensions X/Y/Z: 762mm/685mm/228mm, resolution: 3048dpi, screen ruling: 250lpi, repeat accuracy: +/-5µm, production capacity: approx. 17plates/h, max. cassette capacity: 180. System dimensions X/Y/Z: approx. 3350mm/1850mm/1850mm, weight: approx. 2000kg. Including a multi-cassette unit MCU U/G, 6-side thermal platesetter Magnus 400 II S, plate transport unit, plate stacker transfer, printing plate stacker 860, Kodak Compressor with Atlas GX2FF and washout unit with collecting tray Agfa Azura C 95. The autoloader has a suction problem with the printing plates. Documentation available. An on-site inspection is possible.

max. plate size: 680 x 780 mm min. plate size: 240 x 240 mm max. speed plates: 20 /h incl. RIP chemical free The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Machine: Dainippon Screen PlateRite 4300S (2013) Type: 4-page Thermal CTP Platesetter Laser Technology: 32-channel infrared laser diode Maximum Plate Size: 830 x 660 mm (32.6 x 25.9) Minimum Plate Size: 324 x 370 mm (12.8 x 14.6) Plate Thickness: 0.15 to 0.3 mm (5.9 to 11.8 mil) Productivity: Up to 21 plates per hour (at 2,400 dpi) Resolutions: 1200, 2400, 2438, 2540, 4000 dpi Loading Configuration: Manual loading (optional auto-loader compatible) Dimensions (W x D x H): 1750 x 1030 x 1178 mm (68.9 x 40.6 x 46.4) Weight: Approx. 650 kg (1,430 lbs) Luxel T6300 CTP S Find more here - .ucymachines/ Contact us at - sales@ucymachines

max. format 66 x 83 cm Year of construction 2008 Screen PT - R 4300 E CTP System for Thermal Plates 4 Sides Thermal Platesetter Autoloader Inline punching HD Autoplate / Bacher 425 mm Azura C 95 Processor Plate stackers Harlequin RIP Delivery date: Immediately

ICTP 2000, built 2010, with navigator RIP for windows 2000/2003/ XP, Dell Optiplex 760 hardware, CD manuals, cleaning kit, dongle and repro materials such as ifinisher, liguid dot reserve drying lamps, etc. In very nice kept condition. Available immediately. Can ship worldwide.

Fujifilm Luxel 6300 S (Screen PT-R 4300 S) year 2012 size 830 x 630 mm 32 diodes 21 plates/h exposure time 8,600 h Running time 24,500 h Apogee Prepress Manager Proliant ML150 Gen9 Windows Server Grafoteam stacker plate processor Glunz&Jensen 85 HDX in production good condition

incl. MultiCassette-Loader, max. plate format approx. 930 x 1140 mm, very well maintained, fully functional, Price from location on request

CTP ECRM DPX 2 Exposure Technology Internal drum - Digital Polyester System Plattenbelichtungssystem / CTP ECRM DPX 2 Baujahr / Year 2008 - _Serial-No. 020203 Druckplattenformat / Plate Size min. 250 x 250mm - max. 460 x 550mm (upgrated) Belichtungsformat / Expose Size max. 436 x 546mm Auflösung / Resolution 900 - 2540 dpi Production Speed 2540dpi - 17 plates/hour; ECRM RIP Ripmate 4.X Harlequin Core Script-Works Plattenbelichtungssystem für Polyesterplatten Exposure Technology Internal drum - Digital Polyester System

CTP Computer to Plate Heidelberg Topsetter 102 Type 2310 CTP Computer to Plate Heidelberg Topsetter 102 Type 2310 Baujahr / Year 2001 - Serial-No. 013940157 Plate Format min. 370 × 323mm - max. 930 - 1140mm Plate thickness 0.15 - 0.40mm Up to 15 plates/h Auto loading Without RIP and Dongle. Up to 15 plates/h

Heidelberg Suprasetter A75 ATL Gen III 4 up Age: 2010 Productivity: 17/22 plates per hour Max. format: 676 x 760 mm Min. format: 240 x 240 mm Total Exposure: 171.873 pieces Total punches: 171.718 pieces 64 Diodes Resolution: 2540 dpi For Thermal Plates Meta Dimension 2017 Autoloader Punching Device Stacker Advand PST 26 With Dongle

- Single Autoloader - 204.000 plate exposures - APOGEE Prepress - Prinect Shooter - PlateStacker

Kodak CTP system, machine number M4Q3115, year 2013, 74 format, with automatic cassettes If you are interested, we will also be happy to inform you about other machines in our company. You are welcome to visit the machine in our house by prior appointment.

Glunz &, Jensen iCTP 3600 Pro Year: 2019 Technical details: Press formats: 2up, 4up and 8up Max. plate size: 915 x 1140 mm (36.0 x 44.9) The system produces press-ready aluminium plates, without the use of chemical processing, in a daylight environment – suitable for commercial printers, quick printers and in-plants, small and midsize newspapers and book printers. The PlateWriter 3600 Pro is based on a new technology that takes inkjet platemaking to a completely new level in productivity and usability. The PlateWriter 3600 Pro is based on the well-known and stable solvent ink technology (same as used in the PlateWriter 2000/2400 systems) ensuring increased stability and reliability in day to day production operations. Furthermore the PlateWriter 3600 Pro is introduced in a modern design with easy access for cleaning and maintenance. This makes the user experience even better than th ...

BASF nyloflex Combi F I Super Type: flexo plate processing unit Year: 1997 Equipped with: Compact unit including exposure, washer, dryer and light finisher Temperature control and solids content monitoring Operating manual included Technical details: Max. plate size: 460 × 620 mm Dimensions (L × W × H): 240 × 120 × 118 cm Weight: 400 kg Power requirement: 3.5 kW Condition: used for research purposes only – in perfect condition
