Moulders SCM COMPACT 23

Code: 0401
Brand: SCM
Model: COMPACT 23 - CE Standard

Automatic 5-spindle moulding machine for joinery, profiles, frames, wooden doors and windows, furniture, timber joinery, sawmills and various – CE Standard


Heavy-duty base



Technical specifications:

Max working width 230 mm

Min working width 23 mm

Max working height 125 mm

Min working height 6 mm

Feed speed 6/12 mt/min

Shaft rotation speed 6000 rpm

Shaft diameter 40 mm

Useful length of vertical shafts 140 mm

Useful length of horizontal shafts 253 mm

Axial adjustment of vertical shafts 0/25 mm

Axial adjustment of upper horizontal spindle 0/25 mm

Axial adjustment of planer spindle 0/15 mm

Min/max diameter of profiling tools on vertical spindles mm 100/180

Min/max diameter of profiling tools on upper horizontal spindle mm 100/180

Min/max diameter of profiling tools on lower horizontal spindle mm 120/140

Planer spindle motor power 5,5 Hp

Vertical spindle motor power 7,5 Hp

Upper horizontal spindle motor power 5,5 Hp

Lower horizontal spindle motor power 5,5 Hp



Safety enclosure

N° 4 suction inlets diameter 120 mm

Flush cutter diameter 165 mm

N° 4 light alloy cutter heads

Feed rollers diameter 120 mm

Infeed table length 2500 mm

Quick adjustment of table and feed guide 10 mm

Manually operated table lubrication pump

Pneumatic feed rollers pressure

Motorised feed unit before surface planer

Feed unit Tandem front right vertical

Set-Up: Simple and quick set-up system



Configuration:


1° Spindle surface planer

2° Spindle right vertical spindle moulder

3° Spindle left vertical spindle moulder

4° Spindle thickness planer

5° Spindle Universal : Effective spindle length 230 mm - Spindle speed 6000 rpm - Min/max tool diameter 100/180 mm - Motor 7,5 Hp - Suction inlet diameter 120 mm

Overall dimensions mm 4800 x 1600 x 1500 h

Weight 2200 kg



seller offer No. resale Code: 0401
