Pressure:800 t distance between columns:3550 mm stroke:1100 mm Distance table/ram, max. stroke up, adjustment up:1900 mm Table surface area:3500 x 1800 mm pressure of drawing cushion in table:350 t Die cushion stroke in table:280 mm Die cushion pressure in ram:80 t Die cushion stroke in ram:160 mm Ram surface:3500 x 1800 mm Side window:1900 mm Weight:100,0 t Floor Space (WxD):5,3 x 4,3 m Height above floor:7,3 m Height below floor:5,0 - 6,0 m die cushion in table:hydraulic, controllable die cushion in ram:hydraulic, controllable cutting impact cushioning:hydraulic sliding table:without rails for moving table
pressure:160 t throat:400 mm stroke:30 - 200 mm no. of strokes:50 /min distance table/ram, max. stroke up, adjustment up:600 mm table surface area:1000 x 770 mm table height over floor:810 mm hole in the table:360 mm Passage to the back:450 mm ram surface:710 x 450 mm ram adjustment:110 mm power requirement:15,0 kW weight:10,5 t Dimensions (WxDxH):1,7 x 2,0 x 3,2 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:hydraulic overload protection in ram:mechanical ram counterbalance:pneumatic
pressure:60 t throat:400 mm stroke:600 mm Distance table/ram, stroke up:700 mm Table surface area:1120 x 700 mm table height over floor:850 mm Ram surface:700 x 700 mm Oil volume:275 l Power capacity:7,5 kW Weight:7,3 t Dimensions (WxDxH):1,6 x 2,0 x 3,7 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 § 20
pressure:500 t stroke:fix 300 mm no. of strokes:20 - 70 Hub/min distance between columns:3100 mm side window:1400 mm distance table/ram, max. stroke up, adjustment up:1000 mm Table area:2800 x 1600 mm ram surface:2800 x 1450 mm ram adjustment:100 mm power requirement:90,0 kW weight:100,0 t Dimensions (WxDxH):5,75 x 3,2 x 7,8 m height above floor:6,4 m height beneath floor:1,4 m clutch:pneumatic; Ortlinghaus ram adjustment:motoric overload protection in ram:hydraulic ram counterbalance:pneumatic
pressure:063 t throat:250 mm stroke:8 - 100 mm Stroke rate:60 - 160 / min Distance table/ram, max. stroke up, adjustment up:415 mm Table surface area:710 x 500 mm Hole in the table:250 / 280 mm Table height above floor:800 mm Passage to the back:290 mm Ram surface:450 x 280 mm Ram adjustment:63 mm Weight:4,3 t Dimensions (WxDxH):1,5 x 1,7 x 2,7 m infinitely variable drive:PIV clutch:pneumatic overload protection in ram:mechanical
pressure:063 t throat:250 mm stroke:8 - 100 mm Stroke rate:47 - 140 / min Distance table/ram, max. stroke up, adjustment up:415 mm Table surface area:710 x 480 mm Hole in the table:280 / 250 mm Table height above floor:800 mm Passage to the back:290 mm Ram surface:450 x 280 mm Ram adjustment:63 mm Weight:4,0 t Dimensions (WxDxH):1,5 x 1,6 x 2,7 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 infinitely variable drive:PIV clutch:pneumatic overload protection in ram:mechanical
pressure:63 t throat:270 mm stroke:160 mm Distance table/ram, max. stroke up, adjustment up:360 mm table surface area:560 x 490 mm hole in the table:280 x 190 mm table height above floor:850 mm ram surface:450 x 360 mm oil volume:360 l power requirement:23,0 kW weight:4,6 t dimensions (W x D x H):1,2 x 1,8 x 2,9 m
pressure:70 t distance between columns:750 mm stroke:900 mm table surface area:700 x 1000 mm Distance table/ram, stroke up:900 mm table height over floor:680 mm ram surface:700 x 1000 mm side window:600 mm max. tool weight:5,0 t max. capacity of swivelling ram plate:2,0 t Speed down:0 - 50 mm/s Speed up:0 - 48 mm/s Working speed:0 - 8 mm/s oil volume:140 l power capacity:9,5 kW weight:8,0 t Dimensions (WxDxH):2,2 x 1,2 x 3,7 m
pressure:40 t throat:285 mm stroke:500 mm Distance table/ram, stroke up:630 mm table surface area:560 x 560 mm pressure of drawing cushion in table:16 t stroke of drawing cushion in table:200 mm die cushion area:425 x 425 mm table height over floor:800 mm ram surface:450 x 450 mm power requirement:11,0 kW weight:4,0 t dimensions (WxDxH):1,15 x 1,8 x 2,85 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 § 20 light guard:Sick
pressure:30 t throat:110 mm stroke:50 mm no. of strokes:35 - 80 /min distance table/ram, max. stroke up, adjustment up:230 mm table surface area:410 x 260 mm table height over floor:790 mm passage to the back:170 mm ram surface:190 mm ram adjustment:35 mm weight:1,3 t dimensions (WxDxH):1,0 x 1,1 x 1,8 m German Safety: moving screen:UVV 11.062 - VBG 7n5.1 § 6
pressure:160 t distance between columns:1360 mm stroke:300 mm Distance table/ram, max. stroke up, adjustment up:620 mm table surface area:1300 x 900 mm table height over floor:950 mm side window:640 mm ram surface:1300 x 900 mm power requirement:45,0 kW weight:16,0 t Dimensions (WxDxH):2,5 x 2,1 x 4,1 m cutting impact cushioning:hydraulic
pressure:600 t distance between columns:3640 mm stroke:350 mm no. of strokes:11 - 44 /min Distance table/ram, max. stroke up, adjustment up:1550 mm table surface area:3600 x 2500 mm sliding table:3600 x 2500 mm ram surface:3600 x 2500 mm Side window:2200 mm ram adjustment:400 mm material width coil line:500 - 1950 mm Material thickness at 1200 mm material width:0,6 - 2,5 mm Material thickness at 1850 mm material width:0,6 - 2,0 mm Material thickness at 1950 mm material width:0,6 - 1,75 mm Coil weight:35,0 t coil internal diameter:610 mm coil external diameter:900 - 1900 mm no. of straightening rolls:13 straightening roll diameter:50 mm Stack height:400 mm stacking dimensions - station 1+2 (L x W):150-2000 x 250-2000 mm stations:2 power requirement:112,0 + 35,0 kW Weight:390,0 t Dimensions (WxDxH):7,3 x 5,1 x 15,0 m Height above floor:9,1 m Height below floor:5,9 m clutch-/ brake combinat ...
pressure:315 t distance between columns:1290 mm stroke:700 mm distance table/ram, max. stroke up, adjustment up:950 mm table surface area:1250 x 1100 mm pressure of drawing cushion in table:125 t stroke of drawing cushion in table:300 mm die cushion area:900 x 900 mm Capacity of ejector in ram:20 t Stroke of ejector in ram:250 mm table height over floor:800 mm ram surface:1250 x 1100 mm oil volume:1200 l power requirement:40,0 kW weight:22,0 t dimensions (WxDxH):2,6 x 1,6 x 5,2 m height over floor:4,05 m drawing cushion in table:hydraulic ejector in ram:hydraulic cutting impact cushioning:hydraulic
Pressure:40 t throat:330 mm stroke:250 mm distance table/ram, max. stroke up, adjustment up:450 mm table surface area:800 x 500 mm hole in the table:100 mm table height over floor:900 mm ram surface:100 mm Speed down:406 mm/s Speed up:393 mm/s Working speed:14 mm/s oil volume:350 l power requirement:7,5 kW weight:4,6 t dimensions (WxDxH):1,3 x 2,3 x 3,4 m German Safety: permitted for manual loading:CE-sign depth stop:mechanical
pressure:40 t throat:300 mm stroke:630 mm Distance table/ram, stroke up:900 mm Table surface area:620 x 520 mm Hole in the table:150 mm table height over floor:600 mm Ram surface:150 mm Power capacity:15,0 kW Weight:4,5 t Dimensions (WxDxH):1,0 x 1,9 x 3,0 m German Safety: permitted for manual loading:CE-sign
Pressure:080 t throat:345 mm stroke:20 - 160 mm no. of strokes:65 /min distance table/ram, max. stroke up, adjustment up:495 mm table surface area:920 x 610 mm table height over floor:800 mm Hole in the table:280 mm passage to the back:670 mm ram surface:650 x 400 mm ram adjustment:50 mm power capacity:10,0 kW weight:7,7 t Dimensions (WxDxH):1,5 x 2,2 x 3,15 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:hydraulic ram adjustment:motoric
pressure:800 t distance between columns:1050 mm stroke:200 mm no. of strokes:8 - 25 /min distance table/ram, max. stroke up, adjustment up:1300 mm Side window:550 mm table surface area:1030 x 900 mm Capacity of ejector in table:15 t Stroke of ejector in table:85 mm ram surface:1040 x 800 mm ram adjustment:120 mm Capacity of ejector in ram:12 t ejector stroke in ram :80 mm power requirement:36,0 - 112,6 kW weight:65,0 t Dimensions (WxDxH):3,0 x 3,1 x 6,07 m ejector in table:hydraulic ejector in ram:hydraulic
pressure:315 t distance between columns:2350 mm distance table/ram, max. stroke up, adjustment up:1200 mm distance between cutting impact cushioning:1600 mm Distance table/ram, stroke up:1200 mm stroke:800 mm table surface area:2060 x 1260 mm table height over floor:750 mm Die cushion pressure in table:100 t Die cushion stroke in table:400 mm die cushion area:1250 x 1000 mm side window:780 mm ram surface:2200 x 1500 mm Capacity of ejector in ram:63 t speed down:500 mm/s speed up:310 / 410 mm/s working speed:20 - 73 mm/s quantity of oil:3900 l power requirement:80,0 + 45,0 kW weight:55,0 t Dimensions (WxDxH):4,6 x 2,7 x 7,2 m Height above floor:6,0 m Height below floor:1,2 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 die cushion in table:hydraulic ejector in ram:hydraulic ram interlocking:hydraulic cutting impact absorption:hydraulic
pressure:160 t throat:450 mm stroke:300 mm distance table/ram, max. stroke up, adjustment up:580 mm table surface area:1000 x 1000 mm die cushion capacity:20 t die cushion stroke:300 mm ram surface:700 x 750 mm feed down:400 mm/s feed up:400 mm/s table height over floor:1350 mm die cushion area:Ø 350 mm power capacity:55 + 11 kW weight:19,5 t Dimensions (WxDxH):1,5 x 3,5 x 4,6 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulisch depth stop:mechanisch
