rs 50 used for sale

Hydraulic injection moulding machine manufactured in 2002. This Engel VICTORY 500/120 features a robust design with a weight of 7400 kg. It includes an integrated keypad and screen for user-friendly control. If you are looking to get high-quality injection moulding capabilities, consider the Engel VICTORY 500/120 machine we have for sale. Contact us for further details.

Lippert Belt Conveyor Riser with Arch and Straight GF 6005-650-500 RA2485 Technical data: Conveying length (NL): 6005 mm (ascending conveyor 2420 mm + arch 500 mm + upper straight 3085 mm) Framework width (NB): 650 mm belt width (GuB): 500 mm height (BH): 105 mm support feet: optionally available Conveying speed (v m/s): adjustable up and down with frequency converter Drive: SEW gear motor S37 DT80N4/MM07/BW1 Electrical data: 50Hz V380-500, kW 0.15 / 0.75 / S1 Deflection roller (UR): Ø = 34 mm Drive drum (AT): Ø = 81 mm Belt: Type HSL 8 E Year of construction: 2001 Slope / Slope: adjustable Optionally available: Supports Side guides Prices net plus VAT from central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg Features: Construction year: 2001 condition: good (used) Conveying length in mm: 6005 ( 2420 + 500 + 3085 ) Nominal / outside width in mm: 650 Belt width in mm: 500 Driven ...

Lippert belt conveyor GF 1715-650-500 RA2484 Technical data: Conveying length (NL): 1715 mm Framework width (NB): 650 mm belt width (GuB): 500 mm height (BH): 105 mm support feet: optionally available Conveying speed (v m/s): adjustable up and down with frequency converter Drive: SEW gear motor R17 DT71D4/MM03/BW1 Electrical data: 50Hz V380-500, kW 0.075 / 0.37 / S1 Deflection roller (UR): Ø = 34 mm Drive drum (AT): Ø = 81 mm Belt: Type SNB-8E Year of construction: 2001 Optionally available: Supports Side guides Prices plus VAT from central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg Features: Construction year: 2001 condition: good (used) Conveying length in mm: 1715 Nominal / outside width in mm: 650 Belt width in mm: 500 Driven: YES Engine type: SEW Eurodrive Zentralantrieb mit Spannstation KW: 0,37/S1 Conveyor speed m / s: freely adjustable scope of delivery: without suppo ...

Transnorm conveyor belt with leading belt GF 4050+4890-600-500 RA2051 Technical data: Conveyor length (NL): 8940 mm (4050 mm + 4890 mm) frame width (NB): 600 mm, 700 mm with motor belt width (GuB): 500 mm Overall height (BH): 80 mm, 430 mm with motor Supporting feet: optionally available Conveying speed (v m/s): Contact us and we will try to meet your preferred conveying speed. Drive: SEW gear motor and overdrive from belt one to belt two Electrical data: 50Hz V380-500, kW 0,75 S1 Drive drum: Ø = 81 mm Belt return roller: Ø = 81 mm Optionally available: Supports Side guide on one side and on both sides Frequency converter for stepless speed change Adjust length (longer/shorter) Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, Germany Features: condition: good (used) Conveying length in mm: 8940 ( 4050 + 4890 ) Nominal / outside width in mm: 600 Belt  ...

Transnorm conveyor belt with leading belt GF 4070+4430 -600-500 RA2052 Technical data: Conveyor length (NL): 8500 mm (4070 mm + 4430 mm) frame width (NB): 600 mm, 700 mm with motor belt width (GuB): 500 mm Overall height (BH): 80 mm, 430 mm with motor Supporting feet: optionally available Conveying speed (v m/s): Contact us and we will try to meet your preferred conveying speed. Drive: SEW gear motor and overdrive from belt one to belt two Electrical data: 50Hz V380-500, kW 0,75 S1 Drive drum: Ø = 81 mm Belt return roller: Ø = 81 mm Optionally available: Supports Side guide on one side and on both sides Frequency converter for stepless speed change Adjust length (longer/shorter) Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, Germany Features: condition: good (used) Conveying length in mm: 8500 ( 4070 + 4430 ) Nominal / outside width in mm: 600 Belt ...

Lippert belt conveyor GF 1810-650-500 RA1438 The Lippert conveyor belt is from 2001 and in good (used) condition. The belt conveyor has a SEW motor with MOVIMOT frequency inverter to control the speed. Lateral guides and/or light barriers can be installed on request at extra cost. Supports are not included in the delivery. These are optionally available on request. The pictures of the conveyor system shown here were taken in a logistics center while still installed. Technical data: Conveying length (NL): 1810 mm Framework width (NB): 650 mm belt width (GuB): 500 mm height (BH): 105 mm support feet: optionally available Conveying speed (v m/s): adjustable up and down with frequency converter Drive: SEW gear motor R17 DT71D4/MM03/BW1 Electrical data: 50Hz V380-500, kW 0.075 / 0.37 / S1 Deflection roller (UR): Ø = 34 mm Drive drum (AT): Ø = 81 mm Belt: Type SNB-8E Year of construction: 2 ...

turning diameter: 490 mm turning length: 2000 mm control: Heidenhain MANUALplus 4110 swing diameter over slide rest: 280 mm spindle turning speed range: 1 - 3000 U/min spindle bore: 93 mm rapid power traverse in X-and Z direction: 7 / 10 m/min power capacity: (100/60 % ED) 15/20 kW tailstock quill diameter: 70 mm tailstock quill stroke: 160 mm tailstock quill taper MT: 5 max. workpiece weight between centres: 1000 kg max. workpiece weight -without tailstock: 500 kg weight of the machine ca.: 3,6 t dimensions of the machine ca.: m Features: Control Heidenhain MANUALplus 4110 2 steady rests Manual chuck with jaws Tool holder with inserts The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Technical data for the shelf: Shelving system: Meta Type: Clip The scope of delivery includes: 01x Shelf, used Soil name: MS150-III Material colour: sendz. galvanized Dimensions: 1,000 x 500 x 40mm Weight: 3.41 kg|pcs. max. load per shelf 150 kg, with the same. distributed load. 04 x Shelf bracket 40 mm, used, vzk Silver for steel shelves with 40 mm edging Surface : Zn blue + therm 4h , Galvanized Color : Silver Your contact persons in our company: Mr.: Andre Evering Sir: Mario Klöver Mr.: Falk German General information about the article: This item is only available for pickup. An additional desired transport or a shipment of this item is associated with additional costs, which will be charged separately depending on the delivery location or scope of delivery.

General SKU253N183 LocationBarneveld MakeJohann Kreuziger Maschinenfabrik TypeRDH 500 RERE No.21159 Pressure Working pressure0 Bar Vacuum possiblecheck Main Features MaterialStainless steel Volume450 Ltr. Motor80 KW Specified Features - Planetary mixer Planetary mixercheck 1 Mixing/kneading shaftmixer arm and dissolver disc With scrapercheck Motor57 kW (mixer): 20 kW (dissolver) With variable speed drivecheck With gear boxcheck With panø 950 x 650 mm (on wheels) Capacity450 l Outlet75 mm With hydraulic liftingcheck (3,6 kW) MaterialStainless steel Information Year of construction1986 With switchgearcheck (as is) Floorspace3,6 x 1,8 m Total height3,4 m Weight6000 kgCatalysts & fillersSolventsDetergent & surf.Other pharmaceuticsLubricants & oleoOther feedDyes & pigmentsMinerals & inorganicPlanetary mixersOther chemicalFine chemicalsOintmentsPaints & coatings ...

General SKU040Z169 MakeHaagen & Rinau / Unimix TypeSH-500 No.301166/2 Year of construction2002 LocationBarneveld Main Features MaterialStainless steel Motor22 KW Rotor150 mm Specified Features - Inline mixer Continuous reactorcheck In-line homogeniser Rotor sizesø 150 x 150 mm Inlet120 mm Outlet75 mm Number of stages:3 Capacitymax. 36 m3/h With mechanical sealcheck Motor22,0 KW, 400 Volt With frequency controllercheck Rotor speed2900 rpm MaterialStainless steel 1.4306 (304L) Information With switchcheck With switchgearcheck Floorspace0,8 x 0,5 m Total height0,5 m Weight300 kg CEcheck Extra Specifications- mirror polished rotor and stator - stator with mechanical seal DiscountInline high shear mixersHaagen & RinauDiscountMixers > Inline high shear mixersBrand > Haagen & Rinau What you can expect from Foeth: -- Machine is in working condition -- At a reduced ...

Control: Manufacture: FANUC 21-M x-travel: 1020 mm y-travel: 510 mm z-travel: 575 mm table-size: 1200 x 500 mm spindle turning speed range: 60-8000 U/min tool magazin:: 24 weight of the machine ca.: 7.5 t HEIDENHAIN TNC-426 Prepared for the 4th axis www.marcels-maschinen.ch The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Manufacturer: Wolf Power Systems Model: GTK 50E0 Year of Manufacture: 2021 Type of Machine : CHP UNIT Condition : Never used, never even connected CE Certified: Yes Technical Specifications • Engine Type: Hoeckle HMG 434 S • Generator Type: Marelli MXB-E 225 MA/4 • Fuel: Natural Gas H (Erdgas H) • Electrical Output: 50 kW • Thermal Output: 90 kW • Power Consumption: 146 kW • Gas connection pressure range: 25 to 60 mbar • Maximum operating pressure: 4 bar • Maximum coolant inlet temperature: 90 degrees C • Rated voltage: 400 VAC 3PH 50Hz • Supply fuse: 100 A • Protection class DIN VDE 0470: IP 22 Find more here - / Contact us at -

: neu : ca. 4 Monate ab Auftragse : Bulgarien : 50390 € : 952.37 € : 500 mm : 1500 mm : 250 mm : 75 mm : 300 mm : 400 mm : 8 : 80 MK : 3 : 25-100, 100-400, 500-2000 U/Min : 120 : 0.04 - 12 mm/U : 0.02 - 6 mm/U : 0.5 - 120 mm : 60-1/4 Gänge/ : 0.125 - 30 : 240-1 : 315 mm : 130 mm : 90 mm : 5 MK : 230 mm : 11 kW : 3100 mm : 1250 mm : 1400 mm : 2800 kg driven by variable speed control (3 steps) 3-axes digital readout FAGOR with CSS (constant surface speed) quick change toolpostAmestra with 4 holders (3 square, 1 round) 3-jaw chuck Bison 3204/DIN6350, Ø 250 mm spindle dead center longitudinal stop for 1 position coolant equipment full length rear splash guard leadscrew and shaft protection safety guard for the chuck toolholder guard levelling bolts and plates quick release tailstock low voltage machine lamp operating manual machine according to ",CE", FURTHER TURNING LENGTHS:  ...

A compact Trumpf CNC laser welding station is available. Laser source: TruPulse 124, wavelength: 1064nm, max. average power: 140W, min. pulse power: 300W, max. pulse power: 6000W, pulse duration range: 0.3ms-50ms, max. pulse energy: 30J, max. pulse frequency: 833Hz, travel X/Y/Z: 450mm/300mm/300mm, travel speed: 3m/min, positioning accuracy: +/-0.1mm, repeatability: +/-0.02mm, rotary table diameter: 120mm, rotational speed: 80rpm, max. table load: 50kg, machine weight: approx. 650kg. Documentation available. An on-site inspection is possible.

The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

General SKU201P110 LocationBarneveld MakeAlfred Bolz Gmbh&Co. KG TypeMF 500 Pressure Working pressure3 Bar Vacuum possiblecheck Working pressure jacket3 Bar Technical specs Max. temperature100 °C Main Features MaterialStainless steel Volume11000 Ltr. Motor15 KW Specified Features - Conical dryer Conical dryercheck Capacity11000 Ltr (5000 Ltr nett capacity) Largest cone diameter2687mm Cone height4400mm Dished topcheck ManholeDN600 Stainless steel armwith mechanical seals Top drivecheck Motorscrew, 15,0 kW, 380 Volt (Ex) Motorarm, 1,35 Kw, 220/380 Volt (Ex) Bottom bearing pintle bearingcheck With jacketcheck (1100 Ltr.) Max. temperature100°C. Outlet with sliding valvecheck MaterialStainless steel 1.4404 (316L) Information Mach.No.WK 109923A / WK 340369 Year of construction1988 Floorspace3,1x3,0 M Total height5,5 M Weight+/- 7000 KGCatalysts & fillersF ...

Number of spindles: 5 St. Working width: 230 mm Working height: 120 mm Length of the planing table: 2500 mm Feed motor: 4 kW Feed speed: 5-30 m/min. control: Memory-Funktion Weinig Powermat 500 with grooved table ---------------------------------- The machine arrives at the warehouse and is cleaned and fully inspected. Brief Summary: ---------------------------------- - 5 Spindles - 8,000 rpm - Grooved table for short or difficult-to-guide workpieces, coated with Marathon PowerCoating - One driven roller in the outfeed table, hardened: 210 mm wide - Left and top spindles controlled for width and height - Quick-release spindle nut Detailed Description: ---------------------------------------------------------------------- - Technical Data: Working width: 20-230 mm Working height: 8-120 mm Number of spindles: 5 1st Spindle - bottom ----------------------------------------------- Motor with ...

Wickert high-precision hydraulic press WKP 5000 S with sliding table. Total pressing force 5000 kN. Table size 1800 x 1200 mm, installation height min 800 mm, installation height max. 2300 mm. Opening stroke 1500 mm. Sliding table extendable 1500 mm. Year of construction 2011 very good condition. available from week 22/2026.

General SKU201P111 MakeAlfred Bolz Gmbh&Co. KG TypeMF 500 Mach.No.M1180 Year of construction1988 Pressure Working pressure3 Bar Vacuum possiblecheck Working pressure jacket3 Bar Technical specs Max. temperature100 °C Main Features MaterialStainless steel Volume11000 Ltr. Motor15 KW Specified Features - Conical dryer MaterialStainless steel 1.4404 (316L) Conical dryercheck Capacity5000 Ltr. (max. 11000 Ltr.) Largest cone diameter2687mm Cone height4400mm Dished topcheck ManholeDN600 Stainless steel armcheck (with mechanical seals) Top drivecheck Motorarm: 1,5 kW (Ex): screw: 16 kW (Ex) Bottom bearing pintle bearingcheck With jacketcheck (1100 Ltr.) Max. temperature100 °C Outlet with sliding valvecheck Information LocationBarneveld Floorspace3,1x3,0 m Total height5,5 m Weight± 7000 kgCatalysts & fillersFeed additivesPaper & otherConical dryersOther pha ...

A used Universum cone winder and pretzel roller is currently for sale and immediately available in our warehouse in Bielefeld. Universum Cone Wrapper / Pretzel Long Roller Type: LWT 3/80 Prem-50J-EB2W/40 More information and pictures on request.

: neu : 2026 : 070152 : prompt, Zwischenverkauf v : Türkei : 4800 € : 1 : 500 kg : 1200 mm : 400 mm : 550 mm : 300 mm : 50 mm : 80 mm : 0.55 kW : 1400 mm : 1200 mm : 1550 mm : 190 kg motorized drive mechanical adjustable coil mandrel with 4 jaws speed control for decoiling speed aswell as acceleration- and deceleration times photoelectric proximity ensor SICK for sag control ALTERNATIVES (prices on request): Version with pneumatic pressure arm Version with brake, without motor, with or withaout pneumatic pressure arm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Absolutely new belt dryer make New Eco Tec Woody 500-100-1.0 SP, built in 2019. Very well preserved, as good as new facility. Immediately available. Suitable for drying fines up to 1.5 to/h. Input moisture up to 50%. Water evaporation up to 500 kg/h! Heating medium warm air 90°C to 110°C. Takeover possible immediately!

Key data: 800 KW, 400 V

CHP Power Plant 800 kWe with 2xMWM TCG 2016V08 Gas Gensets Good condition and low operating hour 800 kWe / 400 V / 50 Hz combined heat and power (CHP) plant running on natural gas or biogas. The plant was delivered by MWM in 2011 and it operation was closed in 2021. Thermal energy is in form of hot water at 90°C and currently used for district heating purpose. Due to the low amount of biogas, cogeneration plant worked at low capacity (30-40%), and not around the clock. It has a complete gas treatment and mixing system to utilize biogas from landfilling which has 40 – 55 % of CH4. Power generators are installed in two soundproof containers, TEAM Evo WMW power plant control system and all electric switches and control cabinets are installed in separate control room. Heat recovery system is built next to genset containers. Both units have separate cooling radiators for engine cooling ...

Highest sheet capacity at 400 N/mm2 x 1000x2 16 A plug Length 1.30 m Width 0.4 m Height 1.30 m Weight 250 kg Tools

CRAMMED FEEDING UNIT, reconditioned, This unit can be synchronized to feeding screw from buffer silo and horizontal screw in extruder to grant a uniform, continuous feeding, for light scraps, mounted on a 130 mm extrusion line, totally reconditioned, possible addition of mastebatch feeder, availability: in stock, conditions: reconditioned, type: for up to 700 kg/h extruders

DECOILER   design: twin reel   coil weight max.: 0.5 to   max. diameter of coil: 1600 mm DIMENSIONS / WEIGHTS   space requirements -left/right-: 1500 mm   space requirements -front/back-: 2100 mm   total height: 2200 mm   total weight approx.: 1570 kg - Double reel - Load capacity 1600 kg - Spreading range 270 - 550 mm - max. sheet width 150 mm - 3 pressure arms - Speed approx. 20 m/min

Trumpf TruBend Cell 5000Year of manuf. : 2018 Control : ____________Description:Technical dataYear of manufacture:2018Pressing force approx.:3200 kNFolding length approx.:4420 mmControl system:TASC 6000Projection:420 mmFree upright clearance approx.:3680 mmUsable installation height approx.:615 mmMachine weight approx.:23400 kgEquipment:- Sturdy machine frame:- Press beam, stress relieved with high bending strength:- Spherical bearing of the press beam (inclined position):- Electro-hydraulic top drive with 4-cylinder technology:- Optical set-up and positioning aid:- Generous edge clearance:- Flat front covers:- Block hydraulics:- Electronic pressure compensator:- Measuring system with glass scale and deflection compensation:- Hydraulic oil in the machine (lifetime lubrication):- Oil cooler:- Control cabinet cooling via air-to-air heat exchanger:- Modern machine designExtended equi ...

: neu : ca. 3-6 Wochen ab Auftrag : Türkei : 7730 € : 149.19 € : 500 kg : 150 mm : 150 mm : 360 kgm : 230 / 50 V / Hz : 0.37 kW : 0.37 kW : 0.1 - 3 U/min : 45 s : 800 mm : M20X6 mm : 640 mm The positioners are available in standard sizes for load capacities from 150 kg to 3,000 kg. The frame is optimally designed for rotation and tilting operations. The positioners consist of a motor, gearbox, table tilting system, steel gears, and control system and are structurally optimally protected. For heavy workpieces, the positioners are mounted on the floor. The tables have radial T-slots that enable quick clamping of the workpieces. Tilting and rotation are controlled by steel gears. For safety, the positioner is equipped with a reduction gear that holds the table in the desired position. Foot pedal Cable for signal to welder Touchpanel for following functions: - rotation speed - operating ...

Lippert belt conveyor GF 5030-570-450 RA2496 Technical data: Conveyor length (NL): 5030 mm frame width (NB): 570 mm, 770 mm with motor belt width (GuB): 450 mm Overall height (BH): 130 mm Supporting feet: optionally available Conveying speed (v m/s): Frequency converter for stepless speed controll Drive: SEW gear motor, Electrical data: 50Hz V380-500, kW 1,1 S1 Drive drum: Ø = 81 mm Belt return roller: Ø = 81 mm Optionally available: Supports Side guide on one side and on both sides Adjust length (longer/shorter) Prices net plus VAT ex central warehouse Dr. Sonntag GmbH & Co KG, 97076 Würzburg, Germany Features: condition: good (used) Conveying length in mm: 5030 Nominal / outside width in mm: 570 Belt width in mm: 450 Driven: YES Engine type: SEW Movi-Mot KW: 1,1/S1 Conveyor speed m / s: freely adjustable scope of delivery: without supports and side guides For individual, professio ...

Diesel Generators 1600 kWe / 50Hz with CAT 3516B engines and local control panel We have multiple identical CAT 3516B skid-mounted diesel generating sets available, all manufactured in 2018 and installed in the same HFO power plant, complete with full HFO plant auxiliaries. Each engine is coupled to a 2000 kVA / 415 V / 50 Hz brushless synchronous alternator via a flexible coupling, both mounted on a rigid base frame. These units are optimized for low emissions, high efficiency, and continuous base load operation. The generators have been serviced exclusively by the local CAT dealer and have only 1,500–2,000 operating hours. The standard scope of supply includes: • Engine control panel (EMCP 4) • 24V electric starting system • Radiator cooler Balance of Plant (BOP) equipment is available for customers requiring multiple units. Technical data Engine type CAT  ...

Key data: 5000 kN, 80 mm

SANDRETTO 500 T Series 7 Type: 3270/500 Clamping Force: 500 T Screw Diameter: 80 mm Theoretical Injection Volume: 2110 cm³ Injection Weight (PS): 2050 g Screw Working Length (L/D): 20 m Plasticizing Capacity: 290 kg/h Heating Zones: 4 Total Heating Power: 31 kW Mold Thickness (Min/Max): 250-800 mm Opening Stroke (Platen Travel): 830 mm Distance Between tiebars: 720 x 720 mm Oil Tank Capacity: 500 L Dimensions: 9.0 x 1.80 x 2.50 m Total Weight: 25,000 kg

Year: 2017 - technically efficient, ready to work – after full service - split heads - pneumatic drive - maximum profile height: 160 mm - resistance unit lowered under the table - hydraulic lock for reversing the resistance unit

Stock number: 4029 Suction Manufacturer: 3NINE LINA, Type: LINA 500 Oilmist Separator Machine NO.: LI500-65-CC-543, Year of manufacture: 2006 Specifications: Fence effect 500m3/hour m/3 Motor power 0.55 Kw Cleaning oil mist (cutting fluid/coolant) Min./max Degree 5-50 Degree Height: 840 mm, Width: Dia. 480 mm, Weight: 30 kg

Gas forklift built in 2018 in technically and visually very good condition. Technical highlights: Load capacity: 5,000 kg Mast: 5.2 meters triplex (3-fold) with free lift 4-way control block Joystick hydraulic control Factory steel cab with heating Work lights Very good solid rubber tires 4 fork extensions (MEYER 6-5409N) Further data: Engine power: 80.2 hp (59 kW) Drive: Hydrostatic Hours: 1,863 h Weight: 7,350 kg Tyres: 4 wheels

turning diameter:500 mm turning length:1000 mm control:Siemens 840 D spindle:42 / 28 kW spindle turning speed - stepless:31 - 4000 1/min max. torque on the spindle:345 Nm c-axis:360000 x 0,001° feeds -stepless-:0 - 10000 mm/min rapid traverse:10000 mm/min turret stations / rotary tool stations:12/12 VDI 40 RPM of rotary tools:2000 1/min diameter of quill:90 mm quill stroke:80 mm tailstock quill taper ISO:SK 30 Tailstock Travel:600 mm Power rotary tools:3,5 kW :22,5 Nm Rotary tool holders:4 ax./ 4 rad. spindle passage:66 mm total power requirement:30 kW weight of the machine ca.:7,5 t dimensions of the machine ca.:8x 3 x 4 m

x-travel:630 mm y-travel:600 mm z-travel:650 mm control:MSC 502 (Fanuc 16) Spindle RPM:12000 1/min spindle drive:22 / 18,5 kW rapid travel x/y/z:32 m/min Pallet dimension:500x500 mm numbers of pallets:2 table load:0,5 t working diameter:max. 610 mm Number of tool station:60 BT40 max. tool length:360 mm max. tool weight:12 kg tool changing time:1,3 sec B-axis positioning (non continuous):1 total power requirement:50 kVA weight of the machine ca.:14 t dimensions of the machine ca.:3,3 x 5,8 x 3,2 m spindle load monitor:Typ C This horizontal machining center comes with a pallet changer with 2 pallets, and has the following options: ATC 60 tool stations, High pressure coolant trough spindle interface,

turning diameter:1600 mm turning length:12000 mm control:FAGOR 8050 Used CNC Lathe with FAGOR 8050 and extensive accessories. For further technical data and accessories, pls browse the Appendix. Parallellathe WMW mod. 4 GUIDE-WAYS ¦ CNC: FAGOR 8050 ¦ bed: monolithic ¦ centres height: 800 mm ¦ centres distance: 12000 mm ¦ swing over cross-slide: 1250 mm ¦ turret: automatic 4 positions ¦ tailstock: motorized ¦ tailstock connection: hydraulic ¦ platform: diam. 1000 mm ¦ steady rests: nr.02 ¦ chip conveyor Warranty: none Take advantage of the favorable leasing and hire-purchase terms from IKB Leasing. Ask us about it.

x-travel:630 mm y-travel:630 mm z-travel:500 mm number of spindle speeds:0 - 15000 spindle motor:32 kW size of pallet:500 x 500 mm b-axis:36000 x 0,001 ° no. of workpieces in the magazine:61 Stück tool taper:HSK 63 weight of the machine ca.:15 t Single-Spindle Mechanical processing cylinder head VR6

grinding diameter max.:3-220 mm regulating wheel width:500 mm max. width of grinding wheel:500 mm weight of the machine ca.:16 t. dimensions of the machine ca.:12 x 10 x 8 m. grinding wheel diam. min/max.:420-610 grinding wheel diameter - width-internal grin:304,8 x 500 mm Regulatin wheel diameter min/max.:300-350 mm The machine is currently designed for plunge grinding JUPITER's Centerless grinding, also available with CBN. Junker this circular grinding method with CBN grinding wheels, which opens up significant productivity benefits from the long service life of the grinding wheel, especially at high volumes. In addition, the simultaneous removal takes on the entire Schleswig-Holstein, which provides both in mass production and in small batches for significantly reduced processing times. The grinding process with JUPITER When centerless grinding, there are two grinding processes: the  ...

turning diameter:500 mm turning length:1500 mm spindle motor:16 kW Spindle RPM:1 - 2500 1/min taper in tailstock MT:5 tailstock quill stroke:160 mm tailstock quill diameter:70 mm total power requirement:22 kW weight of the machine ca.:3,2 t dimensions of the machine ca.:3,2 x 1,8 x 1,4 m Machine with Heidenhain Manual plus control - Multifix quick tool change device - 3-jaw chuck - sliding splash door - various accessories.

turning diameter over bed:500 mm turning diameter over slide rest:310 mm turning length:1500 mm spindle turning speed range:7 - 710 U/min feed range:5,6 - 224 mm/min total power requirement:15 kW weight of the machine ca.:3,7 t dimensions of the machine ca.:2,9 x 1,4 x 1,6 m Machine with 2-axis digital readout - MULTIFIX quick tool change device - 3-jaw chuck

Performance ·Max. motor power: 30 kW ·Max. engine speed: 10,000 rpm ·Rated torque (test bench): > 100 Nm ·Max. braking torque: up to 122 Nm ·Max. braking power: up to 46 kW (overload) Dynamometer ·Type: AC asynchronous dynamometer, frequency-controlled ·Voltage: 360 V ·Cooling: Forced ventilation (IC06) ·Protection class: IP23 ·Insulation class: F ·Speed range: 0 ? 10,000 rpm ·Continuous operation: up to 40 kW (depending on speed) ·Overload capability: 1 min every 10 min Measurement System ·Torque measurement: oHBM T12HP torque flange oMeasurement range: 200 Nm oAccuracy class: 0.02 ·Speed measurement: oIncremental encoder, 1024 pulses/rev oAccuracy: ±0.01 rpm ·Vibration monitoring: oIntegrated vibration sensor Mechanical Structure ·Slotted base plate with air suspension (Bilz air springs) ·Vibration-damped test bench ·Motor mounting system: oAdjustable aluminum fram ...

turning diameter:500 mm turning length:1000 mm control:MANUAL PLUS Grundig total power requirement:24 kVA weight of the machine ca.:2650 kg dimensions of the machine ca.:2500 x 1750 x 1850 mm swing diameter over face slide:290 mm chuck:Ø max. 260 mm cross movement:260 mm spindle head:DIN 55027 Größe 8 spindle bore diameter:70 mm rapid travel - longitudinal/face:8 /6 m/min spindle speeds::8 - 2800 tailstock travel:180 mm tailstock quill taper MT:5 Documents:vorhanden

turning diameter:500 mm turning length:1000 mm control:MANUAL PLUS Grundig total power requirement:24 kVA weight of the machine ca.:2650 kg dimensions of the machine ca.:2500 x 1750 x 1850 mm swing diameter over face slide:290 mm chuck:Ø max. 260 mm cross movement:260 mm spindle head:DIN 55027 Größe 8 spindle bore diameter:70 mm rapid travel - longitudinal/face:8 /6 m/min spindle speeds::8 - 2800 tailstock travel:180 mm tailstock quill taper MT:5

turning length:2000 mm control:- total power requirement:25 kW weight of the machine ca.:3 t dimensions of the machine ca.:3800 x 1800 x 1850 mm swing over bed:500 mm swing diameter over face slide:280 mm control:Zyklen-Steuerung Heidenhain bed width:350 mm Documents:vorhanden

grinding length:600 mm grinding width:250 mm workpiece height:380 mm :Sinumerik max. dia. of grinding wheel:300 mm weight:4000 kg total power requirement:12,5 kW grinding wheels:Ø 400 mm max. width of grinding wheel:100 mm grinding wheel hole diameter:127 mm turning speeds:470 - 12030 1/min x-axis:600 mm y-axis:300 mm z-axis:250 mm grinding range:450 x 200 mm distance spindle nose and table:500 mm table load:250 kg dimensions of the machine ca.:2600 x 2100 x 2400 mm switchgear cabinet:1300 x 800 x 2000 mm hydraulical unit::450 x 350 x 500 mm Documents:vorhanden

faceplate diameter:5000 mm swing diameter:6100 mm turning height:2400 mm ram stroke each side:1490 mm ram head dimension:340 x 340 mm max. workpiece weight:100.000 kg total power requirement:100 kW weight of the machine ca.:155 t faceplate turning speed range:0,4 - 50 U/min with 2 x 2 axes CNC SIEMENS 840 D

Pressure:500 t distance between columns:1550 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:900 mm table surface area:1200 x 1300 mm pressure of drawing cushion in table:250 t stroke of drawing cushion in table:150 mm die cushion area:950 x 950 mm table height over floor:1245 mm side window:1250 mm ram surface:1200 x 1300 mm speed down:750 mm/s speed up:780 mm/s working speed:105 mm/s oil volume:4000 l power requirement:263,0 kW weight:45,0 t Dimensions (WxDxH):3,3 x 3,3 x 6,1 m height over floor:6,1 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic cutting impact cushioning:motoric adjustable

pressure:500 t distance between columns:2400 mm stroke:400 fix mm no. of strokes:13 - 23 /min Distance table/ram, max. stroke up, adjustment up:1600 mm table surface area:2300 x 1800 mm column travel -side:1600 mm ram surface:2170 x 1800 mm ram adjustment:300 mm total power requirement:110,0 kW Weight:135,0 t Dimensions (WxDxH):3,35 x 4,85 x 7,0 m clutch:pneumatic overload protection in ram:hydraulic ram adjustment:motoric

pressure:500 t distance between columns:2240 mm stroke:1180 mm distance table/ram, max. stroke up, adjustment up:1800 mm table surface area:2050 x 1800 mm pressure of drawing cushion in table:250 t stroke of drawing cushion in table:380 mm drawing cushion surface in table:1800 x 1200 mm pressure of drawing cushion in ram:122 t stroke of drawing cushion in ram:200 mm drawing cushion area in ram:1800 x 1200 mm ram surface:2215 x 1800 mm table height over floor:500 mm speed down:400 mm/s speed up:10 - 400 mm/s working speed:10 - 100 mm/s depth of the foundation:3,0 m power requirement:122 + 75 + 64,5 kW weight:110,0 t Dimensions (WxDxH):3,6 x 2,2 x 8,5 m height over floor:6,8 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table and ram:hydraulic
