roll bending machine used for sale

Manufacturer: Fasti Model: 902-315/40 Year of Manufacture: 1990.The machine was last retrofitted in 2019. Type of Machine : Bending Machine Technical Specifications - Total Weight : 25,000 kg - Nominal Pressing Force : 3150 kN - Stroke Length: 250 mm - Working Width: 4050 mm - Maximum Working Pressure: 30 MPa - Stopping Time: 71 ms - Two-Hand Release Safety Distance : 114 mm Find more here - .ucymachines/ Contact us at - sales@ucymachines

CNC bending machine Type: Biegemaster BM 6,15 Manufacturer: Sperr & Lechner Year: 2016 The bending machine can bend sheets up to a thickness of 1.5 mm steel sheet, in the case of aluminum sheet the maximum thickness is 2 mm. The maximum length of the bent sheet is 6200mm and the width is 915mm. Machine in good condition, fully functional, under power Find more here - .ucymachines/ Contact us at - sales@ucymachines

bending speed: 2.1 m/min Bending capacity - square: 30x30 mm bending capacity - flat iron: 80x15 mm Bending capacity - flat iron on edge: 50x10 mm tube diameter: 1 oder 60x2 mm Shaft diameter - upper: 35 mm Shaft diameter - lower: 30 mm total power requirement: 0,75 kw range L-W-H: 650 x 500 x 1300 mm weight: 170 kg Standard features: - hardened special steel shafts - a set of hardened rollers - Bottom rollers are driven - lateral straightening rollers - Foot pedal - horizontal and vertical working The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 2040 mm plate thickness: 4,0 mm distance between columns: 2100 mm roll diameter: 150 mm total power requirement: 7,0 KW weight of the machine ca.: 2,2 t dimensions of the machine ca.: 2,95 x 1,0 x 1,75 mm Sheet metal bending machine with 3 rollers - 2 driven rollers - Rear roller electrically adjustable - Conical bending - Foot switch - Emergency stop device The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

This 11-axis Finn-Power SG6 12.61 was manufactured in 2010. It features a maximum punching force of 300 kN and can handle sheet thicknesses up to 6 mm. The machine includes a thick turret with 20 stations and an integrated CNC right-angle shear for efficient part separation. If you are looking to get high-quality punching capabilities, consider the Finn-Power SG6 12.61 punching and bending machine we have for sale. Contact us for further details.

Max. pipe extension length: 3,000 mm 4-fold bending angle preselection with digital display up to 180° Working area 6 to 38 x 5 or 48.3 x 3.25 mm Includes pre-assembly device with hydraulic cylinder Deburring unit for tubes inside and outside from 6 - 48.3 mm Tools included: Bending mandrels: 35 x 2, 28 x 2.5, 22 x 2, 42.2, 18 x 2, 28 x 2 Bending shoes: 42, 38, 35, 18, 30 ZD, 16-R 35, 22 R 45, 20-2 XD, 25-2 XD, 28 R 55 Weight: approx. 600 kg

Press brake, bending machine, swing bending machine, die bending machine -Handover: in its current condition as inspected -Function: Manual operation (no automatic operation) -Manufacturer: RAFAMET Swivel bending machine type KM-4 -Drive: mechanical -Max. working width: 2020 mm -Max. sheet thickness: 4 mm -Stop depth: 750 mm -Connected power: kW -Dimensions: 3350/1540/H1510 mm -Weight: 3900 kg

Faceplate bending machine, profile bending machine, bending machine, angle bending machine, pipe bending machine, ring bender, ring former -Diameter of faceplate: 1330 mm -Clamping disc diameter: 775 mm -For an additional charge: other round shapes can be produced -Geared motor power: 1.5 kW -Speed: 86 rpm -Dimensions: 2440/1330/H1400 mm -Weight: 1420 kg

Offer 26148 Technical data: - Pressure capacity 420 KN / 42 t - Stroke length 0 - 300 mm - Lifting speed 0 - 0.6 m/min - Tool height 200 mm - Bending performance - with prism MW 125 flat approx. 200 x 16 mm - with prism MW 240 flat approx. 200 x 24 mm - Tube bending up to 2 inches - CNC control SIEMENS SIMATIC HMI TOUCH - For angle programming + length programming - Controlled length stop 3000 mm - Various bending tools - Operating hours (read) 1404 h - Drive 400 V / 4.0 kW - Space requirement approx. W 850 x H 1250 x D 1250 mm - Weight approx. 1200 kg

Inv. Num. : 9163 Type: MAH 40/3 CNC Producer: AMOB Created: 2022 Parameters: Diameter of the cylinders: 148 mm Length: 1200 mm Width: 770 mm Height: 1450 mm Weight: 540 kg Hydraulically controlled upper roller feed Can be used vertically and horizontally 3 mechanically driven rollers Side rollers (manually adjustable) Adjustable control pedal 3 standard rollers

This TFM GM-SB-38CNC-2A1S was manufactured in 2019. It features a max bending capacity of 38 × 2 mm, bending speeds up to 65 °/sec, and motor power of 4 kW. Ideal for precise bending with a max bending angle of 180° and effective length over mandrel of 3200 mm. Consider the opportunity to buy this TFM GM-SB-38CNC-2A1S profile bending machine. Contact us for more information.

Fasti - Round bending machine / type 2040x2mm -GS / Identifier -Roller diameter 105mm -Max. sheet thickness over the entire length 2mm -Footswitch -Safety device Dimensions: LxWxH 3x1x1.3 meters / Weight 1400Kg Hebjvdnahskn Au S Tsl

STIERLI - Bender 300 U / Horizontal bending machine -Year of construction 2011 -CE marking -Max. working pressure 300KN -Stroke length 300mm -Motor power 4 KW -Hand switch -Footswitch -Various matrices -Bending tools -Stop -Documentation Dimensions: LxWxH 1.5x1.2x1.3 meters / Weight 800Kg

Tube bending machine Tubend TB 42 hydraulic new machine - Capacity: 42 × 3 mm - Hydraulic drive - Adjustable stroke - Emergency stop function - Includes 3 tool sets: 33.7 mm, 26.9 mm, 21.3 mm - Documentation available - Connection: 400 V

Key data: 3200 , 8 , 490

The dual servo pump controllde press brake adopts a dual servo drive pump control system. Compared with the electro-hydraulic synchronous press brake, it’s hydraulic synchronization work relies on high-power dual servo pumps and does not need to rely on a throttle valve to control the cylinder. The temperature of the hydraulic oil will not rise during operation, which extends the working life of the hydraulic system. Therefore, this model has the following advantages: electro-hydraulic synchronization, as well as high efficiency, energy saving, quietness, durability and other properties

wire diameter 10-16 mm feed legth 100-250 mm pitch 5x dia. output pieces/min 25-50

wire diameter range 10 mm width of band 100 mm feeding length 250 mm

wire diameter 2-7 mm output - pieces/min 100

wire diameter range 0,5 -5,0 mm width of band max 70 mm feeding length max 320 mm output pieces/min max 132 number of slides 5

dia. range 1-4 mm width of band 20 mm output pieces/min 80-150 feeding length 240 mm

dia. range 0,5-2,5 mm width of band 50 mm feeding length 170 mm number of slides 5 punching power 5 to output - pieces/min 225

Offer 26165 Technical data - Two driven rollers, each roller hydraulically adjustable - For bending and conical rolling - Operation of separate control panel, with digital actual value display - and manual operation - Max. working width 1300 mm - Max. sheet thickness at 400 N/mm² without bending - With a bending diameter of 370 mm, 30 mm inside - With bending at bending diameter 370 mm, inside 25 mm - without bending with a bending diameter of 380 mm inside and - Width of 370 mm 45 mm - Upper roller diameter each 300 mm - Side roller diameter each 310 mm - Working speed 4.5 m/min - Drive 400 V / 30 kW - Required space W 5800 x H 1900 x D 2200 mm - Weight 8500 kg

Key data: 6000 mm, 6 mm

Zschokke HAP 063a - 4/6 - Hydraulic press brake - Year of construction 1967 Technical data - Max. bending force: 630 t - Max. oil pressure: 400 atü - Column passage: 4100 mm - Max. bending length: 6000 mm - Projection: 375 mm - Stroke (adjustable): 0 - 500 mm - Distance of the tool holding surface: 300 - 800 mm Hydraulic pumps: - Main pumps: 2x 22 kW - Idle flow rate: 2x 153 l/min - Full load flow rate: 2x 33 l/min - Control pump: 0.75 kW Installation: - Footprint WxD: 6960 x 3250 mm - Height above ground: 4100 mm - Underfloor front: 2200 mm - Underfloor rear: 600 mm - Operating voltage: 3x 400 V / 50 Hz - Machine weight: 51000 kg

Inv. Num. : 9273 Type: APK 61 Producer: AKYAPAK Created: 2015 Parameters: Number of driven rollers: 3 pieces Shaft diameter: 61 mm Weight: 1080 kg

A hydraulic 4-roll plate rolling machine Promau (Prümau) is available. Working width: 3000mm, bending capacity: 13mm, pre-bending capacity: 10mm, rolls: 4. An on-site inspection is possible.

Offer 26174 Technical data: - Bending performance - Tube at 45 kg / mm² Ø 6 - 48 mm - Wall thickness up to 3.25 mm - Max. bending radius 180 mm - Bending speed 20 °/sec. - Drive 400 V / 2.4 kW - Space requirement approx. W 6200 x H 1200 x D 1000 mm - Weight approx. 1100 kg - Operating hours read 972 h -with - Digital bending angle display + bending angle fine adjustment - With control SIEMENS SIMATEC Touch Panel - Mandrel bending device 4.5 m. with hydr. Withdrawal - Sawing unit - Deburring unit for internal and external deburring - Pipe positioning system - Bending tools without mandrels - 6 ,8 , 10 , 12 , 16 , 20 , 22 , 28 , 30 mm , - Partly possibly incomplete

A BPR ring bending machine is available. Shaft diameter: 40mm, max. roller diameter: 162mm, center distance: 300mm, shaft speed: 7.5rpm, max. flat steel bending capacity: 100mm/15mm, max. edgewise steel bending capacity: 60mm/10mm, max. bending diameter: 35mm, machine dimensions X/Y/Z: approx. 950mm/650mm/1400mm, weight: approx. 500kg. An on-site inspection is possible.

Ref.Nr. 00928 Name of the system Biegomat Post III 3D bending machine For sale is a Biegomat Post III 3D bending machine for the production of wire and bent parts. The machine is suitable for the flexible production of complex geometries. Manufacturer Biegomat Model Post III Year of manufacture 2001 Condition: Under power Technically Ok Demonstration Remark Bending machine for thin wires 3D bending machine Control: The programming works with G and M codes, all program lines have to be written completely by hand Recommendation: Overhaul of the hydraulics with hose, valves, seals would be recommended

Key data: 1020 mm, 6 mm

Max. sheet thickness: 6 mm steel Upper roller diameter: 150 mm Motorized rear roll infeed Clockwise and counterclockwise rotation via footswitch Safety rope pull switch Conical rounds possible Weight: 1200 kg

Tube & profiles bending machine ,Tauring Slalom 60-3A 8 rollers for left and right hand bending sense Operation in manual and automatic programmable axis with digital screen readout One-pass bending programmable in different planes manipulator programmable tube turner” 12 mtrs length tube feeder Complete with several set of rolls for tube from 14 to 60 mm - 8 pcs each set = total 140 rolls. Power rotation 3 kw voltage Vac 400/50 power hydraulic bending 2,2 Kw

sheet width: 1250 mm plate thickness: 1.5 mm roll length: 1270 mm roll diam. toproll: 75.0 mm engine output: 1.5 kW weight: 400 kg range L-W-H: 1730 x 700 x 1160 mm Exhibition machine - like NEW not yet in use () Special price on request Equipment: - electro-motor-driven 3-roller round bending machine - asymmetrical roller arrangement - 2x driven rollers using a brake motor - manual folding bearing for quick removal of the workpiece - wire insertion grooves on the bottom and rear rollers - double foot switch for R/L running including emergency stop button - rear roller feed with ratchet lever - electrical safety device The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

tube diameter: 40-168 x10,0 mm wall strength: . mm bending radius min.: ohne Rohr 190 mm voltage: 380 V operating pressure: 200 bar total power requirement: . kW weight of the machine ca.: 22 t dimensions of the machine ca.: 7,50x2,8x1,6 ( 30 m²) m The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale, Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team The data for this ad was created with ModulMWS - the software solution of LogoT ...

: neu : ca. 12 Wochen ab Auftrags : Türkei : 16600 € : 318.72 € : 2050 mm : 4 mm : 140 mm : 2.2 kW : 3200 mm : 750 mm : 1000 mm : 1650 kg 3 reels asymmetrical roller arrangement - with pre-bending 2 driven rollers by means of a brake motor manual Back Roll upper roller can be swiveled forward forward / reverse run conical rounding by inclining the rear rollers movable control panel OPTIONS (PRICES ON REQUEST): hardened Rolls Motorised Back Roll (Power Rear Roll) Digital Read-Out (sample photo) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: neu : ca. 12 Wochen ab Auftrags : Italien : 3050 mm : 16 mm : 16 mm : 10 mm : 13 mm : 11 mm Hardened and polished rollers Numerical control Siemens PGS-Classic with touchscreen Cone bending with electronic control and inclination of the bottom roller oil cooler Simultaneous rotation and roller movement Simultaneous roller and support movement Possibility to bend variable radii (ovals, ellipses, etc.) Hydraulic micro-positioning by the PLC for higher accuracy Infinitely variable speed for roller movement Infinitely variable speed for rotation Prepared for retrofitting supports (up to 5 axes) Prepared for retrofitting loading/unloading stations Prepared for retrofitting CNC controls Extra large, double hinged drop end Electronic parallelism system for the synchronization of the rollers Hydraulic lifting of the top roll (for models with a top roll diameter of 205 mm or more) Double linear ...

: neu : ca. 12 Wochen ab Auftrags : Italien : 3050 mm : 7 mm : 7 mm : 4 mm : 5 mm : 5 mm Hardened and polished rollers Numerical control Siemens PGS-Classic with touchscreen Cone bending with electronic control and inclination of the bottom roller oil cooler Simultaneous rotation and roller movement Simultaneous roller and support movement Possibility to bend variable radii (ovals, ellipses, etc.) Hydraulic micro-positioning by the PLC for higher accuracy Infinitely variable speed for roller movement Infinitely variable speed for rotation Prepared for retrofitting supports (up to 5 axes) Prepared for retrofitting loading/unloading stations Prepared for retrofitting CNC controls Extra large, double hinged drop end Electronic parallelism system for the synchronization of the rollers Hydraulic lifting of the top roll (for models with a top roll diameter of 205 mm or more) Double linear guid ...

ERCOLINA MB 42 / Mandrel tube bending machine -CE - Identifier -Year of construction 2009 -Bending capacity / steel tube 42.4x3mm -Max. tube diameter aluminum / copper 54x2mm -Bending performance furniture construction tube 48x1.5mm -Solid material up to 30mm -Max. bending angle 210 degrees -Electronic control with digital display -Max. 30 x program memory -Programs with 9 x bends - Overload Protection / Yes - Operation: Double foot pedal ( bend - return) -Max. bending speed 2rpm -Incl. 1x tool -1.1 KW -Footswitch -Documentation Dimensions: LxWxH 0.5x0.6x1.2 meters / Weight 100Kg

: neu : ca. 8 Wochen ab Auftragse : Türkei : 7300 € : 140.89 € : 10 to : 185 mm : 150x8 mm : 450x900 mm : 150 mm : 60 mm : 10 mm/s : 10 mm/s : 1.1 kW : 915 mm : 900 mm : 450 mm : 1130 mm : 250 kg Stroke adjustment with digital display Manual and automatic operation mode Tool holder pins and tools hardened and ground Bending tool Foot pedal OPTIONS: Cutting-, punching- or pipe bending tools on request The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: neu : ca. 12 Wochen ab Auftrags : Türkei : 97400 € : 1840.86 € : 2050 mm : 30 mm : 30 mm : 25 mm : 25 mm : 20 mm : 350 mm : 350 mm : 260 mm : 1,5-5 m/min : 22 kW : 5000 mm : 2000 mm : 1900 mm : 11000 kg 4 rolls fullhydraulic drive of upper roll and lower roll hydraulic infeed of lower and side roll digital read-out of lower and side rolls position hardened rolls conical bending device hydraulic load relieving of upper roll hydraulic drop-end bearing 2 working speeds central lubrication system protectionagainst overload moveable control pane according to CE rules OPTIONAL EQUIPMENT: infinitely adustable speed of rolls hydraulic side support hydraulic top support NC control IMPORTANT ISSUES AT CONICAL BENDING: the max. sheet metal thickness isequivalent to 50 % of nominal capacity the cone length can be max. 30 % oremust be more than 60 % of roll length hardened rolls are recommende ...

: neu : ca. 10 Wochen ab Auftrags : Türkei : 5200 € : 100.36 € : 1270 mm : 1.5 mm : 75 mm : 1.5 kW : 1830 mm : 700 mm : 1160 mm : 400 kg 3 rolls asymmetric rolls - prebending 2 rolls driven by brakemotor lateral roll adjustable by ratchet lever longitudinal grooves in lower and lateral roll tiltable upper roll right / left rotation with double foot switch user manual in GERMAN or ENGLISH OPTION (PRICE ON REQUEST): hardened rolls The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: neu : ca. 8 Wochen ab Auftragse : Türkei : 12900 € : 247.68 € : 40 to : 285 mm : 200x24 mm : 660x1250 mm : 250 mm : 80 mm : 10 mm/s : 10 mm/s : 4 kW : 930 mm : 1250 mm : 650 mm : 1250 mm : 1100 kg Stroke adjustment with digital display Manual and automatic operation mode Tool holder pins and tools hardened and ground Bending tool Foot pedal OPTIONS: Cutting-, punching- or pipe bending tools on request The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: neu : ca. 10 Wochen ab Auftrags : Türkei : 12300 € : 236.16 € : 1270 mm : 4 mm : 120 mm : 3 m/min : 2.2 kW : 2470 mm : 750 mm : 1000 mm : 1110 kg 3 rolls asymmetric rolls - prebending 2 rolls driven by brakemotor manual Back Roll forward tiltable upper roll forward and reverse revs conical bending by tilt of backroll movable control panel users manual in ENGLISH or GERMAN OPTIONS: hardened Rolls Motorised Back Roll (Power Rear Roll) Digital Read-Out The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: neu : ca. 12 - 14 Wochen ab Auf : Türkei : 134000 € : 2532.6 € : 3100 mm : 25 mm : 25 mm : 20 mm : 20 mm : 20 mm : 16 mm : 360 mm : 360 mm : 270 mm : 60 mm : 1510 mm : 22 kW : 5560 mm : 2060 mm : 2050 mm : 16750 kg 4 rolls fully hydraulic drive of upper and lower roll (from 30 mm bending capacity all four rolls) by planetary gear box hydr. side rolls positioning with electronical synchronisation hydr. lower roll feed with mechanical synchronisation adjustable pinching pressure variable rolling speed hardened rolls conical bending device hydraulic drop-end bearing moveable control panel overload protection user manual in GERMAN or ENGLISH according to CE rules OPTIONAL: NC control upper and lateral supports IMPORTANT ISSUES AT CONICAL BENDING: the max. sheet metal thickness isequivalent to 50 % of nominal capacity The data for this ad was created with ModulMWS - the software solut ...

: neu : 2026 : 090209 : prompt, Zwischenverkauf v : Italien : 7780 € : 150.15 € : 1 : 1 : 42 mm : 400 mm : 570 mm : 1000 mm : 80 kg : 4 cm³ : 42 x 3 mm : 48 x 1,5 mm : 42 x 4 mm : 42 x 2 mm : 42 x 2 mm : 50 x 3 mm : 54 x 2 mm : 54 x 2 mm : 60 x 2 mm : 50 x 4 mm : 30 mm : 40x20 (liegend), 40x12 (s mm : 260 mm : 10 mm : 3,3 U/min : 1.1 kW manual clamping electronic preselection of bending angle digital read our for Clamping position 30 programms with each 9 bends material spring back compensation overload protection mobile by rolls and handle foot pedal tools not included Alternatively also available as following models (prices on request): MB 42M (single phase, 2 U/min) MB 42PM (portable, single phase, 2 U/min) The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

: neu : ca. 10 Wochen ab Auftrags : Türkei : 43550 € : 831.81 € : 1550 mm : 12 mm : 12 mm : 10 mm : 10 mm : 8 mm : 220 mm : 200 mm : 160 mm : 1,5 / 6 m/min : 5.5 kW : 3900 mm : 1150 mm : 1250 mm : 3600 kg 4 rolls Top rolll driven by hydromotor and planetary gearbox, bottom roll driven by gear and cardan system Pinch roll and latereal rolls move with hydraulic cylinders Digital read-out for lower and side rolls position Hardened rolls Conical bending device Hydraulic load relieving of upper roll Hydraulic drop-end bearing 2 working speeds Protectionagainst overload Moveable control pane According to CE rules OPTIONAL EQUIPMENT: Infinitely adustable speed of rolls Hydraulic side support Hydraulic top support NC control IMPORTANT ISSUES AT CONICAL BENDING: The max. sheet metal thickness isequivalent to 50 % of nominal capacity The cone length can be max. 30 % oremust be more than 60 %  ...

: neu : ca. 12 Wochen ab Auftrags : Türkei : 28450 € : 543.4 € : 1550 mm : 7 mm : 7 mm : 4.5 mm : 4.5 mm : 3.5 mm : 150 mm : 150 mm : 130 mm : 1,5 / 6 m/min : 4 kW : 3750 mm : 960 mm : 1100 mm : 2500 kg 4 rolls Top rolll driven by hydromotor and planetary gearbox, bottom roll driven by gear and cardan system Pinch roll and latereal rolls move with hydraulic cylinders Digital read-out for lower and side rolls position Hardened rolls Conical bending device Hydraulic load relieving of upper roll Hydraulic drop-end bearing 2 working speeds Protectionagainst overload Moveable control pane According to CE rules OPTIONAL EQUIPMENT: (time of deliver with options approx. 10 weeks) Infinitely adustable speed of rolls Hydraulic side support Hydraulic top support NC control IMPORTANT ISSUES AT CONICAL BENDING: The max. sheet metal thickness isequivalent to 50 % of nominal capacity The cone leng ...

: neu : ca. 12 Wochen ab Auftrags : Türkei : 24500 € : 470.4 € : 1550 mm : 4.5 mm : 4.5 mm : 3.5 mm : 4.5 mm : 3.5 mm : 3.5 mm : 2.5 mm : 130 mm : 130 mm : 130 mm : 5 m/min : 2,2 + 1,1 kW : 3300 mm : 1150 mm : 1110 mm : 2370 kg motorized roller drive upper and lower roller driven hydraulic side roll feed 3 digital displays hydraulic folding bearings hardened rollers conical bending device user manual in GERMAN or ENGLISH OPTIONAL EQUIPMENT (PRICES ON REQUEST): overhead crane side supports NC control variable speed The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Offer 22186 Technical data: - Bending performance - Tube at 45 kg / mm² Ø 6 - 48 mm - Solid material up to approx. 30 mm - Max. bending angle 180 ° - Bending radius 2 x D - Drive 400 V / 1.5 kW - Space requirement approx. W 4500 x H 1400 x D 1000 mm - Weight approx. 600 kg - with - Digital bending angle display + bending angle fine adjustment - Mandrel bending device 3.0 m. with hydr. Withdrawal - Bending tools 20 R 60 ; 22 R 66 ; 25 R 75 mm - 25 R 50 ; 38 R 114 mm - various bending mandrel e 3000 mm

sheet width: 3100 mm plate thickness: 50 mm pre-bending: 40 mm diameter of upper rolls: 540 mm diameter of lower rolls: 500 mm side roll diameter: 440 mm engine output: 55 kW total power requirement: kW weight of the machine ca.: 40 t dimensions of the machine ca.: 6,7 x 3,0 x 3,0 m With: Cone bending device Induction hardened rolls Digital readout for side rolls Fully welded steel (St-52) frame Separate moveable control panel Bending speeds, slow and fast Electronic Parallelism All rolls are mounted in spherical roller bearings Hydraulically opened/closed drop end controlled from control panel Activation of cone rolling function and position adjustment via buttons on the control panel Central rolls (top and bottom rolls) driven by hydraulic motors and planetary gear reducers Electro – hydraulic calibration OPTIONAL FEATURES AND ACCESSORIES: Center support: 21.468,75 € Side supports  ...

tube diameter: 60 mm wall strength: 3 mm bending radius min.: 2 x Rohr-Ø ÷ R200 mm : 0 - 180 ° : 2 (60.,3mm) mm : stufenlos 0,5 - 2,0 : 1,5 kW : 700 kg - Powerful mandrel bending machine up to 2 gas pipe (60.3mm) in semi-automatic design (6000 mm pipe slide length) - Electromechanical drive of the bending axis - hydraulic clamping - mandrel feed / extract - 30 programs x 9 bending angle + correction angle The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

sheet width: 2070 mm plate thickness: 25 mm pre-bending: 18 diameter of upper rolls: 320 mm side roll diameter: 260 mm diameter of lower rolls: 320 mm : 26 kW : 8100 kg : 4700 x 2000 x 2200 mm Features: - Hydraulic side roller adjustment - Conical bending device - 2 driven rollers - Hardened rollers - Hydraulic folding bearing - Mobile control panel - Foot switch - Safety device - CE mark The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
