ram used for sale

pressure:400 t throat:520 mm stroke:20 - 200 mm no. of strokes:30 /min distance table/ram, max. stroke up, adjustment up:680 mm table surface area:1600 x 1000 mm table height over floor:715 mm passage to the back:1000 mm ram surface:1300 x 800 mm ram adjustment:130 mm power requirement:38,0 kW weight:41,0 t dimensions (WxDxH):2,1 x 2,6 x 4,2 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch-/ brake combination:pneumatic, Ortlinghaus overload protection in ram:hydraulic ram adjustment:motoric ram counterbalance:pneumatic

pressure:150 t throat:520 mm stroke:30 - 200 mm no. of strokes:15 - 60 /min distance table/ram, max. stroke up, adjustment up:650 mm table surface area:1600 x 1000 mm hole in the table:1040 x 140 mm table height over floor:1000 mm passage to the back:1000 mm ram surface:1400 x 800 mm ram adjustment:120 mm power requirement:20,0 kW weight:27,5 t dimensions (WxDxH):2,3 x 2,75 x 4,5 m clutch-/ brake combination:pneumatic; Ortlinghaus overload protection in ram:hydraulic ram counterbalance:pneumatic ram adjustment:semi-automatic Option: NEW electrical controls:Siemens S7-1500 F

pressure:315 t throat:480 mm stroke:20 - 190 mm no. of strokes:36 + 45 /min distance table/ram, max. stroke up, adjustment up:615 mm table surface area:1400 x 880 mm hole in the table:250 mm table height over floor:800 mm passage to the back:950 mm ram surface:850 x 630 mm ram adjustment:125 mm power requirement:33,0 kW weight:30,0 t dimensions (WxDxH):2,0 x 3,0 x 4,4 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch-/ brake combination:pneumatic overload protection in ram:hydraulic stroke adjustment:semi-automatic ram adjustment:motoric ram counterbalance:pneumatic

pressure:200 t stroke:30 - 160 mm no. of strokes:40 - 120 /min distance between columns:1500 mm distance between oil collecting pans:1300 mm distance table/ram, max. stroke up, adjustment up:860 mm hole in the table:550 x 300 mm table surface area:1250 x 1250 mm table height over floor:1000 mm column travel -side:600 x 530 mm ram surface:1250 x 1000 mm ram adjustment:125 mm Material width of feeder:30 - 500 mm Material thickness feeder:0,5 - 3,0 mm feeding length:0 - 999,9 mm power requirement:50,0 kW weight:34,0 t dimensions (WxDxH):4,0 x 1,7 x 5,2 m clutch-/ brake combination:pneumatisch, Ortlinghaus overload protection in ram:hydraulisch ram adjustment:automatisch stroke adjustment:automatisch ram counterbalance:pneumatisch roll feed:Weingarten, WE 60 Option: NEW electrical controls:Siemens S7-1500 F

pressure:400 t distance between columns:1100 mm stroke:250 mm no. of strokes:25 - 75 /min distance table/ram, max. stroke up, adjustment up:900 mm table surface area:1100 x 965 mm capacity of ejector in table:30 t ejector stroke of ejector in table:80 mm capacity of ejector in ram:3 t stroke of ejector in ram:60 / 70 mm ram surface:980 x 800 mm column travel -side:800 mm ram adjustment:20 mm power capacity:80,0 + 5,5 kW weight:47,0 t Dimensions (WxDxH):3,5 x 3,3 x 6,0 m weight of switch cabinet:1,4 t dimensions of electrical cabinet (WxDxH):4,9 x 0,5 x 2,6 m ejector in ram:hydraulic

Pressure:1000 t distance between columns:4100 mm stroke:1200 mm Distance table/ram, stroke up:2100 mm Table surface area:4000 x 2200 mm pressure of drawing cushion in table:360 t Die cushion stroke in table:300 mm Die cushion area in table:3500 x 1600 mm Die cushion pressure in ram:100 t Die cushion stroke in ram:160 mm Die cushion area in ram:3250 x 1600 mm Ram surface:4000 x 2200 mm Side window:1300 mm Oil volume:8000 l Power capacity:300,0 kW Dimensions (WxDxH):5,75 x 4,3 x 9,55 m Height above floor:7,7 m die cushion in table:hydraulic, controllable die cushion in ram:hydraulic, controllable cutting impact cushioning:hydraulic

Pressure:800 t distance between columns:3250 mm stroke:1100 mm Distance table/ram, stroke up:1900 mm Table surface area:3100 x 1900 mm pressure of drawing cushion in table:300 t Die cushion stroke in table:300 mm Die cushion area in table:2500 x 1800 mm Die cushion pressure in ram:80 t Die cushion stroke in ram:200 mm Die cushion area in ram:2200 x 1000 mm Ram surface:3100 x 1900 mm Side window:900 mm Oil volume:4700 l Power capacity:200,0 kW Dimensions (WxDxH):4,95 x 3,3 x 10,2 m Height above floor:7,05 m die cushion in table:hydraulic, controllable die cushion in ram:hydraulic, controllable cutting impact absorption:hydraulic

Pressure:600 t distance between columns:2600 mm stroke:900 mm Distance table/ram, max. stroke up, adjustment up:1600 mm Table surface area:2500 x 1730 mm pressure of drawing cushion in table:250 t Die cushion stroke in table:400 mm Die cushion area in table:2300 x 1300 mm Die cushion pressure in ram:63 t Die cushion stroke in ram:160 mm Die cushion area in ram:1900 x 1300 mm Ram surface:2500 x 1730 mm Side window:1100 mm Oil volume:3500 l Power capacity:200,0 kW Dimensions (WxDxH):4,1 x 2,8 x 9,6 m Height above floor:6,4 m die cushion in table:hydraulic, controllable die cushion in ram:hydraulic, controllable cutting impact absorption:hydraulic

pressure:500 t stroke:fix 300 mm no. of strokes:20 - 70 Hub/min distance between columns:3100 mm side window:1400 mm distance table/ram, max. stroke up, adjustment up:1000 mm Table area:2800 x 1600 mm ram surface:2800 x 1450 mm ram adjustment:100 mm power requirement:90,0 kW weight:100,0 t Dimensions (WxDxH):5,75 x 3,2 x 7,8 m height above floor:6,4 m height beneath floor:1,4 m clutch:pneumatic; Ortlinghaus ram adjustment:motoric overload protection in ram:hydraulic ram counterbalance:pneumatic

pressure:600 t distance between columns:3640 mm stroke:350 mm no. of strokes:11 - 44 /min Distance table/ram, max. stroke up, adjustment up:1550 mm table surface area:3600 x 2500 mm sliding table:3600 x 2500 mm ram surface:3600 x 2500 mm Side window:2200 mm ram adjustment:400 mm material width coil line:500 - 1950 mm Material thickness at 1200 mm material width:0,6 - 2,5 mm Material thickness at 1850 mm material width:0,6 - 2,0 mm Material thickness at 1950 mm material width:0,6 - 1,75 mm Coil weight:35,0 t coil internal diameter:610 mm coil external diameter:900 - 1900 mm no. of straightening rolls:13 straightening roll diameter:50 mm Stack height:400 mm stacking dimensions - station 1+2 (L x W):150-2000 x 250-2000 mm stations:2 power requirement:112,0 + 35,0 kW Weight:390,0 t Dimensions (WxDxH):7,3 x 5,1 x 15,0 m Height above floor:9,1 m Height below floor:5,9 m clutch-/ brake combinat ...

pressure:800 t distance between columns:1050 mm stroke:200 mm no. of strokes:8 - 25 /min distance table/ram, max. stroke up, adjustment up:1300 mm Side window:550 mm table surface area:1030 x 900 mm Capacity of ejector in table:15 t Stroke of ejector in table:85 mm ram surface:1040 x 800 mm ram adjustment:120 mm Capacity of ejector in ram:12 t ejector stroke in ram :80 mm power requirement:36,0 - 112,6 kW weight:65,0 t Dimensions (WxDxH):3,0 x 3,1 x 6,07 m ejector in table:hydraulic ejector in ram:hydraulic

pressure:315 t distance between columns:2350 mm distance table/ram, max. stroke up, adjustment up:1200 mm distance between cutting impact cushioning:1600 mm Distance table/ram, stroke up:1200 mm stroke:800 mm table surface area:2060 x 1260 mm table height over floor:750 mm Die cushion pressure in table:100 t Die cushion stroke in table:400 mm die cushion area:1250 x 1000 mm side window:780 mm ram surface:2200 x 1500 mm Capacity of ejector in ram:63 t speed down:500 mm/s speed up:310 / 410 mm/s working speed:20 - 73 mm/s quantity of oil:3900 l power requirement:80,0 + 45,0 kW weight:55,0 t Dimensions (WxDxH):4,6 x 2,7 x 7,2 m Height above floor:6,0 m Height below floor:1,2 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 die cushion in table:hydraulic ejector in ram:hydraulic ram interlocking:hydraulic cutting impact absorption:hydraulic

Capacity, ton 800 Movable die stroke, mm 180 Max. upsetting ram stroke, mm 380 Upsetting ram workstore, mm 250 Upsetting ram return stroke with closed dies, mm 130 Distance bentween upsetting ram and dies stroke forward, mm 140 Number of ram strokes per minute 35 Die dimensions, mm 590 x 220 x 660 Electric motor power, kW 40 Dimensions: mm 6300 x 3900 x 2850 Weight: kg app. 80800

pressure: 80 t throat: 250 mm stroke: 10 - 115 mm no. of strokes: 60 Hub/min dayligth: 285 mm distance table - lower edge of ram: 400 mm ram adjustment: 50 mm table-size: 500 x 750 mm ram head dimension: 340 x 440 mm work height max.: 700 mm table hole: 220 mm ram hole: 45 mm total power requirement: 5,5 kW weight of the machine ca.: 4 t dimensions of the machine ca.: 1,5 x 1,4 x 2,5 m This eccentric press machine with 80 ton capacity is suitable to carry out tasks involving deep-drawing, cutting, punching and stamping. Our Profi Press mechanical presses can be used for various applications in many different industries: the automotive, railway and aerospace industries (for example) and many more related industries that use metal forming. Made of S355JR steel and equipped with a 4 guided ram. The rod is made out of high-strength forged steel and high-performance alloy bushings. This high  ...

pressure: 30 t throat: 180 mm stroke: 10 - 75 mm no. of strokes: 125 Hub/min dayligth: 225 mm distance table - lower edge of ram: 300 mm ram adjustment: 50 mm table-size: 360 x 560 mm ram head dimension: 260 x 340 mm work height max.: 670 mm table hole: 140 mm ram hole: 35 mm total power requirement: 2,2 kW weight of the machine ca.: 2,8 t dimensions of the machine ca.: 1,1 x 1,3 x 2,0 m This eccentric press machine with 80 ton capacity is suitable to carry out tasks involving deep-drawing, cutting, punching and stamping. Our Profi Press mechanical presses can be used for various applications in many different industries: the automotive, railway and aerospace industries (for example) and many more related industries that use metal forming. Made of S355JR steel and equipped with a 4 guided ram. The rod is made out of high-strength forged steel and high-performance alloy bushings. This hig ...

pressure: 125 t throat: 300 mm stroke: 10 - 135 mm no. of strokes: 50 Hub/min dayligth: 315 mm distance table - lower edge of ram: 450 mm ram adjustment: 60 mm table-size: 600 x 900 mm ram head dimension: 315 x 550 mm work height max.: 800 mm table hole: 250 mm ram hole: 50 mm total power requirement: 11,0 kW weight of the machine ca.: 5,5 t dimensions of the machine ca.: 1,65 x 1,68 x 2,87 m This eccentric press machine with 80 ton capacity is suitable to carry out tasks involving deep-drawing, cutting, punching and stamping. Our Profi Press mechanical presses can be used for various applications in many different industries: the automotive, railway and aerospace industries (for example) and many more related industries that use metal forming. Made of S355JR steel and equipped with a 4 guided ram. The rod is made out of high-strength forged steel and high-performance alloy bushings. Thi ...

pressure: 60 t throat: 235 mm stroke: 10 - 100 mm no. of strokes: 60 Hub/min dayligth: 270 mm distance table - lower edge of ram: 370 mm ram adjustment: 50 mm table-size: 470 x 700 mm ram head dimension: 310 x 410 mm work height max.: 670 mm table hole: 190 mm ram hole: 40 mm total power requirement: 4,0 kW weight of the machine ca.: 3,5 t dimensions of the machine ca.: 1,23 x 1,46 x 2,35 m This eccentric press machine with 80 ton capacity is suitable to carry out tasks involving deep-drawing, cutting, punching and stamping. Our Profi Press mechanical presses can be used for various applications in many different industries: the automotive, railway and aerospace industries (for example) and many more related industries that use metal forming. Made of S355JR steel and equipped with a 4 guided ram. The rod is made out of high-strength forged steel and high-performance alloy bushings. This  ...

pressure: 75 t throat: 300 mm stroke: 8 - 110 mm table surface area: 750 x 600 mm ram adjustment: 75 mm ram surface: 430 x 230 mm hole in the table: 250 x 150 mm tool hole in ram: 40 mm no. of strokes: 60 + 90 Hub/min weight of the machine ca.: 4,4 t total power requirement: 4,5 - 6,8 kW dimensions of the machine ca.: 1,95 x 1,1 x 2,35 m distance table/ram: Hub unten, Stöß. unten 19 mm distance table/ram: Hub oben, Stöß. oben 380 mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

Length: 0 mm Module: 0 mm Width: 0 mm CNC Brand: 0 CNC Model: 0 Technical data Working range: Module from: 0.5 up to: 6 Max. wheel diameter: 400 mm Max. gear cutting width: 70 mm Max. gear cutting diameter: 400 mm Min. ram stroke: 0 mm Max. ram stroke: 82 mm Adjustment of stroke position: 100 mm Distance ram to table: from: 265 mm up to: 365 mm Taper in ram: 5 MT Ram stroke speeds: from: 118 s/min up to: 1000 s/min Voltage 50 Hz 3x: 380 Volt Machine´s weight about: 6300 kg Overall dimensions machine: Length: 2570 mm Width: 1320 mm Height: 2200 mm

pressure: 160 t distance between columns: 2700 mm stroke: 280 mm ram adjustment: 120 mm daylight (stroke down, ram adjustment above): 550 mm table surface area: 2700 x 1200 mm ram surface: 2700 x 1200 mm no. of strokes: 20 - 40 Hub/min total power requirement: 22 kW weight of the machine ca.: 33 t dimensions of the machine ca.: B 3520 x T 2850 x H 4550 m Double-column eccentric press in a special design - size of the GTX 250 S, but only a pressing force of 160 t Furnishing: - hydraulic roller bars - hydraulic Tool clamping above + below - Motorized ram adjustment - infinitely variable speed control - hydraulic overload - Grease central lubrication - Hand oiler for ram weight compensation converted by MAWI GmbH Germany: - Swivel arm with Siemens Touch control panel - Light barrier from Sick - Safety control from Pilz + Siemens - frequency converter - Monitored protection area at the rear  ...

TOSHIBA SHIBAURA CNC VERTICAL BORING MILL with FANUC 16i-T CNC Control Control: GE Fanuc Series 16i-T Table Diameter: 117.7” (3000mm) Maximum Swing: 141.7” (3600mm) Maximum Weight on Table: 50T (2) Ram Heads L & R Z-Stroke: 48 – 375” Maximum Distance Under Rail: 126.7”(3220mm) Maximum Height under Ram: 119.2”(3030mm) Cross Rail Travel: 79.9” Vertical Ram Stroke Right: 62.9”(1600mm) Vertical Ram Stroke Left: 49.2”(1250mm) Speeds: .32 – 63 RPM Approx. Weight: 125,222 lbs  Equipped With 3000mm dia. Table / GE Fanuc 16i-T CNC Control / (2) Ram Heads

year 1985 Capacity 2500 / 2750 Ton 24900 / 27400 kN Speed 65 SPM, continuous mode Ram/Slide Stroke 12.60in, 320.00mm Ram/Slide Adjustment 0.39in, 10.00mm Shut Height (Ram / Slide Down, Adjustment Up) 35.60in, 905.00mm Stroke of Upper Knockout 2.00in, 50.00mm Stroke of Lower Knockout 2.80in, 70.00mm Ram/Slide Width 52.00 in, 1320.00 mm Ram/Slide Height 43.00 in, 1100.00 mm Bed Width 53.00 in, 1340.00 mm Bed Depth 55.00 in, 1400.00 mm power Existing Additional 28 Strokes per minute in manual mode, height shown is above floor, total height is 291 in ( 7390 mm), new quick change hydraulic type bolster Machine Length 160.00 in, 4055.00 mm Machine Width 157.00 in, 4000.00 mm machine height 264.00 in, 6710.00 mm Weight 320000 lbs, 145455 kg Condition Excellent Currently disassembled an ...

pressure: 1500 t daylight: 5060 mm mould space: - mm table surface area: 5000 x 2700 mm main drive: 90 kW max. ram stroke: 800 mm ram adjustment: 600 mm no. of strokes: 10 Hub/min ram head dimension: 5000 x 2700 mm die cushion stroke: 200 mm die cushion: to total power requirement: kW weight of the machine ca.: t MECHANICAL PRESS - Distance between clamping plate and ram with stroke at bottom, adjustment at top: 1600 mm - Compressed air pulling device in the table -- stroke 200mm - Ejector in ram -- Stroke 150mm The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.

This machine is a numerically controlled and cross rail elevating double column type vertical boring and turning mill. Is a machine with two rail heads. One, on the right side is turning head and the other, on the left side is a milling head. The right head is utilized exclusively for turning work and can withstand heavy duty operation, and left performs boring and milling work. After the turning is completed, both heads can be performed without changing the machine set-up. These features, coupled with table indexing and milling feed, assure versatility machining capabilities. The cross rail is guided by the slideways of the two columns. Electro-hydraulic clamping clamping devices assure clamping of the cross rail at the desired position. Highly accurate horizontal straightness is guaranteed by the simple and stabilized method of utilizing the compensation beam inside the cross beam. ...

SMERAL LZK 2500 Hot Forging press Fully refurbished in 2024 Capacity: 2500 Ton Speed: 65 SPM, continuous mode Ram/Slide Stroke: 320.00mm Ram/Slide Adjustment: 10.00mm Shut Height (Ram/Slide Down, Adjustment Up): 905.00mm Stroke of Upper Knockout: 50.00mm Stroke of Lower Knockout: 70.00mm Ram/Slide Width: 1320.00 mm Ram/Slide Height: 1100.00 mm Bed Width: 1340.00 mm Bed Depth: 1400.00 mm Power: 130kW Machine Length: 4055.00 mm Machine Width: 4000.00 mm Machine Height: 6710.00 mm Weight: 140000 kg Condition: like new refurbishing report: 1. Mechanical part • Complete disassembly of the press. • Measurement and troubleshooting of all parts. • The main parts of the press are tested (without destruction) in order to identify any defects. Frame: The frame was inspected and non-destructive testing of the most loaded areas was carried out. Damage to the table pl ...

Key data: 1250 , 640

HYDRAULIC DOUBLE-ACTING DIE FORGING HAMMER HOU 160 equipped with ejector Blow energy (with installed upper die with nominal weight): 16 [kJ] Nominal weight of upper die: 100 [kg] Blow frequency at nominal capacity approx. 95 [1/min] Ram velocity: 5 [m/s] Ram depth: 460 [mm] Ram weight: 1250 [kg] Ram stroke max.: 640 [mm] Ram stroke min. to reach max. blow energy (distance billet to upper die): min. 480 [mm] Max. die height without dovetails (incl. billet): 320 [mm] Min. die height without dovetails: 160 [mm] Daylight between guides: 580 [mm] Width of frame base: 2290 [mm] Depth of frame base: 1250 [mm] Frame weight: 24 [t] Total weight approx.: 32,5 [t] Total mass to be absorbed approx.: 33 [t] Moving mass approx.: 1350 [t] Height above floor level (assuming insert height 700 m) approx.: 4310 [mm] Total height approx.: 5000 [mm] Main motor capacity (with 400 V / 50Hz) ...

SINGLE SHAFT SHREDDER, 1.000 mm wide rotor, 370 mm diameter, adjustable counter-knife, off-set rotor bearings (low maintenance), V-Rotor with knife pockets, Welded knife holders with screwed knives and covered bold heads, Offset rotor bearings ( low-maintenance / closed ), Fast hydraulic backwards incl. different settings by PLC control and anti shock valve, Shredding room unpainted, Movable screen basket (electro-hydraulically), Screen thickness 10mm, Hydrodynamic starting clutch (energy saving system for machine start), Electromechanical drive with heavy duty gearbox, Control cabinet incl. 5m cable, Electrical control system Siemens S7 PLC control, Reverse counter and transmission limit switch (safety package), Star delta starter, Universal joints for piston with ram impulse and load-related ram function, Machine frame on anti - vibration foundation, Machine prepared for discharge by c ...

SINGLE SHAFT SHREDDER, V-rotor width 600 mm. diameter 260 mm, Rotor speed 80 - 125 rpm, Throughput rate 100-150 kg/h depending on material and screen, Drive power 22 kW, Max. number of knives 28 pcs 40 mm., screen size bespoke to project :15 to 40 mm, Hopper 600 x 800 mm, adjustable counter-knife, off-set rotor bearings (low maintenance), V-Rotor with knife pockets, Welded knife holders with screwed knives and covered bold heads, Offset rotor bearings ( low-maintenance / closed ), Fast hydraulic backwards incl. different settings by PLC control and anti shock valve, Shredding room unpainted, Movable screen basket (electro-hydraulically), Screen thickness 10mm, Hydrodynamic starting clutch (energy saving system for machine start), Electromechanical drive with heavy duty gearbox, Control cabinet incl. 5m cable, Electrical control system Siemens S7 PLC control, Reverse counter and transmiss ...

SINGLE SHAFT SHREDDER, V Rotor width 1.500 mm. Rotor diameter 500 mm 16.69″ Motor power 90 kW n.82 knives 60 x 60, adjustable counter-knife, off-set rotor bearings (low maintenance), V-Rotor with knife pockets, Welded knife holders with screwed knives and covered bold heads, Offset rotor bearings ( low-maintenance / closed ), Fast hydraulic backwards incl. different settings by PLC control and anti shock valve, Shredding room unpainted, Movable screen basket (electro-hydraulically), Screen thickness 10mm, Hydrodynamic starting clutch (energy saving system for machine start), Electromechanical drive with heavy duty gearbox, Control cabinet incl. 5m cable, Electrical control system Siemens S7 PLC control, Reverse counter and transmission limit switch (safety package), Star delta starter, Universal joints for piston with ram impulse and load-related ram function, Machine frame on anti - v ...

SINGLE SHAFT SHREDDER, V Rotor width 2.000 mm. 78,74 Rotor diameter 500 mm 16.69″ Motor power 90 kW n.112 knifes 60 x 60, adjustable counter-knife, off-set rotor bearings (low maintenance), V-Rotor with knife pockets, Welded knife holders with screwed knives and covered bold heads, Offset rotor bearings ( low-maintenance / closed ), Fast hydraulic backwards incl. different settings by PLC control and anti shock valve, Shredding room unpainted, Movable screen basket (electro-hydraulically), Screen thickness 10mm, Hydrodynamic starting clutch (energy saving system for machine start), Electromechanical drive with heavy duty gearbox, Control cabinet incl. 5m cable, Electrical control system Siemens S7 PLC control, Reverse counter and transmission limit switch (safety package), Star delta starter, Universal joints for piston with ram impulse and load-related ram function, Machine frame on  ...

SINGLE SHAFT SHREDDERS SPECIAL FOR PLASTIC SCRAPS, form 600 mm to 2.000 mm wide rotor., Adjustable counter-knives, off-set rotor bearings (low maintenance), V-Rotor with knife pockets, Welded knife holders with screwed knives and covered bold heads, Offset rotor bearings ( low-maintenance / closed ), Fast hydraulic backwards incl. different settings by PLC control and anti shock valve, Shredding room unpainted, Movable screen basket (electro-hydraulically), Screen thickness 10mm, Hydrodynamic starting clutch (energy saving system for machine start), Electromechanical drive with heavy duty gearbox, Reverse counter and transmission limit switch (safety package), Star delta starter, Universal joints for piston with ram impulse and load-related ram function, Machine frame on anti-vibration, Machine prepared for discharge by conveyor belt, Bolted and hardened rotor shaft on gear box side (ant ...

faceplate diameter:5000 mm swing diameter:5200 mm turning height:3000 mm max. turning diameter:5200 mm Travel of Ram (vertical):1500 mm Travel of ram (horiz.):+/- 2500 mm ram stroke speed:15000 mm/min cutting capacity:150000 Nm in X-/Z-Achse ram head dimension:400 x 400 mm CNC controller:Siemens/Fanuc/Fagor Rams:2 Stk. Scales:v. Heidenhain servo motors:Siemens/Fanuc/Fagor CNC controls from:Siemens/Fanuc/Fagor ATC:32/60/90 fach Chip Conveyor Coolant Tank Oil/Water Separator Machine Cover (High guarding) Heat exchanger For Electrical Cabinet Auto Lubrication for Guide way 4 Jaw Manual Chuck 1600mm Hydraulic Unit BT50 Tool Connection in RAM Metal frame and case in machine shipment packing(Wooden packing with metal base) 3 colors Warning Light Chamber light Anti- Dropping in Z axis -- Auto Motor Brake System Options Installed Air Conditioner For cabinet Coolant Through Spindle Filter for Coo ...

Pressure:080 t throat:380 mm stroke:8 - 112 mm no. of strokes:60 /min distance table/ram, max. stroke up, adjustment up:472 mm table surface area:840 x 610 mm table height over floor:800 mm passage to the back:520 mm ram surface:650 x 400 mm ram adjustment:70 mm power capacity:7,5 kW weight:6,9 t Dimensions (WxDxH):1,1 x 2,15 x 3,2 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:mechanical ram counterbalance:pneumatic clutch-/ brake combination:pneumatic

pressure:250 t throat:450 mm stroke:36 - 126 mm no. of strokes:40 /min distance table/ram, max. stroke up, adjustment up:525 mm table surface area:1000 x 750 mm hole in the table:400 x 360 mm table height over floor:1000 mm ram surface:600 x 500 mm ram adjustment:111 mm power requirement:19,0 kW weight:13,5 t Dimensions (WxDxH):1,3 x 3,2 x 3,35 m clutch:pneumatic overload protection in ram:mechanical ram adjustment:motoric

Pressure:250 t throat:450 mm stroke:8 - 135 mm no. of strokes:50 /min distance table/ram, max. stroke up, adjustment up:635 mm table surface area:1250 x 850 mm hole in the table:355 mm table height over floor:950 mm passage to the back:660 mm ram surface:790 x 610 mm ram adjustment:120 mm power requirement:18,5 kW weight:14,0 t Dimensions (WxDxH):1,5 x 2,8 x 3,65 m German Safety: permitted for manual loading:CE-Norm - EN 692, BGR 500 clutch:pneumatisch overload protection in ram:mechanisch ram counterbalance:pneumatisch

pressure:500 t distance between columns:2400 mm stroke:400 fix mm no. of strokes:13 - 23 /min Distance table/ram, max. stroke up, adjustment up:1600 mm table surface area:2300 x 1800 mm column travel -side:1600 mm ram surface:2170 x 1800 mm ram adjustment:300 mm total power requirement:110,0 kW Weight:135,0 t Dimensions (WxDxH):3,35 x 4,85 x 7,0 m clutch:pneumatic overload protection in ram:hydraulic ram adjustment:motoric

pressure:160 t distance between columns:2050/1900 mm stroke:15 - 170 mm no. of strokes:15 - 40 /min distance table/ram, max. stroke up, adjustment up:690 mm table surface area:1600 x 800 mm side window:800 mm ram surface:1620 x 700 mm ram adjustment:140 mm power requirement:15,0 kW weight:24,0 t Dimensions (WxDxH):3,3 x 2,3 x 5,3 m height over floor:4,8 m height beneath floor:0,5 m clutch:pneumatic ram adjustment:motoric ram counterbalance:pneumatic

Pressure:063 t throat:400 mm stroke:16 - 90 mm no. of strokes:60 /min distance table/ram, max. stroke up, adjustment up:350 mm table surface area:1000 x 750 mm hole in the table:260 x 140 mm table height over floor:710 mm ram surface:600 x 220 mm ram adjustment:50 mm weight:4,3 t dimensions (WxDxH):1,1 x 2,6 x 2,4 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatisch overload protection in ram:mechanisch ram counterbalance:pneumatisch

pressure:100 t throat:540 mm stroke:560 mm distance table/ram, max. stroke up, adjustment up:800 mm table surface area:1000 x 1000 mm pressure of drawing cushion in table:50 t stroke of drawing cushion in table:200 mm die cushion area:710 x 650 mm table height over floor:910 mm ram surface:1000 x 1000 mm capacity of ejector in ram:2 t ejector stroke in ram:200 mm return capacity:19,5 t speed down:400 mm/s speed up:300 mm/s working speed:57,7 mm/s oil volume:650 l power requirement:37,5 kW weight:15,0 t dimensions (WxDxH):1,5 x 2,5 x 4,45 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion / ejector in table:hydraulisch ejector in ram:hydraulisch depth stop:mechanisch

pressure:63 t throat:320 mm stroke:200 mm distance table/ram, max. stroke up, adjustment up:450 mm table surface area:750 x 600 mm pressure of drawing cushion in table:6,5 t stroke of drawing cushion in table:80 mm die cushion area:240 mm table height over floor:800 mm ram surface:500 x 450 mm capacity of ejector in ram:0,5 t ejector stroke in ram:70 mm speed down:300 mm/s speed up:300 mm/s working speed:50 mm/s oil volume:380 l power requirement:12,0 kW weight:6,5 t dimensions (WxDxH):1,3 x 2,0 x 2,75 m drawing cushion in table:hydraulic ejector in ram:hydraulic depth stop:mechanical cutting impact cushioning:hydraulic

pressure:100 t throat:315 mm stroke:30 - 160 mm no. of strokes:40 /min distance table/ram, max. stroke up, adjustment up:460 mm table surface area:910 x 680 mm Hole in the table:400 mm table height over floor:800 mm passage to the back:400 mm ram surface:630 x 400 mm ram adjustment:80 mm power requirement:7,5 kW weight:7,5 t dimensions (WxDxH):1,7 x 2,0 x 3,0 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic overload protection in ram:mechanical ram counterbalance:pneumatic

pressure:500 t distance between columns:3400 mm stroke:850 mm no. of strokes:9 - 18 /min distance table/ram, max. stroke up, adjustment up:2050 mm table surface area:3100 x 1900 mm table height over floor:400 mm side window:1550 mm ram surface:3100 x 1900 mm ram adjustment:350 mm pressure of drawing cushion in ram:70 t pressure of drawing cushion in table:140 t stroke of drawing cushion in table:0 - 250 mm stroke of drawing cushion in ram:150 mm height beneath floor:6,0 m height over floor:8,3 m weight:155,0 t dimensions (WxDxH):5,1 x 4,5 x 12,3 m Kind of drive:link drive tool changing unit:2 x

pressure:500 t distance between columns:3400 mm stroke:850 mm no. of strokes:9 - 18 /min distance table/ram, max. stroke up, adjustment up:2050 mm table surface area:3100 x 1900 mm table height over floor:400 mm side window:1550 mm ram surface:3100 x 1900 mm ram adjustment:350 mm pressure of drawing cushion in ram:70 t pressure of drawing cushion in table:140 t stroke of drawing cushion in table:0 - 250 mm stroke of drawing cushion in ram:150 mm height beneath floor:6,0 m height over floor:8,3 m weight:155,0 t dimensions (WxDxH):5,1 x 4,5 x 12,3 m Kind of drive:link drive tool changing unit:2 x

pressure:500 t distance between columns:3400 mm stroke:850 mm no. of strokes:9 - 18 /min distance table/ram, max. stroke up, adjustment up:2050 mm table surface area:3100 x 1900 mm table height over floor:400 mm side window:1550 mm ram surface:3100 x 1900 mm ram adjustment:350 mm pressure of drawing cushion in ram:70 t pressure of drawing cushion in table:140 t stroke of drawing cushion in table:0 - 250 mm stroke of drawing cushion in ram:150 mm height beneath floor:6,0 m height over floor:8,3 m weight:155,0 t dimensions (WxDxH):5,1 x 4,5 x 12,3 m Kind of drive:link drive tool changing unit:2 x

pressure:080 t throat:300 mm stroke:7 - 100 mm no. of strokes:120 /min distance table/ram, max. stroke up, adjustment up:450 mm table surface area:720 x 600 mm hole in the table:300 x 120 mm table height over floor:850 mm ram surface:400 x 275 mm ram adjustment:60 mm power requirement:5,5 kW weight:6,5 t dimensions (WxDxH):1,2 x 2,0 x 2,9 m German Safety: permitted for manual loading:CE-sign light guard:Sick clutch:hydraulic overload protection in ram:hydraulic ram adjustment:motoric stroke adjustment:automatic

pressure:160 t throat:690 mm stroke:8 - 180 mm no. of strokes:50 /min distance table/ram, max. stroke up, adjustment up:500 mm table surface area:1300 x 1000 mm hole in the table:400 / 120 mm table height over floor:850 mm passage to the back:900 mm ram surface:1000 x 700 mm ram adjustment:130 mm power requirement:11,0 kW weight:19,0 t dimensions (WxDxH):2,4 x 2,8 x 3,4 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch:pneumatic ram adjustment:motoric ram counterbalance:pneumatic

pressure:160 t throat:480 mm stroke fix:fix 180 mm no. of strokes:25 - 70 /min distance table/ram, max. stroke up, adjustment up:650 mm table surface area:1100 x 900 mm Hole in the table:450 mm table height over floor:900 mm passage to the back:700 mm ram surface:900 x 600 mm ram adjustment:144 mm power requirement:30,75 kW weight:15,3 t dimensions (WxDxH):2,0 x 2,4 x 3,75 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 clutch-/ brake combination:pneumatic, Desch overload protection in ram:hydraulic ram counterbalance:pneumatic

pressure:500 t distance between columns:1220 mm stroke:600 mm distance table/ram, max. stroke up, adjustment up:1000 mm table surface area:1600 x 1200 mm pressure of drawing cushion in table:320 t stroke of drawing cushion in table:150 mm drawing cushion surface in table:750 x 625 mm pressure of drawing cushion in ram:180 t stroke of drawing cushion in ram:100 mm drawing cushion area in ram:750 x 625 mm ram surface:1600 x 1200 mm table height over floor:800 mm speed down:665 mm/s speed up:530 mm/s working speed:34 - 100 mm/s quantity of oil:2000 l power requirement:180,0 kW weight:40,0 t Dimensions (WxDxH):3,2 x 2,4 x 7,5 m Depth of foundation pit:4,1 m Height above floor:5,55 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2

pressure:080 t throat:280 mm stroke:8 - 112 mm no. of strokes:30 - 120 /min distance table/ram, max. stroke up, adjustment up:500 mm table surface area:840 x 580 mm hole in the table:150 mm table height over floor:910 mm passage to the back:640 mm ram surface:560 x 300 mm ram adjustment:80 mm power requirement:7,5 kW weight:8,0 t dimensions (WxDxH):1,6 x 2,3 x 3,3 m German Safety: permitted for manual loading:UVV 11.062 - VBG 7n5.1 overload protection in ram:hydraulisch ram adjustment:motoric

pressure:200 t distance between columns:1400 mm stroke:300 mm distance table/ram, max. stroke up, adjustment up:500 mm table surface area:1300 x 1100 mm pressure of drawing cushion in table:80 t stroke of drawing cushion in table:150 mm die cushion area:700 x 700 mm capacity of ejector in ram:10 t ejector stroke in ram:50 mm table height over floor:930 mm side window:770 mm ram surface:1300 x 1100 mm speed down:400 mm/s speed up:410 mm/s working speed:20 - 50 mm/s return capacity:30 t oil volume:1350 l power requirement:70,0 kW weight:23,0 t dimensions (WxDxH):4,5 x 3,0 x 3,5 m German Safety: permitted for manual loading:UVV 11.064 - VBG 7n5.2 drawing cushion in table:hydraulic ejector in ram:hydraulic foundation pit:not necessary
